Samsung AC TXAD C Series User manual

Airconditioner
Installationmanual
AC***TXAD*C
• Thank you forpurchasing this Samsung airconditioner.
• Before operating this unit, please read this manual carefully and retain itforfuture reference.

2English
Contents
SafetyInformation 3
InstallationProcedure 5
Step1 Choosing the installation location 5
Step 2 Fixing the outdoorunit in place 8
Step 3 Connecting the powercables, communication cable, and controllers 9
Step 4 Optional: Extendingthe powercable 15
Step 5 Connecting the refrigerant pipe 17
Step 6 Optional: Cutting and flaringthe pipes 17
Step 7 Installing oil traps 18
Step 8 Connecting up and removing airin the circuit 19
Step 9 Adding refrigerant (R-410A) 20
Step10 Performing the gas leak test 21
Step11 Connecting the drain hose to the outdoorunit 21
Step12 Insulating the refrigerant pipes 22
Step13 Checking the earthing 23
Step14 Performing final check and trial operation 23
Extraprocedures 27
Pumping down refrigerant 27
Relocatingthe indoorand outdoorunits 27
Using the stop valve 28
Appendix 29
Troubleshooting 29
Correct Disposalof This Product
(WasteElectrical&ElectronicEquipment)
(Applicableincountrieswith separatecollectionsystems)
This marking on the product, accessories or literature indicates that the product and its electronic accessories (e.g.
charger, headset, USB cable) should not be disposed of with otherhouseholdwaste at the end of theirworking life. To
prevent possible harmto the environment orhuman health from uncontrolledwaste disposal, please separate these
itemsfrom othertypesofwasteand recyclethem responsiblyto promotethesustainablereuseof material resources.
²ͱЇϑʪ˵ͱʒЇϑʪθϑϑ˵ͱЇʒʀͱϩɇʀϩʪϩ˵ʪθϩ˵ʪθʪϩɇʪθи˵ʪθʪϩ˵ʪцΧЇθʀ˵ɇϑʪʒϩ˵ϑΧθͱʒЇʀϩࡥͱθϩ˵ʪθͱʀɇ˝ͱЭʪθʪϩͱ˙ѣʀʪࡥ
fordetails of where and howthey can takethese items forenvironmentallysafe recycling.
Businessusersshouldcontacttheirsupplierandcheckthetermsandconditionsofthepurchasecontract.Thisproduct
and its electronic accessories should not be mixed with othercommercialwastes fordisposal.

3
English
SafetyInformation
WARNING
• Hazards orunsafe practicesthat mayresult in severe
personal injuryordeath.
CAUTION
• Hazards orunsafe practicesthat mayresult in minor
personal injuryorproperty damage.
• Carefully followthe precautions listed belowbecause
theyare essential to guarantee the safetyof the
equipment.
WARNING
• Always disconnect the airconditionerfrom the power
supplybefore servicing it oraccessing its internal
components.
• Verifythat installation and testing operations are
performed byqualified personnel.
• Verifythat the airconditioneris not installed in an
easilyaccessible area.
Generalinformation
WARNING
• Carefully read the content of this manual before installing
the airconditionerand store the manual in a safe place in
orderto be able to use it as reference afterinstallation.
• Formaximum safety, installers should always carefullyread
the followingwarnings.
• Store the operation and installation manual in a safe
location and rememberto hand it overto the newownerif
the airconditioneris sold ortransferred.
• This manual explains howto install an indoorunit with a
split systemwith two SAMSUNG units. The use of other
types of unitswith different control systems may damage
the units and invalidate thewarranty. The manufacturer
shall not be responsible fordamages arising from the use of
non compliant units.
• The manufacturershall not be responsible fordamage
originating from unauthorized changes orthe improper
connection of electric and requirements set forth in the
“Operating limits” table, included in the manual, shall
immediatelyinvalidate the warranty.
• The airconditionershould be used onlyforthe applications
forwhich it has been designed: the indoorunit is not
suitable to be installed in areas used forlaundry.
• Do not use the units if damaged. If problems occur, switch
the unit off and disconnect it from the powersupply.
• In orderto prevent electric shocks, fires orinjuries, always
stop the unit, disablethe protection switch and contact
SAMSUNG’s technical support if the unit produces smoke, if
the powercable is hot ordamaged orif the unit is verynoisy.
• Always rememberto inspect the unit, electric connections,
refrigerant tubes and protections regularly. These
operations should be performed byqualified personnel only.
• The unit contains moving parts,which should always be
kept out of the reach of children.
• Do not attemptto repair, move, alterorreinstall the unit. If
performed byunauthorized personnel, these operations may
cause electric shocks orfires.
• Do not place containerswith liquids orotherobjects on the
unit.
• All the materials usedforthe manufacture and packaging of
the airconditionerare recyclable.
• The packing material and exhaust batteries of the remote
controller(optional) must be disposed of in accordancewith
current laws.
• The airconditionercontains a refrigerant that hasto be
disposed of as specialwaste. Atthe end of its life cycle, the
airconditionermust be disposed of in authorized centres
orreturned to the retailerso that it can be disposed of
correctlyand safely.
• Wearprotective equipment (such as safetygloves, goggles,
and headgear) during installation and maintenanceworks.
Installation/repairtechnicians maybe injured if protective
equipment is not properly equipped.
• This appliance is not intended foruse bypersons (including
children)with reduced physical, sensory ormental
capabilities, orlack of experience and knowledge, unless
theyhave been given supervision orinstruction concerning
use of the appliance bya person responsible fortheirsafety.
Children should be supervised to ensurethat theydo not
playwith the appliance.
SafetyInformation

4
SafetyInformation
English
SafetyInformation
• Foruse in Europe: This appliance can be used by
children aged from 8years and above and persons
with reduced physical, sensory ormental capabilities
orlack of experience and knowledge if theyhave been
given supervision orinstruction concerning use of the
appliance in a safeway and understandthe hazards
involved. Children shall not playwith the appliance.
Cleaning and usermaintenance shall not be made by
childrenwithout supervision.
Installingtheunit
WARNING
IMPORTANT:When installingthe unit,alwaysremember
ϩͱʀͱʪʀϩѣθϑϩϩ˵ʪθʪ˙θ˝ʪθɇϩϩЇɵʪϑࡥϩ˵ʪϩ˵ʪʪʪʀϩθʀɇ
lines.
• Upon receipt, inspectthe product toverifythat
it has not been damaged during transport. If the
product appears damaged, DO NOTINSTALLit and
immediatelyreport the damage to the carrieror
retailer(if the installerorthe authorized technician has
collected the material from the retailer.)
• Aftercompleting the installation, always carry out a
functional test and provide the instructions on howto
operatethe airconditionerto the user.
• Do not use the airconditionerin environmentswith
hazardous substances orclose to equipmentthat
release free flames to avoid the occurrence of fires,
explosions orinjuries.
• Do not install the product in a place where thermo-
hygrostat is needed (such as serverroom, machinery
room, computerroom, etc.) Those places do not
provide guaranteed operation condition of the product
therefore performance can be poorin these places.
• Do not install the product in a ship ora vehicle (such as
a campervan).
Salt, vibration orother environmental factormaycause
the product malfunction, electric shock orfire.
• Ourunits should be installed in compliance withthe
spaces shown in the installation manual,to ensure
accessibilityfrom both sides and allowrepairs or
maintenance operations to be carried out. The
unit’s components should be accessible and easy to
disassemblewithout endangering people and objects.
• Forthis reason,when provisions ofthe installation
manual are not compliedwith, the cost required to
access and repairthe units (in SAFETY CONDITIONS,
as set out in prevailing regulations)with harnesses,
ladders, scaffolding orany otherelevation system will
NOTbe considered part of thewarrantyandwill be
chargedto the end customer.
Powersupplyline,fuseorcircuit
breaker
WARNING
• Always make sure that the powersupplyis compliant
with current safetystandards.Always installthe air
conditionerin compliancewith current local safety
standards.
• Alwaysverifythat a suitable earthing connection is
available.
• Verifythat the voltage and frequencyof the power
supplycomplywith the specifications and that the
installed poweris sufficient to ensure the operation of
anyotherdomestic appliance connected to the same
electric lines.
• Alwaysverifythat the cut-off and protection switches
are suitably dimensioned.
• Verifythat the air conditioneris connected to the
powersupplyin accordancewith the instructions
provided in thewiring diagram included in the manual.
• Alwaysverifythat electric connections (cable entry,
section of leads, protections…) are compliant with
the electric specifications andwith the instructions
provided in thewiring scheme. Alwaysverify that all
connections complywith the standards applicable to
the installation of airconditioners.
• Devices disconnected from the powersupplyshould
be completelydisconnected in the condition of
overvoltage category.
• Be sure notto perform powercable modification,
extensionwiring, and multiplewire connection.
– It maycause electric shock orfire due to
poorconnection, poorinsulation, orcurrent limit
override.
– When extensionwiring is required due to power
line damage, referto "Step 4 Optional: Extending
the powercable" in the installation manual.

5
English
InstallationProcedure
InstallationProcedure
Step1 Choosingtheinstallationlocation
Installationlocationrequirements
• Do not place the outdoorunit on its side orupside
down. Failing to do so maycause the compressor
lubrication oil to run into the cooling circuit and lead
to a serious damage to the unit.
• Install the unit in a well-ventilated location away from
direct sunlight orstrongwinds.
• Install the unit in a location thatwould not obstruct
anypassageways orthoroughfares.
• Install the unit in a location thatwould not
inconvenience ordisturb yourneighbors, as theycould
be affected bythe noise orthe airflowcoming from
the unit.
• Install the unit in a locationwhere the pipes and the
cables can be easilyconnected to the indoorunit.
• Install the unit on a flat, stable surfacethat can
withstand theweight of the unit. Otherwise, the unit
can generate noise and vibration during operation.
• Install the unit so that the airflow is directed towards
the open area.
• Maintain sufficient clearance around the outdoorunit,
especiallyfrom a radio, computer, stereo system, etc.
IndoorUnit
Fuse
Control
1.5 m ormore
1.5 m ormore 300 mm
200 mm
OutdoorUnit
AirGuide Duct (This product is not provided bySamsung)
Stereo Computer etc
1 m ormore 1 m ormore
• Install the unit at a heightwhere its base can be firmly
fixed in place.
• Make sure that thewaterdripping from the drain hose
runs awaycorrectlyand safely.
CAUTION
• You have just purchased a system airconditionerand it
has been installed byyourinstallation specialist.
• This device must be installed according tothe national
electrical rules.
• Ifyouroutdoorunit exceeds a netweight of 60 kg, do
not install it on a suspendedwall, but stand it on a
floor.
• When installing the outdoorunit at the seaside, make
surethat it is not directly exposedto sea breeze. If
you cannotfind an adequate place free from direct
sea breeze, construct a protection wall ora protective
fence.
– Install the outdoorunit in a place (such as near
buildings etc.)where it can be prevented from sea
breeze. Failure to do so may cause a damageto the
outdoorunit.
Sea breeze
Sea Sea OutdoorUnitOutdoorUnit
Sea breeze
• Ifyou cannot avoid installing the outdoorunit at the
seaside, construct a protection wall aroundto block
the sea breeze.
• Construct a protection wallwith a solid material such
as concrete to block the sea breeze. Make sure that the
height and thewidth of the wall are1.5 times larger
than the size ofthe outdoorunit. Also, secure a space
largerthan 700 mm between the protectionwall and
the outdoorunit forexhausted airto ventilate.
Sea breeze OutdoorUnit
Protectionwall
Sea

6
InstallationProcedure
English
InstallationProcedure
CAUTION
• Depending on the condition of powersupply, unstable
powerorvoltage maycause malfunction of the parts
orcontrol system. (At the ship orplaces using power
supplyfrom electric generator...etc)
• Installtheunit in aplacewherewatercan drainsmoothly.
• Ifyou have anydifficultyfinding installation location as
prescribed above, contactyourmanufacturerfordetails.
• Be sure to clean the sea waterand the dust on the
heat exchangerof the outdoorunit and applya
corrosion inhibitoron it. (At least once in a year.)
• Check the condition of the product periodically.
– Check the installation site every3 months and
perform anti-corrosion treatment such as R-Pro
supplied by SAMSUNG (Code: MOK-220SA) or
commercialwaterrepellent grease and wax, etc.,
based on the product condition.
– When the product is to be shut down fora long
period of time, such as off-peak hours, take
appropriate measures like covering the product.
• If the product installedwithin 500m of seashore,
special anti-corrosiontreatment is required.
࢜Please contactyourlocal SAMSUNG
representative forfurther details.
Outdoorunitdimensions
(Unit: mm)
Type A
AC052TXADKC
880
310
15
338
638
661
58
Type B
AC071TXADKC
880 49
798
310 661
338
15
Type C
AC100TXAD*C
940
977
998
528
537
675 330
360
384
620
Type D
AC120/140TXAD*C
1185
940
1210
558
567675 330
620
360
384
Type E
AC160TXAD*C
940
1395
1420
558
567 1095 330
620
360
384

7
English
InstallationProcedure
Minimumclearancesforthe outdoorunit
Wheninstalling1 outdoorunit
(Unit: mm)
150 ormore
500 ormore
150 or
more 150 or more
150 or
more
1000
ormore
1000
ormore
500
ormore
150
ormore
1000 ormore 150 or
more
Wheninstallingmorethan1outdoorunit
(Unit: mm)
1000
ormore 2000 ormore 2000 ormore 3000 ormore 150 ormore
150
ormore 150
ormore
1500
ormore 300
ormore
1000 ormore
300
ormore 150 ormore 150 ormore 200 ormore
300
ormore
500 ormore 500 ormore
300 ormore
300 ormore
CAUTION
• The outdoorunit must be installed accordingto the
specified distances in orderto permit accessibility
from each side, to guarantee correct operation,
maintenance, and repairof the unit.
The components of the outdoorunit must be
reachable and removable undersafe conditions for
people and the unit.
WARNING
• Should adopt bartype louver. Don’t use a type of rain
resistance louver.
[Bartype louver] [Rain resistance louver]
• Louverspecifications.
– Angle criteria : less than 20°
– Opening ratio criteria : greaterthan 80%

8
InstallationProcedure
English
InstallationProcedure
Movingtheoutdoorunitwithwirerope
1 Before carrying the outdoorunit, fasten twowire ropes
ͱ˙ߪͱθͱ˝ʪθࡥɇϑϑ˵ͱиϩ˵ʪѣ˝Їθʪ࢏
2 To prevent damages orscratches effectively, insert a
piece of cloth betweenthe outdoorunit and the ropes.
3 Move the outdoorunit.
Wire rope
AC100/120/140/160TXAD*C
Plate protection cloth
Wire rope
AC052/071TXADKC
Plate protection cloth
Step2 Fixingtheoutdoorunitinplace
Install the outdoorunit on a rigid and stable base to
prevent disturbance from anynoise caused byvibration.
When installing the unit at a height orin a location
ʪуΧͱϑʪʒϩͱϑϩθͱ˝иʒϑࡥѣуϩ˵ʪЇϩϑʪʀЇθʪцϩͱɇϑЇΧΧͱθϩ
(i.e., awall ora ground).
Fix the outdoorunit with anchorbolts. Make surethat the
anchorbolts are 20 mm orhigherfrom the base surface.
AC052/071TXADKC
Anchorbolt hole
357
338
359
661
880
(Unit : mm)
AC100/120/140/160TXAD*C
Anchorbolt hole
330
360
384
620
940
(Unit : mm)
CAUTION
• Install a drain outlet atthe lowest end aroundthe base
foroutdoorunit drainage
• When installing the outdoorunit on the roof,
waterproof the unit and check the ceiling strength.
• Make sure that thewall can support theweights of the
rack and the outdoorunit.
• Install the rack close to the column as much as
possible.

9
English
InstallationProcedure
Optional:Fixingtheoutdoorunittoawallwith
arack
Designed to cut off residual vibration from
outdoorunit to rack. (not supplied with product)
Anchorbolt
20 mm
Base surface
Soft rubberdesigned to cut offvibration from rack towall.
(not supplied with product)
• Install a propergrommet in orderto reduce noise
and residualvibration transferred bythe outdoorunit
towards thewall.
CAUTION
• When installing an airguide duct, be sure to check the
following:
– The screws do not damage the copperpipe.
– The airguide duct is fixed firmlyon the guard fan.
Step3 Connectingthepowercables,
communicationcable,and controllers
You must connect the following three electrical cables to
the outdoorunit:
• The main powercable between the auxiliarycircuit
breaker and the outdoorunit.
• The outdoor-to-indoorpowercable betweenthe
outdoorunit and the indoorunit.
• The communication cable between the outdoorunit
and the indoorunit.
CAUTION
• During installation, makefirst the refrigerant
connections and then the electrical connections. If the
unit is uninstalled, first disconnectthe electrical cables
and then the refrigerant connections.
• Connectthe airconditionerto the earthing system
before making the electrical connections.
NOTE
• Especially, ifyouroutdoorunit is the one designed for
Russian and European markets, consult the supply
authority, if necessary,to estimate and reduce the
supplysystem impedance before installation.
Airconditioningsystemexamples
When using earth leakage circuit breaker(ELCB)fora
single phase
MCCB
1
ELCB
1
ELB
OR
Main power
cable Communication cable
Outdoor-to-indoorpowercable
Earthing
OutdoorUnit IndoorUnit
When using earth leakage circuit breaker(ELCB)fora
3-phase, 4-wire system (3P4W)
MCCB
3
ELCB
3
ELB
OR
Main power
cable Communication cable
Outdoor-to-indoorpowercable
OutdoorUnit IndoorUnit
Earthing
CAUTION
• If the outdoorunit is installed in a locationvulnerable
to an electric leak orsubmergence, make sure to
install an ELCB.

10
InstallationProcedure
English
InstallationProcedure
Connectingthe mainpowercable
WhenusingELB
1(L) 2(N) L N F1 F2
PowerSupply
MCCB
ELB
Cable clamp
Outdoorto indoor
powercable Main Power
Cable
Cabletie
Communication
cable
WhenusingELBfor1 phase and 3 phase
Electrical
component box
The appearance of the unit may be different fromthe
picture depending on the model.
IndoorUnit
PowerSupply
MCCB
ELB
1-phase
3-phase
Outdoor-to
indoorpowercable
Outdoor-to
indoorpowercable 3-phase 4-wire main powercable
(AC 380V)
Communication
cable
Main powercable Communication cable
Cabletie
Cabletie

11
English
InstallationProcedure
CAUTION
• You should connect the powercable intothe power
cableterminal and fasten it with a clamp.
• The unbalanced powermust be maintainedwithin 2%
of supplyrating.
If the poweris unbalanced greatly, it may shorten
the life of the condenser. If the unbalanced poweris
exceeded over4% of supplyrating, the indoorunit is
protected, stopped andthe errormode indicates.
• To protect the product fromwaterand possible shock,
you should keep the powercable and the connection
cord ofthe indoorand outdoorunits within ducts. (with
appropriate IPrating and material selection foryour
application)
• Ensurethat main supplyconnection is made through a
switchthat disconnects all poles,with contact gap of a
least 3 mm.
• Devices disconnected from the powersupplyshould
be completely disconnected in the condition of
overvoltage category.
• Keep distances of 50 mm ormore between power
cable and communication cable.
đɇΧͱиʪθϩʪθɇɵͱʀϑΧʪʀѣʀɇϩͱϑ
AC052/071TXADKC (Unit: mm)
13.8 10.3 11.4
10.1
• 1-phase terminal block specifications
AC100/120/140/160TXADKC (Unit: mm)
16.5 12 11.4
10.1
• 3-phase terminal block specifications
AC100/120/140/160TXADNC (Unit: mm)
9.8 14.2 11.4
10.1
đɇΧͱиʪθʀɇɵʪϑΧʪʀѣʀɇϩͱϑ
The powercable is not supplied with airconditioner.
• Selectthe powersupplycable in accordance with
relevant local and national regulations.
• Wire size must complywith the applicable local and
national code.
• Specifications forlocalwiring powercord and branch
wiring are in compliancewith local cord.

12
InstallationProcedure
English
InstallationProcedure
Model Outdoorunit Inputcurrent(A) Powersupply
Indoorunit Outdoorunit Hz Voltagerange(V) Outdoorunit Indoorunit Total MCA(A) MFA(A)
Rated Min. Max.
AC052TN1DKC
AC052TXADKC
50 220 to 240 198 264
20.0 1.5 21.5 21.5 25.0
AC052TN4PKC 20.0 1.5 21.5 21.5 25.0
AC052TN4DKC 20.0 1.5 21.5 21.5 25.0
AC052TNLDKC 20.0 2.3 22.3 22.3 25.0
AC052TNCDKC 20.0 1.5 21.5 21.5 25.0
AC071TN1DKC
AC071TXADKC
20.0 1.5 21.5 21.5 25.0
AC071TN4PKC 20.0 1.5 21.5 21.5 25.0
AC071TN4DKC 20.0 1.5 21.5 21.5 25.0
AC071TNMDKC 20.0 2.3 22.3 22.3 25.0
AC071TNCDKC 20.0 2.5 22.5 22.5 25.0
AC100TN4PKC
AC100TXADKC
24.0 2.0 26.0 26.0 30.0
AC100TN4DKC 24.0 2.0 26.0 26.0 30.0
AC100TNMDKC 24.0 2.5 26.5 26.5 30.0
AC100TNCDKC 24.0 2.5 26.5 26.5 30.0
AC120TN4PKC
AC120TXADKC
32.0 2.0 34.0 34.0 40.0
AC120TN4DKC 32.0 2.0 34.0 34.0 40.0
AC120TNMDKC 32.0 2.5 34.5 34.5 40.0
AC120TNCDKC 32.0 2.5 34.5 34.5 40.0
AC140TN4PKC
AC140TXADKC
32.0 2.0 34.0 34.0 40.0
AC140TN4DKC 32.0 2.0 34.0 34.0 40.0
AC140TNMDKC 32.0 2.5 34.5 34.5 40.0
AC140TNCDKC 32.0 2.5 34.5 34.5 40.0
AC160TNMDKC AC160TXADKC 32.0 3.5 35.5 35.5 40.0
AC160TNCDKC 32.0 3.0 35.0 35.0 40.0
AC100TN4PKC
AC100TXADNC 50 380 to 415 342 456.5
16.1 2.0 18.1 18.1 18.1
AC100TN4DKC 16.1 2.0 18.1 18.1 18.1
AC100TNMDKC 16.1 2.5 18.6 18.6 18.6
AC100TNCDKC 16.1 2.5 18.6 18.6 18.6
AC120TN4PKC
AC120TXADNC
50 380 to 415 342 456.5
16.1 2.0 18.1 18.1 18.1
AC120TN4DKC 16.1 2.0 18.1 18.1 18.1
AC120TNMDKC 16.1 2.5 18.6 18.6 18.6
AC120TNCDKC 16.1 2.5 18.6 18.6 18.6
AC140TN4PKC
AC140TXADNC
16.1 2.0 18.1 18.1 18.1
AC140TN4DKC 16.1 2.0 18.1 18.1 18.1
AC140TNMDKC 16.1 2.5 18.6 18.6 18.6
AC140TNCDKC 16.1 2.5 18.6 18.6 18.6
AC160TNMDKC AC160TXADNC 16.1 3.5 19.6 19.6 19.6
AC160TNCDKC 16.1 3.0 19.1 19.1 19.1

13
English
InstallationProcedure
NOTE
1 Voltage range
• Units are suitable foruse on electrical systems
wherevoltage supplied to unit terminal is not
below orabove listed range limits.
2 Maximum allowablevoltage variation between phases
is 2%.
3 Wire size & type must complywith the applicable local
and national code.
• Wire size: Based on thevalue of MCA.
• Wiretype: 60245 IEC57(IEC) orH05RN-F(CENELEC)
grade ormore.
4 MFA is used to select the circuit breakerand the
groundfault circuit interrupter(earth leakage circuit
breaker).
5 MCA represents maximum input current.
• MFA represents capacitywhich mayaccept MCA
• Abbreviations
MCA: Min. CircuitAmps. (A)
MFA: Max. Fuse Amps. (A)
Silencemodecontrollerwiring diagram
• AC052/071TXADKC
CN001
Outdoorunit
Non-voltage contact
CN001
• AC100/120/140/160TXAD*C
Outdoorunit
ASSY Control out
Non-voltage contact
Connectingthe outdoor-to-indoorpowercable
andthecommunicationcable
1-phase
Forconnecting the powerand
communication cables
IndoorUnit
OutdoorUnit
Outdoor-to-indoor
powercable Communication cable
Cabletie
Main powercable

14
InstallationProcedure
English
InstallationProcedure
3-phase
LN
F1 F2
1(L) 2(N) L1(R) L2(S)L3(T) N F1 F2
IndoorUnit
OutdoorUnit
Outdoor-to-indoor
powercable Communication cable
Cabletie
3-phase 4-wire main
powercable (AC 380V)
NOTE
• Laythe electricalwiring so that the front coverdoes
not rise upwhen doing wiringwork and attach the
front coversecurely.
• Groundwire forthe indoorunit and outdoorunit
connection cable must be clampedto a soft copper
tin-plated eyelet terminalwith M4 screwhole(NOT
SUPPLIEDWITH UNITACCESSORIES).
Outdoor-to-indoorpowerterminal
specifications
• Connect the cables to the terminal board using the
compressed ring terminal.
• Covera solderless ring terminal and a connectorpart
of the powercable and then connect it.
Silversolder
Nominal
dimensions
forcable
(mm²)
Nominal
dimensions
forscrew
(mm)
BDd1EFLd2t
Standard
dimension
(mm) Allowance
(mm) Standard
dimension
(mm) Allowance
(mm) Standard
dimension
(mm) Allowance
(mm) Min. (mm) Min. (mm) Max. (mm) Standard
dimension
(mm) Allowance
(mm) Min. (mm)
4/6 49.5 ±0.2 5.6 +0.3
-0.2 3.4 ±0.2 6.0 520.0 4.3 +0.2
00.9
815.0 928.58.4
+0.4
0
10 8 15.0 ±0.2 7.1 +0.3
-0.2 4.5 ±0.2 7.9 9 30.0 8.4 +0.4 01.15
16 8 16.0 ±0.2 9.0 +0.3
-0.2 5.8 ±0.2 9.5 13 33.0 8.4 +0.4 01.45
25 812.0 ±0.3 11.5 +0.5
-0.2 7.7 ±0.2 11.0 15 34.0 8.4 +0.4 01.7
816.5 13 8.4
35 816.0 ±0.3 13.3 +0.5
-0.2 9.4 ±0.2 12.5 13 38.0 8.4 +0.4 01.8
822.0 1343.08.4
50 8 22.0 ±0.3 13.5 +0.5
-0.2 11.4 ±0.3 17.5 14 50.0 8.4 + 0.4 01.8
70 8 24.0 ±0.4 17.5 +0.5
-0.4 13.3 ±0.4 18.5 20 51.0 8.4 +0.4 02.0

15
English
InstallationProcedure
• Connectthe rated cables only.
• Connect using a driverwhich is able to applythe rated
torque to the screws.
• If the terminal is loose,fire mayoccurcaused byarc. If
the terminal is connected too firmly, the terminal may
be damaged.
Tighteningtorque(N·m)
M4 0.8to1.2
M5 2.0 to 3.0
• 1 N·m =10 kg·fcm
CAUTION
• When connecting cables, you can connect the cables to
the electrical part orconnect them throughthe holes
belowdepending on the spot.
• Connectthe communication cable between the indoor
and outdoorunits through a conduit to protect against
external forces, and feed the conduit through thewall
togetherwith refrigerant piping.
• Remove all burrs atthe edge of the knock-out hole
and secure the cable to the outdoorknock-out using
lining and bushing with an electrical insulation such as
rubberand so on.
• Must keep the cable in a protection tube.
• Keep distances of 50mm ormore between powercable
and communication cable.
• When the cables are connected through the hole,
remove the Plate bottom.
Outdoor-to-indoorpowerand communication
cablesspecifications
Indoorpowersupply
Powersupply Max/Min(V) Indoorpowercable
1ø, 220-240V, 50 Hz ±10% ߣ࢏ߧࠌࡥߥиθʪϑ
Communicationcable
0.75to1.5 mm², 2wires
• Powersupplycordsof partsof appliancesforoutdooruse
shallnotbelighterthanpolychloroprenesheathedflexible
cord.(CodedesignationIEC:60245IEC 57/CENELEC:
H05RN-ForIEC:60245IEC66/CENELEC:H07RN-F)
• When installing the indoorunit in a computerroom
ornetwork room, use the double shielded (tape
aluminium / polyesterbraid + copper) cable of
FROHH2R type.
Step4 Optional:Extendingthepowercable
1 Prepare the following tools.
Tools Spec Shape
Crimping pliers MH-14
Connection sleeve
(mm) 20xØ6.5 (HxOD)
Insulationtape Width19
mm
Contraction tube
(mm) 70xØ8.0 (LxOD)
2 ϑϑ˵ͱиϩ˵ʪѣ˝ЇθʪࡥΧʪʪͱ˙˙ϩ˵ʪϑ˵ʪʒϑ˙θͱϩ˵ʪ
rubberand wire of the powercable.
• Peel off 20 mm of cable shields fromthe pre-
installed tube.
Powercable (Unit: mm)
20 20 20
60
120
180
180
120
60
20 20 20
Pre-installed
tube forthe
powercable
CAUTION
• Forinformation about the powercablespecificationsfor
indoorand outdoorunits, refertothe installationmanual.
• Afterpeeling off cablewires fromthe pre-installed
tube, insert a contractiontube.

16
InstallationProcedure
English
InstallationProcedure
3 Insert both sides of corewire of the powercable into
the connection sleeve.
• Method1: Push the core wire into the sleeve from
both sides.
• Method2: Twist thewire cores togetherand push it
into the sleeve.
Method1
Connection sleeve Connection sleeve
Method2
CAUTION
• If cablewires are connected without using connecting
sleeves, theircontact area becomes reduced, or
corrosion develops on the outersurfaces of thewires
(copperwires) overa long time. This maycause an
increase of resistance (reduction of passing current)
and consequentlymayresult in a fire.
4 Using a crimping tool, compress the two points and
ѤΧϩͱЭʪθɇʒʀͱΧθʪϑϑɇͱϩ˵ʪθϩиͱΧͱϩϑϩ˵ʪ
same location.
• The compression dimension should be 8.0.
Compression
dimension
• Aftercompressing it, pull both sides of thewire to
make sure it is firmlypressed.
Method1 Method 2
5 mm
Compress it 4 times. Compress it 4 times.
5 mm
5 Wrap itwith the insulation tape twice ormore and
positionyourcontraction tube in the middle of the
insulation tape.
Method1 Method 2
40 mm
Insulationtape Insulation tape
35 mm
6 Apply heat to the contraction tube to contract it.
Method1 Contractiontube Contractiontube Method2
7 Aftertube contractionwork is completed,wrap itwith
ϩ˵ʪϑЇɇϩͱϩɇΧʪϩͱѣϑ˵࢏
Three ormore layers of insulation are required.
Method1 IInsulation tape IInsulation tape Method2
CAUTION
• Make sure that the connection parts are not exposed
to outside.
• Be sure to use insulation tape and a contraction tube
made of approved reinforced insulating materials
that havethe same level ofwithstand voltage with
the powercable. (Complywith the local regulations on
extensions.)
WARNING
• In case of extending the electricwire, please DO NOT
use a round-shaped Pressing socket.
– Incompletewire connections can cause electric
shock ora fire.

17
English
InstallationProcedure
Step5 Connectingtherefrigerantpipe
Items Outdoorunit
models Mainpipe (L1) Max. height difference
betweenoutdoorand
indoorunits (h1)
Maximum
allowable
length
AC052TXADKC 30 20
AC071TXADKC 50 30
AC100TXAD*C 50 30
AC120TXAD*C 75 30
AC140TXAD*C 75 30
AC160TXAD*C 75 30
n=1
Outdoor
L1
h1
IndoorUnit indoor
• Tempergradeandminimumthicknessofthe refrigerantpipe
Outerdiameter
[mm] Minimumthickness [mm] Tempergrade
ø 6.35 0.7
C1220T-O
ø 9.52 0.7
ø12.70 0.8
ø15.88 1.0
ø15.88 0.8 C1220T-1/2H OR
C1220T-H
ø19.05 0.9
ø 22.23 0.9
CAUTION
• Be sureto use C1220T-1/2H (Semi-hard) pipeformore
than Ø19.05 mm. Ifyou use C1220T-O (Soft) pipe forØ19.05
mm, the pipe maybe broken,which can result in an injury.
Blockthe part. A
Make at least one round:
It will reduce noise and vibration
• The appearance ofthe unit maybe differentfrom the
diagram depending on the model.
CAUTION
Pipe outlet
• Cut the pipe outlet tothe exact pipe size. In addition,
remove foreign substances and burrs aroundthe outlet.
• ťʪθ˙ͱθʀЇϩϩ˝иϩ˵ͱцɇʀЇϩϩʪθ࣑ʪу࢏ΧΧʪθ࣒ɇʒ
nevertapwith a hammernearthe pipe outlet.
Otherwise, it maycause product damage such as
warping of the cabinet.
• Afterconnecting the pipeswith pipe outlet, plug the
space aroundthe pipes.
• Afterconnecting the pipes, proceed exactlyas directed in
the guide to prevent interference withthe internal parts.
• Tighten the nutsto the specifiedtorques. If overtightened,
the nuts could be broken so refrigerant may leak.
• Protect orenclose refrigerant tubing to avoid
mechanical damage.
• Afterinstalling pipes, blockthe unused knock hole
to prevent small animal from entering. However, the
radiant heat hole(A) should be able to intake air.
Step6 Optional:Cuttingandflaring
thepipes
1 Make sure that you have the required tools available.
࣑ΧΧʪʀЇϩϩʪθࡥθʪɇʪθࡥѤɇθ˝ϩͱͱࡥɇʒΧΧʪ˵ͱʒʪθ࣒
2 Ifyou wish to shortenthe pipes, cut itwith a pipe
cutter, taking care to ensure that the cut edge remains
at a 90° anglewith the side of the pipe. Referto the
illustrations below forexamples of edges cut correctly
and incorrectly.
Pipe cutter
90°
Pipe Oblique Rough Burr

18
InstallationProcedure
English
InstallationProcedure
3 To prevent anygas from leaking out, remove all burrs
at the cut edge of the pipe, using a reamer.
4 ƊʒʪɇѤɇθʪЇϩͱϩͱϩ˵ʪΧΧʪɇʒͱʒ˙цϩ˵ʪѤɇθʪ࢏
D
Flare
Flare
L
R 0.4to 0.8 mm
90° ±2°
45° ±2°
D
Pipe
Outerdiameter(D) Depth(A) Flaredimension (L)
ø 6.35 mm 1.3 mm 8.7 to 9.1 mm
ø 9.52 mm 1.8 mm 12.8 to13.2 mm
ø12.70 mm 2.0 mm 16.2 to16.6 mm
ø15.88 mm 2.2 mm 19.3 to19.7 mm
ø19.05 mm 2.2 mm 23.6 to 24.0 mm
5 A˵ʪʀϩ˵ɇϩϩ˵ʪѤɇθ˝ϑʀͱθθʪʀϩࡥθʪ˙ʪθθ˝ϩͱϩ˵ʪ
Їϑϩθɇϩͱϑɵʪͱи˙ͱθʪуɇΧʪϑͱ˙ʀͱθθʪʀϩѤɇθ˝࢏
ߣ
ߤ
ߥ
Correct Inclined Damaged
Surface Cracked Uneven Thickness
CAUTION
• If the pipes require brazing ensure that OFN(Oxygen
Free Nitrogen) is flowing through the system.
• Nitrogen blowing pressure range is 0.02to 0.05 MPa.
Step7 Installingoiltraps
Check the following list and install an oil trap.
• Based on cooling operation, install it on the gas side
pipe only.
• Install the oil trap only in between the outdoorunit
and the first branch joint and it should be installed at
every10 m.
• Radius of curvature (R) on the oiltrap are as follows;
Pipe
diameter
(D,mm) 12.70 15.88 19.05 22.23 25.40 28.60 31.75
Radiusof
curvature
(R,mm) 25 and
over 32 and over 38 and over 41 and over 51 and over 57 and over 60 and over
• ²ʪ˝˵ϩͱ˙ϩ˵ʪͱϩθɇΧ࣑²࣒ࡤߦŵ²ߨŵ
• When the indoorunit is installed at a higherplace than
the outdoorunit
H
R
IndoorUnit
OutdoorUnit
Oil trap (Install it at
every10 m)

19
English
InstallationProcedure
Step8 Connectingupandremovingair
inthecircuit
CAUTION
• When installing, make sure there is no leakage.When
recovering the refrigerant, ground the compressorfirst
before removing the connection pipe. If the refrigerant
pipe is not properly connected and the compressor
workswith the servicevalve open, the pipe inhales the
airand it makes the pressure inside of the refrigerant
cycle abnormally high. It maycause explosion and
injury.
The airin the indoorunit and in the pipe must be
evacuated. If airremains in the refrigerant pipes, it will
affectthe compressoreitherreduce cooling capacityor
lead to a malfunction. Refrigerantforairpurging is not
charged inthe outdoorunit. Use Vacuum Pump as shown
ɇϩϩ˵ʪθ˝˵ϩѣ˝Їθʪ࢏
1 Connect each assembly pipe to the appropriatevalve
ͱϩ˵ʪͱЇϩʒͱͱθЇϩɇʒϩ˝˵ϩʪϩ˵ʪѤɇθʪЇϩ࢏
2 ŵʪ˙ʪθθ˝ϩͱϩ˵ʪЇϑϩθɇϩͱɵʪͱиࡥϩ˝˵ϩʪϩ˵ʪѤɇθʪ
ЇϩͱϑʪʀϩͱUѣθϑϩɇЇɇцɇʒϩ˵ʪиϩ˵ɇϩͱθαЇʪ
wrench, applying the following torque.
D
C
OuterDiameter(mm) Torque(N·m)
ø 6.35 14 to18
ø 9.52 34 to 42
ø12.70 49to 61
ø15.88 68 to 82
ø19.05 100to120
A (Gas)
OutdoorUnit
B (Liquid)
3 Connectthe charging hose of lowpressure side of
manifold gauge tothe packedvalve having a service
Χͱθϩɇϑϑ˵ͱиɇϩϩ˵ʪѣ˝Їθʪ࢏
CAUTION
• The designs and shape are subjectto change
according to the model.
4 Open thevalve ofthe lowpressure side(A) of manifold
gauge anticlockwise.
AC052/071TXADKC
Vacuum
pump
AC100/120/140/160TXAD*C
Vacuum
pump
OutdoorUnit
A (Gas)
B (liquid)

20
InstallationProcedure
English
InstallationProcedure
5 Purgethe airfrom the system using vacuum pumpfor
about10 minutes.
• Close thevalve of the lowpressure side of manifold
gauge clockwise.
• Make sure that pressure gauge shows -0.1 MPa (-76
cmHg) afterabout10 minutes. This procedure is
veryimportant to avoid a gas leak.
• Turn off the vacuum pump.
• Remove the hose ofthe lowpressure side of
manifold gauge.
6 Open the stopvalve of both liquid and gas sides.
7 Mount thevalve stem nuts and the service port capto
ϩ˵ʪЭɇЭʪࡥɇʒϩ˝˵ϩʪϩ˵ʪɇϩϩ˵ʪϩͱθαЇʪͱ˙ߣߪߥ˝˙҃ʀ
with a torquewrench.
8 Check forgas leakage.
• At this time, especiallycheck forgas leakage from
the 3-wayvalve’s stem nuts(A port), and from the
service port cap.
CAUTION
• Connect the indoorand outdoorunits using pipes with
flared connections (not supplied). Forthe lines, use
insulated, unwelded, degreased and deoxidized copper
pipe, (Cu DHPtype to ISO1337 orUNI EN12735-1),
suitable foroperating pressures of at least 4200 kPa and
fora burst pressure of at least 20700 kPa. Copperpipe
forhydro-sanitaryapplications is completelyunsuitable.
• Forsizing and limits (height difference, line length,
max. bends, refrigerant charge, etc.) see“Connecting
refrigerant pipe section”.
Step9 Addingrefrigerant(R-410A)
• The outdoorunit is loaded with sufficient refrigerant
forthe standard piping. Thus, refrigerant must be
added if the piping is lengthened. This operation
can onlybe performed bya qualified refrigeration
specialist. To determine the quantityof refrigerant
charge, see Calculatingthe quantityof refrigerant to
add on page 21.
1 Check if the stopvalve is closed completely.
2 AC052/071TXADKC : Charge the refrigerantthrough
the service port of the gas stopvalve.
AC100/120/140/160TXAD*C : Charge the refrigerant
throughthe service port of the liquid stopvalve.
NOTE
• AC100/120/140/160TXAD*C : Do not charge the
refrigerant through the service port of the gas stopvalve.
3 Ã˙цͱЇ˵ɇЭʪɇцʒ˙ѣʀЇϩцʀ˵ɇθ˝˝ϩ˵ʪθʪ˙θ˝ʪθɇϩɇϑ
described in the steps above,take thefollowing steps:
a Open the liquid stopvalve and gas stopvalve.
b Operatethe airconditionerby pressing the K2
button on the outdoorunit PCB.
c Afterabout 30 minutes, charge the refrigerant
throughthe service port of the gas stopvalve.
Vacuum
Pump
Ref
Balance
Gas side stopvalve
(service port)
Liquid side stopvalve
(Non-service port)
AC052/071TXADKC
IndoorUnit
Vacuum
Pump
Ref
Balance
Liquid side stopvalve(service port)
Gas side stopvalve(service port)
AC100/120/140/160TXAD*C
IndoorUnit
OutdoorUnit
