Salton JVPM1B User manual

USE AND CARE GUIDE FOR
MODEL JVPM1B, JVPM1W
READ AND SAVETHESE INSTRUCTIONS
Pod Coffee Maker
JVPM1B-609 8/18/04 4:40 PM Page 1

2
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed, including the following:
• Read all instructions.
• Do not touch hot surfaces. Use handles or knobs.
• To protect against fire, electric shock, do not place cord, plugs,
or appliance in water or other liquid.
• Close supervision is necessary when any appliance is used by
or near children.
• Unplug from outlet when not in use and before cleaning. Allow
to cool before putting on or taking off parts, and before cleaning
the appliance.
• Do not operate any appliance with a damaged cord or plug or after
the appliance malfunctions, or has been damaged in any manner.
Contact Consumer Service for examination, repair or adjustment.
• The use of accessory attachments not recommended by the
appliance manufacturer may result in fire, electric shock or injury
to persons.
• Do not use outdoors.
• Do not let cord hang over edge of table or counter, or touch hot
surfaces.
• Do not place on or near a hot gas or electric burner, or in a
heated oven.
• To disconnect, turn any control to “off,” then remove plug from
wall outlet.
• Do not use appliance for other than intended use.
• Be certain lid is securely in place before operating appliance.
• Scalding may occur if the lid is opened during the brewing cycles.
SAVETHESE INSTRUCTIONS
THIS PRODUCT IS FOR HOUSEHOLD USE ONLY.
JVPM1B-609 8/18/04 4:40 PM Page 2

3
ADDITIONAL IMPORTANT
SAFEGUARDS
WARNING: This appliance generates heat and escaping steam
during use. Use proper precautions to prevent the risk of burns,
fires, or other injury to persons or damage to property.
• All users of this appliance must read and understand this
Owner’s Manual before operating or cleaning this appliance.
• The cord to this appliance should be plugged into a 120V AC
electrical outlet only.
• Use water only in this appliance! Do not put any other liquids or
food products in this appliance.Do not mix or add anything to the
water placed in this appliance, except as instructed in the User
Maintenance Instructions to clean the appliance.
• DO NOT attempt to move an appliance containing hot liquids.
Allow appliance to cool completely before moving.
• Keep appliance at least 4 inches away from walls or other objects
during operation. Do not place any objects on top of appliance
while it is operating. Place the appliance on a surface that is
resistant to heat.
• If this appliance begins to malfunction during use, immediately
unplug the cord. Do not use or attempt to repair the malfunc-
tioning appliance.
• If this appliance falls or accidentally becomes immersed in water
or any other liquid, unplug immediately. Do not reach into the
water! Do not use this appliance after it has fallen into or
has become immersed in water. Contact Consumer Service
for examination and repair.
• Do not leave this appliance unattended during use.
• Always use fresh, cool water in your coffee maker. Warm water
or other liquids, except as listed in cleaning section, may cause
damage to the appliance.
JVPM1B-609 8/18/04 4:40 PM Page 3

4
POLARIZED PLUG:This appliance has a polarized plug, (one
blade is wider than the other).To reduce the risk of electric shock,
this plug is intended to fit into a polarized outlet only one way. If
the plug does not fit fully in the outlet, reverse the plug.If it still does
not fit, contact a qualified electrician. Do not attempt to modify the
plug in any way.
SHORT CORD INSTRUCTIONS:A short power supply cord is pro-
vided to reduce the risk resulting from becoming entangled in or
tripping over a longer cord.
Do not use an extension cord with this product.
ELECTRIC POWER: If the electric circuit is overloaded with other
appliances, your appliance may not operate properly. It should be
operated on a separate electrical circuit from other appliances.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT REMOVE THE BOTTOM COVER. NO USER-
SERVICEABLE PARTS INSIDE. REPAIR SHOULD BE DONE BY
AUTHORIZED SERVICE PERSONNEL ONLY.
CAUTION: To prevent Plasticizers from migrating from the finish of
the countertop or tabletop or other furniture, place NON-PLASTIC
coasters or placemats between the appliance and the finish of the
countertop or tabletop.
Failure to do so may cause the finish to darken, permanent
blemishes may occur or stains can appear.
JVPM1B-609 8/18/04 4:40 PM Page 4

55
Parts Identification
Lever
Water
Diffuser
Adjustable Brew Spout
(P/N 31156B, 31156W)
Drip Tray
(P/N 31157)
Lid
Water
Tank
(P/N 31160)
Base
Control Panel
Over Flow Tray
(P/N 31158B,
31158W)
Pod Holder
(P/N 31159B,
31159W)
Pod Chamber
(P/N 31163)
Your product may vary slightly from illustration.
5-ounce Serving Power Light/
Indicator Button
8-ounce Serving
FIGURE 1
FIGURE 2
Pod
(To order, see page 14.)
JVPM1B-609 8/18/04 4:40 PM Page 5

6
Before UsingYour
Pod Coffee Maker
Become familiar with all parts of the appliance.
Keep your Pod Coffee Maker clean
Clean and descale your Pod Coffee Maker on a regular basis. See
“Cleaning and Descaling”, pages 11-12.We recommend cleaning
the Water Tank and the Adjustable Brew Spout as well as the Pod
Holder and Pod Chamber, before using for the first time.Turn on
the machine for a full cycle using water only by following steps 1-9.
IMPORTANT: THE MACHINEWILL NOT FILTER COFFEE UNLESS
THE PUMP HAS BEEN PRIMED.
1. Remove the Water Tank by pulling out and then up to remove
from the Base, see Figure 3.
FIGURE 3
JVPM1B-609 8/18/04 4:40 PM Page 6

7
2. Fill the Water Tank with fresh water up to the‘Max’line, and fit
back into the Base (down and in) until it “snaps”into place, see
Figure 4.
3. Lift Lid by pulling out on the Lever.Top will pop up.Push back so
Lid is in fully raised position, see Figure 5.
4. Place the Adjustable Brew Spout inside the coffee maker.
FIGURE 5
FIGURE 4
JVPM1B-609 8/18/04 4:40 PM Page 7

8
5. Make sure the mouth of the Pod Chamber is inside the Adjustable
Brew Spout.Do not place a coffee pod in chamber.See Figure 6.
6. Place the Pod Holder so it sits securely on top of the Pod
Chamber, see Figure 7.
7. To close the Lid, press down firmly on the top of the Lid and
hold in place while pushing the Lever back so it is flush with the
Lid and locks into place, see Figure 7.
8. Place a cup or mug below the Adjustable Brew Spout to collect
the water.
NOTE: Adjustable Brew Spout is always in “relaxed” position
unless forced up by a tall mug.
FIGURE 6
FIGURE 7
JVPM1B-609 8/18/04 4:40 PM Page 8

9
9. Press the Power Light/Indicator Button to turn power on, then
simultaneously press the 5-Ounce Serving and 8-Ounce Serving
Buttons, see Figure 8.
The water from theWaterTank will cycle through the coffee maker.
NOTE: If unit goes unused for 3 or more days, please repeat
above process (steps 1-9).
CAUTION: Do not immerse cord, plug or machine in water or
other liquid. Brewing Coffee
CAUTION: Before Brewing in your coffee maker for the first
time, complete the steps listed under “Before UsingYour Pod
Coffee Maker” on pages 6-9 to ensure your machine functions
properly.
1. Fill the Water Tank with water up to the ‘MAX’ line. Never pour
other liquids such as milk or hot water into the Water Tank. A
full tank will yield about 7 5-oz. servings or 4 8-oz. servings of
coffee.
2. Press the Power Light/Indicator Button.The indicator light will
flash while the water heats up.Heating will take approximately
11/2 minutes.
3. To open the Lid, place one finger behind Lever and pull out.
Gently raise Lid to open position.
4. Place the Adjustable Brew Spout inside the coffee maker.
5. Place the empty Pod Holder inside the Pod Chamber, see
Figure 7.
FIGURE 8
JVPM1B-609 8/18/04 4:40 PM Page 9

10
6. Place one coffee pod inside the Pod Holder.Press lightly on the
coffee pod to make sure it sits evenly in the Pod Holder. See
Figures 9 and 10 for correct pod insertion.
CAUTION: Use only pre-measured coffee pods in your Pod
Coffee Maker.The use of loose ground coffee may result in
inferior coffee, cause overflow and could possibly damage the
machine.
CAUTION: Never use torn coffee pods as this could clog the
machine and damage it. Each coffee pod is pre-portioned with
the optimal amount of coffee required per cup.
7. To close the Lid, press down firmly on the top of the Lid and hold
in place while pushing the Lever back so it is flush with the Lid
and locks into place.
8. Place a mug or cup under the Adjustable Brew Spout.The cup
should hold at least 7 to 10 ounces, depending on your
selection.
9. When the indicator light stops flashing, the coffee maker is
ready to use.If the indicator light flashes at rapid intervals, see
Troubleshooting on page 13.
10. Select the amount of coffee you wish to brew: either a 5 ounce
serving or an 8 ounce serving.The machine will begin the brew-
ing process.At the beginning of the brewing cycle, a small amount
of water is dispersed to pre-moisten the pod to ensure full extrac-
tion.Following a short pause, the machine will brew for about 50
seconds.You can manually stop the brewing process at any
time by pressing the Power Button.
CAUTION: Dripping may occur between brewing cycles.
11. Dispose of the coffee pod after use by removing the Pod Holder
from the Pod Chamber and emptying it.Do not use a pod more
than once.Repeated use may cause the pod to burst and result
in weak and inferior coffee.
Note: Regular rinsing of the Pod Holder will optimize the flavor of
the beverage.
FIGURE 9 FIGURE 10
correct incorrect
JVPM1B-609 8/18/04 4:40 PM Page 10

11
You may leave your coffee maker on if you intend to brew another
cup of coffee.The coffee maker will turn off automatically after one
hour. Helpful Hints for Brewing
FreshWater
For optimal results, use fresh water daily. If you haven’t used your
machine for a few days, follow steps 1-9 in section “Before Using
Your Pod Coffee Maker” on pages 6-9.
Note: If Water Tank becomes dry for 3 or more days, you must re-
prime the pump. See “Before UsingYour Pod Coffee Maker,”
steps 1-9.
Coffee Pods
Remember to remove pods after use. If a pod is left inside the
machine for some time, remove it and wash the Pod Holder before
attempting to brew coffee.
Use only pre-measured coffee pods in your Pod Coffee Maker.
The use of loose ground coffee may result in inferior coffee, cause
overflow and could possibly damage the machine.
Never use torn coffee pods as this could clog the machine and dam-
age it. Each coffee pod is pre-portioned with the optimal amount of
coffee required per cup.
Care and Cleaning
CAUTION: Do notimmersecord,plugormachineinwaterorotherliquid.
1. Always unplug the appliance before cleaning.
2. Clean the outer surface of the unit and the Water Diffuser with a
damp cloth.
3. Remove the Pod Holder, Pod Chamber and Adjustable Brew
Spout.
JVPM1B-609 8/18/04 4:40 PM Page 11

12
4. Remove the Drip Tray and OverflowTray, see Figure 11.
5. Clean the Water Tank, Pod Holder, Pod Chamber, Adjustable
Brew Spout, Drip Tray and OverflowTray with hot water.If nec-
essary, use a little dish soap.
Note: The Pod Holder, the Drip Tray, Overflow Tray and the
Adjustable Brew Spout may be washed in the dishwasher (top
shelf only).The top part of the tank can be removed for thorough
cleaning.Do not place the WaterTank in the dishwasher.
6. Rinse all parts with fresh water after cleaning.
Note: Do not try to dry the inside of the RemovableWaterTank
with a cloth because this could leave a residue of lint and may
clog your coffee maker.
Descaling
Regular descaling will extend the service life of your machine and
ensure optimal results over time.
1. Follow the instructions given in “Before UsingYour Pod Coffee
Maker,” pages 6-9, replacing one fourth of the water with
white vinegar.
2. Brew 3, 8-oz.cups using empty Pod Holder (follow the Brewing
Instructions on page 9.)
3. Remove WaterTank, Pod Holder, Pod Chamber and Adjustable
Brew Spout and wash thoroughly.
4. Repeat instructions in step 2 up to four times in order to flush
vinegar residue. Empty Water Tank and refill with fresh water
after each cycle.
Note:You may also use a cleaner designed for automatic drip
coffee makers. Simply follow the instructions as stated on the
package.
FIGURE 11
JVPM1B-609 8/18/04 4:40 PM Page 12

13
Troubleshooting
Should a problem occur, you may be able to find an answer in the
text below. If the text proves unhelpful or if you require further
information, please contact Consumer Service.
1. The coffee is too weak.
Check the following:
• the pod is placed properly in the Pod Holder.You may need
to lightly press it down into the holder.
• you have selected the correct button according to the number
of ounces and strength desired.Use one coffee pod for either
one 5-ounce, bold European serving, or an 8-ounce serving
of American-style coffee.
• you are using a fresh coffee pod.
2. The coffee is too strong.
Check that you have selected the correct button. Use the
8-ounce button for less robust coffee.
3. There is less water than normal used during brew cycle.
• Tank may be empty. Refill and brew again.
• Descale appliance.See “Descaling,” page 12.
4. Water drips from the coffee maker.
Note:Some water may drip between cycles, this is normal.
If dripping seems excessive, check the following:
• the Pod Holder must be placed properly within the Pod Cham-
ber and the Lever locked into position.
• the Water Tank must not be filled above the ‘MAX’ line.
• the Pod Holder may be clogged. Rinse under tap water to
unclog the screen.If necessary, you may also use a scrubbing
brush or a pin to unclog holes.
• the pod must be properly placed so it sits evenly in the holder.
Lightly tap it down into the holder. See Figure 9.
• some water droplets on your countertop are normal and may
be caused by the filling and replacing of the Water Tank.
FIGURE 12
correct incorrect
JVPM1B-609 8/18/04 4:40 PM Page 13

14
5. The indicator light is flashing.
A flashing indicator light means the machine is heating.This
normally lasts for 11/2-2 minutes. If indicator light is flashing
rapidly (more than a second apart), see #6 below.
If the indicator light flashes continually for more than 4 minutes,
contact Consumer Service.
6. The indicator light keeps flashing at rapid intervals.
Check the following:
• the Water Tank must be inserted properly inside the coffee
maker.
• there must be enough water in the Water Tank. Fill the Water
Tank to the “Max” fill line.
• the appliance may require cleaning. See “Before Using Your
Pod Coffee Maker”, pages 6-9.
• room temperature must be above 40°F.
7. The Lid will not open.
Turn coffee maker off. Unplug coffee maker. Wait for appliance
to cool completely (about 30 minutes) and try opening Lid
again. Clean all removable parts (Adjustable Brew Spout, Pod
Holder, Pod Chamber) as described on pages 11-12.
For any other problem please contact Consumer Service,
1-800-577-1557 or email us at [email protected].
To Order Coffee Pods
It’s easy to order pods. Just log onto our dedicated website,
www.juanvaldezpods.com, and order online.
To order by phone, call toll-free, 1-800-577-1557.
Coffee pods are also available at Target and other retail outlets that
carry the Pod Coffee Maker.
JVPM1B-609 8/18/04 4:40 PM Page 14

15
IMPORTANT NOTICE
If any parts are missing or defective,
DO NOT return this product.
Please call our Customer Service Department for assistance.
800-577-1557 Monday - Friday 9:00 am - 5:00 pm CST
ThankYou
LIMITED ONEYEAR WARRANTY
Warranty: This product is warranted by Salton, Inc. to be free from defects
in materials or workmanship for a period of (1) year from the original purchase
date.This product warranty covers only the original consumer purchaser of
the product.
Warranty Coverage:This warranty is void if the product has been damaged by
accident in shipment, unreasonable use, misuse, neglect, improper service,
commercial use, repairs by unauthorized personnel, normal wear and tear,
improper assembly, installation or maintenance abuse or other causes not aris-
ing out of defects in materials or workmanship.This warranty is effective only if
the product is purchased and operated in the USA, and does not extend to
any unit which has been used in violation of written instructions furnished with
the product, or to units which have been altered or modified, or to damage to
products or parts thereof which have had the serial number removed, altered,
defaced or rendered illegible.
Implied Warranties: ANY IMPLIED WARRANTIES WHICH THE PUR-
CHASER MAYHAVEARE LIMITED IN DURATIONTO ONE (1)YEAR FROM
THE DATE OF PURCHASE.Some states do not allow limitations on how long
an implied warranty lasts, so the above limitation may not apply to you.
Warranty Performance: During the above one-year warranty period, a prod-
uct with a defect will be either repaired or replaced with a reconditioned com-
parable model (at our option) when the product is returned to the Repair Center,
or the purchase price refunded.The repaired or replacement product will be in
warranty for the balance of the one-year warranty period and an additional one-
month period. No charge will be made for such repair or replacement.
Service and Repair: Should the appliance malfunction, you should first call
toll-free 1-800-577-1557 between the hours of 9:00 am and 5:00 pm Central
StandardTime and ask for CONSUMER SERVICE stating that you are a con-
sumer with a problem.Please refer to model number JVPM1B or JVPM1W when
you call.
In-Warranty Service (USA): For an appliance covered under the warranty
period, no charge is made for service or postage.Call for return authorization
1-800-577-1557.
JVPM1B-609 8/18/04 4:40 PM Page 15

Out-of-Warranty Service:A flat rate charge by model is made for out-of-war-
ranty service. Include $12.00 (U.S.) for return shipping and handling.We will
notify you by mail of the amount of the charge for service and require you to
pay in advance for the repair or replacement.
For products purchased in the USA, but used in Canada:You may return
the product insured, packaged with sufficient protection, and postage and
insurance prepaid to the USA address listed below. Please note that all cus-
toms duty / brokerage fees, if any, must be paid by you and we will require you
to pay the cost of customs duty / brokerage fees to us in advance of our per-
forming any service.
Risk During Shipment: We cannot assume responsibility for loss or dam-
age during incoming shipment. For your protection, carefully package the
product for shipment and insure it with the carrier.Be sure to enclose the fol-
lowing items with your appliance: any accessories related to your problem,
your full return address and daytime phone number, a note describing the
problem you experienced, a copy of your sales receipt or other proof of pur-
chase to determine warranty status.C.O.D. shipments cannot be accepted.
To return appliance, ship to: To contact us, please write to, call or email:
Attn: Repair Center Salton, Inc.
Salton, Inc. P.O. Box 6916
708 South Missouri Street Columbia, MO 65205-6916
Macon, MO 63552 1-800-577-1557
Email: [email protected]
Limitation of Remedies: No representative or person is authorized to
assume for Salton, Inc. any other liability in connection with the sale of our
products.There shall be no claims for defects or failure of performance or
product failure under any theory of tort, contract or commercial law including,
but not limited to negligence, gross negligence, strict liability, breach of war-
ranty and breach of contract.Repair, replacement or refund shall be the sole
remedy of the purchaser under this warranty, and in no event shall Salton, Inc.
be liable for any incidental or consequential damages, losses or expenses.
Some states do not allow the exclusion or limitation of incidental or conse-
quential damages, so the above limitation or exclusion may not apply to you.
Legal Rights:This warranty gives you specific legal rights, and you may also
have other rights which vary from state to state.
For more information on Salton products:
Visit our website: www.eSalton.com
© 2004 Salton, Inc. P/N 67601
All Rights Reserved Printed in China
JVPM1B-609 8/18/04 4:40 PM Page 16
