Samsung NSE6D 87 Series User manual

Electric Range
User manual
NSE6D*87****

2 English
WARNING
To reduce the risk of tipping the range, the range must
be secured by a properly installed Anti-Tip device.
AFTER THE RANGE HAS BEEN INSTALLED, CONFIRM
THAT THE ANTI-TIP DEVICE HAS BEEN PROPERLY
INSTALLED AND VERIFY THAT THE ANTI-TIP DEVICE IS
PROPERLY ENGAGED. Refer to the installation manual for
instructions.
a)If the Anti-Tip device is not installed, a child or adult can
tip the range and be killed.
b)Verify that the Anti-Tip device has been properly
installed and engaged at the rear right (or rear left) of
the range bottom.
c) If you move the range and then move it back into place,
ensure the Anti-Tip device is re-engaged at the right or
left rear of the range bottom.
d)Do not operate the range without the Anti-Tip device in
place and engaged.
e)Failure to do so can result in death or serious burns to
children or adults.
WARNING
Do not step, lean, or sit on the doors of the range.
You can cause the range to tip, resulting in burns or
serious injuries.
Conrm that the Anti-Tip device is installed
properly.
Then, to verify that the Anti-Tip device is engaged,
grasp the top rear edge of the range and carefully
attempt to tilt it forward. The Anti-Tip device should
prevent the range from tilting forward more than a
few inches.
If you pull the range out from the wall for any
reason, make sure the Anti-Tip device is properly
engaged when you push the range back against the
wall. If it is not, there is a risk of the range tipping
over and causing injury if you or a child stand, sit,
or lean on the open door.
Never completely remove the leveling legs. If you
remove the leveling legs, the range will not be
secured to the Anti-Tip device properly.
Anti-tip device

English 3
Regulatory Notice
1.FCC Notice
CAUTION
FCC CAUTION: Any changes or modications not
expressly approved by the party responsible for
compliance could void the user’s authority to operate
the equipment.
This device complies with part 15 of FCC Rules.
Operation is Subject to following two conditions:
1) This device may not cause harmful interference,
and
1) This device must accept any interference
received including interference that cause
undesired operation.
For products sold in the US and Canadian markets, only
channels 1–11 are available. You cannot select any
other channels.
Radio Apparatus Notice
CAUTION
Any changes or modications not expressly
approved by the party responsible for compliance
could void the user’s authority to operate the
equipment.S
The remote enable equipment installed on this
product complies with Part 15 of FCC Rules and
Innovation, Science and Economic Development
Canada’s license-exempt RSS(s). Operation is
Subject to following two conditions:
1) This equipment may not cause harmful
interference, and
2) This equipment must accept any interference
received including interference that cause
undesired operation.
For products available in the US/Canadian markets,
only channels 1~11 are available. You cannot
select any other channels.

4 English
Regulatory Notice
Radio Apparatus STATEMENT:
This equipment has been tested and found to
comply within the limits for a Class B digital device,
pursuant to part 15 of the FCC Rules and Canadian
ICES-003. These limits are designed to provide
reasonable protection against harmful interference in
a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct
the interference by one or more of the following
measures:
FCC STATEMENT:
This equipment has been tested and found to comply
within the limits for a Class B digital device, pursuant
to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful
interference in a residential installation.
This equipment generates, uses, and can radiate radio
frequency energy and, if not installed and used in
accordance with the instructions, may cause harmful
interference to radio communications. However, there
is no guarantee that interference will not occur in a
particular installation. If this equipment does cause
harmful interference to radio or television reception,
which can be determined by turning the equipment
off and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment and
receiver
• Connecting the equipment to an outlet that is on a
different circuit than the radio or TV.
• Consulting the dealer or an experienced radio/TV
technician for help.

English 5
FCC RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC radiation exposure
limits set forth for an uncontrolled environment. This
equipment should be installed and operated so there
is at least 8 inches (20 cm) between the radiator and
your body. This device and its antenna(s) must not be
co-located or operated in conjunction with any other
antenna or transmitter.
2.IC Notice
The term “IC” before the radio certication number only
signies that Industry Canada technical specications
were met. Operation is subject to the following two
conditions: (1) this device may not cause interference,
and (2) this device must accept any interference,
including interference that may cause undesired
operation of the device.
This Class B digital apparatus complies with Canadian
ICES-003.
For products sold in the US and Canadian markets, only
channels 1–11 are available. You cannot select any
other channels.
• Reorienting or relocating the receiving antenna
• Increasing the separation between the equipment
and receiver
• Connecting the equipment to an outlet that is on a
different circuit than the radio or TV
• Consulting the dealer or an experienced radio/TV
technician for help.

6 English
RADIATION EXPOSURE STATEMENT:
This equipment complies with FCC and IC RSS-
102 radiation exposure limits set forth for an
uncontrolled environment. This equipment should
be installed and operated so there is at least
8 inches (20 cm) between the radiator and your
body. This device and its antenna(s) must not be
co-located or operated in conjunction with any
other antenna or transmitter.
IC RADIATION EXPOSURE STATEMENT:
This equipment complies with IC RSS-102 radiation
exposure limits set forth for an uncontrolled
environment. This equipment should be installed
and operated so there is at least 8 inches (20 cm)
between the radiator and your body. This device and
its antenna(s) must not be co-located or operated in
conjunction with any other antenna or transmitter.

English 7
Contents
Contents
Important safety instructions 6
What you need to know about safety instructions 6
California Proposition 65 Warning 6
For your safety 7
Surface Cooking Units 9
Electrical Safety 10
Child safety 11
Oven 11
Remote Operation 12
Self-cleaning ovens 12
Ventilating hood 13
Glass/Ceramic cooking surfaces 13
Critical installation warnings 14
Critical usage warning 15
Usage cautions 18
Critical cleaning warnings 19
Introducing your new range 20
Overview 20
What’s included with your range 20
Before you begin 21
Energy saving tips 21
Surface cooking 21
About surface cooking 21
How to set the appliance for surface cooking 23
Using the proper cookware 25
Choosing the proper cookware 26
Protecting the cooktop 26
Operating the oven 27
The oven control panel 27
How to use dial knob 27
Display mode 28
Clock 28
Oven cooking 29
Cooking mode 29
Camera In Oven (applicable models only) 30
Using the oven racks 31
Recipe guide 33
Temperature probe 42
Cooking options 44
Smart control 45
Voice control 46
Special features 46
More functions 47
System Settings 50
Maintaining your appliance 52
Self-cleaning 52
Steam-cleaning 54
Care and cleaning of the oven 55
Care and cleaning of the glass cooktop 57
Removing and reinstalling the oven door 58
Removing and reinstalling the storage drawer 60
Changing the oven light 60
Troubleshooting 61
Troubleshooting 61
Information codes 65
Warranty (U.S.A) 67
Warranty (CANADA) 68
Appendix 70
Open Source Announcement 70

8 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
CAUTION
To reduce the risk of re, explosion, electric shock, or personal injury
when using your range, follow these basic safety precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric shock.
Call a Samsung service center for help.
Note
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Important safety instructions
Read and follow all instructions before using your range to prevent
the risk of re, electric shock, personal injury, or damage when using
the range. This guide does not cover all possible conditions that may
occur. Always contact your service agent or the manufacturer about
problems that you do not understand.
WHAT YOU NEED TO KNOW ABOUT
SAFETY INSTRUCTIONS
Warnings and Important safety instructions in this manual do not
cover all possible conditions and situations that may occur. It is
your responsibility to use common sense, caution, and care when
installing, maintaining, and operating your oven.
Important safety symbols and precautions
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe personal injury
or death.
CAUTION
Hazards or unsafe practices that may result in minor personal injury
or property damage.

English 9
Important safety instructions
SAVE THESE INSTRUCTIONS
FOR YOUR SAFETY
When using electrical appliances, you should follow basic safety
precautions, including the following:
CAUTION
• Use this appliance only for its intended purpose as described in
this Owner’s Manual.
• Potentially hot surfaces include the cooktop, areas facing the
cooktop, the oven vent opening, surfaces near the opening, and
crevices around the oven door.
Be sure your appliance is properly installed and grounded by a
qualied technician.
User servicing - Do not repair or replace any part of the
appliance unless specically recommended in this manual. All
other servicing should be referred to a qualied technician.
Always disconnect the power to the appliance before servicing
by removing the fuse or switching off the circuit breaker.
• Do not enter the oven.
• Do not store items of interest to children in cabinets above
the range or on the back guard of the range. Children
climbing on the range to reach items could be seriously
injured.
• Do not leave children alone. Never leave children alone or
unattended in an area where this appliance is in use. They
should never be allowed to sit or stand on any part of the
appliance.
• Never use your appliance for warming or heating the room.
• Do not use water on grease res. Turn off the oven to avoid
spreading the ames. Smother the re or ames by closing
the door or use a dry chemical, baking soda, or foam-type
extinguisher.
• Avoid scratching or striking the glass doors, the cooktop, or
the control panel. Doing so may lead to glass breakage. Do
not cook on a product with broken glass. Shock, re, or cuts
may occur.

10 English
Important safety instructions
Important safety instructions
SAVE THESE INSTRUCTIONS
• Use only dry potholders. Placing moist or damp potholders
on hot surfaces may result in burns from steam. Do not let
the potholder touch hot heating elements. Do not use a towel
or other bulky cloth.
• Teach children not to play with the controls or any other part
of the range.
• For your safety, do not use high-pressure water cleaners or
steam jet cleaners to clean any part of the range.
• If the power cord is damaged, it must be replaced by the
manufacturer, its service agent, or similarly qualied persons
to avoid creating a hazard.
• The appliance is not intended for use by persons (including
children) with reduced physical, sensory or mental
capabilities, or lack of experience and knowledge, unless they
have been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
• Do not lean on the range as you may turn the control knobs
inattentively.
• If there is a re in the oven during self-cleaning, turn the
oven off and wait for the re to go out. Do not force the
door open. The introduction of fresh air at self-cleaning
temperatures may lead to a burst of ame from the oven.
Failure to follow these instructions may result in severe
burns.
• If the oven is heavily soiled with oil, self-clean the oven
before using the oven again. Leaving the oil in place creates
a risk of re.
• Wipe up heavy soil on the oven bottom with a paper towel or
rag before self-cleaning. Self-cleaning the oven when there
is heavy soil on the oven bottom requires longer cleaning
cycles and produces more smoke.
• Storage in or on the appliance. Do not store ammable
materials in the oven or near the surface units. Be sure all
packing materials are removed from the appliance before
operating it. Keep plastics, clothes, and paper away from
parts of the appliance that may become hot.
• Wear proper apparel. Never wear loose-tting or hanging
garments while using the appliance.
Important safety instructions
