Samsung NE63 861 Series User manual

Electric Range
User manual
NE63*861***

2English
WARNING
To reduce the risk of tipping the range, the range must be secured
by a properly installed Anti-Tip device. AFTER THE RANGE HAS
BEEN INSTALLED, CONFIRM THAT THE ANTI-TIP DEVICE HAS BEEN
PROPERLY INSTALLED AND VERIFY THAT THE ANTI-TIP DEVICE IS
PROPERLY ENGAGED. Refer to the installation manual for instructions.
a) If the Anti-Tip device is not installed, a child or adult can tip the
range and be killed.
b) Verify that the Anti-Tip device has been properly installed and
engaged at the rear right (or rear left) of the range bottom.
c) If you move the range and then move it back into place, ensure
the Anti-Tip device is re-engaged at the right or left rear of the
range bottom.
d) Do not operate the range without the Anti-Tip device in place and
engaged.
e) Failure to do so can result in death or serious burns to children
or adults.
WARNING
Do not step, lean, or sit on the doors of the range. You can cause the
range to tip, resulting in burns or serious injuries.
Conrm that the Anti-Tip device is installed properly. Then, to verify
that the Anti-Tip device is engaged, grasp the top rear edge of the
range and carefully attempt to tilt it forward. The Anti-Tip device
should prevent the range from tilting forward more than a few inches.
If you pull the range out from the wall for any reason, make sure the
Anti-Tip device is properly engaged when you push the range back
against the wall. If it is not, there is a risk of the range tipping over
and causing injury if you or a child stand, sit, or lean on the open door.
Never completely remove the leveling legs. If you remove the leveling
legs, the range will not be secured to the Anti-Tip device properly.
Anti-tip device

English 3
FCC STATEMENT:
This equipment has been tested and found to comply within the
limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in accordance
with the instructions, may cause harmful interference to radio
communications. However, there is no guarantee that interference
will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which
can be determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of the
following measures:
•Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and receiver
• Connecting the equipment to an outlet that is on a different
circuit than the radio or TV.
• Consulting the dealer or an experienced radio/TV technician for
help.
Regulatory Notice
1. FCC Notice
CAUTION
FCC CAUTION: Any changes or modications not expressly approved
by the party responsible for compliance could void the user’s
authority to operate the equipment.
This device complies with part 15 of FCC Rules. Operation is Subject
to following two conditions:
1) This device may not cause harmful interference, and
2) This device must accept any interference received including
interference that cause undesired operation.
For products sold in the US and Canadian markets, only channels
1–11 are available. You cannot select any other channels.

4 English
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure limits set
forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
2. IC Notice
The term “IC” before the radio certication number only signies
that Industry Canada technical specications were met. Operation
is subject to the following two conditions: (1) this device may not
cause interference, and (2) this device must accept any interference,
including interference that may cause undesired operation of the
device.
This Class B digital apparatus complies with Canadian ICES-003.
For products sold in the US and Canadian markets, only channels
1–11 are available. You cannot select any other channels.
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation exposure limits
set forth for an uncontrolled environment. This equipment should be
installed and operated so there is at least 8 inches (20 cm) between
the radiator and your body. This device and its antenna(s) must not
be co-located or operated in conjunction with any other antenna or
transmitter.
General safety instructions
This unit has been tested and found to comply with the limits for a class
B digital device, pursuant to Part 18 of the FCC rules. These limits are
designed to provide reasonable protection against harmful interference
in a residential installation. This unit generates, uses and can radiate radio
frequency energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur in a
particular installation. If this unit does cause harmful interference to radio
or television reception, which can be determined by turning the unit off
and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
• Reorient or relocate the receiving antennae.
•Increase the distance between the unit and receiver.
• Connect the unit into an outlet or a circuit different from that to
which the receiver is connected.

English 5
Contents
Contents
Important safety instructions 6
Introducing your new range 21
Overview 21
What’s included 21
Before you begin 22
Energy saving tips 22
Surface cooking 22
About induction cooktop cooking 22
How to set the appliance for cooktop cooking 24
Before using the cooktop 26
Cookware for induction cooking zones 27
Using the correct size cookware 27
Pot and pan sizes 27
Induction cookware test 28
Operating noises 28
Using suitable induction cookware 28
Temperature detection 29
Suggested settings for cooking specic foods 30
Protecting the cooktop 30
Operating the oven 31
The oven control panel 31
Oven lock 31
Setting the clock 32
Setting the kitchen timer 32
Timed cooking 32
Delay start 33
Turning the oven light on and off 33
Minimum and maximum settings 33
Using the oven racks 34
Baking 35
Convection baking 36
Convection roasting 37
Broiling 37
Air fry 38
Using the special function 40
Using the keep warm feature 41
Using the smart control feature 42
Using the voice control 42
Using the options function 44
Using the Sabbath feature 46
Maintaining your appliance 47
Self-cleaning 47
Steam-cleaning 49
Care and cleaning of the oven 50
Care and cleaning of the glass cooktop 52
Removing and reinstalling the oven door 54
Removing and reinstalling the storage drawer 56
Changing the oven light 56
Troubleshooting 57
Troubleshooting 57
Information codes 62
Warranty (U.S.A) 64
Warranty (CANADA) 65
Appendix 67
Open Source Announcement 67

6English
Important safety instructions
Important safety instructionsImportant safety instructions
SAVE THESE INSTRUCTIONS
CAUTION
To reduce the risk of re, explosion, electric shock, or personal injury
when using your range, follow these basic safety precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call a Samsung service center for help.
Note
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
Important safety instructions
Read and follow all instructions before using your range to prevent
the risk of re, electric shock, personal injury, or damage when using
the range. This guide does not cover all possible conditions that may
occur. Always contact your service agent or the manufacturer about
problems that you do not understand.
WHAT YOU NEED TO KNOW ABOUT
SAFETY INSTRUCTIONS
Warnings and Important safety instructions in this manual do not
cover all possible conditions and situations that may occur. It is
your responsibility to use common sense, caution, and care when
installing, maintaining, and operating your oven.
Important safety symbols and precautions
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury
or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury
or property damage.

English 7
Important safety instructions
SAVE THESE INSTRUCTIONS
FOR YOUR SAFETY
When using electrical appliances, you should follow basic safety
precautions, including the following:
CAUTION
•Use this appliance only for its intended purpose as described in
this Owner’s Manual.
•Potentially hot surfaces include the cooktop, areas facing the
cooktop, the oven vent opening, surfaces near the opening, and
crevices around the oven door.
Be sure your appliance is properly installed and grounded by a
qualied technician.
User servicing - Do not repair or replace any part of the
appliance unless specically recommended in this manual. All
other servicing should be referred to a qualied technician.
Always disconnect the power to the appliance before servicing
by removing the fuse or switching off the circuit breaker.
•Do not enter the oven.
•Do not store items of interest to children in cabinets above
the range or on the back guard of the range. Children
climbing on the range to reach items could be seriously
injured.
•Do not leave children alone. Never leave children alone or
unattended in an area where this appliance is in use. They
should never be allowed to sit or stand on any part of the
appliance.
•Never use your appliance for warming or heating the room.
•Do not use water on grease res. Turn off the oven to avoid
spreading the ames. Smother the re or ames by closing
the door or use a dry chemical, baking soda, or foam-type
extinguisher.
•Avoid scratching or striking the glass doors, the cooktop, or
the control panel. Doing so may lead to glass breakage. Do
not cook on a product with broken glass. Shock, re, or cuts
may occur.

8English
Important safety instructions
Important safety instructionsImportant safety instructions
SAVE THESE INSTRUCTIONS
•If there is a re in the oven during self-cleaning, turn the
oven off and wait for the re to go out. Do not force the
door open. The introduction of fresh air at self-cleaning
temperatures may lead to a burst of ame from the oven.
Failure to follow these instructions may result in severe
burns.
•If the oven is heavily soiled with oil, self-clean the oven
before using the oven again. Leaving the oil in place creates
a risk of re.
•Wipe up heavy soil on the oven bottom with a paper towel
or rag before self-cleaning. Self-cleaning the oven when
there is heavy soil on the oven bottom requires longer
cleaning cycles and produces more smoke.
•Storage in or on the appliance. Do not store ammable
materials in the oven or near the surface units. Be sure all
packing materials are removed from the appliance before
operating it. Keep plastics, clothes, and paper away from
parts of the appliance that may become hot.
•Wear proper apparel. Never wear loose-tting or hanging
garments while using the appliance.
•Use only dry potholders. Placing moist or damp potholders
on hot surfaces may result in burns from steam. Do not
let the potholder touch hot heating elements. Do not use a
towel or other bulky cloth.
•Teach children not to play with the controls or any other
part of the range.
•For your safety, do not use high-pressure water cleaners or
steam jet cleaners to clean any part of the range.
•If the power cord is damaged, it must be replaced by
the manufacturer, its service agent, or similarly qualied
persons to avoid creating a hazard.
•The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless
they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.
•Do not lean on the range as you may turn the control knobs
inattentively.

English 9
Important safety instructions
SAVE THESE INSTRUCTIONS
INDUCTION COOKTOP ELEMENTS
•Be sure you know which touch control operates each
surface heating unit. Place a pan of food on the unit before
turning it on, and turn the unit off before removing the pan.
•Use proper pan sizes - This appliance is equipped with
surface units of different sizes. Select pots and pans that
have at bottoms large enough to cover the surface area of
the heating element. Using undersized cookware will expose
a portion of the heating element to direct contact and may
result in the ignition of clothing. Matching the size of the
pot or pan to the burner will also improve efciency.
•Cookware handles should be turned inward and not extend
over adjacent surface elements - To reduce the risk of
burns, ignition of ammable materials, and spillage due to
unintentional contact with the cookware, cookware handles
should be positioned so that they are turned inward, and do
not extend over adjacent surface units.
•Glazed cookware - Only certain types of glass, glass/
ceramic, ceramic, earthenware, or other glazed cookware are
suitable for range-top service without breaking due to the
sudden change in temperature.
•Never leave surface elements unattended at high heat
settings - Boilovers cause smoking and greasy spillovers
that may ignite. A pan that has boiled dry may melt.
•Metallic objects such as knives, forks, spoons, and lids
should not be placed on the Induction Cooktop surface since
they can get hot.
•When preparing aming foods under a ventilating hood,
turn the fan on.
•Use care when touching the cooktop. The glass surface of
the cooktop will retain heat after the controls have been
turned off.
•Always turn the surface units off before removing cookware.
•Keep an eye on foods being fried at high or medium high
heat settings.
•Be careful when placing spoons or other stirring utensils
on the glass cooktop surface when it is in use. They may
become hot and could cause burns.
•Do not lift the cooktop. Lifting the cooktop can lead to
damage and improper operation of the range.
•Never use the glass cooktop surface as a cutting board.
•Do not operate the cooktop without cookware.
•Appliance is not intended to be operated by means of an
external timer or separate remote-control system.

10 English
Important safety instructions
Important safety instructionsImportant safety instructions
SAVE THESE INSTRUCTIONS
ELECTRICAL SAFETY
•Proper Installation - Be sure your appliance is properly
installed and grounded by a qualied technician.
•The appliance should be serviced only by qualied service
personnel. Repairs carried out by unqualied individuals
may cause injury or a serious malfunction. If your appliance
is in need of repair, contact a Samsung authorized service
center. Failure to follow these instructions may result in
damage and void the warranty.
•Flush-mounted appliances may be operated only after they
have been installed in cabinets and workplaces that conform
to the relevant standards. This ensures that the appliances
are installed in compliance with the appropriate safety
standards.
•If your appliance malfunctions or if fractures, cracks, or
splits appear:
-switch off all cooking zones.
-unplug the range from the AC wall outlet.
-contact your local Samsung service center.
WARNING
If the surface is cracked, switch off and unplug the appliance to avoid
the possibility of electrical shock. Do not use your cooktop until the
glass surface has been replaced.
WARNING
•Ensure that the appliance is switched off before replacing the
lamp to avoid the possibility of electric shock.
•The range should not be placed on a base.
