Samsung S22F380HY User manual

Monitor
User Manual
The color and the appearance may differ depending on the
product, and the specifications are subject to change without
prior notice to improve the performance.
S22F380HY

2
Table of contents
Before Using the Product
Copyright 4
Securing the Installation Space 5
Precautions for storage 5
Safety Precautions 5
Symbols 5
Cleaning 6
Electricity and Safety 6
Installation 7
Operation 9
Correct posture to use the product 12
Preparations
Checking the Components 13
Components 13
Parts 14
Frontal Button 14
Reverse Side 16
Installation 17
Attaching the Stand 17
Removing the Stand 18
Adjusting the Product Tilt 19
Anti-theft Lock 20
Connecting and Using a Source
Device
Before Connecting 21
Pre-connection Checkpoints 21
Connecting and Using a PC 21
Connection Using the D-SUB Cable 21
Connection Using the HDMI Cable 22
Connection Using an HDMI-DVI Cable 22
Connecting the Power 23
Driver Installation 24
Setting Optimum Resolution 24
Screen Setup
SAMSUNG MAGIC Bright 25
Configuring SAMSUNG MAGIC Bright 25
Brightness 27
Configuring Brightness 27
Contrast 28
Configuring Contrast 28
Sharpness 29
Configuring Sharpness 29
Color 30
Configuring Color 30
SAMSUNG MAGIC Upscale 31
Configuring SAMSUNG MAGIC Upscale 31
HDMI Black Level 32
Configuring the HDMI Black Level Settings 32
Eye Saver Mode 33
Configuring Eye Saver Mode 33
Game Mode 34
Configuring Game Mode 34
Picture Size 35
Changing the Picture Size 35
Screen Adjustment 37
Configuring H-Position & V-Position 37
Configuring Coarse 38
Configuring Fine 39
Coordinating OSD
Transparency 40
Changing Transparency 40
Position 41
Configuring Position 41
Language 42
Configuring Language 42
Display Time 43
Configuring Display Time 43

3
Table of contents
Setup and Reset
Night View Setting 44
Configuring Night View Setting 44
Eco Saving Plus 47
Configuring Eco Saving Plus 47
Off Timer 48
Configuring Off Timer 48
Configuring Turn Off After 49
PC/AV Mode 50
Configuring PC/AV Mode 50
Source Detection 51
Configuring Source Detection 51
Key Repeat Time 52
Configuring Key Repeat Time 52
Reset All 53
Initializing Settings (Reset All) 53
Information Menu and Others
Information 54
Displaying Information 54
Configuring Brightness, Contrast and Sharpness
from the Initial Screen 55
Installing the Software
Easy Setting Box 56
Installing the Software 56
Removing the Software 56
Troubleshooting Guide
Requirements Before Contacting Samsung
Customer Service Center 57
Testing the Product 57
Checking the Resolution and Frequency 57
Check the following. 58
Q & A 61
Specifications
General 63
PowerSaver 65
Standard Signal Mode Table 66
Appendix
Responsibility for the Pay Service
(Cost to Customers) 68
Not a product defect 68
A Product damage caused by customer's fault 68
Others 68
Correct Disposal 69
Correct Disposal of This Product (Waste Electrical &
Electronic Equipment) 69
Terminology 70

4
Copyright
The contents of this manual are subject to change without notice to improve quality.
ⓒ2015 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.
Before Using the Product
Chapter 01

5
Securing the Installation Space
Ensure some space around the product for ventilation. An internal temperature rise may cause fire and
damage the product. Be sure to allow the amount of space as shown below or greater when installing
the product.
―The exterior may differ depending on the product.
10 cm
10 cm 10 cm
10 cm
10 cm
Precautions for storage
High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used
nearby.
―Contact your nearest Samsung Customer Service Center if you want to clean the inside of the product
(Service fee will be charged.)
Safety Precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)
THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and maintenance has been
included with this product.
Symbols
Warning
A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.

6
Cleaning
―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
―Take the following steps when cleaning.
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
1
Power off the product and computer.
2
Disconnect the power cord from the product.
―Hold the power cable by the plug and do not touch the cable with
wet hands. Otherwise, an electric shock may result.
!
3
Wipe the monitor with a clean, soft and dry cloth.
•Do not apply a cleaning agent that contains alcohol,
solvent, or surfactant to the monitor.
•Do not spray water or detergent directly on the
product.
4
Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the product.
5
Connect the power cord to the product when cleaning is finished.
6
Power on the product and computer.
Electricity and Safety
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
•An electric shock or fire may result.
Do not use multiple products with a single power socket.
•Overheated power sockets may cause a fire.
Do not touch the power plug with wet hands. Otherwise, an electric shock
may result.
!
Insert the power plug all the way in so it is not loose.
•An unsecure connection may cause a fire.
!
Connect the power plug to a grounded power socket (type 1 insulated
devices only).
•An electric shock or injury may result.

7
Do not bend or pull the power cord with force. Be careful not to leave the
power cord under a heavy object.
•Damage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
•A fire or electric shock may result.
!
Clean any dust around the pins of the power plug or the power socket with
a dry cloth.
•A fire may result.
Caution
Do not disconnect the power cord while the product is being used.
•The product may become damaged by an electric shock.
!
Only use the power cord provided with your product by Samsung. Do not
use the power cord with other products.
•A fire or electric shock may result.
!
Keep the power socket where the power cord is connected unobstructed.
•The power cord must be disconnected to cut off power to the product
when an issue occurs.
!
Hold the plug when disconnecting the power cord from the power socket.
•An electric shock or fire may result.
Installation
Warning
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF
THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
•A fire may result.
Do not install the product in poorly ventilated spaces such as a bookcase or
closet.
•An increased internal temperature may cause a fire.
!
Install the product at least 10cm away from the wall to allow ventilation.
•An increased internal temperature may cause a fire.
!
Keep the plastic packaging out of the reach of children.
•Children may suffocate.

8
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.)
•The product may fall and become damaged and/or cause an injury.
•Using the product in an area with excess vibration may damage the
product or cause a fire.
!
Do not install the product in a vehicle or a place exposed to dust, moisture
(water drips, etc.), oil, or smoke.
•A fire or electric shock may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
•The product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
•The product may fall and injure children.
Edible oil (such as soybean oil) may damage or distort the product. Keep the
product away from oil pollution. And do not install or use the product in the
kitchen or near the kitchen stove.
Caution
!
Do not drop the product while moving.
•Product failure or personal injury may result.
Do not set down the product on its front.
•The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the
bottom edge of the front of the product is not protruding.
•The product may fall and become damaged and/or cause an injury.
•Install the product only on cabinets or shelves of the right size.
!
Set down the product gently.
•Product failure or personal injury may result.
SAMSUNG
!
Installing the product in an unusual place (a place exposed to a lot of fine
dust, chemical substances, extreme temperatures or a significant presence
of moisture, or a place where the product will operate continuously for an
extended period of time) may seriously affect its performance.
•Be sure to consult Samsung Customer Service Center if you want to
install the product at such a place.

9
Operation
Warning
There is a high voltage inside the product. Never disassemble, repair or
modify the product yourself.
•A fire or electric shock may result.
•Contact Samsung Customer Service Center for repairs.
!
To move the product, first disconnect all the cables from it, including the
power cable.
•Damage to the cord may result in a fire or electric shock.
!
If the product generates abnormal sounds, a burning smell or smoke,
disconnect the power cord immediately and contact Samsung Customer
Service Center.
•An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
•Children may become injured or seriously harmed.
If the product is dropped or the outer case is damaged, turn off the power
and disconnect the power cord. Then contact Samsung Customer Service
Center.
•Continued use can result in a fire or electric shock.
Do not leave heavy objects or items that children like (toys, sweets, etc.) on
top of the product.
•The product or heavy objects may fall as children try to reach for the
toys or sweets resulting in a serious injury.
!
During a lightning or thunderstorm, power off the product and remove the
power cable.
•A fire or electric shock may result.
!
Do not drop objects on the product or apply impact.
•A fire or electric shock may result.
Do not move the product by pulling the power cord or any cable.
•Product failure, an electric shock or fire may result from a damaged
cable.
!GAS
If a gas leakage is found, do not touch the product or power plug. Also,
ventilate the area immediately.
•Sparks can cause an explosion or fire.
Do not lift or move the product by pulling the power cord or any cable.
•Product failure, an electric shock or fire may result from a damaged
cable.

10
!
Do not use or keep combustible spray or an inflammable substance near
the product.
•An explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
•An increased internal temperature may cause a fire.
100
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects
that burn easily (paper, matches, etc) into the product (via the vent or input/
output ports, etc).
•Be sure to power off the product and disconnect the power cord
when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Center.
•Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
•Be sure to power off the product and disconnect the power cord
when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Center.
•Product failure, an electric shock or fire may result.
Caution
!
Leaving the screen fixed on a stationary image for an extended period of
time may cause afterimage burn-in or defective pixels.
•Activate power-saving mode or a moving-picture screen saver if you
will not be using the product for an extended period of time.
-_-
!
Disconnect the power cord from the power socket if you do not plan on
using the product for an extended period of time (vacation, etc).
•Dust accumulation combined with heat can cause a fire, electric shock
or electric leakage.
!
Use the product at the recommended resolution and frequency.
•Your eyesight may deteriorate.
Do not put power adapters together.
•Otherwise, a fire may result.
Remove the plastic bag from the power adapter before you use it.
•Otherwise, a fire may result.
Do not let water enter the power device or get the device wet.
•An electric shock or fire may result.
•Avoid using the product outdoors where it can be exposed to rain or
snow.
•Be careful not to get the power adapter wet when you wash the floor.

11
Do not put the power adapter near to any heating apparatus.
•Otherwise, a fire may result.
!
Keep the power adapter in a well-ventilated area.
!
If you place the AC/DC power adapter so that it is hanging with the cord
input facing upwards, water or other foreign substances could enter the
Adapter and cause the Adapter to malfunction.
Make sure to rest the AC/DC power adapter flat on a table or the floor.
Do not hold the product upside-down or move it by holding the stand.
•The product may fall and become damaged or cause an injury.
!
Looking at the screen too close for an extended period of time can
deteriorate your eyesight.
Do not use humidifiers or stoves around the product.
•A fire or electric shock may result.
!
Rest your eyes for more than 5 minutes for every 1 hour of product use.
•Eye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an
extended period of time as it will become hot.
!
Store small accessories out of the reach of children.
!
Exercise caution when adjusting the product angle or stand height.
•Your hand or finger may get stuck and injured.
•Tilting the product at an excessive angle may cause the product to fall
and an injury may result.
Do not place heavy objects on the product.
•Product failure or personal injury may result.

12
Correct posture to use the product
Use the product in the correct posture as follows:
•Straighten your back.
•Allow a distance of 45 to 50cm between your eye and the screen, and look slightly downward at
the screen. Keep your eyes directly in front of the screen.
•Adjust the angle so light does not reflect on the screen.
•Keep your forearms perpendicular to your upper arms and level with the back of your hands.
•Keep your elbows at about a right angle.
•Adjust the height of the product so you can keep your knees bent at 90 degrees or more, your
heels attached to the floor, and your arms lower than your heart.

13
Preparations
Chapter 02
Checking the Components
-Contact the vendor where you
purchased the product if any
components are missing.
-The appearance of the components may
differ from the images shown.
-The optimal resolution may not be
available when using a non-high speed
HDMI or HDMI-DVI cable.
Components
―Components may vary depending on the country.
Quick Setup Guide Warranty card
(Not available in some locations) Regulatory guide Power cable (P. 23)
Power adapter (Detachable) (P. 23) D-SUB cable (Optional) (P. 21) HDMI cable (Optional) (P. 22) HDMI-DVI cable (Optional) (P. 22)
Stand base Stand neck

14
Parts
Frontal Button
―The color and shape of parts may differ from what is shown. Specifications are
subject to change without notice to improve quality.
SOURCEMENU
NIGHT
VIEW
AUTO
SOURCEMENU
NIGHT
VIEW
Function Key Guide
―To activate a button on the product, tap the area on the bottom of the panel.
Tapping around the button label on the front will not activate the button.
Icons Description
MENU
Open or close the onscreen display (OSD) menu, or return to the parent menu.
•OSD control lock: Maintain the current settings, or lock the OSD control to prevent
unintended changes to settings.
•Enable: To lock the OSD control, press and hold the MENU button for 10 seconds.
•Disable: To unlock the OSD control, press and hold the MENU button for more than 10
seconds.
―If the OSD control is locked,
Brightness and Contrast can be adjusted. Eye Saver Mode is available.
Information can be viewed.
―The Night View Mode function can be used by pressing the button. (The Night View
Mode is available even when the OSD control is locked.)
Press to enable or disable Night View Mode.
The items below are not available if the Night View Mode function is enable.
•Picture
SAMSUNG
MAGIC
Bright, Brightness, Eye Saver Mode, Game Mode
•System Eco Saving Plus
Move to the upper or lower menu or adjust the value for an option on the OSD menu.
: Use this button to control the brightness, contrast and sharpness of the screen.
Confirm a menu selection.
Pressing the button when the OSD menu is not displayed will change the input source
(Analog/HDMI). If you power on the product or change the input source by pressing the
button, a message that shows the changed input source will appear at the top left corner of the
screen.
AUTO
Press the AUTO button to automatically adjust the screen settings.
―Changing the resolution in Display Properties will activate the Auto Adjustment function.
―Available only in Analog mode.

15
Icons Description
Turn the screen on or off.
Function Key Guide
When a control button on the product is pressed, the Function Key Guide will be displayed
before the onscreen menu opens.
(The guide shows the function of the button pressed.)
To access the onscreen menu when the guide is displayed, press the corresponding button
again.
The Function Key Guide may vary depending on the function or product model.
Refer to the actual product.
―The function buttons page shows if Night View Mode is enabled.
―
NIGHT
VIEW
: Off
―
NIGHT
VIEW
: Mode1, Mode2, Mode3

16
Reverse Side
―The color and shape of parts may differ from what is shown. Specifications are
subject to change without notice to improve quality.
Port Description
Connects to the power adapter.
Connects to a source device using an HDMI cable or HDMI-DVI cable.
Connect to a PC using the D-SUB cable.

17
Installation
Attaching the Stand
―Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards.
1
Insert the stand neck into the stand base in the
direction shown in the figure.
2
Check that the stand neck is firmly connected.
3
Tightly fasten the connecting screw at the bottom of
the stand base.
44
Place a soft cloth over the table to protect the product
and place the product onto the cloth so that the front
of the product is facing downwards.
5
Hold the main body of the product with your hand as
shown by the figure.
Push the assembled stand into the main body in the
direction of the arrow as shown in the figure.
RGBIN
- Caution
Do not hold the product upside down only by the
stand.

18
Removing the Stand
―Before assembling the product, place the product down on a flat and stable surface so that the screen is facing downwards.
1
Place a soft cloth over the table to protect the product
and place the product onto the cloth so that the front of
the product faces downwards.
2
While holding the stand neck with one hand, pound the
other fisted hand down onto the top of the stand base in
the direction of the arrow to detach the stand base.
3
Turn the connecting screw at the bottom of the stand
base to separate it.
4
Remove the stand neck from the stand base by pulling it
in the direction of the arrow as shown in the figure.

19
Adjusting the Product Tilt
―The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve quality.
-1° (±2°) ~ 20° (±2°)
•You can adjust the tilt of your monitor.
•Hold the lower part of the product and adjust the tilt carefully.

20
Anti-theft Lock
―An anti-theft lock allows you to use the product securely even in public places.
―The locking device shape and locking method depend on the manufacturer. Refer to the user guide provided with your anti-theft locking device for details.
To lock an anti-theft locking device:
1
Fix the cable of your anti-theft locking device to a heavy object such as a desk.
2
Put one end of the cable through the loop on the other end.
3
Insert the Kensington Lock into the security slot on the back of the display.
4
Lock the locking device.
-An anti-theft locking device can be purchased separately.
-Refer to the user guide provided with your anti-theft locking device for details.
-Anti-theft locking devices can be purchased at electronics retailers or online.
