SalonTechSpa Water Joy User manual
Copyright 2010 by
Printed in USA
Whirlpool Pedicure Spa Manual
Joy
Water
Thank you for choosing , the leading manufacturer well known worldwide for its innovation and design in pedicure
spas. takes pride in bringing you quality products that meet today’s demand for safety and service.
The Whirlpool Pedicure Spa has been designed for dependability, and to benet all with a health conscious clientele.
Important Requirements
requires that you contact your local, licensed plumber and licensed electrician to install your new spa. Installation
MUST be in compliance with all local and state building codes. Your pedicure spa cannot operate eciently or safely unless it is
provided with adequate electrical power, sucient water pressure, proper water temperature, and required drainage capabilities.
Contact your local building inspector for information and local code compliance procedure that need to be followed when having
your new pedicure spa installed. Subsequent inspections and approvals that may be required are the responsibility of the purchaser.
Shipment Inspection
Examine the components immediately upon arrival to make sure no damages have occurred to the pedicure spa and chair during the
shipment. It is very important that you notify the driver on the face of the freight bill or bill lading of any damage. Failure to note
damage on the bill of lading may prevent any claims you may have against the carrier.
If damage is found, you MUST notify the carrier at once and request an inspection. DO NOT DISCARD THE SHIPPING CARTON. If you
do, you do so at your own risk and expense.
Precaution
- Do not stand in the basin of the spa.
- Excessive water temperature is dangerous and should be checked before use.
Maximum water Temperature should not exceed 150°F (65°C).
- Always enter and exit the spa slowly and carefully.
- Never bring or operate any electrical device near pedicure spa.
- The unit has a weight capacity of 250 pounds.
Health Warning
Individuals whose feet or legs are inamed or have open wounds should not be allowed to use the pedicure spa at any time. The
technician should advise clients to consult their physician before using the spa if there is any sign of fungal infection, swelling, fracture,
or persistent pain. In some cases diabetics may experience improved circulation in their feet, but should rst consult their physician
prior to receiving a pedicure.
Joy
Water
If the client experiences any pain or discomfort, discontinue the use of the pedicure spa immediately.
PLEASE TAKE TIME TO READ THIS MANUAL THOROUGHLY BEFORE USE. If you have any questions or
problems with your pedicure spa, please contact our Customer Service and Technical Support at 516-433-0900, Monday
Serial Number :
Order Number :
Installed BY :
79F Express St. Plainview, NY 11803
Tel. 516.433.0900 / 877.725.6683
Fax. 516.433.0977
www.salontechspa.com
Whirlpool Pedicure Spa
Joy
Water
Important Considerations
Electrical Service
A 110V, 60HZ, 15AMP GFCI protected ground must be used to supply power to each indivisual pedicure spa. And the main circuit
breaker MUST be at 25AMP for maximum of two unit.
Water Supply
All plumbing connections must conform to local codes.
Water supply to the spa should be provided with adequate water pressure and water temperature.
- Water pressure
To ll the basin correctly up to level, Normal water pressure should be between 30 to 80 P.S.I.
- Water temperature
The hot water supply temperature must not exceed 140℉. Adjust your hot water accordingly. For hot and cold water supply
ttings and drain ttings location, see below diagram. Carefully connect the water supply line to the appropriate ttings located
on the rear of the pedicure spa.
Backow Preventive Device
This Device is optional, therefore yot need to order seperately. Salontech does not guarantee the quality of this device.
- Specication
Backow preventive device for faucet: Vacuum breaker comply with ANSI / NSF - 61 - 2000, ASMB A112.18.1 - 2000,
ASSE1014 and CSA standard - B125.98
ANSI / ASME A112.18.3M (performance requirements for backow preventive device and systems in plumbing xture ttings) is
applicable to plumbing xture ttings with outlets not protected by an air gap. Included in the possible range of applications are
ttings with hose connected outlets, tting with pull out spout, hand held showers, shampoo ttings and deck mounted ttings.
ASME A112.18.3M is now referenced in ASME A112.18.1M (plumbing xture ttings) and CSA B125. Backow preventive devices
are listed to both standards with the Canadian Standard Association, IAPMO and UL.
ANSI - American National Institute. ASME - American Society of Mechanical Engineers. CSA - Canadian Standard Association.
APMO - International Association of Plumbing and Mechanical Ocials. UL - Underwriters Laboratory.
Drain Facilities
The pedicure spa drain must meet local plumbing codes. Check valve for Drain (not provided) Must be installed by a licensed
plumber.
1-1/2” PVC Drain
Outlet
3/8” PIP
Cold Water
Supply Inlet
3/8” PIP
Hot Water
Supply Inlet
Back of the Water Joy Base
Identifying Components
Joy
Water
Headrest
Back Cushion
Armrest
Footrest
Cushion
Manicure Tray
Polish Tray
* Due to continuous improvements on all of our products, specication, characteristics, packing, color and design are subject to change without notice
On / O Switch
Shower Head
Water Joy (Base Unit)
Water Joy (Chair)
Stool
JJT Dual Impeller Motor Jets
Air Control
Motor
Discharge Pump (optional)
Massage System
Hot Water
Cold Water
Drain
Unit
Optional Item
29”W X 51”L X 16”H Wt. 165Lbs
22”W X 34 1.2”L(Incline), 50”L(Recline) X 44”H(Incline), 34”H(Recline) Wt. 125Lbs
19”W X 19”L X 22”H Wt. 13Lbs
4.25 US Gallon
On / O Air activated switch
Hydro Therapeutic Motor Jet with Dual Impeller System
Air Induction System
115V 1.2 Amp 60Hz 55W / Each Motor
115V 3.2 Amp 60Hz
110V - 120V 60Hz 90W 5Amp
1/2 inch (tting pre-installed) / 3/8 PIP Connection
1/2 inch (tting pre-installed) / 3/8 PIP Connection
1 - 1/2 inch (see plumbing instruction)
1 Year (see warranty)
180 Days
Specications
Hydro Therapeutic JJT Motor Jets with Dual Impeller System
Joy
Water
* Due to continuous improvements on all of our products, specication, characteristics, packing, color and design are subject to change without notice
Dimension & Weight
Capacity of Tub
Swithch
Whirlpool
Power Source
Plumbing Source
Warranty
Specications
51”
60”
29”
Joy
Water
Arm to Arm width
30.5”
51”
29”
16”
3”
41” 25.5”
14.5”
24.5”
22”
15”
60”
INSTALLATION SPECIFICATONS SUMMARY
Warning: Failure to comply with federal, state or local codes and ordinances will result in warranty
being null and void.
As stated, the pedicure spa installation must comply with all plumbing and electrical codes. A licensed plumber and licensed electri-
cian must complete the applicable connections of the pedicure spa.
LOCATION AND SUPPORT
Select a level location. The oor structure beneath the pedicure spa must be capable of supporting the occupied pedicure spa. For the
seat back to full recline, the pedicure spa base must be mounted 22 inches from the wall as shown below:
51” 22”
15.7”
16” * Minimun space
required is 22”
from the wall.
30
How to use adjustable footrest
Place left hand on the back of the footrest and gently pull up toward the front as shown g2.
Place right hand on the front of the footrest and gently pull up
for desired height and use locking lever to secure the footrest.
Fig 1 Fig 2
Fig 3
* Due to continuous improvements on all of our products, specication, characteristics, packing, color and design are subject to change without notice
Power Drain
Joy
Water
NOTE: The requirement for vaccum breaker varies from state to state
and province to province. Please consult with the licensed plumber.
15”
6” 37”(1.5” PVC drain pipe)
Adjustable
P-Trap and connector
5.5”
5.5”
5.5”
Discharge
Pump
Massage System
Important Safety Instructions
Warning: To reduce risk of burns, re, electric shock or injury:
READ ALL INSTRUCTIONS BEFORE USE; burns will result from improper use; please be care-
ful handling this product.
Close supervision is necessary when unit is used by, on , or near children and the disabled. Use
This unit only for its intended use as described in this manual. Do not use any attachments not
recommended by MFG.
- Keep the cord away from heated and wet surfaces.
- Do not use outdoors.
- Do not operate where aerosol products are being used or where oxygen is being administered.
- Never operate If it has a damaged cord or plug, or dropped in the water. To disconnect, press power button to turn o, then remove
the plug from the outlet.
- Allow 30 minutes break time between operations.
- Do not place any heavy object on the chair and do not let children play with it.
- The maximum weight capacity for the massage chair is 250lbs.
Your massage chair is simple to operate using the handheld controller included with your chair.
Before you use your chair, we recommend that you familiarize yourself with the remote control and the basic massage functions.
Joy
Water
* Due to continuous improvements on all of our products, specication, characteristics, packing, color and design are subject to change without notice
Massage Chair Remote Control Instruction
Discharge Pump Installation Instruction
1. Make a hole (size 1-3/8”) for the on/o switch as shown
Fig1. Pre drill required.
2. Place 1/8” clear hose into the rear of the switch and
on/o switch into the hole.
3. The discharge pump kit is made to t into the pedicure
unit as shown is Fig2.
4. Connect EZ connector to the drain elbow.
5. Plug discharge pump outlet into black 2 minute timer.
6. Plug black 2 minute timer into the wall outlet.
7. It is very important that tip of white tube remain above
the water level with one big loop as shown in Fig3.
Operation Instruction
Please DO NOT run dry
1. Turn to open the drain plug - wait 2 seconds.
2. Press on/o switch to activate the timer.
3. After the water has drained out from the basin. Press the
on/o switch again to stop.
* Loop to connect main drain
(Must have the loop
before the main drain
to prevent AIRLOCK)
Fig 3.
White tube
must have
the loop
Fig 1.
On/O Push Button
On/O
Switch
Fig 2.
Pre Assembled
Discharge Pump
Discharge
Pump
1-1/4”
Drain Elbow
1-1/4”
EZ connector
3/4” x 1
Adapter
1/2” Check Valve
(Provided by MFG)
Wall of
the Base
Fastener
Outlet2 min.
Timer
Electrical
Cord
Clear Tube
Joy
Water
Discharge Pump
1” PVC pipe
Discharge Pump Kit
Technical Support
79F Express Street Plainview, NY 11803
T: 516-433-0900 F: 516-433-0977
manufactures the First Class, Whirlpool Pedicure Spa with the highest standards for quality materials, with UL listed
components and highest workmanship for duration of the warranty period. Duration begins on the date of purchase by the cus tomer
(end-user). Each customer is responsible for maintaining the proof of purchase (invoice) to initiate the warranty. The customer MUST
send in warranty card in the manual booklet. Read and ll out (warranty form) carefully and return to within 15 days
from purchase.
Warranty Period
◈ All components: One (1) year from date of shipment.
◈ All optional items: 180 days from date of shipment.
If receives defective product notice during the applicable warranty period, shall either repair or
replace the defective parts at Salontechspa’s option. Replacement product (part) may be either new or equivalent in performance.
NO CONSEQUENTIAL, INCIDENTAL, OR CONTINGENT DAMAGE WILL BE ALLOWED WHATSOEVER. This warranty is null and void
if the spa is removed from its place of initial installation, or is not in accordance with federal, state or local codes and ordinances.
Furthermore, this warranty does not apply if the spa has been subject to misapplication, improper installation or maintenance, neg
ligence, improper cleaning, refurbished or tampered with in any way or other circumstances beyond Salontechspa’s control.
’s warranty is valid in only within the continental 48 U.S. The warranty may be available from any authorized
service facility where the product is distributed by Salontechspa or by an authorized distributor.
Not Covered
1. Damage to motor and/or motor parts due to obstruction in plumbing, etc.
2. Staining, fading or discoloration of surface due to exposure and/or the use of harmful cleaning substance or chemical.
3. Staining, fading or discoloration caused by improper or poor water additives not related to maintenance of proper water.
4. Malfunctions or damage caused by improper installation; including NOT meeting local and state plumbing, electrical, and building
codes.
5. Staining, fading or discoloration of the leather chair and urethane footrest.
6. Damage resulting from standing in basin.
7. Freight damage, misuse, neglect, accident, natural disaster, and abuse.
8. Unauthorized repairs.
LIMITED WARRANTY
Should service be required for any reason or any question on our product/s, please contact
* Due to continuous improvements on all of our products, specication, characteristics, packing, color and design are subject to change without notice
is not responsible for such warranties or representations.
No distributor or other person has any authority to bind to change or add this warranty or its products.
