Samsung NQ50C7935ES User manual

imagine the possibilities
Thank you for purchasing this Samsung product.
Combi Steam Built-in
Oven
user manual
NQ50C7935ES
This manual is made with 100 % recycled paper.
Please be advised that the Samsung warranty does NOT cover service
calls to explain product operation, correct improper installation, or
perform normal cleaning or maintenance.
NQ50C7935ES_EU_DG68-00471E-01_EN.indb 1 2014-10-23  12:01:56

English - 2
contents
OVEN FEATURES
14
14 Oven
15 Oven controls
16 Accessories
BEFORE YOU BEGIN
17
17 Setting the clock
18 Setting the energy save mode
18 Switching off the beeper
19 Child safety lock
20 Filling the water tank
21 Setting the water hardness
OVEN USE
22
22 Types of heating
25 Using the steam mode
29 Using the combi steam mode
31 Using the reheat mode
32 Using oven mode
43 Using multi-level cook mode
45 Using the keep warm mode
46 Setting cook time
47 Setting end time
48 Setting delay start
49 Using the auto menu mode
50 Guide to auto menu setting
53 Using the auto defrost mode
55 Test dishes
DESCALING AND CLEANING
56
56 Descale mode
58 Using the steam clean feature
59 Cleaning
60 Changing the lamp
TROUBLESHOOTING AND
INFORMATION CODE
61
61 Troubleshooting
63 information codes
TECHNICAL DATA
64
64 Technical data
65 Product data sheet
NQ50C7935ES_EU_DG68-00471E-01_EN.indb 2 2014-10-23  12:01:56

English - 3
01 SAFETY INFORMATION
safety information
USING THIS INSTRUCTION BOOKLET
You have just purchased a SAMSUNG oven. Your Owner’s Instructions contain valuable information
on cooking with your oven:
• Safety precautions
• Suitable accessories and cookware
• Useful cooking tips
• Cooking tips
LEGEND FOR SYMBOLS AND ICONS
WARNING
Hazards or unsafe practices that may result in severe personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury or property
damage.
Warning; Fire hazard Warning; Hot surface
Warning; Electricity Warning; Explosive material
Do NOT attempt. Do NOT touch.
Do NOT disassemble. Follow directions explicitly.
Unplug the power plug from the wall
socket.
Make sure the machine is grounded to
prevent electric shock.
Call the service center for help. Note
Important
IMPORTANT SAFETY INSTRUCTIONS
READ CAREFULLY AND KEEP FOR FUTURE
REFERENCE.
Make sure that these safety precautions are obeyed at all times.
Before using the oven, confirm that the following
instructions are followed.
WARNING
This appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision
or instruction concerning use of the appliance by a
person responsible for their safety.
NQ50C7935ES_EU_DG68-00471E-01_EN.indb 3 2014-10-23  12:01:57

English - 4
Children should be supervised to ensure that they do
not play with the appliance.
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard.
Appliance should allow to disconnection of the
appliance from the supply after installation.
The disconnection may be achieved by having the plug
accessible or by incorporating a switch in the fixed
wiring in accordance with the wiring rules.
During use the appliance becomes hot. Care should
be taken to avoid touching heating elements inside the
oven.
WARNING: Accessible parts may become hot during
use. Young children should be kept away.
A steam cleaner is not to be used.
WARNING: Ensure that the appliance is switched o
before replacing the lamp to avoid the possibility of
electric shock.
WARNING: The appliance and its accessible parts
become hot during use.
Care should be taken to avoid touching heating
elements.
Children less than 8 years of age shall be kept away
unless continuously supervised.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user
maintenance shall not be made by children without
supervision.
NQ50C7935ES_EU_DG68-00471E-01_EN.indb 4 2014-10-23  12:01:57

English - 5
01 SAFETY INFORMATION
Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of
the glass.
The temperature of accessible surfaces may be high
when the appliance is operating.
The door or the outer surface may get hot when the
appliance is operating.
Keep the appliance and its cord out of reach of
children less than 8 years.
Appliances are not intended to be operated by means
of an external timer or separate remote-control system.
Please put the bent up frame side to the
back, in order to support the restposition
when cooking big loads.
Do not use oven rack for microwave oven mode.
INSTALLATION INSTRUCTIONS
General
Technical Information
Electrical Supply: 230 V ~ 50 Hz
Dimensions (w×h×d)
Set size : W 595 x H 454.2 x D 570
Built in size : W 555 x H 445 x D 548.8
This appliance complies with EU regulations.
Disposal of Packaging and Appliance
Packaging is recyclable.
Packaging may consist of the following materials:
- cardboard;
- polyethylene film (PE);
- CFC-free polystyrene(PS rigid foam).
NQ50C7935ES_EU_DG68-00471E-01_EN.indb 5 2014-10-23  12:01:57

English - 6
Please dispose of these materials in a responsible manner
in accordance with government regulations.
The authorities can provide information on how to dispose
of domestic appliances in a responsible manner.
Safety
This appliance should only be connected by a qualified
technician. The Oven is NOT designed for use in a
commercial cooking setting. It should be used exclusively
for cooking food in a home setting. The appliance is hot
during and after use.
Exercise caution when young children are present.
Electrical Connection
The house mains to which the appliance is connected
should comply with national and local regulations.
Appliance should allow to disconnection of the appliance
from the supply after installation. The disconnection
may be achieved by having the plug accessible or by
incorporating a switch in the fixed wiring in accordance
with the wiring rules.
Install in the Cabinet
Kitchen Cabinets in contact with the oven must be heat-
resistant up to 100 °C.
Samsung will take no responsibility for damage of cabinets
from the heat.
NQ50C7935ES_EU_DG68-00471E-01_EN.indb 6 2014-10-23  12:01:58

English - 7
01 SAFETY INFORMATION
Fig1. Slide the oven partly into the recess. Lead the
connection cable to the power source.
Fig2. Slide the oven completely into the recess.
Fig3. Fasten the oven using the two screws (4 X 25 mm)
provoded.
Fig4. Make the electrical connection.
Check that the appliance works.
Fig1 Fig3
Fig2 Fig4
NQ50C7935ES_EU_DG68-00471E-01_EN.indb 7 2014-10-23  12:02:17

English - 8
Building-in dimensions
600
Min. 564
Max. 568
Min. 446
Max. 450
Min. 550 200 cm²
Min. 50
200 cm²
Space for
power outlet
(30 ¢ Hole)
555
595
358
454.2 445
549
21
341
85
Be sure to hold the appliance with
2side handles and door handle
when unpacking the product.
Side
handle
Side
handle
Door handle
Built-under Dimensions
Min. 550 Min.
564
Max. 568
Min. 446
Max. 450 50
200 cm²
NQ50C7935ES_EU_DG68-00471E-01_EN.indb 8 2014-10-23  12:02:18

English - 9
01 SAFETY INFORMATION
INSTALLATION & WIRING INSTRUCTIONS
IMPORTANT NOTE :
The mains lead on this equipment is supplied with a
moulded plug incorporating a fuse.
The value of the fuse is indicated on the pin face of the
plug and, if it requires replacing, a fuse approved to
BS1363 of the same rating must be used.
Never use the plug with the fuse cover omitted if the cover
is detachable. If a replacement fuse cover is required, it
must be of the same colour as the pin face of the plug.
Replacement covers are available from your Dealer. If the
fitted plug is not suitable for the power points in your house
or the cable is not long enough to reach a power point, you
should obtain a suitable safety approved extension lead
or consult your Dealer for assistance. However, if there is
no alternative to cutting o the plug, remove the fuse and
then safely dispose of the plug. Do not connect the plug to
a mains socket, as there is a risk of shock hazard from the
bared flexible cord.
WIRING INSTRUCTIONS
WARNING THIS APPLIANCE MUST BE EARTHED.
This appliance must be earthed. In the event of an
electrical short circuit, earthing reduces the risk of electric
shock providing an escape wire for the electric current. The
appliance is equipped with a mains lead which includes
an earth wire for connecting to the earth terminal of your
mains plug. The plug must be plugged into a socket that is
properly installed and earthed.
The wires in this mains lead are coloured in accordance
with the following code:
• Green and yellow : Earth
• Blue : Neutral
• Brown : Live
NQ50C7935ES_EU_DG68-00471E-01_EN.indb 9 2014-10-23  12:02:18

English - 10
As the colours of the wires in the mains lead of this
appliance may not correspond with the coloured markings
indentifying the terminals in your plug, proceed as follows.
Connect the green and yellow wire to the terminal in the
plug marked with the letter E or the earth symbol ( ) or
coloured green or green-and-yellow.
Connect the blue wire to the terminal marked with the letter
N or coloured black.
Consult a qualified electrician or service technician if in
doubt about any of these instructions. The manufacturer
of this oven will not accept any liability for damage
to persons or material for non observance of these
requirements. There are no user-serviceable parts
inside the oven and if the mains lead of this appliance is
damaged, it must only be replaced by qualified service
personnel approved by the manufacturer because
special tools are required.
WARNING : Ensure that the plug and
power cord are not damaged before
use. If you have any reason to remove
the moulded plug from this appliance,
immediately remove the fuse and
dispose of the plug.
Do not connect the plug to a mains
socket under any circumstances as
there is a danger of electric shock.
CIRCUITS : Your microwave oven should be operated
on a separate circuit from other appliances. Failure to
do this may cause the circuit breaker to trip, the fuse
to blow, or the food to cook more slowly.
WARNING
WARNING
NQ50C7935ES_EU_DG68-00471E-01_EN.indb 10 2014-10-23  12:02:18
