943BT •943BWT •2243BWT •2443BWT
Adjustable LCD Monitors
Features:
• Fully adjustable stand: height, swivel, tilt, pivot
• High dynamic contrast ratios of 8000:1 (943BT, 943BWT,
2243BWT), and 20,000:1 (2443BWT)
• Ultra-fast 5 ms response time
• Ultra-thin 15mm (.59") bezels
• Exclusive MagicTune™ display control software
• Exclusive MagicColor™ and MagicBright 3™ picture technology
• MagicRotation™ software allows portrait or landscape views
It’s easier if your monitor pivots, tilts, swivels
and adjusts to the perfect height, rather
than you. The infinitely adjustable Samsung
BT/BWT series LCD displays are not only
easy on the neck and shoulders, they’re
easy on the eyes. High dynamic contrast
ratios of 8000:1, and 20,000:1 on 2443BWT,
combine with fast 5 ms response for highly
detailed motion graphics. Exclusive
MagicTune™software gives you accurate and
easy display management. And multitasking
is easy with the BWT widescreens. You’ll
have more room for open applications, tool
palettes and images. The height of comfort
and productivity. Samsung BT/BWT displays.
2443BWT

943BT
943BWT
2243BWT
2443BWT
Adjustable LCD Monitors
©2009 Samsung Electronics America, Inc. Samsung is a registered mark of Samsung Electronics Corp., Ltd.
Specifications and design are subject to change without notice. See www.samsung.com for detailed information.
Printed in USA. MON-943BT943BWT2243BWT2443BWTDSHT-Feb09T-R2
Product Information: 1-866-542-7214 samsung.com/monitor
Product Support: 1-800-SAMSUNG
Features
Fully Adjustable
BT/BWT series displays are ergonomic
marvels. You can swivel, tilt, pivot
and adjust to the perfect height.
MagicRotation software allows you
to easily switch from portrait view to
landscape view.
High Dynamic Contrast Ratios
Samsung dynamic contrast continually
optimizes signal for optimized contrast.
Dynamic contrast ratios of 8000:1,
and 20,000:1 on the 2443BWT, deliver
superior detail in the whites and blacks.
Fast 5 ms Response Time
The fast 5 ms response time means
your motion video will be smooth and
smear-free.
Aspect Ratio Control
Samsung BWT series widescreens
feature aspect ratio control, which
allows you to view 5:4 and 4:3 content
on a wide-format monitor, without
having the picture automatically
stretched artificially.
Exclusive Magic Technologies
MagicTune offers software- and
wizard-based full control of display
characteristics and adjustments.
MagicColor features Full mode to
enhance overall color, and Intelligent
mode to enhance color without affecting
delicate skin tones. And MagicBright 3
gives you picture presets, for optimum
viewing at the touch of a button.
2443BWT Dimensions
21.9"
17.0"
Specifications 943BT 943BWT 2243BWT 2443BWT
Display Type a-si TFT/TN a-si TFT/TN a-si TFT/TN a-si TFT/TN
Viewable Size 19" 19" wide 22" wide 24" wide
Native Resolution 1280 x 1024 1440 x 900 1680 x 1050 1920 x 1200
Pixel Pitch (mm) 0.285 0.294 0.282 0.27
Aspect Ratio 5:4 16:10 16:10 16:10
Contrast Ratio (Typical/
Dynamic)
1000:1/8000:1 1000:1/8000:1 1000:1/8000:1 1000:1/20000:1
Viewing Angle (Horizontal/
Vertical)
170°/160° (CR>10) 170°/160° (CR>10) 170°/160° (CR>10) 170°/160° (CR>10)
Response Time 5ms 5ms 5ms 5ms
Light Source CCFL CCFL CCFL CCFL
Brightness (Typical) 300 cd/m2300 cd/m2300 cd/m2300 cd/m2
Panel Surface Matte Matte Matte Matte
Maximum Color Supported 16.7M 16.7M 16.7M 16.7M
Video Input
Signal
Analog Analog RGB Analog RGB Analog RGB, Analog RGB
Digital DVI (with HDCP) DVI DVI (with HDCP) DVI (with HDCP)
Frequency (H/V) 30~81kHz(H) / 56~75Hz(V) 30~81kHz(H) / 56~75Hz(V) 30~81kHz(H) / 56~75Hz(V) 30~81kHz(H) / 56~75Hz(V)
Sync H/V Separated, Composite
H/V, Sync on Green
H/V Separated, Composite
H/V, Sync on Green
H/V Separated, Composite
H/V, Sync on Green
H/V Separated, Composite
H/V, Sync on Green
Compatibilty PC Mac OS Leopard, X, 9 Mac OS Leopard, X, 9 Mac OS Leopard, X, 9 Mac OS Leopard, X, 9
Mac Windows Vista Premium
Certification, XP, 2000, 98
Windows Vista Premium
Certification, XP, 2000, 98
Windows Vista Premium
Certification, XP, 2000, 98
Windows Vista Premium
Certification, XP, 2000, 98
Input Connectors 15-pin D-sub, DVI-D, 3-pin
AC plug (CEE22)
15-pin D-sub, DVI-D, 3-pin
AC plug (CEE22)
15-pin D-sub, DVI-D, 3-pin
AC plug (CEE22), USB
(1-up/2-down)
15-pin D-sub, DVI-D, 3-pin
AC plug (CEE22)
Power Voltage AC 100-240 ~ VAC (±10%),
60 / 50 Hz ±3 Hz
AC 100-240 ~ VAC (±10%),
60 / 50 Hz ±3 Hz
AC 100-240 ~ VAC (±10%),
60 / 50 Hz ±3 Hz
AC 100-240 ~ VAC (±10%),
60 / 50 Hz ±3 Hz
Consumption
(Typical/Standby)
34 watts (max)/<1 watts
(DPMS mode)
34 watts (typ)/<1 watts
(DPMS mode)
45 watts (typ)/ <1 watts
(DPMS mode)
50 watts (typ)/<1 watts
(DPMS mode)
Features Plug & Play DDC 2B/DDC-CI DDC 2B/DDC-CI DDC 2B/DDC-CI DDC 2B/DDC-CI
Wall Mount (VESA) 75mm 75mm 100 mm 100 mm
Cabinet Color Matte Black Matte Black Matte Black Matte Black
Special Features Height Adjustable Stand
(MagicStand - Up, Down,
Swivel, Tilt, 90-degree Rotate)
n n n n
Built-in USB N/A N/A nN/A
Magic
Technologies
MagicColor (Full and
Intelligent Mode)
n n n n
MagicBright3 (Custom,
Text, Internet, Game, Sport,
Movie, Dynamic Contrast)
n n n n
MagicTune Display Control n n n n
MagicStand HAS (Height
Adjustable, Swivel, Tilt, Pivot)
n n n n
Operating
Conditions
Temperature 10°~ 40° 10°~ 40° 10°~ 40° 10°~ 40°
Humidity 10% ~ 80%, non-condensing 10% ~ 80%, non-condensing 10% ~ 80%, non-condensing 10% ~ 80%, non-condensing
Dimensions and
Weight
Product Dimension
(With Stand, W x H x D)
16.0" x 15.0" x 7.5" 17.3" x 14.1" x 7.5" 20.0" x 14.8" x 7.9" 21.9" x 17.0" x 9.8"
Product Dimension
(Without Stand, W x H x D)
16.0" x 13.2" x 2.5" 17.3" x 11.4" x 2.6" 20.0" x 13.1" x 2.7" 21.9" x 14.2" x 2.6"
Shipping Carton Dimension
(W x H x D)
18.9" x 8.0" x 16.2" 20.2" x 8.0" x 14.5" 23.0" x 8.0" x 16.3" 25.4" x 11.8" x 20.0"
Product Weight (With Stand) 10.8 lbs. 11.0 lbs. 14.1 lbs. 17.0 lbs.
Shipping Weight 14.3 lbs. 14.6 lbs. 18.1 lbs. 22.0 lbs.
Package Contents Monitor, Power Cable, 15-pin
D-sub Cable, DVI-D Cable,
Manuals, Driver CD
Monitor, Power Cable, 15-pin
D-sub Cable, DVI-D Cable,
Manuals, Driver CD
Monitor, Power Cable, 15-pin
D-sub Cable, DVI-D Cable,
Manuals, Driver CD
Monitor, Power Cable, 15-pin
D-sub Cable, DVI-D Cable,
Manuals, Driver CD
Warranty 3 years parts and labor 3 years parts and labor 3 years parts and labor 3 years parts and labor
Environmental Emission Standard EMC, TCO 99 EMC EMC EMC
RoHS Compliant N/A N/A N/A N/A
Energy Star Compliant n n n n
Product Recyclability CCFL panel contains mercury,
please dispose of properly
CCFL panel contains mercury,
please dispose of properly
CCFL panel contains mercury,
please dispose of properly
CCFL panel contains mercury,
please dispose of properly
Packaging Recyclability All packing materials are
recyclable
All packing materials are
recyclable
All packing materials are
recyclable
All packing materials are
recyclable
