Samsung LN19A330 User manual
Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products,
please contact the SAMSUNG customer care center.
Contate a SAMSUNG EM TODO O MUNDO
Caso tenha dúvidas ou comentários sobre os produtos da Samsung,
entre em contato com o centro de atendimento ao cliente da SAMSUNG.
Country Customer Care Center Web Site
ARGENTINE 0800-333-3733 www.samsung.com/ar
BRAZIL 0800-124-421
4004-0000 www.samsung.com
CHILE 800-SAMSUNG(726-7864) www.samsung.com/cl
COLOMBIA 01-8000112112 www.samsung.com.co
COSTA RICA 0-800-507-7267 www.samsung.com/latin
ECUADOR 1-800-10-7267 www.samsung.com/latin
EL SALVADOR 800-6225 www.samsung.com/latin
GUATEMALA 1-800-299-0013 www.samsung.com/latin
HONDURAS 800-7919267 -
JAMAICA 1-800-234-7267 www.samsung.com/latin
PANAMA 800-7267 www.samsung.com/latin
PUERTO RICO 1-800-682-3180 www.samsung.com/latin
REP. DOMINICA 1-800-751-2676 www.samsung.com/latin
NICARAGUA 00-1800-5077267 -
MEXICO 01-800-SAMSUNG(726-7864) www.samsung.com
TRINIDAD & TOBAGO 1-800-SAMSUNG(726-7864) www.samsung.com/latin
VENEZUELA 0-800-100-5303 www.samsung.com/latin
IMPORTADO POR:
AV. PRESIDENTE MASARIK #111 INT701
COL. CHAPULTEPEC MORALES C.P.11570
DELEGACION MIGUEL HIDALGO MEXICO. DISTRITO FEDERAL
Tel: 01-55-5747-5100 / 01-800-726-7864
LCD TV
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/global/register
Model Serial No.
BN68-01514H-00
BN68-01514H-00L02-Cover.indd 1 2008-05-15 �� 2:38:20
Precautions When Displaying a Still Image
A still image may cause permanent damage to the TV screen
• Do not display a still image on the LCD panel for more than 2 hours as it can cause screen image retention. This image retention is also
known as "screen burn". To avoid such image retention, reduce the degree of brightness and contrast of the screen when displaying a still
image.
• Watching the LCD TV in 4:3 format for a long period of time may leave traces of borders displayed on the left, right and
center of the screen caused by the difference of light emission on the screen.
Playing a DVD or a game console may cause a similar effect to the screen.
Damages caused by the above effect are not covered by the Warranty.
• Displaying still images from Video games and PC for longer than a certain period of time may produce partial after-images.
To prevent this effect, reduce the ‘brightness’ and ‘contrast’ when displaying still images.
© 2008 Samsung Electronics Co., Ltd. All rights reserved.
Contact SAMSUNG WORLDWIDE
If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care center.
(See back cover for more informations.)
BN68-01514H-00Eng-0515.indd 1 2008-05-15 �� 2:38:55
English
English
Contents
English - 1
Symbol Press Note One-Touch
Button
English
General Information
List of Features....................................................................2
Accessories .........................................................................2
Viewing the Control Panel ..................................................3
Viewing the Connection Panel.............................................4
Remote Control ...................................................................5
Installing Batteries in the Remote Control ...........................6
Connections
Connecting VHF and UHF Antennas...................................6
Connecting Cable TV ..........................................................7
Connecting a VCR...............................................................8
Connecting a DVD Player/Set-Top Box...............................9
Connecting a DVD Player/Set-Top Box via HDMI ...............9
Connecting a DVD Player/Set-Top Box via DVI ................10
Connecting a PC ...............................................................10
Operation
Turning the TV On and Off ................................................11
Plug & Play Feature...........................................................11
Changing Channels...........................................................12
Adjusting the Volume.........................................................12
Viewing the Display ...........................................................13
Selecting the Video Signal-source.....................................13
Storing Channels Automatically.........................................13
Storing Channels Manually................................................14
Fine Tuning Channels........................................................14
To Select the Source .........................................................15
To Edit the Input Source Name..........................................15
Picture Control
Using Automatic Picture Settings ......................................16
Customizing the Picture.....................................................16
Adjusting the Color Tone ...................................................17
Changing the Picture Size.................................................17
Adjusting the Color Control................................................18
Freezing the Picture ..........................................................18
Sound Control
Using Automatic Sound Settings .......................................18
Customizing the Sound .....................................................19
Choosing a Multi-Channel Sound (MTS) Soundtrack........19
Using the Auto Volume ......................................................20
Connecting headphones....................................................20
Time Setting
Setting the Clock ...............................................................21
Setting the Sleep Timer .....................................................21
Setting the On/Off Timer....................................................22
Function Description
Selecting a Menu Language..............................................22
Viewing Closed Captions ..................................................23
Setting the Blue Screen Mode...........................................23
PC Display
Using Your TV as a Computer (PC) Display......................24
Display Modes...................................................................24
Setting up the TV with your PC .........................................25
Appendix
Troubleshooting.................................................................26
How to Adjust the Stand ....................................................27
How to Adjust the Angle of the TV.....................................27
Installing the Wall Mount Kit ..............................................27
Installing VESA compliant mounting devices.....................27
Using the Anti-Theft Kensington Lock ...............................28
Securing the TV to the Wall...............................................29
Specications ....................................................................30
BN68-01514H-00Eng-0515.indd 1 2008-05-15 �� 2:38:55
English - 2
Accessories
Please make sure the following items are included with your LCD TV.
If any items are missing, contact your dealer.
Remote Control & Batteries
(AAA x 2) Power Cord Wall Mount kit
Warranty Card/
Safety Guide Manual
(Not available in all locations) Owner’s Instructions Cleaning Cloth
The items color and shape may vary depending on the model.
General Information
List of Features
Easy-to-use remote control
Easy-to-use on-screen menu system
Automatic timer to turn the TV on and off.
Adjustable picture settings that can be stored in the TV’s memory.
Aspecialltertoreduceoreliminatereceptionproblems.
Fine tuning control for the sharpest picture possible
A built-in multi-channel sound decoder for stereo and bilingual listening
Headphone jack for private listening
BN68-01514H-00Eng-0515.indd 2 2008-05-15 �� 2:38:57
English - 3
Viewing the Control Panel
1
SOURCE
Toggles between all the available input sources
(TV, AV, S-Video, Component, PC, HDMI).
In the on-screen menu, use this button as you would
use the ENTER button on the remote control.
2
MENU
Press to see an on-screen menu of your TV’s features.
3
+ VOL -
Press to increase or decrease the volume.
In the on-screen menu, use the + VOL - buttons as you
wouldusethe◄and►buttonsontheremotecontrol.
4CH
Press to change channels.
In the on-screen menu, use the
CH
buttons as
youwouldusethe▲and▼butonsontheremote
control.
5
POWER INDICATOR
Blinks and turns off when the power is on and lights up
in stand-by mode.
6
(POWER)
Press to turn the TV on and off.
7
REMOTE CONTROL SENSOR
Aim the remote control towards this spot on the TV.
8
SPEAKERS
Buttons on the Lower-Right Part of the Panel
The buttons on the lower-right panel control your TV’s basic features, including the on-screen menu.
To use the more advanced features, you must use the remote control.
The product color and shape may vary depending on the model.
1
2
3
4
6
7
8
Front Panel buttons
Touch the right side of
each button to operate.
5
BN68-01514H-00Eng-0515.indd 3 2008-05-15 �� 2:38:58
English - 4
6
Viewing the Connection Panel
Rear Panel Jacks
Use the rear panel jacks to connect A/V components that will be connected continuously, such as VCR or DVD players.
For more information on connecting equipment, see pages 6-10.
1
HDMI/DVI IN, DVI IN (AUDIO R/L)
Connects to the
HDMI/DVI IN
jack of a device with an
HDMI output.
Use the HDMI/DVI IN terminal for a DVI connection to an
external device.
You should use the DVI to HDMI cable or DVI-HDMI
adapter (DVI to HDMI) for a video connection, and the DVI IN
‘R-AUDIO-L’ terminal for audio.
HDMI/DVI IN terminal does not support PC.
- No sound connection is needed for an HDMI to
HDMI connection
2
PC IN
Connect to the video and audio output jacks on your PC.
3
ANT IN
Connect to an antenna or cable TV system.
4
HEADPHONE
Connects a set of external headphones for private
listening
5
AV IN
Video and audio inputs for external devices, such as a
camcorder or VCR.
S-VIDEO
Connect an S-Video signal from a camcorder or VCR.
6
COMPONENT IN
Connect Component video/audio.
7
POWER INPUT
Connect the supplied power cord.
8
KENSINGTON LOCK
The Kensington Lock (optional) is a device used to
physically fix the system when used in a public place.
If you want to use a locking device, contact the dealer
where you purchased the TV.
The location of the Kensington Lock may be different
depending on its model.
1 3
45
The product color and shape may vary depending on the model.
2
78
BN68-01514H-00Eng-0515.indd 4 2008-05-15 �� 2:38:58
English - 5
Remote Control
You can use the remote control up to a distance of about 23 feet from the TV.
The performance of the remote control may be affected by bright light.
This is a special remote control for the visually impaired, and has Braille points on the Power, Channel and Volume buttons.
1
POWER
Turns the TV on and off.
2
NUMERIC BUTTONS
Press to change the channel.
3
–
Press to select channels over 100.
For example, to select channel 121,
press " – ", then "2", then "1".
4
VOL / VOL
Press to increase or decrease the
volume.
5 (
MUTE)
Press to temporarily cut off the
sound.
6
MENU
Displays the main on-screen
menu.
7
UP▲ / DOWN▼ / LEFT◄ /
RIGHT► / ENTER
Use to select on-screen menu
items and change menu values.
8
S.MODE
Press to select the sound mode.
9
P.MODE
Press to select the picture mode.
0
P.SIZE
Press to change the screen size.
!
CAPTION
Controls the caption decoder.
@
SRS
Not available.
#
INFO
Press to display information on the
TV screen.
$
SOURCE
Press to display all of the available
video sources.
%
PRE-CH
Tunes to the previous channel.
^
CH
/ CH
Press to change channels.
&
EXIT
Press to exit the menu.
*
MTS
Press to choose stereo, mono or
Separate Audio Program
(SAP broadcast).
(
SLEEP
Press to select a preset time
interval for automatic shut off.
)
STILL
Press to stop the action during
a particular scene.
Press again to resume normal
video.
a
ADD/DEL
Use to store and delete channels
to/from memory.
b
AUTO PROG.
Press to automatically store TV/
Cable channels.
BN68-01514H-00Eng-0515.indd 5 2008-05-15 �� 2:38:59
English - 6
1. Lift the cover at the back of the remote control upward as shown in the figure.
2. Install two AAA size batteries.
Make sure to match the "+" and "–" ends of the batteries with the diagram inside the compartment.
3. Replace the cover.
Remove the batteries and store them in a cool, dry place if you won’t be using the remote control for a
long time.
The remote control can be used up to about 23 feet from the TV.
(Assuming typical TV usage, the batteries last for about one year.)
If the remote control doesn’t work, check the following:
1. Is the TV power on?
2. Are the plus and minus ends of the batteries reversed?
3. Are the batteries drained?
4. Is there a power outage, or is the power cord unplugged?
5. Is there a special fluorescent light or neon sign nearby?
Installing Batteries in the Remote Control
Connecting VHF and UHF Antennas
Ifyourantennahasasetofleadsthatlooklikethis,see"Antennaswith300ΩFlatTwinLeads"
below.
Ifyourantennahasoneleadthatlookslikethis,see"Antennaswith75ΩRoundLeads".
If you have two antennas, see "Separate VHF and UHF Antennas".
1. Placethewiresfromthetwinleadsunderthescrewsona300-75Ωadapter
(not supplied).
Use a screwdriver to tighten the screws.
2. Plug the adaptor into the ANT IN terminal on the back of the TV.
ANT IN
Antennas with 300 Ω Flat Twin Leads
Ifyouareusinganoff-airantenna(suchasaroofantennaor"rabbitears")thathas300Ωtwinatleads,followthedirections
below.
1. Plug the antenna lead into the ANT IN terminal on the back of the TV.
Antennas with 75 Ω Round Leads
ANT IN
Separate VHF and UHF Antennas
If you have two separate antennas for your TV (one VHF and one UHF), you must combine the two antenna signals before
connecting the antennas to the TV. This procedure requires an optional combiner-adaptor (available at most electronics shops).
1. Connect both antenna leads to the combiner.
2. Plug the combiner into the ANT IN terminal on the bottom of the rear panel.
UHF
VHF
ANT IN
UHF
VHF
Connections
BN68-01514H-00Eng-0515.indd 6 2008-05-15 �� 2:39:00
English - 7
After you have made this connection, set the A/B switch to the "A" position for normal viewing. Set the A/B switch to the "B" position to
view scrambled channels. (When you set the A/B switch to "B", you will need to tune your TV to the cable box’s output channel, which is
usually channel 3 or 4.)
Connecting to a Cable Box that Descrambles Some Channels
If your cable box descrambles only some channels (such as premium channels), follow the instructions below. You will need a two-
way splitter, an RF (A/B) switch, and four lengths of RF cable. (These items are available at most electronics stores.)
2. Connect this cable to a two-way splitter.
3. Connect an RF cable between an OUTPUT
terminal on the splitter and the IN terminal
on the cable box.
4. Connect an RF cable between the
ANT OUT terminal on the cable box and
the B–IN terminal on the RF(A/B) switch.
1. Find and disconnect the cable that is
connected to the ANT IN terminal on your
cable box.
This terminal might be labeled "ANT IN",
"VHF IN" or simply, "IN".
5. Connect another cable between the other
OUT terminal on the splitter and the A–IN
terminal on the RF (A/B) switch.
6. Connect the last RF cable between the
OUT terminal on the RF (A/B) switch and
the ANT IN terminal on the rear of the TV.
Splitter
Incoming
cable
Splitter
Cable Box
Incoming
cable
Splitter
Cable Box
RF (A/B)
Switch
Incoming
cable
ANT IN
Splitter
Cable Box
Incoming
cable
RF (A/B)
Switch
Splitter
Cable Box
Incoming
cable TV Rear
RF (A/B)
Switch
ANT IN
Connecting Cable TV
To connect to a cable TV system, follow the instructions below.
Cable without a Cable Box
1. Plug the incoming cable into the ANT IN terminal on the back of the TV.
Because this TV is cable-ready, you do not need a cable box to view unscrambled cable channels.
Connecting to a Cable Box that Descrambles All Channels
1. Find the cable that is connected to the ANT OUT terminal on your cable box.
This terminal might be labeled "ANT OUT", "VHF OUT" or simply, "OUT".
2. Connect the other end of this cable to the ANT IN terminal on the back of the TV.
ANT OUT
ANT IN
ANT IN
ANT IN
BN68-01514H-00Eng-0515.indd 7 2008-05-15 �� 2:39:02
English - 8
Connecting a VCR
These instructions assume that you have already connected your TV to an antenna or a cable TV system (according to the
instructions on pages 6-7). Skip step 1 if you have not yet connected to an antenna or a cable system.
1. Unplug the cable or antenna
from the back of the TV.
2. Connect the cable or antenna
to the ANT IN terminal on the
back of the VCR.
3. Connect an Antenna Cable
between the ANT OUT
terminal on the VCR and the
ANT IN terminal on the TV.
4. Connect a Video Cable
between the VIDEO OUT
jack on the VCR and the
AV IN [VIDEO] jack on the
TV.
5. Connect Audio Cables
between the AUDIO OUT
jacks on the VCR and the
AV IN [R-AUDIO-L] jacks
on the TV.
If you have a "mono"
(non-stereo) VCR, use
a Y-connector (not
supplied) to hook up to
the right and left audio
input jacks of the TV.
If your VCR is stereo, you
must connect two cables.
Follow the instructions in "Viewing a VCR or Camcorder Tape" to view your VCR tape.
Each VCR has a different back panel configuration.
When connecting a VCR, match the color of the connection terminal to the cable.
VCR Rear Panel
TV Rear Panel
2
Antenna Cable (Not supplied)
3
Video Cable (Not supplied)
4
Audio Cable (Not supplied)
5
ANT IN
Your Samsung TV can be connected to an S-Video signal from a VCR.
(This connection delivers a better picture as compared to a standard VCR.)
1. To begin, follow steps 1–3
in the previous section to
connect the antenna or
cable to your VCR and your
TV.
2. Connect an S-Video Cable
between the S-VIDEO OUT
jack on the VCR and the
AV IN [S-VIDEO] jack on
the TV.
3. Connect Audio Cables
between the AUDIO OUT
jacks on the VCR and the
AV IN [R-AUDIO-L] jacks
on the TV.
An S-Video cable is usually included with a VCR. (If not, check your local electronics store.)
Each VCR has a different back panel configuration.
When connecting a VCR, match the color of the connection terminal to the cable.
S-Video Cable (Not supplied)
2
VCR Rear Panel
Audio Cable (Not supplied)
3
Video Connection
S-Video Connection
TV Rear Panel
Antenna Cable (Not supplied)
1
BN68-01514H-00Eng-0515.indd 8 2008-05-15 �� 2:39:02
English - 9
Connecting a DVD Player/Set-Top Box
The rear panel jacks on your TV make it easy to connect a DVD player to your TV.
1. Connect a Component
Cable between the
COMPONENT IN [Y, PB,
PR] jacks on the TV and the
COMPONENT [Y, PB, PR]
jacks on the DVD player/Set-
Top Box.
2. Connect Audio Cables
between the COMPONENT
IN [R-AUDIO-L] jacks on the
TV and the AUDIO OUT jacks
on the DVD player/Set-Top
Box.
Component video separates the video into Y (Luminance (brightness)), Pb (Blue) and
Pr (Red) for enhanced video quality.
Be sure to match the component video and audio connections.
For example, if connecting the video cable to COMPONENT IN, connect the audio cable
to COMPONENT IN also.
Each DVD player/STB has a different back panel configuration.
When connecting a DVD player /STB, match the color of the connection terminal to the
cable.
DVD Player Rear Panel
TV Rear Panel
Component Cable (Not supplied)
1
Audio Cable (Not supplied)
2
Connecting a DVD Player/Set-Top Box via HDMI
This connection can only be made if there is an HDMI Output connector on the external device.
1. Connect an HDMI Cable
between the HDMI/DVI IN
connector on the TV
and the HDMI connector
on the DVD player/Set-Top
Box.
DVD Player Rear Panel
TV Rear Panel
HDMI Cable (Not supplied)
What is HDMI?
• HDMI(High-Definition Multimedia Interface), is a next-generation interface that
enables the transmission of digital audio and video signals using a single cable.
• The difference between HDMI and DVI is that the HDMI device is smaller in size,
has the HDCP (High Bandwidth Digital Copy Protection) coding feature installed.
Each DVD player/Set-top box has a different back panel configuration.
When connecting via HDMI, you do not need to connect Audio Cables.
You only need to connect Audio cables when connecting via HDMI/DVI.
BN68-01514H-00Eng-0515.indd 9 2008-05-15 �� 2:39:03
English - 10
PC TV Rear Panel
PC Audio Cable (Not supplied)
2
D-Sub Cable (Not supplied)
1
Connecting a PC
1. Connect a D-Sub
Cable between PC IN
[PC] connector on
the TV and the PC
output connector on
your computer.
2. Connect a PC Audio
Cable between PC IN
[AUDIO] jack on the
TV and the Audio Out
jack of the sound card
on your computer.
Each PC has a different back panel configuration.
When connecting a PC, match the color of the connection terminal to the cable.
HDMI/DVI IN terminal does not support PC.
Connecting a DVD Player/Set-Top Box via DVI
This connection can only be made if there is a DVI Output connector on the external device.
1. Connect a DVI to HDMI
Cable or DVI-HDMI Adapter
between the HDMI/DVI IN
connector on the TV and
the DVI connector on the
DVD player/Set-Top Box.
2. Connect Audio Cables
between the DVI IN
[R-AUDIO-L] jack on the
TV and the AUDIO OUT jacks
on the DVD player/
Set-Top Box.
Each DVD player/Set-top box has a different back panel configuration.
When connecting a DVD player/STB, match the color of the connection terminal
to the cable.
DVD Player / Set-Top Box
TV Rear Panel
Audio Cable (Not supplied)
2
DVI to HDMI Cable (Not supplied)
1
BN68-01514H-00Eng-0515.indd 10 2008-05-15 �� 2:39:04
English - 11
Plug & Play Feature
When the TV is initially powered on, basic settings proceed automatically and subsequently :
Turning the TV On and Off
Press the POWER button on the remote control.
You can also use the POWER button on button on the TV.
Operation
1. Press the POWER button on the remote control.
The message "Start Plug & Play" is displayed with "OK" selected.
2. Selecttheappropriatelanguagebypressingthe▲or▼button.
Press the ENTER button to confirm your choice.
3.
The message “Check antenna input.” is displayed with “OK” selected.
Press the ENTER button.
Please check that the antenna or cable TV is connected correctly.
4. Pressthe▲or▼buttontoselect“Air”or“Cable”,thenpresstheENTER button.
5. Press the ENTER button to select “Start”.
The channel search will start and end automatically.
After all the available channels are stored, the “Clock Set” menu appears.
Press the ENTER button at any time to interrupt the memorization process.
6.
Press the ENTER button.
Pressthe◄or►buttontomovetothe“Hour”,“Minute”or“am/pm”.
Setthe“Hour”,“Minute”or“am/pm”bypressingthe▲or▼button.
You can also set the hour and minute by pressing the number buttons on the remote control.
7.
Press the ENTER button to confirm your setting.
The message “Enjoy your watching.” is displayed.
Language: Select your language.
Air/Cable: Selects between terrestrial antenna connection or your local cable company TV system.
Auto Program: The TV automatically cycles through all of the available channels and stores them in memory.
This takes about one to two minutes.
Clock Set: Sets the current time for the TV clock.
Plug & Play
Enter Exit
Start Plug & Play.
OK
If you want to reset this feature...
1. Press the MENU button to display the menu.
Pressthe▲or▼buttontoselect"Setup",thenpresstheENTER button.
2. Press the ENTER button again, to select "Plug & Play".
3. The message "Start Plug & Play" is displayed.
Setup
Move Enter Return
Plug & Play
Language : English
Time
Caption
Blue Screen : Off
PC
BN68-01514H-00Eng-0515.indd 11 2008-05-15 �� 2:39:05
English - 12
Changing Channels
1. Press the CH or CH button to change channels.
When you press the CH or CH button, the TV changes channels in
sequence.
You will see all the channels that the TV has memorized. (The TV must have
memorized at least three channels). You will not see channels that were either
erased or not memorized. See page 13 to memorize channels.
Using the Channel Buttons
1. Press the number buttons to go directly to a channel. For example, to select
channel 27, press 2, then 7.
The TV will change channels when you press the second number.
Using the Number Buttons
Adjusting the Volume
1. Press the
VOL or VOL
buttons to decrease or increase the volume.
Using Mute
At any time, you can cut off the sound using the MUTE button.
1. Press MUTE button and the sound cuts off.
The word " " will appear in the lower-left corner of the screen.
2. To turn mute off, press the MUTE button again, or simply press the
VOL or VOL
buttons.
1. Press the "-" button to select a channel over 100. For example, to select
channel 122, press “-”, then “2”, then “2”.)
Using the “-” Button
1. Press the PRE-CH button.
The TV will switch to the last channel viewed.
To quickly switch between two channels that are far apart, tune to one
channel, then use the number button to select the second channel. Then
use the PRE-CH button to quickly alternate between them.
Using the PRE-CH Button to select the Previous Channel
BN68-01514H-00Eng-0515.indd 12 2008-05-15 �� 2:39:06
English - 13
Viewing the Display
1. Press the INFO button on the remote control.
The TV will display the channel, the type of sound,
and the status of certain picture and sound settings.
Press the INFO button once more or wait approximately 10 seconds and it
disappears automatically.
Thedisplayidentiesthecurrentchannelandthestatusofcertainaudio-videosettings.
Selecting the Video Signal-source
Before your television can begin memorizing the available channels, you must specify the type of signal source that is connected to
the TV (i.e. an antenna or a cable system).
1.
Press the MENU button to display the menu.
Pressthe▲or▼buttontoselect“Channel”,thenpresstheENTER button.
2. Press the ENTER button to select “Air/Cable”.
3. Pressthe▲or▼buttontoselectthevideosignalsource,thenpressthe
ENTER button.
4. Press the EXIT button to exit.
Air 3
Mono
Picture : Dynamic
Sound : Custom
MTS : Stereo
05 : 54 pm
Channel
Move Enter Return
Air/Cable : Air
Auto Program
Add/Delete
Fine Tune
Air/Cable
Move Enter Return
Air
Cable
Storing Channels Automatically
The TV automatically cycles through all of the available channels and stores them in memory.
This takes about one to two minutes.
1.
To select the signal source, follow the “Selecting the Video Signal-source”
instructions numbers 1 to 3.
2. Pressthe▲or▼buttontoselect“AutoProgram”,thenpresstheENTER button.
3.
Press the ENTER button to select “Start”.
The channel search will start and end automatically.
Press the ENTER button at any time to interrupt the memorization process
and return to the “Channel” menu.
4. After all the available channels are stored, the “Channel” menu reappears.
5. Press the EXIT button to exit.
Press the AUTO PROG. button on the remote control.
Channel
Move Enter Return
Air/Cable : Air
Auto Program
Add/Delete
Fine Tune
BN68-01514H-00Eng-0515.indd 13 2008-05-15 �� 2:39:06
English - 14
Storing Channels Manually
Set the channels according to your preference. You can easily delete or add the channels you want.
1.
Use the number buttons to directly select the channel that will be added or deleted.
2.
Press the MENU button to display the menu.
Pressthe▲or▼buttontoselect“Channel”,thenpresstheENTER button.
3. Pressthe▲or▼buttontoselect“Add/Delete”,thenpresstheENTER button.
4. Pressthe▲or▼buttontoselectthechannelstobedeletedoradded.
5. Press the ENTER button to select “ ” column, then press the ENTER button.
The channels marked with “ ” will be added.
6. Press the EXIT button to exit.
You can directly select any channel (including an erased channel) by using the
number buttons on the remote control.
Use the number buttons to directly select the channel that will be added or
erased. Press the ADD/DEL button on the remote control.
Channel
Move Enter Return
Air/Cable : Air
Auto Program
Add/Delete
Fine Tune
Air 8
1/5
Ch.
Air 8
Air 9
Air 10
Air 11
Air 12
Air 13
Air 14
Air 15
Air 16
Air 17
Air 18
Air 19
Air 20
Air 21
Air 22
Add/Delete
Move Enter
Page Return
Add
Fine Tuning Channels
Use fine tuning to manually adjust a particular channel for optimal reception.
1.
Use the number buttons to directly select the channel that you want to fine tune.
2.
Press the MENU button to display the menu.
Pressthe▲or▼buttontoselect“Channel”,thenpresstheENTER button.
3. Pressthe▲or▼buttontoselect“FineTune”,thenpresstheENTER button.
4. Pressthe◄or►buttontoadjustthefinetuning.
5. To store the fine tuning setting in the TV’s memory, press the ENTER button.
6. Press the EXIT button to exit.
If you do not store the fine-tuned channel in memory, adjustments are not saved.
Fine tuned channels that have been saved are marked with an asterisk “ * ” on the right-hand side of the channel number in
the channel banner.
To reset the fine-tuning, select “Reset” by pressing the ▲or▼ button and then press the ENTER button.
Channel
Move Enter Return
Air/Cable : Air
Auto Program
Add/Delete
Fine Tune
BN68-01514H-00Eng-0515.indd 14 2008-05-15 �� 2:39:07
English - 15
To Select the Source
Use to select TV or other external input sources connected to the TV.
Use to select the input source of your choice.
1. Press the MENU button to display the menu.
Pressthe▲or▼buttonstoselect“Input”,thenpresstheENTER button.
2. Press the ENTER button to select "Source List".
Pressthe▲or▼buttonstoselectsignalsource,thenpresstheENTER button.
When you connect equipment to the LCD, you can choose between the
following sets of jacks: TV, AV, S-Video, Component, PC or HDMI on the TV’s
rear panel.
HDMI input can only be selected when the external device is turned on and
connected via HDMI.
You can choose only those external devices that are connected to the TV.
3. Press the EXIT button to exit.
Press the SOURCE button on the remote control to view an external signal source.
To Edit the Input Source Name
You can name the input device connected to the input jacks to make your input source selection easier.
1. Press the MENU button to display the menu.
Pressthe▲or▼buttonstoselect“Input”,thenpresstheENTER button.
2. Pressthe▲or▼buttonstoselect"EditName",thenpresstheENTER button.
3. Pressthe▲or▼buttontoselectthedesiredinputdevice,thenpressthe
ENTER button.
4. Pressthe▲or▼buttonrepeatedlyuntiltheappropriatesourcenameappears.
After the source is selected, press the ENTER button.
The following options are available:
- - - - - VCR - DVD - Cable STB - HD STB - Satellite STB - AV Receiver - DVD
Receiver - Game - Camcorder - DVD Combo - DHR - PC
DHR: DVD HDD Recorder
5. Press the EXIT button to exit.
Source List
Move Enter Return
TV
AV : ----
S-Video : ----
Component : ----
PC : ----
HDMI : ----
Input
Source List : TV
Edit Name
Move Enter Return
Edit Name
Move Enter Return
AV : ----
S-Video : ----
Component : ----
PC : ----
HDMI : ----
Input
Source List : TV
Edit Name
Move Enter Return
Edit Name
Move Enter Return
----
VCR
DVD
Cable STB
HD STB
Satellite STB
AV Receiver
DVD Receiver
BN68-01514H-00Eng-0515.indd 15 2008-05-15 �� 2:39:08
English - 16
Using Automatic Picture Settings
Your TV has three automatic picture settings (“Dynamic”, “Standard”, “Movie” and “Custom”) that are preset at the factory.
1. Press the MENU button to display the menu.
Pressthe▲or▼buttontoselect“Picture”,thenpresstheENTER button.
2. Press the ENTER button to select "Mode".
3. Pressthe▲or▼buttontoselectthedesiredpictureeffect.
Press the ENTER button.
4. Press the EXIT button to exit.
Dynamic:Selectsthepictureforhigh-denitioninabrightroom.
Standard: Selects the picture for optimum display in a normal environment.
Movie: Selects the picture for comfortable display in a dark room.
Custom: Select to view your favorite display settings.
[PC mode]
Entertain: High brightness. (For watching motion pictures such as a DVD or
Video CD.)
Internet: Medium brightness. (For working with a mixture of images such as
text and graphics.)
Text: Normal brightness. (For documentations or works involving heavy text.)
Custom: Select to view your favorite display settings.
In the PC mode, “Entertain”, “Internet”, “Text” and “Custom” appears.
You can also press the P.MODE button on the remote control to select one of the
picture settings.
Picture Control
Move Enter Return
Mode : Dynamic
Custom
Color Tone : Cool1
Size : Wide
Mode
Move Enter Return
Dynamic
Standard
Movie
Custom
Customizing the Picture
Your set has several settings which allow you to control picture quality.
1. Press the MENU button to display the menu.
Pressthe▲or▼buttontoselect“Picture”,thenpresstheENTER button.
2. Pressthe▲or▼buttontoselect“Custom”,thenpresstheENTER button.
3. Pressthe▲or▼buttontoselectaparticularitem.
Press the ENTER button.
4. Press the ◄or► button to decrease or increase the value of a particular item.
Press the ENTER button.
5. Press the EXIT button to exit.
Contrast: Adjusts the lightness and darkness between objects and the back-
ground.
Brightness: Adjusts the brightness of the whole screen.
Sharpness: Adjusts the outline of objects to either sharpen them or make them
more dull.
Color : Adjusts the colors, making them lighter or darker.
Tint(G/R): Adjusts the color of objects, making them more red or green for a
more natural look.
If you make any changes to these settings, the Picture Mode is automatically
switched to “Custom”.
In the PC mode, only “Contrast” and “Brightness” can be adjusted.
“Tint(G/R)” doesn’t operate in Component or HDMI mode.
The energy consumed during use can be significantly reduced if the level of
brightness of the picture is reduced, and that this will reduce the overall running cost.
Move Enter Return
Mode : Dynamic
Custom
Color Tone : Cool1
Size : Wide
Custom
Move Enter Return
Contrast
Brightness
Sharpness
Color
Tint G 50 R
100
45
75
55
50
BN68-01514H-00Eng-0515.indd 16 2008-05-15 �� 2:39:09
English - 17
Adjusting the Color Tone
You can Change the color of the entire screen according to your preference.
1. Press the MENU button to display the menu.
Pressthe▲or▼buttontoselect“Picture”,thenpresstheENTER button.
2. Pressthe▲or▼buttontoselect“ColorTone”,thenpresstheENTER button.
3. Pressthe▲or▼buttontoselectthedesiredcolortonesetting.
Press the ENTER button.
4. Press the EXIT button to exit.
Cool2: Makes the color temperature bluer than “Cool1” menu.
Cool1: Makes whites bluish.
Normal: Keeps whites white.
Warm1 : Makes whites reddish.
Warm2: Makes the color temperature redder than “Warm1” menu.
In the PC mode, “Cool”, “Normal”, “Warm” and “Custom” appears.
Move Enter Return
Mode : Dynamic
Custom
Color Tone : Cool1
Size : Wide
Color Tone
Move Enter Return
Cool 2
Cool 1
Normal
Warm 1
Warm 2
Changing the Picture Size
You can select the picture size which best corresponds to your viewing requirements.
1. Press the MENU button to display the menu.
Pressthe▲or▼buttontoselect“Picture”,thenpresstheENTER button.
2. Pressthe▲or▼buttontoselect“Size”,thenpresstheENTER button.
3. Selecttherequiredoptionbypressingthe▲or▼button.
Press the ENTER button.
4. Press the EXIT button to exit.
Wide: Adjusts the picture size to Wide appropriate for DVDs or wide
broadcasting.
16:9:
Adjusts the picture size to 16:9 appropriate for DVDs or wide broadcasting.
Zoom: Magnifies the Wide picture (in the vertical direction) to fit the screen
size.
4:3 : This is the default setting for a video movie or normal broadcasting.
In PC, Component and HDMI mode, only “Wide” and “4:3” mode can be selected.
Zoom: Select by pressing the
◄
or
►
buttons.
Use the
▲
or
▼
button to move the picture up and down.
After selecting , use the
▲
or
▼
button to magnify or reduce the picture
size in the vertical direction.
Alternately, you can press the P.SIZE button on the remote control repeatedly to
change the picture size.
Move Enter Return
Mode : Dynamic
Custom
Color Tone : Cool1
Size : Wide
Size
Move Enter Return
Wide
16:9
Zoom
4 : 3
BN68-01514H-00Eng-0515.indd 17 2008-05-15 �� 2:39:10
English - 18
Adjusting the Color Control
Adjust the individual R, G, B Color Controls.
1. Press the MENU button to display the menu.
Pressthe▲or▼buttontoselect“Picture”,thenpresstheENTER button.
2. Pressthe▲or▼buttontoselect““ColorControl”,thenpressthe
ENTER button.
3. Pressthe▲or▼buttontoselectaparticularitem.
Press the ENTER button.
4. Pressthe◄or►buttontodecreaseorincreasethevalueofaparticularitem.
Press the ENTER button.
5. Press the EXIT button to exit.
Available in PC Mode Only
Move Enter Return
Mode : Dynamic
Custom
Color Tone : Cool1
Color Control
Size : Wide
Color Control
Move Enter Return
Red
Green
Blue
0
19
50
Freezing the Picture
1. Press the STILL button to freeze a moving picture.
Normal sound will still be heard. Press again to cancel.
This function doesn’t work when the Input Source is Component, HDMI, and PC.
Using Automatic Sound Settings
You can select the type of the special sound effect to be used when watching a given broadcast.
1. Press the MENU button to display the menu.
Pressthe▲or▼buttonstoselect"Sound",thenpresstheENTER button.
2. Press the ENTER button to select “Mode”.
3. Pressthe▲or▼buttontoselectthedesiredsoundeffect.
Press the ENTER button.
4. Press the EXIT button to exit.
Standard: Selects the normal sound mode.
Music:
Emphasizes music over voices.
Movie: Provides live and full sound for movies.
Speech: Emphasizes voices over other sounds.
Custom: Selects your custom sound settings.
You can also press the S.MODE button on the remote control to select one of the
sound settings.
Sound Control
Sound
Move Enter Return
Mode : Music
Custom
MTS : Stereo
Auto Volume : Off
Mode
Move Enter Return
Standard
Music
Movie
Speech
Custom
BN68-01514H-00Eng-0515.indd 18 2008-05-15 �� 2:39:11
Other manuals for LN19A330
1
This manual suits for next models
2
Table of contents
Languages:
Other Samsung LCD TV manuals
Samsung
Samsung LE32C650L1K User manual
Samsung
Samsung LA32C450E1M User manual
Samsung
Samsung LTP227W - HD-Ready Flat-Panel LCD TV User manual
Samsung
Samsung LN40C500F3F User manual
Samsung
Samsung LE40F8 User manual
Samsung
Samsung LN32A550P3R User manual
Samsung
Samsung LED 6300 Series User manual
Samsung
Samsung 5 Series User manual
Samsung
Samsung LN-R238WA Setup guide
Samsung
Samsung LE32C53 Series User manual
Samsung
Samsung BN68-02541C-03 User manual
Samsung
Samsung LN40A650 User manual
Samsung
Samsung LN32A540P2D User manual
Samsung
Samsung LE32M86BDX User manual
Samsung
Samsung LN32B540 User manual
Samsung
Samsung UN60ES7500F Guide
Samsung
Samsung LN55C750 User manual
Samsung
Samsung LCD TV User manual
Samsung
Samsung PDP 8500 series User manual
Samsung
Samsung 6 series User manual
