Samsung QN Q65FNF Series User manual

QLED TV
SERVICEManual
QLED TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
QN**Q65FNF
Project QNQ6FS
Chassis : QWY80
Model : QN49Q65FNF
QN55Q65FNF
QN65Q65FNF
QN75Q65FNF
QN82Q65FNF

Contents
1. Precautions....................................................................................................................... 1-1
1-1. Safety Precautions .......................................................................................................................1-1
1-1-1. Warnings.............................................................................................................................1-1
1-1-2. Servicing the LED TV........................................................................................................1-1
1-1-3. Fire and Shock Hazard......................................................................................................1-1
1-1-4. Product Safety Notices.................................................................................................... 1-2
1-2. Servicing Precautions................................................................................................................. 1-3
1-2-1. General Servicing Precautions ...................................................................................... 1-3
1-3. Static Electricity Precautions .................................................................................................... 1-4
1-4. Installation Precautions............................................................................................................. 1-5
2. Product Specications .................................................................................................... 2-1
2-1. Product information.....................................................................................................................2-1
2-2. Product specication.................................................................................................................. 2-3
2-3. Accessories................................................................................................................................2-26
2-4. Viewing the Functions.............................................................................................................. 2-27
2-4-1. 2018' Concept......................................................................................................2-27
2-4-2. Quick Guides..................................................................................................................2-30
2-4-3. The Samsung Smart Remote ......................................................................................2-34
3. Disassembly and Reassemble........................................................................................ 3-1
3-1. Disassembly ................................................................................................................................. 3-1
4. Troubleshooting .............................................................................................................. 4-1
4-1. Power............................................................................................................................................. 4-1
4-1-1. TV POWER STANDBY....................................................................................................... 4-1
4-1-2. TV POWER ON SEQUENCE .............................................................................................4-6
4-1-3. SMPS / PANEL BACKLIGHT (Parallel Wired SMPS Panel Connections) ................4-10
4-1-4. Additional Option Backlight Test................................................................................ 4-13
4-1-5. FUNCTION Control Test ................................................................................................ 4-14
4-2. Video ........................................................................................................................................... 4-15
4-2-1. Customer Picture Test................................................................................................... 4-15
4-2-2. Check Test Patterns...................................................................................................... 4-16
4-2-3. MAIN/T-CON BOARD.................................................................................................... 4-17
4-3. Audio.......................................................................................................................................... 4-20
4-4. Network...................................................................................................................................... 4-21
4-5. Smart Hub ..................................................................................................................................4-22
4-6. Bluetooth / WiFi Module..........................................................................................................4-24
4-7. Factory Mode..............................................................................................................................4-26
4-8. Factory Mode Adjustments.....................................................................................................4-32
4-8-1. Entering Factory Mode .................................................................................................4-32
4-8-2. Detail Factory Option...................................................................................................4-33
4-8-3. Factory Data...................................................................................................................4-38

4-9. AV Control Tabe ......................................................................................................................... 4-51
4-10. Updating the TV’s Software...................................................................................................4-58
4-10-1. Updating the TV’s software to the latest version...................................................4-58
4-10-2. Updating the TV automatically.................................................................................4-58
5. Wiring Diagram................................................................................................................ 5-1
5-1. Wiring Diagram.............................................................................................................................5-1
5-2. Connector.....................................................................................................................................5-6
5-2-1. Main Board........................................................................................................................5-6
5-2-2. SMPS Board.....................................................................................................................5-11
ANNEX. Exploded View & Part List [QN49Q65FNFXZA FA01] ...............................ANNEX-1
1-1. Exploded View....................................................................................................................ANNEX-1
1-1-1. Parts List ..................................................................................................................ANNEX-1
2-1. Electrical Parts List...........................................................................................................ANNEX-2
ANNEX. Exploded View & Part List [QN55Q65FNFXZA FA01] ...............................ANNEX-1
1-1. Exploded View....................................................................................................................ANNEX-1
1-1-1. Parts List ..................................................................................................................ANNEX-1
2-1. Electrical Parts List...........................................................................................................ANNEX-2
ANNEX. Exploded View & Part List [QN65Q65FNFXZA FA01] ...............................ANNEX-1
1-1. Exploded View....................................................................................................................ANNEX-1
1-1-1. Parts List ..................................................................................................................ANNEX-1
2-1. Electrical Parts List...........................................................................................................ANNEX-2
ANNEX. Exploded View & Part List [QN75Q65FNFXZA AA01] ...............................ANNEX-1
1-1. Exploded View....................................................................................................................ANNEX-1
1-1-1. Parts List ..................................................................................................................ANNEX-1
2-1. Electrical Parts List...........................................................................................................ANNEX-2
ANNEX. Exploded View & Part List [QN82Q65FNFXZA FA01] ...............................ANNEX-1
1-1. Exploded View....................................................................................................................ANNEX-1
1-1-1. Parts List ..................................................................................................................ANNEX-1
2-1. Electrical Parts List...........................................................................................................ANNEX-2

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished underapplicable
International and/or domestic law.
© 2018 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

1. Precautions
1-1. Safety Precautions
Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
Forcontinued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
When servicing the LED TV, Disconnect the AC line cord from the AC outlet.1.
It is essential that service technicians have an accurate voltage meteravailable at all times. Check the calibration of2.
this meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitorto the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the1.
chassis and other metal parts in the monitor.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and2.
compartment covers orshields, isolation resistorcapacitornetworks, mechanical insulators, etc.
Leakage Current Hot Check:3.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL EXPOSED
METAL SURFACES
2-WIRE CORD
ALSO TESTWITH PLUG
REVERSED (USING AC
ADAPTER PLUG AS
REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current testeror a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch4.
rst in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit,
etc.) and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from
visual inspection. The protection they give may not be obtained by replacing them with components rated forhigher
voltage, wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists.
A substitute replacement that does not have the same safety characteristics as the recommended replacement part
might create shock, re and/or other hazards. Product safety is under review continuously and new instructions are
issued whenever appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
Always unplug the unit’s AC power cord from the AC powersource and disconnect the DC PowerJack before attempting1.
to: (a) remove orreinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect a test
component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube ortape is sometimes used.2.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such
elements to theiroriginal position.
Afterservicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that3.
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input4.
terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect5.
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greaterthan 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;6.
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-eect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your1.
body by touching a known earth ground. Alternatively, weara discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
Afterremoving an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent2.
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.3.
Use only a grounded-tip soldering iron to solder or desolderESDs.4.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate 5.
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs6.
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil orother conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective7.
material to the chassis orcircuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or8.
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

Forsafety reasons, more than a people are required for carrying the product.1.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.2.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal3.
temperature may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed4.
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power o and unplug the power cord from the outlet before repositioning the product. Also check 5.
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the 6.
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (0.4m) between the product and the wall forventilation purposes.7.
A rise in temperature within the product may cause re.
If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an8.
explosion (for example, with some lithium batteries), the following applies:
CAUTION
Risk of explosion if battery is replaced by an incorrect type dispose of used batteries according•
to the instructions.
Do not dispose of batteries in a re.•
Do not short circuit, disassemble or overheat the batteries.•
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent•
type.
Do not be exposed to excessive heat such as sunshine, re or the like.•
1-5
1. Precautions
1-4. Installation Precautions

2-1
2. Product specications
2. Product Specications
2-1. Product information
Model QN**Q65FNF
Front View
W
* W : Width H : High D : Depth
H
D
Detail View
Color Front : CARBON SILVER / Stand : CARBON SILVER / Deco : CARBON SILVER
Dimensions
(W x H x D)
49"
Body 43.0 x 25.0 x 2.2 inches (1092.7 x 634.6 x 54.9 mm)
With Stand 43.0 x 27.7 x 9.8 inches (1092.7 x 703.3 x 247.7 mm)
55"
Body 48.3 x 28.0 x 2.2 inches (1227.1 x 710.7 x 54.9 mm)
With Stand 48.3 x 30.7 x 9.8 inches (1227.1 x 779.2 x 247.7 mm)
65" Body 56.9 x 32.8 x 2.2 inches (1446.3 x 833.8 x 54.9 mm)
With Stand 56.9 x 35.8 x 11.1 inches (1446.3 x 909.4 x 285.7 mm)
75" Body 65.9 x 38.0 x 2.3 inches (1673.8 x 964.1 x 57.6 mm)
With Stand 65.9 x 41.3 x 14.1 inches (1673.8 x 1048.3 x 359.1mm)
82" Body 72.0 x 41.5 x 2.4 inches (1830.0 x 1054.0 x 60.9 mm)
With Stand 72.0 x 45.1 x 15.2 inches (1830.0 x 1144.6 x 387.3 mm)

2-2
2. Product specications
Model QN**Q65FNF
Weight
49"
Without Stand 29.5 lbs (13.4 kg)
With Stand 30.6 lbs (13.9 kg)
55"
Without Stand 37.9 lbs (17.2 kg)
With Stand 39.0 lbs (17.7 kg)
65" Without Stand 53.4 lbs (24.2 kg)
With Stand 54.7 lbs (24.8 kg)
75" Without Stand 79.4 lbs (36.0 kg)
With Stand 81.1 lbs (36.8 kg)
82" Body 98.1 lbs (44.5 kg)
With Stand 100.8 lbs (45.7 kg)

2-3
2. Product specications
2-2. Product specication
NOTE
Design and specications are subject to change without prior notice.
Last Update Date : 2018.04.02
Item QN49Q65FNFXZA
General Information Product QLED
Cabinet Basic Code Q49NS2
Series Q
Country UNITED STATES
Tools Support N/A
Platform(TV) SoC | Kant-M2
Display Inch 49
Real Inch 48.5
Real cm 123
Resolution 3,840 x 2,160
Screen Curvature N/A
10bit Support N/A
Ultra Black N/A
Video Picture Engine Q Engine
Motion Rate 240 (*49":120)
PQI (Picture Quality Index) "2800
(*49"": 2600)"
HDR (High Dynamic Range) Q HDR Elite
HDR10+ Yes
HLG (Hybrid Log Gamma) Yes
Contrast Q Constrast
Color Q Color
Viewing Angle N/A
Micro Dimming Supreme UHD Dimming
Local Dimming Ultra Slim Array
Auto Depth Enhancer N/A
Contrast Enhancer Yes
Auto Motion Plus Yes
Film Mode Yes
Picture HDMI Black Level
Response Time 6ms
Viewing Angle (H/V) 89/89
Natural Mode Support Yes
Audio Dolby Digital Plus Yes

2-4
2. Product specications
Item QN49Q65FNFXZA
Audio DTS Codec N/A
Harman Sound N/A
Hole Array Speaker N/A
Sound Output (RMS) 40W
Speaker Type 4.1CH
Woofer Yes
Main Speaker Output (W) 7W+7W
Woofer Speaker Output (W) 14W
Twitter Speaker Output (W) 7W+7W
Multiroom Link Yes
Bluetooth Audio Yes
Smart Service Smart TV Type Smart
Bixby US English
Voice Interaction US English, Spanish, French, German,
Italian, Brazilian Portuguese, Korean
TV Plus Yes(US only, Channel)
Web Browser Yes
SmartThings App Support Yes
SmartThings Yes
Smart View N/A,N/A.0
Universal Guide YES (US Only)
Gallery Yes
VESA Standard Screw Size M8
Screw depth 43-45
VESA Spec 200 x 200
Smart Feature TV to Mobile - Mirroring Yes
Mobile to TV - Mirroring, DLNA Yes
360 Video Player Yes
360 Camera Support Yes
Together play Yes
Easy Setup Yes
App Casting Yes
Wireless TV On - Samsung WOL Yes
Wired TV On - Samsung WOL Yes
Bluetooth Low Energy Yes
WiFi Direct Yes
TV Sound to Mobile Yes
Sound Mirroring N/A
Localization S-Share N/A

2-5
2. Product specications
Item QN49Q65FNFXZA
Localization Dongle Compatibility (3G / LTE / WiFi) N/A
Analog Clean View N/A
Senior mode N/A
Clean View N/A
Family TV 2.0 N/A
Local Cinema Mode N/A
Triple Protection N/A
Feature AI Technology N/A
Art Mode (The Frame) N/A
Motion Detection (The Frame) N/A
Ambient Mode Yes
IMAX N/A
Instant On Yes
Processor Quad-Core
Accessibility
Learn menu screen(US English)/
SeeColors/ Negative colors/ Grayscale/
Voice Guide(US English)/ Enlarge/ High
Contrast/ Learn TV Remote(US English)/
Multi-output Audio
Digital Clean View Yes
Ultra Clean View N/A
Auto Channel Search Yes
Auto Power O Yes
Caption (Subtitle) Yes
ConnectShare™ (HDD) Yes
ConnectShare™ (USB 2.0) Yes
Embeded POP Yes
EPG Yes
Extended PVR N/A
Game Mode Yes(Game Motion Plus)
OSD Language English, Spanish, French
Picture-In-Picture N/A
BT HID Support Yes
USB HID Support Yes
Teletext (TTX) N/A
Time Shift Yes
Invisible Connection N/A
V-Chip Yes
MBR Support Yes,Yes.0
IPv6 Support Yes,Yes.0

2-6
2. Product specications
Item QN49Q65FNFXZA
Feature Gigabit N/A
Additional Feature - -
System Digital Broadcasting ATSC/ClearQAM
DTV Sound System Dolby
Analog Tuner Yes
Analog Tuner Type NTSC 3.58,NTSC 4.43, VIT
2 Tuner N/A
CI (Common Interface) N/A
Data Broadcasting N/A
ATV Sound System M
Tuner Vendor & Model CNXG(Xuguang) | GVTH-7A21
TV Key N/A
Core Component DDR SDRAM Samsung
Flash Memory EMMC | 8GB
Serial Flash Memory WINBOND
HDMI Switch N/A
Display Device Vender SDC
Connectivity HDMI 4
Resolution 3840 x 2160
DVI Support Port ALL
MHL Support Port N/A
USB 2
Port 1 Type 2.0
Port 2 Type 2.0
Port 3 Type N/A
Port 4 Type N/A
Port 5 Type N/A
Component In (Y/Pb/Pr) N/A
Composite In (AV) N/A
Ethernet (LAN) Yes
Audio Out (Mini Jack / LR) N/A
Digital Audio Out (Optical) 1
RF In (Terrestrial / Cable input / Satellite Input) 1/1(Common Use for Terrestrial)/0
Ex-Link ( RS-232C ) 1
CI Slot N/A
Monitor Output N/A
DVI
Resolution N/A
D-Sub Resolution N/A | N/A

2-7
2. Product specications
Item QN49Q65FNFXZA
Connectivity HDMI A / Return Ch. Support Yes
HDMI Quick Switch Yes
Wireless LAN Adapter Support N/A
Wireless LAN Built-in Yes
Anynet+ (HDMI-CEC) Yes
Design Design Slim Design
Bezel Type 3 Bezel-less
Slim Type Slim
Front Color Carbon Silver
Light Eect (Deco) N/A
Stand Type Simple
Swivel (Left/Right) N/A
Eco Eco Sensor Yes
Power Power Supply (V) AC110-120V 50/60Hz
Power Consumption (Max) (W) PR Check
Power Consumption (Energy Saving Mode) (W) N/A
Power Consumption (Stand-by) (W) PR Check
Power Consumption (Typical) PR Check
Peak Luminance Ratio (%) N/A
Yearly Power Consumption (EU standard) (kWh) N/A
AC Input Power Freq. (Hz) 50/60Hz
SMPS/IP Board SoluM
Last Update Date : 2018.04.02
Item QN55Q65FNFXZA
General Information Product QLED
Cabinet Basic Code Q55NS2
Series Q
Country UNITED STATES
Tools Support N/A
Platform(TV) SoC | Kant-M2
Display Inch 55
Real Inch 54.6
Real cm 138
Resolution 3,840 x 2,160
Screen Curvature N/A
10bit Support N/A
Ultra Black N/A
Video Picture Engine Q Engine
Motion Rate 240 (*49":120)

2-8
2. Product specications
Item QN55Q65FNFXZA
Video PQI (Picture Quality Index) "2800
(*49"": 2600)"
HDR (High Dynamic Range) Q HDR Elite
HDR10+ Yes
HLG (Hybrid Log Gamma) Yes
Contrast Q Constrast
Color Q Color
Viewing Angle Wide Viewing Angle
Micro Dimming Supreme UHD Dimming
Local Dimming Ultra Slim Array
Auto Depth Enhancer N/A
Contrast Enhancer Yes
Auto Motion Plus Yes
Film Mode Yes
Picture HDMI Black Level
Response Time 6ms
Viewing Angle (H/V) 89/89
Natural Mode Support Yes
Audio Dolby Digital Plus Yes
DTS Codec N/A
Harman Sound N/A
Hole Array Speaker N/A
Sound Output (RMS) 40W
Speaker Type 4.1CH
Woofer Yes
Main Speaker Output (W) 7W+7W
Woofer Speaker Output (W) 14W
Twitter Speaker Output (W) 7W+7W
Multiroom Link Yes
Bluetooth Audio Yes
Smart Service Smart TV Type Smart
Bixby US English
Voice Interaction Spanish, French
TV Plus Yes(US only, Channel)
Web Browser Yes
SmartThings App Support Yes
SmartThings Yes
Smart View N/A
Universal Guide YES (US Only)

2-9
2. Product specications
Item QN55Q65FNFXZA
Smart Service Gallery Yes
VESA Standard Screw Size M8
Screw depth 43-45
VESA Spec 200 x 200
Smart Feature TV to Mobile - Mirroring Yes
Mobile to TV - Mirroring, DLNA Yes
360 Video Player Yes
360 Camera Support Yes
Together play Yes
Easy Setup Yes
App Casting Yes
Wireless TV On - Samsung WOL Yes
Wired TV On - Samsung WOL Yes
Bluetooth Low Energy Yes
WiFi Direct Yes
TV Sound to Mobile Yes
Sound Mirroring Yes
Localization S-Share N/A
Dongle Compatibility (3G / LTE / WiFi) N/A
Analog Clean View N/A
Senior mode N/A
Clean View N/A
Family TV 2.0 N/A
Local Cinema Mode N/A
Triple Protection N/A
Feature AI Technology N/A
Art Mode (The Frame) N/A
Motion Detection (The Frame) N/A
Ambient Mode Yes
IMAX N/A
Instant On Yes
Processor Quad-Core
Accessibility
Learn menu screen(US English)/
SeeColors/ Negative colors/ Grayscale/
Caption moving/ Voice Guide(US
English)/ Enlarge/ High Contrast/ Learn
TV Remote(US English)/ Multi-output
Audio
Digital Clean View Yes
Ultra Clean View N/A
Auto Channel Search Yes

2-10
2. Product specications
Item QN55Q65FNFXZA
Feature Auto Power O Yes
Caption (Subtitle) Yes
ConnectShare™ (HDD) Yes
ConnectShare™ (USB 2.0) Yes
Embeded POP Yes
EPG Yes
Extended PVR N/A
Game Mode Yes(Auto Game Mode, Game Motion Plus)
OSD Language English, Spanish, French
Picture-In-Picture N/A
BT HID Support Yes
USB HID Support Yes
Teletext (TTX) N/A
Time Shift N/A
Invisible Connection N/A
V-Chip Yes
MBR Support Yes
IPv6 Support Yes
Gigabit N/A
Additional Feature - -
System Digital Broadcasting ATSC/ClearQAM
DTV Sound System Dolby
Analog Tuner Yes
Analog Tuner Type NTSC 3.58,NTSC 4.43, VIT
2 Tuner N/A
CI (Common Interface) N/A
Data Broadcasting N/A
ATV Sound System M
Tuner Vendor & Model CNXG(Xuguang) | GVTH-7A21
TV Key N/A
Core Component DDR SDRAM Samsung
Flash Memory EMMC | 8GB
Serial Flash Memory WINBOND
HDMI Switch N/A
Display Device Vender SDC
Connectivity HDMI 4
Resolution 3840 x 2160
DVI Support Port ALL
MHL Support Port N/A

2-11
2. Product specications
Item QN55Q65FNFXZA
Connectivity USB 2
Port 1 Type 2.0
Port 2 Type 2.0
Port 3 Type N/A
Port 4 Type N/A
Port 5 Type N/A
Component In (Y/Pb/Pr) N/A
Composite In (AV) N/A
Ethernet (LAN) Yes
Audio Out (Mini Jack / LR) N/A
Digital Audio Out (Optical) 1
RF In (Terrestrial / Cable input / Satellite Input) 1/1(Common Use for Terrestrial)/0
Ex-Link ( RS-232C ) 1
CI Slot N/A
Monitor Output N/A
DVI
Resolution N/A
D-Sub Resolution N/A | N/A
HDMI A / Return Ch. Support Yes
HDMI Quick Switch Yes
Wireless LAN Adapter Support N/A
Wireless LAN Built-in Yes
Anynet+ (HDMI-CEC) Yes
Design Design Slim Design
Bezel Type 3 Bezel-less
Slim Type Slim
Front Color Carbon Silver
Light Eect (Deco) N/A
Stand Type Simple
Swivel (Left/Right) N/A
Eco Energy Efciency Class Yes
Eco Sensor Yes
Power Power Supply (V) AC110-120V 50/60Hz
Power Consumption (Max) (W) 145
Power Consumption (Energy Saving Mode) (W) N/A
Power Consumption (Stand-by) (W) 0.5
Power Consumption (Typical) 70
Peak Luminance Ratio (%) N/A
Yearly Power Consumption (EU standard) (kWh)N/A
