Samsung NV70F7584DS User manual

This manual is made with 100 % recycled paper.
Built-in Oven
user manual
imagine the possibilities
Thank you for purchasing this Samsung product.
NV70F7584DS
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 1 2015-03-13 �� 11:33:25

English - 2
contents
OVEN CONTROLS
12
12 Oven controls
ACCESSORIES
12
12 Accessories
INITIAL CLEANING
14
14 Initial cleaning
USING THE OVEN
14
14 Set temperature
14 Useful auto speed preheating
TIME SETTING
15
15 Set time
15 Set cook timer
15 Set end timer
16 Set delay start
16 Set kitchen timer
OTHER SETTINGS
16
16 Tone signal
16 Oven light
16 Child lock
16 Switch off
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 2 2015-03-13 �� 11:33:25

English - 3
AUTOMATIC COOKING
18
18 Single oven auto cook programmes
COOKING GUIDE
21
21 Convection
21 Large grill
21 Eco grill
22 Conventional
22 Bottom + Convection
22 Top + Convection
23 Test dishes
COOKING FUNCTIONS
17
17 Cooking functions
CLEANING AND CARES
24
24 Steam cleaning (depending on model)
24 Catalytic enamel surface
(depending on model)
24 Hand cleaning
25 Water collector cleaning
25 Detaching the side runners
(depending on model)
25 Cleaning the ceiling (depending on model)
26 Troubleshooting
26 Information codes
27 Product data sheet
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 3 2015-03-13 �� 11:33:25

English - 4
using this manual
Thank you for choosing SAMSUNG Built - In Oven.
This user Manual contains important information on safety and instructions intended to assist you in the
operation and maintenance of your appliance.
Please take the time to read this Owner’s Manual before using your oven and keep this book for future
reference.
The following symbols are used in the text of this Owner’s Manual:
WARNING or CAUTION Important Note
safety instructions
Installation of this oven must be performed only by a licensed electrician. The installer is responsible
for connecting the appliance to the mains power supply in observance of the relevant safety
recommendations.
WARNING
This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
Children should be supervised to ensure that they do not
play with the appliance.
If the supply cord is defective, it must be replaced by a
special cord or assembly available from the manufacturer or
an authorised service agent. (Fixed wiring type model only)
If the supply cord is damaged, it must be replaced by
the manufacturer, its service agent or similarly qualified
persons in order to avoid a hazard. (power cord type
model only)
Appliance should allow to disconnection of the appliance
from the supply after installation. The disconnection
may be achieved by having the plug accessible or by
incorporating a switch in the fixed wiring in accordance
with the wiring rules.
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 4 2015-03-13 �� 11:33:27

English - 5
During use the appliance becomes hot. Care should be
taken to avoid touching heating elements inside the oven.
WARNING: Accessible parts may become hot during
use. Young children should be kept away.
If this appliance has steam or self cleaning function,
excess spillage must be removed before cleaning and
all utensils should not be left in the oven during steam
cleaning or self cleaning. (cleaning function model only)
If this appliance has self cleaning function, during self
cleaning the surfaces may get hotter than usual and
children should be kept away. (cleaning function model
only)
Only use the temperature probe recommended for this
oven.
(temperature sensing probe model only)
A steam cleaner is not to be used.
WARNING: Ensure that the appliance is switched o
before replacing the lamp to avoid the possibility of
electric shock.
Do not use harsh abrasive cleaners or sharp metal scrapers
to clean the oven door glass since they can scratch the
surface, which may result in shattering of the glass.
WARNING: The appliance and its accessible parts
become hot during use.
Care should be taken to avoid touching heating
elements.
Children less than 8 years of age shall be kept away
unless continuously supervised.
This appliance can be used by children aged from
8years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe way
and understand the hazards involved. Children shall not
play with the appliance. Cleaning and user maintenance
shall not be made by children without supervision.
01 USING THIS MANUAL & SAFETY INSTRUCTIONS
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 5 2015-03-13 �� 11:33:27

English - 6
The temperature of accessible surfaces may be high
when the appliance is operating.
The door or the outer surface may get hot when the
appliance is operating.
Keep the appliance and its cord out of reach of children
less than 8 years.
Appliances are not intended to be operated by means of
an external timer or separate remote-control system.
Please put the bent up frame side to the
back, in order to support the restposition
when cooking big loads. (Depending on
model)
CAUTION
If the oven has been damaged in transport, do not connect it.
This appliance must be connected to the mains power supply only by a specially licensed
electrician.
In the event of a fault or damage to the appliance, do not attempt to operate it.
Repairs should be performed by a licensed technician only. Improper repair may result in
considerable danger to you and others. If your oven needs repair, contact a SAMSUNG Service
Centre or your dealer.
Electrical leads and cables should not be allowed to touch the oven.
The oven should be connected to the mains power supply by means of an approved circuit
breaker or fuse. Never use multiple plug adapters or extension leads.
The power supply of the appliance should be turned off when it is being repaired or cleaned.
Take care when connecting electrical appliances to sockets near the oven.
If this appliance has steam cooking function, do not operate this appliance when the water
supply cartridge is damaged. (Steam function model only)
When the cartridge is cracked or broken, do not use it and contact your nearest service center.
(Steam function model only)
This oven has been designed only for the cooking of household foods.
During use, the oven interior surfaces become hot enough to cause burns. Do not touch heating
elements or interior surfaces of the oven until they have had time to cool.
Never store flammable materials in the oven.
The oven surfaces become hot when the appliance is operated at a high temperature for an
extended period of time.
When cooking, take care when opening the oven door as hot air and steam can escape rapidly.
When cooking dishes that contain alcohol, the alcohol may evaporate due to the high
temperatures and the vapour can catch fire if it comes into contact with a hot part of the oven.
For your safety, do not use high-pressure water cleaners or steam jet cleaners.
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 6 2015-03-13 �� 11:33:27

English - 7
Children should be kept at a safe distance when the oven is in use.
Frozen foods such as pizzas should be cooked on the Big grid. If the baking tray is used, it may
become deformed due to the great variation in temperatures.
Do not pour water into the oven bottom when it is hot. This could cause damage to the enamel
surface.
The oven door must be closed during cooking.
Do not line the oven bottom with aluminium foil and do not place any baking trays or tins on it.
The aluminium foil blocks the heat, which may result in damage to the enamel surfaces and cause
poor cooking results.
Fruit juices will leave stains, which can become indelible on the enamel surfaces of the oven.
When cooking very moist cakes, use the deep pan.
Do not rest bakeware on the open oven door.
Young children should be supervised to ensure that they do not play with the appliance.
Keep children away from the door when opening or closing it as they may bump themselves on
the door or catch their fingers in the door.
Do not step, lean, sit or place heavy stuff on the door.
Do not open the door with unnecessarily strong power.
WARNING: Do not disconnect the appliance from the main power supply even after the
cooking process is completed.
WARNING: Do not leave the door open while oven is cooking.
Keep children away from the door when opening or closing it as they may bump themselves on
the door or catch their fingers in the door.
BULB EXCHANGE
Danger of electric shock! Before replacing any of
the oven bulbs, take the following steps:
•Switch oven O.
•Disconnect the oven from the mains.
•Protect the oven light bulb and the glass cap by laying a
cloth on the bottom of the oven compartment.
•Bulbs can be purchased from the SAMSUNG Service
Centre.
01 USING THIS MANUAL & SAFETY INSTRUCTIONS
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 7 2015-03-13 �� 11:33:27

English - 8
Rear oven light
1.Remove cap by turning anticlockwise and
remove the metal ring, the sheet ring and
clean the glass cap. If necessary, replace
the bulb with a 25 watt, 300 °C heat-
resistant oven light bulb.
2.Clean the glass cap, the metal ring and the sheet ring if
necessary.
3.Fit the metal and the sheet ring to the glass cap.
4.Place glass cap where you have removed it in step 1 and
turn it clockwise to keep it in place.
Oven side light (Depending on model)
1.To remove the glass cover,
hold the lower end with
one hand, insert a flat
sharp implement such as
a table knife between the
glass and the frame.
2.Pop out the cover.
3.If necessary, replace the halogen bulb with a 25-40 watt,
300°C heat resistant halogen oven light bulb.
Tip: Always use a dry cloth when handling a halogen
bulb to prevent sweat from fingers being deposited on
the bulb surface. It increases the life of the bulb when
you exchange the bulb.
4.Reattach the glass cover.
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 8 2015-03-13 �� 11:33:28

English - 9
DOOR REMOVAL
For normal use, the oven door must not be removed but if removal is necessary, for example, for
cleaning purposes, follow these instructions.
CAUTION: The oven door is heavy.
70
2
1
1. Open the door and flip
open the clips at both
hinges completely.
2. Close the door by
approximately 70 °. With
both hands, grasp the
sides of the oven door at its
middle and pull-lift until the
hinges can be taken out.
3. After cleaning, for
attaching the door repeat
the 1 and 2 steps in
revers order. The clip
on the hinge should be
closed on both side.
DOOR GLASS REMOVAL
The oven door is equipped with three sheets of glass placed against each other. These sheets can
be removed for cleaning.
Glass 1
Glass 1 Glass 1
Glass 2
Glass 2
Glass 1
1. Press the both buttons on
the left and right sides of
the door.
2. Detach the covering and
remove glass 1 and 2
from the door.
3. After cleaning the door
glasses, for assembly
repeat 1, 2 steps in revers
order. Check the right
locations of glass 1 and 2
with above picture.
ATTACHING: The Door-Glass is different from 2EA to 4EA model by model.
When assembly the inner glass 1, put printing to direction below.
01 USING THIS MANUAL & SAFETY INSTRUCTIONS
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 9 2015-03-13 �� 11:33:31

English - 10
AUTO ENERGY SAVING FUNCTION
• Ifyoudonotselectanyfunctionwhenapplianceisinthemiddleofsettingoroperatingwith
temporary stop condition, function is canceled and clock will be displayed after 10 minutes.
• Light : During cooking process, you can switch off Oven lamp by pressing ‘Oven light’ button.
For energy saving, the oven lighting is switched off a few minutes after cooking program has
started.
CORRECT DISPOSAL OF THIS PRODUCT
(WASTE ELECTRICAL & ELECTRONIC EQUIPMENT)
(Applicable in countries with separate collection systems)
This marking on the product, accessories or literature indicates that the product and its electronic
accessories (e.g. charger, headset, USB cable) should not be disposed of with other household
waste at the end of their working life. To prevent possible harm to the environment or human health
from uncontrolled waste disposal, please separate these items from other types of waste and
recycle them responsibly to promote the sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local
government office, for details of where and how they can take these items for environmentally safe
recycling.
Business users should contact their supplier and check the terms and conditions of the purchase
contract. This product and its electronic accessories should not be mixed with other commercial
wastes for disposal.
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 10 2015-03-13 �� 11:33:31

English - 11
installation
Safety instructions for the installation
This oven may be installed only by an approved electrician. The installer is responsible for
connecting the appliance to the main supply, while observing the relevant safety regulations.
•
Ensure protection from live parts when installing the oven.
Power connection
If it is not possible to connect the appliance to the mains with a plug due to
allowable current limitations, a multi-pole isolator switch (with at least 3 mm
contact spacing) must be provided in order to satisfy safety regulations. The
power cable (H05 RR-F or H05 VV-F, min., 1.5-2.5 mm²) must be of sufficient
length to be connected to the oven, even if the oven stands on the floor in front of
its built-in cabinet. Open the rear connection cover of the oven with a screwdriver
and loosen the screws of the cable clamp before you connect the power lines to
the relevant connection terminals. The oven is earthed via the ( )-terminal. The
yellow and green cable(earth connection) must be connected first and be longer
than the others. If the oven is connected to the mains with a plug, this plug must
remain accessible after the oven is installed. Samsung will take no responsibility
for accidents that originate from a missing or faulty earth connection.
WARNING: Do not allow the connecting cable to become trapped during installation, and
prevent it coming into contact with hot parts of the oven.
Installation in the cabinet
With built-in furniture, plastic surfaces and adhesive for the oven should be resistant to 90 °C inside of
the furniture and to 75 °C for adjacent furniture. Samsung will take no responsibility for damage of plastic
surfaces or adhesive from the heat.
There should be a ventilation gap in the base of the kitchen cabinet where the oven is to be placed. For
ventilation, a gap of about 50mm should be left between the lower shelf and the supporting wall. If the
oven is to be installed below a hob, the hob’s installation instructions should be followed.
Push the appliance completely into the cabinet and fix the oven firmly on both sides using 2 screws. Make
sure that a gap of at least 5mm should be left between the appliance and the adjacent cabinet.
After installation, remove the vinyl protective film, tape, paper and accessories from the door and inside
of oven. Before uninstalling the oven from the furniture, disconnect the oven from the power supply and
release the 2 screws on the both sides of the oven.
WARNING: The built-in furniture must have a minimum ventilation gap for Air-flow as shown
on picture. Do not cover this hole with strips of wood, for this is used to provide ventilation.
The front exterior of the oven such as handle is different model by model. But the size of the
oven in the picture is same.
min. 550
595
370 560
545
21
595
Max.50
Min.550 Min.560
Min.50
Min.590 ~ Max.600
Min.460 x Min.50
Built-in
055
550
275
572
595
370 560
545
21
85
595
175
Max.494
Min.550 Min.560
Min.600
Min.460 x Min.50
Built-under
Built-in + Built-under
055
550
275
572
Max.506
02 INSTALLATION
BROWN
or BLACK
BLUE or
WHITE
YELLOW
and GREEN
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 11 2015-03-13 �� 11:33:33

English - 12
oven controls
Front design
The front panel is available in various material and color options including stainless steel,
white, black and glass. For purposes of quality improvement, the appearance may be
subject to change.
accessories
Your new Samsung oven comes with a lot of accessories that should become very helpful
during the preparation of different meals. The following accessories are supplied differently
model by model.
WARNING: Be very carefull removing meals and/or accessories out of the oven. Hot meals,
accessories and surfaces can burn you!
Allow at least a 1 cm space from the accessory and the bottom of the oven, and from any
other accessory.
The oven operates without the side runners and racks in position.
The accessories can become deformed when they become hot. When they have cooled
down, the deformation disappears with no effect on the function.
Wire shelf
The wire shelf should be used for grilling and roasting meals. You could use
it with casseroles and other baking pots. Please put the bent up frame side
to the back, in order to support the restposition when cooking big loads.
Wire tray insert (Depending on model)
The wire tray insert should be used for grilling and roasting meals. It can be
used in combination with the tray to prevent liquids from dropping onto the
bottom of the oven.
Mode selector Multi function
selector
Sound On/Off End timer
Temperature Cook timer
Display
Preheating indicator
Oven lightKitchen timer Child lockTime
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 12 2015-03-13 �� 11:33:35

English - 13
Baking tray (Depending on model)
The baking tray (Depth : 20mm) could be used for the preparation of cakes,
cookies and other pastries. Please put the slanted side to the front.
Universal tray (Depending on model)
The universal tray (Depth : 30mm) could be used for the preparation of cakes,
cookies and other pastries. And it is also good for roasting. It can be used in
combination with the wire tray insert to prevent liquids from dropping onto the
bottom of the oven. Please put the slanted side to the front.
Extra deep tray (Depending on model)
The extra deep tray (Depth : 50mm) is also good for roasting. It can be used in
combination with the wire tray insert to prevent liquids from dropping onto the
bottom of the oven. Please put the slanted side to the front.
Rotisserie spit (Depending on model)
The rotisserie spit could be used for grilling such as chicken. The rotisserie
spit can only be used in single mode on shelf level 3, because its spit has to
be attached to an adapter on the back plane. Remove black plastic handle
while cooking.
Rotisserie spit and Shashlik (Depending on model)
To use it :
• Place the tray (no trivet) at shelf level 1 to collect the cooking juices or on
the bottom of the oven if the piece of meat to be roasted is too big.
• Slide one of the forks onto the spit; put the piece of meat to be roasted
onto the spit;
• Parboiled potatoes and vegetables can be placed around the edge of
the tray to roast at the same time.
• Place the cradle on the middle shelf and position with the “v” shape at
the front.
• To help insert the spit, the handle can be screwed onto the blunt end.
• Rest the spit onto the cradle with the pointed end towards the back and
gently push until the tip of the spit enters the turning mechanism at the
back of the oven. The blunt end of the spit must rest on the “v” shape.
(The spit has two lugs which should be nearest to the oven door so to
stop the spit going forward, the lugs also act as a grip for the handle.)
• Unscrew the handle before cooking. After cooking screw the handle
back on to help remove the spit from the cradle.
It is recommended that the spit accessories are used with food under
1.5kg weight.
Telescopic rails (Depending on model)
• To insert the wire shelf or tray, first slide out the telescopic rails for one
particular level.
• Place the wire shelf or tray on the rails and push them back completely
into the oven. Close the oven door only after you have pushed the
telescopic rails into the oven.
Grease filter (Depending on model)
The grease filter installed on the back oven interior wall protects the fan,
round heater, and the oven from impurity, particularly spattering fat. When
cooking meat, we recommend using the fat filter. When baking pastry,
always remove the filter! If the filter is installed when baking pastry or cakes,
the results can be quite poor.
03 OVEN CONTROLS & ACCESSORIES
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 13 2015-03-13 �� 11:33:38

English - 14
initial cleaning
Before the oven is used for the first time, initial cleaning of the oven is required to remove the new oven smell.
1. Remove all accessories from the oven.
2. Run oven with convection 200 °C or conventional 200 °C for an hour. This procedure will burn
any remaining production substances in the oven.
3. Switch o the oven by tunring mode selector to o after an hour.
For the first time use of the accessories, clean the accessories thoroughly with warm water,
detergent and soft clean cloth.
using the oven
Your new oven has below basic steps for cooking.
SET TEMPERATURE
The temperature can be set after setting the cooking function.
Each cooking function has different temperature range, refer the cooking function part in the manual.
1. Press the key, temperature figure will blink.
2. Turn the multi function selector to set desired temperature.
3. Press the key again.
During cooking, you can change the temperature in the same order as above.
USEFUL AUTO SPEED PREHEATING
Your oven offerscooking functions, which include a fast preheating stage.
This stage will be indicatedbeside temperature setting in the display.
During this preheatingstage various heating elements are applied to speed up heating of the oven.
Even though you change temperature to higher, the oven automatically change target temperature
and auto speed preheating will be applied. After the selected temperature is reached, the
preheating indicator will disappear and a signal reminds you to insert the food into your oven.
STEP 1
SELECT THE
COOKING MODE
STEP 2
SET
TEMPERATURE
Mode selector Multi function
selector
Temperature
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 14 2015-03-13 �� 11:33:39

English - 15
time setting
SET TIME
For the first time use of the oven or after power failure, time setting is required.
1. Press the key, hours figure will blink.
2. Turn the Multi function selector to set hours.
3. Press the key, minutes figure will blink.
4. Turn the Multi function selector to set minutes.
5. Press the key again to set the current time.
The desired time can be reset in the same order as above.
During cooking process, press key to see the current time.
SET COOK TIMER
After you get cooking function, you can set how much time you will cook. And the setted time is
over, heating elements automatically turn off.
1. Press key, cook timer figure will blink.
2. Turn the multi function selector to apply the desired time for cook timer.
3. Press key again.
The cook timer can be reset in the same order as above. When the setted time is over, the
display shows blinking “0:00” with a signal. You can set a new cook timer or turn off the oven.
To cancel the cook timer, press key and set the c ook timer to zero.
SET END TIMER
After you get cooking function, you can set when the cook is over. And the setted time is over,
heating elements automatically turn off.
1. Press key, end timer figure will blink.
2. Turn the Multi function selector to apply the time for end timer.
3. Press key again.
The end timer can be reset in the same order as above and when the setted time is over, the
display shows blinking “0:00” with a signal.
To cancel the end timer, press key and set the end timer to current time.
04 INITIAL CLEANING & USING THE OVEN & TIME SETTING
End timer Multi function
selector
Cook timerKitchen timer Time
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 15 2015-03-13 �� 11:33:40

English - 16
SET DELAY START
If the end timer is entered after the cook timer has already been set, the cook timer and the end
timer are calculated and if necessary the oven sets a delay start point.
WARNING: Do not leave the food for too long time in the oven as food may spoil.
1. Press key, cook timer figure will blink.
2. Turn the multi function selector to apply the time for cook timer.
3. Press key, end timer figure will blink.
4. Turn the multi function selector to apply the time for end timer.
5. The delay start point is automatically calculated and the oven is waiting until delay start point.
The cook timer, end timer and delay start can be set after cooking function setting.
SET KITCHEN TIMER
The kitchen timer can be set independently of the oven function and used with cook timer or end
timer at the same time. As kitchen timer has it’s own signal you can discriminate it from others.
1. Press key, kitchen timer figure will blink.
2. Turn the multi function selector, to apply the desired time for kitchen timer.
3. Press key again.
To cancel the kitchen timer, press the hold key for two seconds.
The kitchen timer can be reset in the same order as above and when the setted time is over,
the display shows blinking “0:00” with a signal.
other settings
TONE SIGNAL
To activate or deactivate the tone signal, press and hold the key for 3
seconds.
OVEN LIGHT
Press key to turn on and off.
For energy saving, the oven lamp is switched off in a few minutes after the start of a
cooking.
CHILD LOCK
To activate or deactivate the child lock function, press and hold key for 3 seconds.
Display will show the when the child lock function is activated. You can use the child
lock function during cooking also. In this case every keys and selector knob will not
react but you can switch off by turning the operation knob to off.
SWITCH OFF
When the oven has been switched off every heating elements stop operating.
The cooling fan will continue to run for a while after the oven has been switched off
for safety.
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 16 2015-03-13 �� 11:33:43

English - 17
cooking functions
This oven offers below various functions.
Symbol Function
Temp Range Use
Conventional
40-250 °C
Heat is emitted from the top and bottom heating system. This
function should be used for standard baking and roasting of almost
any type of dishes.
Suggested temperature : 200 °C
Convection
40-250 °C
The heat generated by the convection is shared evenly in the oven by
fans. This function should be used for frozen dishes and baking.
Suggested temperature : 170 °C
Top +
Convection
40-250 °C
The heat generated by the top heating system and the convection is
shared evenly in the oven by fans. This function should be used for
roasting crusty dishes like meat.
Suggested temperature : 190 °C
Bottom +
convection
40-250 °C
The heat generated by the bottom heating system and the convection
is shared evenly in the oven by fans. This function should be used for
pizzas, bread and cakes.
Suggested temperature : 190 °C
Large grill
40-270 °C
Heat is emitted from the large area grill. This function should be used
for scalloped dishes like lasagne and grilling meat.
Suggested temperature : 240 °C
Eco grill
40-270 °C
Heat is emitted from the small area grill. This function should be used
for smaller dishes that need less heat, like fish and filled baguettes.
Suggested temperature : 240 °C
Fan grill
40-270 °C
The heat generated by the two top heating elements is distributed by
the fan.
This mode can be used for grilling meat and fish.
Suggested temperature : 240 °C
Intensive cook
40-250 °C
This mode activates all heating elements such as upper, lower and
convection fan alternately.
The heat is distributed evenly in the oven. This mode is suitable for
big quantities of food, which need heat supply, such as large gratins
and pies.
Suggested temperature : 170 °C
ProRoasting
40-150 °C
This mode includes an automatic heating-up cycle up to 220 °C.
The top heater and the convection fan is operating during the process
of searing the meat.
After this stage the food is cooked gently by the low temperature of pre-
selection.
This process is done while the top and the bottom heaters are
operating. This mode is suitable for meat roasts, poultry and fish.
Suggested temperature : 100 °C
05 OTHER SETTINGS & COOKING FUNCTIONS
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 17 2015-03-13 �� 11:33:46

English - 18
automatic cooking
With automatic cooking function, you can select desired auto programmes for cooking,
roasting and baking.
1. Turn the mode selector to Auto cook mode.
2. Turn the multi function selector to select the desired Food item No. and wait for 4-5 seconds.
3. Turn the multi function selector to select the desired weight and wait for 4-5 seconds.
4. After 4-5 seconds, Auto cook programmes will start automatically.
SINGLE OVEN AUTO COOK PROGRAMMES
The following table presents 25 Auto Programmes for Cooking, Roasting and Baking.
It contains its quantities, weight ranges and appropriate recommendations.
Cooking modes and times have been pre-programmed for your convenience.
You can refer to these guidelines for cooking. Always insert food in cold oven.
No Food item Weight/kg Accessory Shelf
level Recommendation
A:01 Frozen Pizza 1. 0.3-0.6
2. 0.7-1.0
Wire shelf 2 Put frozen Pizza in the centre of Wire
shelf. We recommend 0.3-0.6 g setting
for thin pizzas, 0.7-1.0 g for pizzas with
thick topping.
A:02 Frozen Oven
Chips
1. 0.3-0.5
2. 0.5-0.7
Baking tray 2 Distribute frozen Oven Chips on baking
tray. The first setting is recommended for
thin French fries, the second setting is
recommended for thick oven chips. Use
baking paper. We recommend to turn
over after 2/3 of cooking time.
A:03 Frozen
Croquettes
1. 0.3-0.6
2. 0.7-1.0
Baking tray 2 Put frozen potato croquettes evenly on
baking tray. We recommend to turnover
after 2/3 of cooking time.
A:04 Homemade
Lasagne
1. 0.3-0.5
2. 0.8-1.0
Wire shelf 3 Use ovenproof glassware. Put chilled or
homemade lasagne in the middle of oven
on wire rack.
A:05 Beef Steaks 1. 0.3 - 0.6
2. 0.6 - 0.8
Wire shelf
Universal
tray
4
3
Put 2-6 beef steaks side by side evenly
on Wire shelf. The first setting is for thin
steaks, the second setting is for thick
steaks. Turn over after beep sounds.
Multi function selectorWeight Food item No.
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 18 2015-03-13 �� 11:33:46

English - 19
No Food item Weight/kg Accessory Shelf
level Recommendation
A:06 Roast Beef 1. 0.6 - 0.8
2. 0.9 - 1.1
3. 1.2 - 1.4
Wire shelf
Universal
tray
2
1
Marinate Roast Beef and put on Wire
shelf. Add 1 cup of water into Universal
tray. Turn over after beep sounds. After
cooking wrap in aluminium foil and let
stand for 5-10 min.
A:07 Pork Roast 1. 0.6 - 0.8
2. 0.9 - 1.1
Wire shelf
Universal
tray
2
1
Put marinated roast pork on Wire shelf.
Turn over, as soon as the oven beeps
A:08 Lamb Chops 1. 0.3 - 0.4
2. 0.5 - 0.6
Wire shelf
Universal
tray
4
3
Marinate lamb chops. Put lamb chops on
Wire shelf. Turn over, as soon as the oven
beeps. The first setting is for thin chops,
the second setting is for thick chops.
A:09 Chicken
Pieces
1. 0.5 - 0.7
2. 1.0 - 1.2
Wire shelf
Universal
tray
4
3
Brush chicken pieces with oil and spices.
Put chicken pieces side by side on the
Wire shelf.
A:10 Roast
Chicken
1. 0.8 - 1.0
2. 1.1 - 1.3
Wire shelf
Universal
tray
2
1
Brush chilled chicken with oil and spices
and put breast-side-up on the Wire shelf.
A:11 Duck Breast 1. 0.3 - 0.5
2. 0.6 - 0.8
Wire shelf
Universal
tray
4
3
Prepare duck breast, put on the Wire shelf
with the fat-side up. First setting is for one
duck breast, the second setting is for 2
thick duck breasts.
A:12 Roll
of Turkey
1. 0.6 - 0.8
2. 0.9 - 1.1
Wire shelf
Universal
tray
2
1
Put roll of turkey on the Wire shelf. Turn
over, as soon as the oven beeps
A:13 Steamed Fish 1. 0.2 - 0.4
2. 0.5 - 0.7
3. 0.8 - 1.0
Wire shelf 2 Put prepared fresh fish (e.g. trout,
haddock, codfish) in a suitable sized
ovenproof glassware with lid. Add liquid
until bottom of dish is covered e.g. 3-4
tbsp. lemon juice, white wine or water
and cover with lid. Put dish on Wire shelf.
If you prefer roasted appearance, brush
skin of fish with olive oil and do not cover.
A:14 Roast Fish 1. 0.5 - 0.7
2. 0.8 - 1.0
Wire shelf
Universal
tray
4
3
Put fishes head to tail on the Wire shelf.
First setting is for 2 fishes, the second
setting is for 4 fishes. The programme
is suitable for whole fishes, like trout,
pikeperch or gilthead.
A:15 Salmon
Steaks
1. 0.3 - 0.4
2. 0.7 - 0.8
Wire shelf
Universal
tray
4
3
Put salmon steaks on the Wire shelf. Turn
over, as soon as the oven beeps.
A:16 Oven
Potatoes
1. 0.4 - 0.6
2. 0.8 - 1.0
Baking tray 2 Rinse potatoes, cut potatoes into halves.
Brush with olive oil, herbs and spices.
Distribute on the baking tray evenly. The
first setting is for small potatoes (each 100
g), the second setting is for large oven
potatoes (each 200 g).
A:17 Roast
Vegetables
1. 0.4 - 0.6
2. 0.8 - 1.0
Universal
tray
4 Put vegetables, such as sliced courgette,
pieces of pepper, sliced aubergine,
mushrooms and cherry tomatoes into
Universal tray. Brush with a mixture of
olive oil, herbs and spices.
06 AUTOMATIC COOKING
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 19 2015-03-13 �� 11:33:46

English - 20
No Food item Weight/kg Accessory Shelf
level Recommendation
A:18 Vegetable
Gratin
1. 0.4 - 0.6
2. 0.8 - 1.0
Wire shelf 2 Prepare vegetable gratin using an
ovenproof round dish. Put dish on Wire
shelf in the centre of oven.
A:19 Marble Cake 1. 0.5 - 0.6
2. 0.7 - 0.8
3. 0.9 - 1.0
Wire shelf 2 Put dough into suitable sized deep round
baking pan for bundt cake/ ring cake.
This programme is suitable for batter such
as marble cake, lemon cake and hazelnut
cake.
A:20 Muffins 1. 0.5 - 0.6
2. 0.7 - 0.8
Wire shelf 2 Put muffin dough in metal muffin dish,
suitable for 12 muffins. Set dish on rack.
0.5 -0.6 kg weight range is recommended
for muffins of each 45 g, 0.7-0.8 kg
weight range is recommended for
medium sized muffins of each 65g.
A:21 White Bread 1. 0.7 - 0.8 Wire shelf 2 This programme is suitable for bread
mixtures using 500 g wheat flour. Follow
instruction on package. Put yeast dough
into rectangular baking dish. Brush top of
dough with water. Cut length with a knife.
A:22 Wholemeal
Bread
1. 0.7 - 0.8 Wire shelf 2 This programme is suitable for bread
mixtures using 500 g wheat and rye flour.
Follow instruction on package. Put leaven
(sour dough) into suitable rectangular
baking dish. Brush top of dough with
water. Cut length with a knife.
A:23 Bread Rolls/
Ciabatta
1. 0.2 - 0.4
2. 0.6 - 0.8
Baking tray 3 The first setting in suitable for dough
used for small pieces such as bread rolls
or fresh dough for croissants (4-8 pcs).
Setting 2 is suitable for dough used for
homemade ciabatta breads or baguettes
(2-6 pcs). Use baking paper.
A:24 Homemade
Pizza
1. 0.2 - 0.6
2. 0.8 - 1.2
Baking tray 2 The first setting is suitable for Pizza
Snacks (7-9 pcs). Setting 2 is suitable for
one round or tray sized Pizza. The weight
ranges are including topping such as
sauce, vegetables, ham and cheese. If
you prefer strong crust, we recommend
to preheat oven with bottom heat plus
convection mode for 5 min.
A:25 Yeast dough
Fermentation
1. 0.2 - 0.4
(pizza dough)
2. 0.4 - 0.6
(yeast
dough)
3. 0.6 - 0-8
(bread
dough)
Wire shelf 2 0.2-0.4 kg weight range setting is to
prepare yeast dough for pizza, cake, or to
pre-rise bread dough. Put into a big round
dish and cover with cling film. 0.4-0.6
kg setting is for bread dough like yeast
dough or sour dough. 0.6-0.8 kg setting
is for leaven. Knead dough manually, put
into baking dish and cover with cling film.
NV70F7584DS-EU_DG68-00191Z-03_EN.indd 20 2015-03-13 �� 11:33:46
