Slim Direct-Lit LED LCD TVs Put Hotels in the Best
Light Possible
The Samsung 677 Series is designed to deliver the entertainment
today’s guests demand. Available in 28", 32", 40" and 46" sizes, they
feature direct-lit LED technology, so you can deliver a heightened
viewing experience that guests are sure to appreciate. Your guests
get stunning Samsung picture quality, while you enjoy a cost of entry
similar to that of a CCFL back-lit option. LED also uses up to 50%
less energy, helping you conserve and save money. The Samsung
REACH 2.0 management solution makes content management
simple. Samsung’s LYNK DRM technology protects content, while
offering guests a seamless viewing experience. Business. Innovated.
Slim Direct-Lit LED Technology
Direct-lit LED technology provides the brilliance and energy savings
advantages of LED technology, along with the uniform brightness typical
of CCFL displays. And it does it all with an efficiency that makes it a
more affordable technology. In fact, it’s possible to upgrade your rooms
to LED technology for a cost comparable to CCFL technology.
Samsung LYNK™ REACH 2.0 Content
Management Solution
The Samsung REACH 2.0 (Remote Enhanced Active Control for Hotels)
Management Solution is used in conjunction with an existing coaxial-
based infrastructure. It provides centralized TV controls, basic static
content management capabilities and an Interactive Program Guide
(IPG). Property management will be able to easily update and change
information using a Windows-based system.
Samsung LYNK HD Content Decryption
Samsung’s software-based DRM technology is integrated into the entire
Samsung 2013 Hotel TV line. Samsung LYNK offers a robust solution to
unlock premium HDTV content from content providers such as cable,
satellite and VOD providers, with maximum efficiency and security.
Pro:Idiom™ DRM
The 677 Series is equipped with Pro:Idiom™MPEG4 technology, making
the TVs compatible with most major VOD/PPV systems. You can offer
your guests premium HDTV content from cable, satellite or video-on-
demand services with no optional cards or external box needed.
A Host of Features
Features include: Volume Limiters, Front Panel Lock-out, Menu Display
Lock-out, Hotel Custom Logo/Welcome Message, Channel List Guide,
Channel Re-mapping, Remote Jack Pack (RJP) Priority, USB Cloning
and Anti-Theft Battery Cover Remote Control. Display pedestal stand
rotates 90º in both directions with optional 20, 60 and 90 degree stops—
only on 32", 40" and 46" models integrated in lockdown mount base.
Every guest deserves a premium
in-room entertainment experience.
Samsung 677 Series Hospitality TVs 28" Class LED
32" Class LED
40" Class LED
46" Class LED
HG28NB677BFXZA
HG32NB677BFXZA
HG40NB677FFXZA
HG46NB677FFXZA
Follow us: @SamsungBizUSA
|
youtube.com/samsungbizusa
Learn more }Hospitality TV Sales 1-888-727-2664
|
1-866-SAM4BIZ
samsung.com/hospitality or samsung.com/business

Samsung Hospitality TVs are loaded with features that provide
premier guest satisfaction, while making your job easier.
Samsung 677 Series Hospitality TVs
HOSPITALITY FEATURES
Anti-Theft Battery Cover
Battery door is secured, ensuring batteries remain in the remote controller.
Channel Remapping
Allows the hotelier to change channel and TV source to a different channel.
Clock On Timer and Alarm Key
Allows the guest to program the TV to turn on as a wake-up alarm.
Closed Captioning
A text display of all audio content, including spoken dialog and non-speech information
such as the identity of the speakers and symbols for sound effects and music.
Hotel Channel List
Guest master channel listing of program content. This will display content in analog or HD.
Hotel Logo Display with Time Out Setting
Display hotel logo bitmap files as a greeting startup display.
Hotel Mode Plug & Play
Interactive stand-alone mode available.
Lockout Controls
The hotelier can enable front panel and menu display lock-outs.
OSD Language
Choose English/French/Spanish.
Picture-in-Picture
Display one program while another is being displayed on the full TV screen at the
same time.
Power On Status Setting
Settings include power always on, last option or standby.
Multi-Code Remote
Eliminates interference when two or more TVs are used in close proximity to each other.
Samsung LYNK
™
REACH 2.0 Content Management Solution
The Samsung LYNK
™
REACH 2.0 (Remote Enhanced Active Control for Hotels)
Management Solution is used in conjunction with an existing coaxial-based infrastructure.
It provides centralized TV controls, basic static content management capabilities and an
Interactive Program Guide (IPG). Samung REACH delivers, in a free-to-guest solution,
content and information on such topics as your hotel, local and in-room dining, spa
and exercise facilities, meetings and events, local attractions, and other simple guest
convenience features. Property managers will be able to easily update and change
information using a Windows
®
-based system.
Sleep Timer
Allows guest to set TV turn-off time in 30-minute intervals up to 180 minutes.
USB Cloning
A quick and easy way to copy the ideal settings off one television to others on the property.
Saves time and helps provide a consistent viewing experience for all televisions.
CONNECTIONS
Anynet + (HDMI – CEC)
This Samsung protocol allows the user to control other HDMI devices connected to the TV
display, such as DVD players, PC computers and Soundbars.
ConnectShare
™
(USB 2.0)
Connect a thumb drive or digital camera quickly and easily. User-friendly interface allows
access to videos, a music playlist and pictures via the remote.
Hotel TV (RJ-12/IR Pass Through)
Allows you to connect an interactive STB/SBB (Set Top Box/Set Back Box).
Hotel TV RJ45
Connection to hotel LAN using custom H-browser or Samsung LYNK SINC.
Interactive Compatibility System
Allin, Enseo
®
, Guest-Tek, iBAHN
®
, InnVue, KoolConnect, LodgeNet
®
, nStreams, NxSystems
™
,
Pro:Idiom
™
, RoomLinx
®
, SeaChange
®
, SuiteLinq
™
, Swisscom, Tangerine
®
, uievolution
®
, VRN
Remote Jack Panel (RJP) Compatibility
G-Link
™
, TeleAdapt
PICTURE QUALITY AND AUDIO
Auto Volume Limiter
During initial product setup, minimum and maximum volume levels can be locked to help
minimize disturbance to other hotel guests.
Full HD 1080p, 720p, MPEG4
Samsung 40" and 46" 677 Series TVs feature Full HD, while the 28" and 32" models
feature HD 720p. All TVs also are compatible with MPEG4.
Music Mode (Input: HDMI/PC/AV/Component)
Allows audio feedback when picture is muted.
Music Mode Backlight On/Off
Shows a background display.
Slim Direct-Lit LED Technology
Direct-lit LED technology provides the brilliance and energy savings advantages of LED
technology, along with the uniform brightness typical of CCFL displays. And it does it
all with an efficiency that makes it a more affordable technology. In fact, it’s possible
to upgrade your rooms to LED technology for a cost comparable to CCFL technology.
When you add the energy savings of up to 50% that LED offers over CCFL, you end up
with the perfect solution for both you and your guests.
Soundbar Compatible
Samsung Hospitality Displays enable Soundbar compatibility by supporting HDMI-CEC.
When you connect the Soundbar to the Samsung Hospitality Display with an HDMI cable,
the TV audio settings and menu lock feature are automatically applied, so you don’t have
to set up the Soundbar separately. You can also prevent guests from changing the settings.
With one single remote, guests can control both the TV and Soundbar simultaneously.
Swivel Stand with Optional Stops
Samsung Hospitality Displays pedestal stand rotates with optional 20-, 60- and
90-degree stops so wherever in the room your guests are they should have an excellent
view of their TV. Swivel stand includes integrated mounting plate and bolt down kit (4
bolts, 2 nuts, 2 washers).
WARRANTY
2-year parts and 2-year labor warranty backed by Samsung Hospitality Hotline
1-866-894-0524. Optional professional installation, accessories and extended
warranty are available.

Samsung 677 Series Hospitality TVs
1
2 3 4
5
6
123456
29.05" 17.15" 32" 19.88" 1.95" 7.55"
32" | HG32NB677BFXZA - 720p | 5000:1 Contrast Ratio
123456
36.56" 21.74" 40" 19.88" 1.95" 8.96"
40" | HG40NB677FFXZA - 1080p | 5000:1 Contrast Ratio
123456
41.70" 24.56" 46" 26.93" 1.95" 8.96"
46" | HG46NB677FFXZA - 1080p | 5000:1 Contrast Ratio
28" | HG28NB677BFXZA - 720p | 3000:1 Contrast Ratio
123456
25.39" 15.15" 28" 17. 5" 1.95" 7.11"
Dimensions
1 2 3 4 5
0 !
6
7
8
9
1. HDMI In 2 (DVI)
2. USB
3. HDMI In 1
4. AV In
5. Ant In/Cable
6. DVI In Audio
7. EX-Link (RS232)
8. Audio Out
9. Digital Audio Out
10. HDMI In 3 (ARC)
11. RJ-12 Data
Connectivity
DIGITAL RIGHTS MANAGEMENT (DRM)
Pro:Idiom
™
DRM
The 677 Series is equipped with Pro:Idiom
™
MPEG4 technology, making the TVs
compatible with most major VOD/PPV systems. You can offer your guests premium
HDTV content from cable, satellite or video-on-demand services with no optional cards or
external box needed.
Samsung LYNK
™
HD Content Decryption DRM
Samsung’s software-based DRM technology is integrated into the entire Samsung
2013 Hotel TV line. Samsung LYNK
™
offers a robust solution to unlock premium HDTV
content from content providers such as cable, satellite and VOD providers, with maximum
efficiency and security.

Samsung Electronics has been named 2012 ENERGY STAR Partner of the Year in the product manufacturing category by the U.S. Environmental Protection Agency (EPA).
Sales Support: 1-888-727-2664
1-866-SAM4BIZ
©2013 Samsung Electronics America, Inc. Samsung is a registered mark of Samsung Electronics Corp., Ltd. Specifications and designs are subject
to change without notice. Non-metric weights and measurements are approximate. All other brand, product, service names and logos are trademarks
and/or registered trademarks of their respective manufacturers and companies. Simulated screen images. See samsung.com for detailed information.
Printed in USA. HOS-677SERIESB2BDSHT-MAY13T
For complete product information and accessories, visit samsung.com/hospitality or samsung.com/business
SAMSUNG 677 SERIES HOSPITALITY TVsKEY SPECIFICATIONS For complete product specifications, visit samsung.com/hospitality
Model Number HG28NB677BFXZA HG32NB677BFXZA HG40NB677FFXZA HG46NB677FFXZA
Display Backlight Direct-Lit LED Direct-Lit LED Direct-Lit LED Direct-Lit LED
Screen Size (Diagonal) 28" 32" 40" 46"
HD (720P) / FHD (1080P) HD (1366 x 768) HD (1366 x 768) FHD (1920 x 1080) FHD (1920 x 1080)
Connectivity Picture Engine HyperReal Engine HyperReal Engine HyperReal Engine HyperReal Engine
Static Contrast Ratio 3000:1 5000:1 5000:1 5000:1
Response Time 6.5ms 6.0ms 8.0ms 8.0ms
Viewing Angle (H/V) 178º/ 178º178º/ 178º178º/ 178º178º/ 178º
Brightness 300 nits 300 nits 350 nits 300 nits
Wide Color Enhancer Plus Yes Yes Yes Yes
Audio Dolby®Dolby®Digital Plus / Dolby®Pulse Dolby®Digital Plus / Dolby®Pulse Dolby®Digital Plus / Dolby®Pulse Dolby®Digital Plus / Dolby®Pulse
SRS / DNSe+ SRS TheaterSound™SRS TheaterSound™SRS TheaterSound™SRS TheaterSound™
DTS 2.0 + Digital Out™Yes Yes Yes Yes
Speaker Type Down Firing + Full Range Down Firing + Full Range Down Firing + Full Range Down Firing + Full Range
Sound Output (RMS) 5W x 2 10W x 2 10W x 2 10W x 2
Features ConnectShare™(USB 2.0) Movie Movie Movie Movie
OSD Language English, Spanish, French English, Spanish, French English, Spanish, French English, Spanish, French
Digital Noise Filter Yes Yes Yes Yes
HDMI 1.4 A / Return Ch. Support Yes Yes Yes Yes
Anynet+ (HDMI-CEC) Yes Yes Yes Yes
Auto Channel Search Yes Yes Yes Yes
Auto Power Off Yes Yes Yes Yes
Auto Volume Leveler Yes Yes Yes Yes
Caption (Subtitle) Yes Yes Yes Yes
Wake-up Timer Yes Yes Yes Yes
Game Mode Yes Yes Yes Yes
Picture-In-Picture Yes Yes Yes Yes
Sleep Timer Yes Yes Yes Yes
Hospitality
Features
Samsung LYNK™ DRM Yes Yes Yes Yes
Pro:Idiom™ DRM Yes Yes Yes Yes
Hospitality Plug & Play (Easy Set-up) Yes Yes Yes Yes
Music Mode (Input: PC/AV/Component) Yes (AV only) Yes (AV only) Yes (AV only) Yes (AV only)
Music Mode BackLight On/Off Yes Yes Yes Yes
RJ 12 / IR Pass Through Yes Yes Yes Yes
Power on Status Setting Yes Yes Yes Yes
Jack Pack Compatiblity (HD Media Hub) Yes Yes Yes Yes
USB Cloning Yes Yes Yes Yes
Hotel Channel List Yes Yes Yes Yes
Hotel Logo Display with Time Out Setting (BMP) Yes Yes Yes Yes
Hotel Logo Display (Movie file) Yes Yes Yes Yes
Welcome Message Yes Yes Yes Yes
Auto Source Mode Yes Yes Yes Yes
Energy Saving Mode (BLU control) Yes Yes Yes Yes
Multi Code Remote Control Yes Yes Yes Yes
Screwed Remote Battery Cover Yes Yes Yes Yes
Alarm Key Yes Yes Yes Yes
Smoovie Compatibility Yes Yes Yes Yes
Samsung LYNK™ REACH Server Compatibility Yes Yes Yes Yes
Sound bar compatibility Yes Yes Yes Yes
Input & Output HDMI (Side/Rear) 2/1 2/1 2/1 2/1
USB (Side/Rear) 1/0 1/0 1/0 1/0
Composite In (AV) (Side/Rear) 1/0 1/0 1/0 1/0
Digital Audio Out (Optical) (Side/Rear) 0/1 0/1 0/1 0/1
Audio Out (Mini Jack) (Side/Rear) 0/1 0/1 0/1 0/1
DVI Audio In (Mini Jack) (Side/Rear) 0/1 0/1 0/1 0/1
RF In (Terrestrial/Cable input) (Side/Rear) 0/1 1/0 1/0 1/0
RS232C (AV CONTROL) (Side/Rear) 1 (Common Use for RJP) 1 (Common Use for RJP) 1 (Common Use for RJP) 1 (Common Use for RJP)
RJ12 Yes Yes Yes Yes
RJP (For Remote Jackpack) Yes Yes Yes Yes
System DTV Tuner ATSC / Clear QAM ATSC / Clear QAM ATSC / Clear QAM ATSC / Clear QAM
Analog Tuner Yes Yes Yes Yes
Design Front Color Black Black Black Deco Black Deco
Stand Type Square Square Square Square
Swivel (Left/Right) No 20º/ 60º/ 90º20º/ 60º/ 90º20º/ 60º/ 90º
Dimensions
(W x H x D)
Set Size with Stand (mm) / ( Inches) 645.0 x 444.5 x 180.7 / 25.39" x 17.5" x 1.95" 737.9 x 504.9 x 191.7 /29.05" x 19.88" x 7.55" 928.2 x 610.1 x 227.7 / 36.56" x 19.88" x 8.96" 1059.6 x 684.0 x 227.7 / 41.7" x 26.93" x 8.96"
Set Size without Stand (mm) / (Inches) 645.0 x 384.9 x 49.5 / 25.39" x 15.15" x 1.95" 737.9 x 435.8 x 49.5 /29.05" x 17.15" x 1.95" 928.2 x 552.3 x 49.4 / 36.56" x 21.74" x 1.95" 1059.6 x 626.2 x 49.4 / 41.71" x 24.56" x 1.95"
Carton Dimensions (H x W x L) (mm) / (Inches) 931.0 x 143.0 x 462.0 / 36.7” x 5.6" x 18.2" 919.0 x 143.0 x 514.0 / 36.2" x 5.6" x 20.2" 1125.0 x 152.0 x 616.0 / 44.3" x 6.0" x 24.3" 1277.0 x 716.0 x 158.0 / 50.3" x 28.2" x 6.2"
Weight Set Weight with Stand (kg / lbs) 4.9 / 10.8 6.7 / 14.77 10.9 / 24 13.7 / 30.2
Set Weight without Stand (kg / lbs) 4.2 / 9.25 5.2 / 11.46 8 / 17.6 10.8 / 23.08
Packaging Weight GrossWeight (kg / lbs) 6.2 / 13.7 8.6 / 19 13.1 / 28.9 17.4 / 36.4
VESA Mounting Dimensions (mm) 100 x 100 200 x 200 200 x 200 400 x 400
Screw Size M4 M8 M8 M8
Power Power Supply AC110-120V 50/60Hz AC110-120V 50/60Hz AC110-120V 50/60Hz AC110-120V 50/60Hz
Multi Voltage AC110-220V AC110-220V AC110-220V AC110-220V
Power Consumption (Rated) (Watts) 50W 66W 116W 120W
Power Consumption (Standby) (Watts) under 0.3W under 0.3W under 0.3W under 0.3W
Power Consumption (Typical) (Watts) 26W 34W 46W 45W
UPC 8806085686199 8806085688605 8806085680579 8806085686229
Eco Eco Mark Energy Star v6.0 Energy Star v6.0 Energy Star v6.0 Energy Star v6.0
Eco Sensor No No Yes Yes
Accessory Remote Controller Model TM1240 TM1240 TM1240 TM1240
Battery (for Remote Control) Yes Yes Yes Yes
Vesa Wall Mount Support Yes Yes Yes Yes
AC Power Cable Yes Yes Yes Yes
Quick Install Guide Yes Yes Yes Yes
Data Cable Yes Yes Yes Yes
Security Screws Yes Yes Yes Yes
Stand Mount Kit Yes Yes Yes Yes
Follow us: @SamsungBizUSA
|
youtube.com/samsungbizusa
