Samsung UE32H6200AW User manual

LED TV
SERVICEManual
LED TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UE**H6200AW
Chassis : U8DC
Model : UE32H6200AW
UE40H6200AW
UE48H6200AW
UE50H6200AW
UE55H6200AW
UE60H6200AW

Contents
1. Precautions...................................................................................................................1-1
1-1. Safety Precautions ..............................................................................................................1-1
1-1-1. Warnings...................................................................................................................1-1
1-1-2. Servicing the LED TV ...............................................................................................1-1
1-1-3. Fire and Shock Hazard.............................................................................................1-1
1-1-4. Product Safety Notices .............................................................................................1-2
1-2. Servicing Precautions..........................................................................................................1-3
1-2-1. General Servicing Precautions .................................................................................1-3
1-3. Static Electricity Precautions ...............................................................................................1-4
1-4. Installation Precautions .......................................................................................................1-5
2. Product Specications.................................................................................................2-1
2-1. Product information .............................................................................................................2-1
2-2. Product specication ...........................................................................................................2-3
2-2-1. Detailed Specications .............................................................................................2-3
2-2-2. Feature & Specications...........................................................................................2-7
2-3. Accessories .........................................................................................................................2-9
2-4. Viewing the Functions .......................................................................................................2-10
3. Disassembly and Reassembly ....................................................................................3-1
3-1. Disassembly and Reassembly ............................................................................................3-1
4. Troubleshooting ...........................................................................................................4-1
4-1. Troubleshooting ...................................................................................................................4-1
4-1-1. Previous Check ........................................................................................................4-1
4-1-2. Simple ow chart of malfunction...............................................................................4-3
4-2. How to Check Fault Symptom.............................................................................................4-4
4-2-1. NO Power .................................................................................................................4-4
4-3. Factory Mode Adjustments..................................................................................................4-7
4-3-1. Detail Factory Option................................................................................................4-7
4-3-2. Entering Factory Mode .............................................................................................4-9
4-3-3. Factory Data ...........................................................................................................4-10
4-4. White Balance ...................................................................................................................4-25
4-4-1. Calibration ..............................................................................................................4-25
4-4-2. Service Adjustment.................................................................................................4-25
4-4-3. Adjustment..............................................................................................................4-26
4-5. RS-232C............................................................................................................................4-27
4-6. AV Control Tabe.................................................................................................................4-28
4-7. Software Upgrade..............................................................................................................4-34
4-7-1. How to Check the Software Version .......................................................................4-34
4-7-2. How to Upgade Software........................................................................................4-35

5. Wiring Diagram.............................................................................................................5-1
5-1. Wiring Diagram....................................................................................................................5-1
5-2. Connector............................................................................................................................5-6
5-3. Connector Functions ...........................................................................................................5-9

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2014 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
When servicing the LED TV, Disconnect the AC line cord from the AC outlet.1.
It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this2.
meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the1.
chassis and other metal parts in the monitor.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and2.
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
Leakage Current Hot Check:3.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch rst 4.
in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.)
and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions
1. Precautions
1-1. Safety Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, re and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before1.
attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used.2.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements
to their original position.
After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that3.
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input4.
terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect5.
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greater than 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;6.
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your1.
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent2.
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.3.
Use only a grounded-tip soldering iron to solder or desolder ESDs.4.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate 5.
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs6.
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material7.
to the chassis or circuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or8.
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

For safety reasons, more than a people are required for carrying the product.1.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.2.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature3.
may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed4.
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check5.
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the 6.
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (0.4m) between the product and the wall for ventilation purposes.7.
A rise in temperature within the product may cause re.
If an equipment is provided with a replaceable battery, and if replacement by an incorrect type could result in an8.
explosion (for example, with some lithium batteries), the following applies:
CAUTION
Risk of explosion if battery is replaced by an incorrect type dispose of used batteries according to•
the instructions.
Do not dispose of batteries in a re.•
Do not short circuit, disassemble or overheat the batteries.•
Danger of explosion if battery is incorrectly replaced. Replace only with the same or equivalent•
type.
Do not be exposed to excessive heat such as sunshine, re or the like.•
1-5
1. Precautions
1-4. Installation Precautions

2-1
2. Product specications
2. Product Specications
2-1. Product information
Model UE**H6200AW
Front View
W
D
* W : Width H : High D : Depth
H
Detail View
Front Color Black
Dimensions
(W x H x D)
32"
Body 721.4 X 431.8 X 62.9 mm
With stand 721.4 X 501.6 X 264.8 mm
40"
Body 906.6 X 536.1 X 63.1 mm
With stand 906.6 X 604.9 X 264.8 mm
48"
Body 1075.1 X 630.9 X 63.5 mm
With stand 1075.1 X 711.2 X 306.9 mm
50"
Body 1116.8 X 654.4 X 63.7 mm
With stand 1116.8 X 733.5 X 306.9 mm
55"
Body 1230.6 X 718.4 X 64.0 mm
With stand 1230.6 X 800.0 X 306.9 mm
60"
Body 1365.0 X 797.4 X 64.4 mm
With stand 1365.0 X 874.4 X 306.9 mm

2-2
2. Product specications
Model UE**H6200AW
Weight
32"
Body 5.1 kg
With stand 6.1 kg
40"
Body 8.0 kg
With stand 9.1 kg
48"
Body 11.3 kg
With stand 12.9 kg
50"
Body 12.8 kg
With stand 14.4 kg
55"
Body 15.8 kg
With stand 17.4 kg
60"
Body 23.5 kg
With stand 25.5 kg
Panel Type Anti Glare
Internal Memory 4GB
DDR 1GB
Feature 2D, Smart Interaction

2-3
2. Product specications
2-2. Product specication
2-2-1. Detailed Specications
NOTE
Design and specications are subject to change without prior notice.
Item UE**H6200AWXXH
General Information Product LED
Series 6
Country HUNGARY
Display Inch 32" / 40" / 48" / 50" / 55" / 60"
Resolution 1,920 x 1,080
Ultra Clear Panel No
Video Picture Engine 3D HyperReal Engine
Clear Motion Rate 100
Micro Dimming No
Precision Black (Local Dimming) No
Wide Color Enhancer (Plus) Yes
Wide Color Gamut N/A
Color Accuracy N/A
Auto Depth Enhancer N/A
Film Mode Yes
Audio Dolby MS10 / MS110 Dolby MS10
DTS Studio Sound / DNSe+ DTS Studio Sound
DTS Premium Sound / DTS Premium Sound 5.1 DTS Premium Sound 5.1
3D Sound Yes
Auto Volume Leveler Yes
Sound Customizer No
Sound Output (RMS) 10W x 2
Speaker Type Down Firing + Full Range
Woofer No
HD Audio No
Smart TV Smart Hub Yes
Samsung SMART TV Yes
On TV Yes (15 European Countries)
Movies & TV Shows Yes (9 European Countries)
Multimedia Yes
Apps Yes
Game Yes (7 European Countries)
Fitness Yes

2-4
2. Product specications
Item UE**H6200AWXXH
Smart TV Kids Yes
Multi-Screen (Dual / Quad Screen) No
Skype™ on Samsung TV Yes
Web Browser Yes
Smart Interaction Voice Interaction No
Voice Control No
Camera Built-in No
Face recognition No
Motion control No
Smart Convergence Contents Streaming Yes
Screen Mirroring Yes
Samsung SMART View Yes
Smart Home Yes (FR,DE,SE)
Easy Pin pairing Yes
Tuner/Broadcasting Twin Tuner No
CI/CI+/2CI+ CI+ (1.3)
DTV Tuner DVB-T/C
Analog Tuner Yes
MHP / MHEG / HbbTV / ACAP / GINGA / OHTV HbbTV (ES,PT,FR,BE,NL,LU,CH,PL,CZ)
Connectivity HDMI 4
USB 3
Component In (Y/Pb/Pr) 1
Composite In (AV) 1 (Common Use for Component Y)
Ethernet (LAN) Yes
Headphone Yes
Digital Audio Out (Optical) 1
RF In (Terrestrial / Cable input) 1/1(Common Use for Terrestrial)/0
Ex-Link ( RS-232C ) N/A
IR Out Yes (15 European Countries)
CI Slot 1
Scart 1
MHL CE 3.0 No
One Connect (Jack) No
WiFi Direct Yes
HDMI 1.4 3D Auto Setting Yes
HDMI 1.4 A/Return Ch. Support Yes
InstaPort S (HDMI quick switch) No
Wireless LAN Adapter Support No

2-5
2. Product specications
Item UE**H6200AWXXH
Connectivity Wireless LAN Built-in Yes
Anynet+ (HDMI-CEC) Yes
Design Design Wavy Deco
Bezel Type VNB
Front Color Black
Light Effect (Deco) No
Stand Type Quad
Swivel (Left/Right) Yes
Additional Feature Samsung 3D Yes
3D Converter Yes
Instant On No
Quad Core+ No
Accessibility TTS, Zoom
Auto Power Off Yes
Clock&On/Off Timer Yes
Sleep Timer Yes
BD Wise Plus Yes
Caption (Subtitle) Yes
Channel List USB-Clone Yes
ConnectShare™ (USB 2.0) Yes
Football Mode Advanced
Embeded POP Yes
EPG Yes
PVR Ready Yes
Game Mode Yes
Multiroom Compatible No
OSD Language 27 European Languages
Picture-In-Picture Yes
BT HID Built-in Yes
USB HID Support Yes
Smart Evolution Support No
TV SoundConnect Yes
Teletext (TTXT) Yes
Time Shift Yes
Eco Feature Eco Sensor Yes
Energy Efciency Class A
Mercury Content 0.0mg
Lead Presence Yes

2-6
2. Product specications
Item UE**H6200AWXXH
Accessory 3D Active Glasses (Included) No
Remote Controller Model TM1250A
Batteries (for Remote Control) Yes
Samsung Smart Touch Control (Included) No
Ultra Slim Wall Mount Supported Yes
Mini Wall Mount Supported Yes
Vesa Wall Mount Supported Yes
Floor Stand Support Yes
TV Camera (Included) No
IR Extender Cable (Included) Yes
Wireless Keyboard (Included) No
Wireless LAN Adaptor (Included) No
User Manual Yes
E-Manual Yes
Power Cable Yes
Slim Gender Cable No

2-7
2. Product specications
2-2-2. Feature & Specications
Feature
Digital-TV, RF, 4-HDMI, 1-Component,1-A/V, 3-USB2.0(Media Play), LAN, WIFI•
PIP(in HDMI 1, 2, 3, 4 Component and Sub picture is available only in TV mode(DTV/ATV))•
CMR 240•
Dolby Digital Plus Pulse, DTS Premium Sound 5.1, DTS Studio Sond•
Specications
Model UE**H6200AW
Item Description
Screen Size (Diagonal) 32 inch 40 inch 48 inch 50 inch
LCD Panel FHD 120Hz
Scanning Frequency Horizontal : 31 kHz ~ 80 kHz
Vertical : 56 Hz ~ 75 Hz
Display Resolution 1920 X 1080
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock Rate 138 MHz
AC Power Voltage & Frequency AC 220-240V 50/60Hz
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage Temperature : -4˚F ~ 113˚F (-20˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Sound (Output) 10W X 2
Note : 2D/ SMART HUB / DLNA / Full browsing / SMART Interaction

2-8
2. Product specications
Model UE**H6200AW
Item Description
Screen Size (Diagonal) 55 inch 60 inch
LCD Panel FHD 120Hz
Scanning Frequency Horizontal : 31 kHz ~ 80 kHz
Vertical : 56 Hz ~ 75 Hz
Display Resolution 1920 X 1080
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock Rate 138 MHz
AC Power Voltage & Frequency AC 220-240V 50/60Hz
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage Temperature : -4˚F ~ 113˚F (-20˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Sound (Output) 10W X 2
Note : 2D/ SMART HUB / DLNA / Full browsing / SMART Interaction

2-9
2. Product specications
2-3. Accessories
NOTE
The items’ colors and shapes may vary depending on the model.•
Cables not included in the package contents can be purchased separately.•
The part code for some accessories may differ depending on your region.•
Product Code. No Product Code. No
Remote Control• BN59-01178B Power Cord• 3903-000849
Batteries (AAA x 2)• 4301-000121 User Manual• BN68-05804A
Image Product Code. No
CI Card Adapter• 3709-001791
Holder-Wire stand• BN61-08370A
IR Extender Cable• BN96-31644A

2-10
2. Product specications
2-4. Viewing the Functions
The Remote Control
{GGzTGGGG
U
kGGGG
GU
jGGGGU
iGG
zGo
G
UGyGGG
TtGS G
zGm 
G
eG
zGo
U
jGU
lGGU
kGG
lwn
GOlG
wGnPU
kGGGG{}G
 U
{ GG{}GGGU
nG GGGU
hGGU
kGGU
hGG{GvuG
kSGtGGvmmU
aGlG mGt GGG
GGGU
zlhyjo aGw GGGGG
GGU
rlwhk
aG~GGGG
GGGSGGG
GGSGGSG
GGU
lTthu|hs aGkGG Tt U
wU zpl aGjGGG¡U
hkVz|i{U
aGkGG
hG
z
U
yGGGG
U
vGGvzkGOtPU
xGGGG
U
yGGGGU
|GGGG
GGGGG{}G
U
|GGGGG
 UG|GGG
GGG GG
G{}GU
tGGSGGG
TGGSGG
GGGGG
G{}NGU

3-1
3. Disassembly and Reassemble
3. Disassembly and Reassembly
This section of the service manual describes the disassembly and reassembly procedures for the LED TV.
WARNING
This LED TV contains electrostatically sensitive devices. Use caution when handling these components.
3-1. Disassembly and Reassembly
CAUTION
Disconnect the LED TV from the power source before disassembly.1.
Follow these directions carefully; never use metal instruments to pry apart the cabinet.2.
If there is no additional coment, it is same for all inches.3.
32" / 40" / 48" / 50"
Description Picture Description Screws
1
Remove screws from the Stand. Torque :
9~11Kgf.cm.
6001-001782
Remove stand.
