400MP
460MP
Features
Full Commercial Connectivity
Designed for demanding commercial
applications, the Samsung MP series
displays give you connections that
include VGA, DVI, CVBS, HDMI, BNC
and Component. Whatever your source,
the MP series will display it beautifully.
Optional Networkability and TV Tuner
Adding network capability (SBB-NT)
or digital TV (SBB-DT) is as easy as
adding a Samsung set back box. They
connect easily with our proprietary
HDMI cable. No professional installation
is required.
Full HD 1080p Resolution
With 1920 x 1080 resolution, the 460MP
is capable of displaying the highest
resolution images possible.
High Contrast Ratio and
Response Time
3,000:1 static contrast ratio, 40,000:1
dynamic contrast ratio and 8ms
response time combine to give you
crisp, sharp, motion video full of detail.
Built-in Speakers
The two 10W built-in speakers mean
you don’t have to source, pay for,
mount and wire external speakers.
460MP Dimensions
40" and 46" Professional LCD Displays
400MP 460MP
Panel Diagonal Size 40" 46"
Type S-PVA S-PVA
Resolution 1366 x 768 1920 x 1080
Pixel Pitch (H x W) 0.648 x 0.648 0.53025 x 0.53025
Brightness (Typ.) 450 cd/m2470 cd/m2
Contrast Ratio 3000:1 3000:1
Dynamic C/R 40,000:1 40,000:1
Viewing Angle (H/V) 178°/178° 178°/178°
Response Time (G-to-G) 8 ms 8 ms
Color Space (CIE1931) 72% 72%
Connectivity PC inputs VGA/DVI/BNC VGA/DVI/BNC
Video Inputs CVBS/HDMI CVBS/Component/HDMI CVBS/Component/HDMI
Speaker 10W x 2 (built-in) 10W x 2 (built-in)
Power Power Consumption (Max) 220W 270W
Power Consumption at
Stand-by (Max)
2W (Energy Saving ON) 2W (Energy Saving ON)
Power Supply AC 100 – 240 V (+/-10%), 50/60 Hz AC 100 – 240 V (+/-10%), 50/60 Hz
Operation Operating Temperature
(Normal/Protection Glass)
10°C ~ 40°C/ 10°C ~ 35°C 10°C ~ 40°C/ 10°C ~ 35°C
Humidity 10 – 80% 10 – 80%
MTBF 50,000 hours 50,000 hours
Regulations Safety: UL, CSA, NOM
EMC: FCC
Ergonomics & Environments (option): TCO’95, TCO’99
Safety: UL, CSA, NOM
EMC: FCC
Ergonomics & Environments (option): TCO’95, TCO’99
Feature Special Features - Lamp Error Detection
- Temperature Sensor
- Built in Fan
- Video Wall
- RS232C
- Lamp Error Detection
- Temperature Sensor
- Built in Fan
- Video Wall
- RS232C
Network Operating System Network Support with SBB Network Suport with SBB
Mechanical Spec VESA Mount 600 x 400 mm 600 x 400 mm
Cabinet Color Black Black
Weight (Set/Package) 42.8 lbs./50.5 lbs. 62.8 lbs./78.3 lbs.
Dimension (W/O Stand) 38.2" x 22.9" x 4.7" 43.4" x 25.9" x 4.9"
Dimension (With Stand) 38.2" x 25.3" x 12.2" 43.4" x 28.2" x 12.2"
Packing Dimension 42.7" x 27.7" x 12.2" 48.0" x 30.7" x 12.2"
Bezel Width 40 mm 40 mm
Protection Glass Optional Optional
Package
Contents
Manuals Quick Setup Guide, Warranty Card, Application CD Quick Setup Guide, Warranty Card, Application CD
Cables D-Sub, Power Cord D-Sub, Power Cord
Others Remote Controller, Batteries Remote Controller, Batteries
Optional
Accessories
Speaker Built-in Standard Built-in Standard
Wall Mount WMN-5770D WMN-5770D
Vertical Mount WMN-5770D WMN-5770D
Stand (Optional) STN-L3257D STN-L3257D
Green
Management
Emission Standard EMC EMC
RoHS Compliant n n
Energy Star Compliant n n
Product Recyclability CCFL panel contains mercury, please dispose of properly CCFL panel contains mercury, please dispose of properly
Packaging Recyclability Packing materials recyclable Packing materials recyclable
43.4"
25.9"
23.6"
2.3"
3.4"
4.9"
15.7"
9.1"
9.1"
12.1"
12.1"
12.3"
13.0"
1.2"
17.3"
28.2"
33.1" 2.4"
