Salicru SLC ADAPT2 Series User manual

SLC ADAPT2
UNINTERRUPTIBLE POWER SUPPLY
USER MANUAL

2SALICRU
General index
1. INTRODUCTION.
1.1. THANK YOU LETTER.
2. SAFETY INFORMATION.
2.1. USING THIS MANUAL.
2.1.1. Conventions and symbols used.
2.1.2. Safety considerations.
3. QUALITY ASSURANCE AND STANDARDS.
3.1. STATEMENT BY THE MANAGEMENT.
3.2. STANDARDS.
3.2.1. First and second environment.
3.2.1.1. First environment.
3.2.1.2. Second environment.
3.3. ENVIRONMENT.
4. PRESENTATION.
4.1. VIEWS OF THE CABINETS.
4.1.1. UPS cabinet
4.1.2. Battery cabinets
4.2. DEFINITION OF THE PRODUCT.
4.2.1. UPS and battery module nomenclature.
4.3. GENERAL DESCRIPTION.
4.3.1. Introduction.
4.3.2. Architecture.
4.3.2.1. Structural diagram.
4.3.2.2. Parallel system.
4.3.2.3. Sleep operating mode.
4.3.3. Operating statuses.
4.3.3.1. Normal status.
4.3.3.2. Battery status.
4.3.3.3. Bypass state.
4.3.3.4. Manual Bypass status (external or optional).
4.3.3.5. Status - ECO mode.
4.3.3.6. Status - Frequency converter (CF) mode.
4.3.4. Battery management (factory default settings).
4.3.4.1. Basic functions.
4.3.4.2. Advanced functions.
5. INSTALLATION.
5.1. RECEPTION.
5.1.1. Reception, unpacking and contents.
5.1.2. Storage.
5.1.3. Unpacking.
5.1.4. Transport to the site.
5.2. LOCATION.
5.2.1. Location of the ADAPT2.
5.2.2. Room for the batteries.
5.3. ENTRY FOR THE CONNECTION CABLES.
5.4. PROTECTIVE DEVICES AND CROSS-SECTIONS OF THE
CONNECTION CABLES.
5.4.1. Input, bypass and output.
5.4.2. Battery installation and maintenance.
5.4.2.1. General recommendations.
5.4.2.2. Installing the batteries. Preliminary considerations before
connecting them and their protections.
5.4.3. Access to the interior of the cabinet for its connection.
5.5. CONNECTIONS.
5.5.1. Connecting the device to the mains.
5.5.2. Independent static bypass line connection. In version B
only.
5.5.3. Output connection, terminals.
5.5.4. Connection of the battery terminals of the device with
those of the battery module.
5.5.5. Earth terminal connection.
5.5.6. Parallel connection.
5.5.6.1. Parallel bus connection.
5.5.7. Interface and communications.
5.5.7.1. Digital inputs, dry contacts and communications.
5.5.7.2. Installation of the SNMP card (Nimbus Services).
6. OPERATION.
6.1. INTRODUCTION.
6.2. STARTING UP THE UPS.
6.2.1. Checks before start-up.
6.2.2. First Start-up.
6.3. OPERATIONS OF THE MANUAL BYPASS SWITCH
(MAINTENANCE).
6.3.1. Procedure to switch from normal mode to maintenance
bypass mode.

3
6.3.2. Procedure to switch from maintenance bypass mode to
normal mode.
6.4. EPO PUSH BUTTON (EMERGENCY STOP). PROCEDURE.
6.4.1. Complete stop of the UPS, with EPO.
6.4.2. UPS restart after full stop with EPO.
6.5. AUTOMATIC RESTART.
6.6. OPERATING INSTRUCTIONS FOR MAINTENANCE OF
POWER MODULES.
6.6.1. Maintenance guide for power modules.
6.6.1.1. With the system operating in normal mode and the
normal bypass voltage and frequency, with at least 1
power module as redundant:
6.6.1.2. No power modules operating as redundant:
6.7. OPERATING INSTRUCTIONS FOR MAINTENANCE OF THE
BYPASS AND MONITORING MODULE.
6.7.1.1. With the system operating in Normal Mode and normal
bypass voltage and frequency, transfer the load over the
manual bypass.
6.8. LANGUAGE SELECTION.
6.9. CHANGING THE CURRENT DATE AND TIME
6.10. LEVEL CONTROL PASSWORD.
7. MONITORING PANEL WITH LCD TOUCH
SCREEN.
7.1. INTRODUCTION.
7.2. FUNCTIONS OF THE RGB LEDS.
7.3. ACOUSTIC ALARM.
7.4. DESCRIPTION OF THE SCREENS SHOWN ON THE LCD
TOUCH SCREEN.
7.4.1. Start menu or main screen.
7.4.1.1. Access to menus and sub-menus from the Main screen.
7.4.1.2. Information content of the Main Screen.
7.4.1.3. Map of screens accessible from the Main Screen.
7.4.2. Measurements menu.
7.4.3. UPS alarms menu.
7.4.4. Status & Ops menu.
7.4.5. Rated values menu.
7.4.6. Charts menu.
7.4.7. Advanced menu
7.4.8. Other screens
7.5. TABLES OF ALARMS, WARNINGS AND EVENTS.
7.5.1. Table of UPS Alarms.
7.5.2. Table of UPS Warnings
7.5.3. UPS Events list
8. OPTIONS
8.1. INTERNAL MANUAL BYPASS.
8.2. AMBIENT TEMPERATURE SENSOR.
9. WARRANTY.
9.1. WARRANTY CONDITIONS.
9.1.1. Terms of the warranty.
9.1.2. Exclusions.
9.2. TECHNICAL SERVICES NETWORK.
10. GENERAL TECHNICAL FEATURES.
10.1. INTERNATIONAL STANDARDS.
10.2. ENVIRONMENTAL CHARACTERISTICS.
10.3. MECHANICAL CHARACTERISTICS.
10.4. ELECTRICAL CHARACTERISTICS.
10.4.1. Electrical characteristics (rectifier input).
10.4.2. Electrical characteristics (DC Bus).
10.4.3. Electrical characteristics (Inverter output).
10.4.4. Electrical characteristics (Bypass input).
10.4.5. Communications.
10.5. EFFICIENCY.
11. ANNEXES.
11.1. ANNEX I: CONNECTION CONFIGURATION FOR SINGLE
MAINS SUPPLY TO RECTIFIER-PFC - STATIC BYPASS.
11.2. ANNEX II. CONNECTIVITY.
11.2.1. Registering the device in the cloud
11.2.1.1. Nimbus portal.
11.2.1.2. Create account
11.2.1.3. Log in
11.2.1.4. Adding a device
11.2.1.5. Using a QR code
11.2.1.6. Log in
11.2.1.7. Adding the device
11.2.2. General technical specifications
12. GLOSSARY
SLC ADAPT 2 - UNINTERRUPTIBLE POWER SUPPLY SYSTEM -USER MANUAL

4SALICRU
SALICRU
1. INTRODUCTION.
1.1. THANK YOU LETTER.
We thank you in advance for the trust placed in us in the pur-
chasing of this product. Read this instruction manual carefully in
order to familiarise yourself with its content, since the more you
know and understand the device the greater your satisfaction,
level of safety and optimisation of its functionalities will be.
Do not hesitate to contact us for any additional information or
queries that you may wish to make.
Yours sincerely.
•The device described here is capable of causing sig-
nificant physical injury if improperly handled. For this
reason, its installation, maintenance and/or repair must be
carried out exclusively by our staff or by qualified per-
sonnel.
•Although no effort has been spared to ensure that the in-
formation in this user manual is complete and accurate, we
accept no liability for any errors or omissions that may exist.
The images included in this document are for illustrative
purposes and may not exactly represent the parts of the
device shown; therefore they are not contractual. However,
any divergence that may arise will be remedied or solved
with the correct labelling on the unit.
•Following our policy of constant evolution, we reserve the
right to modify the characteristics, operations or ac-
tions described in this document without prior notice.
Consequently, the contents of this manual may differ from
the latest version available on our website. Check that you
have the latest version of the document (listed on the back
cover, on the logo of our brand) and download it from the
website.
•Any reproduction, copying, assignment to third par-
ties, amendment or total or partial translation of this
manual or document, in any form or by any means, without
the prior written permission of Salicru is prohibited,
with the company fully and exclusively reserving its owner-
ship rights over it.

5
2. SAFETY INFORMATION.
2.1. USING THIS MANUAL.
The latest version of the device’s user manual is available toThe latest version of the device’s user manual is available to
the customer for download on our websitethe customer for download on our website (www.salicru.(www.salicru.
com)com). It is necessary to read it carefully before performing any. It is necessary to read it carefully before performing any
actions, procedures or operations on it.actions, procedures or operations on it.
The purpose of the user manual is to provide information aboutThe purpose of the user manual is to provide information about
safety and the procedures for device installation and operation.safety and the procedures for device installation and operation.
Read them carefully and follow the steps indicated in the orderRead them carefully and follow the steps indicated in the order
established.established.
The “Safety Instructions” document EK266*08 is sup-
plied with this device. Compliance with these instruc-
tions is obligatory, with the user being legally
responsible for observing and applying them.
The device is delivered properly labelled for correct identifica-
tion of each of its parts, which, together with the instructions
described in this user manual, allows installation and start-up
operations to be performed in a simple and organised manner
without any doubts whatsoever.
However, because the product is constantly evolving,
discrepancies or slight contradictions may arise. If in
any doubt, the labelling on the device itself will always
prevail.
Once the device is installed and operating, it is recommended
to keep all of the documentation in a secure place for future
reference.
This user manual applies to the SLC ADAPT 2, series con-
sisting of cabinets with 24, 33 and 42U of height and with 10
and 15 kVA modules, with the following configurations:
•24U cabinets: with 2 or 4 slots that allow them to hold up
to 4 x 10kVA modules or 3 x 15kVA modules (*).
•33U cabinets: with 2, 4 or 6 slots that allow them to hold
up to 6 x 10kVA modules or 6 x 15kVA modules (*).
•42U cabinets: with 2, 4 or 6 slots that allow them to hold
up to 6 x 10kVA modules or 6 x 15kVA modules (*).
(*) 10kVA modules: degrade to 6kVA/FPout = 1.
(*) 15kVA modules: degrade to 9kVA/FPout = 1 when
operating with a three-phase input of 3x220V or 3x208V.
The housings are 19” rack cabinets, which may or may not
share the space with the batteries.
While the customer can perform these adaptations on their
own or otherwise, we can also manufacture any configuration
on demand.
When a system differs from that shown in the figures in
Chapter , except when it differs in the number of mod-
ules connected in parallel and/or the technical specifi-
cations are modified, additional explanatory annexes
will be published if deemed appropriate or necessary.
These will be supplied in printed format with the device.
The following terms are used interchangeably in the document
to refer to:
•‘SLC ADAPT 2, ADAPT 2, UPS, system, device or
unit’.- ADAPT2 series of Uninterruptible Power Supplies.
Depending on the context of the phrase, it can refer either
to the actual UPS itself or to the UPS and the batteries,
regardless of whether or not it is all assembled in the same
metal enclosure.
•‘Batteries’ or ‘accumulators’.- Bank or set of elements
for storing the flow of electrons by electrochemical means.
•‘T.S.S.’.- Technical Service and Support.
•‘Customer’, ‘installer,’ ‘operator’ or ‘user’.- These are
used interchangeably, and by extension can refer to the in-
staller and/or operator who will carry out the corresponding
actions, while this same person may be responsible for car-
rying out the respective actions when acting on behalf or in
representation of the first.
2.1.1. Conventions and symbols used.
Some symbols may be used and appear on the device, batteries
and/or in the context of the user manual.
For more information, see Section 1.1.1 of the ‘Safety Instruc-
tions’ document EK266*08.
In the event that there are differences in relation to the safety
instructions between document EK266*08 and the user's
manual of the device, the latter will always prevail.
2.1.2. Safety considerations.
•While safety-related considerations will be dealt with in
more detail in Chapter , the following must be taken into
account:
Inside the battery cabinet there are accessible parts with
HAZARDOUS VOLTAGE and consequently risk of electric
shock, so they are classified as RESTRICTED ACCESS
ZONES. Therefore, the key of the battery cabinet will
not be available to the OPERATOR or USER, unless such
person has been properly instructed.
In case of intervention inside the battery cabinet either
during the connection, preventive maintenance or re-
pair procedures, it must be taken into account that the
voltage of the battery set exceeds 200 V DC, so
appropriate safety measures must be taken.
Any operation of connecting and disconnecting the ca-
bles or handling inside a cabinet will not take place for
around 10 minutes in order to allow the internal dis-
charge of the capacitors of the device. Even so, check
with a multimeter that the voltage at terminals is less
than 36 V.
In case of installation in neutral IT mode, the switches,
circuit breakers and thermal magnetic protection must
cut the NEUTRAL in addition to the three phases.
SLC ADAPT 2 - UNINTERRUPTIBLE POWER SUPPLY SYSTEM -USER MANUAL

6SALICRU
3. QUALITY ASSURANCE AND STANDARDS.
3.1. STATEMENT BY THE MANAGEMENT.
Our goal is customer satisfaction, therefore this Management
has decided to establish a Quality and Environment Policy,
through the implementation of a Quality and Environmental
Management System that will enable us to comply with the re-
quirements demanded in the ISO 9001 and ISO 14001 standards
and by our Customers and Stakeholders.
Likewise, the management of the company is committed to the
development and improvement of the Quality and Environmental
Management System, through:
•Communication to the entire company of the importance
of satisfying both the customer's requirements as well as
legal and regulatory requirements.
•The dissemination of the Quality and Environment Policy
and the setting of the Quality and Environment objectives.
•Conducting reviews by the Management.
•Providing the necessary resources.
3.2. STANDARDS.
The SLC ADAPT 2 is designed, manufactured and sold in ac-
cordance with Quality Assurance Standard ENISO9001. The
marking indicates conformity with EC Directives through
the application of the following standards:
•2014/35/EU. - Low voltage safety.
•2014/30/EU. - Electromagnetic Compatibility (EMC).
•2011/65/EU. - Restriction of the use of hazardous substances
in electrical and electronic equipment (RoHS).
In accordance with the specifications of the harmonised standards.
Reference standards:
•EN-IEC 62040-1. Uninterruptible power supplies (UPS).
Part 1-1: General and safety requirements for UPS used in
user access areas.
•EN-IEC 62040-2. Uninterruptible power supplies (UPS).
Part 2: EMC requirements.
The manufacturer is not liable in the event of modifica-
tion or intervention on the device by the user.
WARNING:
This is a category C3 UPS. This is a product for com-
mercial and industrial application in the second environ-
ment; Installation restrictions or additional measures
may be necessary to avoid disturbances.
It is not appropriate to use this device in basic life sup-
port applications (BLS), where a failure of the former
can render vital equipment out of service or significantly
affect its safety or effectiveness. It is also not recom-
mended in medical applications, commercial transport,
nuclear installations, or other applications or loads,
where a failure of the product can lead to personal or
material damage.
The EC declaration of conformity of the product is avail-
able to the customer upon express request to our offices.
3.2.1. First and second environment.
The environment examples that follow cover most UPS instal-
lations.
3.2.1.1. First environment.
Environment including residential, commercial and light in-
dustry installations, directly connected, without intermediate
transformers, to a low voltage public power grid.
3.2.1.2. Second environment.
An environment that includes all commercial, light industrial and
industrial establishments that are not directly connected to a
low voltage power grid supplying buildings used for residential
purposes.
3.3. ENVIRONMENT.
This product has been designed to respect the environment and
has been manufactured in accordance with ISO14001.
Recycling of the device at the end of its useful life:
Our company undertakes to use the services of authorised and
regulatory companies to treat the set of products recovered at
the end of their useful life (contact your distributor).
Packaging:
For the recycling of the packaging there must be compliance
with the legal requirements in force, in accordance with the
specific regulations of the country where the device is installed.
Batteries:
Batteries pose a serious danger to health and the environment.
The disposal of them shall be carried out in accordance with
the laws in force.

7
4. PRESENTATION.
4.1. VIEWS OF THE CABINETS.
4.1.1. UPS cabinet
The models described above can be integrated into 3 different
cabinets that differ in height and the number of slots available:
up to 4 in the 24U cabinet and up to 6 in the 33 and 42U cabinets,
as can be seen in to :
Communications
interface
(See ) + Bypass
Module
Battery
Isolator Switch
Power
modules
Manual Bypass
Isolator Switch
(Optional)
LCD
Fig. 1. Front views of the 24U cabinet, with the door closed
(left) and the door open with 2 and 4 modules
installed (centre and right, respectively).
Detail A: Terminal block. External
battery
terminals
Terminal
block,
See Detail A
Manual
Bypass
Terminals
(Optional)
Fig. 2. Rear views of the 24U cabinet with 2 and 4 modules
installed and detail A of the terminal block.
SLC ADAPT 2 - UNINTERRUPTIBLE POWER SUPPLY SYSTEM -USER MANUAL

8SALICRU
LCD
Battery
Isolator
Switch
Manual Bypass
Isolator Switch
(Optional)
Communications
interface
(See ) + Bypass
Module
Fig. 3. Front views of the 33U cabinet, with the door
closed (above left) and the door open with 2, 4
and 6 modules installed (below).

9
Detail B: Terminal block.
Terminal
block, See
Detail B
Terminal block, See
Detail A, page 7
External
battery
terminals
Manual
Bypass
Terminals
(Optional)
Fig. 4. Rear views of the 33U cabinet with protective
cover removed for 2 ,4 and 6 modules installed.
SLC ADAPT 2 - UNINTERRUPTIBLE POWER SUPPLY SYSTEM -USER MANUAL

10 SALICRU
Battery
Isolator
Switch
Power
modules
External
battery
terminals
Terminal block, See
Detail A, page 7
Disconnector
Manual Bypass (Optional)
Manual
Bypass
Terminals
(Optional)
Communications interface
(See ) + Bypass Module
LCD
Fig. 5. Front views of the 42U cabinet, with the door
closed (left), with the door open and 2 modules
installed (centre) and rear view with protective
cover removed (right).
