OPERATOR'S MANUAL
SCISSOR TRIMMER
PG 150 (F) – 1,50m
PG 150L (F) – 1,50m
PG 200 (F) – 2,00m
PG 200L (F) – 2,00m
Suitable for extension arms:
KWT, CAMEL, FISHER
IN331EN002
06.09.2017
EDITION NO. 2
Translation of the original operator’s manual
– English –
Nr. Serial no.

This operator’s manual is indispensable part of any scissors trimmer and is to familiarize
future user with principles of proper operation and use of the machine as well as with risks these
encompass. Prior to commissioning content of the hereby manual and safety advices should be
learned thoroughly.
The hereby manual is to be used together with operator’s manual of extension arm KWT,
Camel or Fisher.
Scissors trimmer can cut only branches, brushes, hedges with diameter up to Ø100mm
(Ø10cm) or similar activities. Using it for purposes other than provided shall be considered as
misuse. Meeting requirements concerning operation, use and repair as advised by the manufacturer
and their thorough following is condition for operation as designed.
Apart from recommendations concerning designation of the machine, its proper use also
encompasses servicing and maintenance in good technical condition as well as application of
genuine spare parts only.
Road sign washer should be operated, serviced and repaired only by personnel who are
trained in technical servicing and principles of safety procedures.
Provisions concerning accident prevention as well as any basic occupational health and
safety provisions and road traffic principles should always be followed.
If you have any questions concerning commission and operation of the machine, please
contact the manufacturer’s service.
The manufacturer does not bear any responsibility for damages resulting from unauthorized
repairs as well as modifications of the machine design without its prior permission.
In case of resale of the machine to other user, operator’s manual must be handed on with
written confirmation of delivery of the manual.
NOTE:
Instructions given in this operator’s manual which are marked with this
symbol and warning signs on the machine inform about a risk.
NOTE:
Keep this manual for future reference.
Well-proven design with thousands of machines in regular use in many countries and quality
materials ensure high durability and reliability of SaMASZ mowers.
We congratulate you on the purchase of your new SaMASZ machine and wish you much pleasure
and the very best work results through the years to come.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 1 -
Contents page
1. IDENTIFYING THE MACHINE .............................................................................................2
2. INTRODUCTION.......................................................................................................................2
3. INTENDED USE AND DESIGN...............................................................................................3
3.1. Specifications.......................................................................................................................4
3.2. Design and principle of operation of the scissor trimmer...................................................4
3.3. Equipment and fittings:........................................................................................................5
4. SAFETY PRECAUTIONS.........................................................................................................5
4.1. Safety rules ..........................................................................................................................5
4.1.1. Operating ......................................................................................................................5
4.1.2. Attaching.......................................................................................................................6
4.1.3. Operation ......................................................................................................................6
4.1.4. Inspection and repair.....................................................................................................7
4.1.5. Replacement of damaged or worn parts .......................................................................8
4.1.6. Storage ..........................................................................................................................8
4.1.7. Qualifications of operator.............................................................................................8
4.1.8. Transport.......................................................................................................................8
4.1.9. Putting the machine onto another vehicle for transport................................................9
4.1.10. Hydraulic assembly ......................................................................................................9
4.2. Residual risk ......................................................................................................................10
4.3. Safety labels.......................................................................................................................12
5. USING OF THE SCISSOR TRIMMER.................................................................................13
5.1. Attaching the scissor trimmer to the extension arm ..........................................................13
5.2. Transport position and drives ............................................................................................13
5.3. Operation ...........................................................................................................................14
5.3.1. Basic information about the operation........................................................................14
5.3.2. Initial adjustment and preparing for operation ...........................................................15
5.3.3. Safe start up and shut down........................................................................................15
5.3.4. Control ........................................................................................................................15
5.3.5. Proceedings in case work unit is locked.....................................................................15
5.3.6. Dismounting machine from the extension arm...........................................................15
6. MAINTENANCE AND SERVICE..........................................................................................16
6.1. Daily maintenance .............................................................................................................16
6.2. After-season maintenance and storing...............................................................................17
6.3. Restarting the machine after repairs or longer storing periods..........................................17
7. MALFUNCTIONS AND THEIR REPAIR ............................................................................18
8. DISMOUNTING AND WITHDRAWAL FROM USE .........................................................19
8.1. Repair.................................................................................................................................19
8.2. Disassembly and scrapping................................................................................................19
8.3. Environment ......................................................................................................................19
9. WARRANTY CARD ................................................................................................................20
10. WARRANTY TERMS..............................................................................................................20
10.1. Warranty terms procedures................................................................................................20
10.2. Warranty repairs record .....................................................................................................22

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 2 -
1. IDENTIFYING THE MACHINE
Data plate is permanently mounted to the main frame in place shown in Fig. 1.
Fig. 1. Placement of the data plate
Data plate includes
:
-
name and adress of the manufacturer,
-
model year
,
-
CE marking means, that the produce
-
version number
,
conforms to 2006/42/EC Directive and
-
m
achine weight
,
harmonized standards
,
-
id number
,
-
machine symbol
,
-
barcode
.
-
date of manufacture
,
CAUTION:
In case the operator's manual is unclear or illegible all necessary information
can be obtained from manufacturer or the dealer.
2. INTRODUCTION
 This operator’s manual should be considered as the basic scissor trimmer’s equipment. If the
machine is handed over to another operator, it should be in working condition and given away
along with operator’s manual and it’s other basic equipment.
 Prior to operating the scissor trimmer its user must familiarize himself with this manual as well
as common work safety rules.
 The scissor trimmer is manufactured in accordance with requirements of safety standards.
 Respecting warnings herein shall ensure full operation safety.
 If you have any questions related to commission and operation of the scissor trimmer, please
contact the manufacturer.
 This operator’s manual is an indispensable part of any machine and is intended to familiarize
future user with principles of proper operation and use of the machine as well as the risks
involved.
GENERAL PRECAUTION
When operating the scissor trimmer warnings and safety rules marked with this
sign herein should be respected.
CAUTION:
Operating the machine without previous familiarizing with its content as well
as by unauthorized personnel, and especially by children, is strictly forbidden.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 3 -
3. INTENDED USE AND DESIGN
Being an additional equipment of an extension arm, scissor trimmer is intended for works
near roads and in orchards for trimming branches, bushes, and hedges. Scissors trimmer can cut
branches with diameter up to Ø100mm (Ø10cm).
Scissor trimmers PG is designed to cooperate with the following extension arms:
 KWT
 Camel
 Fisher
Scissor trimmer can be mounted also on other type of extension arm with the same type of a
mounting plate or any other upon its previous adaptation.
Fig. 2. Mounting plate for scissor trimmer
CAUTION:
It is forbidden to use the machine for purposes other than those listed in this
instruction. Using the machine for other purposes will be classified as use not
according with the intended use and could exclude the manufacturer from
responsibility from any resulting damages. The machine should be used,
serviced and repaired only by persons familiar with its characteristics and with
safety regulations. Unauthorized modification of the machine may release the
manufacturer from responsibility for any resulting malfunctions or damages.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 4 -
5
2
3
1
4
6
7
8
3.1. Specifications
Tab. 1. General description of scissor trimmers
Characteristic parameters PG 150 (F), PG 150L (F) PG 200 (F), PG 200L (F)
Working diameter 1,5 m 2,0 m
Dimensions (length/width/height) 1500 mm/860 mm/220 mm 2000 mm/860 mm/220 mm
Max. technical cutting diameter 100 mm
Nominal WOM rpm (for SaMASZ
extension arm
)
300÷350 rpm
Recommended hydraulic oil 45÷60 l/min
Max. permissible pressure 16 MPa
Weight 200 kg 240 kg
Mounting on extension arm 6 bolts M14x50
Nozzles of hydraulic hoses M30x2
Transport speed Max 25 km/h
Number of operators One person
Drive type hydraulic
Level of noise emitted by the machine
L
pA
95 ± 1 dB
L
Amax
106 ± dB
L
Cpeak
109 ± dB
L
pA
– level of noise exposure related to an 8-hour work shift. Time-averaged acoustic pressure level
for emission corrected by frequency characteristic A.
L
Amax
– maximum value of measurement for acoustic pressure level for emission corrected by frequency
characteristic A.
L
Cpeak
– peak acoustic pressure level for emission corrected by frequency characteristic C.
3.2. Design and principle of operation of the scissor trimmer
Fig. 3. Description of scissor trimmer and working principle
Scissor trimmer generally comprises fixed lower cutting bar (7) and movable upper cutting
bar (5) and screwed together (6). Top cutting bar is powered by covered hydraulic cylinder. Double-
1
-
Hydra
ulic drive cover
5
-
Top cutting bar
2
-
Mounting plate
6
-
Upper bar set screw
3
-
Nozzles of hydraulic hoses
7
-
Lower cutting bar
4
-
Mounting plate tilt adjustment
8
-
Cutting bars cover

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 5 -
acting cylinder is controlled by reversing valve, and direction is changed by switching limit sensor
or increasing pressure in the system.
Mounting plate (2) enabling to connect the scissor trimmer and the extension arm by screwed.
The cutting bars cover is accompanied to machine (8).
3.3. Equipment and fittings:
The machine are sold with the following standard equipment:
 warranty card,
 operator's manual with spare part list and the Declaration of Conformity,
 spray paint (150 ml).
Equipment and spare parts:
 all parts in the spare part list.
4. SAFETY PRECAUTIONS
CAUTION:
Scissor trimmer is a device the use of which involves risk. The machine can
only be operated by personnel who have learned this manual.
Each operator of the scissor trimmer should be fully aware of potential risks
resulting from its operation and principles of their prevention.
When operating the scissor trimmer always wear protective clothing and
footwear as well as adequate personal protective equipment:
 Protective helmet
 Ear protection
 Protective gloves
Operator should always have a first-
aid kit within his reach
(Journal of Laws No. 12/98 item 51.)
4.1. Safety rules
4.1.1.Operating
 During operation of the machine the Regulation of the Farm Ministry and Food Economy
(Rozporządzenie Ministra Rolnictwa i Gospodarki Żywnościowej) from 12.01.1998 dealing with
safety and hygiene during the operation of tractors, machinery, tools and equipment used for
farming (Journal of Laws No. 12/98 item 51), should be observed.
 Before operating the scissor trimmer learn content of this operator's manual and follow rules
provided by the Manufacturer herein.
 Apart from this operator’s manual follow the instructions as given in the extension arm
operator's manual.
 Do not use the scissor trimmer for any purposes other than its intended use.
 Do not introduce any design modifications without prior arrangements with the Manufacturer.
 Failure to learn the operator’s manual can result in damaging the scissor trimmer.
 The machine must not be operated by minors or handicapped persons.
 Observe all safety signs, warnings or warning signs placed on the machine.
 When cutting it is forbidden to make any perpendicular motion with the extension arm in
relation to the cutting plane as this may damage the cutting bars.
 It is forbidden to operate the scissor trimmer when cutting bars are contaminated. Sand, rocks,
wires and other solid objects (non-wooden) cause accelerated blunting of blades and their
damage.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 6 -
 Do not operate the machine if cutting bars have significant plays on guides or there is no
lubricant in between.
 It is forbidden to use the trimmer for cutting any non-wooden materials.
 It is forbidden to operate the scissor trimmer if any damages are found.
CAUTION:
Be certain that children and animals are at a safe distance away from the
machine.
4.1.2.Attaching
 Mount and dismount the scissor trimmer on an extension arm with the latter mounted on a
tractor, and when the whole aggregation is prevented against moving by the tractor’s parking
brake engaged.
 When connecting hydraulic hoses to the scissor trimmer nozzles wear protective gear such as
eyewear, gloves and clothing.
 Mount and dismount the scissor trimmer from extension arm on an even and paved surface
while keeping particular attention.
 Tractor's 3-point linkage should be adjusted with tensioning chains, so as to ensure a stiff
connection between the tractor and the extension arm, onto which the scissor trimmer is to be
mounted.
 Tractor with the mounted aggregation of the extension arm and the scissor trimmer should be
balanced so as to provide the stability of the aggregation including the tractor and the extension
arm.
 In order to mount the scissor trimmer on the extension arm use original fittings and safety
devices only.
 When connecting hydraulic hoses to the tractor's hydraulic connectors make sure, that the
hydraulics on either the tractor or the extension arm aggregate are pressure free.
 Before connecting the hydraulics reduce pressure in hoses.
4.1.3.Operation
 When operating on public roads always respect the local traffic regulations..
 Admissible slope, on which the machine is able to operate is provided by the Manufacturer.
Angular value for safe operation on slope is 8º (Journal of Laws No. 12/98 item 51.)
 Unauthorised personnel and animals should keep away from the scissor trimmer for a safe
distance, which is at least 10 m from the machine. Keep particular attention when operating near
roads and lanes, where presence of unauthorized personnel is likely.
 When operating the aggregation of arm and scissor trimmer, make sure the tractor is always
equipped with operator's cabin.
 Before operating, the machine should undergo a technical inspection. Pay particular attention to
the condition of basic connections of the machine’s assemblies as well as proper mounting of
the machine to the tractor.
 Each time before operating, check condition of the cutting knives along with cutting disk, and if
need be, deliver it for recovery or replace.
 Before starting the tractor, make sure that all drives are disconnected and control levers for
hydraulics are in neutral position.
 Before moving, make sure whether there are no unauthorised personnel directly nearby the
machine, give an acoustic signal.
 Never leave the tractor’s engine running without any supervision. Before leaving the tractor,
turn the drive off, set the aggregation of tractor and extension arm and the scissor trimmer in a
standstill position and remove the ignition key (Journal of Laws No. 12/98 item 51.)
 For any break in the machine operation, disconnect the drive (Journal of Laws No. 12/98 item
51.)

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 7 -
 Scissor trimmer should be operated with the PTO shaft running at 300-350 rpm (applicable for
the SaMASZ extension arm).
 Perform any manoeuvring of the scissor trimmer only from the operator’s seat. Do not control
the machine from outside the tractor’s cabin.
 The operator is not allowed to leave the tractor while driving.
 Operate the scissor trimmer only when the tractor is not moving, and move the scissor trimmer
only by the extension arm and adjust the operation to conditions such as size and number of
scissor trimmer to be ground.
 Low speed is recommended. During work at higher speed, the scissor trimmer and the extension
arm may be destroyed.
 Do not operate the scissor trimmer after dusk.
 Do not leave the aggregation of tractor and extension arm on slopes or other inclinations
without providing any additional protection.
 Do not operate with damaged or missing guards (Journal of Laws No. 12/98 item 51.)
 In case of a fatal failure, stop the machine's drive, turn the tractor's engine off and take out the
ignition key. Then call for technical service, and if an accident (in this case: road accident)
occurs, respect first aid rules and contact responsible authorities.
4.1.4.Inspection and repair
 Perform any inspection, repair and maintenance works as well as cleaning parts or assemblies
when the drive is switched off and there is no pressure in the hydraulics, having taken the
ignition key off and set the aggregation of tractor and machine in a standstill position (Journal
of Laws No. 12/98 item 51.)
 Inspect bolts and other fasteners regularly. Do not operate with damaged or worn fasteners.
 Do not operate with damaged or worn fasteners. When the rubber guard shows signs of ageing
(e.g. micro cracks over the surface), it should be replaced.
 Do not perform any repair works underneath the lifted machine’s assemblies, unless protected
against free falling (Journal of Laws No. 12/98 item 51.)
 Replace damaged or worn (aged 5 years or older) hydraulic hoses and other hydraulic parts as
recommended by the Manufacturer.
 Never repair damaged hydraulic hoses with tape.
 Do not perform any repair works underneath the lifted machine’s assemblies, unless protected
against free falling (Journal of Laws No. 12/98 item 51).
 Before any operation, check the condition of cutting knives. If blunt, rotate the knife by 1/3 turn
(3 sharp cutting edges per a single knife can be achieved), or handle it for a recovery. Damaged
or worn blades must be replaced.
 Use only original spare parts ordered at our store or at your dealer.
 During operation, maintenance and adjustment, always wear protective gloves, shoes and
clothing without loose elements, belts, etc. Always respect warnings on safety labels attached to
the machine.
 When operating the hydraulics, always wear protective eyewear and gloves. Hydraulic oil
leaking under pressure (16 MPa) may penetrate the skin and cause its irritation thereafter. In
such case, visit a doctor immediately.
 In the event of a serious failure, please call for technical service, and if an accident (in this case:
road accident) occurs, respect first aid rules and contact responsible authorities.
CAUTION:
Before maintenance and repair the machine, turn off the engine of tractor. All
rotating parts should be stopped.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 8 -
4.1.5.Replacement of damaged or worn parts
 Any works related to replacement of worn or damaged parts should be done only after the
machine has been switched off, and having previously learned the contents herein.
 After the engine has been turned off and the ignition key removed, the vehicle should be
secured against any accidental movement.
 When conducting repair works or replacing worn or damaged parts wear protective gloves,
protective footwear as well as protective clothing without any loose elements.
 When operating with the machine lifted up, protect it properly with supports and when replacing
parts with sharp edges, use personal protective equipment and corresponding tools.
 Once works related to replacement of defective parts are completed, mount back all elements of
guards and safety devices.
CAUTION:
During replacement of working parts, it should be used personal protective
gloves.
4.1.6.Storage
 Scissor trimmer should be stored under a roof and protected against access of animals and
unauthorised persons who could get injured.
4.1.7.Qualifications of operator
To provide safe machine operation each person being the machine operator must meet the
following requirements:
 Operator should hold driving license, have ability to drive vehicles safely and know road traffic
rules.
 Operator must be in proper physical condition to be able to operate the machine.
 Operator must not be under the influence of alcohol, drugs and medicines, which all have
influence on vehicle driving and machine operation.
 Operator should be familiarized with this manual and follow its provisions.
 Operator should be familiar with working principles of both the tractor and the machine, and be
able to recognize and avoid hazards resulting from operation of the aggregate.
4.1.8.Transport
 When driving on public roads always respect the local traffic regulations.
 For transport of the aggregation of arm and machine, remove or partially disconnect the PTO
shaft from the tractor’s side.
 For transport protect blades on the machine with an additional protective guard.
 While transporting the above aggregation mount remote warning light device and warning
triangle for a slow driving vehicle.
 During transport, always set the scissor trimmer in its proper and safe transport position.
 Any modifications in the machine‘s position are possible only if no vehicles or unauthorized
personnel are around (children in particular).
 Do not drive over 25 km/h (15 mph).
 While transporting, if hydraulics are damaged, the extension’s arm cylinder should be protected
with a special lock (channel section on the cylinder’s rod).

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 9 -
4.1.9.Putting the machine onto another vehicle for transport
Both the driver and the carrier are responsible for the machine's safe transport. Any equipment
and parts must be secured for transport. The following rules should be observed when placing a
machine onto a transport vehicle:
 Using lifting devices grab only stiff elements on the machine such as housing and mounting
plate.
 In order to lift the machine, use only lifting devices of hoisting capacity bigger than the
machine’s weight provided on the data plate.
 When the machine is to be transported, make sure to install the guard on cutting bars.
 On the vehicle's trailer, the scissor trimmer should be protected against moving.
When the machine is to be transported, make sure to install the guard on cutting bars. Cover the
machine with bubble foil and fix it on a pallet with duct tape. Any further moving of the machine
should be done with the fixed pallet, considered as its integral part.
To place the scissor trimmer on a pallet use belt suspension and lifting device with capacity of
no less than the trimmer's weight.
CAUTION:
The person in charge of the machine's transport shall be responsible for
securing the danger area and performing the work.
4.1.10. Hydraulic assembly
 Caution! Hydraulic assembly is under pressure! Hydraulic oil under pressure may permeate
through skin and cause serious injury, therefore skin and eyes should be protected in particular.
In case of injuries caused by a liquid under pressure, call a doctor immediately.
 Hydraulic hoses can be connected to tractor's hydraulics, provided that both the extension arm’s
and the trimmer's hydraulic assemblies are not under pressure. To remove the pressure from the
hoses just simply restart the tractor's hydraulic valves several times, once the tractor is off.
 When dismounting the machine from the tractor, set the equipment aside, deflate the pressure
from hydraulics and turn tractor's engine off.
 When controlling for hydraulic assembly's malfunction and looking for oil leaks, it is forbidden
to touch any potential leaks until the entire assembly is under pressure.
 Note! It is recommended to use hydraulic oil featuring oil purity class <10 in accordance
with NAS 1638.
When using hydraulic hoses:
 Avoid stretching the hoses when operating.
 Do not allow hydraulic hoses to get deflected.
 Do not expose hydraulic hoses to contact with any sharp edges.
 If damaged or worn, replace the hoses with new ones.
 Useful life for hydraulic hoses is 5 years from their production date.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 10 -
4.2. Residual risk
Despite the fact, that company SaMASZ– the manufacturer of the machine takes
responsibility for design and manufacturing of the rake, in order to eliminate dangerous
situations, certain risk during machine’s operation is unavoidable. Residual risk results from
incorrect behaviour of the scissor trimmer operator.
Major source of risk follows performance of these operations:
 operation of machine by minors as well as not being familiarized with operator's manual,
 operation of machine by persons under influence of alcohol or other abusive substances,
 not keeping caution while transportation and shifting of scissor trimmer during operation,
 transport of persons remaining on the machine,
 presence of persons and animals within the machine operation range,
 performing operations related to servicing and adjustment with engine on.
1. Danger of catching
This kind of risk is present when position of machine is being changed, as a result of
operating near rotating parts.
During operation, maintenance and regulations always wear protective gloves, shoes and
clothes without loose parts, belts and so on. Always comply with safety decals placed on the
machine.
2. Danger of injury and abrasion
This risk is present when replacing working parts with sharp edges, cleaning the machine,
removing the clogging and jams. During any maintenance and repair works, always wear safety
gloves.
3. Danger of cutting limbs off
Contact between cutting knives and body may lead to serious injuries, and in extreme cases
amputation of limbs or even death. Failure to pay enough attention when operating the machine
nearby unauthorized personnel may cause an accident.
4. Danger of kick
Kick is one of the most dangerous accidents which are likely when operating machine. It is
described as uncontrolled, sudden and very quick motion of an object or part of it being processed
(splinter, knurl, etc.). Direct impact of the material against human body may cause, depending on
the material weight and size, as well as speed and the impact location, bruises, injections, loss of an
eye, teeth, or even death due to damage to organs and vast internal haemorrhages.
5. Danger of irritation to the respiratory tract
Lesser threat when cutting is also a dusty atmosphere as emission of significant fractions of fine
chips and dust. The operator thus should operate in a tight cabin with proper airflow.
6. Danger of liquid ejection out of hydraulic system
During connection of hydraulic hoses to hydraulic connectors make sure, that either the
extension arm’s and the trimmer's hydraulic system is without pressure.
During operation of hydraulic system always wear protective glasses and gloves. Check
regularly hydraulic hoses.
CAUTION:
Residual risk results from incorrect behaviour of the machine operator.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 11 -
7. Prohibited actions
Bear in mind the following prohibited actions when operating machine:
 Do not remove impurities, make any adjustments or repairs when the scissor trimmer is
operating.
 Never change the sequence of operation and maintenance works as specified herein.
 Never use the scissor trimmer, if it is not in operating condition.
 Never get near the machine’s operating parts.
 During repair and maintenance works at scissor trimmer always follow descriptions included
herein, and perform them when the tractor’s drive is turned off.
 Before any works, focus your attention solely on the tasks to do.
 Never operate the scissor trimmer when being under the influence of alcohol, drugs or
medicines which impair your motor skills.
 Scissor trimmer cannot be operated by unauthorized and unskilled personnel.
 Scissor trimmer cannot be operated by minors and handicapped persons.
 When operating the scissor trimmer, observe whether there are no unauthorized personnel and
animals around.
When describing residual risk, the scissor trimmer shall be considered a machine, which until
the moment of its production had been designed and manufactured in accordance with the state-of-
the-art as per its manufacture date.
CAUTION:
Despite following the specified instructions and prohibitions, residual risk is
still present.
8. Residual risk evaluation
When keeping such recommendations as:
 thorough familiarizing with operator’s manual,
 no persons remaining on the machine when operating and during drives,
 no persons remaining within the machine operation range,
 adjustment, maintenance and lubrication of the machine with engine off,
 performing repairs of the machine only by skilled persons,
 operation of the machine by persons, which are familiarized with operator’s manual,
 in the event of the machine protection against children and unauthorized personnel residual risk
when operating the scissor trimmer may be limited to necessary minimum.
In the event when avoiding or eliminating professional risk resulting from
exposure to noise is not possible through use of mass safety device or work
organization, the employer (farmer):
1) makes available personal hearing safety devices if the levels of noise in
working environment exceed 80 dB.
2) makes available personal hearing safety devices and ensures they are
properly used if the levels of noise in the working environment reach or
exceed 85 dB.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 12 -
4.3. Safety labels
CAUTION:
Always follow the safety labels describing risks, and warning signs attached
to the machine.
CAUTION:
a) all warning decals should be clean and legible,
b) lost or damaged decals must be replaced,
c) please order new decals from your dealer or supplier.
N-3
Before use read the operator’s
manual
N-4
Disconnect the machine before
approaching any service or
repair works
N-7
Operating is forbidden when
any person is within the danger
area of 50 m / 170 ft
N-23
Caution: power lines
N-49
Do not remain in machine’s
swinging area
N-99
Danger of crushing
N-105
Warning: cutting elements
N-52
Wear protective gloves
N-100
Wear pr
otective eyewear
N-101
Wear protective clothing
N-102
Wear protective helmet
N-103
Wear ear protection

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 13 -
CAUTION:
Spare assemblies used for the scissor trimmer repair should hold all warning
labels provided by the manufacturer.
5. USING OF THE SCISSOR TRIMMER
5.1. Attaching the scissor trimmer to the extension arm
In order to mount scissor trimmer on extension arm do the following in a sequence:
 place pallet with scissor trimmer on an even and paved ground,
 drive the tractor with the attached extension arm and position the mounting plate of the arm so it
matches the scissor trimmer‘s mounting plate,
 secure the tractor against moving,
 bolt trimmer‘s mounting plate to the arm's mounting plate with bolts and M14 nuts,
 connect hydraulic hoses using push-in fittings while paying particular attention so that the
scissor trimmer’s supplying hose is connected to the supply connector P(+) of the extension arm
and the scissor trimmer’s return hose to return connector T(-) of the extension arm,
 lift up the connected scissor trimmer slightly above the pallet and check all bolt connections and
whether there are no apparent damages,
 take off the cutting bars cover and next pre-start scissor trimmer in order to check whether
connections and operation are correct.
Fig. 4. Markings of hydraulic hoses
CAUTION:
When connecting and inspecting the scissor trimmer, follow any and all safety
conditions provided herein.
5.2. Transport position and drives
Transport position of scissor trimmer aggregated with SaMASZ extension arm corresponds to
the arm's transport position. See.
When mounting the scissor trimmer on other type of extension arm, fold the scissor trimmer
aggregated with the arm in the position as compact as possible.
 To transport the aggregation of arm and scissor trimmer, use any protective means as intended
for control and design of the extension arm.
 Dismount the PTO shaft for transport.
 Provide proper marking and lighting of the aggregated machines for a low-speed vehicle to
comply with road traffic provisions.
 Driving speed should always be adjusted to current road conditions.
 Transport speed on public roads cannot exceed the mean speed of 25 km/h (15 mph).

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 14 -
Fig. 5. The machine in transport position
5.3. Operation
5.3.1. Basic information about the operation
In order to ensure proper high-quality operation, as well as to maintain machine's durability
follow these rules::
 respect work safety and traffic rules solely,
 scissors trimmer can cut branches with diameter up to Ø100mm (10 cm),
 keep hydraulic oil consumption for scissor trimmer’s supply pump at max. 45÷60 l/min. For
SaMASZ extension arm such demand is achieved at tractor’s PTO shaft rpm of 300-350 rpm,
 it is recommended for the operator before cutting to set the machine in an adequate position and
does not modify such position on a single drive. Such manner of operation provides work safety
and treatment aesthetics,
 longer branches should be cut gradually, starting from the top and moving to the bottom for the
likeliness of damaging the tractor by falling cut branches.
 remember to adjust driving speed to the thickness and quantity of the branches being cut at the
same time so as not to overload the scissor trimmer and thus prevent it from jamming,
 when cutting do not make any perpendicular motion with the extension arm in relation to the
cutting plane as this may damage the cutting bars
 cutting plane when using scissor trimmer should be as parallel to driving direction as possible,
 it is forbidden to operate the scissor trimmer when cutting bars are contaminated. Sand, rocks,
wires and other solid objects (non-wooden) cause accelerated blunting of blades and their
damage,
 do not operate the machine if cutting bars have significant plays on guides or there is no
lubricant in between,
 it is forbidden to use the trimmer for cutting any non-wooden materials,
 for long operating periods, it is recommended, on few-hours basis, to periodically inspect
cutting bars, bolt connections, as well as the scissor trimmer itself,
 it is forbidden to operate the scissor trimmer if any damages are found. For further operation,
immediately correct any damages,
 if cutting bars become blunt, order their recovery or replace them.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 15 -
5.3.2.Initial adjustment and preparing for operation
Scissor trimmer is factory adjusted and requires no additional adjustments. If any signs of
improper operation of the machine are found, please contact the Manufacturer's service.
Before operating the machine do the following:
 set tilt by means of mounting plate tilt adjustment,
 thoroughly examine the machine for operational condition, plays and damages. Pay particular
attention to condition of bolt connections on cutting knives,
 remove any guards, locks and safety devices mounted on the aggregation of extension arm and
scissor trimmer,
 connect the PTO shaft to the tractor,
 having made sure there is no unauthorized personnel around, start machine with no load and
reach the pre-set PTO rpm rate, and then shut down and check for tightness,
 if the machine's condition and its idle operation raise no doubts, start operating.
5.3.3.Safe start up and shut down
Before operating make sure there are no unauthorized personnel or animals within the range
of 10 m. Next set the machine in the mean working position and start it afterwards.
Before stopping the machine first stop cutting by driving the scissor trimmer into a space with
no branches or bushes around. Then turn off the machine's drive. After this it is possible to start
operation of the extension arm in order to set the arm-trimmer aggregate to transport position.
5.3.4.Control
Scissors trimmer is controlled with the extension arm control panel.
5.3.5.Proceedings in case work unit is locked
 Lower adaptor onto the ground.
 Perform any works at the machine only with its drive turned off and no pressure present in the
hydraulics.
 Remove the ignition key and secure the vehicle against uncontrolled movements or unintended
start up.
 Wear protective gloves and remove the part which causes the machine's locking.
5.3.6. Dismounting machine from the extension arm
To dismount the machine from the extension arm:
 turn cutterbar’s drive off,
 drive the tractor with connected the extension arm and the scissor trimmer to the pallet. The
pallet must be placed on the equal and hardened ground,
 carefully put a scissor trimmer on a pallet,
 secure the tractor against its free runaway,
 turn the tractor's engine off and take ignition key off,
 fit a cutting bars cover,
 disconnect a hydraulic hoses,
 disconnect trimmer’s mounting plate from the extension arm’s mounting plate by unscrewing,
 carefully drive away with the tractor.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 16 -
6. MAINTENANCE AND SERVICE
CAUTION :
Use only original SaMASZ fittings and spare parts. Spare parts of unknown
origin or new made are of less strength and have unfavourable influence the
on machine’s overall performance and safety.
CAUTION:
The SaMASZ co. shall not bear any responsibility for damages and defects
caused as a result of applying non-genuine parts and fittings.
6.1. Daily maintenance
Each time before operating the machine do the following:
 make sure that both the tractor and the extension arm, which the machine is mounted on, work
properly,
 examine bolt connections of cutting disk, knife holders, knives and tighten if necessary,
 examine torque of all bolts and nuts,
 tighten set screws so as to remove play between cutting bars
 examine condition of hoses and hydraulic connections,
 examine condition of cutting bars, and if needed, order their recovery or replace,
 replace damaged parts,
 lubricate all lubrication points marked with special label as in Fig. 6
Fig. 6. Lubrication point
After 4-5 hours of operation:
 check the play between cutting bars, and if needed correct using set screws for upper cutting
bar,
 check for any loosened bolts, and if needed tighten using torque values,
 examine condition of hoses and hydraulic connections,
 examine cutting bars for function,
 lubricate.
Once operation with the trimmer is complete, do as follows:
 clean and wash thoroughly,
 if needed, lubricate all lubrication points marked with special label as in Fig. 6.

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 17 -
6.2. After-season maintenance and storing
After the machine has been dismounted from the extension arm, for idle period longer than one
month, perform the following maintenance works:
 clean the machine thoroughly from any soiling and then wash and dry,
 if need be, perform any repairs, adjustments, replacement of sealing or hoses,
 lubricate all lubrication points marked with special label as in Fig. 6,
 remove any sources of corrosion and complement any paintwork defects,
 protect non-painted metal surfaces with a thin film of a solid grease, e.g. ŁT – 43, or gearbox,
mineral or motor oil, e.g. 15W40,
 complement or replace illegible warning and information labels,
 close connection nozzles of hydraulic hoses,
 install the guard on the trimmer's cutting bars.
The machine should be stored in a standstill position in a dry and clean place, inaccessible to
unauthorised personnel and animals, on an even and paved ground under a roof or any other cover
protecting it from the weather.
6.3. Restarting the machine after repairs or longer storing periods
 Make sure that all nuts and screws are tightened with correct torque (Tab. 2).
 Examine technical condition of hydraulics and drive train as on daily basis.
Tab. 2. Values of bolt tightness

Operator’s manual
SCISSOR TRIMMER
PG 150 (F), PG 200 (F)
PG 150L (F), PG 200L (F)
- 18 -
7. MALFUNCTIONS AND THEIR REPAIR
Defect Reason Repair
Trimmer will not cut
Damaged cutting bars
Order a recovery or replace
Too low PTO rpm Switch rpm to 300-350, increase
engine
’
s rotary speed.
Worn guide and pressure blocks Replace guide and pressure
blocks
Worn, damaged hydraulic engine Recover hydraulic cylinder or
replace
Protracted or sheared cylinder
mounting pin
Install or replace
Not tight hydraulics
Seal or tighten connectors
Improperly adjusted or damaged
oil distributor
Adjust or replace
Improperly connected hydraulic
hoses
Swap connections
Trimmer will not cut
Damaged or blunt cutting bars Order a recovery or replace
Too low pressure of upper cutting
bar on lower cutting bar
Tighten set screws on upper
cutting bar
Too slow motion of
cutting bar
Low rpm
at tractor's PTO
Increase tractor's engine rotary
speed
Overtightened set screws
Loosen set screws
Worn skid
Replace for a new
Worn guide and pressure blocks Replace for a new
No lubrication
Lubricate
Hydraulic system leaking
Seal up
Loud operation
Worn skid
Replace for a
new
Worn guide and pressure blocks
Replace for a new
Plays on cylinder mounting pins
Replace for a new
Loosened bolt connections
Tighten the bolts
Oil leak
Improperly bolted connecting
nozzles
Bolt connecting nozzles
Worn, damaged sealants, fittin
gs
Replace sealants, fittings
Not tight hydraulic cylinder
Recover
Replace
