Salton EX-15 User manual

3 –IN –1 COFFEE CENTRE
Espresso/Cappuccino/Filter Coffee Maker
MODEL EX-15

IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
followed, including the following:
1. Read all instructions.
2. Do not touch hot surfaces. Use handles or knobs.
3. Never leave the appliance unattended when in use.
4. To protect against electrical hazards, do not immerse cord, plugs, or the
appliance in water or other liquid.
5. Close supervision is necessary when any appliance is used by or near
children.
6. Unplug from outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts, and before cleaning the appliance.
7. Never use the appliance without water.
8. Do not operate any appliance with a damaged cord or plug or after the
appliance malfunctions, or has been damaged in any manner. Return
appliance to Salton for examination, repair or adjustment. See Warranty.
9. The use of accessory attachments not recommended by Salton may cause
hazards.
10.Do not use outdoors.
11.Do not let cord hang over edge of table or counter, or touch hot surfaces.
12.Do not place on or near a hot gas or electric burner, or in a heated oven.
13.Extreme caution must be used when moving an appliance containing hot
liquids.
14.Prior to connecting or disconnecting plug from wall outlet, turn any control to
Off.
15.Do not use appliance for other than intended household use.
16.Scalding may occur if the Boiler Cap or Espresso Filter Holder is removed
during the brewing cycle.
17.Keep Steam Control Knob in the closed position when not being used.
18.The Carafe is designed for use with this appliance. It must never be used on a
range top. Do not set the hot Carafe on a wet or cold surface. Do not use a
cracked Carafe or a Carafe having a loose or weakened handle. Do not clean
Carafe with cleansers, steel wool pads, or other abrasive material.
SAVE THESE INSTRUCTIONS

BEFORE FIRST USE
Before using your Salton EX-15 for the first time wash all removable parts in
warm, soapy water, rinse thoroughly and dry. Run water through both sides of the
machine, the filter coffee side and the espresso side. Follow the directions as
described in each section, leaving out the coffee.
DESCRIPTION OF PARTS
1. Reservoir Lid for filter coffee
2. Water Level Indicator
3. Filter Coffee On/Off Button and Light
4. Swing-out Filter Holder
5. Filter Coffee Carafe
6. Keep Warm Plate
7. Boiler Cap
8. Espresso Strength Control Dial
9. Steam Control Knob
10.Espresso/Cappuccino On/Off Button
and Light
11.Steam Indicator Light
12.Espresso Filter Holder
13.Frothing Nozzle
14.Espresso Coffee Carafe
15.Removable Overflow Grid
16.Cup Adapter
17.Metal Filter
18.Cord Storage
MAKING ESPRESSO COFFEE
1. Plug your EX-15 into a 120 volt AC outlet. Make sure the Espresso Coffee
Light is Off and the Steam Control Knob is turned clockwise to the closed
position.
2. Unscrew the Boiler Cap by turning it counterclockwise.
3. Fill the Espresso Carafe with 2 to 4 cups of cold water using the carafe
markings for reference.
N.B.: When making Cappuccino add extra water to the Steam Cloud level for
2 cups or to the bottom of the metal band for 4 cups. Pour the water into the
Boiler. All water will be processed until the Boiler is empty. Therefore, pour
only as much water as you intend to use.
4. Screw the Boiler Cap securely in place by turning clockwise.
5. Place the Metal Filter into Filter Holder and fill to the desired level with
Espresso coffee.
N.B.: Markings inside the Filter indicate coffee level for 2 to 4 cups. Use a
fine drip grind coffee. If the coffee is too fine the flow of water through the

Filter will be impeded. Never press down on the coffee. Never fill the Filter
above the 4 cup marking.
6. Brush away excess coffee from the edge of the Filter.
7. To insert the Metal Filter/Filter Holder, push upward into the machine with the
handle of the Filter Holder pointing to the left. Then turn the handle to the
right until locked securely into the position.
8. Place the Lid on the Carafe and position under the Filter Holder. NOTE: To
make espresso coffee directly into cups, clip the Cup Adapter onto the Filter
Holder. Place cups directly under the two spouts.
9. Regulate the strength of the Espresso by turning the Espresso Strength
Control to any position between LIGHT and STRONG.
10.Press the Espresso/Cappuccino Switch on the front of the machine. The light
will go on. The Espresso will soon start to flow into the Carafe. N.B. The
Steam Control Knob must be closed, turn Knob clockwise.
Warning: Do not attempt to remove either the Boiler Cap or Filter Holder
during the brewing process. Scalding may occur.
11.When Espresso has stopped flowing, press the Espresso/Cappuccino Button
to turn off. The light will go Off.
12.Turn the Espresso Strength Control to the LIGHT position, open the Steam
Control Knob slowly to relieve the pressure before removing the Filter Holder
or the Boiler Cap.
13.Remove the Carafe and pour Espresso into demitasse cups.
14.To remove the Filter Holder turn the handle to the left and lower. Hold the
Metal Filter in place by pushing the Filter Holder Lock onto the rim of the Metal
Filter. Coffee can now be tapped out while the Metal Filter is held in place.
15.For additional servings remove the Boiler Cap, close the Steam Control Knob
and refill the Boiler with water. Repeat steps 2 to 13.
MAKING CAPPUCCINO
Cappuccino is prepared by topping Espresso coffee with frothy steamed milk. Fill
a narrow pitcher half full with fresh, cold milk (the colder the better). Low fat or
skim milk works best.
1. Follow steps 1-10 for making Espresso.
2. As soon as the Espresso starts to flow into the Carafe, switch the Espresso
Strength Control Dial to Steam symbol. Shortly after the green Steam
Indicator Light will glow and you are ready to froth the milk. Slowely turn the
Steam Control Knob counterclockwise to open the steam valve. Move the
pitcher up and down, keeping the tip of the Frothing Nozzle just below the
surface of the milk to produce the best froth and avoid splattering.
3. Once the milk has been frothed, turn the Steam Control Knob clockwise to
close the valve and remove the pitcher. Turn the Strength control Dial back to
the desired strength of the Espresso coffee and the coffee will continue to flow
into the carafe. Important: After the Espresso has stopped flowing into the

carafe, open the Steam Control Knob for a few seconds to expel any milk
remnants from the Steam Tube then close again.
4. Turn the appliance Off by pressing the Espresso/Cappuccino On/Off Button .
5. Pour espresso into cups. Spoon frothed milk onto the Espresso and add hot
milk to fill the cup. Sprinkle with cinnamon, nutmeg or chocolate.
6. IMPORTANT: Before removing the Boiler Cap or Filter Holder slowly open the
Steam Control Knob to relieve any pressure left in the Boiler. To remove the
Filter Holder turn the handle to the left and lower. Hold the Metal Filter in
place by pushing the Filter Holder Lock onto the rim of the Metal Filter. Coffee
can now be tapped out while the Metal Filter is held in place.
STEAM ONLY
If you only want to froth milk, fill the Espresso Carafe with water up to the Steam
Cloud. This will give you approximately one minute of steaming.
1. Make sure the Strength Control Knob is set to the Steam symbol.
2. Pour the water in the Boiler and press the Espresso/Cappuccino On/Off
button.
3. Place an empty cup under the Steam Nozzle to collect any water which may
escape.
4. Fill a narrow pitcher half full with fresh, cold milk (the colder the better). Low
fat or skim milk works best. As soon as the Steam Indicator Light comes on,
slowly turn the Steam Control Knob counterclockwise to open the steam valve.
Move the pitcher up and down, keeping the tip of the Frothing Nozzle just
below the surface of the milk to produce the best froth and avoid splattering.
5. Once the milk has been frothed, turn the Steam Control Knob clockwise to
close the valve and remove the pitcher.
6. Turn the appliance off by pressing the Espresso/Cappuccino On/Off Button.
The light will go out.
7. To clean the steam tube, turn the Espresso Strength Control Dial to the Light
position and slowly open the Steam Control Knob.
8. Before removing the Filter Holder or the Boiler Cap be sure that there is no
pressure left in the Boiler by slowly opening the Steam Control Knob.
MAKING AUTOMATIC FILTER COFFEE
Plug your EX-15 into a 120 Volt AC outlet. Make sure the light for Filter Coffee is
off and the Filter Coffee On/Off Button is in the Off position.
1. Lift the Reservoir Lid and pour in the water from the Carafe to the desired
amount indicated on the Water Level Indicator on the left side of the machine.
2. Swing out the Filter Holder. Place a #?? paper filter into the Filter Holder and
add the desired amount of ground coffee. Swing the Filter Holder back into
the closed position.
3. Place the Coffee Carafe on the Keep Warm Plate. Make sure that it is
securely in position.

4. To turn the machine on, press the Filter Coffee On/Off Button. The light will go
on and the brewing will begin.
5. The Keep Warm Plate will keep the coffee hot until the Filter Coffee On/Off
Switch is turned off.
PAUSE & SERVE FEATURE
The Pause & Serve feature allows you to pour a cup of coffee before the brew
cycle has finished. Remove the Carafe slowly to temporarily stop the flow of
coffee. Quickly pour a cup of coffee and reposition the Carafe securely on the
Keep Warm Plate.
CARE AND MAINTENANCE
1. Unplug the appliance from the electrical outlet and allow to cool completely
before cleaning.
2. Wash the Filter Coffee Carafe and Lid, Espresso Carafe and Lid, Espresso
Filter, Espresso Filter Holder, Swing-Out Basket and Drip Tray in warm, soapy
water. To remove the Basket, swing out and lift up. Rinse in clear water and
dry thoroughly. Never wash any components in a dishwasher.
3. If the Steam Tube becomes blocked
you may remove the Frothing Nozzle
and clean it in hot soapy water. (Ill. 2)
Use a pin periodically, to loosen any
milk remnants from the Steam Tube.
Replace the Nozzle after cleaning.
4. Wipe the outside of your EX-14 with a damp cloth. Never immerse the
appliance in water or in any other liquid. Do not use abrasive cleaners.
Descaling
Over a period of time, minerals and calcium found in water will accumulate in your
3-in 1 Coffee Centre and affect its operation. The appliance should be cleaned
approximately every six months, depending on water conditions. Use distilled
vinegar in the following manner to remove the mineral deposits.
Espresso Boiler
1. Make sure the appliance has been disconnected from the wall outlet and both
switches are in the ‘Off’ position.
2. Unscrew the Boiler Cap.
3. Fill the Espresso Carafe with white vinegar and pour into the Boiler.
4. Close the Boiler Cap securely by turning it clockwise.
5. The Espresso Filter and the Filter Holder should be inserted until securely
locked into position.

6. Place the Espresso Carafe on the Drip Tray.
7. Plug into a wall outlet and press the Espresso/Cappuccino 'On/Off' Button.
8. Let the whole quantity of vinegar run through the machine, then turn the
appliance off.
9. With the Espresso Strength Control Dial turned to the LIGHT position open the
Steam Control Knob slowly to relieve the pressure before removing the Filter
Holder or the Boiler Cap.
10.Repeat the above steps using cold water to rinse away any residual vinegar.
Repeat twice.
Filter Coffee System
1. Fill the Filter Coffee Carafe with equal parts of white vinegar and cold water.
2. Open the Lid of the Water Reservoir and pour in the vinegar/water solution.
Close the Lid. Swing the Basket into the 'Locked' position.
3. Place the Carafe on the Keep Warm Plate, making sure it is securely in
position.
4. Press the Filter Coffee 'On/Off' Switch.
5. Let the whole quantity of the vinegar/water solution run through the machine,
then turn the appliance off.
6. Repeat the above steps using cold water to rinse away any residual vinegar.
Repeat twice.

TROUBLESHOOTING
PROBLEM SOLUTION
1. Coffee does not flow. •Remember to fill Reservoir or Boiler with
water before machine is switched On.
•Check if Switch is On.
•Use a coarser grind of coffee.
•Reduce the amount of coffee in the
Espresso Filter. Do not compact coffee in
the Filter.
2. Coffee is too weak or flows
too quickly. •Use a finer grind of coffee.
•Increase the amount of coffee in the Filter
•Adjust the Espresso Strength Control Dial
to 'STRONG' setting.
3. Coffee flows too slowly or is
too strong. •Use coarser grind.
•Reduce the amount of coffee in the Filter.
•Follow the Descaling instructions in this
booklet.
•Adjust the Espresso Strength Control Dial
to 'LIGHT' setting.
4. Coffee flows from the edge
of the Filter Holder. •Wipe excess grinds from the Filter Holder.
•Make sure the Filter Holder is installed
securely in the 'Lock' position.
5. No steam from the Steam
Tube or steam stops before
frothing is complete.
•Remember to fill the Boiler.
•Check if the switch is On.
•Open the Steam Control Knob.
•Close the Steam Control Knob, remove
and wash the plastic Steam Nozzle.
Unblock the Steam Tube and using a
straight pin. Then try again.
6. Steam escapes from the
Boiler Cap area. •This is the normal functioning of the
pressure regulating device.

A short supply cord is provided to reduce the hazards of becoming entangled in or
tripping over a long cord. Extension cords may be used if care is exercised in
their use. If an extension cord is used, the marked electrical rating of the
detachable power-supply cord or extension cord should be at least as great as the
electrical rating of the appliance. If the appliance is of the grounded type, the
extension cord should be of the grounding-type 3-wire cord. The extension cord
should be arranged so that it will not drape over the counter top or table top,
where it can be pulled on by children or tripped over.
LIMITED WARRANTY
SALTON warrants that this appliance shall be free from defects in material and
workmanship for a period of one year from the date of purchase. During that
period these defects will be repaired or the product will be replaced at SALTON's
option without charge. This warranty covers normal domestic usage and does not
cover damage which occurs in shipment or failure which results from alteration,
accident, misuse, abuse, glass breakage, neglect, commercial use, or improper
maintenance.
TO RETURN FOR SERVICE
1. Securely package and return the product PREPAID to: SALTON CANADA,
81A Brunswick, Dollard-des-Ormeaux, Quebec, H9B 2J5
2. Be sure to enclose your name, address, postal code and description of
defect.
3. To ensure prompt "In-Warranty" service, be sure to include a proof of
purchase. We recommend you take the necessary precaution of insuring
the parcel.
4. For repairs not covered by the Warranty, you will be advised of the cost of
repair in advance, and upon receipt of your cheque or money order, the
repairs will be completed and the product returned to you.
SALTON CANADA
81A Brunswick
Dollard-des-Ormeaux
Quebec H9B 2J5
Website: www.salton.com
Service: [email protected]
