SAGEMCOM F@ST 2704R User manual
F@ST
2
7
04R
Reference
Manual
F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited Page 0-1
Sagemcom assiduously monitors technical developments and is constantly seeking to improve its products in
order to let its clients take full advantage of them. It therefore reserves the right to modify its documentation
accordingly without notice.
All brands mentioned in this guide are registered by their respective owners:
• F@ST is a registered trademark.
• Sagemcom is a registered trademark.
• WindowsTM and Internet ExplorerTM are registered trademarks of Microsoft Corporation.
The purpose of this reference manual is to give users the functions for operating and managing the equipment.
The only access level required (Administrator) is protected by a password and allows one to access these
functions in read and write mode for all the user and network parameters (Login: admin; password: etdm).
Note
Configuration of the router by HTTP is described in detail (cf. section 5).
To ease legibility of the reference manual, the term "router" will be used throughout the document to designate
F@ST 2704R equipment.
Guide
to
symbols used
in this
manual
Symbols
Definition
Note Gives you important informationwhich you must take into account.
Important
Warns you not to do an action, or commit a serious omission.
Page 0-2 F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited
How
should
the
document be
used?
This reference manual is organised into sections and annexes. These sections and annexes cover the
following subjects.
Section 1 Presentation of F@ST 2704R equipment
Section 2 Description of F@ST 2704R equipment
Section 3 Installation of F@ST 2704R equipment
Section 4 Configurationof network parameters
Section 5 Configurationof the router by HTTP
Section 6 Configuration of the advanced parameters
Section 7 Description of Internet access service
Section 8 Description of TV over ADSL service
Section 9 Updating the application
Annex A Troubleshooting
Annex 10 EC compliance declaration
Annex 11 Environment
Annex 12 Technical Characteristics
Annex 13 Default configuration
Annex B Glossary
Annex C Connector technology
F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited Page 0-3
Contents
Pages
Guide to symbols used in this manual 0-1
How should the document be used? 0-2
Contents 0-3
List of figures 0-7
1. Introduction 1-1
1.1 Presentation
.....................................................................................................................................
1-2
1.2 Composition of router pack
..............................................................................................................
1-4
1.3 (Minimum) prerequisites
...................................................................................................................
1-5
2. Description and connection of router 2-1
2.1 Description
.......................................................................................................................................
2-2
2.1.1 Connectors
..........................................................................................................................................
2-3
2.1.2 LEDs and buttons
................................................................................................................................
2-4
2.2 Connecting the ports of your router
..................................................................................................
2-6
2.3 Installation of your F@ST 2704R
.....................................................................................................
2-7
2.3.1 Powering up
.........................................................................................................................................
2-7
2.3.2 Connecting the ADSL cable .................................................................................................................2-7
2.3.3 Connecting to your computer ...............................................................................................................2-8
2.3.4 Connectingthe Ethernet interface of your router to your TV decoder ................................................. 2-9
2.3.5 Connecting the USB interface of your router ....................................................................................... 2-9
2.4 Installation safety instructions
........................................................................................................
2-10
3. Installing and configuring the F@ST 2704R router 3-1
4. Configuration of network parameters 4-1
4.1 Configuring as a DHCP client
...........................................................................................................
4-3
4.2 Status of the DHCP server
...............................................................................................................
4-4
4.3 Data of the DHCP client
...................................................................................................................
4-5
5. Information / Configuration 5-1
5.1 Accessing the welcome screen
........................................................................................................
5-2
5.2 Recommendations
...........................................................................................................................
5-4
5.3 ADSL connection status
...................................................................................................................
5-5
5.4 Display frame
...................................................................................................................................
5-5
Page 0-4 F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited
5.5 Basic parameters
.............................................................................................................................
5-6
5.5.1 My network
..........................................................................................................................................
5-6
5.5.2 Configuration
.......................................................................................................................................
5-9
5.5.3 Services
.............................................................................................................................................
5-13
5.5.4 Management
......................................................................................................................................
5-15
6. Advanced parameters 6-1
6.1 Accessing the advanced parameters
...............................................................................................
6-2
6.2 Device Info
.......................................................................................................................................
6-5
6.2.1 Summary
.............................................................................................................................................
6-5
6.2.2 WAN
....................................................................................................................................................
6-6
6.2.3 3G Status
.............................................................................................................................................
6-7
6.2.4 Statistics
..............................................................................................................................................
6-7
6.2.5 Route
.................................................................................................................................................
6-12
6.2.6 ARP
...................................................................................................................................................
6-13
6.2.7 DHCP
.................................................................................................................................................
6-14
6.3 Internet Connection
........................................................................................................................
6-15
6.4 Advanced Setup
.............................................................................................................................
6-16
6.4.1 Layer2 Interface
.................................................................................................................................
6-17
6.4.2 WAN Service
.....................................................................................................................................
6-22
6.4.3 3G Config
...........................................................................................................................................
6-46
6.4.4 LAN
....................................................................................................................................................
6-47
6.4.5 NAT
....................................................................................................................................................
6-50
6.4.6 Security
..............................................................................................................................................
6-57
6.4.7 Parental Control
.................................................................................................................................
6-63
6.4.8 Quality of Service
...............................................................................................................................
6-66
6.4.9 Routing
..............................................................................................................................................
6-74
6.4.10 DNS
...................................................................................................................................................
6-79
6.4.11 DSL
....................................................................................................................................................
6-82
6.4.12 Upnp
..................................................................................................................................................
6-85
6.4.13 DNS Proxy
.........................................................................................................................................
6-86
6.4.14 Interface Grouping .............................................................................................................................6-87
6.4.15 Certificate
...........................................................................................................................................
6-90
6.4.16 Power Management ...........................................................................................................................6-94
6.4.17 Multicast
.............................................................................................................................................
6-95
6.5 Wireless
..........................................................................................................................................
6-97
6.5.1 Basic
..................................................................................................................................................
6-97
6.5.2 Security
............................................................................................................................................
6-100
6.5.3 MAC Filter
........................................................................................................................................
6-112
6.5.4 Advanced
.........................................................................................................................................
6-114
6.5.5 Station Info
.......................................................................................................................................
6-118
6.6 Multimedia
....................................................................................................................................
6-119
6.6.1 Print Server
......................................................................................................................................
6-119
F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited Page 0-5
6.6.2 Storage Service
...............................................................................................................................
6-120
6.7 Diagnostics
...................................................................................................................................
6-121
6.8 Management
................................................................................................................................
6-122
6.8.1 Settings
............................................................................................................................................
6-122
6.8.2 System Log
......................................................................................................................................
6-127
6.8.3 Security Log
.....................................................................................................................................
6-130
6.8.4 TR-069 Client
...................................................................................................................................
6-131
6.8.5 Access Control
.................................................................................................................................
6-132
6.8.6 Update Software ..............................................................................................................................6-133
6.8.7 System Info
......................................................................................................................................
6-134
6.8.8 Reboot
.............................................................................................................................................
6-135
7. Internet access service 7-1
8. TV over ADSL service 8-1
8.1 Introduction
.......................................................................................................................................
8-2
8.2 Access to the optional TV over ADSL service ..................................................................................8-2
9. Updating the firmware 9-1
10. Annex 10 - Warnings for safety 10-1
10.1Warnings for safety
........................................................................................................................
10-2
10.1.1 Safety levels in relation to the case ................................................................................................... 10-2
10.2EC compliance declaration
............................................................................................................
10-2
11. Annex 11 - Environment 11-1
11.1Directive E 2002/96/CE
.................................................................................................................
11-2
12. Annex 12 - Technical Characteristics 12-1
12.1Mechanics;Display
........................................................................................................................
12-2
12.2Characteristicsof the different interfaces
......................................................................................
12-3
12.3Environmentalcharacteristics
........................................................................................................
12-5
12.4Applicationand protocols
...............................................................................................................
12-6
13. Annex 13 - Default configuration 13-1
13.1Default username and password
...................................................................................................
13-2
13.2Default configuration for the local network(LAN) ...........................................................................13-2
13.3Default configurationfor the local wireless network (WLAN) ......................................................... 13-2
A. Annex A - Troubleshooting A-1
A.1 Checking the assignment of an IP address
......................................................................................
A-2
A.2 Front panel LEDs
.............................................................................................................................
A-3
A.3 Supervising your router
....................................................................................................................
A-4
A.4 Diagnosticstool
................................................................................................................................
A-5
A.5 Interpretingthe LEDs
.......................................................................................................................
A-6
A.5.1 The "ADSL" LED blinks slowly
.............................................................................................................
A-6
Page 0-6 F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited
A.5.2 "Wi-Fi" LED off
.....................................................................................................................................
A-6
A.5.3 All LEDs are off
....................................................................................................................................
A-6
A.6 Restarting your router
.......................................................................................................................
A-7
A.7 Resetting factory configuration
.........................................................................................................
A-7
A.8 Offline mode
.....................................................................................................................................
A-8
B. Annex B - Glossary B-1
C. Annex C - Connector Technology C-1
C.1 Pinouts of the LINE connector ......................................................................................................... C-2
C.2 Pinouts of the PWR connector ........................................................................................................ C-2
C.3 Pinouts of the LAN1, LAN2, LAN3 and LAN4 connectors ............................................................... C-3
F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited Page 0-7
List of
figures
Figure 1.1 - Home Network Overview
...............................................................................................................
1-2
Figure 2.1 - Overview of case
...........................................................................................................................
2-2
Figure 2.2 - Interconnectionof ports of F@ST 2704R
......................................................................................
2-6
Figure 2.3 - ADSL line / Power Supply Connection
...........................................................................................
2-7
Figure 2.4 - USB Interface Connection
.............................................................................................................
2-9
Page
0-8
F@ST 2704R Reference
M
an
u
a
l
-
253526032
-
A
Sagemcom
Broadband SAS
document. Reproduction
and
disclosureprohibited
F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited Page 1-9
1. Introduction
• presentationof the F@ST 2704R router § 1.1
• composition of the packaging § 1.2
This section covers
• required hardware and software § 1.3
1- Introduction
Page 1-2 F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited
1.1 Presentation
This reference manual is dedicated to the F@ST 2704R equipment. This equipment is a router which gives
users broadband Internet access from their computer or their game console by various Ethernet (10 or 100
BASE-T) or Wi-Fi (IEEE 802.11n) interfaces via an ADSL/ADSL2/ ADSL2+ network.
Using these interfaces,this router enablesyou both to surf the Internet and to watch television.It also allows
give phone calls over the Internet from an IP SIP telephone linked by Wi-Fi to your router.
Important
F@ST 2704R products adapt the ADSL function respectively for POTS (UIT
G.992.1/3/5 - Annex A) and for ISDN (UIT G.992.1/3/5 - Annex B).
Figure 1.1 - Home Network Overview
1- Introduction
F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited Page 1-
Its principal characteristics and functions are as follows:
• High-performance secure Bridge/Router with ADSL/ADSL2/ADSL2+and Fast Ethernet (for FTTH)
interfaces,
• User access:
- 4 x 10/100BT Ethernet ports,
- 1 Wi-Fi interface (802.11n),
- 1 USB 2.0.,
- HSDPA backup,
- Samba server,
- DLNA server v 1.5 (option).
• DHCP Client/Server/Relay,
• DNS Server/Relay,
• Access control
(FTP/TELNET/HTTP/SSH
Client),
• NAT/PAT router - FTP Compatibility, IRC, Net2Phone, Netbios, DNS, Netmeeting, VPN passthrough
(IPSec, IKE, PPTP, L2TP), CUSeeMe,RealAudio, Microsoft IM and others,
• Security,
• Firewall,
• Spanning tree,
• Multi-VC ATM and ATM Quality of service (CBR, UBR, VBR),
• UPnP,
• TR069,
• QoS,
• Upgrade Firmware (Local and Remote),
• Backup/Restoreand Upgrade configurationfile (Local and Remote).
1- Introduction
Page
1-
4
F@ST 2704R Reference
M
an
u
a
l
-
253526032
-
A
Sagemcom
Broadband SAS
document. Reproduction
and
disclosureprohibited
1.2
C
o
mposition
of router pack
The router pack is composed of the following elements (present content may vary):
Item
Description
1
F@ST 2704R router
2
Mains adapter
3
ADSL RJ11/11 FDT line cable (length = 3 m) used to connect your router to your telephone line
4
Ethernet RJ45/RJ45 cable (length = 1.75 m) used to connect your router to the Ethernet port of
your computer
5
Quick Installation Guide
6
Filter/Splitter used to connect one phone set and your router to your telephone line*
7
Microfilter used to connect another phone set to your telephone line*
* Option depending on pack content requested
1- Introduction
F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited Page 1-5
1.3 (Minimum)
prerequisit
es
Using a router requires a minimum of:
• a computer equipped with:
- a Wi-Fi 802.11n
interface,
or - an Ethernet interface (10BASE-T or 10/100BASE-T).
• a WEB browser (Internet Explorer version 5 or higher recommended).
The minimum configuration of your computer must be:
• for Windows: Pentium II, 400 MHz, RAM: 128 MB,
• for MacOS: Power PC G3, 233 MHz, RAM: 128 MB,
• a monitor of minimum resolution: 1024 x 768.
Note
Before installing the router, we advise you to uninstall any modem or other router
(for example, an ADSL router).
Page
1-
6
F@ST 2704R Reference
M
an
u
a
l
-
253526032
-
A
Sagemcom
Broadband SAS
document. Reproduction
and
disclosureprohibited
1-
Introduction
F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited Page 2-1
2.
Description and connection
of router
• the descriptionof your router § 2.1
• connecting the ports of your router § 2.2
• installing your router § 2.3
This section covers
• installation safety instructions § 2.4
Page 2-2 F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited
2-
Description and connection
of route
r
2.1 Description
The following figure gives an overview of a router F@ST 2704R.
Figure 2.1 - Overview of
case
This case consists principally of a lid and a base. Inside is a printed circuit equipped with electronic
components.
The front face of the lid has ten display LEDs (see § 2.1.2).
The base has the LED ideogramsand the manufacturer logo.
Behindthe base is a label on whichthe product's identificationcode, serial number and barcodeare shown.
F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited Page 2-3
2-
Description and connection
of router
2.1.1
C
onnectors
Marking
Meaning
LINE RJ11 connector - 6 pts. This connector is identified by the colour grey.
It is used for the connection to an ADSL line (WAN interface).
LAN x
(1 to 4)
RJ45 connectors - 8 pts (10/100BASE-T Ethernet Interface). These connectors are
identified by the colour yellow.
They are used to connect to a computer or a television set (via a TV/Video Decoder).
USB USB connector.
Power
Miniature jack fixed connector.
This connector enables the router to be supplied with direct current from a mains
adapter unit.
Page 2-4 F@ST 2704R Reference Manual - 253526032-A
Sagemcom Broadband SAS document.Reproduction and disclosure prohibited
2-
Description and connection
of route
r
2.1.2
LEDs and
buttons
2.1.2.1 On the front panel
The following table describes the meaning of the LEDs on the front panel of the router:
LED
Status
Meaning
Off Power Off
Green Power On
Power Red Router in rescue mode
Green steady ADSL Up
ADSL
Green blinking • ADSL Synchronisationin progress
or
• down
Off
• Power Off
or
• The Internet account must be configured
or
• Bridge mode
Green steady The Internet account is configured
Green blinking Tx/Rx traffic
Internet
Red Invalid or unauthorised Internet account
Off No link detected on the Ethernet port
Green steady Ethernet port has detected a link with 100 Mbps device
LAN x
(1 to 4)Green blinking Tx/Rx traffic at 100 Mbps
Off Wi-Fi deactivated
Green steady Wi-Fi activated
WLAN Green blinking Wi-Fi Tx/Rx
Table of contents
Other SAGEMCOM Wireless Router manuals
