Samsung S19C150N User manual

User manual
S19C150N
S19C150F
S20C150FL
S20C150NL
S22C150N
S19C325N PLUS
S19G325N PLUS
S19H325N PLUS
S19R325N PLUS
S19V325N PLUS
S20C325B PLUS
S20G325B PLUS
S20H325B PLUS
S20R325B PLUS
S20V325B PLUS
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.

Table Of Contents 2
Table Of Contents
BEFORE USING THE
PRODUCT
11 Copyright
11 Icons used in this manual
12 Cleaning
13 Securing the Installation Space
13 Precautions for storage
14 Safety Precautions
14 Symbols for safety precautions
15 Electricity and Safety
16 Installation and Safety
18 Operation
22 Correct posture to use the product
PREPARATIONS 23 Checking the Contents
23 Removing the Packaging
24 Checking the Components
25 Parts
25 Frontal Button (The functions available may vary
depending on the product model.)
27 Frontal Button (The functions available may vary
depending on the product model.)
29 Frontal Button (The functions available may vary
depending on the product model.)
31 Reverse Side
33 Installation
33 Attaching the Stand (S19C150N / S19C150F /
S20C150FL / S20C150NL / S22C150N /
S19C325N PLUS / S19G325N PLUS /
S19H325N PLUS / S19R325N PLUS /
S20C325B PLUS / S20G325B PLUS /
S20H325B PLUS / S20R325B PLUS)
34 Attaching the Stand (S19V325N PLUS /
S20V325B PLUS)
35 Removing the Stand
(S19C150N / S19C150F / S20C150FL /
S20C150NL / S22C150N /

Table Of Contents
Table Of Contents 3
S19C325N PLUS / S19G325N PLUS /
S19H325N PLUS / S19R325N PLUS /
S20C325B PLUS / S20G325B PLUS /
S20H325B PLUS / S20R325B PLUS)
36 Removing the Stand (S19V325N PLUS /
S20V325B PLUS)
37 Installing a Wall-mount Kit or Desktop Stand
(S19C150F / S20C150FL / S19C325N PLUS /
S19G325N PLUS / S19H325N PLUS /
S19R325N PLUS / S19V325N PLUS)
38 Adjusting the Product Tilt
39 Anti-theft Lock
CONNECTING AND USING
A SOURCE DEVICE
40 Before Connecting
40 Pre-connection Checkpoints
41 Connecting and Using a PC
41 Connection Using the D-SUB Cable (Analogue
Type)
42 Connection Using the DVI Cable
43 Connection Using an DVI-HDMI Cable
43 Connecting the Power
44 Driver Installation
45 Setting Optimum Resolution
46 Changing the Resolution Using a PC
SCREEN SETUP 50 Brightness
50 Configuring Brightness
51 Contrast
51 Configuring Contrast
52 Sharpness
52 Configuring Sharpness
53 SAMSUNG MAGIC Bright
53 Configuring SAMSUNG MAGIC Bright

Table Of Contents
Table Of Contents 4
54 SAMSUNG MAGIC Upscale
54 Configuring SAMSUNG MAGIC Upscale
55 Image Size
55 Changing the Image Size
56 H-Position & V-Position
56 Configuring H-Position & V-Position
57 Coarse
57 Adjusting Coarse
58 Fine
58 Adjusting Fine
SCREEN SETUP 59 Brightness
59 Configuring Brightness
60 Contrast
60 Configuring Contrast
61 Sharpness
61 Configuring Sharpness
62 SAMSUNG MAGIC Bright
62 Configuring SAMSUNG MAGIC Bright
63 SAMSUNG MAGIC Angle
63 Configuring SAMSUNG MAGIC Angle
64 SAMSUNG MAGIC Upscale
64 Configuring SAMSUNG MAGIC Upscale
65 Image Size
65 Changing the Image Size
66 H-Position & V-Position
66 Configuring H-Position & V-Position
67 Coarse
67 Adjusting Coarse

Table Of Contents
Table Of Contents 5
68 Fine
68 Adjusting Fine
SCREEN SETUP 69 Brightness
69 Configuring Brightness
70 Contrast
70 Configuring Contrast
71 Sharpness
71 Configuring Sharpness
72 SAMSUNG MAGIC Bright
72 Configuring SAMSUNG MAGIC Bright
73 SAMSUNG MAGIC Angle
73 Configuring SAMSUNG MAGIC Angle
74 Coarse
74 Adjusting Coarse
75 Fine
75 Adjusting Fine
CONFIGURING TINT 76 Red
76 Configuring Red
77 Green
77 Configuring Green
78 Blue
78 Configuring Blue
79 Color Tone
79 Configuring the Color Tone Settings
80 Gamma
80 Configuring Gamma
CONFIGURING TINT 81 SAMSUNG MAGIC Color
81 Configuring SAMSUNG MAGIC Color

Table Of Contents
Table Of Contents 6
82 Red
82 Configuring Red
83 Green
83 Configuring Green
84 Blue
84 Configuring Blue
85 Color Tone
85 Configuring the Color Tone Settings
86 Gamma
86 Configuring Gamma
COORDINATING OSD 87 Language
87 Configuring Language
88 Menu H-Position & Menu V-Position
88 Configuring Menu H-Position & Menu V-
Position
89 Display Time
89 Configuring Display Time
90 Transparency
90 Changing Transparency
COORDINATING OSD 91 H-Position & V-Position
91 Configuring H-Position & V-Position
92 Image Size
92 Changing the Image Size
94 Menu H-Position & Menu V-Position
94 Configuring Menu H-Position & Menu V-
Position
SETUP AND RESET 95 Reset
95 Initializing Settings (Reset)

Table Of Contents
Table Of Contents 7
96 Eco Saving
96 Configuring Eco Saving
97 Off Timer
97 Configuring Off Timer
98 Turn Off After
98 Configuring Turn Off After
99 Key Repeat Time
99 Configuring Key Repeat Time
100 Customized Key
100 Configuring Customized Key
SETUP AND RESET 101 Reset
101 Initializing Settings (Reset)
102 Eco Saving
102 Configuring Eco Saving
103 Off Timer
103 Configuring Off Timer
104 Turn Off After
104 Configuring Turn Off After
105 Key Repeat Time
105 Configuring Key Repeat Time
106 Customized Key
106 Configuring Customized Key
SETUP AND RESET 107 Reset
107 Initializing Settings (Reset)
108 Language
108 Configuring Language
109 Eco Saving
109 Configuring Eco Saving

Table Of Contents
Table Of Contents 8
110 Off Timer On/Off
110 Configuring Off Timer On/Off
111 Off Timer Setting
111 Configuring Off Timer Setting
112 PC/AV Mode
112 Configuring PC/AV Mode
113 Key Repeat Time
113 Configuring Key Repeat Time
114 Customized Key
114 Configuring Customized Key
115 Auto Source
115 Configuring Auto Source
116 Display Time
116 Configuring Display Time
117 Menu Transparency
117 Changing Menu Transparency
INFORMATION MENU AND
OTHERS
118 INFORMATION
118 Displaying INFORMATION
119 Configuring Brightness and Contrast in
the Initial Screen
INSTALLING THE
SOFTWARE
120 MagicTune
120 What is "MagicTune"?
120 Installing the Software
121 Removing the Software
122 MultiScreen
122 Installing the Software
123 Removing the Software

Table Of Contents
Table Of Contents 9
TROUBLESHOOTING
GUIDE
124 Requirements Before Contacting
Samsung Customer Service Center
124 Testing the Product
124 Checking the Resolution and Frequency
124 Check the following.
127 Q & A
SPECIFICATIONS 129 General (S19C150N / S22C150N)
131 General (S19C150F / S20C150FL)
133 General (S20C150NL)
135 General (S19C325N PLUS / S19G325N
PLUS)
137 General (S19H325N PLUS / S19R325N
PLUS)
139 General (S19V325N PLUS / S20C325B
PLUS)
141 General (S20G325B PLUS / S20H325B
PLUS)
143 General (S20R325B PLUS / S20V325B
PLUS)
145 PowerSaver
146 Standard Signal Mode Table
APPENDIX 149 Contact SAMSUNG WORLD WIDE
155 Responsibility for the Pay Service (Cost
to Customers)
155 Not a product defect
155 A Product damage caused by customer's fault
155 Others

Table Of Contents
Table Of Contents 10
156 Correct Disposal
156 Correct Disposal of This Product (Waste
Electrical & Electronic Equipment)
157 Terminology
INDEX

11
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
2013 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Icons used in this manual
An administration fee may be charged if either
(a) an engineer is called out at your request and there is no defect in the product.
(i.e. where you have failed to read this user manual)
(b) you bring the unit to a repair centre and there is no defect in the product.
(i.e. where you have failed to read this user manual)
The amount of such administration charge will be advised to you before any work or home visit
is carried out.
The following images are for reference only. Real-life situations may
differ from what is shown in the images.
©

12
Before Using the Product
Before Using the Product
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
1. Power off the monitor and computer.
2. Disconnect the power cord from the monitor.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the monitor with a clean, soft and dry cloth.
Do not apply a cleaning agent that contains alcohol,
solvent, or surfactant to the monitor.
Do not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the monitor.
5. Connect the power cord to the product after cleaning the product.
6. Power on the monitor and computer.
!
!

13
Before Using the Product
Before Using the Product
Securing the Installation Space
Ensure some space around the product for ventilation. An internal temperature rise may cause fire and
damage the product. Be sure to allow the amount of space as shown below or greater when installing
the product.
The exterior may differ depending on the product.
Precautions for storage
Be sure to contact Samsung Customer Service Center (page 149) if the inside of the monitor needs
cleaning. (Service fee will be charged.)
3.93
inches
(10 cm)
3.93
inches
(10 cm)
3.93 inches(10 cm)
3.93 inches(10 cm)
3.93 inches
(10 cm)

14
Before Using the Product
Before Using the Product
Safety Precautions
Symbols for safety precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO
QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside. It is dangerous to
make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and
maintenance has been included with this product.
Warning A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.

15
Before Using the Product
Before Using the Product
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
An electric shock or fire may result.
Do not plug many products into the same power socket.
Otherwise, the socket may overheat and cause a fire.
Do not touch the power plug with wet hands.
Otherwise, an electric shock may result.
Insert the power plug all the way in so it is not loose.
An unstable connection may cause a fire.
Connect the power plug to a grounded power socket (type 1 insulated devices
only).
An electric shock or injury may result.
Do not bend or pull the power cord with force. Do not weigh the power cord
down with a heavy object.
A damaged power cord may cause an electric shock or fire.
Do not place the power cord or product near heat sources.
An electric shock or fire may result.
Remove foreign substances such as dust around the plug pins and power socket
with a dry cloth.
Otherwise, a fire may result.
!
!
!

16
Before Using the Product
Before Using the Product
Caution
Installation and Safety
Warning
Do not unplug the power cord when the product is in use.
The product may become damaged by an electric shock.
Do not use the power cord for products other than authorized products supplied
by Samsung.
An electric shock or fire may result.
Keep the power socket where the power cord is connected unobstructed.
If any problem occurs in the product, unplug the power cable to completely
cut the power to the product.
Power to the product cannot be completely cut off with the power button.
Hold the plug when disconnecting the power cord from the power socket.
An electric shock or fire may result.
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP
OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
Otherwise, a fire may result.
Avoid installing the product in a narrow space with bad ventilation, such as a
bookshelf or wall closet.
Otherwise, a fire may result due to an increased internal temperature.
Keep the plastic packaging bag for the product in a place that cannot be reached
by children.
Children may suffocate.
!
!
!
!

17
Before Using the Product
Before Using the Product
Caution
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.).
The product may fall and break or cause a personal injury.
Using the product in an area with excess vibration may damage the product
or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
An electric shock or fire may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
Otherwise, the product lifespan may be reduced, or a fire may result.
Do not install the product within the reach of young children.
The product may fall and injure children.
Edible oil, such as soybean oil, can damage or deform the product. Do not install
the product in a kitchen or near a kitchen counter.
Take care not to drop the product when moving it.
Otherwise, product failure or personal injury may result.
Do not set down the product on its front.
The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the bottom
edge of the front of the product is not protruding.
The product may fall and break or cause a personal injury.
Install the product only on cabinets or shelves of the right size.
!
!

18
Before Using the Product
Before Using the Product
Operation
Warning
Put down the product carefully.
The product may fall and break or cause a personal injury.
Installing the product in an unusual place (a place exposed to a lot of fine
particles, chemical substances or extreme temperatures, or an airport or train
station where the product should operate continuously for an extended period of
time) may seriously affect its performance.
Be sure to consult Samsung Customer Service Center (page 149) before
installation if you want to install the product at such a place.
High voltage runs through the product. Do not attempt to disassemble, repair, or
modify the product on your own.
An electric shock or fire may result.
Contact Samsung Customer Service Center (page 149) for repair.
Before moving the product, turn off the power switch and disconnect the power
cable and all other connected cables.
Otherwise, the power cord may be damaged and a fire or electric shock may
result.
If the product generates a strange noise, a burning smell, or smoke, remove the
power cord immediately and contact Samsung Customer Service Center (page
149).
An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
The product may fall, and your child may become injured or seriously
harmed.
If the product falls or the exterior is damaged, power off the product, remove the
power cord, and contact Samsung Customer Service Center (page 149).
Otherwise, an electric shock or fire may result.
Do not put a heavy object, toy, or sweets on top of the product.
The product or heavy objects may fall as children try to reach for the toy or
sweets resulting in a serious injury.
!
SAMSUNG
!
!
!

19
Before Using the Product
Before Using the Product
During a lightning or thunderstorm, power off the product and remove the power
cable.
An electric shock or fire may result.
Do not drop objects on the product or apply impact.
An electric shock or fire may result.
Do not move the product by pulling the power cord or any cable.
Otherwise, the power cable may be damaged and product failure, an electric
shock or fire may result.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate
the area immediately.
Sparks can cause an explosion or fire.
Do not lift or move the product by the power cord or any cable.
Otherwise, the power cable may be damaged and product failure, an electric
shock or fire may result.
Do not use or keep combustible spray or an inflammable substance near the
product.
An explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
Otherwise, a fire may result from an increased internal temperature.
Do not insert a metallic object (a chopstick, coin, hair pin, etc.) or inflammable
object (paper, match, etc.) into the vent or ports of the product.
If water or any foreign substance enters the product, be sure to power off the
product, remove the power cord, and contact Samsung Customer Service
Center (page 149).
Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
If water or any foreign substance enters the product, be sure to power off the
product, remove the power cord, and contact Samsung Customer Service
Center (page 149).
Product failure, an electric shock or fire may result.
!
!
!
GAS
!
100

20
Before Using the Product
Before Using the Product
Caution
Leaving the screen fixed on a stationary image for an extended period of time
may cause afterimage burn-in or defective pixels.
If you are not going to use the product for an extended period of time,
activate power-saving mode or a moving-picture screen saver.
Disconnect the power cord from the power socket if you do not plan on using the
product for an extended period of time (vacation, etc).
Otherwise, a fire may result from accumulated dust, overheating, an electric
shock, or electric leakage.
Use the product at the recommended resolution and frequency.
Your eyesight may deteriorate.
Do not put DC power adapters together.
Otherwise, a fire may result.
Remove the plastic bag from the DC power adapter before you use it.
Otherwise, a fire may result.
Do not let water enter the DC power device or get the device wet.
An electric shock or fire may result.
Avoid using the product outdoors where it can be exposed to rain or snow.
Be careful not to get the DC power adapter wet when you wash the floor.
Do not put the DC power adapter near to any heating apparatus.
Otherwise, a fire may result.
Keep the DC power adapter in a well-ventilated area.
Looking at the screen too close for an extended period of time can deteriorate
your eyesight.
!
!
-_-
!
!
!
!
