Samsung UD46E-A User manual

User Manual
The color and the appearance may differ depending on the product, and the
specifications are subject to change without prior notice to improve the performance.
UD46E-A UD46E-C UD46E-B UD55E-B

Table of contents
Before Using the Product
Copyright 5
Safety Precautions 6
Symbols 6
Cleaning 6
Storage 7
Electricity and Safety 7
Installation 8
Operation 10
Precautions when handling the panel 13
Preparations
Checking the Components 14
Components 14
Parts 15
External sensor KIT 15
Reverse Side 16
Remote Control 17
Connection Using an IR Stereo Cable
(sold separately) 19
Before Installing the Product (Installation
Guide) 20
Switching between portrait and landscape 20
Ventilation 20
Dimensions 21
Installing the Wall Mount 22
Installing the Wall Mount 22
Wall Mount Kit Specifications (VESA) 22
Remote Control (RS232C) 23
Cable Connection 23
Connection 26
Control Codes 27
Connecting and Using a Source
Device
Before Connecting 36
Pre-connection Checkpoints 36
Connecting to a PC 36
Connection using the D-SUB cable
(Analog type) 36
Connection using a DVI cable (Digital type) 37
Connection Using an HDMI-DVI Cable 37
Connection Using an HDMI Cable 38
Connection Using an DP Cable 38
Connecting to a Video Device 39
Connection Using an HDMI-DVI Cable 39
Connection Using an HDMI Cable 40
Connecting to an Audio System 40
Connecting the LAN Cable 41
Connecting the Network box
(Sold separately) 42
MagicInfo 42
Changing the Input source 44
Source 44
Using MDC
MDC Program Installation/Uninstallation 45
Installation 45
Uninstallation 45
Connecting to MDC 46
Using MDC via RS-232C
(serial data communications standards) 46
Using MDC via Ethernet 47
Home feature
Video Wall 49
Video Wall 49
Horizontal x Vertical 49
Screen Position 50
Format 50
Picture Mode 51
On/Off Timer 52
On Timer 52
Off Timer 52
Holiday Management 53
Network Settings 54
MagicInfo Player I 55
2

Table of contents
ID Settings 56
ID Settings 56
Device ID Auto Set 56
PC Connection Cable 56
More settings 57
Screen Adjustment
Picture Mode 58
Backlight / Brightness / Contrast / Sharpness /
Color / Tint (G/R) 59
Color Temperature 59
White Balance 59
Gamma 59
Calibrated Value 59
Picture Options 60
Color Tone 60
HDMI Black Level 60
Dynamic Backlight 60
UHD COLOR 60
Picture Size 61
Picture Size 61
Zoom/Position 61
Resolution 61
Auto Adjustment 62
PC Screen Adjustment 62
Picture Off 62
Reset Picture 62
OnScreen Display
Display Orientation 63
Onscreen Menu Orientation 63
Source Content Orientation 63
Aspect Ratio 63
Screen Protection 64
Pixel Shift 64
Timer 64
Immediate Display 64
Side Gray 64
Message Display 65
Source Info 65
No Signal Message 65
MDC Message 65
Menu Language 65
Reset OnScreen Display 65
System
Setup 66
Time 67
Clock Set 67
DST 67
Sleep Timer 67
Power On Delay 67
MagicInfo I Source 67
Auto Source Switching 67
Auto Source Switching 67
Primary Source Recovery 68
Primary Source 68
Secondary Source 68
Power Control 68
Auto Power On 68
PC Module Power 68
Standby Control 68
Network Standby 68
Power Button 68
Eco Solution 69
Energy Saving 69
Eco Sensor 69
Screen Lamp Schedule 69
No Signal Power Off 69
Auto Power Off 69
Temperature Control 69
Change PIN 70
General 70
Security 70
HDMI Hot Plug 70
Reset System 70
3

Table of contents
Sound Adjustment
HDMI Sound 71
Sound on Video Call 71
Reset Sound 71
Support
Software Update 72
Contact Samsung 72
Go to Home 73
Video Wall 73
Picture Mode 73
On/Off Timer 73
Network Settings 73
MagicInfo Player I 73
ID Settings 73
More settings 73
Reset All 73
Troubleshooting Guide
Requirements Before Contacting Samsung
Customer Service Center 74
Testing the Product 74
Checking the Resolution and Frequency 74
Check the followings. 75
Q & A 82
Specifications
General 84
PowerSaver 86
Preset Timing Modes 87
Appendix
Responsibility for the Pay Service
(Cost to Customers) 90
Not a product defect 90
A Product damage caused by customer's fault 90
Others 90
Optimum Picture Quality and Afterimage Burn-
in Prevention 91
Optimum Picture Quality 91
Prevention of Afterimage Burn-in 91
License 93
Terminology 94
4

5
Before Using the Product
Copyright
The contents of this manual are subject to change without notice to improve quality.
©2015 Samsung Electronics
Samsung Electronics owns the copyright for this manual.
Use or reproduction of this manual in parts or entirety without the authorization of Samsung Electronics is prohibited.
Microsoft, Windows are registered trademarks of Microsoft Corporation.
VESA, DPM and DDC are registered trademarks of the Video Electronics Standards Association.
Ownership of all other trademarks is attributed to their due owner.
Chapter 01

6
Safety Precautions
Caution
RISK OF ELECTRIC SHOCK DO NOT OPEN
Caution : TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT REMOVE COVER. (OR BACK)
THERE ARE NO USER SERVICEABLE PARTS INSIDE.
REFER ALL SERVICING TO QUALIFIED PERSONNEL.
This symbol indicates that high voltage is present inside.
It is dangerous to make any kind of contact with any internal part of this product.
This symbol alerts you that important literature concerning operation and maintenance has been
included with this product.
Symbols
Warning
A serious or fatal injury may result if instructions are not followed.
Caution
Personal injury or damage to properties may result if instructions are not followed.
Activities marked by this symbol are prohibited.
Instructions marked by this symbol must be followed.
Cleaning
―Exercise care when cleaning as the panel and exterior of advanced LCDs are easily scratched.
―Take the following steps when cleaning.
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
1
Power off the product and computer.
2
Disconnect the power cord from the product.
―Hold the power cable by the plug and do not touch the cable with wet
hands. Otherwise, an electric shock may result.
!
3
Wipe the product with a clean, soft and dry cloth.
•Do not use detergents that contain alcohol, solvent or
surface-active agents.
•Do not spray water or detergent directly on the product.
4
Wet a soft and dry cloth in water and wring thoroughly to clean the
exterior of the product.
5
Connect the power cord to the product when cleaning is finished.
6
Power on the product and computer.

7
Storage
Due to the characteristics of high-glossy products, using a UV humidifier nearby may create
white-colored stains on the product.
―Contact Customer Service Center if the inside of the product needs cleaning (service fee will be
charged).
Electricity and Safety
―The following images are for reference only. Real-life situations may differ from what is shown in the
images.
Warning
Do not use a damaged power cord or plug, or a loose power socket.
•An electric shock or fire may result.
Do not use multiple products with a single power socket.
•Overheated power sockets may cause a fire.
Do not touch the power plug with wet hands. Otherwise, an electric shock
may result.
!
Insert the power plug all the way in so it is not loose.
•An unsecure connection may cause a fire.
!
Connect the power plug to a grounded power socket
(type 1 insulated devices only).
•An electric shock or injury may result.
Do not bend or pull the power cord with force. Be careful not to leave the
power cord under a heavy object.
•Damage to the cord may result in a fire or electric shock.
Do not place the power cord or product near heat sources.
•A fire or electric shock may result.
!
Clean any dust around the pins of the power plug or the power socket with
a dry cloth.
•A fire may result.

8
Caution
Do not disconnect the power cord while the product is being used.
•The product may become damaged by an electric shock.
!
Only use the power cord provided with your product by Samsung. Do not
use the power cord with other products.
•A fire or electric shock may result.
!
Keep the power socket where the power cord is connected unobstructed.
•The power cord must be disconnected to cut off power to the product
when an issue occurs.
•Note that the product is not completely powered down by using only
the power button on the remote.
!
Hold the plug when disconnecting the power cord from the power socket.
•An electric shock or fire may result.
Installation
Warning
DO NOT PLACE CANDLES, INSECT REPELLANTS OR CIGARETTES ON TOP OF
THE PRODUCT. DO NOT INSTALL THE PRODUCT NEAR HEAT SOURCES.
•A fire may result.
!
Have a technician install the wall-mount hanger.
•Installation by an unqualified person can result in an injury.
•Only use approved cabinets.
Do not install the product in poorly ventilated spaces such as a bookcase or
closet.
•An increased internal temperature may cause a fire.
!
Install the product at least 10 cm away from the wall to allow ventilation.
•An increased internal temperature may cause a fire.
!
Keep the plastic packaging out of the reach of children.
•Children may suffocate.

9
Do not install the product on an unstable or vibrating surface (insecure shelf,
sloped surface, etc.)
•The product may fall and become damaged and/or cause an injury.
•Using the product in an area with excess vibration may damage the
product or cause a fire.
!
Do not install the product in a vehicle or a place exposed to dust, moisture
(water drips, etc.), oil, or smoke.
•A fire or electric shock may result.
Do not expose the product to direct sunlight, heat, or a hot object such as a
stove.
•The product lifespan may be reduced or a fire may result.
Do not install the product within the reach of young children.
•The product may fall and injure children.
•As the front is heavy, install the product on a flat and stable surface.
Edible oil, such as soybean oil, can damage or deform the product. Do not
install the product in a kitchen or near a kitchen counter.
Caution
!
Do not drop the product while moving.
•Product failure or personal injury may result.
Do not set down the product on its front.
•The screen may become damaged.
When installing the product on a cabinet or shelf, make sure that the
bottom edge of the front of the product is not protruding.
•The product may fall and become damaged and/or cause an injury.
•Install the product only on cabinets or shelves of the right size.
!
Set down the product gently.
•Product failure or personal injury may result.
SAMSUNG
!
Installing the product in an unusual place (a place exposed to a lot of fine
dust, chemical substances, extreme temperatures or a significant presence
of moisture, or a place where the product will operate continuously for an
extended period of time) may seriously affect its performance.
•Be sure to consult Samsung Customer Service Center if you want to
install the product at such a place.

10
Operation
Warning
There is a high voltage inside the product. Never disassemble, repair or
modify the product yourself.
•A fire or electric shock may result.
•Contact Samsung Customer Service Center for repairs.
!
Before moving the product, turn off the power switch and disconnect the
power cable and all other connected cables.
•Otherwise, the power cord may be damaged and a fire or electric
shock may result.
!
If the product generates abnormal sounds, a burning smell or smoke,
disconnect the power cord immediately and contact Samsung Customer
Service Center.
•An electric shock or fire may result.
Do not let children hang from the product or climb on top of it.
•Children may become injured or seriously harmed.
If the product is dropped or the outer case is damaged, turn off the power
switch and disconnect the power cord. Then contact Samsung Customer
Service Center.
•Continued use can result in a fire or electric shock.
Do not leave heavy objects or items that children like (toys, sweets, etc.) on
top of the product.
•The product or heavy objects may fall as children try to reach for the
toys or sweets resulting in a serious injury.
!
During a lightning or thunderstorm, power off the product and remove the
power cable.
•A fire or electric shock may result.
!
Do not drop objects on the product or apply impact.
•A fire or electric shock may result.
Do not move the product by pulling the power cord or any cable.
•Product failure, an electric shock or fire may result from a damaged
cable.
!GAS
If a gas leakage is found, do not touch the product or power plug. Also,
ventilate the area immediately.
•Sparks can cause an explosion or fire.
Do not lift or move the product by pulling the power cord or any cable.
•Product failure, an electric shock or fire may result from a damaged
cable.

11
!
Do not use or keep combustible spray or an inflammable substance near
the product.
•An explosion or fire may result.
Ensure the vents are not blocked by tablecloths or curtains.
•An increased internal temperature may cause a fire.
100
Do not insert metallic objects (chopsticks, coins, hairpins, etc) or objects
that burn easily (paper, matches, etc) into the product (via the vent or input/
output ports, etc).
•Be sure to power off the product and disconnect the power cord
when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Center.
•Product failure, an electric shock or fire may result.
Do not place objects containing liquid (vases, pots, bottles, etc) or metallic
objects on top of the product.
•Be sure to power off the product and disconnect the power cord
when water or other foreign substances have entered the product.
Then contact Samsung Customer Service Center.
•Product failure, an electric shock or fire may result.
Caution
!
Leaving the screen fixed on a stationary image for an extended period of
time may cause afterimage burn-in or defective pixels.
•Activate power-saving mode or a moving-picture screen saver if you
will not be using the product for an extended period of time.
-_-
!
Disconnect the power cord from the power socket if you do not plan on
using the product for an extended period of time (vacation, etc).
•Dust accumulation combined with heat can cause a fire, electric shock
or electric leakage.
!
Use the product at the recommended resolution and frequency.
•Your eyesight may deteriorate.
Do not hold the product upside-down or move it by holding the stand.
•The product may fall and become damaged or cause an injury.
!
Looking at the screen too close for an extended period of time can
deteriorate your eyesight.
Do not use humidifiers or stoves around the product.
•A fire or electric shock may result.

12
!
Rest your eyes for more than 5 minutes for every 1 hour of product use.
•Eye fatigue will be relieved.
Do not touch the screen when the product has been turned on for an
extended period of time as it will become hot.
!
Store small accessories out of the reach of children.
!
Exercise caution when adjusting the product angle or stand height.
•Your hand or finger may get stuck and injured.
•Tilting the product at an excessive angle may cause the product to fall
and an injury may result.
Do not place heavy objects on the product.
•Product failure or personal injury may result.
When using headphones or earphones, do not turn the volume too high.
•Having the sound too loud may damage your hearing.
Be careful that children do not place the battery in their mouths when
removed from the remote control. Place the battery in a location that
children or infants cannot reach.
•If children have had the battery in their mouths, consult your doctor
immediately.
When replacing the battery, insert it with the right polarity (+, -).
•Otherwise, the battery may become damaged or it may cause fire,
personal injury or damage due to leakage of the internal liquid.
!
Use only the specified standardized batteries, and do not use a new battery
and a used battery at the same time.
•Otherwise, the batteries may be damaged or cause fire, personal injury
or damage due to a leakage of the internal liquid.
!
The batteries (and rechargeable batteries) are not ordinary refuse and must
be returned for recycling purposes. The customer is responsible for returning
the used or rechargeable batteries for recycling.
•The customer can return used or rechargeable batteries to a nearby
public recycling center or to a store selling the same type of the
battery or rechargeable battery.

13
Precautions when handling the panel
Do not stand the product as shown in the image. The panel is fragile and
can get damaged.
!
Lay the product down to handle it as shown in the image. (the packaging
can be used).
!
Ensure you use the handles on the back when moving the product.
15 mm
Do not hold or grasp any area of the product within 15 mm from the front.

14
-Contact the vendor where you
purchased the product if any
components are missing.
-The pictures may look different from the
actual components.
Checking the Components
Components
―Components may differ in different locations.
Quick Setup Guide Warranty card
(Not available in some locations) Regulatory guide Power cord
+
+
-
-
Batteries
(Not available in some locations) Remote Control DP cable RS232C(IN) adapter
Holder-Ring (4EA) / Screw (4EA)
Preparations
Chapter 02

15
Parts
External sensor KIT
POWER
ON
―The External sensor KIT has a remote-control sensor, a brightness sensor and function keys. If mounting the display onto a
wall, you can move the External sensor KIT to the side of the display.
―The color and shape of parts may differ from what is shown. Specifications are subject to change without notice to improve
quality.
Buttons Description
Remote Control
Sensor
Aim the remote control towards this spot on the LCD Display.
―Keep the area between the remote sensor and remote control obstacle-free.
Light sensor
Automatically detects the intensity of ambient light around a selected display and
adjusts the screen brightness.
Power indicator
The power indicator will turn off when the product is turned on. It will blink in
power-saving mode.
POWER button Use this button for turning the LCD Display on and off.
SOURCE button
Switches from PC mode to Video mode.
Selects the input source that an external device is connected to.
Use the remote control within 7m to 10m from the sensor on the product at an angle of 30 from the left and right.
―Store used batteries out of reach of children and recycle.
―Do not use a new and used battery together. Replace both batteries at the same time.
―Remove batteries when the remote control is not to be used for an extended period of time.

16
Reverse Side
―The color and shape of parts may differ from what is shown. Specifications are
subject to change without notice to improve quality.
IR
OUT CONTROL IN DP IN
HDMI IN 1 HDMI IN 2
DVI IN
(MAGICINFO) RGB IN USB
DP OUT
(LOOPOUT)
IN
OUT
RS232C
IN
OUT
AUDIO
RJ45
Port Description
IR OUT
Receives the remote control signal via the external sensor board and outputs the
signal via LOOP OUT.
CONTROL IN
Supplies power to the external sensor board or receives the light sensor signal.
DVI IN (MAGICINFO)
DVI IN: Connects to a source device using a DVI cable or HDMI-DVI cable.
MAGICINFO: To use MagicInfo, make sure to connect the DP-DVI cable.
HDMI IN 1, HDMI IN 2
Connects to a source device using an HDMI cable.
DP IN
Connects to a PC using a DP cable.
RGB IN
Connects to a source device using a D-SUB cable.
DP OUT (LOOPOUT)
Connects to another product using a DP cable.
―When connecting monitors through DP Loopout, using the DP cable that
came with the package is recommended.
―This port uses an algorithm that is specific to UHD resolution input and
output. The port is not compatible with monitors that have FHD content-
specific DP Loopout ports. Connecting Loopout ports between monitors
of the same model is recommended.
AUDIO IN
Receives sound from a PC via an audio cable.
AUDIO OUT
Connects to the audio of a source device.
RS232C IN
Connects to MDC using an RS232C cable.
RS232C OUT
RJ45
Connects to MDC using a LAN cable.
USB
Connect to a USB memory device. (Only for update purpose)

17
-Remote control button functions may
differ for different products.
Remote Control
―Using other display devices in the same space as the remote control of this product can cause the other display devices to be inadvertently controlled.
―A button without a description in the image below is not supported on the product.
HOME
MENU
POWER
OFF
VOL
CH
MagicInfo
Player I
.QZ
1
ABC
2
DEF
3
GHI
4
JKL
5
MNO
6
SYMBOL
0
PRS
7
TUV
8
WXY
9
MUTE
DEL-/--
SOURCE
CH LIST
Power off the product.
Number buttons
Enter the password in the OSD menu.
Mute the sound.
Unmuting the sound: Press MUTE again or press
the volume control(+ VOL -) button.
Go to Home Launch Button.
Display or hide the onscreen display menu, or
return to the previous menu.
Power on the product.
Adjust the volume.
Change the input source.
Use this hotkey to directly access MagicInfo Player I.
This hotkey is available when a network box or
PIM (Plug In Module) is connected.
Not Available.Not Available.

18
TOOLS INFO
SET
UNSET
LOCK
PC
A
DVI
B
HDMI
C
DP
D
EXITRETURN
IR control
Display information about the current input
source.
Move to the upper, lower, left or right menu, or
adjust an option's setting.
Confirm a menu selection.
Exit the current menu.
Manually select a connected input source from
PC, DVI, HDMI, or DisplayPort.
Not Available.
Quickly select frequently used functions.
Return to the previous menu.
It sets safe lock function.
If multiple products are connected through the
Video Wall feature, press the SET button and
enter a product ID using the number buttons.
Control the product using the remote control.
Cancel a value that has been set using the
SET button and control all connected products
using the remote control.
-Remote control button functions may
differ for different products.
To place batteries in the remote control

19
Connection Using an IR Stereo Cable
(sold separately)
Make sure to connect the External ambient sensor while the product is powered
off. Then, power on the product.
Controlling more than one display product using
your remote control
•Connect the IR OUT port on the product to the IR /AMBIENT SENSOR IN
port on the other display product using the dedicated stereo cable.
•A command sent from the remote control pointed at product
1
will be
received by both display products
1
and
2
.
―The appearance may differ depending on the product.
1 2
IR OUT IR /AMBIENT
SENSOR IN
Controlling more than one display product using an
External ambient sensor (sold separately)
•A command sent from the remote control pointed at product
1
(to which
the External ambient sensor is connected) will be received by both display
products
1
and
2
.
―The appearance may differ depending on the product.
1 2
IR OUT IR /AMBIENT
SENSOR IN
IR /AMBIENT
SENSOR IN
POWER
SOURCE

20
Before Installing the Product
(Installation Guide)
To prevent injury, this apparatus must be securely attached to the floor/wall in accordance with the installation instructions.
•Ensure that an authorized installation company installs the wall mount.
•Otherwise, it may fall and cause personal injury.
•Make sure to install the specified wall mount.
Switching between portrait and landscape
―Contact Samsung Customer Service Center for further details.
•To use the product in portrait orientation, rotate it clockwise.
A
B
Figure 1.1 Side view
Ventilation
Installation on a Perpendicular Wall
AMinimum 40 mm
BAmbient temperature: Under 35 C
•When installing the product on a perpendicular wall, allow at least 40 mm of space between the product and wall surface
for ventilation and ensure that the ambient A temperature is kept below 35 C.
