High Resolution 12X IR Camera SCO-2120R User Guide

Before operating the camera, confirm the camera model and correct input power
voltage. In order to that you can understand this manual thoroughly, we will explain the
model description.
n SCO-2120R SERIES
 •NTSCMODEL •PALMODEL
  SCO-2120RN SCO-2120RP
nMODEL DESCRIPTION
 •SCO-2120RX
_
 •SIGNALSYSTEM
  NNTSCMODEL
  PPALMODEL
SIGNALSYSTEM
This installation should be made by a qualified service person and
should conform to all local codes.
Thelightningflashwithanarrowheadsymbol,withinanequilateraltriangleis
intended to alert the user to the presence of uninsulated “dangerous voltage”
withintheproduct'senclosurethatmaybeofsufficientmagnitudetoconstitute
a risk of electric shock to persons.
Theexclamationpointwithinanequilateraltriangleisintendedtoalerttheuser
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
INFORMATION - This equipment has been tested and found to comply with limits
for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio
communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference at
his own expense.
WARNING - Changes or modifications not expressly approved by the manufacturer
could void the user ’ s authority to operate the equipment.
WARNING - To prevent electric shock and risk of fire hazards:
◆Do NOT use power sources other than that specified.
◆Do NOT expose this appliance to rain or moisture.

COLOR CCD CAMERA User Guide
4
COLOR CCD CAMERA User Guide
5
Contents
Contents
• Features ……………………………………………………………… 5
• Warnings & cautions ………………………………………………… 6
• Precautions…………………………………………………………… 7
• Components and Accessories ……………………………………… 9
• Overview …………………………………………………………… 9
nFront 
nBack  
nSide  
• Connection …………………………………………………………… 12
nConnectingtoamonitor 
nConnectingtopower  
nRS-485Communicationcontrol 
nUsingCoaxialCommunications 
• Operating Your Camera …………………………………………… 16
nMenuConfiguration 
nMenuSetup  
 •SSDR(SamsungSuperDynamicRange)  
 •WhiteBalance(WhiteBal.)  
 •BACKLIGHT 
 •MOTIONDETECTION  
 •FOCUS 
 •EXPOSURE  
 •SPECIAL  
 •RESET 
 •EXIT 
• Troubleshooting ……………………………………………………… 41
• Specifications ………………………………………………………… 42
• Dimension …………………………………………………………… 44
DAY&NIGHT(ICR)
This camera has a function that automatically selects
themodethat isappropriatefordaytimeornight-time
conditions.
TheCOLORmodeoperatesindaytimeconditionsto
provideoptimumcolors,andBWmodeoperatesin
night-time conditions to enhance the definition of the
image.
Outdoor Visibility range 70M
TheIRLEDsoftheSOC-2120Rautomaticallyilluminates
viewing area in the extreme darkness allowing the
cameraalong-rangevisibilityofupto70meters.
IR MODE Function
This function prevents the saturation of the image by
theIRilluminatorsatshortdistance.
IP66 Approved/Dust and Rain
Resistant
Withdustandrainresistantdesign,thecameracanbe
installedoutside underbuildingeavesorplaces that
are exposed to the dust and rain.
Ultra High Sensitivity
A/F 12X Optical ZOOM
Thebuilt-inhighsensitivityCOLORCCDproducesa
clearimageevenin0Lux(B/W,IR-LEDON)orlower
illumination.
Thebuilt-inSCO-2120R optical zoomlensis ahighly
durablecomponent.Itfeatureautofocus,autoiris,and
zoomfunctions.
High Resolution
Byadoptingadiagonal6mm(1/3")410,000(NTSC)
pixel,470,000(PAL)pixelSONYCCD,thecamera
producesclearpicturequalitywithahorizontal
resolutionof600TVlinesforcolorandahorizontal
resolutionof700TVlinesforBWmode.
SSDR
(Samsung Super Dynamic Range)
Forimageswithhighcontrastbetweenbrightanddark
Areasfromdifficultlightingconditionssuchas
backlighting,thiscameraselectivelyilluminatesdarker
Areaswhile retainingthe samelightlevel forbrighter
Areastoevenouttheoverallbrightness.
Communication
RS-485,Coaxialcommunicationmethodsare
supported.
-RS-485Communications
:SAMSUNG-T,SAMSUNG-E,PELCO-P,PELCO-D,VICON,
PANASONIC,BOSCH,HONEYWELL
-CoaxialCommunications
:PelcoCoaxitron
Miscellaneous Functions
HLC(HighLightCompensation),SENS-UP,FLIP(H/V-REV),
D-ZOOM,SHARPNESS,MOTIONDETECTIONand
PRIVACYfunctionsareprovided.
OSD
Thecamera’sOSDiscomplimentedby18languages.
-NTSC:Korean,English,French,Spanish, Japanese,
Portuguese,Taiwanese
-PAL :English, French,German,Spanish,Italian,
Chinese, Russian,Czech,Polish,Romanian,
Serbian,Swedish,Danish,Turkish,Portuguese
SSNR3 (Samsung Super Noise
Reduction) Function
Thehigh-performanceW-VDSPchipeffectively
removeslow-lightgain noiseandghosting to provide
clear images even in dark environments.
Features

COLOR CCD CAMERA User Guide
6
COLOR CCD CAMERA User Guide
7
Thisinformationisprovidedtoensureyoursafetyandtopreventanylosses,financialor
otherwise.Pleasereaditcarefullyandusetheproductaccordingly.
*For product inquiries, please contact the retail shop where you bought the camera.The use of
equipmentsuchasanaerialladderwhileprovidingafter-salesserviceshallbeatyourexpense.
Ignoring this information may result in
death or or serious personal injuries.
Indicates"NeverAllowed."
Ignoring this information may result in
material loss or personal injuries.
Indicates "NoDisassembling."
SamsungTechwincaresfortheenvironmentatallproductmanufacturingstagestopreserve
theenvironment,andistakinganumberofstepstoprovidecustomerswithmore
environment-friendly products.The Eco mark represents Samsung Techwin's will to create
environment-friendlyproducts,andindicatesthattheproductsatisfiestheEURoHSDirective.
Warnings & Cautions
Warning/Attention/Special Mark Messages
Notes
•Pleasemakesuretheproductisinstalledappropriateplaceswheresecuredfrom
flood, such as under the eaves, to operate properly.
Precautions
Do not install under extreme
temperature conditions.
Use only under temperature conditions
between -10°C and +50°C. Provide
good ventilation when using in high
temperature conditions.
Do not install in high humidity
environment.
May lower image quality.
Do not install under unstable
lighting conditions.
Severe lighting changes or flickering may
hinder normal camera operation.
Avoid touching the camera lens.
The lens is the most important component
of the camera. Be careful not to smear it
with fingerprints.

COLOR CCD CAMERA User Guide
8
COLOR CCD CAMERA User Guide
9
Do not drop the camera or
subject it to physical shock.
May cause a product malfunction.
Never keep the camera face to
strong light directly.
May damage the CCD.
Do not expose the camera to
radioactivity.
Radioactivity exposure may damage the
CCD.
•Exposuretoaspotlightoranobjectemittingstronglightmaycausesmearor
blooming.
•Ensurethatthepowersourcecomplieswithnormalspecificationsbeforesupplying
it to the camera.
•IncaseofIRLEDhasbeenlighted,donotlightendirectlyeye.
Notes
Precautions
Components and Accessories
Overview
❶ 2
FRONT
❶Camera Sunshield
2S unshield adaptor : Fixing the sunshield onto the camera.
3x12 Zoom Module
4Front cover
5Function Setup Switch :
Display the menu on the screen and move the cursor to four directions to confirm
status or after changing a selected item.
6Video Output Terminal to Monitor :
Used for monitoring of video output When camera installation.
❶
SCO-2120R 2 Sunshield 3 L-typehexagonwrenches(3.0mm)
4
SunshieldAdaptor(1EA) 5 TappingScrew(3EA)
❻
UserGuide
➐ InstallationVideoOutputCable
❹
3
➐❻
5
❶
4
5 6
23

COLOR CCD CAMERA User Guide
10
COLOR CCD CAMERA User Guide
11
•Toensuretheweatherproofintegrityismaintained,ensurethefrontcoveris
tightened correctly.
Notes
Overview
BACK
SIDE
•Ifthefrontcoveriscrossthreadedornotcorrectlytightenedthecamerahousing
willnotbeweatherproof.
•Whenyoucombinethefrontcover,combinethetriangleoffrontcoverandtriangle
ofmainbodyconfronteachother.
Notes
Front cover
FunctionSetup
Switch
➐Power input terminal : Connect the power as specified for each model here.
8Video output terminal : Video signals are output through this port. Connect
this port to the Video IN port of a monitor.
9
RS-485 control terminal :
You can control SETUP MENU through this port by using external controllers like a
Remote controller that RS-485 Communication is supported. For details, see page 14.
➐
8
9

COLOR CCD CAMERA User Guide
12
COLOR CCD CAMERA User Guide
13
Connecting to Monitor
Please connect the video output terminal located on the back of the camera to the
monitor.
CCDCamera
CCDCamera
Intermediate Endmonitor
Monitor
• The connection method varies depending on the type of monitor and accessories.
Please refer to the user's manual for each instrument.
• Please turn off the power when connecting.
• Please select Hi-Z on the 75Ω/Hi-Z switch for the intermediate video TV set and
select 75Ω for the Intermediate device as shown in the picture below.
Connection
The recommended adaptor specification for SCO-2120RN/P is DC 12V/4A, AC
24V/1A over.
Please check the standard power requirement before connecting the power.
Connecting to Power
Whentheresistancevalueofcopperwireisat[20°C(68°F)]
Copperwiresize(AWG) #24(0.22mm2)#22(0.33mm2)#20(0.52mm2)#18(0.83mm2)
Resistancevalue(Ω/m) 0.078 0.050 0.030 0.018
Voltagedrop(V/m) 0.028 0.018 0.011 0.006
• As shown in the table above, voltage decreases as the wire gets longer.
Therefore having an excessively long distance between the power adaptor and the
camera may affect the camera's performance.
✽Standardvoltageforcameraoperation:DC12V±10%/AC24V±10%
✽Theremaybesomedeviationinvoltagedropdependingonthetypeofwireandthemanufacturer.
•Pleaseuseapoweradaptorthatmeetstherequiredstandards.
•Pleaseconnectthepowerafterinstallation.
Notes

COLOR CCD CAMERA User Guide
14
COLOR CCD CAMERA User Guide
15
• Whenmakingacontrolsystemtocontrolthecamera,pleaseusetothe
protocol(SAMSUNG-T, SAMSUNG-E, PELCO-P, PELCO-D,VICON, PANASONIC, BOSCH,
HONEYELL).
•When you connecting to RS-485 CONTROLTERMINAL, please peel off the outer
skininsidetheRS-485CONTROLTERMINAL.
• IncaseofSCC-101connection,changecommunicationmode to8-E-1atCommunication
configurationmenu.(Formoreinformation,refertoSCC-101manual.)
Notes
Using Coaxial Communications
DVD
•Coaxial Communications System
•OSD Control method
DVR
Distance Recommended Cable Specification
300m 3C2V(RG-59/U)
450m 5C2V(RG-6/U)
600m 7C2V(RG-11/U)
– Video Cable
The camera's video output port is connected to the monitor with a BNC coaxial cable,
shown below : If the distance between the camera and the monitor exceeds the
recommended maximum, please use an auxiliary video amp.
•Ifthecameraiscontrolledthroughcoaxialcommunication,pleaseuseavideoamp
intendedforcoaxialcommunications.Regularvideo amps do nottransfercoaxial
signals.
Notes
Using RS-485 communication will enable you to control the OSD menu from a SAMSUNG
TECHWIN System Controller or DVR.
(1) Connection to a PC.
Connect the camera to the PC via a RS-485 converter using RS-485 and a serial cable.
EX) SERIAL PORT OF THE PC(COM1) →SERIAL CABLE →RS-485 CONVERTER →RS-485
CONTROL CABLE
Connecting to RS-485 Control Cable
CONTROL CABLE SPEC
WHITE (TRX+) RS-485+
BLUE (TRX-) RS-485-
* RS-485 Communication establishment initial value
485 Control Board Connection Port RS-485 Control Port
(+) CONNECTION TERMINAL WHITE (TRX+)
(-) CONNECTION TERMINAL BLUE (TRX-)
Item Camera ID BAUD RATE UART MODE RET PKT
Initial value
19600 8-NONE-1 ENABLE
(2) Connection to a DVR or System Controller.
Connect the RS-485 cable to the connection ports of the DVR or System Controller.
CAMERA DVR CONTROLLER
SET MENU/ENTER OSD KEY
UP UP KEY JOYSTICK UP
DOWN DOWN KEY JOYSTICK DOWN
LEFT LEFT KEY JOYSTICK LEFT
RIGHT RIGHT KEY JOYSTICK RIGHT
RS-485 communication control
Connection
• :BNC
•---- :RS-485

COLOR CCD CAMERA User Guide
16
COLOR CCD CAMERA User Guide
17
Operating Your Camera
Menu Configuration
MAIN SETUP MENU
SSDR
OFF  ON
WHITE BAL
ATW  MANUAL  AWC→SET
OUTDOOR INDOOR
BACKLIGHT
OFF  BLC  HLC
MOTION DET
OFF  ON
FOCUS
MODE  ZOOM TRACK  ZOOM SPEED
D-ZOOM  ZOOM POS INIT  USER PRESET
LENS INIT  RETURN
EXPOSURE
BRIGHTNESS  IRIS  SHUTTER
AGC  SSNR3  SENS-UP
RETURN
SPECIAL
PRIVACY  DAY/NIGHT  DIS
SYNC  COMM ADJ  IMAGE ADJ
MONITOR  DISPLAY  RETURN
RESET
EXIT
Use the Function Setup switch within the camera.
FunctionSetupswitch
Menu Setup
1. Press the Function Setup switch.
• Main setup menu is displayed on the monitor screen.
2. Select a desired function using the Function Setup switch.
• Place the cursor over a desired item.
3. Set up a selected item by using the Function Setup switch.
4. To finish the setting, select ‘EXIT’ and press the Function Setup switch.
Select the function using
the Function Setup switch.
Change the status using the
Function Setup switch.
• An item with the icon also has sub menus. To select a sub menu, select an item with
the icon and press the Function Setup switch.
• An item with the - - - icon is unavailable due to function settings.
Notes
MAIN SETUP
SSDR ON
WHITE BAL ATW
BACKLIGHT OFF
MOTION DET OFF
FOCUS
EXPOSURE
SPECIAL
RESET
EXIT

COLOR CCD CAMERA User Guide
18
COLOR CCD CAMERA User Guide
19
Operating Your Camera
SSDR (Samsung Super Dynamic Range)
SSDR illuminates darker spots of an image while retaining the same light level for brighter
spots to even out the overall brightness of images with high contrast between bright and
dark spots.
SSDROFF
1. When the SETUP menu screen is displayed, select ‘SSDR’ by using the switch so that the
arrow indicates ‘SSDR’.
2. Use the switch to change the SSDR level according to the contrast between bright and dark areas.
SSDRON
Select one of the following 5 modes, as appropriate for your purpose.
 ATW : Select this when the color temperature is between 1,800˚K and 10,500˚K.
 MANUAL : Select this to fine-tune White Balance manually. Set White Balance first by
using the ATW or AWC mode. After that switch to MANUAL mode, fine-
tune the White Balance and then press the Function Setup switch.
 AWC SET : To find the optimal luminance level for the current environment, point the
camera towards a sheet of white paper and press the Function Setup
switch. If the environment changes, readjust it.
 OUTDOOR : Select this when the color temperature is between 1,700˚K and 11,000˚K.
(sodium light inclusion)
 INDOOR : Select this when the color temperature is between 4,500˚K and 8,500˚K.
• White Balance may not work properly under the following conditions. In this case
select the AWC mode.
 When the color temperature of the environment surrounding the subject is out of the
control range (e.g. clear sky or sunset).
 When the ambient illumination of the subject is dim.
 If the camera is directed towards a fluorescent light or is installed in a place where
illumination changes dramatically, the White Balance operation may become unstable.
Notes
Use the White Balance function to adjust the screen color.
1. When the SETUP menu screen is displayed, select ‘White Bal’ by using the Function Setup
switch so that the arrow indicates ‘White Bal’ .
2. Select a desired mode using the Function Setup switch.
White Balance (White Bal)
MAIN SETUP
SSDR ON
WHITE BAL ATW
MAIN SETUP
SSDR ON
WHITE BAL ATW
BACKLIGHT OFF
MAIN SETUP
SSDR ON
WHITE BAL ATW
BACKLIGHT OFF
MOTION DET OFF
BACKLIGHT
Unlike conventional cameras, the SCO-2120R is designed to deliver a distinctive subject and
background at the same time, even when the subject is backlight, by using the features of the
proprietary W-V DSP chip.
1. When the SETUP menu screen is displayed, select ‘BACKLIGHT’ by using the Function Setup
switch so that the arrow indicates ‘BACKLIGHT’.

COLOR CCD CAMERA User Guide
20
COLOR CCD CAMERA User Guide
21
Operating Your Camera
• For effective viewing of license plates, there is a minimum required illumination and
the shutter speed needs to be faster than 1/200sec.
• Because there can be a difference in the effectiveness of HLC according to the
amount of light area in the screen, optimize the installation angle for the best HLC
performance.
• When dark, the HLC is only activated when a bright light exceeding a specific size.
(In NIGHT ONLY mode.)
• The HLC is not activated in day light or when bright light is not present at night.
(In NIGHT ONLY mode.)
• The HLC is not activated when the D-ZOOM mode is 'ON' or DIS mode is 'ON'.
Notes
3. Select a desired mode using the Function Setup switch and press the Function Setup switch.
• Select ‘BLC’ to adjust the area to be
enhanced then adjust the level.
• HLC : Enable the user to change the level,
mask tone area.
 HLC (High Light Compensation) :
If the scene contains extremely bright light areas such as; from car headlight, the light
can mask out much of the on-screen detail.
- LEVEL : Adjust level of the HLC function.(LOW,MIDDLE,HIGH)
- MASK TONE : Change the brightness
- LIMIT : Enable to change the operating condition.
2. Select a desired mode using the Function Setup Switch.
OFF : Not being used
BLC : Enables a user to directly select a desired area from a picture, and to view the
area more clearly.
MAIN SETUP
SSDR ON
WHITE BAL ATW
BACKLIGHT OFF
MOTION DET OFF
FOCUS
Motion Detection
This product has a feature that will detect movements of objects in 8 different areas on the
screen. The camera detects an object’s movement by sensing disparity of outline, brightness
levels and color. The camera sends a detection signal out via the MD output terminal and will
zoom into a pre-determined point.
1. Please press the Function Setup Switch.
OFF : MOTION DETECTION mode is cancelled.
 ON : Any motion in the selected areas is observed.
• AREA SEL : You can select 8 different sensitivity MOTION
DET area.
• AREA MODE : Determines whether to use the MD area selected in SENSITIVITY.
• SEL POS(XPOS/YPOS) : You can control MD area size.
• SMART ZOOM : Smart zoom is operated in connection
with MOTION DETECTION. When the
SMART ZOOM function is ‘ON’ while the
MOTION DETECTION mode is ‘ON’, the
zoom goes to the TARGET ZOOM
position once motion is detected. Once
the zoom action is finished and ‘DWELL
TIME’ has passed, the zoom returns to
the ‘START ZOOM’ position.
MOTION DET SENSTIVITY
AREA1
MIN
AREA8
MAX

COLOR CCD CAMERA User Guide
22
COLOR CCD CAMERA User Guide
23
Operating Your Camera
- START ZOOM : By moving the left or right direction of the Function Setup Switch in the
‘START ZOOM’ item to select the zoom position from 1x to 12x to be
returned after the ‘SMART ZOOM’ action is over.
- TARGET ZOOM : By moving the left or right direction of the Function Setup Switch in the
‘TARGET ZOOM’ item to select the zoom position from 1x to 12x to be
used during MOTION DETECTION.
- DWELLTIME : By moving the left or right direction of the Function Setup Switch in the
‘DWELL TIME’ item to select a time between 5 and 60 seconds for the dwell
time before the zoom is returned to the ‘START ZOOM’ position.
(5,7,10,15,20,30,40,60 sec)
TipsonUsingtheMotionDetectionFeature
• The feature may not function properly under flickering light conditions.
• The camera interprets sudden changes in lighting and subsequent change in
brightness of an object as motion.
• With the feature enabled, other algorithms may require additional time to operate.
• This system does not guarantee prevention of fire or theft. The manufacturer shall not
be held responsible for any accident or damage incurred.
• Connect an external alarm device to MD Out on back of the camera.
Notes
MAIN SETUP
SSDR ON
WHITE BAL ATW
BACKLIGHT OFF
MOTION DET OFF
FOCUS
EXPOSURE
FOCUS
ZOOM/FOCUS POS SETUP
↑: TELE ↓: WIDE
←: NEAR →: FAR
- ONE PUSH : Focus is automatically adjusted just once, after
zoom position is changed. Select 'ONE PUSH'
and press the Function Setup Switch to
confirm. Increase or decrease optical zoom
(ZOOM) or digital zoom (D-ZOOM) positions
by moving the directional key of Function
Setup Switch while verifying the changes on
screen. Press the Function Setup Switch once
the desired image quality is obtained.
1. Press the Function Setup Switch to access the main setup menu and then position the
indicator over FOCUS moving the up or down direction of Function Setup Switch.
2. Press the Function Setup Switch.
MODE :You can select the most suitable zoom mode. Move the arrow indicator to
’MODE‘ by moving the up or down direction of the Function Setup Switch
FOCUS SETUP
MODE ONE-PUSH
ZOOM TRACK AUTO TRACK
ZOOM SPEED FAST
D-ZOOM OFF
ZOOM POS INIT OFF
USER PRESET OFF
LENS INIT MANUAL
RETURN

COLOR CCD CAMERA User Guide
24
COLOR CCD CAMERA User Guide
25
Operating Your Camera
ZOOM POS SETUP
↑: TELE ↓: WIDE
- AUTO : Select AUTO and press the Function Setup Switch to
confirm. Increase or decrease optical zoom (ZOOM)
or digital zoom (D-ZOOM) positions by moving the
up or down direction of the Function Setup Switch
while verifying the changes on screen. Enabling
D-ZOOM (ON) means that digital zoom will activate
once optical zoom ends. The focus automatically
adjusts when the lens zooms in and out.
- MANUAL : Select 'MANUAL' and press the Function Setup
Switch to confirm. Increase or decrease optical
zoom (ZOOM) or digital zoom (D-ZOOM)
positions moving directional key of Function
Setup Switch while verifying the changes on
screen. Press the Function Setup Switch until the
desired image quality is obtained. Focus can be
manually adjusted, independent of moving
zoom.
By moving the left or right direction of the Function Setup Switch in the ‘ZOOM’ item to select
‘AUTO TRACK’ or ‘TRACK’ and press Function Setup Switch to activate the zoom action focus
function.
- AUTO TRACK : Zooming in while deciding or adjusting the status of the focus.
- TRACK : The camera moves the focus track which is established.
- OFF : Only the zoom lens moves.
 ZOOM TRACK : Select ‘ON’ for the ‘SMART ZOOM’ item in the MOTION DETECTION menu
and press Function Setup Switch to change the settings for the ‘SMART
ZOOM’ function.
FOCUS SETUP
MODE AUTO
ZOOM TRACK AUTO TRACK
ZOOM SPEED FAST
ZOOM/FOCUS POS SETUP
↑: TELE ↓: WIDE
←: NEAR →: FAR
FOCUS SETUP
MODE AUTO
ZOOM TRACK AUTO TRACK
ZOOM SPEED FAST
D-ZOOM OFF
FOCUS SETUP
MODE AUTO
ZOOM TRACK AUTO TRACK
ZOOM SPEED FAST
D-ZOOM OFF
ZOOM POS INIT OFF
 ZOOM SPEED : Configure zoom tracing speed using this feature. Position the indicator
over 'ZOOM SPEED' by moving the up or down direction of the Function
Setup Switch and then set to desired mode by moving the left or right
direction of the Function Setup Switch
 D-ZOOM :
Configure magnification limit from x2~x16 using this feature. Position the indicator
over 'D-ZOOM' by moving the up or down direction of the Function Setup Switch
Set 'D-ZOOM' to 'ON' and press the Function Setup Switch to confirm.
- FAST :To move zoom fast.
- SLOW : To move zoom slowly.
- MEDIUM : To move zoom at medium speed.
- Set 'ZOOM LIMIT' to the desired level by moving the left or
right direction of the Function Setup Switch.
D-ZOOM LIMIT SETUP
▶LIMIT X2
RETURN
• When the DIS is enabled, you cannot use the D-ZOOM.
Notes

COLOR CCD CAMERA User Guide
26
COLOR CCD CAMERA User Guide
27
Operating Your Camera
FOCUS SETUP
MODE AUTO
ZOOM TRACK AUTO TRACK
ZOOM SPEED FAST
D-ZOOM OFF
ZOOM POS INIT OFF
USER PRESET OFF
FOCUS SETUP
MODE AUTO
ZOOM TRACK AUTO TRACK
ZOOM SPEED FAST
D-ZOOM OFF
ZOOM POS INIT OFF
USER PRESET OFF
LENS INIT MANUAL
 ZOOM POS INIT : Moves to the controlled ZOOM position when the power is truned on
and the initial ZOOM position has been set.
USER PRESET :
Preset user-designated configurations using this feature. Position the
indicator over ‘USER PRESET’ by moving the up or down direction of
the Function Setup Switch and then set to ‘ON’ by moving the left or
right direction of the Function Setup Switch. Press the Function Setup
Switch to confirm.
INIT ZOOM POS SETUP
▶POS INIT X1
RETURN
• AUTO : If you turn the power off and on, the zoom
magnification level is set to the previous level that
was set before the power went off.
• MANUAL : The zoom magnification level can be set from 1x
to 12X.
• The zoom postion is saved after 5 seconds when you set zoom function.
Notes
- PRESET NO : Up to 128 preset configurations are supported.
- SAVE : Save configured preset.
- CLEAR : Clear configured preset.
- RETURN : Revert to the FOCUS SETUP menu.
ZOOM POS SETUP
↑: TELE ↓: WIDE
1X
USER PRESET
▶ PRESET NO 1
SAVE
CLEAR
RETURN
PRESET NOT DEFINED
||||||||||||||||||||||||||
LENS INIT :
By moving the left or right direction of
the Function Setup Switch in the ‘Lens
initialization’ item select ‘Automatic’ or
‘Manual’ and then press the SET button.
- AUTO :The lens can automatically be set by a pre-selected
day, from 1-day to 7-days. This will start from when
the time is set.
- Manual :The Lens will reset when you press the Function
Setup Switch.
FOCUS SETUP
MODE AUTO
ZOOM TRACK AUTO TRACK
ZOOM SPEED FAST
D-ZOOM OFF
ZOOM POS INIT OFF
USER PRESET OFF
LENS INIT AUTO
RETURN
LENS INIT SETUP
DAY 1
RETURN

COLOR CCD CAMERA User Guide
28
COLOR CCD CAMERA User Guide
29
Operating Your Camera
MAIN SETUP
SSDR ON
WHITE BAL ATW
BACKLIGHT OFF
MOTION DET OFF
FOCUS
EXPOSURE
SPECIAL
EXPOSURE
1. Press the Function Setup Switch to access the main setup menu and then position the
indicator over 'EXPOSURE' by moving the up or down direction of the Function Setup Switch.
2. Press the Function Setup Switch to confirm.
 BR IGHTNESS : Use this feature to adjust image brightness. Position the indicator over
'BRIGHTNESS' by moving the up or down direction of the Function Setup
Switch. Then increase or decrease brightness level by moving the up or
down direction of the Function Setup Switch while verifying the changes
on screen. Set END once desired level is obtained.
 IRIS : Set 'IRIS' to 'AUTO' or 'MANUAL'. Position the indicator over 'IRIS' by moving the up
or down direction of the Function Setup Switch and then select the desired iris
mode by moving the left or right direction of the Function Setup Switch.
EXPOSURE SETUP
BRIGHTNESS 50
IRIS AUTO
||||||||||||
|
|||||||||||||
EXPOSURE SETUP
BRIGHTNESS 50
IRIS AUTO
SHUTTER ---
||||||||||||
|
|||||||||||||
- AUTO :The iris is automatically activated upon illumination.
- MANUAL : Manual iris configuration. Set 'IRIS' to 'MANUAL' by moving the left or right
direction of the Function Setup Switch and then press the Function Setup Switch. Increase or
decrease iris level by moving the left or right direction of the Function Setup Switch while verifying
the changes on screen.
IRIS AUTO SETUP
▶
OPEN LIMIT 938
CLOSE LIMIT 1
RETURN
IRIS MANUAL SETUP
▶IRIS F-No F1.6
IRIS MAN 1023
RETURN
SHUTTER MANUAL SETUP
▶SHUTTER VAL 1/50
RETURN
||||||||||||||||||||||||||
||||||||||||||||||||||||
||||||||||||||||||||||||
 SHUTTER : Control image brightness by adjusting shutter speed.
 Position the indicator over 'SHUTTER' by moving the up or down direction of the
Function Setup Switch. Then select the desired shutter mode (A.FLK, ESC, MANUAL)
by moving the up or down direction of the Function Setup Switch.
 If you choose ’MANUAL‘, select the optimal shutter
speed.
- In MANUAL mode, the optimal shutter speed needs
to be designated. Select from 1/60 to 1/120,000
(NTSC) or from 1/50 to 1/120,000 (PAL).
* 'Sens-Up' mode can be configured manually
(2x to 512x).
- Verify changes made to the shutter speed by
referencing to changes the 'on-screen' brightness.
 Press the Function Setup Switch to complete.
EXPOSURE SETUP
BRIGHTNESS 50
IRIS AUTO
SHUTTER ---
AGC HIGH
||||||||||||
|
|||||||||||||
- MANUAL : Manual shutter speed setting.
- A.FLK (NTSC: 1/100, PAL: 1/120) : Flicker-free mode.
- ESC : Automatic shutter speed setting (optimal).
Auto operation is possible only when the IRIS is set to MANUAL.

COLOR CCD CAMERA User Guide
30
COLOR CCD CAMERA User Guide
31
Operating Your Camera
GAIN MANUAL SETUP
▶AGC VAL 5dB
RETURN
SSNR3 LEVEL SETUP
▶LEVEL 12
RETURN
• Image may become unstable if the camera is set to 'ESC' mode and faces a strong
fluorescent light.
• Under 'ESC' mode, the brightness can be adjusted by moving the left or right direction
of the Function Setup Switch.
Notes
 AGC (Auto Gain Control) : For brighter images.
 Position the indicator over 'AGC' by moving the up or down direction of the Function
Setup Switch.
 Set 'AGC' to the desired mode by moving the left or right direction of the Function
Setup Switch.
- HIGH : Wide range gain value adjustment
- MANUAL : Selecting gain value range. (5dB ~ 41dB)
- OFF : Disabled
- LOW : Narrow range gain value adjustment
- MEDIUM : MEDIUM range gain value adjustment
 SSNR3(Samsung Super Noise Reduction) : On screen noise reduction.
 Position the indicator over 'SSNR3' by moving the up or down direction of the
Function Setup Switch.
 Set 'SSNR3' to the desired mode by moving the left or
right direction of the Function Setup Switch.
- OFF : Disabled
EXPOSURE SETUP
BRIGHTNESS 50
IRIS AUTO
SHUTTER ---
AGC HIGH
SSNR3 ON
||||||||||||
|
|||||||||||||
||||||||||||||||||||||||
• Changing the 'AGC' setting from LOW to HIGH results in greater sensitivity, as well as
on screen noise.
• Setting 'AGC' to OFF locks 'SSNR3' configuration.
Notes
SENS-UP : This feature ensures clear images at night or under low light conditions.
 Position the indicator over 'SENS-UP' by moving the up
or down direction of the Function Setup Switch.
 Set 'SENS-UP' to the desired mode by moving the left
or right direction of the Function Setup Switch.
- AUTO : Select this mode for use in night time or under
low light conditions.
- OFF : Disabled
SENS-UP LIMIT SETUP
▶LIMIT X2
RETURN
• Once 'AUTO' mode is set, the user can configure the SENS-UP limit by increasing/
decreasing the shutter speed (e.g.: X2, X4....... X32, X64, X128, X256, X512).
• Enabling Sens-Up increases camera sensitivity and may result in additional noise and/
or other phenomenons. This is normal.
Notes
SPECIAL
MAIN SETUP
SSDR ON
WHITE BAL ATW
BACKLIGHT OFF
MOTION DET OFF
FOCUS
EXPOSURE
SPECIAL
RESET

COLOR CCD CAMERA User Guide
32
COLOR CCD CAMERA User Guide
33
SPECIAL SETUP
PRIVACY ON
DAY/NIGHT AUTO
1. Press the Function Setup Switch to access the main setup menu and then position the
indicator over 'SPECIAL' by moving the up or down direction of the Function Setup Switch.
2. Press the Function Setup Switch to confirm.
 PRIVACY : Hide an area you want to hide on the screen.
 When the SPECIAL menu screen is displayed, by
moving the up or down direction of the Function Setup
Switch so that the arrow indicates ‘PRIVACY’.
 Set up the mode using the 4 direction buttons.
- AREA SEL : You can select up to 12 MD areas.
- AREA MODE : Determines whether to use the area selected in the AREA SEL.
- MASK COLOR : Determine area color. You can select Green, Red, Blue, Black, White,
Gray.
PRIVACY SETUP
▶AREA SEL AREA1
AREA MODE ON
MASK COLOR GRAY
TOP 39
BOTTOM 79
LEFT 14
RIGHT 53
RETURN
|||||
|
|||||||||||||||||||
|||||||
|
|||||||||||||||||
|
|||||||||||||||||||||||||
|||||
|
|||||||||||||||||||
Operating Your Camera
SPECIAL SETUP
PRIVACY OFF
DAY/NIGHT AUTO
DIS OFF
 DAY/NIGHT : You can display pictures in color or black and white.
 When the SETUP menu screen is displayed, select ‘DAY/NIGHT’ by moving the up or
down direction of the Function Setup Switch so that the arrow indicates 'DAY/NIGHT'.
 Select a desired mode by moving the left or right direction of the Function Setup
Switch according to the picture display you want.
• DWELL TIME : You can select tday/night switching delay time from.
 5,7,10,15,20,30,40, 60(sec)
• DURATION : You can select the day/night switching point(lux).
AUTO SETUP
IR MODE MANUAL
▶COLORB/W -
DWELL TIME 5 SEC
DURATION SLOW
B/WCOLOR -
DWELL TIME 5 SEC
DURATION SLOW
RETURN
BURST MODE SETUP
▶BURST MODE ON
IR MODE MANUAL
RETURN
 When AGC is middle mode.
Color → B/W B/W →Color
Fast 0.7lux 5lux
Slow 1lux 3lux
BURST LEVEL SETUP
▶BURST LEVEL 50
RETURN
|||||||||||||||||||||||
- AUTO : The mode is switched to 'Color' in a normal
environment, but switches to 'B/W' mode
when ambient illumination is low. To set up
the switching time or speed for AUTO mode,
press the Function Setup Switch.
· IR MODE AUTO : The IR LED is controlled automatically
according to brightness of object
which is situated on screen center.
· MANUAL : You can control WIDE LED and NARROW
LED step from 0 to 32.
· OFF : Disabled.
*LED ON : Only B/W mode.
IR LEVEL SETUP
▶WIDE 32
NARROW 32
RETURN
IR LEVEL SETUP
▶WIDE 32
NARROW 32
RETURN
- COLOR : The picture is always displayed in color.
- B/W : The picture is always displayed in black and
white.

COLOR CCD CAMERA User Guide
34
COLOR CCD CAMERA User Guide
35
Operating Your Camera
SPECIAL SETUP
PRIVACY OFF
DAY/NIGHT AUTO
DIS OFF
• When using a Video Auto Iris Lens, if you set the lens level to low, automatic switching
between Color and Black & White may not occur.
• You cannot control the DAY/NIGHT menu when AGC in the EXPOSURE menu is ‘OFF’.
At this time, the exchange between DAY mode and NIGHT mode operates as like
selecting ‘COLOR’ mode.
• The OSD key does not work for 3 seconds when switching to Color or B/W, to ensure
stable camera operation.
• The camera may focus less well under infrared illumination than under normal
illumination.
• Since the camera may not focus as well under infrared illumination at night as it does
under normal illumination, install an Extra-low Dispersion Lens to obtain sharp
pictures.
• The brightness of illumination is changeable by installed environment.
Notes
DIS : The DIS mode can compensate for vibration of the camera.
• When DIS is operating, D-ZOOM does not operate.
Notes
 SYNC : Two synchronization modes are available INTERNAL and EXTERNAL LINE-LOCK.
In LINE-LOCK mode, it synchronizes the camera's video out signal to the external
SYNC signal.
SPECIAL SETUP
PRIVACY OFF
DAY/NIGHT COLOR
DIS OFF
SYNC INT
 COMM ADJ (Communication Adjustment) :
This function sets up the camera communication status
when controlling the camera through an external
controlled device.
 When the SPECIAL menu screen is displayed, by
moving the up or down direction of the Function Setup
Switch so that the arrow indicates ‘COMM ADJ’.
 Set up the mode moving the 4 direction of Function Setup Switch.
COMMUNICATION SETUP
▶PROTOCOL SAMSUNG-T
CAM ID 1
BAUD RATE 9600
UART MODE 8-N-1
RET PKT DISABLE
RETURN
||||||||||||||||||||||||||
- CAM ID : Determines the camera's identification number (between 0 and 255).
- Protocol : Select the communication PROTOCOL. (SAMSUNG-T/SAMSUNG-E,
PELCO-D/PELCO-P/BOSCH/HONEYWELL/VICON/AD/PANASONIC)
- BAUD RATE : You can select 2400/4800/9600/19200/38400/57600 bps.
- UART MODE : You can select NONE, EVEN or ODD for the parity bits.
• INT : Internal synchronization
• LL : External line-lock synchronization
· If you choose 'LL', you can adjust the desired phase.
Press the SET button.
· You can adjust the desired phase from 0 to 359.

COLOR CCD CAMERA User Guide
36
COLOR CCD CAMERA User Guide
37
 IMAGE ADJ : Includes image quality or special function factors.
- RET PKT : You can choose whether to send an ACK signal when the communication
control command is issued to the camera.
SPECIAL SETUP
PRIVACY OFF
DAY/NIGHT AUTO
DIS OFF
SYNC INT
COMM ADJ
IMAGE ADJ
MONITOR CRT
 When the SETUP menu screen is displayed, select ‘IMAGE ADJ.’ by moving the up or
down direction of the Function Setup Switch so that the arrow indicates 'IMAGE ADJ.
 Select a desired mode by moving the up or down direction of the Function Setup
Switch.
- H-REV : You can flip the picture horizontally on the
screen.
- V-REV :You can flip the picture vertically on the screen.
IMAGE SETUP
▶H-REV OFF
V-REV OFF
SHARPNESS ON
RETURN
SHARPNESS SETUP
▶LEVEL 16
RETURN
||||||||||||||||||||||||||
Operating Your Camera
- LCD : Please select this menu item when using an LCD
monitor.
LCD MONITOR SETUP
▶GAMMA 0.45
PED LEVEL 17
COLOR LEVEL 50
RETURN
||||||||||||||||||||||||||
|||||||||||||||||||||||
- CRT : Please select this menu item when using a CRT
monitor.
CRT MONITOR SETUP
▶PED LEVEL 17
COLOR LEVEL 50
RETURN
||||||||||||||||||||||||||
|||||||||||||||||||||||
Monitor : Please change the settings value of video appropriate to your monitor.
SPECIAL SETUP
PRIVACY OFF
DAY/NIGHT AUTO
DIS OFF
SYNC INT
COMM ADJ
IMAGE ADJ
MONITOR CRT
DISPLAY
- USER : Please use this menu item when using a monitor
other than standard ones. You can change the
gamma, PED level, and color gain in the sub
menus.
USER MONITOR SETUP
▶GAMMA 0.55
PED LEVEL 17
COLOR LEVEL 50
RETURN
||||||||||||||||||||||||||
|||||||||||||||||||||||
- SHARPNESS : As you increase this value, the picture
outline becomes stronger and clearer.
• If use the sharpness level overly, the image comes out affectedly or appears image noise.
Notes

COLOR CCD CAMERA User Guide
38
COLOR CCD CAMERA User Guide
39
 DISPLAY : Us e this feature to designate a name for the camera, which will display on the
monitor screen
SPECIAL SETUP
PRIVACY OFF
DAY/NIGHT AUTO
DIS OFF
SYNC INT
COMM ADJ
IMAGE ADJ
MONITOR CRT
DISPLAY
RETURN
 CAM TITLE
 Press the Function Setup Switch to display the main setup menu and move the arrow
indicator to ‘CAM TITLE’ by moving the up or down direction of the Function Setup
Switch.
 Set ‘CAM TITLE’ to ‘ON’ by moving the left or right direction of the Function Setup
Switch.
 Press Function Setup Switch.
• If the CAM TITLE feature is set to ‘OFF’, the name will not
displayed in the monitor
Notes
DISPLAY SETUP
▶
CAM TITLE OFF
CAM ID ON
CAM INFO ON
MOTION ALARM OFF
ZOOM MAG ON
FONT COLOR WHITE
LANGUAGE ENGLISH
RETURN
CAMERA TITLE SETUP
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcdefghijklm
nopqrstuvwxyz
-. 0123456789
←→ CLR POS END
Operating Your Camera
 You can enter up to 15 characters.
a. Move the cursor to the character entry field moving left or right direction of
Function Setup Switch.
b. Use the 4 direction of Function Setup Switch to select a desired character.
c. Press the Function Setup Switch to confirm the selection of the blinking character.
The character is then saved, and the cursor in the entry field moves to the next
position.
d. Repeat steps 'a' through 'c' until the desired name has been entered.
 You can use only English character.
 Enter a title, move the cursor to ‘POS’ and press the
Function Setup Switch. The entered title appears on
the screen. Select the position to display the title on
the screen by moving the 4 direction of Function
Setup Switch and press the Function Setup Switch.
When the position is determined, select.
• Correcting Mistakes
Move the cursor th ‘CLR’ and press the Function Setup Switch to clear the entire entry.
To modify one character, use 'LEFT' or 'RIGHT' to position the cursor above the character
to be modified and click the Function Setup Switch after selecting the character to enter.
Notes
FRONT DOOR
- CAM ID : Displays camera ID on top left corner of the screen.
- CAM INFO : Displays camera information on screen.
- MOTION ALARM : You can toggle the use of the camera alarm.
- ZOOM MAG : Use th is feature to display the current zoom magnification level on
screen. Position the indicator over ‘ZOOM MAG’ by moving the up or
down direction of the Function Setup Switch. Then set to ON by moving
the left or right direction of the Function Setup Switch.
- FONT COLOR : You can select the font color. (white,yellow,green,red,blue)
- LANGUAGE : You can select the menu language according to your requirements
(Korean, Spanish, French, Italian, German, English, Japanese, Chinese,
Russian, Czech, Polish, Portuguese, Taiwanese, Romanian, Serbian,
Swedish, Danish, Turkish)
- END : Select this to save the SPECIAL menu settings and return to the SPECIAL menu.
