Samsung Digimax 101 User manual

SERVICE MANUAL
TECHWIN
DIGIMAX 101

3
CONTENTS
ⅠⅠ
.. SSPPEECCIIFFIICCAATTIIOONN
1. SPECIFICATION ……………………………………………………………………………………………… 4
2. SYSTEM REQUIRMENT ……………………………………………………………………………………… 5
3. TFT LCD PANEL MARK ………………………………………………………………………………………6
4. CONNECTION DIAGRAM ………………………………………………………………………………………7
5. PRODUCT EXTERIOR …………………………………………………………………………………………8
ⅡⅡ
.. SSOOFFTTWWAARREE IINNSSTTAALLLLAATTIIOONN
………………………………………………………………………10
ⅢⅢ.. EEXXPPLLOODDEEDD VVIIEEWW AANNDD PPAARRTTSS LLIISSTT
1. FRONT COVER ASSEMBLY ……………………………………………………………………………… 14
2. B
ODY ASSEMBLY ………………………………………………………………………………………… 16
3. BACK COVER ASSEMBLY ………………………………………………………………………………… 18
4. PACKING ITEM ………………………………………………………………………………………………20
5. INITIAL PARTS LIST …………………………………………………………………………………………22
ⅣⅣ.. AADDJJSSUUTTMMEENNTT
1. REPLACEMENT PARTS AND ADJUSTMENT ITEMS …………………………………………………… 23
2. ADJUSTMENT TOOLS …………………………………………………………………………………………23
3. FIRMWARE UPGRADE…………………………………………………………………………………………24
4. ADJUSTMENT ITEMS
1) FOCUS ADJUSTMENT ……………………………………………………………………………………24
2) BAD PIXEL ADJUSTMENT ………………………………………………………………………………25
3) AWB ADJUSTMENT ………………………………………………………………………………………28
4) TRIG ADJUSTMENT ………………………………………………………………………………………28
5) LCD ADJUSTMENT…………………………………………………………………………………………29
6) STROBO ADJUSTMENT ……………………………………………………………………………………30
ⅤⅤ.. PPRROODDUUCCTTSS CCOONNSSTTRRUUCCTTIIOONN
1. PARTS ARRANGEMENT FOR EACH PCB ASS’Y
1) MAIN PCB ASSEMBLY ……………………………………………………………………………………31
2) POWER PCB ASSEMBLY …………………………………………………………………………………33
3) TOP PCB ASSEMBLY ……………………………………………………………………………………35
2. BLOCK DIAGRAM ……………………………………………………………………………………………36
3. CIRCUIT DIAGRAM
1) BLOCK DIAGRAM …………………………………………………………………………………………37
2) INTERFACE …………………………………………………………………………………………………38
3) LCD …………………………………………………………………………………………………………39
4) CPU …………………………………………………………………………………………………………40
5) CMOS ………………………………………………………………………………………………………41
6) SDRAM, FLASH & SD CARD …………………………………………………………………………42
7) UI ……………………………………………………………………………………………………………43

4
11.. SSppeecciiffiiccaattiioonnss
Ⅰ
. SPECIFICATIONS
Type 1/2 CMOS
Effective Pixels Approx. 1.3 Mega pixels
Total Pixels Approx. 1.4 Mega pixels
Focal Length Samsung Lens f=9.0mm
(35mm film equivalent : 46mm)
F No. F3.0
Digital Zoom STILL IMAGE : 2X , PLAY mode : 2X
Optical Viewfinder Optical viewfinder
LCD Monitor 1.6" color TFT LCD
Type Fixed focus
Range 1.0m ~ infinity
Type Electronic shutter
Speed 1/15 ~ 1/2,000 sec..
Control Program AE
Compensation ±2EV (0.5EV steps)
ISO Equivalent Automatic (100, 200)
Modes Auto/ Auto & Red – eye reduction / Flash off
Range 1.0 ~ 3.0 m
Recharging Time Approx. 10 sec.
White Balance Auto / Daylight / Cloudy / Sunset / Tungsten / Fluorescent
Size : 320x240
Recording time : Memory capacity dependent
Self-timer 10 sec.
Media Internal memory : 8MB flash memory
External memory (optional) : SD / MMC card (up to
256MB Guaranteed)
File Format Still image : JPEG(DCF), DPOF
Movie Clip : AVI (MJPEG)
Image Size Large : 1280x1024 pixels, Small : 640x 512 pixe
Capacity Large : Super fine 15, Fine 22, Normal 44
(8/16MB) Small : Super fine 30, Fine 60, Normal 121
These figures are measured by internal memory based.
These figures are measured under Samsung standard
conditions and may vary depending on shooting conditions
and camera settings.
Image Play Single image / Thumbnails / Slide show / Movie Clip
Digital output connector : USB
Video output : NTSC / PAL (User selectable)
DC power input connector : 3.3V
Storage
Flash
Exposure
Focusing
Viewfinder
Shutter
Lens
Image Sensor
Movie Clip
Interface

5
22.. SSyysstteemm rreeqquuiirreemmeenntt
Specifications are subject to change without prior notice.
FFOORR WWIINNDDOOWWSS
PC with processor better than MMX Pentium 266MHz
(XP : Pentium II 300MHz)
Windows 98/98SE/2000/ME/XP
Minimum 32MB RAM (XP : 128MB)
110MB of available hard-disk space
USB port
CD-ROM drive
800 X 600 pixels, 16-bit color display compatible monitor
(24-bit color display recommended)
FFOORR MMAACCIINNTTOOSSHH
Power Mac G3 or later
Mac OS 8.6 ~ 10.2
Minimum 32MB RAM
110MB of available hard-disk space
USB port
CD-ROM drive
QuickTime 4.0 or later for Movie Clip
ⅠⅠ.. SSPPEECCIIFFIICCAATTIIOONN
2 x AA alkaline / 2 x Ni-MH / CR-V3 batteries
AC adapter(Optional)
Dimensions (WxHxD) 108x56x37mm / 4.3x2.2x1.5in
Weight Approx. 125g / 4.4oz (without batteries and card)
Storage Driver
(Windows98/98SE/2000/ME/XP, Mac OS 8.6~10.2)
Application MGI PhotoSuite
Digimax Viewer
Software
Power Source
Camera Driver

No. Description Icons
1 Battery
2 Camera shake warning
3 Flash
4 Self-timer
5 White balance
6 Exposure compensation +0.5 EV (Exposure Value)
7 Date 2002/09/01
8 Time 03:15
9 Card indicator
10 Quality
11 Image size
Number of available shots remaining(still image) 0015
Recording time(while recording a movie clip) 00:50
13 Message for canceling a movie clip recording
14 Digital zoom
15 Recording mode
6
■PLAY mode
44.. TTFFTT LLCCDD PPaanneell MMaarrkk
■SHOT mode
ⅠⅠ.. SSPPEECCIIFFIICCAATTIIOONN
①
⑦
②
③
④
⑤⑧
⑨
⑩
⑪
⑫
⑥
⑮ ⑬⑭
①④
②
③
No. Description Icons
1 Battery
2 Recording date 2002/09/01
3 Card indicator
4 Number of stored images 100-0003
12

7
AC Adaptor
USB Cable
SD & MMC Card.
B
atteries
Alkarain x2
IBM PC / MACINTOSH
3.3V/2.0A
Digimax 101 camera
55.. CCOONNNNEECCTTIIOONN DDIIAAGGRRAAMM
ⅠⅠ.. SSPPEECCIIFFIICCAATTIIOONN

8
66..
PPrroodduucctt EExxtteerriioorr
ⅠⅠ.. SSPPEECCIIFFIICCAATTIIOONN
Power switch
Lens
Self-timer lamp
Viewfinder
Flash
DC input connection
point
Video connection
terminal
USB connection
terminal
Shutter button
Battery chamber /
Card cover
Card slot
Battery chamber
Strap eyelet

9
ⅠⅠ.. SSPPEECCIIFFIICCAATTIIOONN
5-function
button
LCD monitor
Camera
status LED
(p.15)
Tripod socket
MENU button
MODE button
LCD button
Viewfinder
FLASH/ LEFT( ) button
DELETE / DOWN( ) button
SELF-TIMER/ RIGHT( ) button
THUMBNAIL / UP( ) button
OK button (p.38 / 56)

10
ⅡⅡ
. INSTALLATION
All application programs (Digimax Viewer 1.0 for viewing images, MGI PhotoSuite III SE for editing
images, and DirectX 8.1 for playing back movie clips) will be installed.
If you installed all application programs by clicking the [Driver Storage Driver], you need not
install Digimax Viewer 1.0 and MGI PhotoSuite III SE separately.
2. A [Welcome] window will open.
Click the [Next>] button.
1. Click [Storage Driver] menu on the Autorun frame.
3. A [start Installation] window will open.
Click the [Next>] button. 4. Installation is complete. Click the [Finish] button and the
[Digimax Viewer 1.0] installation will be started.
5. The [Digimax Viewer 1.0] installation window will be
displayed as shown below. Click [Next] button.
·If you select [Cancel] at the step 2, the camera driver
installation will be cancelled and a window for installing
Digimax Viewer 1.0 will be displayed.
If you select [Cancel] at the step 5, the Digimax Viewer 1.0
installation will be cancelled and a window for installing MGI
PhotoSuite III SE will be displayed.

11
8. Select the Program folder and click [Next].
7. Select a destination folder and click [Next].
9. Installation is completed. Click [OK] button and the [MGI
PhotoSuite III SE] installation will be started.
10. The [Choose Setup Language] window will open.
Select a language and click [OK] button. 11. A [Welcome] window will be displayed. Click [Next>]
to move to the next step.
If you select [Cancel] at the step 10, the MGI PhotoSuite III
SE installation will be cancelled and a window for installing
DirectX 8.1 will be displayed.
6. The Software License Agreement window will display. If
you agree to it, click [Yes].

12
15. The MGI Registration window will be displayed. Click
the [Continue] button.
According to your operating system, the window as
shown below may be displayed.
Should this be the case, click the [NO] button.
14. If the installation is completed correctly, the autoplay is
registered automatically into the start menu program as
shown below. Click [Next>] button.
13. A [Setup Type] window will open. Select setup type
and click [Next >] button.
12. The Software License Agreement window will be
displayed. If you agree to this, click [Yes] button.
16. The [Online Registration Utility] window will be
displayed. Fill in the blanks and click the [Register]
button.

13
18. All application programs are installed correctly. Check
[Yes, I want to restart my computer now.] button and click
[Finish] button.
You must restart your computer after the installation, or your computer can’t recognize the camera as a Removable
disk.
17. Installation is complete. Click the [Finish] button.

14
ⅢⅢ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT
1-17
1-7 1-21
1-13
1-2
1-18
1-19
1-6
1-3
1-1
1-4
1-5
1-24
1-22
1-23
1-16
1-15
1-14
1-20
1-9
1-12
1-10 1-11
1-8
11.. FFRROONNTT CCOOVVEERR AASSSSEEMMBBLLYY

15
ⅢⅢ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT
▶▶PARTS LIST
1-1 9007-1850-01A FRONT COVER ASS'Y-KENOX DIGIMAX 101 1
9007-1851-01A FRONT COVER ASS'Y-DIGIMAX 101 1
1-2 7217-2708-01A FRONT COVER-KENOX DIGIMAX 101 1
7217-2709-01A FRONT COVER-DIGIMAX 101 1
1-3 7217-2711-01A GRIP 1
1-4 7217-2710-01A SAMSUNG LOGO 1
1-5 7217-2730-01A FLASH COVER 1
1-6 7212-1700-01A LENS RING 1
1-7 7212-1699-01A LENS COVER 1
1-8 6003-0378-01A SCREW 1
1-9 6003-0377-01A SCREW 1
1-10 7409-1350-01A FLASH COVER TAPE-A 1
1-11 7409-1352-01A FLASH COVER TAPE-C 1
1-12 7409-1351-01A FLASH COVER TAPE-B 2
1-13 9007-1854-01A TOP COVER ASS'Y 1
1-14 7217-2722-01A RELEASE COVER 1
1-15 7217-2723-01A RELEASE BUTTON 1
1-16 6107-0522-01A RELEASE BUTTON SPRING 1
1-17 7217-2721-01A TOP COVER 1
1-18 7217-2724-01A POWER BUTTON 1
1-19 7217-2725-01A POWER SP 1
1-20 6003-0381-01A SCREW 5
1-21 9007-1852-01A JACK COVER ASS'Y 1
1-22 7217-2712-01A JACK COVER 1
1-23 7409-1356-01A JACK COVER TAPE 1
1-24 7217-2713-01A INNER JACK COVER 1
Fig.No. Parts No. Parts Name Q'ty Remarks

16
2-8
2-13
2-14
2-15
2-9 2-7
2-5
2-3
2-4
2-1
2-12
2-19
2-11
2-20 2-18 2-17
2-21
2-22
2-24
2-25
2-35 2-34
2-29
2-31
2-30
2-23 2-28 2-26
2-27
2-32
2-16
2-6
2-6
2-6
2-10
2-6
2-6
2-10
2-33
2-2
2-6
2-6
22.. BBOODDYY
ⅢⅢ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT

17
▶▶PARTS LIST
ⅢⅢ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT
2-1 9008-0582-01A LCD ASS'Y 1
2-2 6003-0379-01A SCREW 1
2-3 7217-2728-01A LCD HOLDER 1
2-4 3002-0011-01A BUZZER 1
2-5 9008-0584-01A MAIN BOARD ASS'Y 1
2-6 6003-0382-01A SCREW 14
2-7 0601-0045-01A LED 1
2-8 7217-2729-01A BATTERY COVER 1
2-9 9008-0586-01A SWITCH BOARD ASS'Y 1
2-10 6003-0383-01A SCREW 2
2-11 9010-0486-01A MAIN FRAME ASS'Y 1
2-12 7204-0157-01A MAIN FRAME 1
2-13 7011-0432-01A BATTERY PLATE 1
2-14 6107-0520-01A BATTERY OPEN SPRING 1
2-15 7217-2714-01A BATTERY CONNECTA 1
2-16 7217-2715-01A BATTERY BOTTOM COVER 1
2-17 7011-0433-01A BATTERYCONTACT-B 2
2-18 6107-0521-01A BATTERYSPRING 1
2-19 7411-0961-01A BATTERYPIN 1
2-20 9003-0196-01A VIEW FINDER ASS'Y 1
2-21 7213-0332-01A VIEW FINDER COVER 1
2-22 7213-0333-01A VIEW FINDER MASK 1
2-23 6723-0018-01A VIEW FINDER LENS-2 1
2-24 6723-0020-01A VIEW FINDER LENS-1 1
2-25 7213-0334-01A VIEW FINDER HOLDER 1
2-26 2501-0003-01A MAIN CONDENSER 1
2-27 9008-0585-01A POWER BOARD ASS'Y 1
2-28 6723-0019-01A VIEW FINDER LENS-3 1
2-29 4719-0012-01A XE TUBE 1
2-30 7012-0753-01A FLASH REFECTOR 1
2-31 7217-2726-01A FLASH HOLDER 1
2-32 7309-0389-01A TUBE HOLDER RUBBER 1
2-33 7409-1355-01A COPPER TAPE 1
2-34 7212-1701-01A LENS HOLDER 1
2-35 9010-0487-01A LENS ASS'Y 1
Fig.No. Parts No. Parts Name Q'ty Remarks

18
3-3
3-2
3-6
3-5
3-9
3-8
3-7
3-1
3-16
3-10
3-11
3-4
3-14
3-15
3-13
3-12
33.. BBAACCKK CCOOVVEERR
ⅢⅢ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT

19
▶▶PARTS LIST
3-1 \9007-1853-01A REAR COVER ASS'Y 1
3-2 7217-2716-01A BACK COVER 1
3-3 7217-2717-01A VF BACK COVER 1
3-4 7217-2720-01A READY LED WINDOW 1
3-5 7217-2727-01A MODE PLATE 1
3-6 9008-0583-01A FPC BOARD ASS'Y 1
3-7 7217-2719-01A MODE KEY(5-WAYBUTTON) 1
3-8 7217-2718-01A SELECT KEY 1
3-9 7411-0962-01A STRAP PIN 1
3-10 7409-1353-01A JACK PLATE-A 1
3-11 7409-1354-01A JACK PLATE-B 1
3-12 6003-0379-01A SCREW 1
3-13 6003-0378-01A SCREW 1
3-14 6003-0380-01A SCREW 3
3-15 6003-0382-01A SCREW 3
3-16 6003-0377-01A SCREW 1
Fig.No. Parts No. Parts Name Q'ty Remarks
ⅢⅢ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT

20
44.. PPAACCKKIINNGG IITTEEMM
4-1
4-2
4-3
4-4
4-5
4-6 4-7
4-9
4-8
4-17
4-16
4-15
4-10
4-11
4-14 4-12 4-13
ⅢⅢ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT

21
▶▶PARTS LIST
ⅢⅢ.. EEXXPPLLOODDEEDD VVIIEEWWSS AANNDD PPAARRTTSS LLIISSTT
Fig.No. Parts No. Parts Name Q'tY Remarks
4-1 7409-1300-01A FCC LABEL(MADE IN CHINA) 1
7409-1301-01A FCC LABEL(MADE BY SAMSUNG) 1
7409-1302-01A MIC LABEL_KENOX D 101 1
4-2 6804-0443-01A PRODUCT STICKER 1
4-3 P960-2101-01A PE BAG(FOR CAMERA) 1
4-4 6904-0236-01A POUCH 1
4-5 6901-1693-01A G/T BOX_KENOX_D 101_KOR 1
6901-1694-01A G/T BOX_DIGIMAX 101 1
6901-1695-01A G/T BOX_USA/CAN 1
4-6 4609-0038-01A DRIVER + MGI PHOTOSUITE(E/F/G/S/I/DUT/P) 1
4609-0039-01A DRIVER + MGI PHOTOSUITE(E/JPN/T.C/S.C/KOR) 1
4-7 6807-0026-01E WARRANTY CARD_KOR 1
6807-0030-03O WARRANTY CARD 1
6807-0038-02D WARRANTY CARD_UK 1
6807-0109-02B WARRANTY CARD_RUS 1
6807-0113-01A WARRANTY CARD_CHI 1
6807-0095-02D CARD PRODUCT_MEXICO 1
4-8 6806-1368-01A USER MANUAL_KENOX_D 101 1
6806-1369-01A USER MANUAL_ENG 1
6806-1370-01A USER MANUAL_GER 1
6806-1371-01A USER MANUAL_FRA 1
6806-1372-01A USER MANUAL_SPA 1
6806-1373-01A USER MANUAL_ITA 1
6806-1374-01A USER MANUAL_CHI(T) 1
6806-1375-01A USER MANUAL_DUT 1
6806-1376-01A USER MANUAL_POR 1
6806-1377-01A USER MANUAL_SWE 1
6806-1378-01A USER MANUAL_DEN 1
6806-1379-01A USER MANUAL_FIN 1
6806-1380-01A USER MANUAL_RUS 1
6806-1381-01A USER MANUAL_CHI(S) 1
4-9 6909-0116-01A PE BAG(FOR ACCESSORY) 1
4-10 3801-0016-01A USB CABLE 1
4-11 7409-1217-01A STRAP 1
4-12 4602-0004-01A SD CARD_16MB 1
4602-0005-01A SD CARD_32MB 1
4-13 4301-0018-01A BATTERY 1
4-14 6901-1692-01A INNER PAD 1
6806-1427-01A QUICK GUIDE_KOR 1
6807-0110-01A CARD_NETHERLAND(DIGITAL CAMERA) 1
6807-0108-01A U.K_VOUCHER 1
6804-0063-01G A/S STICKER_KOR 1
6804-0088-01A SECURITY STICKER_USA 1
6804-0377-01A TECH/SUPPORT(DSC_USA) 1
7409-0637-01A SAFETY_RUSSIA 1
