Samsung SDC-7340BC User manual

www.samsungsv.com
FIRST EDITION 01-2014
• 720TV lines of high resolution (SDC-7340BCN)
• True Day & Night with ICR for perfect color reproduction
• IP66 weather resistant rating
• Night vision up to 82ft
Weather-resistant
High Resolution Bullet Camera
960H Accessory Camera
SDC-7340BC
960H Weatherproof IR Camera

Design and specifications are subject to change without notice.
960H Weatherproof IR Camera
SDC-7340BC
SAMSUNG TECHWIN CO., LTD.
6, Pangyo-ro 319beon-gil, Bundang-gu, Seongnam-si, Gyeonggi-do, SEOUL 463-400 Rep. of KOREA
Tel : [phone]~8749, 8752~8760 Fax : [phone] www.samsungsecurity.com www.samsungcctv.com
COPYRIGHT BY SAMSUNG TECHWIN. ALL RIGHT RESERVED
SAMSUNG TECHWIN EUROPE LTD.
2nd Floor, No. 5 The Heights, Brooklands, Weybridge,
Surrey, KT13 0NY, UK
Tel : [phone] Fax : [phone]
SHANGHAI SAMSUNG TECHWIN CO., LTD.
32F, Blk B, International Business Center,
No. 391 Guiping Rd., Shanghai, China, 200233
Tel : [phone] Fax : [phone]
SAMSUNG TECHWIN AMERICA Inc.
100 Challenger Rd. Suite 700 Ridgefield Park, NJ 07660
Toll Free : [phone] Direct : [phone]
Fax : [phone]
The Eco mark represents
Samsung Techwin’s will to create
environment-friendly products,
and indicates that the product
satisfies the EU RoHS Directive.
Kit Contents
• Camera (SDC-7340BC) 1pcs
• 60ft BNC Cable 1pcs
• Plastic Achors / Screws
• User Manual
SDC-7340BCN SDC-7340BCP
VIDEO
Imaging Device 1/3" 960H CMOS
Effective Pixels 976(H) x 494(V) 976(H) x 582(V)
Scanning System Interlace
Frequency H : 15.734KHz / V : 59.94Hz
Horizontal Resolution 720TV lines 700TV lines
Min. Illumination Color : 7Lux
B/W : 0Lux (IR LED on)
S / N Ratio 46dB
Min. Cable Length 60ft (18.3m) included
LENS
Focal Length 3.8mm
Max. Aperture Ratio F2.0
Angular Field of View H : 75˚ / V : 66˚ / D : 80˚
OPERATIONAL
Shutter Mode Auto (Rolling shutter)
Gain Control Auto
White Balance Auto (1,800°K ~ 10,500°K)
Digital Noise Reduction Auto
Day & Night Mechanical : Auto (ICR)
IR Distance (850nm) 25m (82ft)
ENVIRONMENTAL
Operating Temperature / Humidity -10°C ~ +50°C (+14°F ~+122°F) / 20% ~ 85%RH
Storage Temperature / Humidity -20°C ~ +60°C (+4°F ~+140°F) / 20% ~ 85%RH
Ingress Protection IP66 grade
ELECTRICAL
Input Voltage 12V DC
Power Consumption Max. 3W
MECHANICAL
Color / Material White gray / Plastic (Poly carbonite)
Dimensions (WxHxD) 72.1 x 62.9 x 192.4mm (2.84" x 2.48" x 7.57")
Weight 252g (0.56 lb)
Dimensions
Unit : mm (inch)
192.4 (7.57")
72.1 (2.84")
62.9 (2.48")
64.0 (2.52")
124.2 (4.89")
192.4 (7.57")
124.2 (4.89")
64.0 (2.52")
72.1 (2.84")
62.9 (2.48")
