Introduction
Package Contents
Note
• Please make sure the following items are included with your LCD Display.
If any items are missing, contact your dealer.
Contact a local dealer to buy optional items.
Note
• This stand is not for the Floor Standing Type.
LCD Display
Manuals
Quick Setup Guide Warranty Card
(Not available in all locations)
User's Guide, MDC Software,
MagicNet Software
Cables
D-Sub Cable Power Cord
Other
Safety Instructions
Introduction
Package Contents
Your LCD Display
Mechanical Layout
Connections
Using the Software
Adjusting the LCD Display
Troubleshooting
Specifications
Information
Appendix

Remote Control
Batteries (AAA X 2)
(Not available in all
locations)
BNC to RCA
Adaptor Jack
Sold separately
Wall Mount KIT DVI Cable BNC Cable
LAN Cable
Your LCD Display
Front
1) MENU
Opens the on-screen menu and exits from the menu or closes the adjustment menu.
2) Navigate buttons (Up-Down buttons)
Moves from one menu item to another vertically or adjusts selected menu values.
3) Adjust buttons (Left-Right buttons)/ Volume buttons
Moves from one menu item to another horizontally or adjusts selected menu values.
Adjusts the audio volume.
4) ENTER
Activates a highlighted menu item.
5) SOURCE
Switches from PC mode to Video mode.
Changing the source is only allowed for external devices that are connected to the LCD Display at the time.
[PC] →[BNC] →[DVI] →[AV] →[S-Video] →[Component] →[HDMI] →[MagicNet]
>> Click here to see an animation clip.
6) PIP
Push the PIP button to turn the PIP screen On / Off.
More than one PIP cannot overlap on screen as BNC and the component use the same terminal.
>> Click here to see an animation clip.

•PC
A
V / S-Video / Component / HDMI Mode
•BNC
A
V / S-Video / HDMI Mode
•DVI
A
V / S-Video / Component Mode
•AV / S-Video
PC / BNC / DVI Mode
•Component
PC / DVI Mode
•HDMI
PC / BNC Mode
7) Power button
Turns the LCD Display On/Off.
8) Brightness Sensor
The product's Brightness Sensor function automatically detects the surrounding brightness using a
brightness sensor and adjusts its brightness accordingly.
9) Power indicator
Shows PowerSaver mode by blinking green.
10) Remote Control Sensor
Aim the remote control towards this spot on the LCD Display.
Note
•SeePowerSaver described in the manual for further information regarding power saving functions. For
energy conservation, turn your LCD Display OFF when it is not needed or when leaving it unattended for
long periods.
Rear
Note
• For detailed information concerning cable connections, refer to Connecting Cables under Setup. The LCD
Display 's configuration at the back may vary slightly depending on the LCD Display model.
1) POWER IN
The power cord plugs into the LCD Display and
the wall plug.

2) REMOTE OUT/IN
You can use a wired remote control by
connecting it to your monitor.
3) RS232C OUT/IN (RS232C Serial PORT)
MDC(Multiple Display Control) Program Port
4) DVI / PC / HDMI IN [HDMI/PC/DVI/BNC
AUDIO IN](HDMI/PC/DVI/BNC Audio
Connection Terminal (Input))
5) DVI / PC / HDMI IN [HDMI]
Connect the HDMI terminal at the back of your
monitor to the HDMI terminal of your digital
output device using a HDMI cable.
6) DVI / PC / HDMI IN [RGB] (PC Video
Connection Terminal)
Using a D-Sub Cable (15 pin D-Sub) - PC
mode (Analog PC)
7) DVI / PC / HDMI IN [DVI(HDCP)] (PC
Video Connection Terminal)
Using a DVI Cable (DVI-D to DVI-D) - DVI
mode (Digital PC)
8) COMPONENT AUDIO IN [L-AUDIO-R]
(Component Audio Connection Terminal
(Input))
9) BNC/COMPONENT OUT [R/PR, G/Y, B/PB,
H, V] (BNC/Component Connection
Terminal (Output))
BNC (Analog PC) Connection: connecting the R,
G, B, H, V ports
Component Connection: connecting the PR, Y,
PBports
10) BNC/COMPONENT IN [R/PR, G/Y, B/PB, H,
V] (BNC/Component Connection Terminal
(Input))
11) AV AUDIO IN [L-AUDIO-R] (LCD Display
Audio Connection Terminal (Input))
12) AV OUT [VIDEO] (VIDEO Connection
Terminal): AV mode (Output)
13) AV IN [VIDEO] (VIDEO Connection
Terminal) (Input)
14) AV OUT [S-VIDEO] (S-VIDEO Connection
Terminal): S-VIDEO mode (Output)
15) AV IN [S-VIDEO] (S-VIDEO Connection
Terminal) (Input)
16) AUDIO OUT [L-AUDIO-R] (LCD Display
Audio Connection Terminal (Output))
AUDIO OUT is the terminal for sound output of
PC, DVI or BNC.
17) LAN (LAN Connection Terminal)
18) USB (USB Connection Terminal)
Keyboard / Mouse, Mass Storage Device
Compatible.

Note
• The number of LCD Displays that can be connected to loopout may differ depending on the cables, signal
source etc. With cables where there is no degradation or signal source, up to ten LCD Displays can be
connected.
Note
•SeeConnecting the LCD Display for further information regarding cable connections.
Remote Control
Note
• The performance of the remote control may be affected by a TV or other electronic device operating near
the LCD Display , causing a malfunction due to interference with the frequency.
1. ON / OFF
2. MAGICNET
3. MDC
4. LOCK
5. MagicNet buttons
6.+100 -/--
7. VOL
8. MUTE
9. TTX/MIX
10. MENU
11. ENTER
12. P.MODE
13. AUTO
14. ENTER/PRE-CH
15 . CH/P
16. SOURCE
17. INFO
18. EXIT
19. Up-Down Left-Right buttons
20. S.MODE
21. STILL
22. FM RADIO
23. P.SIZE
24. SRS
25. DUAL/MTS
26. PIP
27. SOURCE
28. SWAP
29. SIZE
30. RE
W
31. STOP
32. PLAY/PAUSE
33. FF
1) ON / OFF
Turns the LCD Display On/Off.
2) MAGICNET
MagicNet Quick Launch Button.

3) MDC
MDC Quick Launch Button.
4) LOCK
Activates or deactivates all function keys on both the remote control and the LCD Display except for the
Power and LOCK buttons.
5) MagicNet buttons
Used for MagicNet.
• Alphanumeric: Used to enter the Internet address.
• DEL: Functions as the backspace.
• SYMBOL: Used to enter the symbols. (.O_-)
• ENTER: Used to enter values.
6) +100 -/--
Press to select channels over 100.
For example, to select channel 121, press "+100", then press "2" and "1".
- This fuction does not work for this monitor.
7) VOL
Adjusts the audio volume.
8) MUTE
Pauses (mutes) the audio output temporarily.
This is displayed on the lower left corner of the screen.
The audio resumes if MUTE or - VOL + is pressed in the Mute mode.
9) TTX/MIX
TV channels provide text information services via teletext.
- This fuction does not work for this monitor.
10) MENU
Opens the on-screen menu and exits from the menu screen or closes the screen adjustment menu.
11) ENTER
Activates a highlighted menu item.
12) P.MODE
When you press this button, current picture mode is displayed on the lower center of the screen.
AV / S-Video / Component : P.MODE
The Monitor has four automatic picture settings that are preset at the factory.
Then push button again to circle through available preconfigured modes.
( Dynamic →Standard →Movie →Custom )
PC/DVI/BNC : M/B (MagicBright™)
MagicBright™ is a new feature providing the optimum viewing environment depending on the contents of
the image you are watching.
Then push button again to circle through available preconfigured modes.
(Entertain →Internet →Text →Custom )
13) AUTO
Adjusts the screen display automatically in PC mode.
By changing the resolution in the control panel, auto function is performed.
14) ENTER/PRE-CH
Returns to the immediately previous channel.
- This fuction does not work for this monitor.
15) CH/P
In TV mode, selects TV channels.
- This fuction does not work for this monitor.
16) SOURCE
Changes the video source.
17) INFO
The current picture information is displayed in the top left corner of the screen.
18) EXIT
Exits from the menu screen.
19) Up-Down Left-Right buttons
Moves from one menu item to another horizontally, vertically or adjusts selected menu values.
20) S.MODE

When pressing this button, the current mode is displayed at the bottom centre of the screen.
The LCD Display has a built-in high fidelity stereo amplifier.
Then press the button again to circle through available preconfigured modes.
( Standard →Music →Movie →Speech →Custom )
21) STILL
Press the button once to freeze the screen. Press it again to unfreeze.
22) FM RADIO
Turns the FM Radio on/off.
In PC/DVI mode, sets the SOUND to FM Radio.
In general Video mode, selects FM Radio, and turns off the screen.
In areas where the signal is weak, noise may occur during FM radio broadcasts.
- This fuction does not work for this monitor.
23) P.SIZE
Press to change the screen size.
24) SRS
SRS
25) DUAL/MTS
- This fuction does not work for this monitor.
DUAL-
STEREO/MONO, DUAL l / DUAL ll and MONO/NICAM MONO/NICAM STEREO can be operated
depending on the broadcasting type by using the DUAL button on the remote control while watching TV.
MTS-
You can select MTS (Multichannel Television Stereo) mode.
Audio Type MTS/S_Mode Default
FM Stereo
Mono Mono
Manual Change
Stereo Mono ↔Stereo
SAP Mono ↔SAP Mono
26) PIP
Every time you press the button, a PIP screen appears.
27) SOURCE
Changes the source of the PIP window signal.
28) SWAP
Swaps the contents of the PIP and main image.
The image in the PIP window will appear on the main screen, and the main screen image will appear in the
PIP window.
29) SIZE
Switches the PIP Picture Size.
30) REW
Rewind
31) STOP
Stop
32) PLAY / PAUSE
Play/Pause
33) FF
Fast forward
© 1995~2007 SAMSUNG. ALL Rights Reserved

Select Language Main Page
Model
The color and appearance of the product may vary depending on the model, and the product specifications are
subject to change without prior notice for reasons of performance enhancement.
Connections
Installing the Stand KIT
Note
• Only the supplied bolts should be used.
Caution
Samsung Electronics will not be responsible for damages caused by using a base other than those
specified.
Installing the Semi Stand
Left stand Right stand
Caution
Make sure to install the stand with the Caution label
folded backwards.
Caution
The resolution may differ for each product model. For information on the optimal resolution, refer to the user
manual.
Connecting the LCD Display
Safety Instructions
Introduction
Connections
Installing the Stand KIT
Connecting the LCD
Display
Using the Software
Adjusting the LCD Display
Troubleshooting
Specifications
Information
Appendix

Using a Power cord with Earth
In the event of failure, the earth lead may cause electric shock. Make sure to wire the earth lead in
correctly, before connecting the AC power. When un-wiring the earth lead, make sure to disconnect
the AC power in advance.
Note
• AV input devices such as DVD players, VCR's or camcorders as well as your computer can be connected
to the LCD Display. For detailed information on connecting AV input devices, refer to the User Controls
under Adjusting Your LCD Display.
Connecting a Computer
1) Connect the power cord for your LCD Display to the power port on the back of the LCD Display.
Trun on the power switch.
2) There are 3 ways to connect the D-sub to your LCD Display.
Choose one of the following:
2-1) Using the D-sub (Analog) connector on the video card.
Connect the D-sub to the 15-pin, RGB port on the back of your LCD Display and the 15 pin D-
sub Port on the computer.
2-2) Using the DVI (Digital) connector on the video card.
Connect the DVI Cable to the DVI(HDCP) port on the back of your LCD Display and the DVI port
on the computer.
2-3)
Using the BNC (Analog) connector on the video card.
Connect the BNC Cable to the BNC/COMPONENT IN - R, G, B, H, V ports on the back of your
LCD Display and the 15 pin D-sub Port on the computer.
