Samsung NV51K6650DS User manual

Built-In Electric Wall Oven
User manual
NV51K6650D*
NV51K6650DS_DG68-00854A-03_EN+MES+CFR.indb 1 2018-08-29  1:04:23

2 English
FCC STATEMENT:
This equipment has been tested and found to comply within the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver
• Connecting the equipment to an outlet that is on a different
circuit than the radio or TV
• Consulting the dealer or an experienced radio/TV technician for
help.
Regulatory Notice
1. FCC Notice
CAUTION
FCC CAUTION: Any changes or modications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is Subject
to following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received including
interference that cause undesired operation.
For products sold in the US and Canadian markets, only channels
1~11 are available. You cannot select any other channels.
NV51K6650DS_DG68-00854A-03_EN+MES+CFR.indb 2 2018-08-29  1:04:23

English 3
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits
set forth for an uncontrolled environment. This equipment should
be installed and operated so there is at least 8 inches (20 cm)
between the radiator and your body. This device and its antenna(s)
must not be co-located or operated in conjunction with any other
antenna or transmitter.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
2. IC Notice
The term “IC” before the radio certication number only signies
that Industry Canada technical specications were met. Operation
is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the
device.
This Class B digital apparatus complies with Canadian ICES-003.
For products sold in the US and Canadian markets, only channels
1~11 are available. You cannot select any other channels.
NV51K6650DS_DG68-00854A-03_EN+MES+CFR.indb 3 2018-08-29  1:04:23

4 English
Contents
ContentsContents
Important safety instructions 5
Introducing your new oven 17
Overview 17
What’s included with your oven 17
Before you begin 17
Energy saving tips 17
Water reservoir 17
Operating the oven 19
The oven control panel 19
Control panel display modes 20
Setting the clock 20
Setting the kitchen timer 20
Control Lockout 21
Timed Cooking 21
Delay Start 22
Turning the light on and off 22
Minimum and maximum settings 22
Using the oven racks 23
Using the Gliding Rack 24
Baking 25
Convection baking 26
Convection roasting 27
No Preheat 27
Broiling 28
Steam baking and roasting (upper oven only) 29
Using Bread Proof (lower oven only) 30
Using Keep Warm (lower oven only) 30
Using the Temp Probe (upper oven only) 30
Using Smart Control 32
Using Options 32
Using the Sabbath feature 34
Maintaining your appliance 35
Self-cleaning 35
Hybrid Cleaning 37
Descale 39
Draining 40
Care and cleaning of the oven 40
Removing the oven doors 42
Replacing the oven doors 43
Changing the oven light 44
Troubleshooting 44
Troubleshooting 44
Information codes 47
Warranty (U.S.A) 48
Warranty (CANADA) 50
Open Source Announcement 51
NV51K6650DS_DG68-00854A-03_EN+MES+CFR.indb 4 2018-08-29  1:04:23

English 5
Important safety instructions
SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS
CAUTION
To reduce the risk of re, explosion, electric shock, or personal
injury when using your oven, follow these basic safety precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call a Samsung service center for help.
Note
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future
reference.
Important safety instructions
Read and follow all instructions before using your oven to
prevent the risk of re, electric shock, personal injury, or damage
when using the oven. This guide does not cover all possible
conditions that may occur. Always contact your service agent or
the manufacturer about problems that you do not understand.
WHAT YOU NEED TO KNOW ABOUT SAFETY
INSTRUCTIONS
Warnings and important safety instructions in this manual do not
cover all possible conditions and situations that may occur. It is
your responsibility to use common sense, caution, and care when
installing, maintaining, and operating your oven.
Important safety symbols and precautions
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal
injury or property damage.
NV51K6650DS_DG68-00854A-03_EN+MES+CFR.indb 5 2018-08-29  1:04:24

6 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
FOR YOUR SAFETY
When using electrical appliances, you should follow basic safety
precautions, including the following:
CAUTION
• Use this appliance only for its intended purpose as described in
this Owner’s Manual.
• Potentially hot surfaces include the oven vent opening, surfaces
near the opening, and crevices around the oven door.
Proper Installation - Be sure your appliance is properly
installed and grounded by a qualied technician.
User servicing - Do not repair or replace any part of the
appliance unless specically recommended in this manual. All
other servicing should be referred to a qualied technician.
Always disconnect the power to the appliance before servicing
by removing the fuse or switching off the circuit breaker.
• Do not enter the oven.
• Do not leave children alone. Never leave children alone or
unattended in an area where this appliance is in use. They
should never be allowed to sit or stand on any part of the
appliance.
• Never use your appliance for warming or heating the
room.
• Do not use water on grease res. Turn off the oven to
avoid spreading the ames. Smother the re or ames by
closing the door or use a dry chemical, baking soda, or
foam-type extinguisher.
• Avoid scratching or striking the glass doors and the control
panel. Doing so may lead to glass breakage. Do not cook on
a product with broken glass. Shock, re, or cuts may occur.
NV51K6650DS_DG68-00854A-03_EN+MES+CFR.indb 6 2018-08-29  1:04:24

English 7
Important safety instructions
SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS
• Use only dry potholders. Placing moist or damp potholders
on hot surfaces may result in burns from steam. Do not
let the potholder touch hot heating elements. Do not use a
towel or other bulky cloth instead of a potholder.
• Teach children not to play with the controls or any other
part of the oven.
• For your safety, do not use high-pressure water cleaners or
steam jet cleaners to clean any part of the oven.
• If the power cord is damaged, it must be replaced by
the manufacturer, its service agent, or similarly qualied
persons to avoid creating a hazard.
• The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their
safety.
• If there is a re in the oven during self-cleaning, turn the
oven off and wait for the re to go out. Do not force the
door open. The introduction of fresh air at self-cleaning
temperatures may lead to a burst of ame from the oven.
Failure to follow these instructions may result in severe
burns.
• If the oven is heavily soiled with oil, self-clean the oven
before using the oven again. Leaving the oil in place
creates a risk of re.
• Wipe up heavy soil on the oven bottom with a paper tower
or rag before self-cleaning. Self-cleaning the oven when
there is heavy soil on the oven bottom requires longer
cleaning cycles and produces more smoke.
• Storage in or on the appliance. Do not store ammable
materials in the oven or near the surface units. Be sure all
packing materials are removed from the appliance before
operating it. Keep plastics, clothes, and paper away from
parts of the appliance that may become hot.
• Wear proper apparel. Never wear loose-tting or hanging
garments while using the appliance.
NV51K6650DS_DG68-00854A-03_EN+MES+CFR.indb 7 2018-08-29  1:04:24

8 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
WARNING
• Ensure that the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
CHILD SAFETY
WARNING
• This appliance is not intended for use by young children
or inrm persons without the adequate supervision of a
responsible adult.
• Young children should be supervised to ensure that they do not
play with the appliance.
• Keep children away from the door when opening or closing it as
they may bump themselves on the door or catch their ngers in
the door.
• During self-cleaning, the surfaces may get hotter than usual.
Keep small children away from the oven when it is in the self-
cleaning mode.
WARNING
Accessible parts may become hot during use. To avoid burns, young
children should be kept away.
ELECTRICAL SAFETY
• Use only the factory installed exible power cord to
connect to the power supply. Do not use a 3rd party power
supply cord kit.
• The appliance should be serviced only by qualied service
personnel. Repairs carried out by unqualied individuals
may cause injury or a serious malfunction. If your appliance
is in need of repair, contact a Samsung authorized service
center. Failure to follow these instructions may result in
damage and void the warranty.
• Flush - mounted appliances may be operated only after
they have been installed in cabinets and workplaces that
conform to the relevant standards. This ensures that the
appliances are installed in compliance with the appropriate
safety standards.
• If your appliance malfunctions or if fractures, cracks, or
splits appear:
• Switch off the oven.
• Unplug the oven from the AC wall outlet.
• Contact your local Samsung service center.
NV51K6650DS_DG68-00854A-03_EN+MES+CFR.indb 8 2018-08-29  1:04:24

English 9
Important safety instructions
SAVE THESE INSTRUCTIONSSAVE THESE INSTRUCTIONS
• Use care when opening the door. Let hot air or steam
escape before you remove food from or put food into the
oven.
• Protective liners. Do not use aluminum foil to line the oven
bottoms, except as suggested in this manual. Improper
installation of these liners may result in a risk of electric
shock or re.
• Placement of oven racks. Always place oven racks in the
desired location while the oven is cool. If the rack must be
moved while the oven is hot, use potholders. Do not let the
potholders come in contact with the hot heating element in
the oven.
• Do not allow aluminum foil or a meat probe to contact the
heating elements.
• During use, the appliance becomes hot.
Care should be taken to avoid touching heating elements
inside the oven.
• Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass. They can scratch the surface
which may result in the glass shattering.
OVEN
• DO NOT TOUCH THE HEATING ELEMENTS OR INTERIOR
SURFACES OF THE OVEN. Heating elements may be hot
even though they are dark in color. Interior surfaces of
an oven become hot enough to cause burns. During and
after use, do not touch or let clothing or other ammable
materials contact the heating elements or interior surfaces
of the oven until they have had sufcient time to cool.
Other surfaces of the appliance may become hot enough to
cause burns. Among these surfaces are oven vent openings
and surfaces near these openings, the oven door, and the
window of the oven door.
• Do not heat unopened food containers. The build-up of
pressure may cause the container to burst and result in
injury.
• Do not use the oven to dry newspapers. If overheated,
newspapers can catch re.
• Do not use the oven for a storage area. Items stored in an
oven can ignite.
NV51K6650DS_DG68-00854A-03_EN+MES+CFR.indb 9 2018-08-29  1:04:24

10 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS SAVE THESE INSTRUCTIONS
• Do not use any commercial oven cleaner or oven liner
protective coating of any kind in or on the outside of the
oven.
• Remove the nickel oven shelves from the oven before you
begin the self-cleaning cycle or they may discolor.
• If the self-cleaning mode malfunctions, turn the oven off
and disconnect the power supply. Have it serviced by a
qualied technician.
• Excess spillage must be removed before you run the self-
cleaning cycle.
VENTILATING HOOD
• Clean ventilating hoods frequently. Do not let grease
accumulate on the hood or lter.
• When aming foods under the hood, turn the fan on.
CAUTION
Do not attempt to operate the oven during a power failure. If the
power fails, always turn the oven off. If the oven is not turned off
and the power returns, the oven may begin to operate again. Food
left unattended could catch re or spoil.
SELFCLEANING OVENS
Do not clean the door gasket. The door gasket is essential for
a good seal. Care should be taken not to rub, damage, or move
the gasket.
• Never keep pet birds in the kitchen. Birds are extremely
sensitive to the fumes released during an oven self-clean
cycle. Fumes may be harmful or fatal to birds. Move birds
to a well-ventilated room.
• Clean only the parts listed in this manual in the self-clean
cycle. Before self-cleaning the oven, remove the partition,
rack, utensils, and any food.
• Before operating the self-clean cycle, wipe grease and food
soils from the oven. Excessive amounts of grease may
ignite, leading to smoke damage to your home.
NV51K6650DS_DG68-00854A-03_EN+MES+CFR.indb 10 2018-08-29  1:04:24
