Samsung LN-T2353H User manual

Owner’s
Instructions
Register your product at www.samsung.com/global/register
Record your Model and Serial number here for future reference.
· Model __________ · Serial No. ____________
LN-T2353H
LN-T2354H
LN-T2653H
LN-T3253H
LN-T4053H
TFT-LCD TELEVISION

Precautions When Displaying a Still Image
A still image may cause permanent damage to the TV screen
• Do not display a still image on the LCD panel for more than 2 hours as it can cause screen image retention.
This image retention is also known as "screen burn".
To avoid such image retention, reduce the degree of brightness and contrast of the screen when displaying a still image.
• Watching the LCD TV in 4:3 format for a long period of time may leave traces of borders displayed on the
left, right and center of the screen caused by the difference of light emission on the screen.
Playing a DVD or a game console may cause a similar effect to the screen.
Damages caused by the above effect are not covered by the Warranty.
• Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images.
To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.
© 2007 Samsung Electronics Co., Ltd. All rights reserved.
Precauciones al mostrar en la pantalla una imagen fija
La imagen fija puede causar daños permanentes en la pantalla del televisor.
• No deje una imagen fija en la pantalla LCD durante más de dos horas ya que se podría producir una retención de la imagen en
la pantalla. Este fenómeno de retención de imágenes también se denomina “quemadura de pantalla”.
Para evitar que se produzca esa persistencia de la imagen, reduzca el nivel de luminosidad y de contraste de la pantalla
cuando muestre imágenes fijas.
• El uso del televisor LCD en formato 4:3 durante un tiempo prolongado puede dejar rastros de bordes en las
partes izquierda, derecha y central de la pantalla debido a las diferencias en la emisión lumínica de la pantalla.
La reproducción de un DVD o el uso de una consola de videojuegos pueden provocar un efecto similar en la
pantalla. Reproducir un DVD o una videoconsola puede causar un efecto similar en la pantalla. La garantía no
cubre estos daños.
• Ver imágenes fijas de videojuegos y PC durante más tiempo del indicado puede producir restos de imágenes parciales.
Para evitar este efecto, reduzca el ‘brillo’ y el ‘contraste’ cuando vea imágenes fijas.

Contents
Symbol Press Important Note One-Touch
Button
English
GENERAL INFORMATION
List of Features ......................................................................... 2
Accessories .............................................................................. 2
Viewing the Control Panel ....................................................... 3
Viewing the Connection Panel (depending on the model)........ 4
Remote Control (LN-T2353H, LN-T2354H , LN-T2653H) ........ 5
Remote Control (LN-T3253H, LN-T4053H).............................. 6
Installing Batteries in the Remote Control ................................ 7
CONNECTIONS
Connecting VHF and UHF Antennas........................................ 7
Connecting Cable TV................................................................ 8
Connecting a VCR.................................................................... 9
Connecting a DVD Player/Set-Top Box .................................. 10
Connecting a Camcorder ....................................................... 10
Connecting a DVD Player/Set-Top Box via HDMI .................. 11
Connecting a DVD Player/Set-Top Box via DVI...................... 11
Connecting a Digital Audio System......................................... 12
&RQQHFWLQJDQ$PSOL¿HU'9'+RPH7KHDWHU ......................... 12
Connecting a PC..................................................................... 12
OPERATION
Turning the TV On and Off...................................................... 13
Plug & Play Feature................................................................ 13
Changing Channels ................................................................ 14
Adjusting the Volume .............................................................. 15
Viewing the Display ................................................................ 15
Viewing the Menus ................................................................. 16
Memorizing the Channels ....................................................... 16
Setting Up Your Remote Control (depending on the model)... 18
Remote Control Codes ........................................................... 20
To Select the Source (depending on the model)..................... 23
To Edit the Input Source Name (depending on the model)..... 23
PICTURE CONTROL
Using Automatic Picture Settings............................................ 24
Adjusting the Color Tone......................................................... 25
Activating Backlight................................................................. 25
Adjusting the Detailed Settings............................................... 26
Changing the Screen Size...................................................... 29
Setting the Active Color .......................................................... 30
DNIe (Digital Natural Image engine)....................................... 30
Freezing the Picture (depending on the model)...................... 31
HDMI Black Level ................................................................... 31
Setting the Film Mode............................................................. 31
Viewing Picture-in-Picture....................................................... 32
SOUND CONTROL
Customizing the Sound........................................................... 34
Using Automatic Sound Settings ............................................ 34
Setting the TruSurround XT .................................................... 35
Choosing a Multi-Channel Sound (MTS) track - Digital ......... 35
Choosing a Multi-Channel Sound (MTS) track - Analog ........ 36
Automatic Volume Control ...................................................... 36
Selecting the Internal Mute..................................................... 37
Setting the On/Off Melody ...................................................... 37
Listening to the Sound of the Sub (PIP) Picture ..................... 38
Resetting the Sound Settings to the Factory Defaults............ 38
Connecting Headphones ........................................................ 38
Selecting the Antenna............................................................. 39
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
CHANNEL CONTROL
Clearing Scrambled Channels - Digital................................... 39
Setting the Channel Lists........................................................ 40
To set-up Your Favorite Channels........................................... 41
Using the Channel Lists.......................................................... 42
Viewing the Channel Lists ...................................................... 42
Labeling Channels .................................................................. 43
/1$/RZ1RLVH$PSOL¿HU ...................................................... 43
Fine Tuning Analog Channels................................................. 44
Checking the Digital-Signal Strength...................................... 44
PC DISPLAY
Using Your TV as a Computer (PC) Display ........................... 45
Display Modes ........................................................................ 45
Setting up the TV with your PC............................................... 46
Setting the Home Theater PC................................................. 47
TIME SETTING
Setting the Clock..................................................................... 48
FUNCTION DESCRIPTION
Selecting a Menu Language................................................... 52
Setting the Blue Screen Mode................................................ 52
Using the Game Mode............................................................ 53
Viewing Closed Captions (On-Screen Text Messages) -
Analog..................................................................................... 54
Viewing Closed Captions (On-Screen Text Messages) -
Digital...................................................................................... 55
Menu Transparency Level ...................................................... 56
Using the Energy Saving Feature........................................... 56
Setting the Function Help ....................................................... 57
Setting the Light Effect............................................................ 57
Digital Noise Reduction .......................................................... 58
Using the V-Chip..................................................................... 59
Upgrading the Software (depending on the model)................ 66
WISELINK
Using the WISELINK Function (LN-T3253H, LN-T4053H)..... 67
Using the WISELINK Menu .................................................... 68
Using the PHOTO (JPEG) List ............................................... 69
Using the MP3 List.................................................................. 76
Using the Setup Menu ............................................................ 78
ABOUT ANYNET+
What is Anynet+? (LN-T3253H, LN-T4053H) ........................ 80
Connecting Anynet+ Devices.................................................. 80
Setting Up Anynet+................................................................. 81
Scanning and Switching between Anynet+ Devices............... 81
Recording ............................................................................... 82
Listening through a Receiver (Home theater)......................... 83
Check Points before Requesting Service ............................... 83
APPENDIX
Troubleshooting ...................................................................... 84
Installing the Stand ................................................................. 86
Disconnecting the Stand......................................................... 86
Wall- Mount Adjustment (LN-T4053H) (Sold separately)........ 87
:DOO0RXQW.LW6SHFL¿FDWLRQV9(6$................................... 88
Using the Anti-Theft Kensington Lock..................................... 89
6SHFL¿FDWLRQV.......................................................................... 89
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
Ŷ
English - 1

English - 2
Accessories
Please make sure the following items are included with your LCD TV.
If any items are missing, contact your dealer.
Remote Control & Batteries (AAA x 2)
LN-T2353H, LN-T2653H (BN59-00598A)
LN-T2354H (BN59-00615A)
LN-T3253H, LN-T4053H (BN59-00599A)
Power Cord
(3903-000144)
Cleaning Cloth
(BN63-01798A)
Cover-Bottom
LN-T2353H, LN-T2653H
(BN63-03221B)
LN-T2354H (BN63-03221C)
LN-T3253H (BN63-03103B)
LN-T4053H (BN63-03113B)
Stand
LN-T2353H (BN96-04663A)
LN-T2354H (BN96-04663B)
LN-T2653H (BN96-04663A)
LN-T3253H (BN96-04662A)
Stand Screw
LN-T2353H, LN-T2653H,
LN-T3253H (6002-001294)
LN-T2354H (6003-001324)
Owner’s Instructions
Warranty Card / Registration
Card / Safety Guide Manual
(Not available in all locations)
The items color and shape may vary depending on the model.
General Information
List of Features
Adjustable picture settings that can be stored in the TV’s memory.
Automatic timer to turn the TV on and off.
A special sleep timer.
V-Chip function.
Excellent Digital Interface & Networking :
With a built-in HD digital tuner, non-subscription HD broadcasts can be viewed with no Set-Top Box needed.
Remote Control
The supplied remote can be used to operate the TV as well as most DVD players, Set-top boxes, Cable Boxes and
VCRs.
Excellent Picture Quality
- DNIe technology provides life-like clear images.
SRS TruSurround XT
- SRS TruSurround XT provides a virtual Dolby surround system.

English - 3
Viewing the Control Panel
1 SOURCE
Toggles between all the available input sources
(TV, AV1, AV2, S-Video 1, S-Video 2, Component1,
Component2, PC, HDMI1, HDMI2, HDMI3).
In the on-screen menu, use this button as you would
use the ENTER button on the remote control.
23,26 inch model supports TV, AV1, AV2, S-Video1,
S-Video 2, Component 1,Component 2, PC, HDMI1,
and HDMI2 only.
2 MENU
Press to see an on-screen menu of your TV’s features.
3 + VOL -
Press to increase or decrease the volume.
In the on-screen menu, use the + VOL - buttons as you
 ZRXOGXVHWKHŻDQGŹEXWWRQVRQWKHUHPRWHFRQWURO
4CH
Press to change channels.
In the on-screen menu, use the
CH buttons as
\RXZRXOGXVHWKHŸDQGźEXWRQVRQWKHUHPRWH
control.
5 (POWER)
Press to turn the TV on and off.
POWER INDICATOR
Blinks and turns off when the power is on and lights up
in stand-by mode.
6 REMOTE CONTROL SENSOR
Aim the remote control towards this spot on the TV.
7 SPEAKERS
Buttons on the Lower-Right Part of the Panel
The buttons on the lower-right panel control your TV’s basic features, including the on-screen menu.
To use the more advanced features, you must use the remote control.
The product color and shape may vary depending on the model.
Front Panel buttons
Touch the right side of
each button to operate.
1
2
3
4
5
6
7

English - 4
Viewing the Connection Panel (depending on the model)
Rear Panel Jacks
Use the rear panel jacks to connect A/V components that will be connected continuously, such as VCR or DVD players.
For more information on connecting equipment, see pages 6-12.
1 AUDIO OUT
Connects to the audio input jacks on your Amplifier/
Home theater.
2 DIGITAL AUDIO OUT (OPTICAL)
Connects to a Digital Audio component.
3 PC IN
Connects to the video and audio output jacks on
your PC.
4 HDMI IN 1,2,3 /DVI IN(HDMI1) (AUDIO R/L)
Connects to the HDMI jack of a device with an HDMI
output.
Use the HDMI IN 1 terminal for a DVI connection to an
external device.
You should use the DVI to HDMI cable or DVI-HDMI
adapter (DVI to HDMI) for a video connection, and the
DVI IN ‘R-AUDIO-L’ terminal for audio.
- No sound connection is needed for an HDMI to HDMI
connection
- When using an HDMI/DVI cable connection, you must
use the HDMI IN 1 terminal.
- 23,26 inch model supports HDMI1 and HDMI2 only.
5 ANT 1 IN/ANT 2 IN
Connects to an antenna or cable TV system.
6
EX LINK
Connect this to the jack on the optional wall mount
bracket. This will allow you to adjust the TV viewing angle
using your remote control.
7
COMPONENT IN
Connects Component video/audio.
8 SERVICE (LN-T2353H, LN-T2354H, LN-T2653H)
Connector for SERVICE only
9 AV IN 1 / AV IN 2
Video and audio inputs for external devices, such as a
camcorder or VCR.
S-VIDEO
Connects an S-Video signal from a camcorder or VCR.
0 POWER INPUT
Connects the supplied power cord
! KENSINGTON LOCK
The Kensington lock (optional) is a device used to
physically fix the system when used in a public place.
If you want to use a locking device, contact the dealer
where you purchased the TV.
The place of the Kensington Lock may be different
depending on its model.
@ HEADPHONE
Connects a set of external headphones for private
listening.
# WISELINK (LN-T3253H,LN-T4053H)
Connect a USB mass storage device to view photo
files(JPEG) and play audio files (MP3).
[Side Panel Jacks]

English - 5
Remote Control (LN-T2353H, LN-T2354H, LN-T2653H)
You can use the remote control up to a distance of about 23 feet from the TV. When using the remote, always point it directly at the
TV. You can also use your remote control to operate your VCR, Cable box, DVD player, or Set-Top Box.
1 POWER
Turns the TV on and off.
2 NUMERIC BUTTONS
Press to change the channel.
3 –
Press to select additional channels(digital
and analog) being broadcast by the same
station. For example, to select channel
“54-3”, press “54”, then press “–” and “3”.
4 CH LIST
Used to display Channel Lists on the
screen.
5 ANTENNA
Press to select “AIR” or “CABLE”.
6 VCR/DVD Functions
- Rewind
- Stop
- Play/Pause
- Fast/Forward
7 VOL / VOL
Press to increase or decrease the
volume.
8( MUTE)
Press to temporarily cut off the sound.
9 MENU
Displays the main on-screen menu.
0 S.MODE
Press to select the sound mode.
! RETURN
Returns to the previous menu.
@ P.MODE
Press to select the picture mode.
# SRS
Selects SRS TruSurround XT mode.
$ MTS
Press to choose stereo, mono or
Separate Audio Program
(SAP broadcast).
% SLEEP
Press to select a preset time interval
for automatic shut off.
^ AUTO PROG.
Press to automatically store selected
TV/Cable channels.
& SET
Sets the remote to control your
TV, VCR, Cable, DVD, or Set-Top Box
* TV, DVD, STB, CABLE, VCR
Press to operate your TV,
DVD, STB, CABLE (box), or VCR
(
see pages 18~22.)
( When pressing this button, a number
of buttons on the remote control (e.g.
TV, DVD, STB, CABLE, VCR, VOL and
CH buttons) light up for a few seconds
and then turn off to save power.
This function is convenient for using
the remote at night or when dark.
(LN-T2353H, LN-T2653H)
) SOURCE
Press to display all of the available
video sources.
a PRE-CH
Tunes to the previous channel.
b FAV.CH
Press to switch to your favorite channels.
c
HDMI
Selects the HDMI mode directly.
d
CH / CH
Press to change channels.
e
EXIT
Press to exit the menu.
f 83Ÿ'2:1ź/()7Ż /
 5,*+7Ź / ENTER
Use to select on-screen menu items
and change menu values.
g
INFO
Press to display information on the TV
screen.
h
CAPTION
Controls the caption decoder.
i
STILL
Press to stop the action during a
particular scene.
Press again to resume normal video.
j
P.SIZE
Picture size selection.
k
PIP
Picture-in Picture ON/OFF.
l
CH /
Displays the available channels in
sequence. (These buttons change
channels in the PIP window only.)
m
ADD/DEL
Use to store and delete channels
to/from memory.
n
RESET
When your remote does not work,
change the batteries and press the
RESET button for 2-3 seconds before
use.
This is a special remote control for the visually impaired, and has Braille
points on the Power, Channel, STOP, PLAY/PAUSE and Volume buttons.
The performance of the remote control may be affected by bright light.

English - 6
Remote Control (LN-T3253H, LN-T4053H)
You can use the remote control up to a distance of about 23 feet from the TV. When using the remote, always point it directly at the
TV. You can also use your remote control to operate your VCR, Cable box, DVD player, or Set-Top Box.
1 POWER
Turns the TV on and off.
2 NUMERIC BUTTONS
Press to change the channel.
3 –
Press to select additional channels(digital
and analog) being broadcast by the same
station. For example, to select channel
“54-3”, press “54”, then press “–” and “3”.
4 CH LIST
Used to display Channel Lists on the
screen.
5 ANTENNA
Press to select “AIR” or “CABLE”.
6 VCR/DVD Functions
- Rewind
- Stop
- Play/Pause
- Fast/Forward
7 VOL / VOL
Press to increase or decrease the
volume.
8( MUTE)
Press to temporarily cut off the sound.
9 MENU
Displays the main on-screen menu.
0 S.MODE
Press to select the sound mode.
! RETURN
Returns to the previous menu.
@ P.MODE
Press to select the picture mode.
#
CAPTION
Controls the caption decoder.
$ FAV.CH
Press to switch to your favorite channels.
% SLEEP
Press to select a preset time interval
for automatic shut off.
^ SRS
Selects SRS TruSurround XT mode.
& SET
Sets the remote to control your
TV, VCR, Cable, DVD, or Set-Top Box
* TV, DVD, STB, CABLE, VCR
Press to operate your TV,DVD, STB,
CABLE (box), or VCR
(See pages 18-22)
( When pressing this button, a number
of buttons on the remote control (e.g.
TV, DVD, STB, CABLE, VCR, VOL and
CH buttons) light up for a few seconds
and then turn off to save power.
This function is convenient for using
the remote at night or when dark.
) SOURCE
Press to display all of the available
video sources.
a PRE-CH
Tunes to the previous channel.
b WISELINK
This function enables you to view and
play photo (JPEG) and audio files
(MP3) from an external device.
(Refer to page 68)
c REC
Records for Live Broadcasting.
d
CH / CH
Press to change channels.
e
EXIT
Press to exit the menu.
f 83Ÿ'2:1ź/()7Ż /
 5,*+7Ź / ENTER
Use to select on-screen menu items
and change menu values.
g
INFO
Press to display information on the TV
screen.
h
Anynet+
Runs the Anynet view functions and
sets up Anynet devices.
i
STILL
Press to stop the action during a
particular scene.
Press again to resume normal video.
j
P.SIZE
Picture size selection.
k
PIP
Picture-in Picture ON/OFF.
l
CH /
Displays the available channels in
sequence. (These buttons change
channels in the PIP window only.)
m
MTS
Press to choose stereo, mono or
Separate Audio Program
(SAP broadcast).
n
RESET
When your remote does not work,
change the batteries and press the
RESET button for 2-3 seconds before
use.
This is a special remote control for the visually impaired, and has Braille
points on the Power, Channel, STOP, PLAY/PAUSE and Volume buttons.
The performance of the remote control may be affected by bright light.

English - 7
1. Lift the cover at the back of the remote control upward as shown in the figure.
2. Install two AAA size batteries.
Make sure to match the “+” and “–” ends of the batteries with the diagram inside the compartment.
3. Replace the cover.
Remove the batteries and store them in a cool, dry place if you won’t be using the remote control for a
long time.
The remote control can be used up to about 23 feet from the TV.
(Assuming typical TV usage, the batteries should last for about one year.)
If the remote control doesn’t work, check the following:
1. Is the TV power on?
2. Are the plus and minus ends of the batteries reversed?
3. Are the batteries drained?
4. Is there a power outage, or is the power cord unplugged?
5. Is there a special fluorescent light or neon sign nearby?
Installing Batteries in the Remote Control
Connecting VHF and UHF Antennas
If your antenna has a set of leads that look like the diagram to the right, see “Antennas with 300
)ODW7ZLQ/HDGV´EHORZ
II\RXUDQWHQQDKDVRQHOHDGWKDWORRNVOLNHGLDJUDPWRWKHULJKWVHH³$QWHQQDVZLWK5RXQG
Leads”.
If you have two antennas, see “Separate VHF and UHF Antennas”.
1. 3ODFHWKHZLUHVIURPWKHWZLQOHDGVXQGHUWKHVFUHZVRQDDGDSWHU 
(not supplied).
Use a screwdriver to tighten the screws.
2. Plug the adaptor into the ANT 2 IN (CABLE) terminal on the back of the TV.
ANT 2 IN
(CALBE)
$QWHQQDVZLWK)ODW7ZLQ/HDGV
,I\RXDUHXVLQJDQRIIDLUDQWHQQDVXFKDVDURRIDQWHQQDRU³UDEELWHDUVWKDWKDVWZLQÀDWOHDGVIROORZWKHGLUHFWLRQV
below.
1. Plug the antenna lead into the ANT 1 IN (AIR) terminal on the back of the TV.
$QWHQQDVZLWK5RXQG/HDGV
ANT 1 IN
(AIR)
Separate VHF and UHF Antennas
If you have two separate antennas for your TV (one VHF and one UHF), you must combine the two antenna signals before con-
necting the antennas to the TV. This procedure requires an optional combiner-adaptor (available at most electronics shops).
1. Connect both antenna leads to the combiner.
2. Plug the combiner into the ANT 1 IN (AIR) terminal on the bottom of the rear panel.
UHF
VHF
ANT 1 IN
(AIR)
UHF
VHF
Connections

English - 8
After you have made this connection, set the A/B switch to the “A” position for normal viewing. Set the A/B switch to the “B” position to
view scrambled channels. (When you set the A/B switch to “B”, you will need to tune your TV to the cable box’s output channel, which is
usually channel 3 or 4.)
Connecting to a Cable Box that Descrambles Some Channels
If your cable box descrambles only some channels (such as premium channels), follow the instructions below. You will need a two-
way splitter, an RF (A/B) switch, and four lengths of RF cable. (These items are available at most electronics stores.)
2. Connect this cable to a two-way splitter.
3. Connect an RF cable between the OUTPUT
terminal on the splitter and the IN terminal
on the cable box.
4. Connect an RF cable between the
ANT OUT terminal on the cable box and
the B–IN terminal on the RF(A/B) switch.
1. Find and disconnect the cable that is
connected to the ANT IN terminal on your
cable box.
This terminal might be labeled “ANT IN”,
"VHF IN” or simply, “IN”.
5. Connect another cable between the other
OUT terminal on the splitter and the A–IN
terminal on the RF (A/B) switch.
6. Connect the last RF cable between the
OUT terminal on the RF (A/B) switch and
the ANT IN terminal on the rear of the TV.
Splitter
Incoming
cable
Splitter
Cable Box
Incoming
cable
Splitter
Cable Box
RF (A/B)
Switch
Incoming
cable
ANT IN
Splitter
Cable Box
Incoming
cable
RF (A/B)
Switch
Splitter
Cable Box
Incoming
cable TV Rear
RF (A/B)
Switch
ANT IN
Connecting Cable TV
To connect to a cable TV system, follow the instructions below.
Cable without a Cable Box
1. Plug the incoming cable into the ANT 2 IN (CABLE) terminal on the back of the TV.
Because this TV is cable-ready, you do not need a cable box to view unscrambled cable channels.
Connecting to a Cable Box that Descrambles All Channels
1. Find the cable that is connected to the ANT OUT terminal on your cable box.
This terminal might be labeled “ANT OUT”, “VHF OUT” or simply, “OUT”.
2. Connect the other end of this cable to the ANT 2 IN (CABLE) terminal on the back of the TV.
ANT OUT
ANT IN
ANT 2 IN
(CABLE)
ANT 2 IN
(CABLE)

English - 9
Connecting a VCR
These instructions assume that you have already connected your TV to an antenna or a cable TV system (according to the
instructions on pages 7-8). Skip step 1 if you have not yet connected to an antenna or a cable system.
1. Unplug the cable or antenna
from the back of the TV.
2. Connect the cable or antenna
to the ANT IN terminal on the
back of the VCR.
3. Connect an RF Cable between
the ANT OUT terminal on the
VCR and the ANT 1 IN (AIR) or
ANT 2 IN (CABLE) terminal on
the TV.
4. Connect a Video Cable
between the VIDEO OUT jack
on the VCR and the AV IN 1 (or
AV IN 2) [VIDEO] jack on the
TV.
5. Connect Audio Cables
between the AUDIO OUT
jacks on the VCR and the
AV IN 1 (or AV IN 2) [R-
AUDIO-L] jacks on the TV.
If you have a “mono”
(non-stereo) VCR, use a
Y-connector (not supplied)
to hook up to the right
and left audio input jacks
of the TV. If your VCR
is stereo, you must
connect two cables.
Follow the instructions in “Viewing a VCR or Camcorder Tape” to view your VCR tape.
Each VCR has a different back panel configuration.
When connecting a VCR, match the color of the connection terminal to the cable.
TV Rear Panel
RF Cable (Not supplied)
3
VCR Rear Panel
2Video Cable (Not supplied)
4
Audio Cable (Not supplied)
5
ANT 1 IN
(AIR)
Your Samsung TV can be connected to an S-Video signal from an VCR.
(This connection delivers a better picture as compared to a standard VCR.)
1. To begin, follow steps 1–3
in the previous section to
connect the antenna or
cable to your VCR and
your TV.
2. Connect an S-Video Cable
between the S-VIDEO OUT
jack on the VCR and the
AV IN1 [S-VIDEO] jack on
the TV.
3. Connect Audio Cables
between the AUDIO OUT
jacks on the VCR and the
AV IN1 [R-AUDIO-L] jacks
on the TV.
An S-Video cable may be included with a VCR. (If not, check your local electronics store.)
Each VCR has a different back panel configuration.
When connecting a VCR, match the color of the connection terminal to the cable.
VCR Rear Panel
RF Cable (Not supplied)
1
Audio Cable (Not supplied)
3
TV Rear Panel
S-Video Cable (Not supplied)
2
ANT 2 IN
(CABLE)
S-Video Connection
Video Connection

English - 10
Connecting a DVD Player/Set-Top Box
The rear panel jacks on your TV make it easy to connect a DVD player to your TV.
1. Connect a Component
Cable between the
COMPONENT IN(1 or 2)
[Y, P
B , P R ] jacks on the TV
and the COMPONENT
[Y, P
B , P R ] jacks on the
DVD/Set-top Box.
2. Connect Audio Cables
between the COMPONENT
IN(1 or 2) [R-AUDIO-L]
jacks on the TV and the
AUDIO OUT jacks on the
DVD/Set-top Box
Component video separates the video into Y (Luminance (brightness)), Pb (Blue) and
Pr (Red) for enhanced video quality.
Be sure to match the component video and audio connections.
For example, if connecting the video cable to COMPONENT IN, connect the audio cable
to COMPONENT IN also.
Each DVD Player/STB has a different back panel configuration.
When connecting a DVD player/STB, match the color of the connection terminal to the
cable.
DVD Player/Set-Top Box
TV Rear Panel
Component Cable (Not supplied)
1
Audio Cable (Not supplied)
2
Connecting a Camcorder
The side panel jacks on your TV make it easy to connect a camcorder to your TV.
They allow you to view the camcorder tapes without using a VCR
1. Connect a Video Cable
between the AV IN2
[VIDEO] jack on the
TV and the VIDEO OUT
jack on the camcorder.
2. Connect Audio Cables
between the AV IN2
[R-AUDIO-L] jacks on the
TV and the AUDIO OUT
jacks on the camcorder.
Camcorder
TV Side Panel
Video Cable (Not supplied)
1
Audio Cable (Not supplied)
2
Each Camcorder has a different back panel configuration.
When connecting a Camcorder, match the color of the connection terminal to the cable.

English - 11
Connecting a DVD Player/Set-Top Box via HDMI
This connection can only be made if there is an HDMI Output connector on the external device.
1.
Connect an HDMI Cable
between the HDMI IN
(1,2 or 3) connector on the
TV and the HDMI connector
on the DVD player/Set-Top
Box
DVD Player Rear Panel TV Rear Panel
HDMI Cable (Not supplied)
What is HDMI?
• HDMI(High-Definition Multimedia Interface), is a next-generation an interface that
enables the transmission of digital audio and video signals using a single cable.
• The difference between HDMI and DVI is that the HDMI device is smaller in size,
has the HDCP (High Bandwidth Digital Copy Protection) coding feature installed.
Each DVD player/STB has a different back panel configuration.
32,40 inch model supports HDMI 3 only
Connecting a DVD Player/Set-Top Box via DVI
This connection can only be made if there is a DVI Output connector on the external device.
1. Connect a DVI to HDMI
Cable or DVI-HDMI Adapter
between the HDMI IN 1
connector on the TV and
the DVI connector on the
DVD player/Set-Top Box.
2. Connect Audio Cables
between the DVI IN (HDMI 1)
[R-AUDIO-L] jack on the
TV and the AUDIO OUT jacks
on the DVD player/
Set-Top Box.
Each DVD player/STB has a different back panel configuration.
When connecting a DVD player/STB, match the color of the connection terminal to the cable.
When using an HDMI/DVI cable connection, you must use the HDMI IN 1 terminal.
TV Rear Panel
DVD Player / Set-Top Box
Audio Cable (Not supplied)
2
DVI to HDMI Cable (Not supplied)
1
or
TV Side Panel

&RQQHFWLQJDQ$PSOL¿HU'9'+RPH7KHDWHU
1. Connect Audio Cables
between the AUDIO OUT
[R-AUDIO-L] on the TV
and AUDIO IN [R-AUDIO-
L] on the Amplifier/DVD
Home Theater.
When an audio amplifier is
connected to the “AUDIO
OUT [L-AUDIO-R]”
terminals: Decrease the
volume of the TV, and adjust
the volume level with the
Amplifier’s volume control.
$PSOL¿HU'9'+RPH7KHDWHU
TV Rear Panel
Audio Cable (Not supplied)
Each Amplifier/DVD Home Theater has a different back panel configuration.
When connecting an Amplifier/DVD Home Theater, match the color of the connection
terminal to the cable.
English - 12
Connecting a Digital Audio System
1. Connect an Optical Cable
between the “DIGITAL
AUDIO OUT (OPTICAL)”
jacks on the TV and the
Digital Audio Input jacks on
the Digital Audio System.
When a Digital Audio
System is connected to the
“DIGITAL AUDIO OUT
(OPTICAL)” terminal:
Decrease the volume
of the TV, and adjust the
volume level with the
system’s volume control.
Digital Audio System
TV Rear Panel
Optical Cable (Not supplied)
5.1CH audio is possible when the TV is connected to an external device supporting 5.1CH.
Each Digital Audio System has a different back panel configuration. .
The rear panel jacks on your TV make it easy to connect a Digital Audio System to your TV.
Connecting a PC
1. Connect a D-Sub
Cable between PC IN
[PC] connector on
the TV and the PC
output connector on
your computer.
2. Connect a PC Audio
Cable between PC IN
[AUDIO] jack on the
TV and the Audio Out
jack of the sound card
on your computer.
Each PC has a different back panel configuration.
When connecting a PC, match the color of the connection terminal to the cable.
When using an HDMI/DVI cable connection, you must use the HDMI IN 1 terminal.
PC
TV Rear Panel
D-Sub Cable (Not supplied)
1
PC Audio Cable (Not supplied)
2

English - 13
Plug & Play Feature
When the TV is initially powered on, basic settings proceed automatically and subsequently:
1. Press the POWER button on the remote control.
The message “Menu language, Shop Mode, Channels and Time will be set.” is
displayed.
Press the ENTER button, then “Select the language of the OSD” menu is
automatically displayed.
2. 3UHVVWKHŸRUźEXWWRQVWRVHOHFWODQJXDJHWKHQSUHVVWKHENTER button.
The message “Select Home Mode when installing this TV at home.” is displayed.
3. 3UHVVWKHŻRUŹEXWWRQVWRVHOHFW³6KRS´RU³+RPH´WKHQSUHVVWKH
ENTER button.
The message “Select the antennas to memorize.” is displayed.
We recommend setting the TV to Home mode for the best picture in your
home environment.
Shop mode is only intended for use in retail environments.
If the unit is accidentally set to Shop mode and you want to return to Dynamic
(Home) mode, press any Volume button and then hold down the MENU button
for five seconds on the side panel of the TV.
4. 3UHVVWKHŸRUźEXWWRQVWRPHPRUL]HWKHFKDQQHOVRIWKHVHOHFWHGFRQQHFWLRQ
Press the ENTER button to select “Start”.
If the antenna is connected to ANT 1(AIR), select “Air” and if it is connected to
ANT 2 (CABLE), select “Cable”.
If both ANT 1 (AIR) and ANT 2 (CABLE) are connected, select the “Air + Cable”.
In Cable mode, you can select the correct signal source among STD, HRC,
   DQG,5&E\SUHVVLQJWKHŸRUźEXWWRQWKHQSUHVVWKHENTER button.
Contact your local cable company to identify the type of cable system that
exists in your particular area.
5. The TV will begin memorizing all of the available channels.
After all the available channels are stored, the Auto program menu reappears.
Press the ENTER button when channel memorization is complete.
The message “Select the clock mode.” is displayed.
To stop the search before it has finished, press the ENTER button with stop
selected.
6. Press the ENTER button.
  3UHVVWKHŸRUźEXWWRQVWRVHOHFW³0DQXDO´RU³$XWR´WKHQ3UHVVWKH
ENTER button.
The message “Set to daylight savings time.” is displayed.
Turning the TV On and Off
Press the POWER button on the remote control.
You can also use the button on the front of the panel.
Operation
Select Home Mode when installing this TV at home.
Plug & Play
Clock Set
Menu Language
Plug & Play
English
Español
Français
Move Enter Skip
Shop
Menu language, Shop Mode,
Channels and Time will be set.
Start
Select the language of the OSD.
Home
Move Enter Skip
Select the antennas to memorize.
Start
Air
Plug & Play
Cable
Air+Cable
Start
Start
Move Enter Skip
Clock Mode :
Move Enter Skip
Select the clock mode.
Plug & Play
Manual
Auto
Plug & Play
35%
Stop
Enter Skip
Auto Program in progress.
Air Channel 50
Plug & Play
Enter Skip
Auto Program is completed.
16 Channels were memorized.
Air : 16, Cable : 0.
OK

English - 14
7. 3UHVVWKHŸRUźEXWWRQVWRVHOHFW³2Q´RU³2II´WKHQ3UHVVWKHENTER button.
The message “Select the time zone in which you live.” is displayed.
8. 3UHVVWKHŸRUźEXWWRQVWRKLJKOLJKWWKHWLPH]RQHIRU\RXUORFDODUHD
Press the ENTER button. If you have received a digital signal, the time will be set
automatically.
If not, see page 49 to set the clock.
9. The message “Enjoy your watching.” is displayed.
When you have finished, press the ENTER button.
Changing Channels
1. Press the CH or CH button to change channels.
When you press the CH or CH button, the TV changes channels in
sequence.
You will see all the channels that the TV has memorized. (The TV must have
memorized at least three channels). You will not see channels that were either
erased or not memorized. See page 17 to memorize channels.
If you want to reset this feature...
1. Press the MENU button to display the menu.
  3UHVVWKHŸRUźEXWWRQVWRVHOHFW³6HWXS´WKHQSUHVVWKHENTER button.
2. Press the ENTER button again, to select “Plug & Play”.
3. The message “Menu language, Shop Mode, Channels and Time will be set."
is displayed.
Using the Channel Buttons
1. Press the PRE-CH button.
The TV will switch to the last channel viewed.
To quickly switch between two channels that are far apart, tune to one
channel, then use the number button to select the second channel. Then
use the PRE-CH button to quickly alternate between them.
Using the PRE-CH Button to select the Previous Channel
Daylight Savings Time :
Move Enter Skip
Set to daylight savings time.
Plug & Play
On
Off
Move Enter Skip
Select the time zone in which you live.
Plug & Play
Newfoundland
Atlantic
Eastern
Central
Mountain
Pacific
Alaska
Hawaii
Enjoy your watching.
OK
Setup
Plug & Play Ź
Language : English Ź
Time Ź
Game Mode : Off Ź
V-Chip Ź
Caption Ź
Menu Transparency : High Ź
źMore
TV
Move Enter Return
Menu language, Shop Mode,
Channels and Time will be set.
Start

English - 15
Adjusting the Volume
1. Press the VOL
or VOL
buttons to decrease or increase the volume.
Using Mute
At any time, you can cut off the sound using the MUTE button.
1. Press MUTE button and the sound cuts off.
The word “ “ will appear in the lower-left corner of the screen.
2. To turn mute off, press the MUTE button again, or simply press the
VOL
or VOL
buttons.
Viewing the Display
1. Press the INFO button on the remote control.
The TV will display the channel, the type of sound,
and the status of certain picture and sound settings.
Press the INFO button once more or wait approximately 10 seconds and the
display disappears automatically.
7KHGLVSOD\LGHQWL¿HVWKHFXUUHQWFKDQQHODQGWKHVWDWXVRIFHUWDLQDXGLRYLGHRVHWWLQJV
Air 7
Mono
Picture Mode : Dynamic
Sound Mode : Custom
MTS : Stereo
05 : 54 pm

English - 16
Viewing the Menus
1. With the power on, press the MENU button.
The main menu appears on the screen. The menu’ s left side has five icons:
Picture, Sound, Channel, Setup, Input.
2. 8VHWKHŸRUźEXWWRQVWRVHOHFWRQHRIWKHILYHLFRQV
Then press the ENTER button to access the icon’s sub-menu.
3. Press the EXIT button to exit.
The on-screen menus disappear from the screen after about one minute.
Input
Source List : TV Ź
Edit Name Ź
WISELINK
Anynet+ (HDMI-CEC)
TV
Move Enter Exit
Memorizing the Channels
Your TV can memorize and store all of the available channels for both “off-air” (Air) and “Cable” channels. After the available
channels are memorized, use the CH or CH buttons to scan through the channels. This eliminates the need to change
channels by entering the channels digits. There are three steps for memorizing channels: selecting a broadcast source, memoriz-
ing the channels (automatic) and adding or deleting channels (Channel Lists).
Selecting the Video Signal-source
Before your television can begin memorizing the available channels, you must specify the type of signal source that is connected to
the TV (i.e. an Air or a Cable system).
1. Press the MENU button to display the menu.
  3UHVVWKHŸRUźEXWWRQVWRVHOHFW³&KDQQHO´WKHQSUHVVWKH
ENTER button.
2. Press the ENTER button select “Antenna”.
  3UHVVWKHŸRUźEXWWRQVWRVHOHFW³$LU´RU³&DEOH´WKHQSUHVVWKHENTER button.
Press the EXIT button to exit.
Antenna : Air Ź
Auto Program Ź
Clear Scrambled Channel Ź
Channel List Ź
Name Ź
Fine Tune Ź
Signal Strength Ź
LNA : On Ź
Channel
Move Enter Return
TV
Channel
Move Enter Return
TV
Antenna : Air
Auto Program
Clear Scrambled Channel
Channel List
Name
Fine Tune
Signal Strength
LNA : On
Air
Cable

English - 17
Storing Channels in Memory (Automatic Method)
1. Press the MENU button to display the menu.
  3UHVVWKHŸRUźEXWWRQVWRVHOHFW³&KDQQHO´WKHQSUHVVWKHENTER button.
2. 3UHVVWKHŸRUźEXWWRQVWRVHOHFW³$XWR3URJUDP´WKHQSUHVVWKHENTER button.
3. 3UHVVWKHŸRUźEXWWRQVWRVHOHFWWKHDQWHQQDFRQQHFWLRQWKHQSUHVVWKH
ENTER button.
Air: “Air” antenna signal. / Cable: “Cable” antenna signal. /
Air+Cable: “Air” and “Cable” antenna signals.
4. When selecting the Cable TV system: Press the ENTER button to start the auto
program. By default, the cable TV system is set to “STD”. If you want to select
  DQRWKHUW\SHRIFDEOHV\VWHPSUHVVWKHŸRUźEXWWRQWRVHOHFW³67'´³+5&´RU
“IRC”.
STD, HRC and IRC identify various types of cable TV systems. Contact your
local cable company to identify the type of cable system that exists in your
particular area. At this point the signal source has been selected.
Press the ENTER button to start the auto program.
To stop the search before it has finished, press the ENTER button with stop
selected.
5. After all the available channels are stored, the “Auto Program” menu reappears.
Press the EXIT button to exit.
Move Enter Return
Antenna : Air Ź
Auto Program Ź
Clear Scrambled Channel Ź
Channel List Ź
Name Ź
Fine Tune Ź
Signal Strength Ź
LNA : On Ź
Channel
Move Enter Return
TV
Move Enter Return
Select the antennas to memorize.
Channel
Move Enter Return
TV
Start
Air
Cable
Air+Cable
Start
Start
Plug & Play
Enter Return
Auto Program is completed.
16 Channels were memorized.
Air : 16, Cable : 0.
Auto Program
Stop
Enter Return
Auto Program in Progress.
Move Enter Return
Select the cable system.
Auto Program
Move Enter Return
TV
Analog
Start
STD
HRC
IRC
Digital
STD
HRC
IRC
35%
Cable Channel 50
OK

English - 18
After the television has been set up properly, your remote control can operate in
five different modes: TV, DVD, Cable, Set-Top Box, VCR. Pressing the corresponding
button on the remote control allows you to switch between these modes, and control
whichever piece of equipment you choose.
The remote control might not be compatible with all DVD Players, VCRs, Cable boxes, and
Set-Top Boxes.
Setting Up the Remote to Operate Your VCR
1. Turn off your VCR.
2. Press the VCR button on your TV’s remote control.
3. Press the SET button on your TV’s remote control.
4. Using the number buttons on your remote control, enter three digits of the VCR code
listed on page 20 of this manual for your brand of VCR. Make sure you enter three digits
of the code, even if the first digit is a “0”.
(If more than one code is listed, try the first one.)
5. Press the POWER button on the remote control.
Your VCR should turn on if your remote is set up correctly.
If your VCR does not turn on after set up, repeat steps 2, 3, and 4, but try one of the
other codes listed for your brand of VCR.
If no other codes are listed, try each VCR code, 000 through 080.
Note on Using Remote Control Modes: VCR
When your remote control is in “VCR” mode, the volume buttons still control your TV’s
volume.
Setting Up the Remote to Operate Your Cable Box
1. Turn off your cable box.
2. Press the CABLE button on your TV’s remote control.
3. Press the SET button on your TV’s remote control.
4. Using the number buttons on your remote control, enter three digits of the cable box code
listed on page 21 of this manual for your brand of cable box. Make sure you enter three
digits of the code, even if the first digit is a “0”. (If there is more than one code listed, try
the first one.)
5. Press the POWER button on the remote control.
Your cable box should turn on if your remote is set up correctly.
If your cable box does not turn on after set up, repeat steps 2, 3, and 4, but try one of the
other codes listed for your brand of cable box. If no other codes are listed, try each code,
000 through 046.
Note on Using Remote Control Modes: Cable Box
When your remote control is in “CABLE” mode, the volume buttons still control your TV’s
volume.
Setting Up Your Remote Control (depending on the model)
