Samsung Visual Displays
Clearly the right choice
Samsung’s comprehensive SyncMaster range of monitors combine the very
latest visual display technology with stylish and award winning design.
Utilising the latest TFT and Plasma technology the range includes a multitude
of screen sizes and features - to ensure a perfectly specified monitor
whatever the application.
Delivering stunning image quality and reliability the SyncMaster range
make an ideal addition to any reception, shop floor, workplace or home.
As individual as you
Central to the SyncMaster’s appeal is a series of advanced Magic features
that are designed to maximise ease of use and enhance the performance of
each product to suit your needs.
54
8016 Visual Display Brochure 8/9/06 11:31 Page 4

Supports Various External A/V Devices
SyncMaster monitors seam effortlessly with a wide range of multimedia devices. They support DVI,
D-sub, BNC connectors, s-Video and other external A/V devices.
HDTV Ready
HDTV-ready with an integrated TV tuner, Samsung monitors also act as a high-contrast, fully
geared stand-alone TV. Users can enjoy high resolution, fine image TV viewing from one multi-use unit.
FM Radio
SyncMaster monitors offer various interfaces for the multimedia generation. Equipped with FM
radio function, users can tune into radio stations by simply pressing the ‘FM radio’ button on the
remote control or monitor bezel.
Monitor as a TV (Built-in TV Tuner)
With Built-in TV Tuner, you can even watch TV without a PC.
Multi-tasking AV and PC with PIP/PBP/POP
The SyncMaster allows you to work on your computer while enjoying a pop-up screen showing TV,
DVD, Video or DTV simultaneously with SyncMaster’s PIP (Picture-in-Picture), PBP (Picture-by-
Picture) and POP (Picture out of Picture)
Excellent Sound Quality
Built-in speakers deliver impressive sound quality for TV watching, online training, music listening,
gaming and DVD playback.
All-in-one Remote Control
Our multifunctional monitor series also come equipped with all-in-one remote controls, enabling
users to conveniently access all features including TV, DVD and PIP/PBP.
Dynamic Contrast
Dynamic Contrast analyses input signals and then adjusts brightness for optimised contrast.
The result: brighter brights and deeper darks.
Innovative Power Saving System (DPMS)
SyncMaster monitors are automatically powered by the main computer
for greater convenience and power saving. Display Power Management
Signaling (DPMS) ensures minimal power consumption (under IW).
Wall and Arm Mountable
The VESA 75mm or 100mm wall mount compatible design provides
maximum function and flexibility to fit into any working environment.
High-Bandwidth Digital Contents Protection (HDCP)
HDCP protects the integrity of the content that is transmitted to your TV and delivers quality,
high-resolution images. All Samsung models support HDCP.
RoHS
As of July 2006, all Samsung monitors comply with the EU directive on restricting the use of
hazardous substances (RoHS) in electrical and electronic equipment. Samsung was also first in
the world to receive the Nemko RoHS Compliance Mark.
76
DVI Cable DVI-HDMI Adapter HDMI
DVI CableMonitor
DVD Player with
HDCP Contents
Conventional SyncMaster
3W
1W 1W
PIP PBP POP
Technology - LCD TFT Features Technology - LCD TV Monitors
8016 Visual Display Brochure 8/9/06 11:31 Page 6

98
Hot Spot of World Media
A New Standard for Digital Display
Two Thumbs Up Award
“If you want an LCD monitor that makes a statement, check out the SyncMaster 970P from
Samsung. This 19-inch gem is both beautiful and functional...”
VAR Business, U.S.A (2006 January)
“The time I set this monitor on my table I almost forgot that I was
looking at the monitor. It was like bright and vivid picture hanging
in the air. SyncMaster 970P means a classic simplicity of shape...”
PL Computers, Russia (2005 October)
“SAMSUNG SyncMaster 770P is the good combination
monitor between stylish design, high display
performance and reasonable price...”
HWH, Thailand (2005 September)
SyncMaster Monitor Achieves Grand Slam in Design Awards!
Ultra-slim and ultra-sleek
Design Award Grand Slam
Six consecutive iF Design Awards
(2000, 2001, 2002, 2003, 2004 and 2006)
Recognised throughout the world as one of the most prestigious distinctions for manufacturers, the
iF Design Award recognises the best product designs. The vast judging criteria include quality of
design, workmanship, material and user-friendliness. A winner for six consecutive years, SyncMaster
770P and 960BF won the iF Design Award in 2006.
2005 Good Design Award
SyncMaster 770P also won the Good Design Award in the category of Product Design for PCs and
Related Products. Sponsored by Japan industrial Design Promotion Organisation (JIDPO), the
award honours products whose designs help to enrich users’ lives.
Three years in a row - Red Dot Design Award in 2004, 2005 and 2006
Long recognised as the international seal of quality for outstanding design, the Red Dot Design
Award is one of the most coveted industrial design awards. Attracting over 4,000 entries from 40
countries, it ranks among the largest design competitions in the world. Winners receive instant
attention not only in Germany and Europe, but also in the global market. Samsung won the Red
Dot Design Award for three consecutive years: for 173P in 2004, 720T in 2005 and 770P in 2006.
iF Design
Germany
Good Design
Japan
Reddot Design
Germany
770P/970P
Design Awards
8016 Visual Display Brochure 8/9/06 11:31 Page 8

LCD Magic Series
With Samsung’s Magic series of monitor technologies, it’s easy to enjoy the most up-to-date
innovations. Experience pioneering features in eye-popping, user friendly designs.
MagicContrast
Samsung’s LCD monitors offer a rich palette of vibrant colours with
high contrast ratios of up to 1500:1. It’s the perfect choice for watching
movies or motion video in detailed imagery.
MagicSpeed
Super-fast 8ms, 6ms, 5ms, 4ms and 2ms response times ensure an
optimised viewing experience of DVDs and streaming video.
MagicColor
Extra colour, extra vividness and extras image quality. MagicColor automatically enhances colour in
areas that need colour correction. The cutting-edge technology intelligently calculates the saturation
of red, green and blue in the input signal to reproduce the most natural colour shades.
MagicBright2
MagicBright has five modes to best serve your application needs: Text, Internet, Game, Sports,
Movie and Custom Adjustment. Brightness and contrast are adjusted according to preconfigured
settings to allow users to get the most of their viewing experience.
1110
Hues and saturation of colours can
be optimised to provide vivid
pictures. In intelligent mode, colour
quality is enhanced except specific
colours such as skin tone, whose
changes are easily recognised.
Conventional MagicColor Conventional MagicColor
The hue and saturation of
the entire screen can be
enhanced to produce clear
and lively colours.
Intelligent Mode (Skin Tone Protection) Full Mode (Full Colour Enhancement)
Conventional SyncMaster
Conventional SyncMaster
Text Mode Internet Mode Gaming Mode Sport Mode Movie Mode
MagicTune™
MagicTune software enables users to change various display settings such as brightness, contrast
and colour levels with just a click of the mouse.
MagicClear
SyncMaster monitors with MagicClear provide the perfect environment for games and multimedia
by producing dramatic colour and sharp, fluid images.
MagicStand
MagicStand offers the most flexible pivoting control with a four-way, triple hinge adjustable stand with
swivel and tilt capabilities for maximum versatility.
MagicRotation (with Auto Pivot)
The automatic pivot feature instantly tracks movement of the screen
image, providing ease and comfort, especially when working with
multipage documents.
Mouse-operated OSD
control software
All display functions are easily
and conveniently controlled
with a mouse.
Colour calibration for
accurate colour images
With MagicTune™ colour
calibration, all images look
just like the original.
Conventional SyncMaster Without MagicTune With MagicTune
High Contrast Ratio Bright & Detailed
Images Rich Colours Wide Viewing Angle
Pivot Height Adjustable
Foldable
Dual-Hinge
Triple-Hinge Swivel Tilt
Magic Series
8016 Visual Display Brochure 8/9/06 11:31 Page 10

SM720N and SM920N
Vibrant, detailed images in a sleek and
stylish design
Providing exceptional performance at a budget price,
Samsung’s entry level TFT monitors make an attractive space
saving addition to any work or home environment. They are the
perfect upgrade from a traditional bulky CRT display.
•Ultra narrow, slim and lightweight design
•Razor-sharp images
•Easy to set up and configure with plug
and play functionality
•Choice of screen sizes (17"or 19") to suit
your needs
•Hassle-free operation with a
comprehensive 3 year warranty
1312
Entry Level
8016 Visual Display Brochure 8/9/06 11:32 Page 12

SM540N, SM740N
and SM940N
Ultra-slim and sleek for the style and
space conscious
Sleek and minimalist, the dynamic lines and slim frame
of Samsung’s monitors bring you adaptable and versatile
working, while fast response times and high contrast
ratios deliver staggering image quality.
•Space saving ultra-thin bezel and wall-mount
capability
•Choice of screen sizes (15", 17" or 19") to suit
your needs
•Fast response time (8ms)
•Fully height adjustable stand with tilt for
easy viewing (SM740N/SM940N)
•Flexibility to display information in portrait or
landscape (SM740N/SM940N)
1514
SM740B, SM940B, SM740T,
and SM940T
Uniting unbelievable colour and
clarity with perfect digital quality
Within their design, the Samsung digital TFT
monitors combine a completely flat screen with
digital input, so images are crisp and completely
distortion free. Dual inputs allow two sources to
be viewed through one screen, while a super
narrow bezel saves valuable desk space.
•Choice of analogue and digital inputs
•Superb image quality - sharp and bright
•Space saving ultra-thin bezel and
wall-mount capability
•Choice of screen sizes (17" or 19")
to suit your needs
•Optional panel type (TN or PVA)
Narrow Bezel Digital
8016 Visual Display Brochure 8/9/06 11:32 Page 14

1716
SM713BM and SM913TM
With inbuilt speakers, the SM713BM and SM913TM are ideal for enjoying multimedia
content at home or in the office. Featuring screen pivot and height adjustable stand
these monitors can be positioned in the ideal viewing position. Combine all this with
stunning image quality, a comprehensive 3 year warranty and you have the ideal display.
•Multimedia speakers
•17"/19" screen sizes
•Analogue and digital input
•Fast response time and wide viewing angles
•Height adjustable stand and screen pivot
Multimedia
8016 Visual Display Brochure 8/9/06 11:32 Page 16

1918
SM970P, SM960BF, SM960BG and SM971P
Stand out in the crowd with the ultimate in sophisticated visual displays
When you need to make a good impression, but don’t want to compromise on quality,
Samsung’s designer displays offer the best of everything - design, image and flexibility.
•High quality, vivid and clear images
•Choice of colours to suit your needs
•Ultra flexible screen pivot and height control
•Incredible contrast ratio (1500:1)
•Unique buttonless design
•Dual Input
Designer
8016 Visual Display Brochure 8/9/06 11:32 Page 18

2120
SM731BF and SM931BF
Boasting a blistering 2ms response time the SM731BF (17")
and SM931BF (19") are perfect for gaming and watching video
content. MagicSpeed reduces ghosting and jagged pixel effects
on such content ensuring improved image quality and user
experience. All this combined with sleek design and dual inputs
make this one of the most sought after screens on the market.
•2ms response time
•World best contrast ratio of 2000:1
•17"/19" screen sizes
•Analogue and digital inputs
•3 year warranty
Gaming
8016 Visual Display Brochure 8/9/06 11:32 Page 20

2322
SM711MP, SM910MP and SM940MW
Everything you need to stay informed - anytime, anywhere
Now you can afford to enjoy a true multimedia experience with Samsung’s entry
level LCD TV Monitors. This monitor and television combination is small enough to
fit in anywhere, but stylish enough to make a big impact.
•Integrated TV tuner, speakers, Teletext and remote
•Extremely clear and responsive image quality
•Stylish and practical design
•Ergonomic design and easy to use, with innovative power saving system
•Can be wall or arm mounted
SM932MP and SM242MP
Enjoy a true multimedia experience wherever you chose
Liberate your home or workspace with these high performance televisions that can also be
used as monitors and multimedia entertainment centres.
•State-of-the-art image quality and control
•Widescreen for easy viewing (SM940MW only)
•Built-in FM radio, as well as TV tuner, speakers and Teletext
LCD TV
8016 Visual Display Brochure 8/9/06 11:32 Page 22

2524
SM940BW, SM205BW, SM215TW and SM225BW
See the bigger picture
Samsung’s latest widescreen monitors bring a new and exciting perspective to life. Ultra-high
resolution images and crisp clean text, viewable across a much larger area, make it so much easier
to work and play.
Compared to traditional 4:3 aspect monitors, choosing a wide aspect 16:10 screen allows you to:
•Do more - View multiple applications, documents or spreadsheets side-by-side, so you don’t
waste time clicking and scrolling around the screen to read or compare information.
•Use less - Why run multiple applications on dual monitors, when a single wide screen monitor
makes multi-tasking so easy, and takes up so much less desk space.
•See more - View content designed in 16:9 aspect ratio, such as DVDs and games, as it’s
meant to be seen - without distortion! Plus you get dual inputs, support for HDCP and, in the
SM215TW, Picture-in-Picture/Picture-by-Picture features.
•Spend less - Future proof your investment with a technology designed to handle the growing
volume of business and entertainment applications available in HD wide screen format
Wide Format for Desktop
8016 Visual Display Brochure 8/9/06 11:32 Page 24

2726
SM203B, SM204B, SM214T, SM244T
The professional choice for intensive users
Samsung’s large format PC monitors provide an effective
working environment for professionals who need that little bit
more space to see the bigger picture. Offering large high
resolution screens which provide multi-document viewing.
•Innovative space-saving narrow bezel design
•Choice of screen sizes (20" or 21") to suit
your needs
•Pivoting display for comfortable and easy viewing
•Ideal for document or graphic intensive work eg.
CAD/CAM, graphic/web designer, engineering, etc.
•Flexibility of dual inputs to accommodate either an
analogue or digital signal
Large Format for Desktop
8016 Visual Display Brochure 8/9/06 11:32 Page 26

SM320P and SM400PX and SM460P
Make sure you’re seen and heard - loud and clear
On those occasions where image size is paramount these displays are ideal. With a high
resolution they are perfect for applications where picture definition is critical, such as point
of sale and point of information spaces. Featuring plug and play as standard, they support
both data and video signals. Optional wall mount bracket and speakers are also available,
making them the most flexible and powerful large screen displays on the market.
•High contrast ratio 10000:1
•Luxurious narrow and slim design
•High resolution 32", 40" and 46" screen sizes for maximum clarity
•Economical to run with low power consumption
•Allow input from various multimedia devices
•Ultra-fast 8ms response times and crisp sharp images
•Anti-glare coating to minimise reflection
Digital Signage
2928
8016 Visual Display Brochure 8/9/06 11:33 Page 28

3130
MagicNet allows you to distribute content across the network delivering unique content to each screen
from a single PC.
As such, MagicNet is perfect for businesses that want the benefits of digital signage without the need for a
dedicated PC for each display. Ideally suited to airports, hotels, shopping malls, offices, corporate lobbies,
theatres, museums, exhibitions, and sports venues. MagicNet transmits media files (photo, audio and movie
files) and office files (Power Point, Excel, Word, HTML and PDF files) existing on a server, to screens connected to
a network using the server/client architecture. Several screens can be connected to a LAN, with content
scheduled to appear at pre-defined times. This technology is unique to Samsung displays and not only delivers
considerable cost savings, but also improves the delivery of information.
MagicNet Software Interface LAN
SM400PXn and SM460Pn
Get the right message across - to the right people at the right time
Optimise the performance of retail, travel, office, leisure, sports and entertainment locations by
delivering targeted information 24/7.
•Choice of stylish and slim screen sizes (40" or 46") to suit your needs
•Crisp, clear images with industry leading image optimisation and response times
•Run multiple screens from one PC, each showing different information/offers, using ‘MagicNet’
•Combine multiple screens to show one larger image
Networked Digital Signage
8016 Visual Display Brochure 8/9/06 11:33 Page 30

PPM42M6SSX, PPM42M6HSX, PPM50M5HSX
and PPM63H3QX
Always make a big impression, whatever you want to say
Whether you are delivering a presentation, displaying customer
information or teleconferencing, Samsung’s plasma displays
give you the quality and versatility needed to grab and sustain
everyone’s attention.
•Slim and stylish design means they can be placed virtually anywhere
•Choice of screen sizes (42", 50" or 63") to suit your needs
•Can be mounted either horizontally, vertically, or set up as a multi-screen video wall
•Capable of displaying a variety of inputs from any conventional broadcast source, including
video, PC, etc.
•Proprietary DNIe™ technology creates lifelike images with vivid colour and optimal detail
•10,000:1 contrast ratio for stunning image quality
3332
Plasma
8016 Visual Display Brochure 8/9/06 11:33 Page 32

SM740T
a-si TFT/PVA
17"
0.264
280
1500:1
178˚/178˚
25
Analogue/Digital
30-81
56-75
1280 x 1024
16.7 Mil.
Analogue RGB,
DVI Digital link: TMDS
15pin D-sub,DVI-D
34 Watts (Max.)
<1 Watt
Yes
No
VESA 75
TCO’03
Silver/Black
Yes
362.1 x 389 x 200
362.1 x 298.2 x 60.2
497 x 375 x 235
4.6
6
3 Year
HAS: Height
Adjustable & Pivot, Swivel
Panel Type
Viewable Area
Pixel Pitch
Brightness (cd/m2)
Contrast Ratio
Viewing Angle (H/V)
Response Time (ms)
Interface
Horizontal Frequency (kHz)
Vertical Frequency (Hz)
Maximum Resolution
Colours Supported
Input Video Signal
Input Connectors
Power Consumption
Standby Mode
Energy star / NUTEK
Multimedia Speakers
Wall-Mount (mm)
Emissions Standard
Colour
Mac Compatible
Set (WxHxD) (with stand)
Set (WxHxD) (w/o stand)
Packing (WxHxD)
Weight Net (kg)
Weight Gross inc packaging (kg)
Warranty
Stand
SM920N SM540N SM740N HAS SM940N* SM740B SM940BSM720N
Entry Level Narrow Bezel Digital
a-si TFT/TN
19"
0.294
250
700:1
160˚/160˚
8
Analogue
30-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB
15pin D-sub
38 Watts (Max.)
<1 Watt
Yes
No
VESA 100
TCO’99
Silver/Black
Yes
416.6 x 424.6 x 215.5
416.6 x 349.4 x 60.2
509 x 494 x 150
6.0
7.6
3 Year
Simple/Tilt
a-si TFT/TN
17"
0.264
300
600:1
160˚/160˚
8
Analogue
30-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB
15 Pin D-sub
34 Watts (Max.)
<1 Watt
Yes
No
VESA 75
TCO’99
Silver/Black
Yes
366 x 379.3 x 200 (Simple Stand)
366 x 391.2 x 200 (HAS)
366 x 301.4 x 60.2
497 x 382 x 235
3.4 (Simple Stand) 4.7 (HAS)
6.6
3 Year
HAS: Height Adjustable &
Pivot, Swivel
a-si TFT/TN
19"
0.294
300
700:1
160˚/160˚
8
Analogue
30-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB
15pin D-sub
38 Watts (Max.)
<1 Watt
Yes
No
VESA 75
TCO’03/TCO’99
Silver/Black
Yes
407.6 x 421.5 x 217 (Simple Stand)
407.6 x 408 x 200 (HAS)
407.6 x 335 x 65.4
495 x 476 x 150 (Simple Stand)
524 x 414 x 235 (HAS)
4.8 (Simple Stand) 5.5 (HAS)
6.7 (Simple Stand) 7.7 (HAS)
3 Year
Available as Simple and HAS:
Height Adjustable, Pivot, Swivel
a-si TFT/TN
17"
0.264
300
600:1
160˚/160˚
8
Analogue/Digital
30-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB,
DVI Digital link: TMDS
15pin D-sub,DVI-D
34 Watts (Max.)
<1 Watt
Yes
No
VESA 75
TCO’03/TCO’99
Silver/Black
Yes
366 x 391.2 x 200
366 x 301.4 x 60.2
497 x 382 x 235
4.7
6.6
3 Year
HAS: Height
Adjustable & Pivot, Swivel
a-si TFT/TN
19"
0.294
300
700:1
160˚/160˚
8
Analogue/Digital
30-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB,
DVI Digital link: TMDS
15pin D-sub,DVI-D
38 Watts (Max.)
<1 Watt
Yes
No
VESA 75
TCO’03/TCO’99
Silver/Black
Yes
407.6 x 408 x 200
407.6 x 335 x 65.4
524 x 414 x 235
5.5
7.7
3 Year
HAS: Height
Adjustable & Pivot, Swivel
SM940T
a-si TFT/PVA
19"
0.294
250
1000:1
178˚/178˚
20
Analogue/Digital
30-81
56-75
1280 x 1024
16.7 Mil.
Analogue RGB,
DVI Digital link: TMDS
15pin D-sub,DVI-D
38 Watts (Max.)
<1 Watt
Yes
No
VESA 75
TCO’03
Silver/Black
Yes
403.2 x 406.4 x 200
403.2 x 331.9 x 65.4
522 x 412 x 235
5.35
6.8
3 Year
HAS: Height
Adjustable & Pivot, Swive
a-si TFT/TN
17"
0.264
300
600:1
160˚/160˚
8
Analogue
30-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB
15pin D-sub
34 Watts (Max.)
<1 Watt
Yes
No
VESA 100
TCO’99
Silver/Black
Yes
370 x 386.5 x 195.4
370 x 316 x 60.3
455 x 437 x 141
4.4
6
3 Year
Simple/Tilt
a-si TFT/TN
15"
0.297
250
450:1
140˚/120˚
16
Analogue
30-61
56-75
1024 x 768
16.2 Mil.
Analogue RGB
15pin D-sub
25 Watts (Max.)
<1 Watt
Yes
No
VESA 75
TCO’99
Silver/Black
Yes
337.5 x 336.8 x 180
337 x 264 x 60
389 x 380 x 132
2.75
3.5
3 Year
Simple
3534
Multimedia
SM713BM
a-si TFT/TN
17"
0.264
300
700:1
160˚/160˚
8
Analogue/Digital
30-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB,
DVI Digital link: TMDS
15pin D-sub,DVI-D
38 Watts (Max.)
<1 Watt
Yes
1Wx2Ch
VESA 100
TCO’99
Silver
Yes
370 x 386.7 x 195.3 (Simple)
370 x 404 x 200 (HAS)
370 x 342.3 x 64.1
451 x 440 x 140 (Simple)
508 x 431 x 235 (HAS)
5.8 (HAS) / 4.6 (Simple)
8 (HAS) / 6 (Simple)
3 Year
Simple and HAS: Height
Adjustable, Swivel, Pivot
SM913TM
a-si TFT/PVA
19"
0.294
250
1000:1
178˚/178˚
8
Analogue/Digital
30-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB,
DVI Digital link: TMDS
15pin D-sub,DVI-D
42 Watts (Max.)
<1 Watt
Yes
1Wx2Ch
VESA 100
TCO’99
Silver
Yes
416.6 x 420.6 x 200
416.6 x 377.5 x 64.2
526 x 469 x 235
7.2
9
3 Year
HAS: Height
Adjustable. Pivot
Specifications
8016 Visual Display Brochure 8/9/06 11:33 Page 34

Panel Type
Viewable Area
Pixel Pitch
Brightness (cd/m2)
Contrast Ratio
Viewing Angle (H/V)
Response Time (ms)
Interface
Horizontal Frequency (kHz)
Vertical Frequency (Hz)
Maximum Resolution
Colours Supported
Input Video Signal
Input Connectors
Power Consumption
Standby Mode
Energy star / NUTEK
Multimedia Speakers
Wall-Mount (mm)
Emissions Standard
Colour
Mac Compatible
Set (WxHxD) (with stand)
Set (WxHxD) (w/o stand)
Packing (WxHxD)
Weight Net (kg)
Weight Gross inc packaging (kg)
Warranty
Stand
Specifications
3736
Gaming
Designer
SM970P
a-si TFT/PVA
19"
0.294
250
1000:1
178˚/178˚
6
Analogue/Digital
30-81
56-75
1280 x 1024
16.7 Mil.
Analogue RGB,
DVI Digital link: TMDS
DVI-I
36 Watts (Max.)
<1 Watt
Yes
No
No
TCO’03
White and Black
Yes
424 x 507 x 242
424 x 350 x 41.2
521 x 186 x 447
7.3
9.6
3 Year
HAS: Height Adjustable,
Swivel, Pivot
SM960BF
a-si TFT/TN
19"
0.294
300
700:1
160˚/160˚
4
Analogue/Digital
30-81
56-75
1280 x 1024
16.7 Mil.
Analogue RGB,
DVI Digital link: TMDS
DVI-I
38 Watts (Max.)
<1 Watt
Yes
No
No
No
High Gloss White
Yes
420.2 x 420.5 x 258.8
420.2 x 348 x 35.8
492 x 137 x 547
5.6
7.7
3 Year
HAS: Height Adjustable,
Pivot, Foldable
SM960BG
a-si TFT/TN
19" with MagicClear™
0.294
300
700:1
160˚/160˚
4
Analogue/Digital
30-81
56-75
1280 x 1024
16.7 Mil.
Analogue RGB,
DVI Digital link: TMDS
DVI-I
38 Watts (Max.)
<1 Watt
Yes
No
No
No
High Gloss White or Black
Yes
420.2 x 420.5 x 258.8
420.2 x 348 x 35.8
492 x 137 x 547
5.6
7.7
3 Year
HAS: Height Adjustable,
Pivot, Foldable
SM731BF
a-si TFT/TN
17"
0.264
300
600:1 (Dynamic Contrast 2000:1)
160˚/160˚
2
Analogue/Digital
30-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB, DVI Digital
Link:TMDS
15pin D-sub, DVI-D
34 Watts (Max.)
<1 Watt
Yes
No
VESA 75
TCO'03
Black
Yes
380.0 x 384.8 x 202.2
380.0 x 325.0 x 57.3
445.0 x 133.0 x 440.0
3.75 kg
5.5 kg
3 Year
Simple
SM931BF
a-si TFT/TN
19"
0.294
300
700:1 (Dynamic Contrast 2000:1)
160˚/160˚
2
Analogue/Digital
30-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB, DVI Digital
Link:TMDS
15pin D-sub, DVI-D
38 Watts (Max.)
<1 Watt
Yes
No
VESA 75
TCO'03
Black
Yes
422.7 x 427.9 x 219.3
422.7 x 360.2 x 62.5
510.0 x 149.0 x 485.0
5.5
7.7
3 Year
Simple
LCD TV
SM711MP SM910MP SM940MW SM932MP SM242MP
a-si TFT/TN
17"
0.264
300
700:1
160˚/160˚
8
Analogue
31-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB, Composite,
S-Video TV (antenna/cable)
15pin D-sub, S-Video,
RCA connector, RF
43 Watts (Max.)
<2 Watts
Yes
1.5W x 2ch.
VESA 75
TCO’99
Silver
Yes
389 x 402.5 x 206
389 x 386 x 63
482 x 542 x 148
5.35
6.95
3 Year
Foldable
a-si TFT/TN
19"
0.294
300
700:1
160˚/160˚
8
Analogue
31-81
56-75
1280 x 1024
16.2 Mil.
Analogue RGB, Composite
S-Video TV (antenna/cable)
SCART
15pin D-sub, CVBS,
S-Video, SCART, RF
49 Watts (Max.)
<2 Watts
Yes
3W x 2ch.
VESA 100
TCO’99
Silver
Yes
430 x 434.4 x 227.8
430 x 420 x 63
527 x 582 x 162
5.8
7.9
3 Year
Simple
a-si TFT/TN
19" Wide
0.294
300
600:1
160˚/160˚
8
Analogue/Digital
33-81
56-75
1440 x 900
16.7 Mil.
Analogue RGB, DVI Digital Link, CVBS,
S-Video, Component,
TV (antenna/cable), SCART
15pin D-sub, DVI-D CVBS,
S-Video, SCART Component, RF
55 Watts (Max.)
<2 Watts
Yes
3W x 2ch.
VESA 100
TCO’99
Silver
Yes
466 x 406 x 216
466 x 371 x 66
532 x 553 x 165
6.2
8
3 Year
Foldable
a-si TFT/TN
19" with MagicClear™
0.294
400
550:1
160˚/160˚
8
Analogue/Digital
31-81
56-85
1280 x 1024
16.2 Mil.
Analogue RGB, DVI Digital Link: TMDS,
Composite S-Video, Component TV
(antenna/cable)
15pin D-sub, DVI-D CVBS,
S-Video, SCART Component, RF
58 Watts (Max.)
<2 Watts
Yes
5W x 2ch.
VESA 100
TCO’99
Silver
Yes
433 x 436 x 198
433 x 419.5 x 58
532 x 553 x 165
5.9
8.9
3 Year
Foldable
a-si TFT/PVA
24"
0.270
500
1000:1
178˚/178˚
16
Analogue/Digital
31-81
56-75
1920 x 1200
16.7 Mil.
Analogue RGB, DVI Digital Link: TMDS,
Composite, S-Video, Component,
15pin D-sub, DVI-D, CVBS,
S-Video, SCART, Component, RF
150 Watts (Max)
<2 Watts
Yes
5Wx 2ch. (option)
VESA 100
TCO’99
Dark Gray, Silver
Yes
558.4 x 427.2 x 177
558.4 x 380.7 x 90
648 x 508 x 270
9
10.5
3 Year
Simple
SM971P
a-si TFT/PVA
19"
0.294
250
1500:1
178˚/178˚
6
Analogue/Digital
30-81
56-75
1280 x 1024
16.7 Mil.
Analogue RGB, DVI
DVI-I
36 Watts (Max.)
<1 Watt
Yes
No
No
No
High Gloss White or Black
Yes
423 x 433 x 228
423 x 387 x 72 (Folded Stand)
557 x 151 x 441
6
8
3 Year
HAS: Height Adjustable,
Pivot, Foldable
8016 Visual Display Brochure 8/9/06 11:33 Page 36

Specifications
38 39
Panel Type
Viewable Area
Pixel Pitch
Brightness (cd/m2)
Contrast Ratio
Viewing Angle (H/V)
Response Time (ms)
Interface
Horizontal Frequency (kHz)
Vertical Frequency (Hz)
Maximum Resolution
Colours Supported
Input Video Signal
Input Connectors
Power Consumption
Standby Mode
Energy star / NUTEK
Multimedia Speakers
Wall-Mount (mm)
Emissions Standard
Colour
Mac Compatible
Set (WxHxD) (with stand)
Set (WxHxD) (w/o stand)
Packing (WxHxD)
Weight Net (kg)
Weight Gross inc packaging (kg)
Warranty
Stand
Wide Format for Desktop
SM940BW
a-si TFT/TN
19" Wide
0.285 x 0.285
300
500:1
160˚/160˚
4
Analogue/Digital
30 - 81
56 - 75
1440 x 900
16.2 Mil.
Analogue RGB, DVI Digital Link
TMDS
15pin D-sub, DVI-D
42 Watts (Max)
<1 Watt
Yes
No
VESA 75
TCO’03
Silver/Black
Yes
439 x 360.7 x 200
439 x 289 x 65.4
525 x 234 x 398
5.6
6.9
3 Year
HAS: Height Adjustable, Swivel, Tilt
SM205BW
a-si TFT/TN
20" Wide
0.258 x 0.258
300
600:1
160˚/160˚
6
Analogue/Digital
30 - 81
56 - 75
1680 x 1050
16.7 Mil.
Analogue RGB, DVI Digital Link
TMDS
15pin D-sub, DVI-D
55 Watts (Max)
<2 Watts
Yes
No
VESA 100
TCO’03
Silver/Black
Yes
471.4 x 351.8 x 200
471.4 x 307.9 x 69.5
564 x 234 x 424
6.8
8.1
3 Year
HAS: Height Adjustable, Swivel, Tilt
SM215TW
a-si TFT/PVA
21" Wide
0.270 x 0.270
300
1000:1
178˚/178˚
8
Analogue/Digital
30 - 81
56 - 75
1680 x 1050
16.7 Mil.
Analogue RGB, DVI Digital Link
TMDS Composite, S-video component
15pin D-sub, DVI-D
CVBS, S-VIDEO Component
75 Watts (Max)
<2 Watts
Yes
Yes
VESA 100
TCO’03
Silver/Black
Yes
490 x 377 x 219.8
490 x 342.5 x 72
587 x 262 x 450
7.5
9
3 Year
HAS: Height Adjustable, Swivel, Tilt
Digital Signage Networked Digital Signage
SM320P SM400PX SM460P SM400PXn SM460Pn
a-si TFT/PVA
32"
0.511
450
1000:1
170˚/170˚
8
Analogue/Digital
30 - 70
50 - 85
1366 x 768
16.7 Mil.
Analogue RGB, BNC DVI, Composite
S-Video, Component Video Separate
H/V, Composite
D-sub, Audio Cable
170 Watts (Max)
<5 Watts
Yes
10W x 2ch (Option)
Mounting kit available (option)
TCO'03
Dark Silver
Yes
780 x 529 x 223
780 x 482 x 107
898 x 600 x 262
17
20
3 Year
Optional stand
a-si TFT/PVA
40"
0.648(H) x 0.648(W)
500
1200:1
178˚/178˚
8
Analogue/Digital
30 - 70
50 - 85
1366 x 768
16.7 Mil.
Analog RGB, DVI-D, Composite
S-Video, component Video
D-sub, RS232C cable
230 Watts (Max)
<1Watt
Yes
10W x 2ch (Option)
Mounting Kit Available (option)
TCO'03
Dark Silver
Yes
971 x 629.5 x 223
971 x 582 x 118
1108 x 700 x 280
23.5
29.5
3 Year
Optional stand
a-si TFT/PVA
46"
0.2485
500
800:1
170˚/170˚
8
Analogue/Digital
31 - 70
50 - 85
1366 x 768
16.7 Mil.
Analogue RGB, DVI-D, Composite
S-Video, Component Video
D-sub, RS232C cable
300 Watts (Max)
<5 Watts
Yes
10W x 2ch (Option)
Mounting kit available (option)
TCO'03
Dark Silver
Yes
1102 x 715 x 293
1102 x 658 x 126.5
1248 x 824 x 304
28
33
3 Year
Optional stand
a-si TFT/PVA
40"
0.648(H) x 0.648(W)
500
1200:1
178˚/178˚
8
Analogue/Digital
30 - 70
50 - 85
1366 x 768
16.7 Mil.
Analog RGB, DVI-D, Composite
S-Video, component Video
D-sub, RS232C cable
230 Watts (Max)
<1Watt
Yes
10W x 2ch (Option)
Mounting Kit Available (option)
TCO'03
Dark Silver
Yes
971 x 629.5 x 223
971 x 582 x 118
1108 x 700 x 280
23.5
29.5
3 Year
Optional stand
a-si TFT/PVA
46"
0.2485
500
800:1
170˚/170˚
8
Analogue/Digital
31 - 70
50 - 85
1366 x 768
16.7 Mil.
Analogue RGB, DVI-D, Composite
S-Video, Component Video
D-sub, RS232C cable
310 Watts (Max)
<5 Watts
Yes
10W x 2ch (Option)
Mounting kit available (option)
TCO'03
Dark Silver
Yes
1102 x 715 x 293
1102 x 658 x 126.5
1248 x 824 x 304
28
33
3 Year
Optional stand
Large Format for Desktop
SM203B
a-si TFT/TN
20" SXGA+
0.292 x 0.292
300
600:1
160˚/160˚
8
Analogue/Digital
30 - 81
56 - 75
1400 x 1050
16.2 Mil.
Analogue RGB, DVI Digital Link:TMDS
15pin D-sub, DVI-D
45 Watts (Max)
<2 Watts
Yes
No
VESA 100
TCO'03
Silver/Black
Yes
HAS: 444 x 427.6 x 200
444 x 344 x 65.4
HAS: 417 x 551 x 234
HAS: 6.8
HAS: 8.7
3 Year
HAS: Height Adjustable
SM204B
a-si TFT/TN
20.1"
0.255 x 0.255
300
800:1
160˚/160˚
5
Analogue/Digital
30 - 81
56 - 75
1600 x 1200
16.7 Mil.
Analogue RGB,DVI Digital
15pin D-sub, DVI-D
63 Watts (Max)
<2 Watts
Yes
No
VESA 100
TCO'03 ,TCO'99(Black)
Silver/Black
Yes
444 x 427.6 x 200
444 x 344 x 74.5
424 x 551 x 235
7.7
9
3 Year
HAS: Height Adjustable
SM214T
a-si TFT/PVA
21.3"
0.270 x 0.270
300
1000:1
178˚/178˚
8
Analogue/Digital
30 - 81kHz
56 - 75Hz
1600x1200@60Hz (Analog) 1600x1200@60Hz (Digital)
16.7M
Analogue RGB, DVI Digital Link:TMDS,
CVBS, S-Video
15pin D-sub, DVI-D CVBS, S-Video
65 Watts (Max)
2 Watts
Yes
No
VESA 100
TCO'03 ,TCO'99(Black)
Silver/Black
Yes
469 x 466.2 x 228.5
469 x 363 x 79.6
456 x 583 x 288
8.8
11.2
3 Year
HAS: Height Adjustable
SM244T
a-si TFT/PVA
24"
0.270 x 0.270
500
1000:1
178˚/178˚
6
Analogue/Digital
30 - 81kHz
56 - 75Hz
1920x1200@60Hz (Analog) 1920x1200@60Hz (Digital)
16.7M
Analogue RGB, DVI Digital Link:TMDS, CVBS,
S-Video, Component
15pin D-sub, DVI-D CVBS, S-Video,Component
100 Watts (Max)
2 Watts
Yes
No
VESA 100
TCO'03 ,TCO'99(Black)
Silver/Black
Yes
560.4 x 443.5 x 247.1
560.4 x 366.0 x 92.1
469 x 725 x 302
9.45
12.2
3 Year
HAS: Height Adjustable
SM225BW
a-si TFT/TN
22" WIDE
0.282 x 0.282
280
700:1
160˚/160˚
5
Analogue/Digital
30 - 81
56 - 75
1680 x 1050
16.7 Mil.
Analogue RGB, DVI
Digital Link
15pin D-sub, DVI-D
55 Watts (Max)
<2 Watts
Yes
No
VESA 100
TCO'03
Silver/Black
Yes
504.7 x 219.8 x 408
504.7 x 65.8 x 335.1
608 x 256 x 484
6.9
9.4
3 Year
HAS: Height Adjustable, Swivel, Tilt
8016 Visual Display Brochure 8/9/06 11:41 Page 38
