Samsung BT62TDBST User manual

BT62TDBST
BT62TDBFST
Owner’s Manual
Installation and Operating Instructions
Built-In Oven
BT62TDBST_XEE_EN.indd 1 2008-08-05  10:29:36

BT62TDBST_XEE_EN.indd 2 2008-08-05  10:29:37

Contents
UsingThisManual .................................................. 2
SafetyInstructions.................................................. 2
Electricalsafety .......................................................2
Safetyduringoperation .................................................3
DisposalInstructions................................................ 3
InstallingtheOven.................................................. 4
Safetyinstructionsfortheinstaller.........................................4
Installingintoalowcabinet ..............................................4
Connectingtothemainspowersupply......................................5
Installingintoahighcabinet .............................................6
PartsandFeatures.................................................. 7
Oven................................................................7
Ovencontrols.........................................................8
Specialfeatures.......................................................8
Accessories ..........................................................9
Usingtheaccessories .................................................11
Safetyshutoff........................................................11
Coolingfan..........................................................11
BeforeYouBegin .................................................. 12
Settingtheclock......................................................12
Initialcleaning........................................................13
Ovenfunctions.......................................................14
Testdishes..........................................................21
OvenUse......................................................... 22
Settingthedividermode................................................22
Settingtheoventemperature............................................26
Switchingtheovenoff .................................................27
Endtime............................................................27
Cooktime...........................................................29
Delayedstart ........................................................31
Kitchentimer.........................................................33
Oven lamp on /off.....................................................33
Childsafetyfunction...................................................34
Switchingthebeeperoff................................................34
Cleaning and Care. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Steamcleaning ......................................................35
Catalyticenamelsurface ...............................................38
Cleaningtheovendoor ................................................39
SideRunners........................................................42
Changingthelamp....................................................45
Warranty&Service................................................. 46
FAQsandTroubleshooting..............................................46
Technicaldata..................................................... 48
1
BT62TDBST_XEE_EN.indd 1 2008-08-05  10:29:37

2
EN
Safety Instructions
Installation of this oven must be performed only by a licensed electrician. The installer is
responsible for connecting the appliance to the mains power supply in observance of the
relevant safety recommendations.
Electrical safety
If the oven has been damaged in transport, do not connect it.
● This appliance must be connected to the mains power supply only by a specially licensed
electrician.
●In the event of a fault or damage to the appliance, do not attempt to operate it.
●Repairs should be performed by a licensed technician only. Improper repair may result
in considerable danger to you and others. If your oven needs repair, contact a SAMSUNG
Service Centre or your dealer.
●If the supply cord is defective, it must be replaced by a special cord or assembly available
from the manufacturer or an authorised service agent.
●Electrical leads and cables should not be allowed to touch the oven.
●The oven should be connected to the mains power supply by means of an approved circuit
breaker or fuse. Never use multiple plug adapters or extension leads.
●The rating plate is located on the right side of the door.
● The power supply of the appliance should be turned off when it is being repaired or
cleaned.
●Take care when connecting electrical appliances to sockets near the oven.
● Thisapplianceisnotintendedforusebypersons(includingchildren)withreducedphysi-
cal, sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of the appliance by a person respon-
sible for their safety.
WARNING
Accessible parts may become hot during use. To avoid burns young children should be kept
away.
WARNING
The appliance should be powered down before replacing the lamp to avoid the possibility of
electric shock. During oven operation, the interior surfaces become very hot.
Using This Manual
Thank you for choosing a SAMSUNG Built - In Oven.
This Owner’s Manual contains important information on safety and instructions intended to
assist you in the operation and maintenance of your appliance.
Please take the time to read this Owner’s Manual before using your oven and keep this book
for future reference.
The following symbols are used in the text of this Owner’s Manual.
* )
Important Note
BT62TDBST_XEE_EN.indd 2 2008-08-05  10:29:37

3
EN
Safety during operation
●This oven has been designed only for the cooking of household foods.
●During use, the oven interior surfaces become hot enough to cause burns. Do not touch
heating elements or interior surfaces of the oven until they have had time to cool.
● Neverstoreflammablematerialsintheoven.
●The oven surfaces become hot when the appliance is operated at a high temperature for
an extended period of time.
● When cooking, take care when opening the oven door as hot air and steam can escape rapidly.
●When cooking dishes that contain alcohol, the alcohol may evaporate due to the high tem-
peraturesandthevapourcancatchfireifitcomesintocontactwithahotpartoftheoven.
●For your safety, do not use high-pressure water cleaners or steam jet cleaners.
●Children should be kept at a safe distance when the oven is in use.
●Frozen foods such as pizzas should be cooked on the wire grill. If the baking tray is used, it
may become deformed due to the great variation in temperatures.
●Do not pour water into the oven bottom when it is hot. This could cause damage to the
enamel surface.
●The oven door must be closed during cooking.
●Take care when opening the door before the end of the steam cleaning procedure; the
water on the bottom is hot.
●Do not line the oven bottom with aluminium foil and do not place any baking trays or tins on
it. The aluminium foil blocks the heat, which may result in damage to the enamel surfaces
and cause poor cooking results.
●Fruit juices will leave stains, which can become indelible on the enamel surfaces of the
oven. When cooking very moist cakes, use the deep pan.
●Do not rest bakeware on the open oven door.
● Thisapplianceisnotintendedforusebyyoungchildrenorinfirmpersonswithouttheadequate
supervision of a responsible person ensuring that they are using the appliance safely.
●Young children should be supervised to ensure that they do not play with the appliance.
Safety Instructions (Continued)
Disposal Instructions
Disposing of the packaging material
● The material used to package this appliance is recyclable.
● Dispose of the packaging materials in the appropriate container at your local waste disposal
facility.
Disposing of old appliances
WARNING
Before disposing of old appliances, make them inoperable so that they cannot be a source of danger.
To do this, disconnect the appliance from the mains supply and remove the mains lead.
To protect the environment, it is important that old appliances are disposed of in the correct manner.
●The appliance must not be disposed of with household rubbish.
●You can obtain information about collection dates and public refuse disposal sites from your
local refuse department or council.
BT62TDBST_XEE_EN.indd 3 2008-08-05  10:29:37

4
EN
1
560
572
595
21
595
545
2
min.550
min.560
min.600
3
50
460
min.50
min.20
4
Installing the Oven
* Electrical installation of this appliance must be performed only by a licensed electrician.
The oven must be installed according to the instructions supplied.
Remove the protective vinyl from the door after installation.
Remove the protective tape from the interior surfaces of the oven after installation.
Safety instructions for the installer
● Installationmustguaranteeprotectionagainstexposuretoelectricallyliveparts.
● TheunitinwhichtheapplianceisfittedmustsatisfytherequirementsofDIN68930in
respect of stability.
Installing into a low cabinet
● Observeminimumclearancerequirements.
● Secureovenintoplacewithscrewsoneithersideoftheoven.
BT62TDBST_XEE_EN.indd 4 2008-08-05  10:29:38

5
EN
6
Live Earth
Neutral
5
min.5min.5
7
Installing the Oven (Continued)
Connecting the oven to the power supply
(H05VV-F,H05RR-F,Min.1.5m,1.5~2.5mm²)
Connecting to the mains power supply
Electricalconnectionsmustbemadeaspertheconnectionplatefixedtothebackoftheap-
pliancebyanelectricalfitterwhomustensurethattheappliancehasbeenconnectedupin
accordancewithfittinginstructionsandlocalregulations.
Where the appliance is not connected to the mains electricity supply by a plug, an omni polar
cutoutdevice(withacontactsgapofatleast3mm)mustbefittedonthesupplysideofthe
connectiontomeetsafetyrequirements.
) When power is connected, the electronics of the oven are initialised; this neutral-
izesthelightingforafewseconds.Theelectriccable(H05RR-ForH05VV-F,Min.
1.5m,1.5~2.5mm²)mustbelongenoughforittobeconnectedtothebuilt-inoven
standingonthefloorinfrontofitsunit.
Openthebackcoveroftheovenatthebottom(usingaflat-bladedscrewdriver)
andcompletelyunscrewtheconnectionscrewandthecableclampbeforefitting
conducting wires into the appropriate terminals.
Theearthwiremustbeconnectedtothe( )terminaloftheoven.
If the oven is connected to the power supply by a plug, this must remain accessible once the
ovenhasbeenfitted.
We cannot accept any liability in the event of an accident resulting from non-existent or faulty
earthing.
BT62TDBST_XEE_EN.indd 5 2008-08-05  10:29:38

6
EN
Installing the Oven (Continued)
Installing into a high cabinet
● Observeminimumclearancerequirements.
● Theovenshouldbeslidintoplaceattheproperangleofalignment.
1
560
572
595
21
595
545
2
min.550
min.590~max.600
min.560
50
3 4
Live Earth
Neutral
5
Connecting the oven to the power supply
(H05VV-F,H05RR-F,Min.1.5m,1.5~2.5mm²)
BT62TDBST_XEE_EN.indd 6 2008-08-05  10:29:39

7
EN
Parts and Features
Oven
)Shelf levels are numbered from the bottom up.
Levels 4 and 5 are used mainly for the grill function.
Please refer to the cooking guides provided throughout this manual to determine
appropriate shelf levels for your dishes.
Top heating elements
Level
Level
Level
Level
Level
Oven lights
Side Runner
Switch divider
Catalytic enameled
cover casing
Glass door
Door handle
Control panel
5
4
3
2
1
BT62TDBST_XEE_EN.indd 7 2008-08-05  10:29:39

8
EN
14
2
5
6
7
8
9
10 11 3
Parts and Features (Continued)
1. Divider Select Knob
2. Window Display
3. Time / Temp Control Knob
4. Oven Button
5. Lamp Button
6. Steam Cleaning Button
7. Clock Button
8. Kitchen Timer Button
9. Cook Time Button
10. End Time Button
11. Temperature Button
)The Divider Select Knob and the Time / Temp Control Knob are pop - up knobs.
Simply push to turn.
Special features
Theovencomesequippedwiththefollowingspecialfeatures.
● Divider modes: When the divider inserted, the appliance’s divider facility enables indepen-
dentcookingintwoseparatedpartitions,enhancingenergyefficiencyandconveniencefor
use.
● Steam cleaning: The oven’s self-cleaning function uses the power of steam to cut through
grease and grime to clean the oven interior safely.
Oven controls
BT62TDBST_XEE_EN.indd 8 2008-08-05  10:29:39

9
EN
Parts and Features (Continued)
Accessories
The following accessories are provided with your oven.
1 Wire grill, for dishes, cake tins, roast-
ing and grilling trays. 2 Wire roast, for roasting.
3 Baking tray, for cakes and biscuits. 4 Deep pan, for roasting or collecting
meat juices or fat drippings.
5 Divider, for the upper, lower and twin
modes. Use inserted in level 3. There
is a divider-sensing switch on the
rear wall of the cooking compartment.
Insert into the back completely.
6 Rotisserie spit (BT62TDBFST)
comprises
a spit, 2 prongs, a removable handle
andacradle,whichfitsintothe3rdshelf
fromthebottom.Tousetherotisserie,fit
the spit into the hole in the rear wall of
the oven’s interior. Place the deep pan
on level 1 when using the spit.
Front Front
BT62TDBST_XEE_EN.indd 9 2008-08-05  10:29:40

10
EN
Parts and Features (Continued)
7 Rotisserie spit and Shasilik. (BT62TDBFST)
To USE IT :
●Placethedeeppan(notrivet)atlevel1tocollectthecookingjuicesoronthebottomoftheovenifthe
piece of meat to be roasted is too big.
●Slide one of the forks onto the spit; put the piece of meat to be roasted onto the spit;
●Parboiled potatoes and vegetables can be placed around the edge of the deep pan to roast at the
same time.
●Place the cradle on the middle shelf and position with the “v” shape at the front.
●To help insert the spit, the handle can be screwed onto the blunt end.
●Rest the spit onto the cradle with the pointed end towards the back and gently push until the tip of the
spit entres the turning mechanism at the back of the oven. The blunt end of the spit must rest on the
“v”shape.(Thespithastwolugswhichshouldbenearesttotheovendoorsotostopthespitgoing
forward,thelugsalsoactasagripforthehandle.)
●Before cooking unscrew the handle. After cooking screw the handle back on to help remove the spit
from the cradle.
BT62TDBST_XEE_EN.indd 10 2008-08-05  10:29:40

11
EN
Parts and Features (Continued)
4
3
2
5
1
gap 2cm
Baking tray
Deep pan
The baking tray, deep pan and wire grill should
be inserted correctly into the side runners.
When taking out the cooked foods from the
oven, be careful of hot utensils and surfaces.
Example Level 1: Deep pan
Level 4: Baking tray
) When using the deep pan or the baking tray to collect drippings from cooking foods,
ensure that the pan or tray is properly placed in the side runners. Allowing these
accessories to contact the bottom surface of the oven can damage the enamel of
the surface. Trays and pans placed on level 1 should clear the bottom surface of the
oven by at least 2 cm.
Using the accessories
Divider, wire grill, baking tray and deep pan
Positioning the divider
Insert the divider into level 3 of the oven.
Positioning the wire grill
Insert the wire grill at any desired level.
Positioning the baking tray or deep pan
Insert the baking tray and/or the deep pan at any desired level.
WARNING
To cook in the lower, upper or twin divider modes,
you must insert the divider.
Safety shutoff
●If a cooking time is not entered, the oven will shut itself off after the lengths of time indi-
cated below.
Shutoff times for various temperature settings
Under 105 °C 16 hours
From 105 °C to 240 °C 8 hours
From 245 °C to 300 °C 4 hours
●This oven’s electrical circuitry features a thermal shutoff system. If the oven heats to abnor-
mally high temperatures, the system will shut off the power supply to the heating elements
for a period of time.
Cooling fan
During cooking, it is normal for the vent to release hot air from the front of the oven.
●The cooling fan will also continue to operate after the oven has been in use. It will turn off
when the internal cabinet temperature has dropped to 60 °C or after 22 minutes.
BT62TDBST_XEE_EN.indd 11 2008-08-05  10:29:41

12
EN
Before You Begin
Setting the clock
When power is rst supplied to the oven, the display on the control panel will light briey.
After 3 seconds, an icon of a clock and 12:00 will begin blinking in the display. The oven
cannot be operated until the clock is set.
1 The oven is inoperable until the clock
has been set. “ ” and “12:00” will
blinkinthedisplaywhenpowerisfirst
supplied to the appliance. Press the
Clock Button. The “ ” and “12: ”
will blink.
2 Turn the Time / Temp Control Knob
to set the hour of the day.
Example To set 1:30
Wait for about 10 seconds. The clock
stops blinking and shows the set hour.
3 Press the Clock Button. The “ ”
and “ :00” will blink. 4 Turn the Time / Temp Control Knob
to set the minute of the time. “ ” will
blink.
5 Press the Clock Buttontofinishsettingtheclockorwaitforabout10seconds.“ ”
will disappear and “30” will stop blinking. The display shows the time of day. The appli-
ance is now ready to use.
BT62TDBST_XEE_EN.indd 12 2008-08-05  10:29:42

13
EN
Initial cleaning
Clean the oven thoroughly before using for the rst time.
*Do not use sharp or abrasive cleaning materials. These could damage the oven
surface. For ovens with enamel fronts, use commercially available cleaning agents.
To clean the oven
1. Open the door. The oven light comes on.
2. Cleanalloventrays,accessoriesandsiderunnerswithwarmwaterorwashing-upliquid
and polish dry with a soft clean cloth.
3. Wash the oven interior in the same way.
4. Wipe the front of the appliance with a damp cloth.
Check that the clock is set correctly. Remove accessories and operate the oven at the convec-
tion setting at 200 °C for 1 hour before using. There will be a distinctive odor; this is normal,
but ensure your kitchen is well ventilated during this conditioning period.
Before You Begin (Continued)
BT62TDBST_XEE_EN.indd 13 2008-08-05  10:29:43

14
EN
Before You Begin (Continued)
Oven functions
The features of this oven include the following functions
1. Conventional
Suggested temperature: 200 °C
The conventional function is ideal for baking and roasting foods arranged on one rack. Both
the top and bottom heating elements operate to maintain the oven temperature.
We recommend to preheat the oven in conventional mode.
Food Item Shelf Level Accessory Temperature
(°C) Time (min)
Frozen Lasagne
(500-1000g) 3 Wire grill 180 - 200 40-50
Whole Fish (e.g. Dorade)
(300-1000g)
3-4 cut on each side
DROP OIL
3 Wire roast +
Deep Pan 240 15-20
Fish lets
(500-1000g)
3-4 cut on each side
DROP OIL
3 Baking tray 200 13-20
Frozen cutlets
(350-1000g)
minced meat & with ham,
cheese or mushroom ling
DROP OIL
3 Baking tray 200 25-35
Frozen cutlets from minced,
carrot, beetroot or potato
(350-1000g)
DROP OIL
3 Baking tray 200 20-30
Pork on bone cutlets
(500-1000g)
DROP OIL, ADD SALT &
PEPPER
3 / 2 Wire roast +
Deep pan
200 40-50
Baked potato
(cut in half)
(500-1000g)
3 Baking tray 180-200 30-45
Frozen Meat roll
with mushrooms ling
(500-1000g)
DROP OIL
3 Baking tray 180-200 40-50
Sponge Cake
(250-500g) 2 Wire grill 160 - 180 20 - 30
Marble Cake
(500-1000g) 2 Wire grill 170 - 190 40 - 50
Yeast Cake on Tray
with fruit & crumbles topping
(1000-1500g)
2 Baking tray 160 - 180 25 - 35
Mufns
(500-800 g) 2 Wire grill 190 - 200 25 - 30
BT62TDBST_XEE_EN.indd 14 2008-08-05  10:29:43

15
EN
Before You Begin (Continued)
2. Top Heat + Convection
Suggested temperature: 190 °C
The top heating element is in operation and the fan operates to constantly circulate the hot
air.
WerecommendtopreheattheovenwithTopHeat+Convectionmode.
Food Item Shelf Level Accessory Temperature
(°C)
Time
(min)
Pork on bone
(1000g)
BRUSH WITH OIL&SPICES
3 Wire roast +
Deep pan
180 - 200 50-65
Pork shoulder in foil
(1000-1500g)
MARINATE
2 Baking tray 180 - 230 80 - 120
Whole chicken
(800-1300g)
BRUSH WITH OIL & SPICES
2 Wire roast +
Deep Pan
190 - 200 45 - 65
Meat or sh steaks
(400-800g)
DROP OIL, ADD SALT & PEPPER
3 Wire roast +
Deep pan
180 - 200 15 - 35
Chicken Pieces
(500-1000g)
BRUSH WITH OIL&SPICES
4 Wire roast +
Deep pan
200 - 220 25 - 35
Roast Fish
(500-1000g)
use ovenproof dish
BRUSH WITH OIL
2 Wire grill 180 - 200 30 - 40
Roast Beef
(800-1200g)
BRUSH WITH OIL&SPICES
2Wire roast +
Deep pan
Add 1 cup water
200 - 220 45 - 60
Duck Breast
(300-500g)
4 Wire roast +
Deep pan
Add 1 cup water
180 - 200 25 - 35
BT62TDBST_XEE_EN.indd 15 2008-08-05  10:29:43

16
EN
Before You Begin (Continued)
3. Convection
Suggested temperature: 170 °C
This function bakes foods placed on up to three shelves and is also appropriate for roasting.
Cooking is achieved by the heating element on the rear wall and the fan distributes the heat.
We recommend to preheat the oven in convection mode.
Food Item Shelf Level Accessory Temperature
(°C)
Time
(min)
Lamb rack
(350-700g) ,
BRUSH WITH OIL & SPICES
3 Wire roast +
Deep pan
190 - 200 40-50
Baked Bananas
(3-5 pcs), cut with knife on top,
add10-15g chocolate, 5-10g nuts
into cuts, drop sugar water, wrap
in aluminium foil.
3 Wire grill 220 - 240 15-25
Baked apples
5-8pcs each 150-200g
Take out the hearts, add raisins
and jam. Use ovenproof dish.
3 Wire grill 200-220 15-25
Cutlets from minced meat
(300-600g)
DROP OIL
3 Baking tray 190 - 200 18-25
Minced Meat roll with lling
,Russian style’
(500-1000g)
BRUSH WITH OIL
3 Baking tray 180-200 50-65
Frozen Croquettes
(500-1000g) 2 Baking tray 180 - 200 25 - 35
Frozen Oven Chips
(300-700g) 2 Baking tray 180 - 200 20 - 30
Frozen Pizza
(300-1000g) 2 Wire grill 200 - 220 15 - 25
Apple & Almond Cake
(500-1000 g) 2 Wire grill 170 - 190 35 - 45
Fresh Croissant
(200-400g)
(ready-dough)
3 Baking tray 180 - 200 15 - 25
BT62TDBST_XEE_EN.indd 16 2008-08-05  10:29:43

17
EN
Before You Begin (Continued)
4. Large Grill
Suggested temperature: 240 °C
Thelargegrillfunctiongrillslargequantitiesofflatfoods,suchassteaks,schnitzelsand
fish.Itisalsosuitablefortoasting.Boththetopheatingelementandthegrillareoninthis
mode.
We recommend to preheat the oven using Large Grill mode.
Food Item Shelf Level Accessory Temperature (°C) Time (min)
Sausages (thin)
5-10pcs 4Wire roast + Deep pan 220
5 - 8
turnover
5 - 8
Sausages (thin)
8-12pcs 4Wire roast + Deep pan
220 4 - 6
turnover
4 - 6
Toasts
5-10pcs
5 Wire grill 240
1 - 2
turnover
1 - 2
Cheese Toasts
4-6 pcs
4Wire roast +
Baking tray 200 4 - 8
Frozen Pancakes
with lling
,Russian Style’
(200- 500g)
3 Baking tray 200 20 - 30
Beef Steaks
(400-800 g)
4 Wire roast +
Deep pan
240 8 - 10
turnover
5-7
BT62TDBST_XEE_EN.indd 17 2008-08-05  10:29:44

18
EN
Before You Begin (Continued)
5. Small Grill
Suggested temperature: 240 °C
Thissettingisforgrillingsmalleramountsofflatfoods,suchassteaks,schnitzels,fishand
toast, placed in the middle of the tray. Only the top element is in operation.
We recommend to preheat the oven using Small Grill mode.
Put food in the centre of accessory.
Food Item Shelf Level Accessory Temperature (°C) Time (min)
Frozen Oven Camembert
(2 – 4 each 75g)
PUT IN COLD OVEN
(before preheat)
3 Wire grill 200 10-12
Frozen Baguettes
with topping
(Tomato-Mozzarella or
Ham & Cheese)
3 Wire roast +
Baking tray
200 15-20
Frozen Fish ngers
(300-700g)
PUT IN COLD OVEN ,
(before preheat)
DROP OIL
3 Wire roast +
Baking tray
200 15-25
Frozen Fish burger
(300- 600g)
PUT IN COLD OVEN,
DROP OIL
3 Baking tray 180-200 20-35
Frozen Pizza
(300-500g)
PUT IN COLD OVEN
(before preheat)
3 Wire roast +
Baking tray
180-200 23-30
BT62TDBST_XEE_EN.indd 18 2008-08-05  10:29:44
