SALICE Shelf F70 User manual

UNITED
STATES
•
CANADA
Shelf F70

2

Index
Technical information page 5
Part number composition and packaging page 7
Locking devices page 8
Adjustments page 9
Accessories
Lock-open function for runners and drawers page 22
Rear hook bracket page 23
Shelf F70 Push
G7E6Q Concealed runner - full-extension page 14
Shelf F70 Smove
G7E6R Concealed runner - full-extension page 18
3

The Shelf F70 runners are for pull out shelves that are attached to the bottom of the cabinet and can be used in various market
segments such as: kitchen cabinets, store xtures, ofce furniture and living room furniture.
The runners enable the shelves to slide out for easy access.
The runners are full extension and are available with either Smove soft closing or with Push, the opening system for handle-less
shelves.
Shelf F70 - Runner for pull-out shelves
4

Plan view - Full-extension
Technical information
Dimensions
With larger shelves, it is possible to increase the number of runners, in order to improve the load capacity and the stability
of the shelf.
8
Y1 = Min. 50
350 : X = 305
400 : X = 305
450 : X = 320
500 : X = 382.5
2
Y2 = Min. 40
300
Y1 = Min. 50
28.5
Y1 = Min. 50 Y1 = Min. 50
Y2 = Min. 40
Y2 = Min. 40
5

Min. 12
1620
8
A
LN - 20
(Y1-A)+17
Min. 12
1620
8
A
LN - 20
(Y1-A)+17
Min. 16
A
LN - 10
11
7
ø 6x10
(Y1-A)+8
Min. 16
A
LN - 10
11
7
ø 6x10
(Y1-A)+8
Assembly on the pull-out shelf with a 12-mm minimum thickness
Rear hook bracket
Assembly on the pull-out shelf with a 16-mm minimum thickness
Shelf F70 - Rear hook - Technical information
Y1 = Min. 50 mm
Y1 = Min. 50 mm
6

Packaging
Part number composition
SMOVE LENGTH BOX PALLET
G7E6R350XXF6 350 mm 6 prs 192 prs
G7E6R400XXF6 400 mm 6 prs 192 prs
G7E6R450XXF6 450 mm 6 prs 192 prs
G7E6R500XXF6 500 mm 6 prs 192 prs
PUSH LENGTH BOX PALLET
G7E6Q350XXF6 350 mm 6 prs 192 prs
G7E6Q400XXF6 400 mm 6 prs 192 prs
G7E6Q450XXF6 450 mm 6 prs 192 prs
G7E6Q500XXF6 500 mm 6 prs 192 prs
CLIP BOX
Right clips
BOX
Left clips
PALLET
Right clips PALLET
Left clips
AFCGXX3B 100 pcs. 100 pcs. 2400 pcs. 2400 pcs.
ARTICLE VERSIONS
Q = PUSH
R = SMOVE
Example:
G7E6 _ ___ XXF6
BASIC PART NUMBER
RUNNER LENGTH
(350 - 400 - 450 - 500 mm)
7

Y1 = Min. 50 mm
AFCGXX3B
Right and left clip with
integrated adjustments
PACKAGING
2 boxes = 100 pcs right and 100 pcs left
Dimension of the clip and drilling position
Shelf F70 - Locking devices
- Dual metal/plastic construction
- For all F70 runner versions
- Integrated tool-free side and depth adjustments
- Pre-drilling recommended ø 2.5 mm (3/32'')
- Assembly to the bottom or to the drawer front
Assembly to the bottom Assembly to the drawer front
Fix with screws
as indicated
(recommended
# 6 x 5/8”)
Fix with screws
as indicated
(recommended
# 6 x 5/8”)
Y1
23
23
51
1
7
A (Y1-A) + 52 8
8

Rotate the white wheel (see drawing) towards the front of the drawer to adjust left.
This operation is tool free.
For side adjustment, it is recommended that both the adjusters on the clips are in the same direction, in order to maintain the correct alignment
and function of the runners.
Side adjustment +/- 1.5 mm
Rotate the white wheel (see drawing) towards the back of the drawer to adjust right.
This operation is tool free.
1.5 mm
1.5 mm
9

Depth adjustment +/- 3 mm
Rotate the white wheel (see drawing) towards the outside of the drawer to increase the gap between the front and the
side. This operation is tool free.
Rotate the white wheel (see drawing) towards the inside of the drawer to reduce the gap between the front and the
side. This operation is tool free.
+ 3 mm
- 3 mm
10

Height adjustment + 2.5 mm
Press the lever towards the back of the drawer to achieve the height adjustment.
This operation is tool free.
+
-
=
=
2.5 mm
11

Position hands under the front of the shelf and press on the orange levers, as indicated in the drawing, sliding
the shelf out of the cabinet.
Shelf removal
2 2
1 1
12

Shelf F70 Push
13

Shelf F70 Push G7E6Q - Concealed runner
Full-extension runner attached to the shelf by clips.
Push: the opening system for handle-less drawers is fully
integrated in the runner. A slight pressure of the drawer front
is enough for the drawer to open.
Product features
- 170 Lbs Static load capacity / 154 Lbs Dynamic load capacity
- Full extension with a synchronized mechanism
- Available in 14'' to 20'' length
- Integrated Push opening system
- Safety system that prevents the shelves from turning over
- Tool free height adjustments +2.5 mm
- Tool free depth adjustments +/- 3 mm
- Tool free side adjustments +/- 1.5 mm
- The shelf is held in the closed position
- Finish: bright zinc-plated
- 100% Made in Italy
28.5
Y1 = Min. 50 Y1 = Min. 50
Y2 = Min. 40
Y2 = Min. 40
Dimensions
14

Locking device
AFCGXX3B
Tool free
height adjustments + 2.5 mm,
depth adjustments +/- 3 mm,
side adjustments +/- 1.5 mm
Packaging:
2 boxes = 100 pcs right and
100 pcs left
Ordering information
To be screw xed
Screw TSP ø 3.5 mm
BASIC PART NUMBER RUNNER LENGTH
(LN)
MIN. CABINET DEPTH
(PM)
PACKAGING
G7E6Q350XXF6 350 360 6 pairs
G7E6Q400XXF6 400 410 6 pairs
G7E6Q450XXF6 450 460 6 pairs
G7E6Q500XXF6 500 510 6 pairs
Rear hook bracket
AGAPXXYI
Packaging:
1 box = 100 pcs
15

16

Shelf F70 Smove
17

Full-extension runner attached to the shelf by clips.
Smove: soft closing mechanism, fully integrated into the drawer
runner.
Product features
- 170 Lbs Static load capacity / 154 Lbs Dynamic load capacity
- Full extension with a synchronized mechanism
- Available in 14'' to 20'' length
- Enhanced smooth soft closing action
- Safety system that prevents the shelves from turning over
- Tool free height adjustments +2.5 mm
- Tool free depth adjustments +/- 3 mm
- Tool free side adjustments +/- 1.5 mm
- Finish: bright zinc-plated
- 100% Made in Italy
Shelf F70 Smove G7E6R - Concealed runner
Dimensions
28.5
Y1 = Min. 50 Y1 = Min. 50
Y2 = Min. 40
Y2 = Min. 40
18

Locking device
AFCGXX3B
Tool free
height adjustments + 2.5 mm,
depth adjustments +/- 3 mm,
side adjustments +/- 1.5 mm
Packaging:
2 boxes = 100 pcs right and
100 pcs left
Rear hook bracket
AGAPXXYI
Packaging:
1 box = 100 pcs
BASIC PART NUMBER RUNNER LENGTH
(LN)
MIN. CABINET DEPTH
(PM)
PACKAGING
G7E6R350XXF6 350 360 6 pairs
G7E6R400XXF6 400 410 6 pairs
G7E6R450XXF6 450 460 6 pairs
G7E6R500XXF6 500 510 6 pairs
To be screw xed
Screw TSP ø 3.5 mm
Ordering information
19
