SyncMaster 940UX
Downloaded from ManualMonitor.com Manuals

Notational
Failure to follow directions noted by this symbol could result in bodily harm or damage to the
equipment.
Prohibited Important to read and understand at all times
Do not disassemble Disconnect the plug from the outlet
Do not touch Ground to prevent an electric shock
Power
When not used for an extended period of time, set your computer to DPM.
If using a screen saver, set it to active screen mode.
The images here are for reference only, and are not applicable in all cases (or countries).
Downloaded from ManualMonitor.com Manuals

Do not use a damaged or loose plug.
zThis may cause electric shock or fire.
Do not pull the plug out by the wire nor touch the plug with wet hands.
zThis may cause electric shock or fire.
Use only a properly grounded plug and receptacle.
zAn improper ground may cause electric shock or equipment damage. (Class l
Equipment only.)
Insert the power plug firmly so that it does not come loose.
zA bad connection may cause fire.
Do not excessively bend the plug and wire nor place heavy objects upon them,
which could cause damage.
zThis may cause electric shock or fire.
Do not connect too many extension cords or plugs to one outlet.
zThis may cause fire.
Do not disconnect the power cord while using the monitor.
zA surge may be caused by the separation and may damage the monitor.
Do not use the power cord when the connector or plug is dusty.
zIf the connector or plug of the power cord is dusty, clean it with a dry cloth.
zUsing the power cord with a dusty plug or connector may cause electric shock
or fire.
To disconnect the apparatus from the mains, the plug must be pulled out from
the mains socket, therefore the mains plug shall be readily operable.
zThis may cause electric shock or fire.
Downloaded from ManualMonitor.com Manuals

Installation
Be sure to contact an authorized Service Center, when installing your monitor in a
location with heavy dust, high or low temperatures, high humidity, and exposed to
chemical substances and where it operates for 24 hours such as at airports, train
stations etc.
Failure to do so may cause serious damage to your monitor.
Place your monitor in a location with low humidity and a minimum of dust.
zFailure to do so may cause electric shock or fire inside the monitor.
Do not drop the monitor when moving it.
zThis may cause damage to the product or the person carrying it.
Install the monitor base in a showcase or shelf so that the end of the base does
not protrude from the showcase or shelf.
zDropping the product may cause damage to the product or the person carrying
it.
Do not place the product on an unstable or small surface area.
zPlace the product on an even and stable surface, as the product may fall and
cause harm to someone walking by, specifically children.
Do not place the product on the floor.
zTake care, as someone, specifically children may trip over it.
TO PREVENT THE SPREAD OF FIRE, KEEP CANDLES OR OTHER OPEN
FLAMES AWAY FROM THIS PRODUCT AT ALL TIMES.
zOtherwise, this may cause fire.A melted coating may cause electric shock or
fire.
Keep any heating devices away from the power cable.
zA melted coating may lead to electric shock or fire.
Do not install the product in places with poor ventilation, for instance, a
Downloaded from ManualMonitor.com Manuals

bookshelf, closet, etc.
zAny increase in the internal temperature may cause fire.
Put down the monitor carefully.
zFailing to do so may damage the monitor.
Do not place the monitor face down.
zThis may damage the TFT-LCD surface.The installation of the bracket must be
done by a qualified professional.
Installing a wall bracket must be done by a qualified professional.
zInstalling the bracket by unqualified personnel may result in injury.
zAlways use the mounting device specified in the owner's manual.
When installing the product, make sure to keep it away from the wall (more
than 10 cm/4 inches) for ventilation purposes.
zPoor ventilation may cause an increase in the internal temperature of the
product, resulting in a shortened component life and degraded performance.
Keep the plastic packaging (bag) out of children's reach.
zThe plastic packaging (bag) may cause suffocation if children play with it.
Clean
When cleaning the monitor case or the surface of the TFT-LCD screen, wipe with a
slightly moistened, soft fabric.
Do not spray water or detergent directly onto the monitor.
zThis may cause damage, electric shock or fire.
Downloaded from ManualMonitor.com Manuals

Use the recommended detergent with a smooth cloth.
If the connector between the plug and the pin is dusty or dirty, clean it properly
using a dry cloth.
zA dirty connector may cause electric shock or fire.
Make sure to unplug the power cord before cleaning the product.
zOtherwise, this may cause electric shock or fire.
Unplug the power cord from the power outlet and wipe the product using a
soft, dry cloth.
zDo not use any chemicals such as wax, benzene, alcohol, thinners, insecticide,
air freshener, lubricant or detergent.
Contact the SAMSUNG customer care center or Customer Center for interior
cleaning once a year.
zKeep the product's interior clean. Dust which has accumulated in the interior
over an extended period of time may cause a malfunction or fire.
Others
Do not remove the cover (or back).
zThis may cause electric shock or fire.
zRefer to a qualified servicing company.
If your monitor does not operate normally - in particular, if there is any unusual
sound or smell coming from the monitor - unplug it immediately and contact an
authorized dealer or the Service Center.
zThis may cause electric shock or fire.
Keep the product away from places exposed to oil, smoke or moisture; do not
install inside a vehicle.
zThis may cause a malfunction, electric shock or fire.
zIn particular, avoid operating the monitor near water or outdoors where the
monitor could be exposed to snow or rain.
Downloaded from ManualMonitor.com Manuals

If the monitor is dropped or the casing is damaged, turn the monitor off and
unplug the power cord. Then contact the Service Center .
zThe monitor may malfunction, causing electric shock or fire.
Disconnect the plug from the outlet during storms or lightning or if it is not
used for a long period of time.
zFailure to do so may cause electric shock or fire.
Do not try to move the monitor by pulling only the wire or the signal cable.
zThis may cause a breakdown, electric shock or fire due to damage to the
cable.
Do not move the monitor right or left by pulling only the wire or the signal
cable.
zThis may cause a breakdown, electric shock or fire due to damage to the
cable.
Do not cover the vents on the monitor cabinet.
zBad ventilation may cause a breakdown or fire.
Do not place water containers, chemical products or small metal objects on the
monitor.
zThis may cause a malfunction, electric shock or fire.
zIf a foreign substance enters the monitor, unplug the power cord and contact
the Service Center.
Keep the product away from combustible chemical sprays or inflammable
substances.
zThis may cause an explosion or fire.
Never insert anything metallic into the monitor openings.
zThis may cause electric shock, fire or injury.
Do not insert metal objects such as chopsticks, wire and tools or inflammable
objects such as paper or matches into the vent, headphone port or AV ports or
etc.
zThis may cause electric shock or fire. If an alien substances or water enters the
product, turn the product off, unplug the power connector from the wall outlet
and contact the Service Center.
Downloaded from ManualMonitor.com Manuals

When viewing a fixed screen for an extended period of time, residual image or
blurriness may appear.
zChange the mode to energy saving mode or set a screensaver to a changing
picture when away from the monitor for an extended period of time.
Adjust the resolution and frequency to the level appropriate for the model.
zAn inappropriate resolution may cause undesirable picture quality.
19 inch (48 cm) - 1280 x 1024
Viewing the monitor continuously at a too close angle may result in damage to
your eyesight.
To ease eye strain, take at least a five-minute break after every hour of using
the monitor.
Do not install the product on an unstable, uneven surface or a location prone to
vibrations.
zDropping the product may cause damage to the product or the person carrying
it. Using the product in a location prone to vibrations may shorten the lifetime of
the product or may cause the product to catch fire.
When moving the monitor, turn off and unplug the power cord.
Make sure that all cables, including the antenna cable and cables connected to
other devices, are disconnected before moving the monitor.
zFailure to disconnect cables may damage it and cause fire or electric shock.
Place the product out of children's reach, as they could damage by hanging
onto it.
zA falling product may cause injury to the person or even fatality.
When not using the product for an extended period of time, keep the product
unplugged.
zOtherwise, this may cause heat emission from the accumulated dirt or
degraded insulation, causing electric shock or fire.
Do not place your children's favorite toys or any other objects of interest on
the product.
zChildren may try to climb on the product to retrieve an object. The product
could fall, causing injury or even fatality.
Downloaded from ManualMonitor.com Manuals

When lifting up or moving the monitor, do not lift the monitor upside down
while holding only the stand.
zThis may cause your monitor to fall, and become damaged or cause personal
injury.
Good Postures When Using the Monitor
Try to maintain a good posture when using the monitor.
zKeep your back straight.
zKeep a distance of about 45 ~ 50 cm between your eyes and the
monitor screen. Look at the screen from slightly above it, and have
the monitor directly in front of you.
zTilt the monitor upwards by 10 ~20 degrees. Adjust the monitor
height so that the top of the monitor is slightly below eye level.
zAdjust the monitor angle so that there is no reflected light on the
screen.Try to maintain your arms perpendicular to your armpits.
zKeep your arms level with the back of your hands.
zKeep the angle of the elbow perpendicular.
zKeep the angle of the knees at more than 90 degree. Do not let your
feet fall up from the floor. Adjust the arm position so that it is below
the heart.
Downloaded from ManualMonitor.com Manuals

Please make sure the following items are included with your monitor.
If any items are missing, contact your dealer.
Contact a local deale
r
to bu
y
o
p
tional items.
Unpacking
Without stand
Monito
r
With stand
Monitor & Slidin
g
Stand
Manual
Downloaded from ManualMonitor.com Manuals

Quick Setup Guide Warranty Card
(Not available in all locations)
User's Guide,
Monitor Driver,
Natural Color software
Cable
D-sub Cable Power Cord
USB Cable
Sold se
p
aratel
y
DVI-D Cable
Front
MENU button [ ]
Opens the OSD menu. Also use to exit the OSD menu or return to the
previous menu.
MagicBright™ [
]
MagicBright™ is a new feature providing optimum viewing environment
depending on the contents of the image you are watching. Currently
seven different modes are available: Custom, Text, Internet, Game,
Downloaded from ManualMonitor.com Manuals

Sport, Movie and Dynamic Contrast. Each mode has its own pre-
configured brightness value. You can easily select one of seven settings
by simply pressing MagicBright™ control button.
1) Custom
Although the values are carefully chosen by our engineers, the pre-
configured values may not be comfortable to your eyes depending on
your taste.
If this is the case, adjust the brightness and contrast by using the
OSD menu.
2) Text
For documentations or work involving a lot of text.
3) Internet
For working with a mixture of images such as texts and graphics.
4) Game
For watching motion pictures such as a game.
5) Sport
For watching motion pictures such as a sport.
6) Movie
For watching motion pictures such as a DVD or Video CD.
7) Dynamic Contrast
Dynamic Contrast is to automatically detect distribution of inputted
visual signal and adjust to create optimum contrast.
>>Click here to see an animation clip
Brightness button
[]
When OSD is not on the screen, push the button to adjust brightness.
>>Click here to see an animation clip
Not available in MagicBright™ mode of Dynamic Contrast.
Adjust buttons [
]
Adjust items in the menu.
Enter button [ ] Activates a highlighted menu item.
Press this to select the type of signal.
[Digital - Analog - USB ] : [Digital - Analog - USB]
If the monitor is used as a USB monitor (when connected via USB cable),
select USB mode by clicking the Enter icon.
AUTO button
[AUTO]
Use this button for auto adjustment.
>>Click here to see an animation clip
Power button [ ]/
Power indicator
Use this button for turn the monitor on and off.
This light glows blue during normal operation, and blinking blue once as the
monitor saves your adjustments.
Make sure to turn off your USB monitor after clicking on the “Remove hardware safely” icon on the
taskbar of your PC and unloading the USB device from Windows.Otherwise, your monitor may not
work normally.If your monitor does not turn on, reboot your PC.
See PowerSaver described in the manual for further information regarding power saving functions.
For energy conservation, turn your monitor OFF when it is not needed, or when leaving it
unattended for long periods.
Downloaded from ManualMonitor.com Manuals

(
The confi
g
uration at the back of the monitor ma
y
var
y
from
p
roduct to
p
roduct.
)
ON [ | ] / OFF [O]
Switch the monitor on and off.
POWER
Connect the power cord for your monitor to the POWER on the back
of the monitor.
Connect the of the monitor and the USB of the computer with the
USB cable.
Connect the of the USB monitor and a USB device with the USB
cable.
zTo use ( ) , you have to connect the (
) to the PC.
zMake sure to use the USB cable supplied with this
monitor to connect the monitor's and your
com
p
uter's USB.
DVI IN
Connect the DVI Cable to the DVI IN on the back of your monitor.
Rear
Downloaded from ManualMonitor.com Manuals

RGB IN
Connect the signal cable to the 15-pin, RGB IN on the back of your
monitor.
Kensington Lock
The Kensington lock is a device used to physically fix the system
when using it in a public place.
(The locking device has to be purchased separately.)
For using a locking device, contact where you
purchase it.
Stand Stopper
Remove the fixing pin on the stand to lift the monitor up and down.
See Connecting the Monitor for further information regarding cable connections.
Downloaded from ManualMonitor.com Manuals

Connecting the Monitor
Connect the power cord for your monitor to the power port on the back of the monitor.
Plug the power cord for the monitor into a nearby outlet.
Use appropriate connection for your computer.
Using the D-sub (Analog) connector on the video card.
Connect the signal cable to the 15-pin, D-sub port on the back of your monitor.
[ RGB IN ]
Using the DVI (Digital) connector on the video card.
Connect the DVI Cable to the DVI IN port on the back of your monitor.
[ DVI IN ]
Connected to a Macintosh.
Connect the monitor to the Macintosh computer using the D-sub connection cable.
If the monitor and the computer are connected, you can turn them on and use them.
Downloaded from ManualMonitor.com Manuals

You can use a USB device such as a mouse, keyboard, Memory Stick or external hard disk drive
by connecting them to the of the monitor without connecting them to the PC.
The USB of the monitor supports High-Speed Certified USB 2.0.
High speed Full speed Low speed
Data Rate 480 Mbps 12 Mbps 1.5 Mbps
Connect the of the monitor and the USB of the computer with the USB cable.
Connect the of the USB monitor and a USB device with the USB cable.
The use procedures are as the same as those for using an external device connecting to the PC.
To use , you have to connect the to the PC.
Make sure to use the USB cable supplied with this monitor to connect the monitor's
and your computer's USB port.
zYou can connect and use a keyboard and mouse.
zYou can play a file from a media device.
(Examples of media devices: MP3, digital camera, etc.)
zYou can run, move, copy or delete the files on the storage device.
(Examples of storage devices: external memory, memory card, memory reader,
HDD-type MP3 player, etc.)
zYou can use other USB devices that can be connected to a computer.
zWhen connecting a device to the of the monitor, connect the device using an
appropriate cable to the device.
(For the purchase of the cable and external devices, ask the service center of the
corresponding product.)
Connectin
g
USB
Downloaded from ManualMonitor.com Manuals

zThe company is not liable for problems or damages to an external device caused by
using an unauthorized cable for the connection.
zSome products do not follow the USB standard, and it may cause a malfunction of the
device.
zIf the device malfunctions even if it is connected to the computer, contact the service
center of the device/computer.
USB monitor
Y
ou can use this product as a monitor simpl
y
b
y
connectin
g
the power cable and the USB cable to
y
our PC.
Minimum hardware requirements
1. When connecting one (1) or two (2) USB monitors
Minimum hardware requirements: 1.2 GHz CPU / 512 MB memory
Display: One monitor can support DVD quality resolution in full screen mode.
( It may not support a sufficient frame speed during playback.)
2. When connecting three (3) USB monitors
Minimum hardware requirements: 1.8 GHz CPU / 1GB memory
Display: One monitor can support DVD quality resolution in full screen mode.
( It may not support a sufficient frame speed during playback.)
3. Monitor connection: Multiple screens of 6 monitors
Minimum hardware requirements: 1.6 GHz Dual core CPU / 1 GB memory
Display: One monitor can support DVD quality resolution in full screen mode.
( It may not support a sufficient frame speed during playback.)
When connecting serially
You can connect up to four (4) USB monitors serially.
When connectin
g
in parallel
You can connect up to six (6) USB monitors in parallel.
When connecting external devices to the USB monitor, you can only connect up to four (4) devices.
Installin
g
Your USB Monito
r
zMake sure to connect the USB cable and begin the installation after your PC has booted.
zThe auto installation will take about one minute. If you turn off your monitor or remove the USB
cable while the installation is in progress, it may cause a problem with your PC and Windows
OS.
zThe optimal resolution for this USB monitor is 1280 x 1024.
Installation
(
Auto & Manual
)
*The installation method is subject to change without prior notice for product enhancement purposes.
1. If you connect your USB monitor to your PC, it recognizes the monitor and the "Found New Hardware"
wizard is displayed, as shown in the figure below.
Downloaded from ManualMonitor.com Manuals

2. Click I Accept.
3. The installation is started automatically and the installation progress window is displayed, as shown in the
figure below.
zManual Installation: If the USB driver is not installed automatically, insert the provided USB Monitor
Install CD into the CD-ROM drive of your PC. ‘Double-click My Computer on the Windows Desktop and
click on User Manual (I:). The volume name of the removable storage disk (for example, E:, F:, G: ) may
be different depending on your computer environment.
Right-click it and select 'Open' from the displayed menu. Double-click the 'Setup' file and an installation
progress window is displayed, as shown in the figure below. The remaining steps are the same as for the
automatic installation.
4.When setup is finished, a monitor icon is created in the system tray at the bottom of the monitor screen,
and the information for the installed USB monitor is displayed.
5. When the installation is completed, configure the following settings to use multiple monitors.
5-1. Right-click on the ‘Windows Desktop’ and select ‘Properties’ from the displayed menu. The “Display
Properties” window appears.
5-2. 'Select the “Settings” tab. A list of connected USB monitors is displayed.
Downloaded from ManualMonitor.com Manuals

5-3. Arrange the monitors displayed in the 'Display Properties' window in the order they are actually
used.
5-4. Then click "OK" button.
Configuring the USB Monitor Display Information
1. When the driver setup for the USB monitor is finished, a monitor icon is created in the system tray at the
bottom of the monitor screen.
2. Click the monitor icon to display a list of connected USB monitors.
Example) The following figure shows when two USB monitors are connected.
3. Select the monitor for which you want to configure the display settings. You can configure the "Screen
Resolution" , "Color Quality" and "Screen Rotation" settings for your monitor.
Downloaded from ManualMonitor.com Manuals

Checking the configuration
A
fter the installation, you can check the configuration by following these steps.
1. 'Right-click ‘My Computer’, and select ‘Properties’ – ‘System Properties’ – the ‘Hardware tab’.
2. Click ‘Device Manager’.
3.
A
list of the installed device will be displayed, as shown in the figure below.
The Initial Screen Settin
g
s after Installin
g
the Pro
g
ram
A
pplicable mode: Extend mode
Mode position: To the right of the primary screen
Mode rotation: 0°
Downloaded from ManualMonitor.com Manuals
