Samsung S23E650D User manual

User manual
S22E450F
S22E650D
S23E650D
S23E650K
S24E450F
S24E650PL
S24E650XL
S24E650DW
S24E650MW
S24E650XW
S27E650D
S27E650X
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
BN46-00480A-11

Table Of Contents 2
Table Of Contents
BEFORE USING THE
PRODUCT
7 Copyright
7 Icons used in this manual
8 Cleaning
9 Securing the Installation Space
9 Precautions for storage
10 Safety Precautions
10 Symbols
11 Electricity and Safety
12 Installation and Safety
14 Operation and Safety
18 Correct posture to use the product
PREPARATIONS 19 Checking the Components
19 Checking the Components
21 Parts
21 Frontal Buttons (S22E450F / S24E450F)
23 Frontal Buttons (S24E650PL / S24E650XL /
S24E650XW / S27E650X)
25 Frontal Buttons (S22E650D / S23E650D /
S24E650DW / S27E650D)
27 Frontal Buttons (S23E650K / S24E650MW)
29 Reverse Side (S23E650K)
30 Reverse Side (S24E650MW)
31 Reverse Side (S22E450F / S24E450F)
32 Reverse Side (S22E650D / S23E650D /
S24E650DW / S27E650D)
33 Reverse Side (S24E650XL / S24E650XW /
S27E650X)
34 Reverse Side (S24E650PL)
35 Right Side View

Table Of Contents
Table Of Contents 3
36 Installation
36 Attaching the Stand
37 Adjusting the Product Tilt and Height
38 Rotating the Monitor
39 Installing a Wall-mount Kit or Desktop Stand
41 Anti-theft Lock
CONNECTING AND USING
A SOURCE DEVICE
42 Before Connecting
42 Pre-connection Checkpoints
43 Connecting and Using a PC
43 Connecting to a PC
47 Connecting the Power
51 Driver Installation
52 Setting Optimum Resolution
SCREEN SETUP 53 Brightness
53 Configuring Brightness
54 Contrast
54 Configuring Contrast
55 Sharpness
55 Configuring Sharpness
56 Eye Saver Mode
56 Configuring Eye Saver Mode
57 Game Mode
57 Configuring Game Mode
58 SAMSUNG MAGIC Bright
58 Configuring SAMSUNG MAGIC Bright
60 SAMSUNG MAGIC Angle (S22E450F /
S24E450F)
60 Configuring SAMSUNG MAGIC Angle
62 SAMSUNG MAGIC Upscale
62 Configuring SAMSUNG MAGIC Upscale

Table Of Contents
Table Of Contents 4
63 Image Size
63 Changing the Image Size
65 HDMI Black Level (S22E450F / S24E450F
/ S23E650K / S24E650PL)
65 Configuring the HDMI Black Level Settings
66 Response Time (Except S22E450F /
S24E450F)
66 Configuring the Response Time
67 H-Position & V-Position
67 Configuring H-Position & V-Position
69 Coarse
69 Adjusting Coarse
70 Fine
70 Adjusting Fine
CONFIGURING TINT 71 Red
71 Configuring Red
72 Green
72 Configuring Green
73 Blue
73 Configuring Blue
74 Color Tone
74 Configuring the Color Tone Settings
75 Gamma
75 Configuring Gamma
RESIZING OR
RELOCATING THE
SCREEN
76 Language
76 Changing the Language
77 Menu H-Position & Menu V-Position
77 Configuring Menu H-Position & Menu V-
Position

Table Of Contents
Table Of Contents 5
78 Display Time
78 Configuring Display Time
79 Transparency
79 Changing Transparency
SETUP AND RESET 80 Reset All
80 Initializing Settings (Reset All)
81 Smart Eco Saving
81 Configuring Smart Eco Saving
82 Off Timer Plus
82 Configuring Off Timer
84 Configuring Eco Timer
86 PC/AV Mode
86 Configuring PC/AV Mode
88 Key Repeat Time
88 Configuring Key Repeat Time
89 Source Detection
89 Configuring Source Detection
INFORMATION MENU AND
OTHERS
90 INFORMATION
90 Displaying INFORMATION
91 Configuring Brightness, Contrast and
Sharpness from the Initial Screen
92 Configuring Volume in the Initial Screen
INSTALLING THE
SOFTWARE
93 MultiScreen
93 Installing the Software
94 Removing the Software

Table Of Contents
Table Of Contents 6
TROUBLESHOOTING
GUIDE
95 Requirements Before Contacting
Samsung Customer Service Center
95 Testing the Product
95 Checking the Resolution and Frequency
95 Check the following.
98 Q & A
SPECIFICATIONS 100 General (S22E450F / S22E650D)
101 General (S23E650D / S23E650K)
102 General (S24E450F)
103 General (S24E650PL / S24E650XL)
104 General (S24E650DW / S24E650MW /
S24E650XW)
105 General (S27E650D / S27E650X)
106 PowerSaver
108 Standard Signal Mode Table
APPENDIX 111 Responsibility for the Pay Service (Cost
to Customers)
111 Not a product defect
111 A Product damage caused by customer's fault
111 Others
113 Correct Disposal
113 Correct Disposal of This Product (Waste
Electrical & Electronic Equipment)
113 Extended warranty
114 Terminology
INDEX

7
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
© 2015 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
Microsoft, Windows and Windows NT are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Icons used in this manual
The following images are for reference only. Real-life situations may
differ from what is shown in the images.

8
Before Using the Product
Before Using the Product
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
1. Power off the monitor and computer.
2. Disconnect the power cord from the monitor.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the monitor screen using a clean, soft and dry cloth.
Do not apply a cleaning agent that contains alcohol,
solvent, or surfactant to the monitor.
Do not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the monitor.
5. Connect the power cord to the product after cleaning the product.
6. Power on the monitor and computer.
!
!

9
Before Using the Product
Before Using the Product
Securing the Installation Space
Ensure some space around the product for ventilation. An internal temperature rise may cause fire
and damage the product. Be sure to allow the amount of space as shown below or greater when
installing the product.
The exterior may differ depending on the product.
Precautions for storage
Be sure to contact Samsung Customer Service Center if the inside of the monitor needs cleaning. (A
service fee will be charged.)
10 cm
10 cm
10 cm
10 cm
10 cm

10
Before Using the Product
Before Using the Product
Safety Precautions
Symbols
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO
QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside. It is dangerous to
make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and
maintenance has been included with this product.
Warning A serious or fatal injury may result if instructions are not followed.
Caution Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.

11
Before Using the Product
Before Using the Product
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
An electric shock or fire may result.
Do not plug many products into the same power socket.
Otherwise, the socket may overheat and cause a fire.
Do not touch the power plug with wet hands.
Otherwise, an electric shock may result.
Insert the power plug all the way in so it is not loose.
An unstable connection may cause a fire.
Ensure you connect the power plug to a grounded power socket. (type 1
insulated devices only).
An electric shock or injury may result.
Do not bend or pull the power cord with force. Do not weigh the power cord
down with a heavy object.
A damaged power cord may cause an electric shock or fire.
Do not place the power cord or product near heat sources.
An electric shock or fire may result.
Remove foreign substances such as dust around the plug pins and power socket
with a dry cloth.
Otherwise, a fire may result.
!
!
!

12
Before Using the Product
Before Using the Product
Caution
Installation and Safety
Warning
Do not unplug the power cord when the product is in use.
The product may become damaged by an electric shock.
Do not use the power cord for products other than authorized products supplied
by Samsung.
An electric shock or fire may result.
Keep the power socket where the power cord is connected unobstructed.
If any problem occurs in the product, unplug the power cable to completely
cut the power to the product.
Power to the product cannot be completely cut off with the power button.
Hold the plug when disconnecting the power cord from the power socket.
An electric shock or fire may result.
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP
OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
Otherwise, a fire may result.
Avoid installing the product in a narrow space with bad ventilation, such as a
bookshelf or wall closet.
Otherwise, a fire may result due to an increased internal temperature.
Keep the plastic packaging bag for the product in a place that cannot be reached
by children.
Children may suffocate.
!
!
!
!

13
Before Using the Product
Before Using the Product
Caution
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.).
The product may fall and break or cause a personal injury.
Using the product in an area with excess vibration may damage the product
or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
An electric shock or fire may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
Otherwise, the product lifespan may be reduced, or a fire may result.
Do not install the product within the reach of young children.
The product may fall and injure children.
Take care not to drop the product when moving it.
Otherwise, product failure or personal injury may result.
Do not set down the product on its front.
The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the bottom
edge of the front of the product is not protruding.
The product may fall and break or cause a personal injury.
Install the product only on cabinets or shelves of the right size.
!
!
Edible oil (such as soybean oil) may damage or distort the product. Keep the
product away from oil pollution.
And do not install or use the product in the kitchen or near the kitchen stove.

14
Before Using the Product
Before Using the Product
Operation and Safety
Warning
Put down the product carefully.
The product may fall and break or cause a personal injury.
Installing the product in an unusual place (a place exposed to a lot of fine dust,
chemical substances, extreme temperatures or a significant presence of
moisture, or a place where the product will operate continuously for an extended
period of time) may seriously affect its performance.
Be sure to consult Samsung Customer Service Center before installation if
you want to install the product at such a place.
High voltage runs through the product. Do not attempt to disassemble, repair, or
modify the product on your own.
An electric shock or fire may result.
Contact Samsung Customer Service Center for repair.
To move the product, first disconnect all the cables from it, including the power
cable.
Otherwise, the power cord may be damaged and a fire or electric shock may
result.
If the product generates a strange noise, a burning smell, or smoke, remove the
power cord immediately and contact Samsung Customer Service Center.
An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
The product may fall, and your child may become injured or seriously
harmed.
If the product falls or the exterior is damaged, power off the product, remove the
power cord, and contact Samsung Customer Service Center.
Otherwise, an electric shock or fire may result.
Do not put a heavy object, toy, or sweets on top of the product.
The product or heavy objects may fall as children try to reach for the toy or
sweets resulting in a serious injury.
!
SAMSUNG
!
!
!

15
Before Using the Product
Before Using the Product
If there is a thunderstorm or lightning strike, turn off the power and disconnect the
power cable.
An electric shock or fire may result.
Do not drop objects on the product or apply impact.
An electric shock or fire may result.
Do not move the product by pulling the power cord or any cable.
Otherwise, the cable may be damaged and product failure, an electric shock
or fire may result.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate
the area immediately.
Sparks can cause an explosion or fire.
Do not lift or move the product by pulling the power cord or any cable.
Otherwise, the cable may be damaged and product failure, an electric shock
or fire may result.
Do not use or keep combustible spray or an inflammable substance near the
product.
An explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
Otherwise, a fire may result from an increased internal temperature.
Do not insert a metallic object (a chopstick, coin, hair pin, etc.) or inflammable
object (paper, match, etc.) into the vent or ports of the product.
If water or any foreign substance enters the product, be sure to power off the
product, remove the power cord, and contact Samsung Customer Service
Center.
Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
If water or any foreign substance enters the product, be sure to power off the
product, remove the power cord, and contact Samsung Customer Service
Center.
Product failure, an electric shock or fire may result.
!
!
!
GAS
!
10 0

16
Before Using the Product
Before Using the Product
Caution
Leaving the screen fixed on a stationary image for an extended period of time
may cause afterimage burn-in or defective pixels.
zIf you are not going to use the product for an extended period of time,
activate power-saving mode or a moving-picture screen saver.
Disconnect the power cord from the power socket if you do not plan on using the
product for an extended period of time (vacation, etc.).
zOtherwise, a fire may result from accumulated dust, overheating, an electric
shock, or electric leakage.
Use the product at the recommended resolution and frequency.
zOtherwise,Your eyesight may deteriorate.
Do not put DC power adapters together.
zOtherwise, a fire may result.
Remove the plastic bag from the DC power adapter before you use it.
zOtherwise, a fire may result.
Do not let water enter the DC power device or get the device wet.
zAn electric shock or fire may result.
zAvoid using the product outdoors where it can be exposed to rain or snow.
zBe careful not to get the DC power adapter wet when you wash the floor.
Do not put the DC power adapter near to any heating apparatus.
zOtherwise, a fire may result.
Keep the DC power adapter in a well-ventilated area.
If you place the AC/DC power adapter so that it is hanging with the cord input
facing upwards, water or other foreign substances could enter the Adapter and
cause the Adapter to malfunction.
Make sure to rest the AC/DC power adapter flat on a table or the floor.
!
!
-_-
!
!
!
!

17
Before Using the Product
Before Using the Product
Looking at the screen too close for an extended period of time can deteriorate
your eyesight.
Do not hold the monitor upside-down or move it by holding the stand.
zThe product may fall and break or cause a personal injury.
Do not use humidifiers or stoves around the product.
zAn electric shock or fire may result.
Rest your eyes for more than 5 minutes for every 1 hour of product use.
zEye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an extended
period of time as it will become hot.
Store the small accessories used with the product out of reach of children.
Exercise caution when adjusting the product angle or stand height.
zOtherwise, children's fingers or hands may become stuck and injured.
zTilting the product excessively may cause it to fall and result in personal
injury.
Do not place heavy objects on the product.
zProduct failure or personal injure may result.
When using headphones or earphones, do not turn the volume too high.
zHaving the sound too loud may damage your hearing.
!
!
!
!

18
Before Using the Product
Before Using the Product
Correct posture to use the product
Use the product in the correct posture as follows:
Straighten your back.
Allow a distance of 45 to 50 cm between your eye and the screen, and look slightly
downward at the screen.
Keep your eyes directly in front of the screen.
Adjust the angle so light does not reflect on the screen.
Keep your forearms perpendicular to your upper arms and level with the back of
your hands.
Keep your elbows at about a right angle.
Adjust the height of the product so you can keep your knees bent at 90 degrees or
more, your heels attached to the floor, and your arms lower than your heart.

19
1 Preparations
1 Preparations
1.1 Checking the Components
1.1.1 Checking the Components
zContact the dealer from whom you purchased the product if any item is missing.
zThe appearance of the components may differ from the images shown.
Components
Quick setup guide Warranty card
(Not available in some locations)
Regulatory guide
(optional)
User manual
(optional) Power cable D-SUB cable
(optional)
D-SUB cable
(optional)
DVI cable
(optional)
DVI cable
(optional)
HDMI cable
(optional)
HDMI-DVI cable
(optional)
DP cable
(optional)
Stereo Cable
(optional)
USB cable
(optional)
Stand base
(optional)

20
Preparations
1
1 Preparations
Components may vary depending on the country.
Stand base
(Applicable to the stand
models that have USB ports
only.)
(optional)
Stand neck
(optional)
