Samsung FE-N300 Series User manual

imagine the possibilities
Thank you for purchasing this Samsung product.
To receive more complete service, please register
your product at
www.samsung.com/global/register
Electric Range
user manual
FE-N300**

2_ Features of your new range
features of your new range
Enhanced convenience. Better cooking. Easy maintenance. Your new electric range has been designed to
bring you these benefits and more.
The latest in heat-distribution technology•
Other ranges with just one fan tend to make a swirl of heat that fails to cover the whole inside of
the oven. This means uneven heat distribution and uneven cooking. Your new range has Surround
Airvection™, Samsung’s innovative convection cooking system with a third heating element and
a multi-fan system that circulates the heat evenly in all directions. You get more efficient energy
consumption and more even cooking.
Steam Quick cleaning• Thanks to Steam Quick™, Samsung’s unique technology for
light-duty cleaning jobs, keeping your oven spick-and-span is a snap — no hassle, no odor, no
chemicals. Steam Quick™ cleans the inside of your range with high-temperature steam in just 20
minutes.
Bigger is better•
With a capacity of 5.9 cubic feet, your new range is equipped with more space than any of its
competitors in the U.S. market. This means greater convenience for you when cooking for the
holidays or when entertaining.
Surface cooktop Feature•
Fast and Efficient - Induction cooking heats faster while using less energy. Induction power
quickly heats to a boil, yet simmers with energy saving efficiency.
A Cooler Cooktop - A unique feature of Induction Cooking zone is whether turned ON or OFF,
the cooktop surface remains cooler than Radiant Cooking Zone style cooktops. Virtually no
wasted heat is produced since the heat begins when you set down a pan.
Magnetic Detector - The coil sensors of the induction elements automatically detects whether a
pan is magnetic and eliminates any accidental “turn-ONs”.
Pan Size Detection - The pan size recognition sensor automatically detects and adapts the
Induction Cooking Zones to the pan sizes in use for consistent, more even cooking.
More Responsive - Induction Cooking zones are more responsive than their electric or gas
counterparts because only the pan heats. This type of cooking heats easier and responds quicker
whether you are boiling, simmering, or heating.
CAUTION - The Cooking Zones may appear to be cool while turned ON and after they have been
turned OFF. The ceramic glass surface may be HOT from residual heat transfered from the
cookware and burns may occur.
CAUTION

Important safety instructions _3
important safety instructions
Read and follow all instructions before using your oven to prevent the
risk of fire, electric shock, personal injury, or damage when using the
range. This guide does not cover all possible conditions that may occur. Always
contact your service agent or manufacturer about problems that you do not
understand.
WHAT YOU NEED TO KNOW ABOUT SAFETY
INSTRUCTIONS
Warnings and Important Safety Instructions in this manual do not cover all
possible conditions and situations that may occur. It is your responsibility to use
common sense, caution, and care when installing, maintaining, and operating
your oven.
IMPORTANT SAFETY SYMBOLS AND PRECAUTIONS
What the icons and signs in this user manual mean:
WARNING
Hazards or unsafe practices that may result in severe
personal injury or death.
CAUTION
Hazards or unsafe practices that may result in minor
personal injury or property damage.
CAUTION
To reduce the risk of fire, explosion, electric shock, or
personal injury when using your oven, follow these basic
safety precautions.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions explicitly.
Unplug the power plug from the wall socket.
Make sure the machine is grounded to prevent electric
shock.
Call the service center for help.
Note
These warning signs are here to prevent injury to you and others.
Please follow them explicitly.
After reading this section, keep it in a safe place for future reference.

4_ Important safety instructions
ANTI-TIP DEVICE
WARNING
WARNING - To reduce the risk of tipping the range, the range must
be secured by a properly installed Anti-Tip device. TO CHECK IF THE
DEVICES ARE INSTALLED PROPERLY, REMOVE (necessary
part or parts) AND VERIFY THAT THE ANTI-TIP DEVICES ARE
ENGAGED. Refer to the installation manual for instructions.
Do not step, lean, or sit on the doors of the range. These can cause
the range to tip, resulting in burns or serious injuries.
Check to see that the Anti-Tip device is installed properly. Then grasp the
top rear edge of the range and carefully attempt to tilt it forward. Verify
that the Anti-Tip device is engaged.
If you pull the range out from the wall for any reason, make sure the
device is properly engaged when you push the range back against the
wall. If it is not, there is a possible risk of the range tipping over and
causing injury if you or a child stand, sit or lean on an open door.
FOR YOUR SAFETY
When using electrical appliances, basic safety precautions should be
followed, including the following:
CAUTION CAUTION - Use this appliance only for its intended purpose as
described in this Owner’s Manual.
Potentially hot surfaces include the cooktop, areas facing the cooktop,
oven vent opening, surfaces near the opening, crevices around the oven
door.
User servicing - Do not repair or replace any part of the appliance
unless specifically recommended in the manual. All other servicing should
be referred to a qualified technician.
Always disconnect power to appliance before servicing by removing the
fuse or switching off the circuit breaker.
WARNING WARNING
ALL RANGES CAN TIP AND CAUSE INJURIES TO
PERSONS
INSTALL THE ANTI-TIP DEVICE PACKED WITH RANGE
FOLLOW ALL INSTALLATION INSTRUCTIONS

Important safety instructions _5
Do not enter inside the oven.
CAUTION - Do not store items of interest to children in cabinets above a
range or on the back guard of a range. Children climbing on the range to
reach items could be seriously injured.
Do not leave children alone. Children should not be left alone or
unattended in an area where appliance is in use. They should never be
allowed to sit or stand on any part of the appliance.
Never use your appliance for warming or heating the room.
Do not use water on grease fires. Turn off the oven to avoid spreading
the flame. Smother the fire or flame by closing the door or use dry
chemical, baking soda, or a foam-type extinguisher.
Storage in or on appliance. Flammable materials should not be
stored in an oven or near surface units. Be sure all packing materials are
removed from the appliance before operating it. Keep plastics, clothes,
and paper away from parts of the appliance that may become hot.
Wear proper apparel. Loose-fitting or hanging garments should never
be worn while using the appliance.
Use only dry potholders. Moist or damp potholders on hot surfaces
may result in burns from steam. Do not let the potholder touch hot
heating elements. Do not use a towel or other bulky cloth.
Teach children not to play with the controls or any other part of the range.
For your safety, do not use high-pressure water cleaners or steam jet
cleaners.
If the supply cord is damaged, it must be replaced by the manufacturer,
its service agent or similarly qualified persons in order to avoid a hazard.
The appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience
and knowledge, unless they have been given supervision or instruction
concerning use of the appliance by a person responsible for their safety.
Read and follow all instructions and warnings on the cleaning cream
labels.
CAUTION

6_ Important safety instructions
COOKTOP ELEMENTS
Be sure you know which touch control operates each surface heating
unit. Place a pan of food on the unit before turning it on, and turn the unit off
before removing the pan.
Use the Proper Pan Size. This appliance is equipped with one or more
surface units of different sizes. Select pots and pans having flat bottoms large
enough to cover the surface unit heating element. The use of undersized pots
or pans will leave a portion of the heating element exposed, increasing the
danger of direct contact and the ignition of clothing. Matching the size of pots
and pans to the sizes of the elements will also improve efficiency.
Use the Proper Type of Pan. This appliance has two kinds of heating
elements, radiant and induction. While you can use most types of
conventional cookware on the radiant elements, you can only use steel, cast
iron, and some kinds of stainless steel cookware on the induction elements.
Utensil Handles Should Be Turned inward and Not Extend Over
Adjacent Surface Elements. To reduce the risk of burns, ignition of
flammable materials, and spillage due to unintentional contact with the
utensil, the handle of the utensil should be positioned so that it is turned
inward, and does not extend over adjacent surface units.
Glazed cooking utensils. Only certain types of glass, glass/ceramic,
ceramic, earthenware, or other glazed utensils are suitable for range-top
service without breaking due to the sudden change in temperature.
Never Leave Surface Elements Set to High Heat Unattended -
Boilovers cause smoke. Greasy spillovers may ignite. A pan that has boiled
dry may melt.
Metallic objects such as knives, forks, spoons, and lids should not be placed
on the Induction Cooktop surface since they can get hot.
When preparing flaming foods under a ventilating hood, turn the fan on.
Use care when touching the cooktop. The glass surface of the
cooktopwill retain heat after the heating elements have been turned off.
Always turn the surface units off before removing cookware.
Do not operate the cooktop when there is no cookware. If the cooktop
operates without a cookware, the touch glass will become hot.
Keep an eye on foods being fried at high or medium high heat settings.
Be careful when placing spoons or other stirring utensils on the glass cooktop
surface when it is in use. They may become hot and could cause burns.

Important safety instructions _7
Do not lift the cooktop. Lifting the cooktop can lead to damage and
improper operation of the range.
Never use the glass cooktop surface as a cutting board.
Do not operate the cooktop when there is no cookware.
ELECTRICAL SAFETY
Proper Installation - Be sure your appliance is properly installed and
grounded by a qualified technician.
The appliance should be serviced only by qualified service personnel.
Repairs carried out by unqualified individuals may cause injury or serious
malfunction. If your appliance is in need of repair, contact a Samsung
authorized service center. Failure to follow these instructions may result in
damage and void the warranty.
Flush - mounted appliances may be operated only after they have
been installed in cabinets and workplaces that conform to the relevant
standards. This ensures sufficient protection against contact for electrical
units as required by the essential safety standards.
If your appliance malfunctions or if fractures, cracks or splits appear:
- switch off all cooking zones;
- disconnect the surface Cooktop from the electrical supply, and
contact your local service center.
The oven must be switched off before removing the guard and that, after
cleaning, the guard must be replaced in accordance with the instructions
WARNING
WARNING - If the surface is cracked, switch off the appliance to avoid
the possibility of electrical shock. Do not use your surface Cooktop until
the glass surface has been replaced.
WARNING
WARNING - Ensure that the appliance is switched off before replacing
the lamp to avoid the possibility of electric shock.
The range should not be placed on a base.

8_ Important safety instructions
CHILD SAFETY
WARNING
WARNING - This appliance is not intended for use by young children or
infirm persons without the adequate supervision of a responsible adult.
Young children should be supervised to ensure that they do not play with
the appliance.
The cooking zones will become hot when you cook. Always keep small
children away from the appliance.
During cleaning, the surfaces may get hotter than usual and children
should be kept away.
WARNING
WARNING - Accessible parts may become hot during use. To avoid
burns, young children should be kept away.
OVEN
DO NOT TOUCH HEATING ELEMENTS OR INTERIOR SURFACES
OF THE OVEN. Heating elements may be hot even though they are dark
in color. Interior surfaces of an oven become hot enough to cause burns.
During and after use, do not touch or let clothing or other flammable
materials contact heating elements or interior surfaces of oven until
they have had sufficient time to cool. Other surfaces of the appliance
may become hot enough to cause burns. Among these surfaces are
oven vent openings and surfaces near these openings, oven doors, and
windows of oven doors.
Do not heat unopened food containers. Build-up of pressure may
cause the container to burst and result in injury.
Do not use the oven to dry newspapers. If overheated, they can
catch on fire.
Do not use the oven for a storage area. Items stored in an oven can
ignite.
Do not use harsh abrasive cleaners or sharp metal scrapers to clean the
oven door glass since they can scratch the surface, which may result in
shattering of the glass

Important safety instructions _9
Use care when opening door. Let hot air or steam escape before you
remove or replace food in the oven.
Protective liners. Do not use aluminum foil to line the oven bottoms,
except as suggested in the manual. Improper installation of these liners
may result in a risk of electric shock or fire.
Keep oven vent ducts unobstructed. The oven vent is located above
the right rear surface unit. This area can become hot during oven use.
Never block this vent or place plastic or heat-sensitive items on it.
Placement of oven racks. Always place oven racks in the desired
location while the oven is cool. If the rack must be moved while the oven
is hot, do not let the potholder come in contact with the hot heating
element in the oven.
During use the appliance becomes hot. Care should be taken to
avoid touching heating elements inside the oven.
Do not allow aluminum foil or a meat probe to contact heating elements.
WARMING DRAWER
DO NOT TOUCH THE HEATING ELEMENT OR THE INTERIOR
SURFACE OF THE DRAWER. These surfaces may be hot enough to
burn.
REMEMBER: The inside surface of the drawer may be hot when the
drawer is opened.
The purpose of the warming drawer is to hold hot cooked foods at
serving temperature. Always start with hot food. Cold food cannot be
heated or cooked in the warming drawer.
Use care when opening the drawer. Open the drawer a crack and
let hot air or steam escape before removing or replacing food. Hot air or
steam which escapes can cause burns to hands, face and/or eyes.
Do not use the drawer to dry newspapers. If overheated, they can
catch on fire.
Do not use aluminum foil to line the drawer. Foil is an excellent heat
insulator and will trap heat beneath it. This will upset the performance of
the drawer and it could damage the interior finish.
Do not leave paper products, plastics, canned food or combustible
materials in the drawer.
Never leave jars or cans of fat drippings in or near your drawer.
Do not warm food in the drawer for more than three hours.

10_ Important safety instructions
SELF-CLEANING OVENS
Do not clean the door gasket. The door gasket is essential for a good
seal. Care should be taken not to rub, damage, or move the gasket.
Never keep pet birds in the kitchen. The health of birds is extremely
sensitive to the fumes released during an oven self-clean cycle. Fumes
may be harmful or fatal to birds. Move birds to a well-ventilated room.
Clean only parts listed in this manual in the self-clean cycle. Before
self-cleaning the oven, remove the broil pan, rack, utensils, and food.
No commercial oven cleaner or oven liner protective coating of any kind
should be used in or on the outside of the oven. Use only a ceramic
cooktop cleaner or the cleaner supplied with this appliance on the glass
cooktop.
Nickel oven shelves should be removed from the oven before beginning
the self-cleaning cycle, or they may discolor.
If the self-clean mode malfunctions, turn the oven off and disconnect the
power supply. Have it serviced by a qualified technician.
Excess spillage and all utensils should be removed before performing self
cleaning.
VENTILATING HOOD
Clean ventilating hoods frequently. Grease should not be allowed to
accumulate on the hood or filter.
When flaming foods under the hood, turn the fan on.
