Samsung RF23J9011SR User manual

RF23J9011SR
23 cu. ft. Counter Depth 4-Door Refrigerator with Cool Select Plus
Features
• 4-Door Counter-Depth Design
• Large Capacity – 23 cu. ft.
• Cool Select Plus
• Triple Cooling System
• Ice Master Ice Maker in the Refrigerator
• ENERGY STAR®Compliant
• High-Eciency LED Lighting
• Stainless-Look Display
• Stainless Steel Accents on Interior
Shelving and Door Bins
• Fingerprint Resistant Coating
• Tempered Glass Spill-Proof Shelves
• Flip-Up Shelf
• Gallon Door Bins
• Two Clear Crispers
Convenience
• Door Alarm
• Water Filter Indicator
ENERGY STAR®rated:
679 kWh/yr
Signature Features
Triple Cooling System
Clean, Modern Design
CLEAN, MODERN DESIGN
• Artful and symmetric design expresses individuality.
• Beautifully appointed stainless steel body and interior trim.
COUNTER DEPTH
• More capacity, smaller oor space.
• Our 23 cu. ft.1 capacity French Door has enough room to t
up to 23 bags of groceries.2
• Stylish counter-depth design allows for more workable space
in the kitchen.
1Actual size is 22.5 cu. ft.
2Grocery comparison based on each cubic foot of usable space equaling one paper bag.
COOL SELECT PLUS
• Versatile, bottom-right door can be a fridge or freezer,
maximizing fresh food storage space.
• The most fresh food storage available in its class at 18.05 cu. ft.,
when the Cool Select Plus is used as a refrigerator.3
• Four customizable temperature settings: Freezer at -90F – 10F,
Soft Freeze at 230F, Chill at 300F and Cool at 410F.
3Among consumer-grade freestanding refrigerators.
Ranked “Highest in customer
satisfaction with French Door
refrigerators, in a tie.”*
– J.D. Power
Available Colors
Stainless Steel
(shown) Black Stainless

*Samsung received the highest numerical score for French door refrigerators in a tie in the proprietary J.D. Power
2014 Kitchen Appliance StudySM. Study based on 15,380 total responses measuring 10 French door refrigerators
brands and measures opinions of consumers about their new appliance purchased in the past 24 months.
Proprietary study results are based on experiences and perceptions of consumers surveyed in January-March 2014.
Your experiences may vary. Visit jdpower.com.
Actual color may vary. Design, specications, and color availability are subject to change without notice.
Non-metric weights and measurements are approximate.
©2016 Samsung Electronics America, Inc. 85 Challenger Road, Ridgeeld Park, NJ 07660. Tel: 800-SAMSUNG. samsung.com.
Samsung is a registered trademark of Samsung Electronics Co. Ltd.
Total Capacity: 22.5 cu. ft.
Refrigerator: 13.6 cu. ft.
• Premium External Filtered Water and Ice Dispenser
(Crushed or Cubed Ice)
• Ice Master Ice Maker
• High-Eciency LED Lighting
• 2 Clear Crispers
• 5 Tempered Glass Spill-Proof Shelves
– 1 Slide-in & fold-up
– 1 Flip-Up
– 3 Fixed
Cool Select Plus: 4.45 cu. ft.
• 1 EZ Slide-Out Shelf
• 2 Drawers
• 4 Temperature Zones:
– 41°F
– 30°F
– 23°F
– -9°F – 1°F
• High-Eciency LED Lighting
Freezer: 4.45 cu. ft.
• 1 EZ Slide-Out Shelf
• 2 Freezer Drawers
• High-Eciency LED Lighting
Accessories
Water Filter: HAF-CIN
Warranty
One (1) Year Parts and Labor on Refrigerator
Five (5) Years Parts and Labor on
Sealed Refrigeration System Only*
Ten (10) Years Parts and Five (5) Years
Labor on Digital Inverter Compressor
*Compressor, evaporator, condenser, drier, connecting tubing
Product Dimensions & Weight
Dimensions (WxHxD with hinges, handles and doors):
353/4" x 717/8" x 287/8"
Dimensions (WxHxD without hinges and door):
353/4" x 703/4" x 241/16"
Dimensions (WxHxD with hinge and door, no handle):
353/4" x 717/8" x 287/8"
Weight: 352.7 lbs.
Shipping Dimensions & Weight (WxHxD)
Dimensions: 385/16" x 78" x 315/16"
Weight: 385.8 lbs.
Color Model # UPC Code
Stainless Steel RF23J9011SR 887276088969
Black Stainless RF23J9011SG 887276113340
Dimensions
Measure height
including flooring.
Be sure to allow
for hinge clearance
height if needed.
Measure width
including
countertop
overhang.
Measure depth
including
molding or trim.
21 3/8"
3 3/8"
35 3/4"
7⁄ 16"
55 1/8"
29 7/8"
33 3/4"
36 1/4"
1 3/8"
22 1⁄4" 9 1⁄ 16"
69 7⁄ 8"
35 1⁄ 8"
5/8"
7/16"
2 3/8"
Installing Your Refrigerator
Dimensions
1. Measure the height, width and depth of the opening, making sure to include baseboards,
molding tile, countertop overhang, etc. Check to be sure there is enough room to open
the door (consider walls, islands or other obstacles when measuring).
2. Refer to illustration below to determine dimensions.
3. Allow 2.5" of clearance on hinge side of refrigerator when installing next to a wall
where handle may make contact.
4. Allow 1" minimum clearance at rear for proper air circulation and water/electrical
connections. Allow a 3/8" minimum clearance at sides and top for ease of installation.
5. Ensure each door and entryway in the home is wide enough for the refrigerator
to be moved through easily.
For optimal usage and to be able to open refrigerator doors completely,
do not install next to a wall.
Please note: The following dimension and cutout information is for planning purposes only.
For complete installation details, consult manual packed with product, or download manual
online at samsung.com.
RF23J9011SR
23 cu. ft. Counter Depth 4-Door Refrigerator with Cool Select Plus
703/4"
717/8"
24 1/16"
413/16"
2813/16"
421/4"
353/4"
24"
