Samsung S24D300B User manual

User manual
S19D300HY
S19D340HY
S19D300NY
S20D300BY
S20D300H
S20D340H
S20D300HY
S20D340HY
S22D300BY
S22D300HY
S22D340HY
S22D300NY
S24D300B
S24D300BL
S24D300H
S24D340H
S24D300HL
S24D340HL
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
BN46-00382G-01

Table Of Contents 2
Table Of Contents
BEFORE USING THE
PRODUCT
8 Copyright
8 Icons used in this manual
9 Cleaning
10 Securing the Installation Space
10 Precautions for storage
11 Safety Precautions
11 Symbols for safety precautions
12 Electricity and Safety
13 Installation and Safety
15 Operation
19 Correct posture to use the product
PREPARATIONS 20 Checking the Contents
20 Checking the Components
21 Parts
21 Frontal Button
32 Reverse Side
35 Installation
35 Attaching the Stand (S19D300HY / S19D340HY
/ S19D300NY)
36 Attaching the Stand (S20D300BY / S20D300H /
S20D340H / S20D300HY / S20D340HY /
S22D300BY / S22D300HY / S22D340HY /
S22D300NY / S24D300B / S24D300BL /
S24D300H / S24D340H / S24D300HL /
S24D340HL)
37 Removing the Stand (S19D300HY /
S19D340HY / S19D300NY)

Table Of Contents
Table Of Contents 3
38 Removing the Stand (S20D300BY / S20D300H
/ S20D340H / S20D300HY / S20D340HY /
S22D300BY / S22D300HY / S22D340HY /
S22D300NY / S24D300B / S24D300BL /
S24D300H / S24D340H / S24D300HL /
S24D340HL)
39 Installing a Wall-mount Kit or Desktop Stand
(S19D300HY / S19D340HY / S19D300NY /
S24D300H (LS24D300HSM* model only))
40 Adjusting the Product Tilt
41 Anti-theft Lock
CONNECTING AND USING
A SOURCE DEVICE
42 Before Connecting
42 Pre-connection Checkpoints
42 Connecting and Using a PC
42 Connection Using the D-SUB Cable (Analog
Type)
43 Connection Using the DVI Cable (S20D300BY /
S22D300BY / S24D300B / S24D300BL)
44 Connection Using the DVI-HDMI Cable
(S20D300BY / S22D300BY / S24D300B /
S24D300BL)
44 Connection Using the HDMI Cable (S19D300HY
/ S19D340HY / S20D300H / S20D340H /
S20D300HY / S20D340HY / S22D300HY /
S22D340HY / S24D300H / S24D340H /
S24D300HL / S24D340HL)
45 Connection Using the HDMI-DVI Cable
(S19D300HY / S19D340HY / S20D300H /
S20D340H / S20D300HY / S20D340HY /
S22D300HY / S22D340HY / S24D300H /
S24D340H / S24D300HL / S24D340HL)
46 Connecting the Power
48 Driver Installation
49 Setting Optimum Resolution
SCREEN SETUP 50 Brightness
50 Configuring Brightness

Table Of Contents
Table Of Contents 4
51 Contrast
51 Configuring Contrast
52 Sharpness
52 Configuring Sharpness
53 Game Mode
53 Configuring Game Mode
54 SAMSUNG MAGIC Bright
54 Configuring SAMSUNG MAGIC Bright
56 SAMSUNG MAGIC Angle (S20D300H /
S20D340H / S24D300B / S24D300H /
S24D340H)
56 Configuring SAMSUNG MAGIC Angle
58 SAMSUNG MAGIC Upscale
58 Configuring SAMSUNG MAGIC Upscale
59 Image Size
59 Changing the Image Size
61 HDMI Black Level (S19D300HY /
S19D340HY / S20D300H / S20D340H /
S20D300HY / S20D340HY / S22D300HY /
S22D340HY / S24D300H / S24D340H /
S24D300HL / S24D340HL)
61 Configuring the HDMI Black Level Settings
63 Response Time (S24D300H / S24D340H)
63 Configuring the Response Time
64 H-Position & V-Position
64 Configuring H-Position & V-Position
66 Coarse
66 Adjusting Coarse
67 Fine
67 Adjusting Fine

Table Of Contents
Table Of Contents 5
CONFIGURING TINT 68 Red
68 Configuring Red
69 Green
69 Configuring Green
70 Blue
70 Configuring Blue
71 Color Tone
71 Configuring the Color Tone Settings
72 Gamma
72 Configuring Gamma
COORDINATING OSD 73 Language
73 Configuring Language
74 Menu H-Position & Menu V-Position
74 Configuring Menu H-Position & Menu V-
Position
75 Display Time
75 Configuring Display Time
76 Transparency
76 Changing Transparency
SETUP AND RESET 77 Reset All
77 Initializing Settings (Reset All)
78 Eco Saving
78 Configuring Eco Saving
79 Off Timer
79 Configuring Off Timer
80 Configuring Turn Off After

Table Of Contents
Table Of Contents 6
81 PC/AV Mode (S19D300HY / S19D340HY
/ S20D300BY / S20D300H / S20D340H /
S20D300HY / S20D340HY / S22D300BY /
S22D300HY / S22D340HY / S24D300B /
S24D300BL / S24D300H / S24D340H /
S24D300HL / S24D340HL)
81 Configuring PC/AV Mode
83 Key Repeat Time
83 Configuring Key Repeat Time
84 Source Detection (S19D300HY /
S19D340HY / S20D300BY / S20D300H /
S20D340H / S20D300HY / S20D340HY /
S22D300BY / S22D300HY / S22D340HY /
S24D300B / S24D300BL / S24D300H /
S24D340H / S24D300HL / S24D340HL)
84 Configuring Source Detection
INFORMATION MENU AND
OTHERS
85 INFORMATION
85 Displaying INFORMATION
86 Configuring Brightness and Contrast in
the Initial Screen
INSTALLING THE
SOFTWARE
87 Easy Setting Box
87 Installing the Software
88 Removing the Software
TROUBLESHOOTING
GUIDE
89 Requirements Before Contacting
Samsung Customer Service Center
89 Testing the Product
89 Checking the Resolution and Frequency
89 Check the following.
92 Q & A
SPECIFICATIONS 94 General (S19D300HY / S19D340HY /
S19D300NY)

Table Of Contents
Table Of Contents 7
96 General (S20D300BY / S20D300H /
S20D340H / S20D300HY / S20D340HY)
97 General (S22D300BY / S22D300HY /
S22D340HY / S22D300NY)
98 General (S24D300BL / S24D300HL /
S24D300H / S24D300B)
100 General (S24D340HL / S24D340H)
102 PowerSaver
104 Standard Signal Mode Table
APPENDIX 109 Contact SAMSUNG WORLD WIDE
115 Responsibility for the Pay Service (Cost
to Customers)
115 Not a product defect
115 A Product damage caused by customer's fault
115 Others
116 Correct Disposal
116 Correct Disposal of This Product (Waste
Electrical & Electronic Equipment)
117 Terminology
INDEX

8
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
2014 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
Microsoft and Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Icons used in this manual
zAn administration fee may be charged if either
(a) an engineer is called out at your request and there is no defect in the product.
(i.e. where you have failed to read this user manual)
(b) you bring the unit to a repair center and there is no defect in the product.
(i.e. where you have failed to read this user manual)
zThe amount of such administration charge will be advised to you before any work or home visit
is carried out.
The following images are for reference only. Real-life situations may
differ from what is shown in the images.
©

9
Before Using the Product
Before Using the Product
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
1. Power off the monitor and computer.
2. Disconnect the power cord from the monitor.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the monitor with a clean, soft and dry cloth.
zDo not apply a cleaning agent that contains alcohol,
solvent, or surfactant to the monitor.
zDo not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the monitor.
5. Connect the power cord to the product after cleaning the product.
6. Power on the monitor and computer.
!
!

10
Before Using the Product
Before Using the Product
Securing the Installation Space
Ensure some space around the product for ventilation. An internal temperature rise may cause fire and
damage the product. Be sure to allow the amount of space as shown below or greater when installing
the product.
The exterior may differ depending on the product.
Precautions for storage
Be sure to contact Samsung Customer Service Center (page 109) if the inside of the monitor needs
cleaning. (Service fee will be charged.)
3.93
inches
(10 cm)
3.93
inches
(10 cm)
3.93 inches (10 cm)
3.93 inches (10 cm)
3.93 inches
(10 cm)

11
Before Using the Product
Before Using the Product
Safety Precautions
Symbols for safety precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER (OR
BACK). THERE ARE NO USER SERVICEABLE PARTS INSIDE. REFER ALL SERVICING TO
QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside. It is dangerous to
make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and
maintenance has been included with this product.
Warning A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are
not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.

12
Before Using the Product
Before Using the Product
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
zAn electric shock or fire may result.
Do not plug many products into the same power socket.
zOtherwise, the socket may overheat and cause a fire.
Do not touch the power plug with wet hands.
zOtherwise, an electric shock may result.
Insert the power plug all the way in so it is not loose.
zAn unstable connection may cause a fire.
Connect the power plug to a grounded power socket (type 1 insulated devices
only).
zAn electric shock or injury may result.
Do not bend or pull the power cord with force. Do not weigh the power cord
down with a heavy object.
zA damaged power cord may cause an electric shock or fire.
Do not place the power cord or product near heat sources.
zAn electric shock or fire may result.
Remove foreign substances such as dust around the plug pins and power socket
with a dry cloth.
zOtherwise, a fire may result.
!
!
!

13
Before Using the Product
Before Using the Product
Caution
Installation and Safety
Warning
Do not unplug the power cord when the product is in use.
zThe product may become damaged by an electric shock.
Do not use the power cord for products other than authorized products supplied
by Samsung.
zAn electric shock or fire may result.
Keep the power socket where the power cord is connected unobstructed.
zIf any problem occurs in the product, unplug the power cable to completely
cut the power to the product.
Power to the product cannot be completely cut off with the power button.
Hold the plug when disconnecting the power cord from the power socket.
zAn electric shock or fire may result.
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP
OF THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
zOtherwise, a fire may result.
Avoid installing the product in a narrow space with bad ventilation, such as a
bookshelf or wall closet.
zOtherwise, a fire may result due to an increased internal temperature.
Keep the plastic packaging bag for the product in a place that cannot be reached
by children.
zChildren may suffocate.
!
!
!
!

14
Before Using the Product
Before Using the Product
Caution
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.).
zThe product may fall and break or cause a personal injury.
zUsing the product in an area with excess vibration may damage the product
or cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
zAn electric shock or fire may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
zOtherwise, the product lifespan may be reduced, or a fire may result.
Do not install the product within the reach of young children.
zThe product may fall and injure children.
Edible oil, such as soybean oil, can damage or deform the product. Do not install
the product in a kitchen or near a kitchen counter.
Take care not to drop the product when moving it.
zOtherwise, product failure or personal injury may result.
Do not set down the product on its front.
zThe screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the bottom
edge of the front of the product is not protruding.
zThe product may fall and break or cause a personal injury.
zInstall the product only on cabinets or shelves of the right size.
!
!

15
Before Using the Product
Before Using the Product
Operation
Warning
Put down the product carefully.
zThe product may fall and break or cause a personal injury.
Installing the product in an unusual place (a place exposed to a lot of fine dust,
chemical substances, extreme temperatures or a significant presence of
moisture, or a place where the product will operate continuously for an extended
period of time) may seriously affect its performance.
zBe sure to consult Samsung Customer Service Center (page 109) before
installation if you want to install the product at such a place.
High voltage runs through the product. Do not attempt to disassemble, repair, or
modify the product on your own.
zAn electric shock or fire may result.
zContact Samsung Customer Service Center (page 109) for repair.
Before moving the product, turn off the power switch and disconnect the power
cable and all other connected cables.
zOtherwise, the power cord may be damaged and a fire or electric shock may
result.
If the product generates a strange noise, a burning smell, or smoke, remove the
power cord immediately and contact Samsung Customer Service Center
(page 109).
zAn electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
zThe product may fall, and your child may become injured or seriously
harmed.
If the product falls or the exterior is damaged, power off the product, remove the
power cord, and contact Samsung Customer Service Center (page 109).
zOtherwise, an electric shock or fire may result.
Do not put a heavy object, toy, or sweets on top of the product.
zThe product or heavy objects may fall as children try to reach for the toy or
sweets resulting in a serious injury.
!
SAMSUNG
!
!
!

16
Before Using the Product
Before Using the Product
During a lightning or thunderstorm, power off the product and remove the power
cable.
zAn electric shock or fire may result.
Do not drop objects on the product or apply impact.
zAn electric shock or fire may result.
Do not move the product by pulling the power cord or any cable.
zOtherwise, the power cable may be damaged and product failure, an electric
shock or fire may result.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate
the area immediately.
zSparks can cause an explosion or fire.
Do not lift or move the product by the power cord or any cable.
zOtherwise, the power cable may be damaged and product failure, an electric
shock or fire may result.
Do not use or keep combustible spray or an inflammable substance near the
product.
zAn explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
zOtherwise, a fire may result from an increased internal temperature.
Do not insert a metallic object (a chopstick, coin, hair pin, etc.) or inflammable
object (paper, match, etc.) into the vent or ports of the product.
zIf water or any foreign substance enters the product, be sure to power off the
product, remove the power cord, and contact Samsung Customer Service
Center (page 109).
zProduct failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
zIf water or any foreign substance enters the product, be sure to power off the
product, remove the power cord, and contact Samsung Customer Service
Center (page 109).
zProduct failure, an electric shock or fire may result.
!
!
!
GAS
!
100

17
Before Using the Product
Before Using the Product
Caution
Leaving the screen fixed on a stationary image for an extended period of time
may cause afterimage burn-in or defective pixels.
zIf you are not going to use the product for an extended period of time,
activate power-saving mode or a moving-picture screen saver.
Disconnect the power cord from the power socket if you do not plan on using the
product for an extended period of time (vacation, etc).
zOtherwise, a fire may result from accumulated dust, overheating, an electric
shock, or electric leakage.
Use the product at the recommended resolution and frequency.
zYour eyesight may deteriorate.
Do not put DC power adapters together.
zOtherwise, a fire may result.
Remove the plastic bag from the DC power adapter before you use it.
zOtherwise, a fire may result.
Do not let water enter the DC power device or get the device wet.
zAn electric shock or fire may result.
zAvoid using the product outdoors where it can be exposed to rain or snow.
zBe careful not to get the DC power adapter wet when you wash the floor.
Do not put the DC power adapter near to any heating apparatus.
zOtherwise, a fire may result.
Keep the DC power adapter in a well-ventilated area.
Looking at the screen too close for an extended period of time can deteriorate
your eyesight.
!
!
-_-
!
!
!
!

18
Before Using the Product
Before Using the Product
Do not hold the monitor upside-down or move it by holding the stand.
zThe product may fall and break or cause a personal injury.
Do not use humidifiers or stoves around the product.
zAn electric shock or fire may result.
Rest your eyes for more than 5 minutes for every 1 hour of product use.
zEye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an extended
period of time as it will become hot.
Store the small accessories used with the product out of reach of children.
Exercise caution when adjusting the product angle or stand height.
zOtherwise, children's fingers or hands may become stuck and injured.
zTilting the product excessively may cause it to fall and result in personal
injury.
Do not place heavy objects on the product.
zProduct failure or personal injure may result.
!
!
!

19
Before Using the Product
Before Using the Product
Correct posture to use the product
Use the product in the correct posture as follows:
zStraighten your back.
zAllow a distance of 45 to 50 cm between your eye and the screen, and look slightly
downward at the screen.
Keep your eyes directly in front of the screen.
zAdjust the angle so light does not reflect on the screen.
zKeep your forearms perpendicular to your upper arms and level with the back of
your hands.
zKeep your elbows at about a right angle.
zAdjust the height of the product so you can keep your knees bent at 90 degrees or
more, your heels attached to the floor, and your arms lower than your heart.
50 cm

20
1 Preparations
1 Preparations
1.1 Checking the Contents
1.1.1 Checking the Components
zContact the dealer from whom you purchased the product if any item is missing.
zThe appearance of the components and items sold separately may differ from the image shown.
Components
Components may vary depending on the country.
Quick setup guide Warranty card
(Not available in some locations)
Regulatory guide
User manual (optional) DC power adapter
(Integrated) (optional)
DC power adapter
(Detachable) (optional)
Power cable (Only provided
with the detachable DC power
adapter.)
D-SUB cable (optional) DVI cable (optional)
HDMI cable (optional) HDMI-DVI cable (optional) Stand base
Stand neck
