Refrigerator
user manual
imagine the possibilities
Thank you for purchasing a Samsung product.
Free Standing Appliance
This manual is made with 100% recycled paper.
DA99-03404D-11.indb 01DA99-03404D-11.indb 01 2015. 5. 7.  8:102015. 5. 7.  8:10
02_ safety information
SAFETY INFORMATION
• Before operating the appliance, please read this
manual thoroughly and retain it at a safe place near the
appliance for your future reference.
• Use this appliance only for its intended purpose as
described in this instruction manual. This appliance is
not intended for use by persons (including children)
with reduced physical, sensory or mental capabilities,
or lack of experience and knowledge, unless they have
been given supervision or instruction concerning use of
the appliance by a person responsible for their safety.
• This appliance can be used by children aged from 8
years and above and persons with reduced physical,
sensory or mental capabilities or lack of experience
and knowledge if they have been given supervision or
instruction concerning use of the appliance in a safe
way and understand the hazards involved.
Children shall not play with the appliance.
Cleaning and user maintenance shall not be made by
children without supervision.
• Warnings and Important Safety Instructions in this
manual do not cover all possible conditions and
situations that may occur. It is your responsibility to
use common sense, caution, and care when installing,
maintaining, and operating your appliance.
• Because these following operating instructions cover
various models, the characteristics of your refrigerator
may differ slightly from those described in this manual
and not all warning signs may be applicable. If you
have any questions or concerns, contact your nearest
service center or find help and information online at
www.samsung.com.
Important safety symbols and
precautions:
WARNING
Hazards or unsafe practices that may
result in severe personal injury or
death.
CAUTION
Hazards or unsafe practices that may
result in minor personal injury or
property damage.
Do NOT attempt.
Do NOT disassemble.
Do NOT touch.
Follow directions carefully.
Unplug the power plug from the wall
socket.
Make sure the machine is grounded to
prevent electric shock.
Call the contact center for help.
Note.
These warning signs are here to prevent injury to
you and others.
Please follow them carefully.
After reading this section, keep it in a safe place
for future reference.
CE Notice
This product has been determined to be in
compliance with the Low Voltage Directive(2006/95/
EC), the Electromagnetic Compatibility Directive
(2004/108/EC), RoHS Directive (2011/65/EU),
Commission Delegated Regulation (EU) No
1060/2010 and the Eco-Design Directive(2009/125/
EC) implemented by Regulation (EC) No 643/2009 of
the European Union. (For products sold in European
Countries only)
SEVERE WARNING SIGNS FOR
TRANSPORTATION AND SITE
• When transporting and installing the
appliance,care should be taken to ensure
that no parts of the refrigerating circuit are
damaged.
• R-600a or R-134a is used as a refrigerant. Check
the compressor label on the rear of the appliance
or the rating label inside the refrigerator to see
which refrigerant is used for your refrigerator.
• When this product contains flammable gas
(Refrigerant R-600a),
- Refrigerant leaking from the pipe work could
ignite or cause an eye injury. If a leak is detected,
avoid any naked flames or potential sources of
ignition and air the room in which the appliance is
standing for several minutes.
- In order to avoid the creation of a flammable
gas-air mixture if a leak in the refrigerating
circuit occurs, the size of the room in which the
appliance may be sited depends on the amount
of refrigerant used.
WARNING
Safety information
DA99-03404D-11.indb 02DA99-03404D-11.indb 02 2015. 5. 7.  8:102015. 5. 7.  8:10
safety information _03
- Never start up an appliance showing any signs
of damage. If in doubt, consult your dealer. The
room where the refrigerator will be sited must be
1m³ in size for every 8g of R-600a refrigerant
inside the appliance. The amount of refrigerant
in your particular appliance is shown on the
identification plate inside the appliance.
- If the appliance contains isobutane refrigerant
(R-600a), a natural gas with high environmental
compatibility that is, however, also combustible.
When transporting and installing the appliance,
care should be taken to ensure that no parts of
the refrigerating circuit are damaged.
SEVERE WARNING SIGNS
FOR INSTALLATION
• Do not install this appliance in a humid, oily
or dusty location, in a location exposed to
direct sunlight and water (rain drops).
- Deteriorated insulation of electrical parts may
cause an electric shock or fire.
• Do not place this refrigerator in direct sunlight or
expose to the heat from stoves, room heaters or
other appliances.
• Do not plug several appliances into the same
multiple power board.
The refrigerator should always be plugged into
its own individual electrical outlet which has a
voltage rating that matched the rating plate.
- This provides the best performance and also
prevents overloading house wiring circuits, which
could cause a fire hazard from overheated wires.
If the wall socket is loose, do not insert the power
plug.
- There is a risk of electric shock or fire.
• Do not use a cord that shows cracks or abrasion
damage along its length or at either end.
• Do not bend the power cord excessively or place
heavy articles on it.
• Do not use aerosols near the refrigerator.
- Aerosols used near the refrigerator may cause an
explosion or fire.
• Do not install this appliance in a location where
gas may leak.
- This may result in an electric shock or fire.
• The installation or any service of this
appliance is recommended by a qualified
technician or service company.
- Failing to do so may result in an electric shock,
fire, explosion, problems with the product, or
injury.
• This refrigerator must be properly installed and
located in accordance with the manual before it
is used.
WARNING
• Connect the power plug in proper position with
the cord hanging down.
- If you connect the power plug upside down, wire
can get cut off and a cause fire or an electric
shock.
• Make sure that the power plug is not squashed
or damaged by the back of the refrigerator.
• When moving the refrigerator, be careful not to
roll over or damage the power cord.
- This constitutes a fire hazard.
• The appliance must be positioned so that the
plug is accessible after installation.
• The refrigerator must be grounded.
- You must ground the refrigerator to
prevent any power leakages or electric
shocks caused by current leakage from
the refrigerator.
• Never use gas pipes, telephone lines or other
potential lightening rods as ground.
- Improper use of the ground plug can result in an
electric shock.
• If the power cord is damaged, have it
replaced immediately by the manufacturer
or its service agent.
• The fuse on the refrigerator must be changed by
a qualified technician or service company.
- Failing to do so may result in an electric shock or
personal injury.
CAUTION SIGNS FOR
INSTALLATION
• Keep ventilation opening in the appliance
enclosure or mounting structure clear of
obstruction.
• Allow the appliance to stand for 2 hours after
installation.
SEVERE WARNING SIGNS
FOR USING
• Do not insert the power plug with wet
hands.
• Do not store articles on the top of the appliance.
- When you open or close the door, the articles
may fall and cause a personal injury and/or
material damage.
• Do not put items filled with water on the
refrigerator.
- If spilled, there is a risk of fire or electric shock.
• Do not let children hang on the door.
CAUTION
WARNING
DA99-03404D-11.indb 03DA99-03404D-11.indb 03 2015. 5. 7.  8:102015. 5. 7.  8:10
04_ safety information
- Failure to do so may cause serious personal
injury.
• Do not leave the doors of the refrigerator open
while the refrigerator is unattended and do not let
children enter inside the refrigerator.
• Do not allow babies or children go inside the
drawer.
- It can cause death from suffocation by
entrapment or personal injury.
• Do not sit on the Freezer door.
- The door may be broken and cause a personal
injury.
• To prevent children entrapment, you must reinstall
the divider using provided screws after cleaning
or other actions if you removed the divider from
the drawer.
• Never put fingers or other objects into the
dispenser hole.
- Failure to do so may cause personal injury or
material damage.
• Do not store volatile or flammable substances
such as benzene, thinner, alcohol, ether or LP
gas in the refrigerator.
- The storage of any of such products may cause
an explosion.
• Do not store low temperature-sensitive
pharmaceutical products, scientific materials or
other low temperature-sensitive products in the
refrigerator.
- Products that require strict temperature controls
must not be stored in the refrigerator.
• Do not place or use electrical appliance inside
the refrigerator, unless they are of a type
recommended by the manufacturer.
• Do not use a hair dryer to dry the inside of the
refrigerator. Do not place a lighted candle in the
refrigerator for removing bad odors.
- This may result in an electric shock or fire.
• Do not touch the inside walls of the freezer or
products stored in the freezer with wet hands.
- This may cause frostbite.
• Do not use me chanical devices or any other
means to accelerate the defrosting process, other
than those recommended by the manufacturer.
• Do not damage the refrigerant circuit.
• This product is intended only for the
storage of food in a domestic environment.
• Bottles should be stored tightly together so that
they do not fall out.
• In the event of a gas leak (such as propane
gas, LP gas, etc.), ventilate immediately without
touching the power plug. Do not touch the
appliance or power cord.
- Do not use a ventilating fan.
- A spark may result in an explosion or fire.
• Use only the LED Lamps provided by
manufacturer or service agent.
• Children should be supervised to ensure that they
do not play with and/or climb into the appliance.
- Keep fingers out of “pinch point” areas;
clearances between the doors and cabinet are
necessarily small. Be careful when you open the
doors when children are in the area.
• Do not disassemble or repair the
refrigerator by yourself.
- You run a risk of causing a fire, malfunction and/
or personal injury. In case of malfunction, please
contact your service agent.
• If the appliance generates a strange noise,
a burning or smell or smoke, unplug the
power plug immediately and contact your
nearest service center.
- Failing to do so may result in an electric or fire
hazards.
• If you experience difficulty when changing the
light, contact service agent.
• If the products is equipped with the LED Lamp,
do not disassemble the Lamp Cover and LED
Lamp by yourself.
- Please contact your service agent.
• If any dust or water is in the refrigerator, pull
out power plug and contact your Samsung
Electronics service center.
- There is a risk of fire.
CAUTION SIGNS FOR USING
• To get best performance from the product,
- Do not place foods too closely in front of
the vents at the rear of the appliance as
it can obstruct free air circulation in the
refrigerator compartment.
- Wrap the food up properly or place it in airtight
containers before putting it into the refrigerator.
- Do not put any newly introduced food for freezing
near to already existing food.
• Do not place carbonated or fizzy drinks in the
freezer compartment. Do not put bottles or glass
containers in the freezer.
- When the contents freeze, the glass may break
and cause personal injury and property damage.
• Do not change or modify the functionality of the
refrigerator.
- Changes or modifications may result in a personal
injury and/or property damage. Any changes or
modifications performed by a 3rd party on this
completed appliance are neither covered under
Samsung warranty service, nor is Samsung
CAUTION
DA99-03404D-11.indb 04DA99-03404D-11.indb 04 2015. 5. 7.  8:102015. 5. 7.  8:10
safety information _05
responsible for safety issues and damages that
result from 3rd party modifications.
• Do not block air holes.
- If the air holes are blocked, especially with a
plastic bag, the refrigerator can be over cooled. If
this cooling period lasts too long, the water filter
may break and cause water leakage.
- Do not put any newly introduced food for freezing
near to already existing food.
• Please observe maximum storage times and
expiry dates of frozen goods.
• Fill the water tank, ice tray, water cubes only with
potable water.
• Use only the ice-maker provided with the
refrigerator.
• The water supply to this refrigerator must only be
installed/connected by a suitably qualified person
and connected to a potable water supply only.
• In order to operate the ice-maker properly, water
pressure of 138~862kpa(1.4~8.8kgf/cm3) is
required.
• Do not spray volatile material such as insecticide
onto the surface of the appliance.
- As well as being harmful to humans, it may also
result in an electric shock, fire or problems with
the product.
CAUTION SIGNS FOR CLEANING
AND MAINTENANCE
• Do not directly spray water inside or
outside the refrigerator.
- There is a risk of fire or electric shock.
• Do not use or place any substances sensitive
to temperature such as inflammable sprays,
inflammable objects, dry ice, medicine, or
chemicals near the refrigerator. Do not keep
volatile or inflammable objects or substances
(benzene, thinner, propane gas, etc.) in the
refrigerator.
- This refrigerator is for storing food only.
- This may result in a fire or an explosion.
• Do not spray cleaning products directly on the
display.
- Printed letters on the display may come off.
• Remove any foreign matter or dust from the
power plug pins. But do not use a wet or damp
cloth when cleaning the plug, remove any foreign
material or dust from the power plug pins.
- Otherwise there is a risk of fire or electric shock.
• Never put fingers or other objects into the
dispenser hole and ice chute.
- It may cause a personal injury or material
damage.
CAUTION
• Unplug the refrigerator before cleaning and
performing maintenance.
SEVERE WARNING SIGNS
FOR DISPOSAL
• Ensure that none of the pipes on the back
of the appliance are damaged prior to
disposal.
• R-600a or R-134a is used as a refrigerant. Check
the compressor label on the rear of the appliance
or the rating label inside the refrigerator to see
which refrigerant is used for your refrigerator.
When this product contains flammable gas
(Refrigerant R-600a), contact your local authority
in regard to safe disposal of this product.
Cyclopentane is used as an insulation blowing
gas. The gases in insulation material require
special disposal procedure. Please contact your
local authorities in regard to the environmentally
safe disposal of this product. Ensure that none
of the pipes on the back of the appliances are
damaged prior to disposal. The pipes shall be
broken in the open space.
• When disposing of this product or other
refrigerators, remove the door/door seals, door
latch so that small children or animals cannot
become trapped inside. Leave the shelves in
place so that children may not easily climb inside.
Children should be supervised to ensure that they
do not play with the old appliance.
• Please dispose of the packaging material for this
product in an environmentally friendly manner.
ADDITIONAL TIPS FOR PROPER USAGE
• In the event of a power failure, call the local office
of your Electricity Company and ask how long it
is going to last.
- Most power failures that are corrected within
an hour or two will not affect your refrigerator
temperatures. However, you should minimize the
number of door openin gs while the power is off.
- Should the power failure last more than 24 hours,
remove all frozen food.
• If keys are provided with the refrigerator, the keys
should be kept out of the reach of children and
not be in the vicinity of the appliance.
• The appliance might not operate consistently
(possibility of temperature becoming too warm
in the refrigerator) when sited for an extended
period of time below the cold end of the range of
temperature for which the refrigerating appliance
is designed.
• Do not store food which spoils easily at low
temperature, such as bananas, melons.
WARNING
DA99-03404D-11.indb 05DA99-03404D-11.indb 05 2015. 5. 7.  8:102015. 5. 7.  8:10
06_ safety information
Contents
SETTING UP YOUR REFRIGERATOR ………………………………………………………………………… 07
OPERATING YOUR SAMSUNG REFRIGERATOR …………………………………………………………… 13
TROUBLESHOOTING …………………………………………………………………………………………… 21
• Your appliance is frost free, which means there is
no need to manually defrost your appliance, as
this will be carried out automatically.
• Temperature rise during defrosting can comply
with ISO requirements. But if you want to prevent
an undue rise in the temperature of the frozen
food while defrosting the appliance, please wrap
the frozen food up in several layers of newspaper.
• Any increase in temperature of frozen food during
defrosting can shorten its storage life.
Saving Energy Tips
- Install the appliance in a cool, dry room with
adequate ventilation.
Ensure that it is not exposed to direct sunlight
and never put it near a direct source of heat
(radiator, for example).
- Never block any vents or grilles on the appliance.
- Allow warm food to cool down before placing it in
the appliance.
- Put frozen food in the refrigerator to thaw. You
can then use the low temperatures of the frozen
products to cool food in the refrigerator.
- Do not keep the door of the appliance open for
too long when putting food in or taking food out.
The shorter time for which the door is open, the
less ice will form in the freezer.
- Clean the rear of the refrigerator regularly. Dust
increases energy consumption.
- Do not set temperature colder than necessary.
- Ensure sufficient air exhaust at the refrigerator
base and at the back wall of the refrigerator. Do
not cover air vent openings.
- Allow clearance to the right, left, back and top
when installing.
This will help reduce power consumption and
keep your energy bills lower.
- For the most efficient use of energy, please keep the
all inner fittings such as baskets, drawers, shelves on
the position supplied by manufacturer.
This appliance is intended to be used
in household and similar applications
such as
- staff kitchen areas in shops, offices and other working
environments;
- farm houses and by clients in hotels, motels and other
residential type environments;
- bed and breakfast type environments;
- catering and similar non-retail applications.
DA99-03404D-11.indb 06DA99-03404D-11.indb 06 2015. 5. 7.  8:102015. 5. 7.  8:10
setting up _07
01 SETTING UP
GETTING READY TO INSTALL
THE REFRIGERATOR
Congratulations on your purchase of the Samsung
Refrigerator. We hope you enjoy the state-of-art
features and efficiencies that this new appliance
offers.
Selecting the best location for the
Refrigerator
• A location with easy access to the water supply.
• A location without direct exposure to sunlight.
• A location with level (or nearly level) flooring.
• A location with enough space for the Refrigerator
doors to open easily.
• Allow sufficient space to the right, left, back and
top for air circulation.
If the Refrigerator does not have enough space,
the internal cooling system may not work
properly.
• Please ensure that appliance can be moved freely
in the event of maintenance & service.
• Do not install the Refrigerator where the
temperature will go below 50ºF (10ºC).
A
A
B
B
C
C
D
D
E
E
Depth “A” 858mm
Width “B” 908mm
Height “C” 1740mm
Overall Height “D” 1774mm
Depth “E” 920mm
1578mm
1578mm
335mm
335mm
125°
125°
125°
125°
50mm
50mm
908mm
908mm
748mm
748mm
1233mm
1233mm
108mm
108mm
46mm
46mm
1346mm
1346mm
Each measurement based on the design
dimension, so it may differ depending on
the measuring method.
When moving your refrigerator
To prevent floor damage be sure the front leveling
legs are in the up position(above the floor).
Refer to ‘ADJUSTING THE DOORS’ in the manual
(at page 10)
FLOORING
For proper installation, this refrigerator must be
placed on a level surface of hard material that is the
same height as the rest of the flooring. This surface
should be strong enough to support a fully loaded
refrigerator. To protect the finish of the flooring, cut
a large section of the cardboard carton and place
under the refrigerator where you are working. When
moving, be sure to pull the unit straight out and push
back in straight.
Setting up your refrigerator
DA99-03404D-11.indb 07DA99-03404D-11.indb 07 2015. 5. 7.  8:102015. 5. 7.  8:10
08_ setting up
2. Disconnect two connectors (3) at each side of
the top cap and the one connector (4) on left
side door. Remove the tube (5) with pressing the
dark gray color part (6) of the water line coupler.
5
6
4
3
3. Remove the 3 hex head bolts ( 7) attached to
the upper left and right door hinges with a socket
wrench (10mm). Remove the ground screw ( 8)
attached to the upper left and right door hinges
with a philips screwdriver(+). Remove the upper
left and right door hinges ( 9).
Socket wrench
Socket wrench
7
9
8
4. Lift the door straight up to remove.
5. Remove the screw (10) attached to the
lower left and right door hinges with a philips
screwdriver(+). Remove the 2 hex head bolts (11)
attached to the lower left and right door hinges
with an allen wrench (3/16”). Remove the lower
left and right door hinges ( 12 ).
Allen wrench
Allen wrench
12
10
11
REMOVING THE
REFRIGERATOR DOORS
If the Refrigerator is too large to pass through your
doorway easily, you can remove the refrigerator
doors.
Disconnect power to the refrigerator before
removing the door or drawer.
• Be careful not to drop, damage or scratch
the door/drawer while removing them.
• Be careful not to get injured while removing the
door/drawer.
• Reattach the door/drawer properly to avoid:
- Moisture from air leakage.
- Uneven door alignment.
- Wasting energy due to improper door seal.
Tools you will need (Not provided)
Philips
screwdriver (+)
Flat-blade
screwdriver (-)
Socket wrench
(10mm)
Pliers Allen wrench
(3/16”) (5mm)
Disassemble the Refrigerator doors
1. With the door opened, remove the Hinge Cover
cap (1) with a Flat head screwdriver, and close
the door. Remove the 3 screws holding down the
Hinge Cover and remove the Hinge Cover (2) .
1
2
WARNING
DA99-03404D-11.indb 08DA99-03404D-11.indb 08 2015. 5. 7.  8:102015. 5. 7.  8:10
setting up _09
01 SETTING UP
When reassembling it, be sure to connect the
wire harness.
If it is not connected, the Flex Room does not
work.
4. Remove 2 hex head bolts from sides with a
socket wrench (10mm)
5. Lift up the Flex door from the rails.
Putting too much food into the freezer
drawers can prevent the freezer from closing
completely and can cause frost build-up.
ASSEMBLE THE FLEX DOOR
To reattach the flex door,assemble parts in reverse
order.
Be sure to connect the Flex Door Wire
Connector.
If it is not connected, the Flex Room does not
work.
CAUTION
CAUTION
CAUTION
REATTACHING THE
REFRIGERATOR DOORS
To reattach the fridge doors, assemble parts in
reverse order.
1. The Water Line must be fully inserted to the
center of transparent coupler (Type A) or the
Guide Lines (Type B) to prevent water leakage
from the dispenser.
Center of Transparent coupler
Center of Transparent coupler
The Guide Lines
The Guide Lines
Dispenser
Dispenser
Type A
Type A
Type B
Type B
DISASSEMBLE THE FLEX DOOR
1. Take out the Flex Zone (1) by lifting it up.
1
2. Take off the cover (2) w/harness with a flat-
blade screwdriver (-).
2
3. Press the locking tab and separate the Wire
Connector.
DA99-03404D-11.indb 09DA99-03404D-11.indb 09 2015. 5. 7.  8:102015. 5. 7.  8:10
10_ setting up
ASSEMBLE THE FREEZER
DRAWER
To reattach the freezer drawer, assemble parts in
reverse order.
ADJUSTING THE DOORS
Now that the doors are back on the Refrigerator, you
want to make sure the Refrigerator is level so that
you can make final adjustments. If the Refrigerator
is not level, it will not be possible to get the doors
perfectly even.
Insert a flat-blade screwdriver (-) into a notch on the
left control lever, and turn it count clockwise to level
the refrigerator. (You turn the lever clockwise to lower
the refrigerator and counterclockwise to raise it.)
flat-blade
flat-blade
screwdriver(-)
screwdriver(-)
Control
Control
Lever
Lever
Both control levers must be touching the floor
to avoid possible personal injury or property
damage because of tipping.
If the right side is lower, perform the same
procedure, but with the right control lever.
CAUTION
DISASSEMBLE THE FREEZER
DRAWER
1. Push the upper drawer in completely.
2. Remove the tilting pocket (1) by pulling on both
brackets (2) upward at the same time.
1
2
3. Take out the lower basket (3) by lifting the
basket up from rail system.
3
4. Remove four 10mm hex-head bolts from both
sides.
5. Lift the freezer door up from the rails.
DA99-03404D-11.indb 10DA99-03404D-11.indb 10 2015. 5. 7.  8:102015. 5. 7.  8:10
