Samsung DVM PLUS III Instruction manual

Outdoor Units
Outdoor Units
SAMSUNG DVM Air Conditioner
DVM PLUS III
2010
North America for 60Hz

Outdoor Units

Outdoor Units

2
1
2
3
Outdoor units
Indoor units
Accessories
I. Products
6
9
11
1
2
3
4
5
6
7
8
Specifications
Dimensional drawing
PCB connector layout
Electrical wiring diagram
Sound pressure level
Operation limit
Cycle operation mode
Cycle function parts
II. Outdoor units
14
20
22
24
25
28
29
36

3
Outdoor unitsProducts Installation
1
2
3
4
5
6
7
8
Outdoor unit combinations
Space requirements
Placing the outdoor units
Electric specifications
Wiring works
Refrigerant piping works
Option switches & function keys
Error codes
III. Installation
40
41
44
45
46
48
55
57

4
DVM PLUS III

5
Products
I. Products
1Outdoor units .............................................6
2Indoor units ................................................9
3Accessories .............................................11

6
1Outdoor units
1-1. Nomenclature
Classification
Outdoor unit (R410A) RVX
Capacity*
×1/10 HP(3 digits)
Type
Mini DVM M
DVM PLUS III
V
DVM PLUS III HR
Airflow direction
Upward airflow T
Frontward airflow F
Mode
Heat Pump H
Heat Recovery R
Rating voltage
1Ø, 220~240V, 50Hz E
3Ø, 208~230V, 60Hz F
3Ø, 380~415V, 50Hz G
3Ø, 380V, 60Hz H
3Ø, 460V. 60Hz J
Version
Export A~Z
Domestic(KOREA) 0~9
* Index
HP TON BTU(MBH)
7.5 6 72
10.0 8 96
12.5 10 120
Model name
RVX
RVX

V
V

H
HT T

100
100 F F

E
E
  

7
Products
TON 6 8
HP 7.5 10.0
Model Name RVXVHT075/100FE
TON 10
HP 12.5
Model Name RVXVHT125FE
TON 12 14 16
HP 15.0 17.5 20.0
Model Name RVXVHT150/175/200FE
TON 18
HP 22.5
Model Name RVXVHT225FE
TON 20
HP 25.0
Model Name RVXVHT250FE
TON 22 24
HP 27.5 30.0
Model Name RVXVHT275/300FE
TON 26
HP 32.5
Model Name RVXVHT325FE
TON 28
HP 35.0
Model Name RVXVHT350FE
TON 30
HP 37.5
Model Name RVXVHT375FE
1-2. Line-up

8
1Outdoor units
1-3. Outdoor unit combinations
1) Basic models
2) Combinations
Classification Capacity (Ton) Capacity (HP) Model
Single unit
6 7.5 RVXVHT075FE
8 10.0 RVXVHT100FE
10 12.5 RVXVHT125FE
Classification Capacity (Ton) Capacity (HP)
Basic model
RVXVHT075FE RVXVHT100FE RVXVHT125FE
Module unit
12 15.0 2
14 17.5 1 1
16 20.0 2
18 22.5 1 1
20 25.0 2
22 27.5 1 2
24 30.0 3
26 32.5 2 1
28 35.0 1 2
30 37.5 3
