Samsung LN32A650A1F User manual

LCD-TV
Chassis : GAM32MUS
GAM40MUS
GAM46MUS
GAM52MUS
Model : LN32A650A1F
LN40A650A1F
LN46A650A1F
LN52A650A1F
SERVICEManual
TFT-LCD TV Contents
LN32A650A1F/LN40A650A1F/
LN46A650A1F/ LN52A650A1F
Refer to the service manual in the GSPN (see the rear cover) for the more information.
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Exploded View & Part List
6. Wiring Diagram
7. Schematic Diagram

Contents
1. Precautions.............................................................................................................. 1-1
1-1. Safety Precautions ......................................................................................................... 1-1
1-2. Servicing Precautions..................................................................................................... 1-2
1-3. Electrostatically Sensitive Devices (ESD) Precautions .................................................. 1-2
1-4. Installation Precautions .................................................................................................. 1-3
2. Product specications............................................................................................ 2-1
2-1. Feature & Specications................................................................................................. 2-1
2-2. MJC : Motion Judder Cancellation (FRC)....................................................................... 2-7
2-3. Spec Comparison to the Old Models.............................................................................. 2-8
2-4. Accessories .................................................................................................................... 2-9
3. Disassembly and Reassemble ............................................................................... 3-1
3-1. Disassembly ................................................................................................................... 3-1
4. Troubleshooting ...................................................................................................... 4-1
4-1. Troubleshooting .............................................................................................................. 4-1
4-2. Alignments and Adjustments ........................................................................................ 4-19
4-3. Factory Mode Adjustments ........................................................................................... 4-20
4-4. White Balance - Calibration .......................................................................................... 4-28
4-5. Servicing Information.................................................................................................... 4-30
5. Exploded View & Part List ...................................................................................... 5-1
5-1. LN32A650A1F Exploded View ....................................................................................... 5-1
5-2. LN40A650A1F Exploded View ....................................................................................... 5-3
5-3. LN46A650A1F Exploded View ....................................................................................... 5-5
5-4. LN52A650A1F Exploded View ....................................................................................... 5-7
5-5. LN32A650A1F Parts List ................................................................................................ 5-9
5-6. LN40A650A1F Parts List .............................................................................................. 5-43
5-7. LN46A650A1F Parts List .............................................................................................. 5-77
5-8. LN52A650A1F Parts List ............................................................................................ 5-110
6. Wiring Diagram........................................................................................................ 6-1
6-1. Wiring Diagram 32”......................................................................................................... 6-1
6-2. Wiring Diagram 40”......................................................................................................... 6-2
6-3. Wiring Diagram 46”......................................................................................................... 6-3
6-4. Wiring Diagram 52”......................................................................................................... 6-4
6-5. Connector Functions ...................................................................................................... 6-6
6-6. Cables ............................................................................................................................ 6-6
7. Schematic Diagram ................................................................................................. 7-1
7-1. Block Diagram ................................................................................................................ 7-1
7-2. Schematic Diagrams ...................................................................................................... 7-4

GSPN (Global Service Partner Network)
Area Web Site
North America http://service.samsungportal.com
Latin America http://latin.samsungportal.com
CIS http://cis.samsungportal.com
Europe http://europe.samsungportal.com
China http://china.samsungportal.com
Asia http://asia.samsungportal.com
Mideast & Africa http://mea.samsungportal.com
This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2008 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea
P/N: BN82-00347A-00

1-1
1. Precautions
1. Precautions
1-1. Safety Precautions
Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LCD TV
When servicing the LCD TV, Disconnect the AC line cord from the AC outlet.
It is essential that service technicians have an accurate voltage meter available at all times.
Check the calibration of this meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the LCD TV to the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the
chassis and other metal parts in the LCD TV.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
Leakage Current Hot Check (Figure 1-1):
WARNING : Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards Institute (ANSI
C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch
rst in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit,
etc.) and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, re and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.
1.
2.
1.
2.
1.
2.
3.
4.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA
LEAKAGE
CURRENT
TESTER
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
*ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED) EARTH
GROUND Figure 1-1. Leakage Current Test Circuit

1-2
1. Precautions
1-2. Servicing Precautions
WARNING: An electrolytic capacitor installed with the wrong polarity might explode.
Caution: Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
Note: If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1 General Servicing Precautions
Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before
attempting to:
(a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect a test
component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes
used. The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such
elements to their original position.
After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels,
input terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON.
Connect an insulation resistance meter (500 V) to theblades of the AC plug.
The insulation resistance between each blade of the AC plug and accessible conductive parts (see above) should be
greater than 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;
always remove the instrument’s ground lead last.
1-3. Electrostatically Sensitive Devices (ESD) Precautions
Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the LCD TV.
After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.
Use only a grounded-tip soldering iron to solder or desolder ESDs.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective
material to the chassis or circuit assembly into which the device will be installed.
Caution: Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together,
or lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1.
2.
3.
4.
5.
6.
1.
2.
3.
4.
5.
6.
7.
8.

1-3
1. Precautions
1-4. Installation Precautions
For safety reasons, more than two people are required for carrying the product.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal
temperature may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (10cm) between the product and the wall for ventilation purposes.
A rise in temperature within the product may cause re.
1.
2.
3.
4.
5.
6.
7.

1-4
1. Precautions
Memo

5-1
5. Exploded View & Part List
5. Exploded View & Part List
5-1. LN32A650A1F Exploded View
T0003
M0215
T0447
M0115
T0175
M0013
M0027
T0175
M0174
M0014

5-2
5. Exploded View & Part List
5-1-2. LN32A650A1F Parts List
Location No. Code No. Description & Specification Q’ty S.A/S.N.A Remark
T0003 BN96-06840B ASSY COVER P-FRONT;32,L650A,UO,,PC(CLEAR 1 S.A
M0215 BN07-00537A LCD-PANEL;LTF320HA02 1 S.A
T0447 BN96-04681N ASSY BRACKET P-PANEL;32,L650,,,,,AMLCD,A 1 S.N.A
M0115 BN61-02947A BRACKET-STAND LINK;JASMINE 32”,SECC,T1.6 1 S.A
T0175 BN96-06818B ASSY SPEAKER P;8ohm,CORAL,L450,10W,4pin, 1 S.A
M0014 BN94-01666H ASSY PCB MAIN;LN32A650A1FXZA 1 S.A
M0013 BN96-06888B ASSY COVER P-REAR;32,L650,UO,PC+ABS,V0,B 1 S.A
M0027 BN96-07211B ASSY STAND P-BASE;32,L650,ABS+PMMA,HB,RD 1 S.A

5-3
5. Exploded View & Part List
5-2. LN40A650A1F Exploded View
T0003
M0215
T0447
M0115
T0175
M0146
M0174
T0175
M0115
T0101
M0254
M0014
M0013
M0027

5-4
5. Exploded View & Part List
5-1-2. LN40A650A1F Parts List
Location No. Code No. Description & Specification Q’ty S.A/S.N.A Remark
T0003 BN96-06842A ASSY COVER P-FRONT;40,L650A,UO,,PC(CLEAR 1 S.A
M0215 BN07-00529A LCD-PANEL;LTF400HC01 1 S.A
T0447 BN96-06883C ASSY BRACKET P-PANEL;40,L650,UO,,,,,GASK 1 S.N.A
T0175 BN96-06809A ASSY SPEAKER P;8ohm,P750 50”,Down Firing 1 S.A
M0146 BN61-03414A BRACKET-PANEL TOP;PEONY52,SECC T1.2 2 S.N.A
M0174 BN44-00198A IP BOARD;SIP40D,PEARL,15mA,130mA,150Hz,2 1 S.A
M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
T0101 BN61-03348A BRACKET-WALL;LCD TV 32,SECC T1.2,-,-,-,- 2 S.N.A
M0254 BN61-02875N HOLDER-SIDE AV;40,L650,UO,PC+ABS,V0,-,-, 1 S.N.A
M0014 BN94-01666G ASSY PCB MAIN;LN40A650A1FXZA 1 S.A
M0013 BN96-06890A ASSY COVER P-REAR;40,L650A,UO,,PC+ABS,V0 1 S.A
M0027 BN96-06259B ASSY STAND P-BASE;40AA1,ABS+PMMA,HB,RD02 1 S.A

5-5
5. Exploded View & Part List
5-3. LN46A650A1F Exploded View
T0003
M0215
T0447
M0115
H/WLEFT
T0175
T0175
M0254
H/WRIGHT
M0014
M0174
M0146
T0175
M0013
M0027

5-6
5. Exploded View & Part List
5-3-1. LN46A650A1F Parts List
Location No. Code No. Description & Specification Q’ty S.A/S.N.A Remark
T0003 BN96-06844A ASSY COVER P-FRONT;46,L650A,UO,,PC(CLEAR 1 S.A
M0215 BN07-00530A LCD-PANEL;LTF460HE01 1 S.A
T0447 BN96-06885D ASSY BRACKET P-PANEL;46,L650,UO,GASKET 1 S.N.A
M0115 BN61-03790A BRACKET-STAND LINK;AMBER 46,SECC,T1.6,-, 1 S.N.A
H/WLEFT BN61-03788A HOLDER-WALL LEFT;L650 46,HIPS V0,BK500,L 1 S.N.A
T0175 BN96-06809A ASSY SPEAKER P;8ohm,P750 50”,Down Firing 1 S.A
M0174 BN44-00203A IP BOARD;SIP468A,PEARL,15mA,135mA,150Hz, 1 S.A
T0175 BN96-06809A ASSY SPEAKER P;8ohm,P750 50”,Down Firing 1 S.N.A
H/WRIGHT BN61-03864A HOLDER-WALL RIGHT;L650 46,HIPS V0,BK500, 1 S.A
M0254 BN61-03606B HOLDER-SIDE AV;46,L650,UO,PC+ABS,V0,BK25 1 S.A
M0146 BN61-03415A BRACKET-PANEL TOP;PEONY 46,SECC T1.2 1 S.N.A
M0013 BN96-06892A ASSY COVER P-REAR;46,L650A,UO,,PC+ABS,V0 1 S.A
M0027 BN96-06873A ASSY STAND P-BASE;46,L650A,,ABS+PMMA,HB, 1 S.A

5-7
5. Exploded View & Part List
5-4. LN52A650A1F Exploded View
T0003
M0215
T0447
H/WLEFT
T0175
M0174
M0146
T0603
M0013
M0027
T0175
M0254
M0014
B/GMAIN
H/WRIGHT

5-8
5. Exploded View & Part List
5-4-1. LN52A650A1F Parts List
Location No. Code No. Description & Specification Q’ty S.A/S.N.A Remark
T0003 BN96-06845A ASSY COVER P-FRONT;52,L650A,UO,,PC(CLEAR 1 S.A
M0215 BN07-00531A LCD-PANEL;LTF520HE01 1 S.A
T0447 BN96-06887C ASSY BRACKET P-PANEL;52,L650A,UO,AMBER,G 1 S.N.A
M0174 BN44-00201A IP BOARD;SIP528A,PEARL,15mA,150mA,150Hz, 1 S.A
T0175 BN96-06809D ASSY SPEAKER P;8ohm,Amber,LCD 52”,10W,4p 1 S.A
M0254 BN61-02875N HOLDER-SIDE AV;40,L650,UO,PC+ABS,V0,-,-, 1 S.A
M0014 BN94-01666E ASSY PCB MAIN;LN52A650A1FXZA 1 S.A
M0146 BN61-03056A BRACKET-PANEL TOP;TULIP52,SECC,T1.2 4 S.N.A
M0013 BN96-06893A ASSY COVER P-REAR;52,L650A,UO,,PC+ABS,V0 1 S.A
M0027 BN96-06875A ASSY STAND P-BASE;52,L650A,,ABS+PMMA,HB, 1 S.A

5-9
5. Exploded View & Part List
5-5. LN32A650A1F Parts List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
LN40A650A1FXZC LN40A650A1F,N47A/40AA1-GAM,40,LCD-TV,CAN
0.1 M0001 BN90-01521A ASSY COVER FRONT;40,L650A,UO,,,,AMBER 1 S.N.A
..2 T0175 BN96-06809A ASSY SPEAKER P;8ohm,L650 40”/46”,Down Fi 1 S.A
..2 T0003 BN96-06842A ASSY COVER P-FRONT;40,L650A,UO,,PC(CLEAR 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.A
...3 CCM1 BN63-02183H COVER-SHEET;Rhcm,PE Vinyl,T0.05,1300mm,2 0.7 S.N.A
...3 M0112 BN63-04141A COVER-FRONT;40,L650A,UO,PC(CLR)+PC(ROSE 1 S.N.A
...3 A/HBBOTTOM BN96-06849B ASSY HOLDER P-BOSS BOTTOM;40,L650A,,ABS, 1 S.N.A
....4 A/HBB BN61-03261N BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.9 S.N.A
....4 H/BBOTTOM BN61-03808B HOLDER-BOSS BOTTOM;40,L650,ABS,V0,WH12,A 1 S.N.A
....4 BN61-03261S BOSS-TAPE;AMBER,ACRYL,T1.1,W20.0mm,WHITE 0.059 S.N.A
...3 A/HBTOP BN96-06850B ASSY HOLDER P-BOSS TOP;40,L650A,,ABS,V0( 1 S.N.A
....4 A/HBB BN61-03261K BOSS-TAPE;AMBER,ACRYL,T1.1,W8.0mm,WHITE, 1 S.N.A
....4 H/BTOP BN61-03809B HOLDER-BOSS TOP;40,L650,ABS,V0,WH12,AMBE 1 S.N.A
....4 A/HBB BN61-03261R BOSS-TAPE;AMBER,ACRYL,T1.1,W16.0mm,WHITE 0.05 S.N.A
...3 F/C BN96-07656A ASSY HOLDER P-BOSS SIDE;40,L650,,PC V1 R 2 S.N.A
....4 BN61-03261H BOSS-TAPE;Tulip,ACRYL,T1.1,W8.0mm,GRAY,T 0.07 S.N.A
....4 BN61-04079A HOLDER-BOSS SIDE;40,L650,PC+ABS,V0,-,-,- 1 S.N.A
...3 M0175 BN96-07244B ASSY BOARD P-TOUCH FUNCTION&IR;LN46A650A 1 S.A
...3 T0069 BN60-00092A SPACER-FELT;40A650,890*,T0.5,W21* 2 S.N.A
...3 T0069 BN60-00098A SPACER-FELT;40A650,L502*,T0.5,W28* 2 S.N.A
...3 CCM1 BN63-04755A COVER-SHEET;AMBER,PE,T0.05,W150mm,200M,6 3.8 S.N.A
0.1 M0002 BN90-01526A ASSY COVER REAR;40,L650A,UO,,,,AMBER 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 11 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 1 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 1 S.A
..2 M0013 BN96-06890A ASSY COVER P-REAR;40,L650A,UO,,PC+ABS,V0 1 S.A
...3 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.A
...3 T0069 AA60-00091J SPACER-FELT;-,FELT,330X10,-,-,BLK,T0.5,- 2 S.N.A
...3 T0101 BN61-03348A BRACKET-WALL;LCD TV 32,SECC T1.2,-,-,-,- 2 S.N.A
...3 CCM1 BN63-02183G COVER-SHEET;Rhcm,PE Vinyl,T0.05,1100mm,2 0.99 S.N.A
...3 M0006 BN63-04301A COVER-REAR;40,L650A,UO,PC+ABS,-,-,-,V0,- 1 S.N.A
...3 T0071 BN64-00807B INLAY-TERMINAL;L650,UO,PS SHEET,T0.3,-,- 1 S.N.A
...3 T0064 BN65-00002A CLAMPER CORE;BORDEAUX,LDPE,-,-,BLK,- 1 S.N.A
0.1 M0216 BN90-01531A ASSY STAND;40,L650A,,,RD02,AMBER 1 S.N.A
..2 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
..2 M0027 BN96-06259B ASSY STAND P-BASE;40AA1,ABS+PMMA,HB,RD02 1 S.A
...3 T0081 6002-001294 SCREW-TAPPING;BH,+,,M4,L16,ZPC(BLK) 4 S.A
...3 M0081 6003-001239 SCREW-TAPTITE;FH,+,-,B,M4,L10,ZPC(WHT),S 8 S.A
...3 H/WRTOP BN61-02248A HOLDER-SWIVEL RING;40R71,ACETAL NATUAL,T 1 S.N.A
...3 B/SBOTTOM BN61-02883A BRACKET-STAND BOTTOM;BORDEAUX PLUS,40,SE 1 S.N.A
...3 H/SRBOTTOM BN61-02885A HOLDER-SWIVEL RING;MURANO40,ACETAL NATUR 1 S.N.A
...3 B/HINGE BN61-02886A BRACKET-HINGE SWIVEL;BORDEAUX PLUS,40,SE 1 S.N.A

5-10
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
...3 T0920 BN61-03681A GUIDE-STAND;40L450,PC+GF 20%,-,-,-,BK500 1 S.N.A
...3 CCM1 BN63-02183E COVER-SHEET;Rhcm,PE Vinyl,T0.05,750mm,20 0.5 S.N.A
...3 T0004 BN63-03030C COVER-STAND BASE;40AA1,ABS+PMMA,HB,RD02, 1 S.N.A
...3 M0126 BN73-00052C RUBBER-FOOT;LCD TV,CR RUBBER,T2.0 DIA19, 4 S.N.A
0.1 A/SHIELD BN91-02039A ASSY SHIELD-SQD;LN40A650A1FXZA,AMLCD, N4 1 S.N.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 5 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 6 S.A
..2 M0081 6003-000115 SCREW-TAPTITE;BH,+,B,M3,L6,ZPC(BLK),SWRC 7 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 3 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 1 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 1 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 2 S.A
..2 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 2 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 1 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 5 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.A
..2 M0081 6003-001188 SCREW-TAPTITE;BH,+,-,B,M4,L10,ZPC(WHT),S 2 S.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 2 S.N.A
..2 M0081 6003-001439 SCREW-TAPTITE;BH,+,-,S,M4,L8,ZPC(WHT),SW 1 S.N.A
..2 M2893 BN39-00674A LEAD CONNECTOR;LNR469DX/XAA,UL1007#26,5P 1 S.A
..2 M2893 BN39-00802F LEAD CONNECTOR;LE46S86BDX,UL1007#26,24PI 1 S.A
..2 M2893 BN39-00830C LEAD CONNECTOR;LN40A450C1D,UL3443 #28,7P 1 S.A
..2 M2893 BN39-01024A LEAD CONNECTOR;LN46A550P1FXZA,UL1007#26, 1 S.A
..2 M0174 BN44-00198A IP BOARD;SIP40D,PEARL,15mA,130mA,150Hz,2 1 S.A
..2 M0114 BN61-02500A HOLDER-WIRE;NYLON6.6,NATURAL 1 S.N.A
..2 M0254 BN61-02875N HOLDER-SIDE AV;40,L650,UO,PC+ABS,V0,-,-, 1 S.N.A
..2 M0115 BN61-02882A BRACKET-STAND LINK;TULIP,40,SECC,T1.6,-, 1 S.N.A
..2 M0146 BN61-03414A BRACKET-PANEL TOP;PEONY52,SECC T1.2 2 S.N.A
..2 M0214 BN96-07161G ASSY CABLE P-FLAT LVDS;LN40A650A1FXZA,FF 1 S.A
..2 M0114 BP61-01088A HOLDER-WIRE;SVP-42L6,NYLON 2 S.N.A
..2 T0066 BN62-00036A HEAT SINK-ES;AMBER,A6063,T1.0,40*40*15,B 1 S.N.A
..2 M0125 BN96-04817B ASSY INLET P;LNT4081FX,XAA,250mm,250mm,- 1 S.A
..2 T0136 BN31-00014C FAN;G6015S12B2-DA-OC,AMBER,PBTP 1 S.A
..2 T0562 6046-001013 STAND OFF;M3,L5,Ni PLT,SUM24L,#4-40 2 S.N.A
..2 T0447 BN96-06883C ASSY BRACKET P-PANEL;40,L650,UO,,,,,GASK 1 S.N.A
...3 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 1 S.A
...3 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 1 S.A
...3 M0081 6003-000337 SCREW-TAPTITE;BH,+,S,M4,L10,ZPC(BLK),SWR 2 S.A
...3 M0131 AA63-01438A GASKET;Bordeaux,Conductive Fabric,7mm,8m 1 S.N.A
...3 BN61-02879A BRACKET-GUIDE MAIN;TULIP,40,GPSP,T1.2 1 S.N.A
...3 BN61-02880A BRACKET-GUIDE POWER R;TULIP,40,gpsp,T1.2 1 S.N.A
...3 BN61-03831A BRACKET-GUIDE POWER L;AMBER 40,SECC,T1.2 1 S.N.A
...3 BN61-03835A BRACKET-GUIDE POWER R;AMBER 40,SECC,T1.2 1 S.N.A
...3 BN61-03861A BRACKET-PANEL BOTTOM;L450 40INCH,GPSP,T1 1 S.N.A
...3 M0131 BN63-03519A GASKET;Tulip,Conductive Fabric,14mm,10mm 3 S.N.A
..2 T0175 BN96-07193F ASSY SHIELD P-PCB MAIN;40,L650,UO,SECC,T 1 S.N.A
...3 AA63-01388A GASKET-EMI,SPONGE;SP-P300M,Conductive Fa 2 S.N.A
...3 M0131 BN63-02627A GASKET;Oxford,Conductive Fabric,8,13,30, 1 S.N.A
...3 M0131 BN63-03480A GASKET;LNT4642HX/XAA,Polyurethane Foam,1 2 S.N.A

5-11
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
...3 T0603 BN63-04303A SHIELD-PCB MAIN;AMBER 40,SECC,T0.5,-,-,- 1 S.N.A
..2 M0523 BN96-08176A ASSY BRACKET P-WALL;L650 40,SECC,T1.0 1 S.N.A
...3 T0069 AA63-60131A SPACER-FELT;SVP403J,FELT,-,-,-,BLK,T0.5, 1 S.N.A
...3 T0101 BN61-03834A BRACKET-WALL;AMBER 40,SECC,T1.2,-,-,-,- 1 S.N.A
0.1 M0017 BN91-02042C ASSY CHASSIS;LN40A650A1FXZA,N47A 1 S.N.A
..2 M0014 BN94-01666G ASSY PCB MAIN;LN40A650A1FXZA 1 S.A
...3 T0245 0202-001608 SOLDER-WIRE FLUX;LFC7-107,D0.8,99.3Sn/0. 0.25 S.N.A
...3 X1001 2801-004732 CRYSTAL-UNIT;27MHz,30ppm,28-AAM,12pF,30o 1 S.A
...3 CN401 3701-001294 CONNECTOR-DSUB;15P,3R,FEMALE,STRAIGHT,AU 1 S.A
...3 CN503B 3701-001388 CONNECTOR-HDMI;20P,Phosphor Bronze,ANGLE 1 S.A
...3 CN906 3707-001081 CONNECTOR-OPTICAL;STRAIGHT,SPDIF 1 S.A
...3 CN330 3711-000058 HEADER-BOARD TO CABLE;BOX,4P,1R,2.5MM,AN 1 S.A
...3 CN330 3711-004484 HEADER-BOARD TO CABLE;BOX,5P,1R,2mm,STRA 1 S.A
...3 CN330 3711-004531 HEADER-BOARD TO CABLE;BOX,10P,1R,2mm,ANG 1 S.A
...3 CN330 3711-005842 HEADER-BOARD TO CABLE;BOX,24P,2R,2MM,STR 1 S.A
...3 JA330 3722-000143 JACK-PHONE;1P(VER),AG,BLK,ANGLE 1 S.A
...3 JA330 3722-001061 JACK-PHONE;1P,3.6PI,AG,BLK,N 1 S.A
...3 CN303B 3722-002275 JACK-DIN;4P,-,SN,BLK,- 1 S.A
...3 U1601 3722-002426 JACK-MODULAR;8P/8C,-,N,STRAIGHT,GRN/YEL, 1 S.A
...3 CN501B 3722-002546 JACK-USB;4P/1C,AU,BLK,ANGLE,A type 1 S.N.A
...3 JA333 3722-002697 JACK-PIN;14P+1P(Shield+Gnd),NI,BLACK,STR 1 S.A
...3 JA333 3722-002728 JACK-PIN;3P, SHIELD,Ni,RED/WHT/YEL,ANGLE 1 S.A
...3 CIS3 AA40-00177A TUNER;TDQU6-K01A,TDQU6-K01A,NTSC/ATSC,18 1 S.A
...3 T0066 BN62-00003A HEAT SINK-ES;NK,SUN,A6063S,T2.5,W28,L28, 1 S.N.A
...3 T0174 BN97-02044J ASSY SMD;LN40A650A1FXZA 1 S.N.A
....4 SUB05 0202-001477 SOLDER-CREAM;LST309-M,-,D20~45um,96.5Sn/ 3.253 S.N.A
....4 D101 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D105 0401-000133 DIODE-SWITCHING;RLS4148,75V,150mA,LL-34, 1 S.A
....4 D1601 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1602 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1603 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1604 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1605 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D413 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D417 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D418 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D421 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D423 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D424 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D451 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D452 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D457 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D464 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D507 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D508 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D509 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D510 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D511 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D512 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D513 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A

5-12
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....4 D514 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D515 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D516 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D701 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D801 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D802 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D803 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D804 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D805 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D806 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D807 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D813 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D814 0401-001056 DIODE-SWITCHING;MMBD4148SE,100V,200mA,SO 1 S.A
....4 D1503 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D1504 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D1505 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D1506 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D1510 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D1511 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D1512 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D1513 0401-001099 DIODE-SWITCHING;1N4148WS,75V,150mA,SOD-3 1 S.A
....4 D0254 0402-000553 DIODE-SCHOTTKY;SS24/B240,40V,2000mA,DO-2 1 S.A
....4 D103 0402-001098 DIODE-RECTIFIER;SK34,40V,3A,SMC,TP 1 S.A
....4 D1501 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D440 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D441 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D442 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D517 0403-000002 DIODE-ZENER;VLZ5V6B,5.45/5.73V,500mW,SOD 1 S.A
....4 D404 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D405 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D406 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D502 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D504 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D505 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D811 0403-000771 DIODE-ZENER;VLZ6V2B,5.96-6.27V,500mW,SOD 1 S.A
....4 D204 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D207 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D208 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D209 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D210 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D211 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D212 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D213 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D214 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D215 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D216 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D218 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D219 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D220 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D221 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D222 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A

5-13
5. Exploded View & Part List
Level Location No. Code No. Description & Specification Q’ty SA/SNA Remark
....4 D223 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D224 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D225 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D226 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D227 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D228 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D229 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D230 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D231 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D232 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D233 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D234 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D235 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D236 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D237 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D303B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D304B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D307B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D308B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D309B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D310B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D312B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D313B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D314B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D315B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D316B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D317B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D318B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D319B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D320B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D321B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D322B 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D407 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D411 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D412 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D443 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D444 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D445 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D446 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D447 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D448 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D449 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D450 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D458 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D465 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D506 0403-001052 DIODE-ZENER;RD8.2MB,7.7-8.7V,200mW,SOT-2 1 S.A
....4 D1514 0403-001174 DIODE-ZENER;VLZ8V2B,7.78-8.19V,500mW,SOD 1 S.A
....4 D702 0403-001425 DIODE-ZENER;BZX84C33,31-35V,350mW,SOT-23 1 S.A
....4 D205 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D206 0406-001172 DIODE-TVS;CDS3C30GTH,48/-/50V,SMD 1 S.A
....4 D501 0406-001181 DIODE-TVS;NUP4201MR6,6/-/-V,500W,TSOP-6 1 S.A
