Samsung iPOLiS SNP-3120 User manual

NETWORK CAMERA
User Manual SNP-3120/
3120V/3120VH

Copyright
©2011 Samsung Techwin Co., Ltd. All rights reserved.
Trademark
is the registered logo of Samsung Techwin Co., Ltd.
The name of this product is the registered trademark of Samsung Techwin Co., Ltd.
Other trademarks mentioned in this manual are the registered trademark of their respective company.
Restriction
Samsung Techwin Co., Ltd shall reserve the copyright of this document. Under no circumstances, this document shall
be reproduced, distributed or changed, partially or wholly, without formal authorization of Samsung Techwin.
Disclaimer
Samsung Techwin makes the best to verify the integrity and correctness of the contents in this document, but no
formal guarantee shall be provided. Use of this document and the subsequent results shall be entirely on the user’s own
responsibility. Samsung Techwin reserves the right to change the contents of this document without prior notice.
Warranty
If the product does not operate properly in normal conditions, please let us know. Samsung Techwin will resolve the
problem for free of charge. The warranty period is 3 years. However, the followings are excluded:
•If the system behaves abnormally because you run a program irrelevant to the system operation.
•Deteriorated performance or natural worn-out in process of time
Design and specifications are subject to change without prior notice.
The default password can be exposed to a hacking thread so it is recommended to change the password
after installing the product.
Note that the security and other related issues caused by the unchanged password shall be responsible
for the user.
Network Camera
User Manual

English _3
●OVERVIEW
IMPORTANT SAFETY INSTRUCTIONS
1. Read these instructions.
2. Keep these instructions.
3. Heed all warnings.
4. Follow all instructions.
5. Do not use this apparatus near water.
6. Clean only with dry cloth.
7. Do not block any ventilation openings, Install in accordance with the manufacturer’s
instructions.
8. Do not install near any heat sources such as radiators, heat registers, stoves, or other
apparatus (including amplifiers) that produce heat.
9. Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized
plug has two blades with one wider than the other. A grounding type plug has two
blades and a third grounding prong. The wide blade or the third prong are provided for
your safety, If the provided plug does not fit into your outlet, consult an electrician for
replacement of the obsolete outlet.
10. Protect the power cord from being walked on or pinched particularly at plugs, conve-
nience receptacles, and the point where they exit from the apparatus.
11. Only use attachments/ accessories specified by the manufacturer.
12. Use only with the cart, stand, tripod, bracket, or table specified by
the manufacturer, or sold with the apparatus. When a cart is used,
use caution when moving the cart/apparatus combination to avoid
injury from tip-over.
13. Unplug this apparatus during lighting storms or when unused for
long periods of time.
14.
Refer all servicing to qualified service personnel. Servicing is required when the apparatus
has been damaged in any way, such as power-supply cord or plug is damaged, liquid has
been spilled or objects have fallen into the apparatus, the apparatus has been exposed to
rain or moisture, does not operate normally, or has been dropped.
overview

overview
4_ overview
WARNING
TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE
THIS PROCUCT TO RAIN OR MOISTURE. DO NOT INSERT ANY METALLIC
OBJECT THROUGH THE VENTILATION GRILLS OR OTHER OPENNINGS
ON THE EQUIPMENT.
Apparatus shall not be exposed to dripping or splashing and that no objects
filled with liquids, such as vases, shall be placed on the apparatus.
CAUTION
CAUTION
RISK OF ELECTRIC SHOCK.
DO NOT OPEN
CAUTION : TO REDUCE THE RISK OF ELECTRIC SHOCK.
DO NOT REMOVE COVER (OR BACK).
NO USER SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
EXPLANATION OF GRAPHICAL SYMBOLS
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of “dangerous voltage” within the product’s
enclosure that may be of sufficient magnitude to constitute a
risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended
to alert the user to the presence of important operating
and maintenance (servicing) instructions in the literature
accompanying the product.

English _5
●OVERVIEW
When used outside of the U.S., it may be used HAR code with fittings of
an approved agency is employed.
CAUTION
These servicing instructions are for use by qualified service personnel only.
To reduce the risk of electric shock do not perform any servicing other than
that contained in the operating instructions unless you are qualified to do so.
The BNC Out terminal of the product is provided for easier installation, and is
not recommended for monitoring purposes.
If you keep the BNC cable connected, a risk of lightening may cause damage
or malfunction to the product.
Please use the input power with just one camera and other devices must not
be connected.
Do not expose the product to the direct airflow from an air conditioner.
Otherwise, it may cause moisture condensation inside the Clear Dome due to
temperature difference between internal and external of the dome camera.
If you install this product in a low-temp area such as inside a cold store, you
must seal up the wiring pipe with silicon, so that the external air can not flow
inside the housing.
Otherwise, external high, humid air may flow inside the housing, pooling
moisture or vapor inside the product due to a difference between internal and
external temperature.

overview
6_ overview
Please read the following recommend safety precautions carefully.
User’s Manual is a guidance book how to use the products
The meaning of the using sign in the book is following
Reference : In case of providing information for helping of product’s usages
Notice : If there’s any possibility to occur any damages for the goods and
human caused by not following the instruction
Please read this manual for the safety before using of goods and keep it in
the safe place.
Do not place this apparatus on an uneven surface. Do not install on a surface where it is exposed to direct
sunlight, near heating equipment or heavy cold area.
Do not place this apparatus near conductive material. Do not attempt to service this apparatus yourself.
Do not place a glass of water on the product. Do not install near any magnetic sources.
Do not block any ventilation openings. Do not place heavy items on the product.

English _7
●OVERVIEW
Samsung Techwin cares for the environment at all product manufacturing stages, and is
taking measures to provide customers with more environmentally friendly products.
The Eco mark represents Samsung Techwin’s devotion to creating environmentally friendly
products, and indicates that the product satisfies the EU RoHS Directive.
This equipment has been tested and found to comply with the limits for a
Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when
the equipment is operated in a commercial environment.
This equipment generates, uses, and can radiate radio frequency energy and,
if not installed and used in accordance with the instruction manual, may cause
harmful interference to radio communications. Operation of this equipment in a
residential area is likely to cause harmful interference in which case the user will
be required to correct the interference at his own expense.
Correct Disposal of This Product (Waste Electrical & Electronic Equipment)
(Applicable in the European Union and other European countries with separate collection
systems)
This marking on the product, accessories or literature indicates that the product and its
electronic accessories (e.g. charger, headset, USB cable) should not be disposed of with other
household waste at the end of their working life. To prevent possible harm to the environment
or human health from uncontrolled waste disposal, please separate these items from other
types of waste and recycle them responsibly to promote the sustainable reuse of material
resources.
Household users should contact either the retailer where they purchased this product, or
their local government office, for details of where and how they can take these items for
environmentally safe recycling.
Business users should contact their supplier and check the terms and conditions of the
purchase contract. This product and its electronic accessories should not be mixed with other
commercial wastes for disposal.

overview
8_ overview
CONTENTS
OVERVIEW
3
3Important Safety Instructions
10 Product Features
10 Recomended PC Specifications
10 Recomended SDHC/SD Memory
Card Specifications
11 What’s Included
13 At a Glance
INSTALLATION &
CONNECTION
18
18 DIP Switch Setting
28 Installation (SNP-3120)
32 Installing with accessories (Sold
Separately)
34 Installation (SNP-3120V)
37 Installation (SNP-3120VH)
41 Inserting/Removing an SD
Memory Card
42 Memory Card Information
(Not Included)
43 Connecting with other Device
NETWORK CONNECTION
AND SETUP
46
46 Connecting the Camera Directly
to Local Area Networking
47 Connecting the Camera Directly
to a DHCP Based DSL/Cable
Modem
48 Connecting the Camera Directly
to a PPPoE Modem
49 Connecting the Camera to an
IP Router with the PPPoE/Cable
Modem
50 Buttons used in IP Installer
51 Static IP Setup
54 Dynamic IP Setup
55 Port Range Forward (Port
Mapping) Setup
57 Connecting to the Camera from a
Shared Local PC
57 Connecting to the Camera from a
Remote PC via the Internet

English _9
●OVERVIEW
CAMERA SETUP
67
67 Using the Camera Menu
67 Camera Setting
77 OSD Setting
79 Initialize
SETUP SCREEN
80
80 Setup
80 Audio & Video Setup
88 Network Setup
93 Event Setup
99 System Setup
WEB VIEWER
58
58 Connecting to the Camera
59 Login
60 Installing Silverlight Runtime
62 Using the Live Screen
65 Playback
66 Playing the backup recordings
APPENDIX
104
104 Specification
109 Product Overview
111 Troubleshooting
113 Open Source Announcement
115 GPL/LGPL Software License

overview
10_ overview
PRODUCT FEATURES
Multi-Streaming
This network camera can display videos in different resolutions and qualities simultane-
ously using different CODECs.
MHowever, MPEG4 video can not be played on a web page. Use CMS software if you want to play
the video on a web page.
Web Browser-based Monitoring
Using the Internet web browser to display the image in a local network environment.
Alarm
If an event occurs, the event-related video will be transferred to the email specified by the
user or saved to the SD memory, or the event signal will be sent to the Alarm Out port.
Intelligent Video Analysis
Analyzes the event video according to the user-specified rules to recognize the event.
ONVIF (Spec 1.02) Compliance
This product supports ONVIF Core Spec. 1.02.
For more information, refer to www.onvif.org.
RECOMENDED PC SPECIFICATIONS
CPU : Intel(R) Core(TM)2 2.00 GHz or higher
Operating System : Windows XP, VISTA, 7
Mac OS
Resolution : 1280X1024 pixels or higher
RAM : 1GB or higher
Web Browser :
Internet Explorer 6.0 or higher
Firefox, Google Chrome, Safari
Video Memory : 128MB or higher
RECOMENDED SDHC/SD MEMORY CARD SPECIFICATIONS
2GB ~ 32GB
To ensure proper recording of video data, we recommend you use a memory card that
supports at least read/write speed 10Mbps and Class 6.

English _11
●OVERVIEW
WHAT’S INCLUDED
Please check if your camera and accessories are all included in the product package.
Appearance Item Name Quantity Description Model Name
User Manual,
Installer S/W DVD,
CMS S/W DVD
2
SNP-3120/3120V/
3120VH
Quick Guide 1
7Pin Terminal Block 1 For communications
8Pin Terminal Block 1 For alarm I/O
Cable for the testing
monitor 1
Used to test the camera
connection to a portable display
device
Audio cable 1

overview
12_ overview
Appearance Item Name Quantity Description Model Name
Template 1 Product installation guide
SNP-3120
ASSY-Tapping Screw 4
Used for installation on the wall or
ceiling
Mount Bracket 1 SNP-3120
L Wrench 1
Used to remove/fix the dome
cover SNP-3120V/3120VH
M The Test Monitor Cable is connected to a portable displayer and used for testing the camera.
If you intend to use it for an actual monitoring camera, use the BNC cable instead.

English _13
●OVERVIEW
AT A GLANCE
❖SNP-3120
Item Description

Main unit Main unit includes the lens, switch board, PCB boards and screws.
b
Dome Cover Dome cover for the lens and unit protection.
c
Audio Audio I/O port.

Alarm In / Out
terminals Used to connect alarm in/out terminal block.

Video, RS-485, Power Used to connect monitor, RS-485 device or power.

ID setup switch Used to setup the camera ID or communication protocol.

Screw Hole Used to fix the camera to the wall or ceiling.

Reset Button
Resets the camera settings to the default. Press and hold it for about 5
seconds to turn off the system indicator and restart the system.
J
If you reset the camera, the network settings will be adjusted so that
DHCP can be enabled. If there is no DHCP server in the network, you
must run the IP Installer program to change the basic network settings
such as IP address, Subnet mask, Gateway, etc., before you can
connect to the network.

Network port Used to connect a PoE or LAN cable.

overview
14_ overview
❖SNP-3120V
Item Description

Surface Mount
Bracket
Used to install the camera directly on the ceiling.
After separating this cover, mount this bracket on to ceiling.
b
Main unit Main unit includes the lens, switch board, PCB boards and screws.
c
Dome Cover Dome cover for the lens and unit protection.

SD Memory Card
Compartment
Compartment for the SD memory card.

Audio Audio I/O port.

Heater Activated when the ambient temperature is under 5ºC to prevent the dome
cover from being covered with frost.

Video, RS-485, Power Used to connect monitor, RS-485 device or power.

ID setup switch Used to setup the camera ID or communication protocol.

Reset Button
Resets the camera settings to the default. Press and hold it for about 5
seconds to turn off the system indicator and restart the system.
J
If you reset the camera, the network settings will be adjusted so that
DHCP can be enabled. If there is no DHCP server in the network, you
must run the IP Installer program to change the basic network settings
such as IP address, Subnet mask, Gateway, etc., before you can
connect to the network.

Alarm In / Out
terminals Used to connect alarm in/out terminal block.

Network port Used to connect a PoE or LAN cable.

English _15
●OVERVIEW
❖SNP-3120VH
Item Description

Sun Shield Housing Used to protect the main unit from the sunlight.
b
Main unit Main unit includes the lens, switch board, PCB boards and screws.
c
Dome Cover Dome cover for the lens and unit protection.

SD Memory Card
Compartment
Compartment for the SD memory card.

Audio Audio I/O port.

Heater Activated when the ambient temperature is under 5ºC to prevent the dome
cover from being covered with frost.

Video, RS-485, Power Used to connect monitor, RS-485 device or power.

ID setup switch Used to setup the camera ID or communication protocol.

Reset Button
Resets the camera settings to the default. Press and hold it for about 5
seconds to turn off the system indicator and restart the system.
J
If you reset the camera, the network settings will be adjusted so that
DHCP can be enabled. If there is no DHCP server in the network, you
must run the IP Installer program to change the basic network settings
such as IP address, Subnet mask, Gateway, etc., before you can
connect to the network.

Alarm In / Out
terminals Used to plug terminal block to connect alarm in/out.

Network port Used to connect a PoE or LAN cable.

overview
16_ overview
❖Camera Wiring Interface Board
For the camera wiring, please refer to the picture below. When using coaxial
communication, a separate control signal connection is not required.
Controller & Auxiliary Signal Connection
No. Name Usage
1 2.COM Alarm Output 2 (Common)
2 2.NO Alarm Output 2 (Normal Open)
3 1.COM Alarm Output 1 (Common)
4 1.NO Alarm Output 1 (Normal Open)
5 1.NC Alarm Output 1 (Normal Open)
6 GND Ground
7 IN1 Alarm Input Sensor Terminal 1
8 IN2 Alarm Input Sensor Terminal 2
ALARM
ID PROTOCOL
VIDEO 485 POWER

English _17
●OVERVIEW
Power, Video & Communication Signal Connection
No. Name Usage
1 VIDEO Video Output
2 GND Ground
3 485+ Controller Data Line
4 485- Controller Data Line
5FGField Ground
6ACAC 24V
7ACAC 24V
M The provided BNC cable’s blue line is Video Output, while the black line is the Ground.
Power supply adaptor (AC) has no polarities.
J The maximum power capacity of the built-in relay is 30V DC/2A, 125V AC/0.5A, and 250V
AC/0.25A.
Connecting the power connector and GND incorrectly to the NC/NO and COM ports may cause a
short circuit and fi re, damaging the camera.
When connecting the camera to an external over-rated product, use a separate relay device to
ensure proper operation.
To prevent possible inflow of lightning while in test monitoring, perform the test with the FG
terminal grounded.

18_ installation & connection
installation & connection
DIP SWITCH SETTING
How to set up Protocols and ID DIP Switches
You can control various settings of the camera system using the Communication and ID
DIP switches. Before installing the product, please set up the DIP switches according to the
installation environment.
1. Detach the camera frame from the install base, and place the bottom of the frame
toward you as shown in the picture below.
2. Set the switches according to your installation environment. For more detailed setup
information, please refer to the chart on the next page.
3. The camera may malfunction if the switches are not fully turned On/Off; please
double check the switches before finishing setup.
Communication Protocol
DIP Switch(SW2)
Camera ID DIP Switch(SW1)

English _19
●INSTALLATION & CONNECTION
Communication Protocol DIP Switch Settings (SW2)
Coaxial communication automatically detects signals, and so does not require a separate
communication setup process.
SW2 Pin No. Purpose
1~4 Protocol Settings
5~6 Baud Rate Settings
7Response Mode Settings
8Termination Settings
Protocol Settings
Select a communication protocol for the camera.
No. Protocol SW2-#1 SW2-#2 SW2-#3 SW2-#4
1 AUTO DETECT OFF OFF OFF OFF
2 Samsung-T OFF OFF OFF ON
3 Pelco-D OFF OFF ON OFF
4 Pelco-P OFF OFF ON ON
5 Samsung-E OFF ON OFF OFF
6 Panasonic OFF ON OFF ON
7 Vicon OFF ON ON OFF
8 Honeywell OFF ON ON ON
9 AD ON OFF OFF OFF
10 GE ON OFF OFF ON
11 BOSCH ON OFF ON OFF
12 Reserved ON OFF ON ON
13 Reserved ON ON OFF OFF
14 Reserved ON ON OFF ON
15 Reserved ON ON ON OFF
16 Reserved ON ON ON ON
ON ON
OFF
SW2

installation & connection
20_ installation & connection
Baud Rate Settings
Select the transfer speed of a selected communication protocol.
No. Baud Rate (BPS) SW2-#5 SW2-#6
1 2,400 ON ON
2 4,800 ON OFF
3 9,600 OFF OFF
4 19,200 OFF ON
Communication Response Settings
Select a communication response method for the camera and controller: Response or No
Response.
Function ON OFF
SW2- #7 Response Mode Switch Response No Response
Termination Settings
To prevent the attenuation of communication signals between the camera and controller,
the items at the end of line must be set up with the termination settings.
Camera Input Position SW2- #8
Termination of Longest Path ON
On the Path OFF
- This model is provided with factory defaults of all DIP switches set to OFF. The default
settings are shaded in the table.
