Ceramic Glass Hob
user & installation manual
CTR264KC01
CTR264KC01_XFA DG68-00446A-02_EN.indd 1 2016-09-02 �� 1:29:01

English - 2
contents
USING THIS MANUAL
4
4 Important safety symbols and
precautions
SAFETY INSTRUCTIONS
5
5 Safety instructions
DISPOSAL INSTRUCTIONS
9
9 Disposing of the packaging material
9 Proper disposal of your old appliance
INSTALLING THE HOB
10
10 Safety instructions for the installer
11 Connecting to the mains power supply
13 Installing into the countertop
PARTS AND FEATURES
15
15 Cooking zones
15 Control panel
16 Components
16 The key features of your appliance
18 Safety shuto
19 Residual heat indicator
19 Temperature detection
BEFORE YOU BEGIN
19
19 Initial cleaning
CTR264KC01_XFA DG68-00446A-02_EN.indd 2 2016-09-02 �� 1:29:01

English - 3
HOB USE
20
20 Using suitable cookware
22 Using the touch control sensors
22 Switching the appliance on
23 Select cooking zone and heat setting
24 Switching the appliance o
24 Switching a cooking zone o
25 Using the child safety lock
26 Timer
28 Suggested settings for cooking
specific foods
28 Auto heat up
CLEANING AND CARE
30
30 Hob
32 Hob frame (option)
32 To avoid damaging your appliance
WARRANTY AND SERVICE
33
33 FAQs and troubleshooting
35 Service
TECHNICAL DATA
36
36 Technical data
36 Cooking rings
CTR264KC01_XFA DG68-00446A-02_EN.indd 3 2016-09-02 �� 1:29:01

English - 4
using this manual
Please take the time to read this owner’s manual, paying particular attention
to the safety information contained in the following section, before using
your appliance. Keep this manual for future reference. If transferring
ownership of the appliance, please remember to pass the manual on to
the new owner.
IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS
The following symbols are used in the text of this Owner’s Manual :
WARNING
Hazards or unsafe practices that may result in
severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in
minor personal injury or property damage.
CAUTION
To reduce the risk of fire, explosion, electric
shock, or personal injury when using your hob,
follow these basic safety precaution
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent
electric shock.
Call the service center for help.
Note
Important
CTR264KC01_XFA DG68-00446A-02_EN.indd 4 2016-09-02 �� 1:29:02

English - 5
safety instructions
The safety aspects of this appliance comply with all accepted technical
and safety standards. However, as manufacturers we also believe it is our
responsibility to familiarize you with the following safety instructions.
WARNING
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
Children should be supervised to ensure that they do
not play with the appliance.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Appliance should allow the disconnection of the
appliance from the supply after installation. The
disconnection may be achieved by having the plug
accessible or by incorporating a switch in the fixed
wiring in accordance with the wiring rules.
WARNING: If the surface is cracked, switch o the
appliance to avoid the possibility of electric shock.
During use the appliance becomes hot. Care should be
taken to avoid touching heating elements inside the hob.
WARNING: Accessible parts may become hot during
use. Young children should be kept away.
A steam cleaner is not to be used to clean the product.
Metallic objects such as knives, forks, spoons and lids
should not be placed on the hob surface since they
can get hot.
After use, switch o the hob element by its control and do
not rely on the pan detector.
01
USING THIS MANUAL & SAFETY INSTRUCTIONS
CTR264KC01_XFA DG68-00446A-02_EN.indd 5 2016-09-02 �� 1:29:02

English - 6
Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the hob glass since they can scratch
the surface, which may result in shattering of the glass.
Appliance is not intended to be operated by means of
an external timer or separate remote-control system.
WARNING: The appliance and its accessible parts
become hot during use.
Care should be taken to avoid touching heating
elements inside the hob.
Children less than 8 years of age shall be kept away
unless continuously supervised.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
WARNING: Unattended cooking on a hob with fat or
oil can be dangerous and may result in fire.
NEVER try to extinguish a fire with water, but switch o
the appliance and then cover flame e.g. with a lid or a
fire blanket.
WARNING: Danger of fire: do not store items on the
cooking surfaces.
The temperature of accessible surfaces may be high
when the appliance is operating.
Keep the appliance and its cord out of reach of
children less than 8 years.
WARNING: Use only hob guards designed by the
manufacturer of the cooking appliance. The use of
inappropriate guards can cause accidents.
CTR264KC01_XFA DG68-00446A-02_EN.indd 6 2016-09-02 �� 1:29:02

English - 7
CAUTION
Be sure the appliance is properly installed and
grounded by a qualified technician.
The appliance should be serviced only by qualified
service personnel. Repairs carried out by unqualified
individuals may cause injury or serious malfunction. If
your appliance is in need of repair, contact your local
service centre. Failure to follow these instructions may
result in damage and void the warranty.
Flush - mounted appliances may be operated only after
they have been installed in cabinets and workplaces that
conform to the relevant standards. This ensures sucient
protection against contact for electrical units as required
by the essential safety standards.
If your appliance malfunctions or if fractures, cracks or
splits appear:
- switch o all cooking zones;
- disconnect the hob from the mains supply; and
- contact your local service centre.
If the cooktop cracks, turn the appliance o to avoid the
possibility of electric shock. Do not use your hob until the
glass surface has been replaced.
Do not use the hob to heat aluminium foil, products
wrapped in aluminium foil or frozen foods packaged in
aluminium cookware.
Liquid between the bottom of the pan and the hob can
produce steam pressure. Which may cause the pan to
jump.
Always ensure that the hotplate and the base of the pan
are kept dry.
The cooking zones will become hot when you cook.
Always keep small children away from the appliance.
Keep all packaging materials well out of the reach of
children, as packaging materials can be dangerous to
children.
01
USING THIS MANUAL & SAFETY INSTRUCTIONS
CTR264KC01_XFA DG68-00446A-02_EN.indd 7 2016-09-02 �� 1:29:02

English - 8
This appliance is to be used only for normal cooking
and frying in the home. It is not designed for
commercial or industrial use.
Never use the hob for heating the room.
Take care when plugging electrical appliances into
mains sockets near the hob. Mains leads must not
come into contact with the cooktop.
Overheated fat and oil can catch fire quickly. Never
leave surface units unattended when preparing foods
in fat or oil, for example, when cooking chips.
Turn the cooking zones o after use.
Always keep the control panels clean and dry.
Never place combustible items on the hob, it may
cause fire.
There is the risk of burns from the appliance if used
carelessly.
Cables from electrical appliances must not touch the
hot surface of the hob or hot cookware.
Do not use the hob to dry clothes.
WARNING : Users with Pacemakers and Active Heart
Implants must keep their upper body at a minimum
distance of 30 cm from induction cooking zones
when turned on. If in doubt, you should consult the
manufacturer of your device or your doctor. (Induction
hob model only)
Do not attempt to repair, disassemble, or modify the
appliance yourself.
Always turn the appliance o before cleaning.
Clean the hob in accordance with the cleaning and
care instructions contained in this manual.
CTR264KC01_XFA DG68-00446A-02_EN.indd 8 2016-09-02 �� 1:29:02

English - 9English - 9
disposal instructions
DISPOSING OF THE PACKAGING MATERIAL
All materials used to package the appliance are fully recyclable. Sheet and hard foam parts
are appropriately marked. Please dispose of packaging materials and old appliances with due
regard to safety and the environment.
PROPER DISPOSAL OF YOUR OLD APPLIANCE
WARNING : Before disposing of your old appliance, make it inoperable so that it cannot be a
source of danger.
To do this, have a qualified technician disconnect the appliance from the mains supply and
remove the mains lead.
The appliance may not be disposed of in the household rubbish.
Information about collection dates and public refuse disposal sites is available from your local
refuse department or council.
02 DISPOSAL INSTRUCTIONS
WARNING
WARNING
CTR264KC01_XFA DG68-00446A-02_EN.indd 9 2016-09-02 �� 1:29:02

English - 10English - 10
installing the hob
Be sure the new appliance is installed and grounded only by
qualified personnel.
Please observe this instruction. The warranty will not
cover any damage that may occur as a result of improper
installation.
Technical data is provided at the end of this manual.
SAFETY INSTRUCTIONS FOR THE INSTALLER
• A device must be provided in the electrical installation that allows
the appliance to be disconnected from the mains at all poles with a
contact opening width of at least 3 mm. Suitable isolation devices
include line protecting cut - outs, fuses (screw type fuses are to be
removed from the holder), earth leakage trips and contactors.
• With respect to fire protection, this appliance corresponds to EN
60335 - 2 - 6. This type of appliance may be installed with a high
cupboard or wall on one side.
• Drawers may not be fitted underneath the hob.
• The installation must guarantee shock protection.
• The kitchen unit in which the appliance is fitted must satisfy the
stability requirements of DIN 68930.
• For protection against moisture, all cut surfaces are to be sealed
with a suitable sealant.
• On tiled work surfaces, the joints in the area where the hob sits
must be completely filled with grout.
• On natural, artificial stone, or ceramic tops, the snap action springs
must be bonded in place with a suitable artificial resin or mixed
adhesive.
• Ensure that the seal is correctly seated against the work surface
without any gaps. Additional silicon sealant must not be applied;
this would make removal more dicult when servicing.
• The hob must be pressed out from below when removed.
• A board is to be installed underneath the hob.
WARNING
CTR264KC01_XFA DG68-00446A-02_EN.indd 10 2016-09-02 �� 1:29:02

English - 11English - 11
CONNECTING TO THE MAINS POWER SUPPLY
Before connecting, check that the nominal voltage of the
appliance, that is, the voltage stated on the rating plate,
corresponds to the available supply voltage. The rating plate is
located on the lower casing of the hob.
Shut o power to circuit before connecting wires to
circuit.
The heating element voltage is AC 230 V~. The appliance also
works perfectly on networks with AC 220 V~ or AC 240 V~.
The hob is to be connected to the mains using a device that
allows the appliance to be disconnected from the mains at
all poles with a contact opening width of at least 3 mm, eg.
automatic line protecting cut - out, earth leakage trips or fuse.
A type H05RN - F cable or one of a higher grade must be used as
the mains connecting cable.
Rated current of
appliance (A)
Nominal cross-sectional
area (mm2)
1N~ > 25 and ≤ 32 ≥ 2.5
2N~ > 10 and ≤ 16 ≥ 1.5
The connection must be carried out as shown in the diagram.
The connecting links should be fitted according to the appropriate
connection diagram.
The earth lead is connected to terminal. The earth lead must be
longer than leads carrying electric current.
The cable connections must be made in accordance
with regulations and the terminal screws tightened
securely.
The connecting cable is to be secured with the mains cable cleat
and the covering closed by pressing firmly (locking into place).
Before switching on for the first time, any protective foil or stickers
must be removed from the ceramic glass surface.
03 INSTALLING THE HOB
WARNING
WARNING
CTR264KC01_XFA DG68-00446A-02_EN.indd 11 2016-09-02 �� 1:29:02

English - 12English - 12
Once the hob is connected to the mains supply, check that all
cooking zones are ready for use by briefly switching each on
in turn at the maximum setting with suit- able cookware.
When the hob is powered on for the first time, all displays light
and the child safety lock is activated.
Pay attention (conformity) to phase and neutral allocation
of house connection and appliance (connection schemes);
otherwise, components can be damaged.
Warranty does not cover damage resulting from improper
installation.
If the supply cord is damaged, it must be replaced by a
special cord or assembly available from the manufacturer or
its service agent.
WARNING
POWER CABLE METAL CONNECTOR
Pole No. Wire Connection
1 L
2 Connect with Pole-1 by metal connector
3 Connect with Pole-2 by metal connector
4 N
Ground
< 1N ~ >
Pole No. Wire Connection
1L-1
2L-2
3 Connect with Pole-2 by metal connector
4 N
Ground
POWER CABLE METAL CONNECTOR
< 2N ~ >
WARNING
WARNING
CTR264KC01_XFA DG68-00446A-02_EN.indd 12 2016-09-02 �� 1:29:03

English - 13English - 13
INSTALLING INTO THE COUNTERTOP
Make a note of the serial number on the appliance rating plate
prior to installation.
This number will be required in the case of requests for
service and is no longer accessible after installation, as it is on
the original rating plate on the underside of the appliance.
Pay special attention to the minimum space and clearance
requirements.
Secure the brackets at both sides with the provided screws
before mounting the hob onto the brackets.
03 INSTALLING THE HOB
x 4
ø 6
90 °
560±1
R3
min. 20
50
490±1
600
Min. 50 mm
CTR264KC01_XFA DG68-00446A-02_EN.indd 13 2016-09-02 �� 1:29:03

English - 14English - 14
=
=
90 ° x 4
ø 2
100
100
490±1
CTR264KC01_XFA DG68-00446A-02_EN.indd 14 2016-09-02 �� 1:29:03

English - 15English - 15
parts and features
COOKING ZONES
CONTROL PANEL
04 PARTS AND FEATURES
Casserole cooking zone 2400 W
Single cooking zone 1200 W
Triple cooking zone 2300 W
Control panel
Single cooking zone 1200 W
148 mm
120/175/215 mm
265 mm
170 mm
148 mm
Timer indicator and
control sensor
Triple cooking zone control sensor
Cooking zone selectors Setting control sensor (Slide control)
Indicators for Heat settings and
residual heat
Casserole zone
control sensor
On/O control sensor
Keep warm
Auto heat up
Lock control sensor
CTR264KC01_XFA DG68-00446A-02_EN.indd 15 2016-09-02 �� 1:29:03

English - 16English - 16
COMPONENTS
Ceramic Glass
Hob
Installation
Brackets
Screws
THE KEY FEATURES OF YOUR APPLIANCE
• Ceramic glass cooking surface: The appliance has a ceramic
glass cooking surface and four rapid - response cooking zones.
The hob’s powerful radiant heater elements significantly shorten
the amount of time required for the zones to heat up.
• Touch control sensors: Your appliance is operated using
touch control sensors.
• Easy cleaning: The advantage of the ceramic glass cooking
surface and the control sensors is their accessibility for
cleaning. The smooth, flat surface is easy to clean.
• On/O sensor: The “On/O” control sensor provides the
appliance with a separate mains switch. Touching this sensor
switches the power supply on or o completely.
• Control and function indicators: Digital displays and indicator
lights provide information about settings and activated
functions, as well as the presence of residual heat in the various
cooking zones.
• Safety shuto: A safety shuto ensures that cooking zones
switch o automatically after a period of time if the setting has
not been changed.
• Residual heat indicator: An icon for residual heat appears in
the display if the cooking zone is so hot that there is a risk of
burning.
CTR264KC01_XFA DG68-00446A-02_EN.indd 16 2016-09-02 �� 1:29:03

English - 17English - 17
• Digital displays: The four display fields are assigned to the four
cooking zones.
They show the following information:
- the appliance has been switched on,
- to selected heat settings,
- residual heat,
- the child lock is activated
- error message, the sensor has been touched for
longer than 60 seconds.
- error message, when the hob is overheated because
of abnormal operation. (example : operation with empty
cookware)
• Keep warm : Use this function to keep warm cooked food.
(The display will show ‘ ’.)
• Auto heat up : Use this function to heat automatically at the
highest power level. (The display will show ‘ ’.)
After completion, cooking zone will automatically reduce to a
lower power level.
Use Auto heat up function only to heat water.
Never leave the hob unattended when in use.
This may result in fire.
WARNING
04 PARTS AND FEATURES
CTR264KC01_XFA DG68-00446A-02_EN.indd 17 2016-09-02 �� 1:29:04

English - 18English - 18
SAFETY SHUTOFF
If one of the cooking zones is not switched o or the heat setting
is not adjusted after an extended period of time, that particular
cooking zone will automatically switch itself o.
Any residual warmth will be indicated with (for “hot”) in the
digital displays corresponding to the particular cooking zones.
The cooking zones switch themselves o at the following times.
Heat setting Switch o
1-3 After 6 hours
4-6 After 5 hours
7-9 After 3 hours
10-15 After 1 hours
If the Hob is overheated because of abnormal operation,
will be displayed.
And the Hob will be switched o.
Should one or more of the cooking zones switch o
before the indicated time has elapsed, see the section
“Troubleshooting”.
Other reasons why a cooking zone will switch itself o
All cooking zones will immediately switch themselves o if
liquid boils over and lands on the control panel.
The automatic shuto will also be activated if you place a
damp cloth on the control panel. In both of these instances,
the appliance will need to be switched on again using the
main On/O control sensor after the liquid or the cloth
has been removed.
CTR264KC01_XFA DG68-00446A-02_EN.indd 18 2016-09-02 �� 1:29:04

English - 19English - 19
RESIDUAL HEAT INDICATOR
When an individual cooking zone or the hob is turned o, the
presence of residual heat is shown with an (for “hot”) in the
digital display of the appropriate cooking zones. Even after the
cooking zone has been switched o, the residual heat indicator
goes out only after the cooking zone has cooled.
You can use the residual heat for thawing or keeping food warm.
As long as the residual heat indicator is illuminated, there is a
risk of burns.
If the power supply is interrupted, the symbol will go out
and information about residual heat will no longer be available.
However, it may still be possible to burn yourself. This can be
avoided by always taking care when near the hob
TEMPERATURE DETECTION
If for any reason the temperatures on any of the cooking zones
were to exceed the safety levels, should this happen then the
cooking zone will automatically reduce to a lower power level.
before you begin
INITIAL CLEANING
Wipe the ceramic glass surface with a damp cloth and ceramic
cooktop glass cleaner.
Do not use caustic or abrasive cleaners. The surface could be
damaged.
05 BEFORE YOU BEGIN & HOB USE
WARNING
WARNING
WARNING
CTR264KC01_XFA DG68-00446A-02_EN.indd 19 2016-09-02 �� 1:29:04

English - 20English - 20
hob use
USING SUITABLE COOKWARE
Better pans produce better results.
• You can recognise good pans by their bases. The base should
be as thick and flat as possible.
• When buying new pans, pay particular attention to the diameter
of the base. Manufacturers often give only the diameter of the
upper rim.
• Pots with aluminium or copper bases can cause metallic
discolouration on the ceramic glass surface. The discolouration
is very difficult or impossible to remove.
• Do not use pans which have damaged bases with rough edges
or burrs. Permanent scratching can occur if these pan are slid
across the surface.
• When cold, pan bases are normally bowed slightly inwards
(concave). They should never be bowed outwards (convex).
• If you wish to use a special type of pan, for example, a pressure
cooker, a simmering pan, or a wok, please observe the
manufacturer’s instructions.
CTR264KC01_XFA DG68-00446A-02_EN.indd 20 2016-09-02 �� 1:29:04
