Sami Max WS-2328 User manual
WEARABLE
User Manual
WS-2328
Thank you for purchasing the Sami wearable WS-2328. Read the instructions carefully to obtain optimum results and
preserve it for future reference.
DESCRIPTION OF THE WEARABLE.
CONTENTS.
Wearable, USB clip charging cable, instruction manual.
CHARGING.
Connect the device to a computer or laptop with the USB charging cable. Insert the charging thimbles of the charger into
the charging points positioned in the back of your device. Kindly use only the USB cable included with the wearable. If you
use a power adapter for charging, the output of the power adapter should be 5V, 1A. Charging time: 2 hours. Please
charge the device fully before using it.
HOW TO POWER ON / POWER OFF?
1) To turn ON the smart band, long press the touch button for a few seconds. The touch button is situated in the
bottom of the of the screen.
2) To turn OFF the smart band, while the device is in the home screen menu, slide on the screen from the bottom to
the top of the screen to change between the different menus of the device. Slide on the screen until you find the
settings icon, with the touch button tap on this icon to enter in the settings menu, slide again in the screen from the
bottom to the top until you see the power off icon, tap in the power off icon to make it Power off.
HOW TO CONTROL?
This device is equipped with a full touch display screen, it supports full screen touch control.
1) On the display screen, tap the touch button to light up the screen, or to return to the home page. The touch button
is situated at the bottom of the screen.
2) In the home page, long press the screen for few seconds until the screen zooms out, then slide the screen left or
Full touch screen
Touch button
Charging Points
Heart Rate Sensor
right to change the digital clock styles.
3) In the home page, tap and slide from the top of the screen to the bottom of the screen to display the menus of: BT
pairing status, don’t disturb mode ON/OFF, brightness setting. To adjust the brightness of your smart band tap in the
brightness icon once or a few times until you get your desired screen brightness.
4) In the home page, tap and slide from the bottom to the top of the screen to change between the different menus
of the device: Steps, sleep control, music control, weather, sports modes, heart rate, blood pressure, blood
oxygen(SPO2), alarm clock, stopwatch, BT Camera, find your phone, timer, and Settings. Tap and slide up or down
to go to the next/previous page. Short tap in the icon to select/enter in that menu. In the submenus tap and slide
left/right to go to the next/previous page. Tap and slide on the screen from left to right to return back.
5) In the home page, tap and slide on the screen from left to right, to display the messages.
6) In the home page, tap and slide on the screen from right to left, to display the heart rate.
GETTING STARTED:
- For Android
1) How to obtain the BT Connection APK (FUNDO PRO)
Search for the FUNDO PRO APP in the Play Store; download it and install it in your Android smartphone, or go to our website
www.sami.es and download the application.
2) Installation of the FUNDO PRO APK.
When installing the FUNDO PRO application on your Android, you must allow all the Application Permissions, allow this
FUNDO PRO app auto run.
The first time you run this FUNDO PRO app, it will ask you to Enable Notifications, please tap OK and tap the FUNDO PRO and
confirm OK. You must tap OK/Allow/Pair/Yes/Confirm for any pop-up request. On your Android permission management,
allow all application permissions.
3) How to make the wearable pair with your Android smart phone?
*First, turn on the Bluetooth of your Phone.
*Second, run the FUNDO PRO app on your Phone, on the home page of FUNDO PRO, select “More”and select ‘’Connect
a device’’, the APP will search for new Bluetooth device(s), when the available Bluetooth device displays, please select Q7
or WS-2328 (the BT name of this device) to make it pair. The pairing will be finished in a few seconds. When you pair for the
first time, the FUNDO PRO app will ask you to fill some personal information such as gender/age/height/weight. When you
finish select OK/Confirm/Allow for any pop-up request.
* Now you can start using your desired functions of the smart band.
Important: To enable all notifications of different softwares such as WhatsAPP, Facebook, Skype, Twitter, you will need to
turn on the notifications on the APP manually. On the FUNDO PRO homepage, select the icon “More” (situated on the right
bottom of the screen), and turn on all the APP notifications you want to active.
For Android smart phone, in order to achieve all of the functions which are supported by the Fundo app, you must allow
the Fundo app runs in background, you must tap OK/Confirm/Allow/Yes for any of the pop-up request at the 1st time of
running of the Fundo APK/APP. And it may ask you to turn on the Fundo app in the Android smart phone’s Accessibility: go
to the settings of the smartphoneAccessibilityfind the Fundo app and turn it on.
- For iPhone
1) How to obtain the BT Connection APP? (FUNDO PRO)
On iPhone, please go to APP Store and search FUNDO PRO and install the app.
2) How to make the wearable pair with your iPhone?
*First, turn on the Bluetooth of iPhone
* Run the FUNDO PRO app on the iPhone, on the home page of FUNDO PRO, tap and select “More”, select ‘’Add
device’’ the APP will search for new Bluetooth device(s), when the available Bluetooth device displays, please tap Q7 or
WS-2328 (the BT name of this device) to make it pair. The pairing will be finished in few seconds. When you finish select
OK/Confirm/Allow for any pop-up request.
*Now you can start using your desired functions of the smart band.
Important: To enable all notifications of different softwares such as WhatsAPP, Facebook, Skype, Twitter, you will need to
turn on the notifications on the APP manually. On the FUNDO PRO homepage, select the icon “More” (situated on the right
bottom of the screen), and turn on all the APP notifications you want to active.
PRODUCT FEATURES
BLUETOOTH (V 4.0)
TOUCH BUTTON
TOUCH SCREEN. Capacitive touch screen 1.3" full touch screen
BUILT IN VIBRATING MOTOR
BUILT IN HEART RATE SENSOR
BUILT IN GRAVITY SENSOR
GESTURE CONTROL TO LIGHT UP THE DISPLAY SCREEN
DISPLAY SCREEN INTERFACE
1) Time/Date/Steps/Calories displaying
2) Walking –steps, distance, calories
3) Sleep monitor
4) Music Control
5) Weather (It will be displayed only after your smart band is successfully paired with your mobile phone)
6) Sports –different sport modes including Walking/Running/Cycling/Climbing/Swimming/Basketball/Football/Ping Pong
7) Heart Rate
8) Blood pressure test
9) Blood Oxygen (SPO2) test
10)Alarm Clock –Support to set it at FUNDO PRO APK/APP.
11)Stopwatch
12)Camera –remote control to take photos. You need to run the camera at your smartphone.
13)Find phone –your smartphone will vibrate. You may need you to turn the vibration OFF at the Fundo PRO APK/APP.
14)Timer
15)Settings –Sedentary ON/OFF, (Raise hand to light up screen), Reset, Shut down
Data can be sync from the wearable to the smart phone on the FUNDO PRO APK/APP.
Your smart phone will synchronize when the Bluetooth is paired with this device.
FUNCTIONS
PHONE CALL NOTIFICATION - vibrating reminder for incoming phone calls. This function needs to be turned on manually at
the FUNDO PRO APK/APP.
MESSAGE NOTIFICATION - vibrating reminder for incoming messages, including SMS, WhatsApp, Facebook, Twitter, Skype
messages, etc. This function needs to be turned on manually at the FUNDO PRO APK/APP.
CLOCK SCREENS (Different home digital clocks) - In the home screen of the smart band, long press the screen for a few
seconds to change the style of the digital clock.
SLEEP MONITOR - build in
ALARM CLOCK - supported on the FUNDO APK/APP
FIND THE DEVICE (Looking for the SMART BAND)
REMOTE SHUTTER - (remote control your smartphone’s camera)
STOPWATCH
SEDENTARY REMIDER(REMIND TO MOVE) –set it on the FUNDO PRO APK/APP
Do Not Disturb Mode –set it on the FUNDO PRO APK/APP
DRINK REMIDER - set it on the FUNDO PRO APK/AP
GESTURE CONTROL (Raise your hand to light up the screen). You need to turn it on manually.
TECHNICAL SPECIFICATIONS:
Display screen: Capacitive touch screen 1.3". Full touch screen
Screen resolution: 240x240pixels.
Internal Memory: RAM 512KB, ROM 64KB+64Mbit
System: Nucleus
CPU: NRF52832
Charge I/O port : USB Clip charging cable
Battery: Built in Li-Polymer 220mAh
Stand by time: 15~20 DAYS
Working time: 5 DAYS
Bluetooth: 4.0.
Water-resist Rating: IP68 this device resists 30 meters waterproof
Weight: 39 g
Exterior Dimensions: 41.6*33.2*11mm
Declaration of Conformity
Hereby we,
Name of manufacturer:
SANTOSHI SL
Address:
CALLE FELIPE ASENJO N.56
Zip code & City:
28947 - FUENLABRADA ( MADRID )
Country:
SPAIN
declare that this DoC is issued under our sole responsibility and that this product:
Product description:
Smart Band
Type designation(s):
WS-2328
Trademark:
SAMI WEARABLE
is in conformity with the relevant Union harmonization legislation:
DIRECTIVE EMC 2014/30/EU
DIRECTIVE LVD 2014/35/EU
Standard CE (RED): DIRECTIVE 2014/53/EU
Standard RoHS: 2011/65/EU: (RoHS) Restriction of Hazardous Substance.
with reference to the following standards applied:
EN 60950-1: 2006+A11:2009+A1:2010+A12:2011+A2:2013
EN 62479:2010
EN 301 489-1 V2.1.1 (2017-02)
EN 301 489-17 V3.1.1 (2017-02)
EN 300 328 V2.1.1 (2016-11)
Signature
Full name: VISHAL MIRPURI
Position: ADMINISTRATOR
Date: 01 / 07 / 2019
