Samsung CNH HDB Series Instruction manual

SINGLE
Technical
Data Book
Low Ambient Line up for America
(R410A, Cooling Only)
Model : CNH**4DB (AC***BN4DCH/AA), CNH**HDB (AC***BNHDCH/AA),
CNH**ADB (AC***BNADCH/AA), CNH**TDB (AC***BNTDCH/AA), CXC**SCB (AC***BXSCCC/AA)

History
Version Modification Date Remark
21. 12. 24
Ver.1.0 Released 2021 CAC TDB for North America (Low Ambient Line up)
22. 02. 07
Ver.1.1 Modified the Net Weight Spec of the Wind-Free 4Way Cassette
22.. 09. 05
Ver.1.2 Updated the Specification page
22.. 12. 12
Ver.1.3 Updated the some data in specification and sound page.

CAC - World-class energy efficiency
Maintain optimal comfort and control with energy and
cost-efficient technologies
Featuring a suite of energy-optimizing technologies,
Samsung CAC Single delivers top-class energy efficiency
to support business in saving costs and the environment.
Quick, efficient heating and cooling
Smart inverter technology offers powerful, quick cooling
and heating with minimal electricity consumption, which
means real cost savings and less energy waste.
Up to 50 percent less energy use
After reaching changes its operation mode to economical.
By avoiding inefficient and frequent switching on and off of
the compressor, the digital inverter saves up to 50percent
in energy consumption compared to non-inverter air
conditioners.
200
300
400
500
600
(Wh/h)
Saving
302
Wh/h
621.4
Wh/h
Non-inverter
Wind-Free Cooling with Micro holes
•The Wind-Free Air conditioner pushes air out through
15,000 micro holes in the panel, producing a dispersed
and gentle flow of air actually defined as “still air” and
the key here is all of those holes create a still, cooled
air flow that infiltrates the room gently and softly.
※ Still Air condition : According to ASHRAE, If velocity
of wind is lower than 0.15m/s, People can not detect
wind. And they define that condition is “Still Air”
※Wind-Free 4Way(600x600) : 9,000 Micro Holes
15,000 Micro Holes
[ Comparison of Room Temp.]
ASHRAE Comfort Zone(23℃~26℃)
Normal
Cooling
Set Off
Wind -Free Cooling
20
34
32
30
28
26
24
22
0 20 40 60 80 100 120 140 160
Room Temp.(℃)
Time (Min)
“ Maintain comfort condition
with Wind-Free cooling ”
※ Internal Test (14.0kW Model @ 122m²)
Features & Benefits

Features & Benefits
CAC Single - Superior performance
Stabilize the atmosphere with broad temperature
allowance and control
Samsung is dedicated to supporting comfortable living
and working environments based on the strength of
its technologies. With a single unit, CAC Single delivers
reliable comfort and control over multiple areas to ensure
a pleasant atmosphere in any climate.
Wide temperature performance
No matter how extreme the temperature, the high-
performing CAC Single can handle the condition-
without the need for an additional unit. Featuring a wide
temperature allowance, it can cool in heat of up to 50 and
provide warmth in the freezing cold of -20℃ to ensure a
constant and comfortable home environment.
Ideal comfort in minutes
The CAC Single digital inverter air conditioner works at
maximum capacity at startup. As soon as the temperature
reaches the desired or set temperature, CAC Single
performs fine adjustments to cope with any changes. This
means less temperature fluctuation and ideal comfort in a
matter of minutes.
Uncomfortable
(Energy Loss)
Comfortable
Uncomfortable
(Energy Loss)
25 C
24 C
23 C
Steady Temperature Fluctuation
Non-inverter
High Temperature Fluctuation
Versatile piping installation
CAC Single outdoor units offer a selection of pipe directions.
The internal pipe connection ports allow four different pipe
directions, supporting a neater, more organized-looking unit
upon installation.

Nomenclature
US Code
(1) Classification
CCAC
(2) Product Type
NIndoor Unit
XOutdoor Unit
(3) Mode
AUniversal
(4) Capacity
X1,000 Btu/h (2 digits)
(5-1) Product Notation (Indoor Unit)
11 Way Cassette / Wind-Free 1Way Cassette
N4 Way Cassette (600x600)
Wind-Free 4 Way Cassette (600x600)
44 Way Cassette, 360 Cassette
Wind-Free 4 Way Cassette
LLSP Duct
HHSP Duct
CCeiling
JConsole
AAR9500 (Wall Mounted)
(5-2) Feature1 (Outdoor Unit)
AInv+Side+General Temp
SInv+Side+Low Temp
QInv+Side+Tropical Temp
FInv+Top+Tropical Temp
(6) Feature
(7) Version
B2022
Model Name
C
(1)
N
(2)
H
(3)
36
(4)
4
(5)
D
(6)
B
(7)
CCooling Only
HHeat Pump
T MAX4 (Wall Mounted)
ZMulti-position AHU
FFlagship
SStandard
DDeluxe
PPremium
CDeluxe + Low Temp.

Nomenclature
Indoor Unit
Model Name
AC
(1)
036
(2)
B
(3)
N
(4)
4
(5)
D
(6)
C
(7)
H
(8)
AA
Buyer
(1) Classification
AC CAC
(2) Capacity
X1,000 Btu/h (3 digits)
(3) Version
(4) Product Type
NIndoor Unit
XOutdoor Unit
(5) Product Notation
(6) Feature
FFlagship
SStandard
DDeluxe
PPremium
(7) Rating Voltage
C1Φ, 208-230V,60Hz
(8) Mode
B2022
CCooling Only
HHeat Pump
11 Way Cassette
N4 Way Cassette (600x600)
Wind-Free 4 Way Cassette (600x600)
44 Way Cassette, 360 Cassette
Wind-Free 4 Way Cassette
LLSP Duct
HHSP Duct
CCeiling
JConsole
AAR9500 (Wall Mounted)
T MAX4 (Wall Mounted)
ZMulti-position AHU

Nomenclature
Outdoor Unit
Model Name
AC
(1)
036
(2)
B
(3)
X
(4)
S
(5)
C
(6)
C
(7)
C
(8)
AA
Buyer
(1) Classification
(2) Capacity
x 1000 Btu/h (3 digits)
(3) Version
(4) Product Type
NIndoor Unit (NASA)
XOutdoor Unit (NASA)
(5) Feature1
AInv+Side+General Temp
SInv+Side+Low Temp
QInv+Side+Tropical Temp
FInv+Top+Tropical Temp
(6) Feature2
(7) Rating Voltage
C1Φ, 208~230V, 60Hz
H3Φ, 400V, 60Hz
(8) Mode
HHeat Pump(R410A)
CCooling Only(R410A)
EHeat Pump(R22)
DCooling Only(R22)
AC CAC
B2022
FFlagship
SStandard
DDeluxe
PPremium
CDeluxe + Low Temp.

Line-up
Indoor unit
Model
Capacity ( kBtu/h)
18 24 30 36
Wind-Free
4Way Cassette
Outdoor Unit
Model
Capacity ( kBtu/h)
18 24 30 36
1Phase
Duct S
Wall Mounted Type

Contents
Wind-Free 4Way Cassette 10
Outdoor Units 68
Installation 85
26
Duct S
Wall Mounted Type 49

Wind-Free 4Way Cassette
1. Specification 12
2. Summary Table 16
3. Capacity Table 17
4. Dimensional Drawing 19
5. Center of Gravity 21
6. Electrical Wiring Diagram 22
7. Sound Data 23
8. Temperature and air flow distribution 25

Wind-Free 4Way Cassette
Features & Benefits
Stage a beautiful yet comfortable environment
With its newly improved design, Wind-Free 4Way Cassette
supports a clean, aesthetically appealing atmosphere and
adds a sense of sophistication to work and living spaces.
Not only is this unit attractively designed, but it also
uses advanced technologies to optimize comfort in any
environment.
The Samsung Wind-Free 4Way Cassette indoor air
conditioning system delivers polish, comfort and
efficiency with features such as:
•Stylishly clean design. Add panache to interior spaces
with a choice of clean, streamlined panel patterns in a
lightweight build.
•Robust operation. Control the atmosphere perfectly
with an advanced design for superior airflow and
cooling/heating performance.
•Low maintenance and simple installation. Ease
installation and minimize maintenance with a
detachable, no-drip design.
Wind-Free 4Way Cassette - Stylishly clean design
Aesthetic panel and display
Wind-Free 4Way Cassette offers two different pattern
designs for the panel. The simple display design with
rounded corners adds a chic sophistication to the interior.
Power Defrost Time Clean
Neat and clean design
The indoor Wind-Free 4Way Cassette boasts a smart
design that promotes a neat and clean look. The
completely hermetic blade structure keeps the indoor
unit clean by preventing dust or other foreign substances
from entering it. The internal parts of the indoor unit are
also out of sight when the blade is shut, thus improving
the unit’s appearance.
Lightweight build
The Samsung Wind-Free 4Way Cassette indoor unit is
now lighter in weight at 17 kg. It is one of the lightest
indoor units in the industry, about 40 percent lighter than
conventional products.
40%
29kg
17kg
40%
29kg
17kg
Wind-Free 4Way Cassette Conventional
*Based on 10kW

1. Specification1. Specification
Wind-Free 4Way Cassette
AC018BN4DCH/AA AC024BN4DCH/AA
AC018BXSCCC/AA AC024BXSCCC/AA
CNH184DB CNH244DB
CXC18SCB CXC24SCB
-Cooling Only Cooling Only
kW 1.17/5.28/6.45 1.76/7.03/8.79
Btu/h 4,000 / 18,000 / 22,000 6,000 / 24,000 / 30,000
US RT0.33/1.50/1.83 0.50/2.00/2.50
kW - -
Btu/h - -
US RT- -
Cooling 0.24 / 1.49 / 2.20 0.30 / 2.14 / 3.69
Heating - -
Cooling 1.50 / 6.82 / 9.70 1.90 / 9.59 /16.20
Heating - -
MCA A 13.5 20.1
MOP A15 25
Cooling -3.54 3.29
Cooling(US) (Btu/h)/W 12.10 11.20
COP2 Heating W/W - -
SEER2 -22.5 21.5
HSPF2 - - -
Type Flare Flare
Φ, mm(inch) 6.35 (1/4) 6.35 (1/4)
Type Flare Flare
Φ, mm(inch) 12.7 (1/2) 15.88 (5/8)
-Both liquid and gas pipes Both liquid and gas pipes
Standard m (ft) 7.5 (24.6) 7.5 (24.6)
Max. m (ft) 30 (98.4) 50 (164.0)
Elevation m (ft) 20 (65.6) 30 (98.4)
Chargeless m (ft) 7.5 (24.6) 7.5 (24.6)
Min. mm20.75 0.75
Remark -F1,F2 F1,F2
-R410A R410A
kg 1.3 2
lbs 2.86 4.41
-0143FF-1950C6-2F343B-370020 0143FF-1950C6-27484F-370020
-020010-100001-200000-300000 020010-100001-200000-300000
Φ,#,V,Hz 1,2,208-230,60 1,2,208-230,60
-Fin & Tube Fin & Tube
Fin -Al Al
Tube -Cu Cu
-Green Hydrophile Green Hydrophile
-Turbo Turbo
EA 1 1
m3/min 24.0/21.0/18.0 24.0/21.0/18.0
ft³/min 848/742/636 848/742/636
l/s 400/350/300 400/350/300
External Static
Pressure Min/Std/Max In Wg- -
-BLDC BLDC
W x n 65 x 1 65 x 1
Drain Φ, mm OD26.67 OD26.67
Sound Pressure
Level H/M/L dB(A) 36/33/30 36/33/30
Sound Power Level dB(A) 53 53
kg(lbs) 15.9(35.1) 16.0(35.3)
kg(lbs) 19.4(42.8) 19.5(43.0)
mm 840 x 246 x 840 840 x 246 x 840
inch 33.07 x 9.69 x 33.07 33.07 x 9.69 x 33.07
mm 898 x 316 x 898 898 x 316 x 898
inch 35.35 x 12.44 x 35.35 35.35 x 12.44 x 35.35
Refrigerant
Type
Factory Charging
Pipe
Connections
Liquid Pipe
Gas Pipe
Heat Insulation
Pipe Length
(ODU-IDU)
Wiring
Connections Communication
Mode
Performance Capacity
(Min/Std/Max)
Cooling
Heating
Power
Power Input
(Min/Std/Max)
Material
Fin Treatment
Fan
Model Name Indoor Unit
Outdoor Unit
US Code Indoor Unit
Outdoor Unit
System
Type
Quantity
Air Flow Rate H/M/L
Option Code Standard
Install
Power Supply
Heat
Exchanger
Type
Indoor
Unit Fan Motor Type
Output
kW
Current Input
(Min/Std/Max) A
Current
Efficiency
EER2
Drain Pipe
Sound
External
Dimension
Net Weight
Gross Weight
Net Dimensions (WxHxD)
Gross Dimensions (WxHxD)

Wind-Free 4Way Cassette
1. Specification
NOTE
•Specification may be subject to change without priornotice.
1) Performances are based on the following test conditions.
-Cooling : Indoor temperature : 80°F(26.7°C) DB, 67°F(19.4°C) WB, Outdoor temperature : 95°F(35°C) DB, 75°F(23.9°C) WB
-Heating : Indoor temperature : 70°F(21.1°C) DB, 60°F(15.6°C) WB, Outdoor temperature : 47°F(8.3°C) DB, 43°F(6.1°C) WB
- Equivalent refrigerant piping length 5m(16.4ft), Level differences : 0m(0ft))
2) Select wire size based on the value of MCA
3) Sound pressure level is obtained in an anechoic room.
- Sound pressure level is a relative value, depending on the distance and acoustic environment.
- Sound pressure level may differ depending on operation condition.
- dBA = A-weighted sound pressure level / Reference acoustic pressure 0 dB = 20uPa
4) Sound power level is an absolute value that a sound source generates.
- dBA = A-weighted sound power level
-Reference power : 1pW / Measured according to ISO 3741
5) These products contain R410A which is fluorinated greenhouse gas.
Casing -Polypropylene Polypropylene
-PC4NUFMUN PC4NUFMUN
-Wind-Free Type Wind-Free Type
-HIPS HIPS
-DA White DA White
kg(lbs) 6.3 (13.9) 6.3 (13.9)
kg(lbs) 8.7 (19.2) 8.7 (19.2)
mm 950 x 64 x 950 950 x 64 x 950
inch 37.4 x 2.5 x 37.4 37.4 x 2.5 x 37.4
mm 1,010 x 117 x 1,000 1,010 x 117 x 1,000
inch 39.8 x 4.6 x 39.4 39.8 x 4.6 x 39.4
-AR-EH04U AR-EH04U
-MWR-WG00UN / MWR-SH11UN MWR-WG00UN / MWR-SH11UN
-Included Included
in / gal/h 29-5/16 6.34gal/h 29-5/16 6.34gal/h
Additional
Accessories -Removable / Washable Removable / Washable
Φ,#,V,Hz 1,2,208-230,60 1,2,208-230,60
-Fin & Tube Fin & Tube
Fin -Al Al
Tube -Cu Cu
-Anti-Corrosion Anti-Corrosion
-UG9TK3150FE4SG UG4T200FUAE4SG
-Twin BLDC Twin BLDC
kW 1.42 1.79
Type -POE POE
Initial Charge cc (fl oz) 500 650
-Propeller Propeller
-Front Front
EA 1 1
m3/min 40 51
ft³/min 1,413 1,801
l/s 667 850
-BLDC BLDC
W x n 125 x 1 125 x 1
Cooling dB(A) 48 50
Heating dB(A) - -
Sound Power Level dB(A) 62 65
kg(lbs) 40.5 (89.3) 52.5 (115.7)
kg(lbs) 43.5 (95.9) 56.5 (124.6)
mm 880 x 638 x 310 880 x 798 x 310
inch 34.64 x 25.12 x 12.20 34.64 x 31.42 x 12.20
mm 1,023 x 881 x 413 1,023 x 881 x 413
inch 40.28 x 28.74 x 16.26 40.28 x 34.69 x 16.26
Casing Material Body -Steel Steel
℃ (℉) -40~50 (-40~122) -40~50 (-40~122)
℃ (℉) - -
Model Name Indoor Unit
Outdoor Unit
US Code Indoor Unit
Outdoor Unit
Indoor
Unit
Material
Panel
Model Name
Type
Material
Color
Net Weight
Gross Weight
Net Dimensions (WxHxD)
Gross Dimensions (WxHxD)
Gross Dimensions (WxHxD)
Control
System
Infrared remote control
Wired remote control
Drain Pump Drain Pump
Max.lifting Height / Displacement
Type
Operating
Temp. Range
Cooling
Heating
Sound
Sound Pressure
Level
External
Dimension
Net Weight
Gross Weight
Net Dimensions (WxHxD)
H/M/L
Air Filter
Outdoor
Unit
Power Supply
Heat
Exchanger
Type
Material
Fin Treatment
Compressor Model
Fan Motor Type
Output
Output
Oil
Fan
Type
Discharge direction
Quantity
Air Flow Rate
AC018BN4DCH/AA
AC018BXSCCC/AA
CNH184DB
CXC18SCB
AC024BN4DCH/AA
AC024BXSCCC/AA
CNH244DB
CXC24SCB

1. Specification
Wind-Free 4Way Cassette
AC030BN4DCH/AA AC036BN4DCH/AA
AC030BXSCCC/AA AC036BXSCCC/AA
CNH304DB CNH364DB
CXC30SCB CXC36SCB
-Cooling Only Cooling Only
kW 2.64/8.79/10.55 2.93/10.55/11.72
Btu/h 9,000 / 30,000 / 36,000 10,000 / 36,000 / 40,000
US RT0.75/2.50/3.00 0.83/3.00/3.33
kW - -
Btu/h - -
US RT- -
Cooling 0.61 / 2.73 / 4.60 0.70 / 3.60 / 4.80
Heating - -
Cooling 3.10 / 12.11 / 20.20 3.60 / 15.81 / 21.10
Heating - -
MCA A 23.5 24.9
MOP A30 30
Cooling -3.22 2.93
Cooling(US) (Btu/h)/W 11.00 10.00
COP2 Heating W/W - -
SEER2 -21.5 19.1
HSPF2 - - -
Type Flare Flare
Φ, mm(inch) 9.52 (3/8) 9.52 (3/8)
Type Flare Flare
Φ, mm(inch) 15.88 (5/8) 15.88 (5/8)
-Both liquid and gas pipes Both liquid and gas pipes
Standard m (ft) 7.5 (24.6) 7.5 (24.6)
Max. m (ft) 50 (164.0) 50 (164.0)
Elevation m (ft) 30 (98.4) 30 (98.4)
Chargeless m (ft) 7.5 (24.6) 7.5 (24.6)
Min. mm20.75 0.75
Remark -F1,F2 F1,F2
-R410A R410A
kg 2.4 2.4
lbs 5.29 5.29
-0143FF-195418-275A5E-370040 0143FF-19546A-276975-370040
-020010-100001-200000-300000 020010-100001-200000-300000
Φ,#,V,Hz 1,2,208-230,60 1,2,208-230,60
-Fin & Tube Fin & Tube
Fin -Al Al
Tube -Cu Cu
-Green Hydrophile Green Hydrophile
-Turbo(3D) Turbo(3D)
EA 1 1
m3/min 28.2/23.6/17.8 34.2/25.8/19.0
ft³/min 996/833/629 1208/911/671
l/s 470/393/297 570/430/317
External Static
Pressure Min/Std/Max In Wg- -
-BLDC BLDC
W x n 97 x 1 97 x 1
Drain Φ, mm OD26.67 OD26.67
Sound Pressure
Level H/M/L dB(A) 37/34/30 43/38/33
Sound Power Level dB(A) 53 59
kg(lbs) 19.0(41.9) 21.2(46.7)
kg(lbs) 22.5(49.6) 24.8(54.7)
mm 840 x 288 x 840 840 x 288 x 840
inch 33.07 x 11.34 x 33.07 33.07 x 11.34 x 33.07
mm 898 x 357 x 898 898 x 357 x 898
inch 35.35 x 14.06 x 35.35 35.35 x 14.06 x 35.35
External
Dimension
Net Weight
Gross Weight
Net Dimensions (WxHxD)
Gross Dimensions (WxHxD)
H/M/L
Fan Motor Type
Output
Drain Pipe
Sound
Indoor
Unit
Power Supply
Heat
Exchanger
Type
Material
Fin Treatment
Fan
Type
Quantity
Air Flow Rate
Refrigerant
Type
Factory Charging
Option Code Standard
Install
Pipe
Connections
Liquid Pipe
Gas Pipe
Heat Insulation
Pipe Length
(ODU-IDU)
Wiring
Connections Communication
kW
Current Input
(Min/Std/Max) A
Current
Efficiency
EER2
Mode
Performance Capacity
(Min/Std/Max)
Cooling
Heating
Power
Power Input
(Min/Std/Max)
Model Name Indoor Unit
Outdoor Unit
US Code Indoor Unit
Outdoor Unit
System

Wind-Free 4Way Cassette
1. Specification
NOTE
•Specification may be subject to change without prior notice.
1) Performances are based on the following test conditions.
-Cooling : Indoor temperature : 80°F(26.7°C) DB, 67°F(19.4°C) WB, Outdoor temperature : 95°F(35°C) DB, 75°F(23.9°C) WB
-Heating : Indoor temperature : 70°F(21.1°C) DB, 60°F(15.6°C) WB, Outdoor temperature : 47°F(8.3°C) DB, 43°F(6.1°C) WB
- Equivalent refrigerant piping length 7.5m(24.6ft), Level differences : 0m(0ft))
2) Select wire size based on the value of MCA
3) Sound pressure level is obtained in an anechoic room.
- Sound pressure level is a relative value, depending on the distance and acoustic environment.
- Sound pressure level may differ depending on operation condition.
- dBA = A-weighted sound pressure level / Reference acoustic pressure 0 dB = 20uPa
4) Sound power level is an absolute value that a sound source generates.
- dBA = A-weighted sound power level
-Reference power : 1pW / Measured according to ISO 3741
5) These products contain R410A which is fluorinated greenhouse gas.
Casing -Polypropylene Polypropylene
-PC4NUFMUN PC4NUFMUN
-Wind-Free Type Wind-Free Type
-HIPS HIPS
-DA White DA White
kg(lbs) 6.3 (13.9) 6.3 (13.9)
kg(lbs) 8.7 (19.2) 8.7 (19.2)
mm 950 x 64 x 950 950 x 64 x 950
inch 37.4 x 2.5 x 37.4 37.4 x 2.5 x 37.4
mm 1,010 x 117 x 1,000 1,010 x 117 x 1,000
inch 39.8 x 4.6 x 39.4 39.8 x 4.6 x 39.4
-AR-EH04U AR-EH04U
-MWR-WG00UN / MWR-SH11UN MWR-WG00UN / MWR-SH11UN
-Included Included
in / gal/h 29-5/16 6.34gal/h 29-5/16 6.34gal/h
Additional
Accessories -Removable / Washable Removable / Washable
Φ,#,V,Hz 1,2,208-230,60 1,2,208-230,60
-Fin & Tube Fin & Tube
Fin -Al Al
Tube -Cu Cu
-Anti-Corrosion Anti-Corrosion
-UG8T300FUBJUSG UG8T300FUBJUSG
-Twin BLDC Twin BLDC
kW 2.82 2.82
Type -POE POE
Initial Charge cc (fl oz) 1200 1200
-Propeller Propeller
-Front Front
EA 1 1
m3/min 78 78
ft³/min 2,755 2,755
l/s 1,300 1,300
-BLDC BLDC
W x n 125 x 1 125 x 1
Cooling dB(A) 52 54
Heating dB(A) - -
Sound Power Level dB(A) 67 69
kg(lbs) 71.0 (156.5) 71.0 (156.5)
kg(lbs) 76.0 (167.6) 76.0 (167.6)
mm 940 x 998 x 330 940 x 998 x 330
inch 37.01 x 39.29 x 12.99 37.01 x 39.29 x 12.99
mm 995 x 1,096 x 426 995 x 1,096 x 426
inch 37.17 x 43.15 x 16.77 37.17 x 43.15 x 16.77
Casing Material Body -Steel Steel
℃ (℉) -40~50 (-40~122) -40~50 (-40~122)
℃ (℉) - -
External
Dimension
Net Weight
Gross Weight
Net Dimensions (WxHxD)
Gross Dimensions (WxHxD)
Operating
Temp. Range
Cooling
Heating
H/M/L
Fan Motor Type
Output
Sound
Sound Pressure
Level
Compressor Model
Type
Output
Oil
Fan
Type
Discharge direction
Quantity
Air Flow Rate
Drain Pump Drain Pump
Max.lifting Height / Displacement
Air Filter
Outdoor
Unit
Power Supply
Heat
Exchanger
Type
Material
Fin Treatment
Net Weight
Gross Weight
Net Dimensions (WxHxD)
Gross Dimensions (WxHxD)
Control
System
Infrared remote control
Wired remote control
US Code Indoor Unit
Outdoor Unit
Indoor
Unit
Material
Panel
Model Name
Type
Material
Color
Model Name Indoor Unit
Outdoor Unit
AC030BN4DCH/AA
AC030BXSCCC/AA
CNH304DB
CXC30SCB
AC036BN4DCH/AA
AC036BXSCCC/AA
CNH364DB
CXC36SCB

2. Summary Table2. Summary Table
Performance Characteristics
Model Code
Net
Weight
(lbs)
Capacity
Fan Speed
Airflow
(Cooling/Heating)
(CFM)
Sound Pressure Level
(dBA)
Sound Power Level
(dBA)
Cooling
(Btu/h)
Heating
(Btu/h)
CNH184DB
(AC018BN4DCH/AA)35.1
Max. 22,000 High 848 / -36 53
Std. 18,000 Mid 742 / -33 -
Min. 4,000 Low 636 / -30 -
CNH244DB
(AC024BN4DCH/AA)35.3
Max. 30,000 High 36
Std. 24,000 Mid 33 -
Min. 6,000 Low 30 -
CNH304DB
(AC030BN4DCH/AA)41.9
Max. 36,000 High 996 / -
Std. 30,000 Mid 833 / --
Min. 9,000 Low 629 / --
CNH364DB
(AC036BN4DCH/AA)46.7
Max. 40,000 High 1,208 / -
Std. 36,000 Mid 911 / --
Min. 10,000 Low 671 / --
NOTE
•Sound data is based on cooling operation.
Electric Characteristics
Model Outdoor Unit Input Current (Amperes) Power Supply
Indoor Unit Outdoor Unit Rated Voltage range Outdoor Unit Indoor
Unit Total MCA(A) MOP(A)
Hz Volts Min. Max Cooling Heating
CNH184DB (AC018BN4DCH/AA) CXC18SCB (AC018BXSCCC/AA)
60 208 to 230 187 253 13.5 15
CNH244DB (AC024BN4DCH/AA) CXC24SCB (AC024BXSCCC/AA)
60 208 to 230 187 253 20.1 25
CNH304DB (AC030BN4DCH/AA) CXC30SCB (AC030BXSCCC/AA)
60 208 to 230 187 253 23.5 30
CNH364DB (AC036BN4DCH/AA) CXC36SCB (AC036BXSCCC/AA)
60 208 to 230 187 253 24.9 30
NOTE
•MCA : Minimum circuit amperes
•MOP: Maximum Overcurrent Protective Device
•Select wire size based on the value of MCA
Wind-Free 4Way Cassette
848 / -
742 / -
636 / -
37
34
30
43
38
33
53
53
59
0.79
0.79
0.79
0.79
-
-
-
-
-
-
-
-
-
-
-
-
11.33
17.95
21.33
21.33
-
-
-
-
12.12
18.74
22.12
22.12

Wind-Free 4Way Cassette
3. Capacity Table3. Capacity Table
(1) CNH184DB (AC018BN4DCH/AA) + CXC18SCB (AC018BXSCCC/AA)
Cooling
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
NOTE
•The performance table shows the average value of each conditions.
(2)CNH244DB (AC024BN4DCH/AA) + CXC24SCB (AC024BXSCCC/AA)
Cooling
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
-40 23.1 16.7 1.26 24.3 17.2 1.29 25.3 17.7 1.31 26.1 18.3 1.34 26.6 18.1 1.35 28.0 17.9 1.37 29.4 17.5 1.40
019.9 14.4 1.40 21.0 14.8 1.43 21.8 15.3 1.46 22.5 15.8 1.49 23.0 15.6 1.50 24.1 15.4 1.52 25.3 15.1 1.55
70 21.5 15.5 1.54 22.6 16.0 1.57 23.6 16.5 1.61 24.3 17.0 1.64 24.8 16.8 1.66 26.0 16.7 1.67 27.3 16.3 1.71
95 15.9 11.5 1.40 16.8 11.9 1.43 17.5 12.2 1.46 18.0 12.6 1.49 18.4 12.5 1.50 19.3 12.3 1.52 20.2 12.1 1.55
115 16.7 13.8 2.10 17.6 14.2 2.15 18.3 14.7 2.19 18.9 15.1 2.24 19.3 15.0 2.26 20.2 14.8 2.28 21.3 14.5 2.33
122 11.9 11.1 1.61 12.6 11.4 1.65 13.1 11.8 1.68 13.5 12.2 1.71 13.8 12.0 1.73 14.5 11.9 1.75 15.2 11.7 1.78
86 / 72 90 / 75
Outdoor
Temp.
(℉, DB)
Indoor Temperature (℉, DB / WB)
68 / 57 72 / 61 77 / 6480 / 67 82 / 70
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
-40 25.5 19.7 1.61 26.8 20.3 1.64 27.9 21.0 1.68 28.8 21.6 1.71 29.4 21.4 1.73 30.8 21.2 1.75 32.4 20.7 1.78
023.4 18.1 1.41 24.6 18.6 1.44 25.6 19.2 1.47 26.4 19.8 1.50 26.9 19.6 1.51 28.3 19.4 1.53 29.7 19.0 1.56
70 28.7 22.2 1.91 30.2 22.9 1.95 31.4 23.6 1.99 32.4 24.3 2.03 33.0 24.1 2.05 34.7 23.8 2.07 36.4 23.3 2.12
95 21.2 15.3 2.01 22.3 15.8 2.06 23.3 16.3 2.10 24.0 16.8 2.14 24.5 16.6 2.16 25.7 16.5 2.18 27.0 16.1 2.23
115 20.2 16.6 2.62 21.2 17.2 2.67 22.1 17.7 2.73 22.8 18.2 2.78 23.3 18.1 2.81 24.4 17.9 2.84 25.6 17.5 2.89
122 18.0 15.8 2.52 19.0 16.3 2.57 19.8 16.8 2.62 20.4 17.3 2.68 20.8 17.2 2.70 21.8 17.0 2.73 22.9 16.7 2.78
Outdoor
Temp.
(℉, DB)
Indoor Temperature (℉, DB / WB)
68 / 57 72 / 61 77 / 6480 / 67 82 / 70 86 / 72 90 / 75

3. Capacity Table
Wind-Free 4Way Cassette
(3)CNH304DB (AC030BN4DCH/AA) + CXC30SCB (AC030BXSCCC/AA)
Cooling
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
NOTE
•The performance table shows the average value of each conditions.
(4)CNH364DB (AC036BN4DCH/AA) + CXC36SCB (AC036BXSCCC/AA)
Cooling
TC : Total Capacity, SHC : Sensible Heat Capacity, PI : Power Input
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
-40 30.5 23.6 2.83 32.1 24.3 2.88 33.5 25.1 2.94 34.5 25.9 3.00 35.2 25.6 3.03 36.9 25.4 3.06 38.8 24.9 3.12
031.8 24.6 2.83 33.5 25.4 2.88 34.9 26.2 2.94 36.0 27.0 3.00 36.7 26.7 3.03 38.6 26.5 3.06 40.5 25.9 3.12
70 33.2 25.7 2.44 34.9 26.5 2.49 36.4 27.3 2.54 37.5 28.1 2.59 38.3 27.8 2.62 40.2 27.6 2.65 42.2 27.0 2.70
95 26.5 20.5 2.57 27.9 21.2 2.62 29.1 21.8 2.68 30.0 22.5 2.73 30.6 22.3 2.76 32.1 22.1 2.78 33.7 21.6 2.84
115 22.6 20.9 2.83 23.7 21.6 2.88 24.7 22.3 2.94 25.5 23.0 3.00 26.0 22.7 3.03 27.3 22.5 3.06 28.7 22.0 3.12
122 19.9 18.5 2.70 21.0 19.1 2.75 21.8 19.6 2.81 22.5 20.3 2.87 23.0 20.0 2.90 24.1 19.8 2.92 25.3 19.5 2.98
86 / 72 90 / 75
Outdoor
Temp.
(℉, DB)
Indoor Temperature (℉, DB / WB)
68 / 57 72 / 61 77 / 6480 / 67 82 / 70
TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI TC SHC PI
MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW MBH MBH kW
-40 36.6 28.3 3.73 38.6 29.2 3.80 40.2 30.1 3.88 41.4 31.1 3.96 42.2 30.7 4.00 44.3 30.4 4.04 46.6 29.8 4.12
038.2 29.6 3.73 40.2 30.5 3.80 41.9 31.4 3.88 43.2 32.4 3.96 44.1 32.1 4.00 46.3 31.8 4.04 48.6 31.1 4.12
70 39.8 30.8 3.22 41.9 31.8 3.28 43.7 32.7 3.35 45.0 33.8 3.42 45.9 33.4 3.45 48.2 33.1 3.49 50.6 32.4 3.56
95 31.8 24.6 3.39 33.5 25.4 3.46 34.9 26.2 3.53 36.0 27.0 3.60 36.7 26.7 3.64 38.6 26.5 3.67 40.5 25.9 3.75
115 27.1 25.1 3.73 28.5 25.9 3.80 29.7 26.7 3.88 30.6 27.5 3.96 31.2 27.3 4.00 32.8 27.0 4.04 34.4 26.5 4.12
122 23.9 22.2 3.56 25.1 22.9 3.63 26.2 23.6 3.70 27.0 24.3 3.78 27.5 24.1 3.82 28.9 23.8 3.86 30.4 23.3 3.93
Outdoor
Temp.
(℉, DB)
Indoor Temperature (℉, DB / WB)
68 / 57 72 / 61 77 / 6480 / 67 82 / 70 86 / 72 90 / 75

Wind-Free 4Way Cassette
4. Dimensional Drawing4. Dimensional Drawing
CNH184DB (AC018BN4DCH/AA), CNH244DB (AC024BN4DCH/AA)
Units : mm [inches]
No. Name Description
CNH184DB (AC018BN4DCH/AA) CNH244DB (AC024BN4DCH/AA)
1Liquid pipe connection Φ 6.35mm(1/4")
2Gas pipe connection Φ 12.7mm(1/2") Φ 15.88mm(5/8")
3Drain pipe connection VP25 [OD32mm(1.26"), ID25mm(0.98")]
4Power supply & Communication wiring conduit
5Fresh air intake knockout hole Φ101mm(4") , Use M4 Screw
NOTE
• As for suspension bolt, please use M8 ~ M10.
(Procured at local site)

4. Dimensional Drawing
CNH304DB (AC030BN4DCH/AA), CNH364DB (AC036BN4DCH/AA)
Units : mm [inches]
No. Name Description
1Liquid pipe connection Φ 9.52mm(3/8")
2Gas pipe connection Φ 15.88mm(5/8")
3Drain pipe connection VP25[OD32mm(1.26"), ID25mm(0.98")]
4Power supply & Communication wiring conduit
5Fresh air intake knockout hole Φ101mm(4") , Use M4 Screw
NOTE
• As for suspension bolt, please use M8 ~ M10.
(Procured at local site)
Wind-Free 4Way Cassette
