2_ using this manual
using this manual
Thank you for purchasing a SAMSUNG combi steam oven.
Your Owner’s Manual contains important safety instructions and essential information on
using and caring for your new combi steam oven.
Before using your oven, please read all the information in this manual and keep it for
future reference.
A handy quick look-up guide explaining basic cooking operations is provided inside the
front cover for your convenience.
WARNING or CAUTION Important Note
BEFORE INSTALLATON
Environmentally-friendly
disposal
Unpack the appliance and dispose of the packaging in an
environmentally-responsible manner.
This appliance is labelled in accordance with European Direc-
tive 2002/96/EU on Waste Electrical and Electronic Equip-
ment - WEEE.
The directive gives a framework for the collection and
recycling of old appliances, which is valid across the EU.
After unpacking Do not open the cooking compartment door while the
appliance is on the oor. The cooking compartment
door could touch the oor and be damaged.
Check the appliance for damage after unpacking it.
Do not connect the appliance if it has been damaged
in transport.
Your appliance was thoroughly factory tested for
proper operation. It may therefore contain some
remaining water.
Installation and connection Please observe the special installation instructions.
Electrical connection If the power cable is damaged, it must be replaced by
customer service in order to prevent hazards.
FQV137UST_XEU-03643C_EN.indb 2 2009-06-17  5:11:09

using this manual _3
SAFETY PRECAUTIONS
This appliance is intended only for domestic use. This
appliance must only be used for food preparation.
•This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
• Children should be supervised to ensure that they do not
play with the appliance.
Hot cooking cavity There is a risk of burning!
• During use the appliance becomes hot. Care should be
taken to avoid touching heating elements.
• Open the cooking compartment door carefully. Hot steam
will escape.
WARNING
• Accessible parts may become hot during use. Young chil-
dren should be kept away.
Risk of re!
• Never store combustible items in the cooking compartment.
There is a risk of short-circuiting!
• Never trap cables of electrical appliances in the hot cooking
compartment door. The cable insulation could melt.
Hot accessories There is a risk of burning!
• Never take accessories out of the appliance without
using oven gloves.
Cleaning Risk of scalding!
• Do not clean the appliance immediately after switching it
off. The water in the evaporator dish is still hot. Wait until
the appliance has cooled down.
• A Steam cleaner is not to be used.
Repairs Danger of electric shock!
• Incorrect repairs are dangerous. Repairs may only be car-
ried out by one of our experienced after-sales engineers. If
the appliance is faulty, switch it off using the fuse in the fuse
box or disconnect the appliance at the mains. Contact the
after-sales service.
WARNING: Ensure that the appliance is switched off before
replacing the lamp to avoid the possibility of electric shock.
FQV137UST_XEU-03643C_EN.indb 3 2009-06-17  5:11:09

4_ using this manual
IMPORTANT INFORMATION ABOUT THE USE OF THE
APPLIANCE
Do not use the cooking compartment door as a shelf.
Do not store any food in the appliance. This can lead to
corrosion.
Ovenware Use only the accessories provided. They are specially
designed for your appliance.
Caution! When steaming in the perforated steam dish, always
insert the multi pan underneath. Dripping liquid is caught.
Ovenware must be heat and steam resistant. Silicone
baking tins are not suitable for combined operation with
hot air and steam.
Do not use ovenware that shows signs of rust. Even the small-
est spots of rust can lead to corrosion in the cooking compart-
ment.
Care and cleaning The cooking compartment in your appliance is made of enamel.
Improper care can lead to corrosion in the cooking compart-
ment. Refer to the care and cleaning instructions in the instruc-
tion manual.
Salts are very abrasive. If salt is deposited in the cooking com-
partment, rust could develop in places.
Acidic sauces, such as ketchup and mustard, or salted foods,
e.g. cured roasts, contain chloride and acids. These affect the
stainless steel surface. Clean the cooking compartment after
each use.
DO NOT use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can scratch
the surface, which may result in shattering of the glass
(if provided).
FQV137UST_XEU-03643C_EN.indb 4 2009-06-17  5:11:10

using this manual _5
CAUSES OF DAMAGE
Very dirty seal If the seal on the outside of the cooking compartment is very
dirty, the cooking compartment door will no longer close
properly during operation. The fronts of adjacent units could
be damaged. Keep the seal clean.
Cooking compartment door
as a seat
Do not stand or sit on the cooking compartment door.
Transport Do not hold or carry the appliance by the door handle.
The door handle cannot hold the weight of the appliance and
may break off.
IMPORTANT INFORMATION ABOUT INSTALLING THE
COMBI STEAM OVEN
• ThisapplianceisNOTintendedforuseinacommercialenvironment.
• Pleaseobservetheinstallationinstructionsprovidedandnotethatthisappliance
should only be installed by a qualified technician.
• Theapplianceisttedwithaplugandmustonlybeconnectedtoaproperlyinstalled
earthed socket. The fuse protection must be rated at 16 amps (L or B-type miniature
circuit breakers).
• Incaseanewsocketisneeded,installationandcableconnectionmustonlybedone
byaqualiedelectrician.Iftheplugisnolongeraccessiblefollowinginstallation,a
pole disconnecting device must be present on the installation site with a contact gap
of at least 3 mm.
• Adapters,multiwaystripsandextensioncordsmustnotbeused.Overloadingcan
result in fire.
• Plugin
When the appliance has been connected for the first time, all segments are lit for a
second. After 3 seconds, 12:00 flashes in the display prompting you to select the
clock. Do not forget to reset the clock when you switch to and from summer or winter
(see the instructions on page 12).
FQV137UST_XEU-03643C_EN.indb 5 2009-06-17  5:11:10

6_ contents
contents
OVEN FEATURES
7
7Oven
8Oven Controls
9Accessories
BEFORE YOU BEGIN
10
10 Setting The Clock
11 Filling The Water Tank
12 Setting The Water Hardness
13 Default Settings
OVEN USE
14
14 Setting The Cooking Function Mode
16 Using The Steam Mode
20 Using The Steam Combi Mode
23 Using The Regeneration/Reheat
Mode
25 Using The Fan Oven Mode
27 Using The Grill Mode
29 Cooking Time Reservation Function
30 Using The Auto Cook Mode
31 Using The Auto Cook Features
35 Using The Defrost Mode
37 Using The Keep Warm Mode
38 Using The memory Mode
40 Test Dishes
DESCALING AND CLEANING
41
41 Descaling
43 Using The Steam Clean Feature
44 Cleaning
46 Switching Off The Beeper / Reading
Out The Temperature
46 Reading Out The Current
Temperature
47 Child Safety Lock
48 Cleaning And Care
49 Changing the lamp
ERROR CODES
50
50 Error Codes
TECHNICAL DATA
51
51 Technical data
FQV137UST_XEU-03643C_EN.indb 6 2009-06-17  5:11:10

oven features _7
02 OVEN FEATURES
oven features
OVEN
Note
• Shelflevelsarenumberedfromthebottomup.
• Thelevels4,5and6aremainlyusedforthegrillfunction.
• Levels1ismainlyusedforbakingandroasting.
• PleaserefertotheCookingGuidesprovidedthroughoutthisbookletto
determine the appropriate shelf level for your dishes.
Control Panel
Door Handle
Drip Tray
To p Heating Elements
Oven Light
Steam Outlet
Door
Level 1
Water Tank
Bottom Heating elements
Level 5
Level 6
Level 4
Level 3
Level 2
Fan
FQV137UST_XEU-03643C_EN.indb 7 2009-06-17  5:11:11

8_ oven features
OVEN CONTROLS
1. OFF
2. AUTO PROGRAMMES
3. REHEAT MODE
4. STEAM COMBI MODE
5. STEAM MODE
6. FAN OVEN MODE
7. GRILL MODE
8. DEFROST MODE
9. FUNCTION KNOB
10. STEAM CLEAN MODE
11. TIMER
12. START TIME
13. KEEP WARM MODE
14. MEMORY
15. SELECT
16. DISPLAY
17. SELECTION KNOB
18. START
19. STOP / CANCEL
10+11. DESCALE
14+15. CHILD LOCK
3 92 810 11 12 13 14 15 17 19
418
1
5 6716
FQV137UST_XEU-03643C_EN.indb 8 2009-06-17  5:11:12

oven features _9
02 OVEN FEATURES
ACCESSORIES
The following accessories are provided with your Combi Steam Oven:
1Multi pan 2Oven Rack
3Steam rack (always use it with a steam
container) 4 Steam container, perforated, 40 mm
deep, GN 2/3 (useful for steam mode,
always use it with the Steam rack)
FQV137UST_XEU-03643C_EN.indb 9 2009-06-17  5:11:12

10_ before you begin
before you begin
SETTING THE CLOCK
Whentheapplianceisrstpluggedin,thedisplaylightsup.(example15:15)
When connecting the power for the first time, please use the product after setting the
time.
1Turn the FUNCTION KNOB to the
“OFF” position. 2Press SELECT. The “12” starts blinking.
3Turn the SELECTION KNOB to set the
hour. 4Press SELECT again. The “00” starts blinking.
5Turn the SELECTION KNOB to set the
minutes. 6Press SELECT again. The clock sets by itself within 5 seconds.
FQV137UST_XEU-03643C_EN.indb 10 2009-06-17  5:11:16

before you begin _11
03 BEFORE YOU BEGIN
FILLING THE WATER TANK
When you open the cooking compartment door, you will see the water tank on the right-hand
side. Only ll the tank with fresh tap water or with still bottled water. If your water is very hard,
we recommend that you use softened water (see also “Water hardness).
Caution Do not ll the water tank with distilled water or any other
liquids.
Fill the water tank before
each use
Lift the water tank over the interlock and pull the tank out of
the appliance. Fill the water tank with cold water up to the
“max.” mark. Close the lid until you feel it engage.
Slide the water tank back until it engages.
Empty the water tank after
each use
Pull the water tank out of the appliance slowly. Pulling it
out quickly may cause water to spill. Hold the water tank
horizontally, so that no remaining water can drip out of the
valve seat.
Empty out the water.
Thoroughly dry the water tank in the appliance and the seal
in the lid.
“Fill water tank” display If the water tank is empty, a signal sounds.
A symbol appears in the display. The operation is inter-
rupted.
1. Open the cooking compartment door carefully. Steam will
escape.
2. Take out the water tank, ll to the “max” mark and rein-
sert.
3. Press the START button.
Removing drip tray Empty drip tray at regular intervals. Push drip tray in until
you hear a click, and remove tray from locked position.
Drip tray
Push in and remove
FQV137UST_XEU-03643C_EN.indb 11 2009-06-17  5:11:17

12_ before you begin
SETTING THE WATER HARDNESS
Itisnecessarytodescaleyourapplianceatregularintervals.Thisistheonlywayto
prevent damage.
Yourappliancehasasystemthatautomaticallydisplayswhenitneedsdescaling.Itis
presettoawaterhardness4.Changethevalueifyourwaterissofter.
Checking the water hardness
Informationonthehardnessofthewaterinyourareacanbeobtainedfromthe
local water board.
1Turn the FUNCTION KNOB to
“OFF” position. 2Press the STEAM CLEAN and the
START button at the same time
and hold for 3 seconds.
3Turn the SELECTION KNOB to the desired water hardness. 4Press the SELECT button.
► The appliance is now pro-
grammed to provide the descal-
ing warning when necessary,
based on the actual hardness of
the water.
FQV137UST_XEU-03643C_EN.indb 12 2009-06-17  5:11:19

before you begin _13
03 BEFORE YOU BEGIN
DEFAULT SETTINGS
During blinking of the default cook time or default temperature (after you have
choosenasettingwiththeFUNCTIONKNOB),youcanchangethetimeortemperature
byturningtheSELECTIONKNOB.
ATurn the FUNCTION KNOB to choose the function you want to use. BThe default time or default temperature starts to blink.
CWhile the default time/temperature is blinking: turn the SELECTION KNOB
to set the desired time/temperature.
Iftheblinkinghasstopped,youcanchangethesettingsbyfollowingthestepsas
described later in this manual.
Note
1) During cooking, COOK TIME and TEMPERATURE can be changed.
• Cooking time: press the TIMER button and then turn the SELECTION KNOB.
• Temperature: press the SELECT button and then turn the SELECTION KNOB.
FQV137UST_XEU-03643C_EN.indb 13 2009-06-17  5:11:21

14_ oven use
oven use
SETTING THE COOKING FUNCTION MODE
Turn the Cooking Function Select Knob to select the
desired oven function.
Oven Modes
The following table represents the various oven modes and settings of your oven.
Use the cooking guide tables for those modes as guidelines for cooking.
Mode Description
Steam Mode
Food is cooked by steam provided by the steam generator and in-
jected into the cavity by several jet nozzles.
This mode is suitable for steaming food like vegetables, sh, eggs,
fruits and rice. When cooking by using this mode, always ll the water
tank with fresh water.
Temperature range: 40~100 °C
Steam Combi Mode
Food is cooked by fan oven mode and the help of steam. The steam
is provided by the steam generator and injected into the cavity by
interval.
This mode is suitable for baking pastries, such as puff pastry, apple
pies, brioches, yeast buns, bread rolls, croissants, baguettes and
yeast cakes. The superheated steam will provide a nice crisp, shiny
surface and uffy structure. Meat roasts and sh will keep a more juicy
texture inside. When cooking with this mode always ll the water tank
with fresh water.
Temperature range: 100~230 °C
Regeneration/Reheat Mode
Food is reheated by fan oven mode and the help of steam. The steam
is provided by the steam generator and injected into the cavity by
interval.
This mode is suitable for plated meals. Dishes can be gently reheated
without dry out. When reheating with this mode always ll the water
tank with fresh water.
Temperature: 120 °C
FQV137UST_XEU-03643C_EN.indb 14 2009-06-17  5:11:23

oven use _15
04 OVEN USE
Mode Description
Fan Oven Mode
Food is heated by two heating elements on top of cavity and one
bottom heating element, while the fan from side distributes the hot air
evenly. This setting is suitable for roasting meat, baking gratins and
cake.
Temperature range: 40~230 °C
Grill Mode
Food is heated by the top heating elements. We recommend this
mode for grilling steaks and sausages as well as cheese toasts.
Defrost Mode
Frozen food is defrosted by steam. The steam is provided by the
steam generator and injected into the cavity by interval.
This mode is suitable for frozen meat, poultry, sh and fruit. When
defrosting with this mode always ll the water tank with fresh water.
Temperature range: 40~70 °C
Keep warm Mode
The food will be kept warm by help of the heat, provided by the bottom
heating element
(Do not keep food warm for longer than 2 hours. Warm food spoils
more quickly.)
Temperature: 70 °C
Automatic Functions
The following table represents additional programmes and functions.
Mode Description
Auto Cook Programmes
40 pre-programmed auto cook settings can be selected for your con-
venience. Time and temperature will be set automatically.
You simply select programme and weight your dish and start the
steam cooking process.
Steam Clean
By the help of hot steam the surface of the oven cavity will be soaked
and you can easily clean your oven. The steam clean programme
takes only 10 minutes time.
FQV137UST_XEU-03643C_EN.indb 15 2009-06-17  5:11:23

16_ oven use
USING THE STEAM MODE
1Fill the water tank up to the maximum line and place it back. Then place your
food into the cooking cavity.
2Turn the FUNCTION KNOB to Steam mode position (default cook time 20
min. temperature 100 °C). The time is
blinking.
3During blinking, turn the SELECTION KNOB and set the desired cooking
time. If the blinking has already stopped
before you have set the time, press the
TIMER button rst and then turn the
SELECTION KNOB.
4Press SELECT. The temperature is
blinking. 5Turn the SELECTION KNOB and set the temperature.
6Press the START button. ► The temperature indicator (°C)
on the display will blink. After the
temperature is reached, it stops
blinking.
FQV137UST_XEU-03643C_EN.indb 16 2009-06-17  5:11:26

oven use _17
04 OVEN USE
Ifthereistoolittlewaterwhilecooking,youwillseethesymbol
in the display along with a beep being played. Add water
into the tank and press START to continue with the steaming.
•Youcanaddwaterintothetankatanytimewhilecooking.
Note
1) During cooking, COOK TIME and TEMPERATURE can be changed.
• Cookingtime:presstheTIMER button and then turn the SELECTION KNOB.
• Temperature:pressSELECT and then turn the SELECTION KNOB.
2) InSteammodesettings,thetopandbottomsteamheatingelementsswitchoff
and on throughout cooking to regulate the temperature.
3) Be careful when removing the plate as it is hot. First leave the door a little open
toallowthehotsteamtoescape.Payattentiontothesteamoutletsaswell.
4) Whenyouhavenishedcooking,pouroutthewaterinthedriptrayandempty
the tank.
5) Drythecookingcavitywithadryclothifthereisanyremainingwater.
6) The cooling fan always works for 3 minutes after a steaming process. However,
this is not a malfunction and you do not need to worry about this.
FQV137UST_XEU-03643C_EN.indb 17 2009-06-17  5:11:27

18_ oven use
Steam Mode Setting
Food is cooked by steam provided by the steam generators and injected into the
cavity by two jet nozzles.
Steam container + Steam rack are usually
placed on level .
Insert the multi pan on level .
Cooking Guide
Use settings and times in this table as guide lines for steaming.
We recommend to always fill the water tank with fresh water to the maximum
level.
Food Item Shelf
level
Steam
mode (°C ) Accessory Time (min.)
Broccoli Florets 3/1 100 °C Steam rack + Steam container
/ multi pan 12-16
Sliced Vegetables
(pepper, courgettes,
fennel, onions)
3/1 100 °C Steam rack + Steam container
/ multi pan 9-14
Green Beans 3/1 100 °C Steam rack + Steam container
/ multi pan 28-33
White Asparagus 3/1 100 °C Steam rack + Steam container
/ multi pan 20-25
Whole Vegetables
(Artichokes,
Whole Cauliower,
Corn on the cob)
3/1 100 °C Steam rack + Steam container
/ multi pan 30-35
Peeled Potatoes
(cut into quarters) 3/1 100 °C Steam rack + Steam container
/ multi pan 30-35
Fish Fillets 3/1 100 °C Steam rack + Steam container
/ multi pan 15-18
Blue Prawns 3/1 100 °C Steam rack + Steam container
/ multi pan 12-15
Chicken Breast 3/1 100 °C Steam rack + Steam container
/ multi pan 23-28
Boiled Eggs 3/1 100 °C Steam rack + Steam container
/ multi pan 15-20
FQV137UST_XEU-03643C_EN.indb 18 2009-06-17  5:11:28

oven use _19
04 OVEN USE
Food Item shelf
level
Steam
mode (°C ) Accessory Time (min.)
2-level cooking:
Dual Meal
(sh llets/sliced
vegetables)
4 / 1 100 °C Steam rack + Steam container
/ multi pan 15-20
White Parboiled
Rice
(use a pyrex bowl,
add 375 ml hot
boiling water, when
cooking 250g rice)
1 100 °C Oven rack 25-30
Milk Rice
(use a at pyrex
dish, add double
quantity of milk)
3 100 °C Oven rack 40-50
Frozen Yeast
Dumplings 3 100 °C Steam rack + Steam container
/ multi pan 23-28
Flan/ Crème
(6 x dessert dishes,
each 100 ml)
3 90 °C Steam rack + Steam container
/ multi pan 20-25
Egg Custard
(Use a large at
glass pyrex dish)
3 90 °C Oven rack 37-42
Fruit Compote
(use a at round
glass pyrex, add 1
teaspoon sugar and
2 tbsp. water)
3 100 °C Oven rack 10-15
FQV137UST_XEU-03643C_EN.indb 19 2009-06-17  5:11:28

20_ oven use
USING THE STEAM COMBI MODE
1Fill the water tank up to the maximum line and place it back. Then place your
food into the cooking cavity.
2Turn the FUNCTION KNOB to Steam Combi mode position (default: 180
°C). The temperature is blinking.
3During blinking, turn the SELECTION KNOB and set the desired tempera-
ture. If the blinking has already stopped
before you have set the temperature,
press the SELECT button rst and then
turn the SELECTION KNOB.
4Press the TIMER button to set the de- sired cooking time. The time is blinking. 5Turn the SELECTION KNOB and set the desired cooking time.
6Press the START button. ► The temperature indicator (°C)
on the display will blink. After the
temperature is reached, it stops
blinking.
FQV137UST_XEU-03643C_EN.indb 20 2009-06-17  5:11:31
