Samsung DE55C User manual

User Manual
DE40C
DE46C
DE55C
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
BN46-00299A-02

Table Of Contents 2
Table Of Contents
BEFORE USING THE
PRODUCT
12 Copyright
13 Cleaning
13 Storage
14 Safety Precautions
14 Symbols
15 Electricity and Safety
16 Installation
18 Operation
PREPARATIONS 23 Checking the Contents
23 Removing the Packaging (for DE40C and
DE46C models only)
24 Removing the Packaging (for DE55C models
only)
25 Checking the Components
28 Parts
28 Control Panel
30 Reverse Side
31 Anti-theft Lock
32 Remote Control
35 Connection Using an IR Stereo Cable
36 Before Installing the Product (Installation
Guide)
36 Tilting Angle and Rotation
37 Ventilation
38 Dimensions
39 Installing the Wall Mount
39 Preparing before installing Wall-Mount
39 Installing the Wall Mount Kit
39 Wall Mount Kit Specifications (VESA)
41 Remote Control
41 Cable Connection
44 Connection
46 Control Codes

Table Of Contents
Table Of Contents 3
CONNECTING AND USING
A SOURCE DEVICE
56 Before Connecting
56 Pre-connection Checkpoints
57 Connecting and Using a PC
57 Connecting to a PC
60 Changing the Resolution
62 Connecting an External Monitor
63 Connecting to a Video Device
63 Connection Using the AV Cable
63 Connection Using the Component Cable
64 Connection Using an HDMI-DVI Cable
64 Connection Using an HDMI Cable
65 Connecting to an Audio System
65 Connecting to an Antenna
66 Connecting the network box (Sold
separately)
66 MagicInfo
70 Changing the Input source
70 Source
USING MDC 71 Configuring Settings for Multi Control
71 Configuring settings for Multi Control
72 MDC Program Installation/Uninstallation
72 Installation
72 Uninstallation

Table Of Contents
Table Of Contents 4
73 What is MDC?
73 Connecting to MDC
75 Connection Management
76 Auto Set ID
77 Cloning
78 Command Retry
79 Getting Started with MDC
81 Main Screen Layout
82 Menus
84 Screen Adjustment
87 Sound Adjustment
88 System Setup
97 Tool Settings
100 Other Functions
105 Troubleshooting Guide
SCREEN ADJUSTMENT 107 Picture Mode
107 If the input source is PC, DVI or DisplayPort
108 If the input source is AV, Component, HDMI or
TV
108 Backlight / Contrast / Brightness /
Sharpness / Color / Tint (G/R)
109 Screen Adjustment
109 Picture Size
111 Zoom/Position
111 PC Screen Adjustment
112 Resolution Select
112 Auto Adjustment

Table Of Contents
Table Of Contents 5
113 Advanced Settings
114 Dynamic Contrast
114 Black Tone
114 Flesh Tone
114 RGB Only Mode
114 Color Space
114 White Balance
114 10p White Balance (Off / On)
115 Gamma
115 Expert Pattern
115 Motion Lighting (Off / On)
116 Picture Options
117 Color Tone
117 Color Temp.
117 Digital Noise Filter
117 MPEG Noise Filter
118 HDMI Black Level
118 Film Mode
118 Calibrated Value
118 Dynamic Backlight
118 Reset Picture
SOUND ADJUSTMENT 119 Sound Mode
120 Sound Effect
121 Broadcast Audio Options
121 Speaker Settings
122 Reset Sound
CHANNEL 123 Antenna (Air / Cable)
124 Auto Program
124 Clear Scrambled Channel
125 Fine Tune
125 Crosstalk Noise Reduction

Table Of Contents
Table Of Contents 6
NETWORK 126 Network Setting
126 Connecting to a Wired Network
127 Wired Network Settings
130 Connecting to a Wireless Network
131 Wireless Network Setting
133 WPS(PBC)
134 Network Status
135 MagicInfo Lite Settings
136 Wi-Fi Direct
136 Soft AP
137 AllShare Settings
137 Using the AllShare Play Function
138 Device Name
SYSTEM 139 Setup
140 Multi Control
140 Configuring settings for Multi Control
141 Time
141 Clock
142 Sleep Timer
142 On Timer
143 Off Timer
143 Holiday Management
144 Menu Language
144 Rotate Menu
145 Eco Solution
145 Energy Saving
145 Eco Sensor (Off / On)
145 No Signal Power Off
146 Auto Power Off (Off / On)

Table Of Contents
Table Of Contents 7
146 Caption
146 Caption
146 Caption Mode
147 Digital Caption Options
148 Security
148 Safety Lock (Off / On)
148 Button Lock (Off / On)
149 Program Rating Lock (Off / On)
151 Change PIN
151 PIP
152 Auto Protection Time
153 Screen Burn Protection
153 Pixel Shift
154 Timer
154 Immediate Display
155 Side Gray
155 Ticker
156 Video Wall
156 Video Wall
156 Format
157 Horizontal
157 Vertical
157 Screen Position
158 Source AutoSwitch Settings

Table Of Contents
Table Of Contents 8
159 General
159 Max. Power Saving
159 Game Mode
160 BD Wise
160 Menu Transparency
160 Sound Feedback
160 Auto Power
160 Standby Control
161 Lamp Schedule
161 OSD Display
161 Power On Adjustment
161 Temperature Control
162 Anynet+ (HDMI-CEC)
162 Anynet+ (HDMI-CEC)
163 Auto Turn Off (No / Yes)
165 DivX® Video On Demand
165 Reset System
166 Reset All
166 PC Module Power
166 Synced Power-On
166 Synced Power-Off
SUPPORT 167 Software Update
167 By USB
167 Alternative Software
167 Contact Samsung
169 Contents Home
169 Channel List
170 Channel Manager
171 MagicInfo Lite
171 AllShare Play
172 Source

Table Of Contents
Table Of Contents 9
ALLSHARE PLAY 173 What is AllShare Play?
173 Read the following before using AllShare Play
with a USB device
175 Using a USB device
176 Connecting to a PC over a network
177 Using the DLNA features
178 Using the Basic AllShare Play Features
178 Sorting the file lists
179 Playing Selected Files
179 Copying Files
180 Creating a Playlist (Playlist)
181 My List
181 My List options
182 Videos
182 Playing a Video
183 Photos
183 Viewing a Photo (or Slide Show)
184 Music
184 Playing Music
185 Videos / Photos / Music Play Option
menu
187 Supported Subtitle and AllShare Play file
formats
187 Subtitle
187 Supported image resolutions
187 Supported music file formats
188 Supported Video Formats
MAGICINFO LITE 190 File Formats Compatible with MagicInfo
Lite Player
191 Contents

Table Of Contents
Table Of Contents 10
195 MagicInfo Lite Player
195 Network Schedule
200 Local Schedule
201 Internal AutoPlay
202 USB AutoPlay
203 Local Schedule Manager
203 Registering a Local Schedule
207 Modifying a Local Schedule
209 Deleting a Local Schedule
210 Running a Local Schedule
211 Stopping a Local Schedule
212 Viewing the details of a Local Schedule
214 Copying a Local Schedule (Local Schedule)
216 Content Manager
216 Copying content
217 Deleting content
218 Settings
218 Content Default Duration
218 Content Ratio
218 Image Effect
218 Default Content
219 Screen Layout
219 Delete All Content
219 Safety Remove USB
220 When Content is Running
220 Viewing the details of the content that is running
221 Changing the settings for the content that is
running
TROUBLESHOOTING
GUIDE
222 Requirements Before Contacting
Samsung Customer Service Center
222 Testing the Product
222 Checking the Resolution and Frequency
223 Check the followings.
226 Q & A

Table Of Contents
Table Of Contents 11
SPECIFICATIONS 228 General
230 PowerSaver
231 Standard Signal Mode Table
233 License
APPENDIX 234 Contact SAMSUNG WORLD WIDE
236 Responsibility for the Pay Service (Cost
to Customers)
236 Not a product defect
236 A Product damage caused by customer's fault
236 Others
237 Optimum Picture Quality and Afterimage
Burn-in Prevention
237 Optimum Picture Quality
238 Prevention of Afterimage Burn-in
240 Terminology
INDEX

12
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
© 2012 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
The SAMSUNG and SyncMaster logos are registered trademarks of Samsung Electronics.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.

13
Before Using the Product
Before Using the Product
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Storage
High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used
nearby.
Contact Customer Service Center if the inside of the product needs cleaning (service fee will be
charged).
1. Power off the product and computer.
2. Disconnect the power cord from the product.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the product with a clean, soft and dry cloth.
Do not use detergents that contain alcohol, solvent or
surface-active agents.
Do not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the exterior
of the product.
5. Connect the power cord to the product when cleaning is finished.
6. Power on the product and computer.
!

14
Before Using the Product
Before Using the Product
Safety Precautions
Symbols
CAUTION
RISK OF ELECTRIC SHOCK DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO
QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside. It is dangerous to
make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and
maintenance has been included with this product.
Warning A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.

15
Before Using the Product
Before Using the Product
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
An electric shock or fire may result.
Do not use multiple products with a single power socket.
Overheated power sockets may cause a fire.
Do not touch the power plug with wet hands. Otherwise, an electric shock may
result.
Insert the power plug all the way in so it is not loose.
An unsecure connection may cause a fire.
Connect the power plug to a grounded power socket (type 1 insulated devices
only).
An electric shock or injury may result.
Do not bend or pull the power cord with force. Be careful not to leave the power
cord under a heavy object.
Damage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
A fire or electric shock may result.
Clean any dust around the pins of the power plug or the power socket with a dry
cloth.
A fire may result.
!
!
!

16
Before Using the Product
Before Using the Product
Caution
Installation
Warning
Do not disconnect the power cord while the product is being used.
The product may become damaged by an electric shock.
Only use the power cord provided with your product by Samsung. Do not use the
power cord with other products.
A fire or electric shock may result.
Keep the power socket where the power cord is connected unobstructed.
The power cord must be disconnected to cut off power to the product when
an issue occurs.
Note that the product is not completely powered down by using only the
power button on the remote.
Hold the plug when disconnecting the power cord from the power socket.
An electric shock or fire may result.
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP
OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
A fire may result.
Have a technician install the wall-mount hanger.
Installation by an unqualified person can result in an injury.
Only use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or
closet.
An increased internal temperature may cause a fire.
Install the product at least 10 cm away from the wall to allow ventilation.
An increased internal temperature may cause a fire.
!
!
!
!
!

17
Before Using the Product
Before Using the Product
Keep the plastic packaging out of the reach of children.
Children may suffocate.
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.)
The product may fall and become damaged and/or cause an injury.
Using the product in an area with excess vibration may damage the product
or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
A fire or electric shock may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
The product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
The product may fall and injure children.
As the front is heavy, install the product on a flat and stable surface.
Bend and keep part of the outdoor TV antenna cable hanging downwards (the
part inside the room) to prevent rainwater from entering the product.
If rainwater enters the product, a fire or electric shock can occur.
When using an outdoor antenna, be sure to install the antenna away from nearby
power lines to prevent the antenna from collapsing onto them in strong winds.
A collapsed antenna can cause an electric shock or injury.
Edible oil, such as soybean oil, can damage or deform the product. Do not install
the product in a kitchen or near a kitchen counter.
!
!
!
!

18
Before Using the Product
Before Using the Product
Caution
Operation
Warning
Do not drop the product while moving.
Product failure or personal injury may result.
Do not set down the product on its front.
The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the bottom
edge of the front of the product is not protruding.
The product may fall and become damaged and/or cause an injury.
Install the product only on cabinets or shelves of the right size.
Set down the product gently
Product failure or personal injury may result.
Installing the product in an unusual place (a place exposed to a lot of fine
particles, chemical substances or extreme temperatures, or an airport or train
station where the product should operate continuously for an extended period of
time) may seriously affect its performance.
Be sure to consult Samsung Customer Service Center if you want to install
the product at such a place.
There is a high voltage inside the product. Never disassemble, repair or modify
the product yourself.
A fire or electric shock may result.
Contact Samsung Customer Service Center for repairs.
Before moving the product, turn off the power switch and disconnect the power
cord, antenna cable and all other connected cables.
Damage to the cord may result in a fire or electric shock.
!
!
SAMSUNG
!
!

19
Before Using the Product
Before Using the Product
If the product generates abnormal sounds, a burning smell or smoke, disconnect
the power cord immediately and contact Samsung Customer Service Center.
An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
Children may become injured or seriously harmed.
If the product is dropped or the outer case is damaged, turn off the power switch
and disconnect the power cord. Then contact Samsung Customer Service
Center.
Continued use can result in a fire or electric shock.
Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of
the product.
The product or heavy objects may fall as children try to reach for the toys or
sweets resulting in a serious injury.
During a lightning or thunderstorm, power off the product and remove the power
cable.
A fire or electric shock may result.
Do not drop objects on the product or apply impact.
A fire or electric shock may result.
Do not move the product by pulling the power cord or any cable.
Product failure, an electric shock or fire may result from a damaged cable.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate
the area immediately.
Sparks can cause an explosion or fire.
Do not lift or move the product by pulling the power cord or any cable.
Product failure, an electric shock or fire may result from a damaged cable.
Do not use or keep combustible spray or an inflammable substance near the
product.
An explosion or fire may result.
!
!
!
!
GAS
!

20
Before Using the Product
Before Using the Product
Caution
Ensure the vents are not blocked by tablecloths or curtains.
An increased internal temperature may cause a fire.
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that
burn easily (paper, matches, etc) into the product (via the vent or input/output
ports, etc).
Be sure to power off the product and disconnect the power cord when water
or other foreign substances have entered the product. Then contact
Samsung Customer Service Center.
Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
Be sure to power off the product and disconnect the power cord when water
or other foreign substances have entered the product. Then contact
Samsung Customer Service Center.
Product failure, an electric shock or fire may result.
Leaving the screen fixed on a stationary image for an extended period of time
may cause afterimage burn-in or defective pixels.
Activate power-saving mode or a moving-picture screen saver if you will not
be using the product for an extended period of time.
Disconnect the power cord from the power socket if you do not plan on using the
product for an extended period of time (vacation, etc).
Dust accumulation combined with heat can cause a fire, electric shock or
electric leakage.
Use the product at the recommended resolution and frequency.
Your eyesight may deteriorate.
Do not hold the product upside-down or move it by holding the stand.
The product may fall and become damaged or cause an injury.
100
!
!
-_-
!
!
