Samsung ME32B User manual

User Manual
ME32B ME40B ME46B ME55B
UE46A UE55A
The color and the appearance may differ depending on
the product, and the specifications are subject to
change without prior notice to improve the performance.
BN46-00098H-05

Table Of Contents 2
Table Of Contents
BEFORE USING THE
PRODUCT
11 Copyright
12 Cleaning
12 Storage
13 Safety Precautions
13 Symbols
14 Electricity and Safety
15 Installation
17 Operation
PREPARATIONS 21 Checking the Contents
21 Removing the Packaging
22 Checking the Components
24 Parts
24 Control Panel
25 Reverse Side
27 Anti-theft Lock
28 Remote Control
31 Connection Using an IR Stereo Cable
32 Before Installing the Product (Installation
Guide)
32 Tilting Angle and Rotation
33 Ventilation
35 Dimensions
36 Installing the Wall Mount
36 Preparing before installing Wall-Mount
36 Installing the Wall Mount Kit
36 Wall Mount Kit Specifications (VESA)
38 Remote Control
38 Cable Connection
41 Connection
43 Control Codes
CONNECTING AND USING
A SOURCE DEVICE
53 Before Connecting
53 Pre-connection Checkpoints

Table Of Contents
Table Of Contents 3
54 Connecting and Using a PC
54 Connecting to a PC
57 Changing the Resolution
59 Connecting an External Monitor
60 Connecting to a Video Device
60 Connection Using the AV Cable
60 Connection Using the component Cable
61 Connection Using an HDMI-DVI Cable
61 Connection Using an HDMI Cable
62 Connecting to an Audio System
63 Connecting the network box (Sold
separately)
63 MagicInfo
67 Changing the Input source
67 Source
USING MDC 68 Configuring Settings for Multi Control
68 Configuring settings for Multi Control
69 MDC Program Installation/Uninstallation
69 Installation
69 Uninstallation

Table Of Contents
Table Of Contents 4
70 What is MDC?
70 Connecting to MDC
72 Connection Management
73 Auto Set ID
74 Cloning
75 Command Retry
76 Getting Started with MDC
78 Main Screen Layout
79 Menus
81 Screen Adjustment
85 Sound Adjustment
86 System Setup
94 Tool Settings
96 Other Functions
101 Troubleshooting Guide
SCREEN ADJUSTMENT 103 Picture Mode
103 If the input source is PC, DVI or DP
103 If the input source is AV, Component, HDMI
104 Backlight / Contrast / Brightness /
Sharpness / Colo(u)r / Tint(G/R)
104 Screen Adjustment
105 Picture Size
106 Position
106 PC Screen Adjustment
107 Resolution Select
107 Auto Adjustment
107 Using the 3D function (UE46A & UE55A
models only)
107 3D Mode
107 Viewing product Using the 3D function

Table Of Contents
Table Of Contents 5
111 Advanced Settings
111 Black Tone
111 Dynamic Contrast
111 Shadow Detail
111 Gamma
112 Expert Pattern
112 RGB Only Mode
112 Colo(u)r Space
112 White Balance
113 10p White Balance (Off / On)
113 Flesh Tone
113 Edge Enhancement (Off / On)
113 Motion Lighting (Off / On)
113 LED Motion Plus (Off / On)
114 Picture Options
114 Colo(u)r Tone
114 Colo(u)r Temp.
114 Digital Noise Filter
115 MPEG Noise Filter
115 HDMI Black Level
115 Film Mode
115 Auto Motion Plus
116 Reset Picture
SOUND ADJUSTMENT 117 Sound Mode
118 Sound Effect
119 3D Audio (UE46A & UE55A models only)
119 3D Audio (Off / Low / Medium / High)
119 Speaker Settings
120 Reset Sound
MEDIA 121 MagicInfo Lite
121 MagicInfo Lite Player Guide

Table Of Contents
Table Of Contents 6
122 Videos
122 Playing a Video
125 Photos
125 Viewing a Photo (or Slide Show)
126 Music
126 Playing Music
128 Videos / Photos / Music - Additional
Functions
128 Sorting the file lists
129 Videos/Photos/Music Play Option menu
131 Source
131 Source
131 Edit Name
132 Information
132 Refresh
NETWORK 133 Network Settings
133 Connecting to a Wired Network
134 Wired Network Settings
136 Connecting to a Wireless Network
137 Wireless Network Setting
139 WPS(PBC)
140 One Foot Connection
141 Ad Hoc Network Setup
141 Network Status
142 MagicInfo Lite Settings
SYSTEM 143 Multi Control
143 Configuring settings for Multi Control

Table Of Contents
Table Of Contents 7
144 Time
144 Clock set
144 Sleep Timer
145 On Timer
145 Off Timer
146 Holiday Management
146 Menu Language
147 Eco Solution
147 Energy Saving
147 Eco Sensor (Off / On)
147 No Signal Power Off
147 Auto Power Off (Off / On)
148 Security
148 Safety Lock (Off / On)
148 Button Lock (Off / On)
148 Change PIN
149 PIP
149 Auto Protection Time
150 Screen Burn Protection
150 Pixel Shift
151 Timer
151 Pixel
151 Side Gray
152 Video Wall
152 Video Wall
152 Format
153 Horizontal
153 Vertical
153 Screen Position
154 Source AutoSwitch Settings

Table Of Contents
Table Of Contents 8
155 General
155 Max. Power Saving
155 Game Mode
155 BD Wise
156 Auto Power
156 Standby Control
156 Lamp Schedule
156 OSD Display
156 Power On Adjustment
156 Temperature Control
157 Device Name
157 3D Video Sync (UE46A & UE55A models only)
158 Anynet+(HDMI-CEC)
158 Anynet+(HDMI-CEC)
159 Auto Turn Off
162 Receiver
163 DivX® Video On Demand
163 Network Remote Control
163 Reset System
163 Reset All
SUPPORT 164 Software Upgrade
164 By USB
164 Alternative Software
165 Contact Samsung
MAGICINFO LITE 166 File Formats Compatible with MagicInfo
Lite Player
166 Video / Audio
170 Network Schedule
170 Connecting to a server
171 MagicInfo Lite Settings
171 Approving a connected device from the server
175 Setting the current time

Table Of Contents
Table Of Contents 9
175 Local Schedule
176 Local Schedule Manager
176 Registering a Local Schedule
178 Modifying a local schedule Local Schedule
179 Deleting a local schedule Local Schedule
181 Running a local schedule Local Schedule
182 Stopping a local schedule Local Schedule
183 Viewing the details of a local schedule Local
Schedule
184 Contents Manager
184 Copying content
185 Deleting content
186 Internal AutoPlay
186 Running Internal AutoPlay
187 USB AutoPlay
187 Running Internal AutoPlay
187 When Content is Running
187 Viewing the details of the content that is running
188 Changing the settings for the content that is
running
TROUBLESHOOTING
GUIDE
189 Requirements Before Contacting
Samsung Customer Service Center
189 Testing the Product
189 Checking the Resolution and Frequency
189 Check the followings.
192 Q & A
SPECIFICATIONS 193 General
195 PowerSaver
197 Preset Timing Modes
199 License

Table Of Contents
Table Of Contents 10
APPENDIX 200 Contact SAMSUNG WORLD WIDE
206 Responsibility for the Pay Service (Cost
to Customers)
206 Not a product defect
206 A Product damage caused by customer's fault
206 Others
207 Optimum Picture Quality and Afterimage
Burn-in Prevention
207 Optimum Picture Quality
208 Prevention of Afterimage Burn-in
210 Correct Disposal of This Product (Waste
Electrical & Electronic Equipment)
210 Correct disposal of batteries in this
product
211 Terminology
INDEX

11
Before Using the Product
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
2012 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is
prohibited.
The SAMSUNG and SyncMaster logos are registered trademarks of Samsung Electronics.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.
zAn administration fee may be charged if either
(a) an engineer is called out at your request and there is no defect in the product
(i.e. where you have failed to read this user manual).
(b) you bring the unit to a repair center and there is no defect in the product
(i.e. where you have failed to read this user manual).
zThe amount of such administration charge will be advised to you before any work or home visit is
carried out.
©

12
Before Using the Product
Before Using the Product
Cleaning
Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
Take the following steps when cleaning.
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Storage
High-glossy models can develop white stains on the surface if an ultrasonic wave humidifier is used
nearby.
Contact Customer Service Center if the inside of the product needs cleaning (service fee will be
charged).
1. Power off the product and computer.
2. Disconnect the power cord from the product.
Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
3. Wipe the product with a clean, soft and dry cloth.
zDo not use detergents that contain alcohol, solvent or
surface-active agents.
zDo not spray water or detergent directly on the product.
4. Wet a soft and dry cloth in water and wring thoroughly to clean the exterior
of the product.
5. Connect the power cord to the product when cleaning is finished.
6. Power on the product and computer.
!

13
Before Using the Product
Before Using the Product
Safety Precautions
Symbols
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)
THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and maintenance
has been included with this product.
Warning A serious or fatal injury may result if instructions are not followed.
Caution Personal injury or damage to properties may result if instructions are not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.

14
Before Using the Product
Before Using the Product
Electricity and Safety
The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
zAn electric shock or fire may result.
Do not use multiple products with a single power socket.
zOverheated power sockets may cause a fire.
Do not touch the power plug with wet hands. Otherwise, an electric shock may result.
Insert the power plug all the way in so it is not loose.
zAn unsecure connection may cause a fire.
Connect the power plug to a grounded power socket (type 1 insulated devices only).
zAn electric shock or injury may result.
Do not bend or pull the power cord with force. Be careful not to leave the power cord
under a heavy object.
zDamage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
zA fire or electric shock may result.
Clean any dust around the pins of the power plug or the power socket with a dry cloth.
zA fire may result.
!
!
!

15
Before Using the Product
Before Using the Product
Caution
Installation
Warning
Do not disconnect the power cord while the product is being used.
zThe product may become damaged by an electric shock.
Only use the power cord provided with your product by Samsung. Do not use the
power cord with other products.
zA fire or electric shock may result.
Keep the power socket where the power cord is connected unobstructed.
zThe power cord must be disconnected to cut off power to the product when an
issue occurs.
zNote that the product is not completely powered down by using only the power
button on the remote.
Hold the plug when disconnecting the power cord from the power socket.
zAn electric shock or fire may result.
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF
THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
zA fire may result.
Have a technician install the wall-mount hanger.
zInstallation by an unqualified person can result in an injury.
zOnly use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or closet.
zAn increased internal temperature may cause a fire.
Install the product at least 10cm away from the wall to allow ventilation.
zAn increased internal temperature may cause a fire.
!
!
!
!
!

16
Before Using the Product
Before Using the Product
Caution
Keep the plastic packaging out of the reach of children.
zChildren may suffocate.
Do not install the product on an unstable or vibrating surface (insecure shelf, sloped
surface, etc.)
zThe product may fall and become damaged and/or cause an injury.
zUsing the product in an area with excess vibration may damage the product or
cause a fire.
Do not install the product in a vehicle or a place exposed to dust, moisture (water
drips, etc.), oil, or smoke.
zA fire or electric shock may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a stove.
zThe product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
zThe product may fall and injure children.
zAs the front is heavy, install the product on a flat and stable surface.
Edible oil, such as soybean oil, can damage or deform the product. Do not install the
product in a kitchen or near a kitchen counter.
Do not drop the product while moving.
zProduct failure or personal injury may result.
Do not set down the product on its front.
zThe screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the bottom edge of
the front of the product is not protruding.
zThe product may fall and become damaged and/or cause an injury.
zInstall the product only on cabinets or shelves of the right size.
!
!
!

17
Before Using the Product
Before Using the Product
Operation
Warning
Set down the product gently
zProduct failure or personal injury may result.
Installing the product in an unusual place (a place exposed to a lot of fine particles,
chemical substances or extreme temperatures, or an airport or train station where the
product should operate continuously for an extended period of time) may seriously
affect its performance.
zBe sure to consult Samsung Customer Service Center if you want to install the
product at such a place.
There is a high voltage inside the product. Never disassemble, repair or modify the
product yourself.
zA fire or electric shock may result.
zContact Samsung Customer Service Center for repairs.
Before moving the product, turn off the power switch and disconnect the power cable
and all other connected cables.
zDamage to the cord may result in a fire or electric shock.
If the product generates abnormal sounds, a burning smell or smoke, disconnect the
power cord immediately and contact Samsung Customer Service Center.
zAn electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
zChildren may become injured or seriously harmed.
If the product is dropped or the outer case is damaged, turn off the power switch and
disconnect the power cord. Then contact Samsung Customer Service Center.
zContinued use can result in a fire or electric shock.
Do not leave heavy objects or items that children like (toys, sweets, etc.) on top of the
product.
zThe product or heavy objects may fall as children try to reach for the toys or
sweets resulting in a serious injury.
!
SAMSUNG
!
!
!

18
Before Using the Product
Before Using the Product
During a lightning or thunderstorm, power off the product and remove the power
cable.
zA fire or electric shock may result.
Do not drop objects on the product or apply impact.
zA fire or electric shock may result.
Do not move the product by pulling the power cord or any cable.
zProduct failure, an electric shock or fire may result from a damaged cable.
If a gas leakage is found, do not touch the product or power plug. Also, ventilate the
area immediately.
zSparks can cause an explosion or fire.
Do not lift or move the product by pulling the power cord or any cable.
zProduct failure, an electric shock or fire may result from a damaged cable.
Do not use or keep combustible spray or an inflammable substance near the product.
zAn explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
zAn increased internal temperature may cause a fire.
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects that burn
easily (paper, matches, etc) into the product (via the vent or input/output ports, etc).
zBe sure to power off the product and disconnect the power cord when water or
other foreign substances have entered the product. Then contact Samsung
Customer Service Center.
zProduct failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic objects on
top of the product.
zBe sure to power off the product and disconnect the power cord when water or
other foreign substances have entered the product. Then contact Samsung
Customer Service Center.
zProduct failure, an electric shock or fire may result.
!
!
!
GAS
!
100

19
Before Using the Product
Before Using the Product
Caution
Leaving the screen fixed on a stationary image for an extended period of time may
cause afterimage burn-in or defective pixels.
zActivate power-saving mode or a moving-picture screen saver if you will not be
using the product for an extended period of time.
Disconnect the power cord from the power socket if you do not plan on using the
product for an extended period of time (vacation, etc).
zDust accumulation combined with heat can cause a fire, electric shock or electric
leakage.
Use the product at the recommended resolution and frequency.
zYour eyesight may deteriorate.
Do not hold the product upside-down or move it by holding the stand.
zThe product may fall and become damaged or cause an injury.
Looking at the screen too close for an extended period of time can deteriorate your
eyesight.
Do not use humidifiers or stoves around the product.
zA fire or electric shock may result.
Rest your eyes for more than 5 minutes for every 1 hour of product use.
zEye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an extended period
of time as it will become hot.
Store small accessories out of the reach of children.
!
!
-_-
!
!
!
!
!

20
Before Using the Product
Before Using the Product
Exercise caution when adjusting the product angle or stand height.
zYour hand or finger may get stuck and injured.
zTilting the product at an excessive angle may cause the product to fall and an
injury may result.
Do not place heavy objects on the product.
zProduct failure or personal injury may result.
When using headphones or earphones, do not turn the volume too high.
zHaving the sound too loud may damage your hearing.
Be careful that children do not place the battery in their mouths when removed from
the remote control. Place the battery in a location that children or infants cannot reach.
zIf children have had the battery in their mouths, consult your doctor immediately.
When replacing the battery, insert it with the right polarity (+, -).
zOtherwise, the battery may become damaged or it may cause fire, personal injury
or damage due to leakage of the internal liquid.
Use only the specified standardized batteries, and do not use a new battery and a
used battery at the same time.
zOtherwise, the batteries may be damaged or cause fire, personal injury or damage
due to a leakage of the internal liquid.
The batteries (and rechargeable batteries) are not ordinary refuse and must be returned
for recycling purposes. The customer is responsible for returning the used or
rechargeable batteries for recycling.
zThe customer can return used or rechargeable batteries to a nearby public
recycling center or to a store selling the same type of the battery or rechargeable
battery.
!
!
!
