Samsung UE40F70 Series User manual

LED TV
SERVICEManual
LED TV Contents
1. Precautions
2. Product specications
3. Disassembly and Reassembly
4. Troubleshooting
5. Wiring Diagram
UE**F70****
Chassis : U89A
Model : UE40F70****
UE46F70****
UE55F70****

Contents
1. Precautions...................................................................................................................1-1
1-1. Safety Precautions ..............................................................................................................1-1
1-1-1. Warnings...................................................................................................................1-1
1-1-2. Servicing the LED TV ...............................................................................................1-1
1-1-3. Fire and Shock Hazard.............................................................................................1-1
1-1-4. Product Safety Notices .............................................................................................1-2
1-2. Servicing Precautions..........................................................................................................1-3
1-2-1. General Servicing Precautions .................................................................................1-3
1-3. Static Electricity Precautions ...............................................................................................1-4
1-4. Installation Precautions .......................................................................................................1-5
2. Product Specications.................................................................................................2-1
2-1. Product specications..........................................................................................................2-1
2-2. Detailed Specications ........................................................................................................2-5
2-1-1. Model Comparison ...................................................................................................2-5
2-1-2. Feature & Specications...........................................................................................2-6
2-3. Accessories .........................................................................................................................2-9
2-4. Viewing the Functions .......................................................................................................2-10
2-4-1. Supported Formats.................................................................................................2-10
2-4-2. Smart Control .........................................................................................................2-13
2-4-3. SMART Interaction .................................................................................................2-17
2-4-4. SMART HUB...........................................................................................................2-20
3. Disassembly and Reassembly ....................................................................................3-1
3-1. Disassembly and Reassembly ............................................................................................3-1
3-1-1. LED TV .....................................................................................................................3-1
4. Troubleshooting ...........................................................................................................4-1
4-1. Troubleshooting...................................................................................................................4-1
4-1-1. Previous Check ........................................................................................................4-1
4-1-2. Simple ow chart of malfunction...............................................................................4-3
4-2. How to Check Fault Symptom.............................................................................................4-4
4-2-1. NO Power and No Video ..........................................................................................4-4
4-2-2. Problems and Solutions............................................................................................4-6
4-3. Factory Mode Adjustments..................................................................................................4-8
4-3-1. Detail Factory Option................................................................................................4-8
4-3-2. Entering Factory Mode .............................................................................................4-9
4-3-3. Factory Data ...........................................................................................................4-10
4-4. White Balance ...................................................................................................................4-23
4-4-1. Calibration ..............................................................................................................4-23
4-4-2. Service Adjustment.................................................................................................4-23
4-4-3. Adjustment..............................................................................................................4-25
4-5. RS-232C............................................................................................................................4-26
4-6. AV Control Tabe.................................................................................................................4-27

4-7. Software Upgrade..............................................................................................................4-33
4-7-1. How to Check the Software Version .......................................................................4-33
4-7-2. How to Upgade Software........................................................................................4-34
5. Wiring Diagram.............................................................................................................5-1
5-1. Wiring Diagram....................................................................................................................5-1
5-2. Connector............................................................................................................................5-2
5-3. Connector Functions ...........................................................................................................5-6
5-4. Cables .................................................................................................................................5-7
5-5. The types of module............................................................................................................5-8
A. Exploded View & Part List [UE40F7000STXXH TE02] ............................................. A-1
A-1. Exploded View ................................................................................................................... A-1
A-2. Electrical Parts List............................................................................................................. A-2
B. Exploded View & Part List [UE46F7000STXXH TE02] ............................................. B-1
B-1. Exploded View ................................................................................................................... B-1
B-2. Electrical Parts List............................................................................................................. B-2
C. Exploded View & Part List [UE55F7000STXXH TE02] ............................................. C-1
C-1. Exploded View ................................................................................................................... C-1
C-2. Electrical Parts List ............................................................................................................ C-2

This Service Manual is a property of Samsung Electronics Co.,Ltd.
Any unauthorized use of Manual can be punished under applicable
International and/or domestic law.
© 2013 Samsung Electronics Co.,Ltd.
All rights reserved.
Printed in Korea

Follow these safety, servicing and ESD precautions to prevent damage and to protect against potential hazards such as
electrical shock.
1-1-1. Warnings
WARNING
For continued safety, do not attempt to modify the circuit board.
Disconnect the AC power and DC power jack before servicing.
1-1-2. Servicing the LED TV
When servicing the LED TV, Disconnect the AC line cord from the AC outlet.1.
It is essential that service technicians have an accurate voltage meter available at all times. Check the calibration of this2.
meter periodically.
1-1-3. Fire and Shock Hazard
Before returning the monitor to the user, perform the following safety checks:
Inspect each lead dress to make certain that the leads are not pinched or that hardware is not lodged between the1.
chassis and other metal parts in the monitor.
Inspect all protective devices such as nonmetallic control knobs, insulating materials, cabinet backs, adjustment and2.
compartment covers or shields, isolation resistorcapacitor networks, mechanical insulators, etc.
Leakage Current Hot Check:3.
DEVICE
UNDER
TEST
(READING SHOULD)
NOT BE ABOVE 0.5mA LEAKAGE
CURRENT
TESTER
TEST ALL
EXPOSED METAL
SURFACES
2-WIRE CORD
ALSO TEST WITH
PLUG REVERSED
(USING AC ADAPTER
PLUG AS REQUIRED)
EARTH
GROUND
WARNING
Do not use an isolation transformer during this test.
Use a leakage current tester or a metering system that complies with American National Standards
Institute (ANSI C101.1, Leakage Current for Appliances), and Underwriters Laboratories (UL
Publication UL1410, 59.7).
With the unit completely reassembled, plug the AC line cord directly into a 120V AC outlet. With the unit’s AC switch rst 4.
in the ON position and then OFF, measure the current between a known earth ground (metal water pipe, conduit, etc.)
and all exposed metal parts, including: metal cabinets, screwheads and control shafts.
The current measured should not exceed 0.5 milliamp.
Reverse the power-plug prongs in the AC outlet and repeat the test.
1-1
1. Precautions
1. Precautions
1-1. Safety Precautions

1-2
1. Precautions
1-1-4. Product Safety Notices
Some electrical and mechanical parts have special safetyrelated characteristics which are often not evident from visual
inspection. The protection they give may not be obtained by replacing them with components rated for higher voltage,
wattage, etc. Parts that have special safety characteristics are identied by on schematics and parts lists. A substitute
replacement that does not have the same safety characteristics as the recommended replacement part might create
shock, re and/or other hazards. Product safety is under review continuously and new instructions are issued whenever
appropriate.

WARNING
An electrolytic capacitor installed with the wrong polarity might explode.
CAUTION
Before servicing units covered by this service manual, read and follow the Safety Precautions section of
this manual.
NOTE
If unforeseen circumstances create conict between the following servicing precautions and any of the
safety precautions, always follow the safety precautions.
1-2-1. General Servicing Precautions
Always unplug the unit’s AC power cord from the AC power source and disconnect the DC Power Jack before1.
attempting to: (a) remove or reinstall any component or assembly, (b) disconnect PCB plugs or connectors, (c) connect
a test component in parallel with an electrolytic capacitor.
Some components are raised above the printed circuit board for safety. An insulation tube or tape is sometimes used.2.
The internal wiring is sometimes clamped to prevent contact with thermally hot components. Reinstall all such elements
to their original position.
After servicing, always check that the screws, components and wiring have been correctly reinstalled. Make sure that3.
the area around the serviced part has not been damaged.
Check the insulation between the blades of the AC plug and accessible conductive parts (examples: metal panels, input4.
terminals and earphone jacks).
Insulation Checking Procedure: Disconnect the power cord from the AC source and turn the power switch ON. Connect5.
an insulation resistance meter (500 V) to theblades of the AC plug. The insulation resistance between each blade of the
AC plug and accessible conductive parts (see above) should be greater than 1 megohm.
Always connect a test instrument’s ground lead to the instrument chassis ground before connecting the positive lead;6.
always remove the instrument’s ground lead last.
1-3
1. Precautions
1-2. Servicing Precautions

Some semiconductor (solid state) devices can be easily damaged by static electricity. Such components are commonly
called Electrostatically Sensitive Devices (ESD). Examples of typical ESD are integrated circuits and some eld-effect
transistors. The following techniques will reduce the incidence of component damage caused by static electricity.
Immediately before handling any semiconductor components or assemblies, drain the electrostatic charge from your1.
body by touching a known earth ground. Alternatively, wear a discharging wrist-strap device. To avoid a shock hazard,
be sure to remove the wrist strap before applying power to the monitor.
After removing an ESD-equipped assembly, place it on a conductive surface such as aluminum foil to prevent2.
accumulation of an electrostatic charge.
Do not use freon-propelled chemicals. These can generate electrical charges sufcient to damage ESDs.3.
Use only a grounded-tip soldering iron to solder or desolder ESDs.4.
Use only an anti-static solder removal device. Some solder removal devices not classied as “anti-static” can generate 5.
electrical charges sufcient to damage ESDs.
Do not remove a replacement ESD from its protective package until you are ready to install it. Most replacement ESDs6.
are packaged with leads that are electrically shorted together by conductive foam, aluminum foil or other conductive
materials.
Immediately before removing the protective material from the leads of a replacement ESD, touch the protective material7.
to the chassis or circuit assembly into which the device will be installed.
CAUTION
Be sure no power is applied to the chassis or circuit and observe all other safety precautions.
Minimize body motions when handling unpackaged replacement ESDs. Motions such as brushing clothes together, or8.
lifting your foot from a carpeted oor can generate enough static electricity to damage an ESD.
1-4
1. Precautions
1-3. Static Electricity Precautions

For safety reasons, more than a people are required for carrying the product.1.
Keep the power cord away from any heat emitting devices, as a melted covering may cause re or electric shock.2.
Do not place the product in areas with poor ventilation such as a bookshelf or closet. The increased internal temperature3.
may cause re.
Bend the external antenna cable when connecting it to the product. This is a measure to protect it from being exposed4.
to moisture. Otherwise, it may cause a re or electric shock.
Make sure to turn the power off and unplug the power cord from the outlet before repositioning the product. Also check5.
the antenna cable or the external connectors if they are fully unplugged. Damage to the cord may cause re or electric
shock.
Keep the antenna far away from any high-voltage cables and install it rmly. Contact with the highvoltage cable or the 6.
antenna falling over may cause re or electric shock.
When installing the product, leave enough space (0.4m) between the product and the wall for ventilation purposes.7.
A rise in temperature within the product may cause re.
1-5
1. Precautions
1-4. Installation Precautions

2-1
2. Product specications
2. Product Specications
2-1. Product specications
Item UE**F70****
General Information Product (LCD, LED, PDP) LED
Series 7
Display Inch 40" / 46" / 55"
Resolution 1,920 x 1,080
Ultra Clear Panel Yes
Video Picture Engine 3D HyperReal Engine
Clear Motion Rate 800
Dynamic Contrast Ratio Mega Contrast
Micro Dimming Micro Dimming
Precision Black (Local Dimming) NO
Wide Color Enhance (Plus) Yes
Auto Motion Plus 120/240Hz 240Hz
Film Mode Yes
Natural Mode Support Yes
Audio Dolby Dolby Digital Plus / Dolby Pulse
SRS / DNSe+ DNSe+
dts 2.0 + Digital Out / DTS Premium Audio DTS Premium Audio
3D Sound Yes
Sound Customizer Yes
Speaker Type Down Firing + Full Range
Sound Output (RMS) 20 W (10 x 2)
Woofer NO
Smart TV 2.0 Smart Hub Yes
Smart Guide 17EU Countries
movies & TV shows Yes (FR, DE, ES, AT, CH,)
Apps Yes
Social Yes
Photos, Clips & Music Yes
Family Story No
Fitness Yes
Kids Yes
ACR(Advertisement) N/A
Samsung Sports Experience (SSE) N/A
Samsung Smart View Yes
Recommendation Bar 17 EU Countries
Web Browser Yes

2-2
2. Product specications
Item UE**F70****
Smart Interaction 2.0 Camera Built-in Yes
Face Recognition Yes
Hand Gesture Recognition Yes
Voice Recognition (Embedded) Yes
Voice Recognition (Server) Yes
NLU (Natural Language Understanding)
Other EU (FR, DE) Yes
United Kingdom Yes
Nordic NO
Italy NO
Camera App Yes
Smasung TV Apps supported Yes
Feature Samsung 3D Yes
3D Converter Yes
History Yes
MultiTasking Yes
Smart Evolution Support Yes
"Allshare
(Contens Sharing, Screen Mirroring)" Yes
ConnectShare (USB 2.0) Movie
RVU N/A
ISP Bound Yes
WiFi Direct Yes
Wireless LAN Built-in Yes
BT HID Bulit-in Yes
USB HID Support Yes
OSD Language 26 European Languages
User Interface Golden bridge
Digital Noise Filter Yes
MHL Yes
InstaPort S(HDMI Quick Switch) Yes
HDMI 1.4 3D Auto Setting Yes
HDMI 1.4 A / Reture Ch. Support Yes
EPG Yes
HbbTV Other EU
(CZ, PL, DE, AT,
CH, BE, NL, LU,
PT, FR, ES)
Yes
United Kingdom N/A
Nordic Yes
Italy N/A

2-3
2. Product specications
Item UE**F70****
Feature Teletext Yes
Anynet+ (HDMI-CEC) Yes
BD Wise Plus Yes
Auto Channel Search Yes
Auto Power Off Yes
Auto Volume Leveler Yes
Cation (Subtitle) Yes
Clock & On/Off Timer Yes
Game Mode Yes
Picture-In-Picture Yes
Sleep Timer Yes
Cannel List USB-Clone Yes
V-Chip N/A
Embeded POP Yes
System
DTV Tuner
U.K & Nordic & Italy &
AUSTRIA 2 x DVB-T2/C/S2
Other EU 2 x DVB-T/C/S2
Analog Tuner Yes
CI/CI+ N/A
Input & Output HDMI 4
USB 3
Component In (Y/Pb/Pr) 1
Composite In (AV) 2 (1 Common Use for Component Y)
Ethernet (LAN) 1
Digital Audio Out (Optical) 1
Audio Out (Mini Jack) 1
RF In(Terrestrial/Cable input) 1
RS232C (AV CONTROL) NO
IR Out Yes
CI Slot 1
Scart 1
Design Design Metal
Bezel Type SNB
Slim Type Slim 2
Front Color Silver
Light Effect (Deco) Yes
Stand Type Metal Square
Push & Pull Camera Yes

2-4
2. Product specications
Item UE**F70****
ECO Energy Efciency Class TBD
Eco Mark EU Ecolabel
Eco Label Yes
Eco Sensor Yes
Accessory 3D Active Glasses (Included) 2
SSG-5100GB
IR Blaster Cable (Included) Yes
Remote Controller Model TM1390A / TM1240
Battery (for Remote Control) Yes
Mini Wall Mount Support Yes
Ultra Slim Wall Mount Soupport Yes
Vesa Wall Mount Support Yes
Slim Gender Cable 1 Scart
Power Cable Yes
User manual Yes
E-maual Yes

2-5
2. Product specications
2-2. Detailed Specications
2-1-1. Model Comparison
Model UE**F70****
Front View
W
D
* W : Width H : High D : Depth
H
Detail View
Front Color Silver
Dimensions
(W x H x D)
40" Set with Stand 904.5 x 573.6 x 227.0 mm
Set without Stand 904.5 x 517.8 x 30.0 mm
46" Set with Stand 1037.0 x 648.0 x 237.0 mm
Set without Stand 1037.0 x 529.6 x 30.0 mm
55" Set with Stand 1229.1 x 756.2 x 237.0 mm
Set without Stand 1229.1 x 700.6 x 30.0mm
Weight
40" Set with Stand 12.85 Kg
Set without Stand 9.15 Kg
46" Set with Stand 15.70 Kg
Set without Stand 11.4 Kg
55" Set with Stand 19.5 Kg
Set without Stand 15.2 Kg
Panel Type Ultra Clear
Internal Memory 2 G
DDR 1024 Mbtye
Feature 3D / MoIP / Media Bridge / Allshare / Internet TV / Built-in Wi-Fi / Full Browser /
Bluetooth

2-6
2. Product specications
2-1-2. Feature & Specications
UE40F70****
Item Description
LCD Panel 40 inch FHD 240 Hz
Scanning Frequency Horizontal : 67.5 kHz
Vertical : 60 Hz
Display Colors 16.7M color
Maximum Resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Active Display (H x V)*
* Horizontal x Vertical
34.8661 (H) x 19.6122 (V) inches / 885.6 (H) x 498.15 (V) mm
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock Rate 148.5 MHz
AC Power Voltage & Frequency AC 220-240 V 50/60 Hz
Power Consumption Typical power : 66 W•
Rating for includking Evolution Kit : 152 W•
TV System Tunning Frequency Synthesize (Refer to detailed Frequency Table)
System
UF70** ZG/XH/ZT/XE/XU•
1 PAL/SECAM/NIM/QAM/Cable/T2/S2 tuner-
UF70** ZG(Germany only) other EU•
1 PAL/SECAM/NIM/QAM/Cable/S2 tuner-
Sound Dolby Digital+, SRS theater HD
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage Temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Audio Specications Audio : DTS Premium Audio 5.1 •
Speaker Type : Down Firing + Full Range•
Sound Output (RMS) : 20 W (10 x 2) •
Note : 3D, MOIP, Media Bridge, Allshare, Internet TV, Built-in Wi-Fi, Full Browser, Bluetooth

2-7
2. Product specications
UE46F70****
Item Description
LCD Panel 46 inch FHD 240 Hz
Scanning Frequency Horizontal : 67.5 kHz
Vertical : 60 Hz
Display Colors 16.7M color
Maximum Resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Active Display (H x V)*
* Horizontal x Vertical
40.08189 (H) x 22.546063 (V) inches / 1018.08 (H) x 572.67 (V) mm
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock Rate 148.5 MHz
AC Power Voltage & Frequency AC 220-240 V 50/60 Hz
Power Consumption Typical power : 71 W•
Rating for includking Evolution Kit : 157 W•
TV System Tunning Frequency Synthesize (Refer to detailed Frequency Table)
System
UF70** ZG/XH/ZT/XE/XU•
1 PAL/SECAM/NIM/QAM/Cable/T2/S2 tuner-
UF70** ZG(Germany only) other EU•
1 PAL/SECAM/NIM/QAM/Cable/S2 tuner-
Sound Dolby Digital+, SRS theater HD
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage Temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Audio Specications Audio : DTS Premium Audio 5.1 •
Speaker Type : Down Firing + Full Range•
Sound Output (RMS) : 20 W (10 x 2) •
Note : 3D, MOIP, Media Bridge, Allshare, Internet TV, Built-in Wi-Fi, Full Browser, Bluetooth

2-8
2. Product specications
UE55F70****
Item Description
LCD Panel 55 inch FHD 240 Hz
Scanning Frequency Horizontal : 67.5 kHz
Vertical : 60 Hz
Display Colors 16.7M color
Maximum Resolution Horizontal : 1920 Pixels
Vertical : 1080 Pixels
Active Display (H x V)*
* Horizontal x Vertical
47.933071 (H) x 27.098425 (V) inches / 1217.5 (H) x 688.3(V) mm
Input Signal Analog 0.7 Vp-p ± 5% positive at 75Ω, internally terminated
Input Sync Signal H/V Separate, TTL, P. or N.
Maximum Pixel Clock Rate 148.5 MHz
AC Power Voltage & Frequency AC 220-240 V 50/60 Hz
Power Consumption Typical power : 76 W•
Rating for includking Evolution Kit : 177 W•
TV System Tunning Frequency Synthesize (Refer to detailed Frequency Table)
System
UF70** ZG/XH/ZT/XE/XU•
1 PAL/SECAM/NIM/QAM/Cable/T2/S2 tuner-
UF70** ZG(Germany only) other EU•
1 PAL/SECAM/NIM/QAM/Cable/S2 tuner-
Sound Dolby Digital+, SRS theater HD
Environmental Considerations Operating Temperature : 50˚F ~ 104˚F (10˚C ~ 40˚C)
Operating Humidity : 10% ~ 80%, non-condensing
Storage Temperature : -13˚F ~ 113˚F (-25˚C ~ 45˚C)
Storage Humidity : 5% ~ 95%, non-condensing
Audio Specications Audio : DTS Premium Audio 5.1 •
Speaker Type : Down Firing + Full Range•
Sound Output (RMS) : 20 W (10 x 2) •
Note : 3D, MOIP, Media Bridge, Allshare, Internet TV, Built-in Wi-Fi, Full Browser, Bluetooth

2-9
2. Product specications
2-3. Accessories
Product Description Code. No Remark
Smart Touch Control & Batteries
(AAA x 2) AA59-00759A
Supplied
Accessories
Remote Control & Batteries
(AAA x 2) AA59-00786A
Power Cord 3903-000742
3D Active Glasses BN96-25614A
User Manual & Regulatory Guide BN68-04851G / BN68-04972A
Quick Start Guide / Warranty Card BN68-05118B / BN68-03548J
Scart Adapter BN39-01154A
CI Card Adapter 3709-001732
IR Blaster Cable BN96-26652A
NOTE
The part code for some accessories may differ depending on your region.

2-10
2. Product specications
2-4. Viewing the Functions
2-4-1. Supported Formats
Supported Subtitle Formats
Exterminal
Name File Extension
MPEG-4 Timed text .ttxt
SAMI .smi
SubRip .srt
SubViewer .sub
Micro DVD .sub or .txt
SubStation Alpha .ssa
Advanced SubStation Alpha .ass
Powerdivx .psb
Internal
Name File Extension
Xsub AVI
SubStation Alpha MKV
Advanced SubStation Alpha MKV
SubRip MKV
MPEG-4 Timed text MP4
Supported Music File Formats
File Extension Type Codec Comments
*.mp3 MPEG MPEG1 Audio Layer 3
*.m4a
MPEG4 AAC*.mpa
*.aac
*.ac FLAC FLAC Supports up to 2 channel
*.ogg OGG Vorbis Supports up to 2 channel
*.wma WMA WMA
WMA 10 Pro supports up to 5.1
channel. WMA lossless audio is
not supported. Supports up to M2
prole (except LBR mode)
*.wav wav wav
*.mid
*.midi midi midi type 0, type 1 are supported.
*.ape ape ape

2-11
2. Product specications
Supported Video Formats
File
Extension Container Video Codec Resolution Frame rate (fps)
Bit rate
(Mbps) Audio Codec
*.avi
AVI
MKV
ASF
MP4
3GP
MOV
FLV
VRO
VOB
PS
TS
SVAF
Divx 3.11 / 4 / 5 / 6
1920 x 1080
6~30
30
AC3
LPCM
ADPCM(IMA,
MS)
AAC
HE-AAC
WMA
DD+
MPEG(MP3)
G.711(A-Law,
μ-Law)
*.mkv
*.asf
MPEG4 SP/ASP
*.wmv
*.mp4
H.264 BP/MP/HP
*.3gp
*.vro
Motion JPEG 640 x 480
8
*.mpg
*.mpeg
Microsoft MPEG-4 v3
1280 x 720
*.ts
*.tp Window Media Video
v7,v8
30
*.trp
*.mov
Window Media Video v9
1920x1080
*.v
*.vob
MPEG2
*.svi
*.m2ts
MPEG1
*.mts
*.divx
MVC
640 x 480
24/25/30 60
VP6
6~30
4
*.webm WebM VP8 1920 x1080 20 Vorbis
Other Restrictions
Codecs may not function properly if there is a problem with the content data. Video content does not play or does not
play correctly if there is an error in the content or container. "Sound or video may not work if they have standard bit rates/
frame rates above the TV’s compatibility ratings." If the Index Table is wrong, the Seek (Jump) function does not work.
"When playing video over a network connection, the video may not play smoothly because of data transmission speeds."
Some USB/digital camera devices may not be compatible with the player.
Video Decorders
Supports up to H.264, Level 4.1 (does not support FMO/ASO/RS)•
VC1 AP L4 is not supported.•
All video codecs excluding WMV v7, v8, MSMPEG4 v3, MVC, and VP6:•
Below 1280 x 720: 60 frame max-
Above 1280 x 720: 30 frame max-
GMC is not supported.•
Supports SVAF top/bottom and left/right only.•
Supports Blu-ray/DVD MVC specs only.•
