Samsung NV51M9770D Series User manual

Built-In Electric Wall Oven
User manual
NV51M9770D*
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 1 2018-03-27  2:35:32

2 English
Regulatory Notice
FCC STATEMENT:
This equipment has been tested and found to comply within
the limits for a Class B digital device, pursuant to part 15 of
the FCC Rules. These limits are designed to provide reasonable
protection against harmful interference in a residential
installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to
radio communications. However, there is no guarantee that
interference will not occur in a particular installation. If
this equipment does cause harmful interference to radio or
television reception, which can be determined by turning the
equipment off and on, the user is encouraged to try to correct
the interference by one or more of the following measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and
receiver
• Connecting the equipment to an outlet that is on a different
circuit than the radio or TV
• Consulting the dealer or an experienced radio/TV technician
for help.
1. FCC Notice
CAUTION
FCC CAUTION: Any changes or modications not expressly
approved by the party responsible for compliance could void
the user’s authority to operate the equipment.
This device complies with Part 15 of FCC Rules. Operation is
Subject to following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received including
interference that cause undesired operation.
For products sold in the US and Canadian markets, only
channels 1~11 are available. You cannot select any other
channels.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 2 2018-03-27  2:35:32

English 3
Regulatory Notice
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated so there is at least
8 inches (20 cm) between the radiator and your body. This
device and its antenna(s) must not be co-located or operated in
conjunction with any other antenna or transmitter.
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits
set forth for an uncontrolled environment. This equipment
should be installed and operated so there is at least 8 inches
(20 cm) between the radiator and your body. This device and
its antenna(s) must not be co-located or operated in conjunction
with any other antenna or transmitter.
2. IC Notice
The term “IC” before the radio certication number only
signies that Industry Canada technical specications were
met. Operation is subject to the following two conditions: (1)
this device may not cause interference, and (2) this device must
accept any interference, including interference that may cause
undesired operation of the device.
This Class B digital apparatus complies with Canadian ICES-003.
For products sold in the US and Canadian markets, only
channels 1~11 are available. You cannot select any other
channels.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 3 2018-03-27  2:35:32

4 English
Contents
ContentsContents
Important safety instructions 5
Introducing your new oven 18
Overview 18
What’s included with your oven 18
Before you begin 19
Energy saving tips 19
Water reservoir 19
Operating the oven 20
Control panel 20
Display 21
Setting the temperature 21
Control lockout 22
Kitchen timer 22
Timed cooking 24
Delay start 25
Using the temp probe 26
Twin cooking mode temperature setting ranges 27
Oven functions 28
Using the healthy cook feature 35
Using the favorite recipes and gourmet cook feature 37
Using the oven racks 38
Using the gliding rack 40
Using the divider 41
Using the clean feature 42
Settings 48
Using the Sabbath feature 51
Maintaining your appliance 53
Care and cleaning of the oven 53
Removing the oven doors 55
Replacing the oven doors 56
Changing the oven light 57
Troubleshooting 57
Troubleshooting 57
Information codes 60
Warranty (U.S.A) 61
Warranty (CANADA) 63
Open source announcement 64
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 4 2018-03-27  2:35:32

English 5
Important safety instructions
SAVE THESE INSTRUCTIONS
CAUTION
To reduce the risk of re, explosion, electric shock, or personal
injury when using your oven, follow these basic safety
precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric
shock.
Call a Samsung service center for help.
Note
These warning signs are here to prevent injury to you and
others. Please follow them explicitly.
After reading this section, keep it in a safe place for future
reference.
Important safety instructions
Read and follow all instructions before using your oven to
prevent the risk of re, electric shock, personal injury, or
damage when using the oven. This guide does not cover all
possible conditions that may occur. Always contact your service
agent or the manufacturer about problems that you do not
understand.
WHAT YOU NEED TO KNOW ABOUT SAFETY
INSTRUCTIONS
Warnings and important safety instructions in this manual do
not cover all possible conditions and situations that may occur.
It is your responsibility to use common sense, caution, and care
when installing, maintaining, and operating your oven.
Important safety symbols and precautions
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal
injury or death.
CAUTION
Hazards or unsafe practices that may result in minor personal
injury or property damage.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 5 2018-03-27  2:35:33

6 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
Always disconnect the power to the appliance before
servicing by removing the fuse or switching off the circuit
breaker.
• Do not enter the oven.
• Do not leave children alone. Never leave children alone or
unattended in an area where this appliance is in use. They
should never be allowed to sit or stand on any part of the
appliance.
• Never use your appliance for warming or heating the room.
• Do not use water on grease res. Turn off the oven to avoid
spreading the ames. Smother the re or ames by closing
the door or use a dry chemical, baking soda, or foam-type
extinguisher.
• Avoid scratching or striking the glass doors and the control
panel. Doing so may lead to glass breakage. Do not cook on
a product with broken glass. Shock, re, or cuts may occur.
STATE OF CALIFORNIA PROPOSITION 65 WARNING
US ONLY
WARNING : This product contains chemicals known to the State of
California to cause cancer and birth defects or other reproductive harm.
FOR YOUR SAFETY
When using electrical appliances, you should follow basic
safety precautions, including the following:
CAUTION
• Use this appliance only for its intended purpose as
described in this Owner’s Manual.
• Potentially hot surfaces include the oven vent opening,
surfaces near the opening, and crevices around the oven
door.
Proper Installation - Be sure your appliance is properly
installed and grounded by a qualied technician.
User servicing - Do not repair or replace any part of the
appliance unless specically recommended in this manual.
All other servicing should be referred to a qualied
technician.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 6 2018-03-27  2:35:33

English 7
Important safety instructions
SAVE THESE INSTRUCTIONS
• Use only dry potholders. Placing moist or damp
potholders on hot surfaces may result in burns from
steam. Do not let the potholder touch hot heating
elements. Do not use a towel or other bulky cloth
instead of a potholder.
• Teach children not to play with the controls or any
other part of the oven.
• For your safety, do not use high-pressure water
cleaners or steam jet cleaners to clean any part of the
oven.
• If the power cord is damaged, it must be replaced
by the manufacturer, its service agent, or similarly
qualied persons to avoid creating a hazard.
• The appliance is not intended for use by persons
(including children) with reduced physical, sensory
or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or
instruction concerning use of the appliance by a person
responsible for their safety.
• If there is a re in the oven during self-cleaning, turn
the oven off and wait for the re to go out. Do not
force the door open. The introduction of fresh air at
self-cleaning temperatures may lead to a burst of ame
from the oven. Failure to follow these instructions may
result in severe burns.
• If the oven is heavily soiled with oil, self-clean the oven
before using the oven again. Leaving the oil in place
creates a risk of re.
• Wipe up heavy soil on the oven bottom with a paper
tower or rag before self-cleaning. Self-cleaning the
oven when there is heavy soil on the oven bottom
requires longer cleaning cycles and produces more
smoke.
• Storage in or on the appliance. Do not store ammable
materials in the oven or near the surface units. Be sure
all packing materials are removed from the appliance
before operating it. Keep plastics, clothes, and paper
away from parts of the appliance that may become hot.
• Wear proper apparel. Never wear loose-tting or
hanging garments while using the appliance.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 7 2018-03-27  2:35:33

8 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
WARNING
• Ensure that the appliance is switched off before replacing
the lamp to avoid the possibility of electric shock.
CHILD SAFETY
WARNING
• This appliance is not intended for use by young children
or inrm persons without the adequate supervision of a
responsible adult.
• Young children should be supervised to ensure that they do
not play with the appliance.
• Keep children away from the door when opening or closing
it as they may bump themselves on the door or catch their
ngers in the door.
• During self-cleaning, the surfaces may get hotter than usual.
Keep small children away from the oven when it is in the
self-cleaning mode.
WARNING
Accessible parts may become hot during use. To avoid burns,
young children should be kept away.
ELECTRICAL SAFETY
• Use only the factory installed exible power cord to
connect to the power supply. Do not use a 3rd party
power supply cord kit.
• The appliance should be serviced only by qualied
service personnel. Repairs carried out by unqualied
individuals may cause injury or a serious malfunction.
If your appliance is in need of repair, contact a Samsung
authorized service center. Failure to follow these
instructions may result in damage and void the warranty.
• Flush - mounted appliances may be operated only after
they have been installed in cabinets and workplaces
that conform to the relevant standards. This ensures
that the appliances are installed in compliance with the
appropriate safety standards.
• If your appliance malfunctions or if fractures, cracks, or
splits appear:
• Switch off the oven.
• Unplug the oven from the AC wall outlet.
• Contact your local Samsung service center.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 8 2018-03-27  2:35:33

English 9
Important safety instructions
SAVE THESE INSTRUCTIONS
• Use care when opening the door. Let hot air or steam
escape before you remove food from or put food into the
oven.
• Protective liners. Do not use aluminum foil to line the oven
bottoms, except as suggested in this manual. Improper
installation of these liners may result in a risk of electric
shock or re.
• Keep oven vent ducts unobstructed. The oven vent is
located above the right rear surface unit. This area could
become hot during oven use. Never block this vent or place
plastic or heat-sensitive items on it.
• Placement of oven racks. Always place oven racks in the
desired location while the oven is cool. If the rack must be
moved while the oven is hot, use potholders. Do not let the
potholders come in contact with the hot heating element in
the oven.
• Do not allow aluminum foil or a meat probe to contact
the heating elements.
OVEN
• DO NOT TOUCH THE HEATING ELEMENTS OR INTERIOR
SURFACES OF THE OVEN. Heating elements may be hot
even though they are dark in color. Interior surfaces of
an oven become hot enough to cause burns. During and
after use, do not touch or let clothing or other ammable
materials contact the heating elements or interior
surfaces of the oven until they have had sufcient time
to cool. Other surfaces of the appliance may become hot
enough to cause burns. Among these surfaces are oven
vent openings and surfaces near these openings, the
oven door, and the window of the oven door.
• Do not heat unopened food containers. The build-up of
pressure may cause the container to burst and result in
injury.
• Do not use the oven to dry newspapers. If overheated,
newspapers can catch re.
• Do not use the oven for a storage area. Items stored in an
oven can ignite.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 9 2018-03-27  2:35:33

10 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
SELFCLEANING OVENS
Do not clean the door gasket. The door gasket is essential
for a good seal. Care should be taken not to rub, damage,
or move the gasket.
• Never keep pet birds in the kitchen. Birds are
extremely sensitive to the fumes released during an
oven self-clean cycle. Fumes may be harmful or fatal to
birds. Move birds to a well-ventilated room.
• Clean only the parts listed in this manual in the self-
clean cycle. Before self-cleaning the oven, remove the
divider, racks, utensils, and any food.
• Before operating the self-clean cycle, wipe grease and
food soils from the oven. Excessive amounts of grease
may ignite, leading to smoke damage to your home.
• Do not use any commercial oven cleaner or oven liner
protective coating of any kind in or on the outside of
the oven.
• Remove the nickel oven shelves from the oven before
you begin the self-cleaning cycle or they may discolor.
• During use, the appliance becomes hot.
Care should be taken to avoid touching heating
elements inside the oven.
• Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass. They can scratch
the surface which may result in the glass shattering.
CAUTION
Do not attempt to operate the oven during a power failure.
If the power fails, always turn the oven off. If the oven is
not turned off and the power returns, the oven may begin to
operate again. Food left unattended could catch re or spoil.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 10 2018-03-27  2:35:34

English 11
Important safety instructions
SAVE THESE INSTRUCTIONS
CRITICAL INSTALLATION WARNINGS
WARNING
• This appliance must be installed by a qualied
technician or service company.
• Failing to have a qualied technician install the
oven may result in electric shock, re, an explosion,
problems with the product, or injury.
• Unpack the oven, remove all packaging material and
examine the oven for any damage such as dents
on the interior or exterior of the oven, broken door
latches, cracks in the door, or a door that is not lined
up correctly. If there is any damage, do not operate the
oven and notify your dealer immediately.
• Plug the power cord into a properly grounded outlet
with the proper conguration. Your oven should be the
only item connected to this circuit.
• Keep all packaging materials out of the reach of
children. Children may use them for play and injure
themselves.
• If the self-cleaning mode malfunctions, turn the oven
off and disconnect the power supply. Have it serviced
by a qualied technician.
• Excess spillage must be removed before you run the
self-cleaning cycle.
VENTILATING HOOD
• Clean ventilating hoods frequently. Do not let grease
accumulate on the hood or lter.
• When aming foods under the hood, turn the fan on.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 11 2018-03-27  2:35:34

12 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
If the power cord is damaged, contact your nearest
Samsung service center.
CRITICAL USAGE WARNING
CAUTION
• If the appliance is ooded by any liquid, please contact
your nearest Samsung service center. Failing to do so
may result in electric shock or re.
• If the appliance produces a strange noise, a burning
smell, or smoke, unplug the power plug immediately
and contact your nearest Samsung service center.
• Failing to do so may result in electric shock or re
• In the event of a gas leak (such as propane gas, LP gas,
etc.), ventilate the area immediately. Do not touch the
power cord. Do not touch the appliance.
• A spark may result in an explosion or re.
• Take care not to contact the oven door, heating
elements, or any of the other hot parts with your body
while cooking or just after cooking.
• Failing to do so may result in burns.
• This appliance must be properly grounded.
• Do not ground the appliance to a gas pipe, plastic water
pipe, or telephone line.
• This may result in electric shock, re, an explosion,
or problems with the product
• Do not cut or remove the ground prong from the power
cord under any circumstances.
• Connect the oven to a circuit that provides the correct
amperage.
• Do not install this appliance in a humid, oily or dusty
location, or in a location exposed to direct sunlight or
water (rain drops).
• This may result in electric shock or re.
• Do not use a damaged power cord or loose wall socket.
• This may result in electric shock or re.
• Do not pull or excessively bend the power cord.
• Do not twist or tie the power cord.
• Do not hook the power cord over a metal object, place
a heavy object on the power cord, or insert the power
cord between objects.
• This may result in electric shock or re.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 12 2018-03-27  2:35:34

English 13
Important safety instructions
SAVE THESE INSTRUCTIONS
• Do not attempt to repair, disassemble, or modify the
appliance yourself.
• Since a high voltage current enters the product
chassis, it may result in electric shock or re.
• When a repair is needed, contact your nearest
Samsung service center.
• If any foreign substance such as water has entered the
appliance, contact your nearest Samsung service center.
• Failing to do so may result in electric shock or re.
• Do not touch the power cord with wet hands.
• This may result in electric shock.
• Do not turn the appliance off while an operation is in
progress.
• This may cause a spark and result in electric shock
or re.
• Do not let children or any person with reduced
physical, sensory, or mental capabilities use this
appliance unsupervised.
• Make sure that the appliance’s controls and cooking
areas are out of the reach of children.
• Failing to do so may result in electric shock, burns,
or injury.
• If materials inside the oven should ignite, keep the
oven door closed, turn the oven off and disconnect
the power cord, or shut off power at the fuse or circuit
breaker panel. If the door is opened, the re may
spread.
• Always observe safety precautions when using your
oven. Never try to repair the oven on your own - there
is dangerous voltage inside. If the oven needs to be
repaired, contact an authorized Samsung service center
near you.
• If you use the appliance when it is contaminated by
foreign substances such as food waste, it may result in
a problem with the appliance.
• Take care when removing the wrapping from food you
have taken out of the oven.
• If the food is hot, hot steam may be emitted
abruptly when you remove the wrapping and this
may result in burns.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 13 2018-03-27  2:35:34

14 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
• Open the cap or stopper of sealed containers (herb
tonic tea bottle, baby bottle, milk bottle and so on)
before heating them. Make a hole in food items that
have shells (eggs, chestnuts, etc.) with a knife before
cooking them.
• Failing to do so may result in burns or injury.
• Never heat plastic or paper containers and do not use
them for cooking.
• Failing to do so may result in re.
• Do not heat food wrapped in paper from magazines,
newspapers, etc.
• This may result in re.
• Do not open the door when the food in the oven is
burning.
• If you open the door, it causes an inow of oxygen
and may cause the food to ignite.
• Do not touch the inside of the appliance immediately
after cooking. The inside of the appliance will be hot.
• Failing to do so may result in burns.
• Do not use or place ammable sprays or objects near
the oven.
• Flammable items or sprays can cause res or an
explosion.
• Do not insert ngers, foreign substances, or metal
objects such as pins or needles into inlets, outlets, or
holes. If foreign substances are inserted into any of
these holes, contact your product provider or nearest
Samsung service center.
• Do not tamper with or make any adjustments or repairs
to the door. Under no circumstances should you remove
the door or outer shell of the oven.
• Do not store or use the oven outdoors.
• Never use this appliance for purposes other than
cooking.
• Using the appliance for any purpose other than
cooking may result in re.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 14 2018-03-27  2:35:35

English 15
Important safety instructions
SAVE THESE INSTRUCTIONS
USAGE CAUTIONS
CAUTION
• If the surface is cracked, turn the appliance off.
• Failing to do so may result in electric shock.
• Dishes and containers can become hot. Handle with
care.
• Hot foods and steam can cause burns. Carefully remove
container coverings, directing the steam away your
hands and face.
• Remove lids from baby food jars before heating. After
heating baby food, stir well to distribute the heat
evenly. Always test the temperature by tasting before
feeding the baby. The glass jar or the surface of the
food may appear to be cooler than the interior, which
can be hot enough to burn an infant’s mouth.
• Take care as beverages or food may be very hot after
heating.
• Especially when feeding a child, make sure the food
or beverage has cooled sufciently.
• Do not apply excessive pressure to the door or the
inside of the appliance. Do not strike the door or the
inside or the appliance.
• Hanging on to the door may result in the product
falling and cause serious injury.
• If the door is damaged, do not use the appliance.
Contact a Samsung service center.
• Do not hold food in your bare hands during or
immediately after cooking.
• Use cooking gloves. The food may be very hot and
you could burn yourself.
• As the handle and oven surfaces may be hot enough
to cause burns after cooking, use cooking gloves to
protect your hands from burns.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 15 2018-03-27  2:35:35

16 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
• Do not put your face or body close to the appliance while
cooking or when opening the door just after cooking.
• Take care that children do not come too close to the
appliance.
• Failing to do so may result in children burning
themselves.
• Do not place food or heavy objects over the edge of the
oven door.
• If you open the door, the food or object may fall and this
may result in burns or injury.
• Do not abruptly cool the door, the inside of the appliance, or
a dish by pouring water over it during or just after cooking.
• This may result in damage to the appliance. The steam
or water spray may result in burns or injury.
• Do not operate while empty except for self-cleaning.
• Do not defrost frozen beverages in narrow-necked bottles.
The bottles can break.
• Do not scratch the glass of the oven door with a sharp
object.
• This may result in the glass being damaged or broken.
• Take care when heating liquids such as water or other
beverages.
• Make sure to stir during or after cooking.
• Avoid using a slippery container with a narrow neck.
• Wait at least 30 seconds after heating before removing
the heated liquid.
• Failing to do so may result in an abrupt overow of the
contents and cause burns.
• Do not stand on top of the appliance or place objects
(such as laundry, an oven cover, lighted candles, lighted
cigarettes, dishes, chemicals, metal objects, etc.) on the
appliance.
• Items, such as a cloth, may get caught in the door.
• This may result in electric shock, re, problems with the
product, or injury.
• Do not operate the appliance with wet hands.
• This may result in electric shock.
• Do not spray volatile substances such as insecticide onto
the surface of the appliance.
• As well as being harmful to humans, it may also result
in electric shock, re, or problems with the product.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 16 2018-03-27  2:35:35

English 17
Important safety instructions
SAVE THESE INSTRUCTIONS
CRITICAL CLEANING WARNINGS
CAUTION
• Do not clean the appliance by spraying water directly
on to it.
• Do not use benzene, thinner, or alcohol to clean the
appliance.
• This may result in discoloration, deformation,
damage, electric shock, or re.
• Take care not to hurt yourself when cleaning the
appliance (externally or internally).
• You may hurt yourself on the sharp edges of the
appliance.
• Do not clean the appliance with a steam cleaner.
• This may result in corrosion.
• Keep the inside of the oven clean. Food particles or
spattered oils stuck to the oven walls or oor can cause
paint damage and reduce the efciency of the oven.
• Do not store anything directly on top of the appliance
when it is in operation.
• Do not use sealed containers. Remove seals and lids
before cooking. Sealed containers can explode due to
the build up of pressure even after the oven has been
turned off.
• Take care that food you are cooking in the oven does
not come into contact with the heating element.
• This may result in re.
• Do not over-heat food.
• Overheating food may result in re.
• Use caution when opening or closing the door. Your
ngers may be pinched, resulting in physical injury.
• The door has wires at the bottom for connecting LED
lights. Be careful not to pull or cut the wires when
handling the door.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 17 2018-03-27  2:35:35

18 English
Introducing your new oven
Introducing your new oven
What’s included with your oven
Wire racks (3)* Gliding racks (3)* Divider (1)*
Temp probe (1)*
NOTE
If you need an accessory marked with a *, you can buy it from the Samsung
Contact Center (1-800-726-7864).
Introducing your new oven
Overview
01
02
02
03
03
05
05
09
04
08
06 07
01 Oven control panel 02 Oven door 03 Oven gasket
04 Halogen lamp* 05 Door LED light 06 Door latch
07 Water reservoir 08 Convection fan 09 Shelf position
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 18 2018-03-27  2:35:36

English 19
Before you begin
Water reservoir
The water reservoir is used for the Steam Bake, Steam Roast , Steam Bread Proof
and Hybrid Clean functions and also to remove water scale that may form on the
oven walls, especially after Steam Baking, Steam Roasting, Steam Bread Proong
and Hybrid cleaning. Fill it with water in advance of steam cooking or descaling.
1. Locate the water reservoir. The water
reservoir is on the right side of the
oven, just above the oven opening.
Touch Reservoir on the control
panel. The oven ejects the water
reservoir.
Grasp the front of the reservoir, and
then slide it out to remove.
2. Open the reservoir cap, and then ll
the reservoir with 22 oz (650 ml) of
drinkable water.
NOTE
You can open the reservoir by removing the
rubber cap or by removing the clear plastic
top.
Before you begin
Clean the oven thoroughly before using it for the rst time. Then, remove the
accessories, set the oven to Bake, and then run the oven at 400 °F for 1 hour.
There will be a distinctive odor. This is normal.
Ensure your kitchen is well ventilated during this conditioning period.
Energy saving tips
• During cooking, the oven door should remain closed except when you turn
food over. Do not open the door frequently during cooking to maintain the
oven temperature and to save energy.
• If cooking time is more than 30 minutes, you can switch the oven off
5-10 minutes before the end of the cooking time to save energy. The residual
heat will complete the cooking process.
• To save energy and reduce the time needed for re-heating the oven, plan oven
use to avoid turning the oven off between cooking one item and the next.
• Whenever possible, cook more than one item at a time.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 19 2018-03-27  2:35:37

20 English
Before you begin
Before you begin
3. Replace the cap or the clear plastic top,
and then slide the water reservoir back
into the reservoir slot.
4. Push the reservoir in. There will be soft
click when it is in place correctly. Touch
Reservoir . The oven retracts the
water reservoir.
5. Close the oven door.
Max
0.5L
0.3L
NOTE
Do not exceed the max line.
A
NOTE
Make sure the cap and the upper portion of
the water reservoir (labeled A) are closed
before using the oven.
CAUTION
The water reservoir becomes hot during cooking. Make sure you wear oven gloves
to remove or rell the water reservoir.
Operating the oven
Control panel
01 02 04 05 08 07 06 01 02
0303
01 Upper or lower mode knob:Use to select the mode of the upper or lower
oven.
• Upper: Bake, Broil, Bake (Convection Bake), Roast (Convection
Roast), Steam Bake, Steam Roast, Steam Bread Proof, Healthy Cook,
Favorite Recipes, Gourmet Cook, Clean.
• Lower : Bake, Broil, Bake (Convection Bake), Roast (Convection
Roast), Broil (Convection Broil), Dehydrate, Keep Warm, Bread Proof,
Healthy Cook, Gourmet Cook, Clean.
02 Temperature knob:Use to set the temperature for the upper or lower oven
respectively.
03 UPPER, LOWER:Use to display the upper oven or lower oven mode screen on
the display. Touching here does not turn the ovens on or off. It only displays
their current status.
04 Timer : Use to display the set Timer screen.
05 Settings and Control Lockout : Use to display the Setting screen. If you
touch and hold this key for 3 seconds, all oven functions will be disabled.
06 Lamp : Use to turn the oven light on or off.
07 Reservoir :Touch to open the water reservoir.
08 Display:Swipe to navigate through the menus and tap to select a desired
setting.
NOTE
If you tap or touch the display while wearing plastic or oven gloves, the display
will not operate properly. Take the gloves off rst, and then tap with a bare nger.
NV51M9770DS_AA_DG68-01001A-01_EN+MES+CFR.indb 20 2018-03-27  2:35:39
