Samsung NX58 Series User manual

Free-Standing Gas Range
User manual
NX58*4311S*
NX58R4311SS_AA_DG68-01151A-00_EN.indd 1 1/25/2019 11:17:34 AM

2 English
Features of your new range
Important safety instructionsFeatures of your new range
READ ALL INSTRUCTIONS BEFORE USING THIS APPLIANCE
All electrical and gas equipment with moving parts can be
dangerous. Please read the important safety instructions for
this appliance in this manual. The instructions must be followed
to minimize the risk of injury, death, or property damage.
Save this manual. Please Do Not Discard.
SAFETY SYMBOLS
What the icons and signs in this user manual mean:
WARNING
Means that death or serious personal injury is a risk.
CAUTION
Means that there is a potential risk for personal injury or
property damage.
CAUTION
To reduce the risk of re, explosion, electric shock, or personal
injury when using your gas range, follow these basic safety
precautions:
Enhanced convenience. Better cooking. Easy maintenance. Your
new gas range has been designed to bring you these benets
and more.
Bigger is better
With a capacity of 5.8 cubic feet, your new range has more
space than many other leading brands in the United States
and Canadian markets. This means greater convenience for
you when cooking for the holidays or when entertaining.
A cooktop with 5 burners
Power burners, simmer burners, as well as a center oval
burner provide exible cooktop heat for a variety of
cookware.
The center oval burner provides even heating over large
areas, so it is perfect for griddle cooking.
• A center oval burner is only provided for the
NX58F5500SS/NX58F5500SB/NX58F5500SW
• A round burner in the center position is provided for the
NX58F5300SS
NX58R4311SS_AA_DG68-01151A-00_EN.indd 2 1/25/2019 11:17:35 AM

English 3
Important safety instructions
SAVE THESE INSTRUCTIONS
WARNING
If the information in this manual is not followed exactly, a re
or explosion may result causing property damage, personal
injury or death.
• DO NOT store or use gasoline or other ammable vapors
and liquids in the vicinity of this or any other appliance.
• WHAT TO DO IF YOU SMELL GAS:
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch.
- DO NOT use any phone in your building.
- Immediately call your gas supplier from a neighbor’s
phone. Follow the gas supplier’s instructions.
- If you cannot reach your gas supplier, call the re
department.
• Installation and service must be performed by a qualied
installer, service agency, or the gas supplier.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power cord from the electrical outlet.
Make sure the range is plugged into an earth grounded
electrical outlet to prevent electric shock. An outlet
equipped with a Ground Fault Interrupter (GFI) is highly
recommended.
Call the service center for help. see page 72.
Note
These warning icons are here to prevent injury to you and
others.
Please observe them explicitly.
Do not discard this manual. Please keep it in a safe place for
future reference.
NX58R4311SS_AA_DG68-01151A-00_EN.indd 3 1/25/2019 11:17:36 AM

4 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions
Follow the installation instructions found in the Installation
Manual. Failure to follow these instructions can result in
death, serious personal injury, and/or property damage.
DO NOT step/sit/lean on the door or drawer to prevent
accidental tipping of the range.
CALIFORNIA PROPOSITION 65 WARNING
WARNING
Cancer and Reproductive Harm - www.P65Warnings.ca.gov.
ANTITIP DEVICE
WARNING
Tip-Over Hazard
• A child or adult can tip the range and be killed.
• Install anti-tip device to range and/or structure per
installation instructions.
• Engage the range to the anti-tip device installed to
the structure.
• Re-engage anti-tip device if range is moved.
• Failure to follow these instructions can result in
death or serious burns to children or adults.
To prevent accidental tipping of the range, attach an
approved anti-tip device to the oor. (See Installing the
Anti-Tip Device in the Installation Instructions.) Check for
proper installation by carefully tipping the range forward.
The anti-tip device should engage and prevent the range
from tipping over.
If the range is pulled out away from the wall for any
reason, make sure the anti-tip device is reengaged after
the range has been pushed back into place.
NX58R4311SS_AA_DG68-01151A-00_EN.indd 4 1/25/2019 11:17:37 AM

English 5
Important safety instructions
SAVE THESE INSTRUCTIONS
Never try to repair or replace this appliance on your own
unless it is specically recommended in this manual. This
appliance should be serviced only by a qualied service
technician.
Know the location of the gas shut-off valve and how to
shut it off if necessary.
Properly remove or destroy the packaging materials after
the appliance is unpacked.
Electrical/Mechanical
Unplug or disconnect power before servicing.
Do not tamper with the controls.
Grates and griddles (if equipped) are heavy. They can be
dangerous if dropped.
The inner portion of the split oven rack (if equipped) could
drop down accidentally if not assembled properly. Place
the inner rack in the proper position within the outer rack.
Always position the oven racks at the same level on each
cavity side. Uneven racks could cause food to slide to the
lower side, posing a risk of burns.
IMPORTANT SAFETY PRECAUTIONS
WARNING
Follow basic precautions when installing and using this range
to reduce the risk of re, electrical shock, injury, or death to
persons, including:
Installation and Service
This range must be properly located and installed in
accordance with the installation instructions before it is
used.
Professional installation is strongly recommended.
Due to the size and weight of the range, it is highly
recommended that two or more people move or install this
appliance.
All ranges can tip over and cause severe injuries. Install
the anti-tip device packed with this range following the
instructions found in the Installation Instructions.
NX58R4311SS_AA_DG68-01151A-00_EN.indd 5 1/25/2019 11:17:37 AM

6 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions
Do not leave children alone or unattended in an area
where a range is in use. They should never be allowed to
sit or stand on any part of a range.
Do not let little children touch the range.
The cooktop grates and griddle (if equipped) are heavy
and presents a risk of injury if dropped on a foot. Teach
children not to touch or play with grates or griddle.
Teach children not to touch or play with the controls or
any part of the range.
We recommend you utilize the control/door lockout
feature to reduce the risk of mis-use by children.
Before disposing of the range, cut off the power cord
to prevent it from being connected to a power source.
Remove the door to prevent children and animals from
getting trapped.
Danger to Children
Do not store any object of interest to children on the
cooktop or backguard of the range. Children climbing
on the range to reach items could be killed or seriously
injured.
The inner rack of the Split Rack can be dropped if it is not
assembled properly. Place the Inner rack in the proper
place on the Outer rack. Always insert the rack or split
rack assembly (if equipped) on the same level of the oven
cavity side.
Keep children away from the door when opening or
closing it as they may bump themselves on the door or
catch their ngers in the door.
Keep all packaging materials out of reach of children.
Children may play with them. Failure to dispose of plastic
bags could result in suffocation.
NX58R4311SS_AA_DG68-01151A-00_EN.indd 6 1/25/2019 11:17:37 AM

English 7
Important safety instructions
SAVE THESE INSTRUCTIONS
Never use your range for any purposes but cooking. Doing
so could result in carbon monoxide poisoning and/or
overheating of the oven.
Do not wear loose-tting or hanging garments while using
this appliance.
DO NOT STORE OR USE combustible materials, gasoline,
or other ammable vapors or liquids in the vicinity of this
appliance. See “WHAT TO DO IF YOU SMELL GAS” under the
Gas Warnings.
Do not pour water into the cooktop well while cleaning
the cooktop. This could leak down into the range gas and
electrical systems creating a risk of electrical shock or high
levels of Carbon Monoxide, due to corrosion of the gas
valves or ports.
Do not use water on a grease re. Water might cause a
grease re to explode, spreading the re and creating a
larger re and health hazard. To put out a grease re, turn
off the heat source and smother the re with tight-tting
lid or use a multipurpose dry chemical or foam-type re
extinguisher.
Fire
Do not touch oven burners, drawer burners, or interior
surfaces of the oven during or immediately after cooking.
Cooking surfaces, grates, cooktop burners and caps, as well
as oven walls may be hot even though they are dark in
color.
Interior oven surfaces can become hot enough to cause
burns. During and after use, do not touch or let clothing or
other ammable materials contact oven burners, drawer
burners, or interior surfaces of the oven until they have
had sufcient time to cool.
Do not let a pot holder touch a hot heating element. Do not
use a towel or other bulky cloth as a pot holder.
Do not use your range to heat unopened food containers
or to dry wet items or clothing.
Keep oven vent ducts unobstructed. Clean vents frequently
to avoid grease buildup. See page 47. There can be slight
popping sound during oven cooking. This sound may occur
during the normal oven burner cycling, when the oven
burner ame is extinguished.
NX58R4311SS_AA_DG68-01151A-00_EN.indd 7 1/25/2019 11:17:37 AM

8 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions
Steam and Vapors
Use care when opening the oven door. Let hot air or steam
escape before removing or placing food in a hot oven.
Use only dry pot holders. Putting moist or damp pot
holders on hot surfaces may result in burns from steam.
Surface Burner Warnings
• The burner spreader can be blocked by food or dust.
Clean the spreader if it appears blocked. If you clean
the spreader with water, assemble it only after it is
completely dry. If the spreader is wet, it might prevent
the burners from igniting.
• Do not pour water on the cooktop for cleaning. It can
get inside the range and cause the parts inside to rust.
• Only ignite the cooktop burners with the burner caps
in place. If the burner caps are not in place, you can
damage the controls or cause an unintended large or
dangerous ame.
Never leave surface units unattended at high heat settings.
Boilovers cause smoke, and greasy spillovers could ignite.
Do not use a ame to check for gas leaks. Instead, use a
brush to spread a soapy water mixture around the area
you are checking. If there is a gas leak, you will see small
bubbles in the soapy water mixture at the point of the
leak.
Do not place portable appliances, or any other object other
than cookware on the cooktop. Damage or re could occur
if the cooktop is hot.
Do not attempt to operate this appliance if it is damaged,
malfunctioning, or has missing or broken parts.
Never place plastic, paper, or other items that could melt
or burn near the oven vents or any of the surface burners.
If the self-clean mode malfunctions, turn the oven off and
disconnect the power supply. Refer to pages 65 and 68 to
contact a qualied service technician.
There can be slight popping sound during oven cooking.
NX58R4311SS_AA_DG68-01151A-00_EN.indd 8 1/25/2019 11:17:38 AM

English 9
Important safety instructions
SAVE THESE INSTRUCTIONS
GAS WARNINGS
WARNING
If the instructions in this manual are not followed exactly, a
re or explosion may result, causing death, personal injury, or
property damage.
If you smell gas:
1. Close the valve and do not use the range.
2. DO NOT light a match, candle, or cigarette.
3. DO NOT turn on any gas or electric appliances.
4. DO NOT touch any electrical switches or plug a power cord
into an outlet.
5. DO NOT use any phone in your building.
6. Clear the room, building, or area of all occupants.
7. Immediately call your gas supplier from a neighbor’s phone.
Follow the gas supplier’s instructions.
8. If you cannot reach your gas supplier, call the re
department.
• Heating of beverages can result in delayed eruptive
boiling. To prevent delayed eruptive boiling, ALWAYS
allow heated beverages to stand at least 20 seconds
after you have turned the burner off so that the
temperature in the liquid can stabilize. In the event of
scalding, follow these FIRST AID instructions:
- Immerse the scalded area in cold water for at least
10 minutes
- Cover with clean, dry dressing
- Do not apply any creams, oils or lotions
• After turning on a surface burner, check to make sure
that the burner has ignited. Adjust the level of the
ame by turning the burner knob.
• When you set a burner to simmer, do not turn the
burner knob quickly. Watch the ame to make sure it
stays on.
NX58R4311SS_AA_DG68-01151A-00_EN.indd 9 1/25/2019 11:17:38 AM

10 English
Important safety instructions
SAVE THESE INSTRUCTIONS
Important safety instructions
Never use this appliance as a space heater to heat or
warm the room. Doing so may result in carbon monoxide
poisoning and overheating of the oven.
Never block the oven vents (air openings). They provide
the air inlet and exhaust that are necessary for the oven to
operate properly with correct combustion.
Do not lean on the range as you may turn the control
knobs inattentively.
Do not stand on top of the appliance or place objects
(such as laundry, an oven cover, lighted candles, lighted
cigarettes,dishes, chemicals, metal objects, etc.) on the
appliance.
• Items, such as a cloth, may get caught in the door.
• This may result in electric shock, re, problems with
the product, or injury.
IN THE COMMONWEALTH OF MASSACHUSETTS
This product must be installed by a licensed plumber
or gas tter qualied or licensed by the State of
Massachusetts.
When using ball-type gas shut-off valves, you must use
the T-handle type.
Multiple exible gas lines must not be connected in series.
Read instructions completely and carefully.
Installation of this range must conform with local codes
or, in the absence of local codes, with the National Fuel
Gas Code, ANSI Z223.1/NFPA.54, latest edition. In Canada,
installation must conform with the current Natural Gas
Installation Code, CAN/CGA-B149.1, or the current Propane
Installation Code, CAN/CGA-B149.2, and with local codes
where applicable. This range has been design-certied by
ETL according to ANSI Z21.1, latest edition, and Canadian
Gas Association according to CAN/CGA-1.1, latest edition.
Do not install this range in a place which is exposed to a
strong draft.
Installation and service must be performed by a qualied
installer, service agency, or gas supplier.
Have the installer show you the location of the gas shut-
off valve and how to shut it off.
Always use NEW exible connectors when installing a gas
appliance. Never reuse old exible connectors. The use of
old exible connectors can cause gas leaks and personal
injury.
NX58R4311SS_AA_DG68-01151A-00_EN.indd 10 1/25/2019 11:17:38 AM
