Samsung 730MW - SyncMaster - 17" LCD Monitor User manual

Install Drivers Install Pro
g
rams

Failure to follow directions noted by this symbol could result in bodily harm or damage to
equipment.
Prohibited Important to read and understand at all times
Do not disassemble Disconnect the plug from the outlet
Do not touch Grounding to prevent an electric shock
Power
When not used for extended period of time, set your computer to DPMS.
If using a screen saver, set it to the active screen mode.
Do not use a damaged or loose plug.
zThis may cause an electric shock or fire.

Do not pull the plug out by the wire nor touch the plug with wet hands.
zThis may cause an electric shock or fire.
Use only a properly grounded plug and receptacle.
zAn improper ground may cause electric shock or equipment damage.
Do not excessively bend the plug and wire nor place heavy objects upon them,
which could cause damage.
zThis may cause an electric shock or fire.
Do not connect too many extension cords or plugs to an outlet.
zThis may cause fire.
Installation
Put your monitor in a location with low humidity and a minimum of dust.
zFailure to do so may cause an electric shock or fire inside the monitor.
Do not drop the monitor when moving it.
zThis may cause damage to the product or human body.
Place the monitor on a flat and stable surface.
zThe monitor can cause injury by falling.

Set down the monitor carefully.
zThe monitor could be damaged or broken.
Do not place the monitor face down.
zThe TFT-LCD surface may be damaged.
Installing a wall bracket must be done by a qualified professional.
zInstallation by unqualified personnel may result in injury.
zAlways use the mounting device specified in the owner's manual.
Leave a space for ventilation between the product and the wall.
zPoor ventilation may cause the interior temperature to rise and lead to fire.
To prevent rainwater from running along the outdoor antenna cable and entering the
house, be sure the outdoor portion of the cable hangs down below the point of entry.
zIf rainwater enters the product, it may cause an electric shock or fire.
If you are using an outdoor antenna, be sure to put sufficient distance between your
antenna and the electrical wires nearby so that they would not come in contact with
each other in case the antenna is knocked over by strong wind.
zA knocked-over antenna may cause injury or an electric shock.
Clean
When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with a
slightly moistened, soft fabric.
Do not spray water or detergent directly on the monitor.
zThis may cause damage, electric shock or fire.

Use the recommended detergent with a smooth cloth.
If the connector between the plug and the pin is dusty or dirty, clean it properly
with a dry cloth.
zA dirty connector can cause an electric shock or fire.
Contact a Service Center or Customer Center for interior cleaning once a year.
zKeep the product's interior clean. Dust which has accumulated
in the interior over an extended period of time may cause malfunction or fire.
Others
Do not remove cover (or back). No user serviceable parts inside.
zThis may cause an electric shock or fire.
zRefer servicing to qualified service personnel.
If your monitor does not operate normally - in particular, if there are any
unusual sounds or smells coming from it - unplug it immediately and contact
an authorized dealer or service.
zThis may cause an electric shock or fire.
Be careful not to let water drip into the monitor or expose the monitor to
moisture.
zThis may cause malfunction, an electric shock or fire.
zEspecially avoid operating the monitor near water or outdoors where it could be
exposed to snow or rain.
If the monitor is dropped or the casing is damaged, turn the monitor off and
unplug the power cord.
zThe monitor may malfunction, causing an electric shock or fire.
zThen contact the Service Center .
Disconnect the plug from the outlet during storms or lightening or if it is not
used for a long period of time.
zFailure to do so may cause an electric shock or fire.

Do not try to move the monitor by pulling on the wire or the signal cable.
zThis may cause a breakdown, electric shock or fire due to damage to the
cable.
Do not move the monitor right or left by pulling only the wire or the signal
cable.
zThis may cause a breakdown, electric shock or fire due to damage to the
cable.
Do not cover the vents on the monitor cabinet.
zBad ventilation may cause a breakdown or fire.
Do not place water containers, chemical products or small metal objects on the
monitor.
zThis may cause malfunction, an electric shock or fire.
zIf a foreign substance enters the monitor, unplug the power cord and contact
the Service Center .
Do not use or store inflammable substances near the monitor.
zThis may cause an explosion or fire.
Never insert anything metallic into the monitor openings.
zThis may cause an electric shock, fire or injury.
Do not insert metal objects such as utensils, wire or drill bits, or things that
catch fire easily, such as pieces of paper or matches, into the vents or the
headphone or A/V ports on the monitor.
zThis may cause malfunction, an electric shock or fire.
zAlways contact the Service Center if foreign substances/objects enter into the
monitor.
If you view a fixed screen for an extended period of time, residual image or
blurriness may appear.
zChange the mode to energy save or set a screensaver to moving picture when
you need to be away from the monitor for an extended period of time.
Adjust the resolution and frequency to the levels appropriate for the model.
zInappropriate resolution may cause undesirable picture quality.
17 inch Wide - 1280 X 768

Keep the volume at a proper level when you use the headphones.
zExcessively loud volume levels may damage hearing.
Keep a proper distance between your eyes and the monitor screen.
zSitting too close to the monitor on a continuous basis may damage eyesight.
To ease eye strain, take at least a five-minute break after every hour of using
the monitor.
Do not use the monitor where it can be exposed to strong vibrations.
zExposure to strong vibrations can be fire hazard and shorten the life of the
monitor.
When moving the monitor, turn the power switch off and unplug the power
cord.
Make sure that all cables, including the antenna cable and cables connecting to
other devices, are disconnected before moving the monitor.
zFailure to disconnect a cable may damage it and lead to fire or an electric
shock.
When you remove batteries from the remote, be careful that they are not
swallowed by children. Keep batteries out of the reach of children.
zIf swallowed, see a doctor immediately.
When replacing batteries, place the batteries in the correct +/- polarity position
as indicated on battery holder.
zIncorrect polarity may cause a battery to break or leak and could lead to fire,
injury, or contamination (damage).
Use only specified standard batteries. Do not use new and used batteries
together.
zmay cause a battery to break or leak and could lead to fire, injury, or
contamination (damage).

Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
Contact a local deale
r
to bu
y
o
p
tional items.
Unpacking
Monito
r
Manual
Quick Setup Guide Warranty Card
(
Not available in all locations
)
User's Guide, Monitor Driver,
Natural Color software
Cable

D-Sub Cable
A
udio Cable Power Cord
Radio Antenna
Sold se
p
aratel
y
DVI Cable
Others
Remote Control Batteries
(
AAA X 2
)
Connerte
r
Front

1. MENU 2. CH 3. - VOL + 4. ENTER / FM RADIO 5. SOURCE
6. PIP 7. Power button 8. Power indicator 9. Remote Control Sensor
1. MENU
Use this button for open the on-screen menu and exits from the menu screen or closes
screen adjustment menu.
2. CH
Moves from one menu item to another vertically or adjusts selected menu values.
In TV mode, selects TV channels.
>>Click here to see an animation clip
3. - VOL +
Moves from one menu item to another horizontally or adjusts selected menu values.
Also adjusts the audio volume.
>>Click here to see an animation clip
4. ENTER / FM RADIO
ENTER : Activates a highlighted menu item.
FM RADIO : Turns on/off FM Radio.
In PC/DVI mode, sets only SOUND to FM Radio.
In general VIDEO SOURCE mode, sets to FM RADIO, turning off the screen.
In areas where signal is weak, noise may occur while FM radio is broadcast.
>>Click here to see an animation clip
5. SOURCE
Switches from PC mode to Video mode.
Changing the source is allowed only external devices that are connected to the monitor at
the time.
To switch Screen modes:
[PC] [DVI] [TV] [Ext.] [AV] [S-Video] [Component]
>>Click here to see an animation clip
NOTE : According to broadcasting type in each country, you may not be able to select one.
EXT(RGB) is mainly used in Europe.
For more information > Broadcasting Systems
6. PIP ( Available Mode : PC/DVI/COMONENT )
In PC Mode, turns on Video or TV screens in PIP mode.
>>Click here to see an animation clip
7. Power button
Use this button for turn the monitor on and off.
8. Power indicator
Power Indicator shows PowerSaver mode by green blinking.
9. Remote Control Sensor
Aim the remote control towards this spot on the Monitor.
See PowerSaver described in the manual for further information regarding power saving functions.
For energy conservation, turn your monitor OFF when it is not needed or when leaving it unattended
