Super Vision at Ultra Low Light SHC-737 User’s Manual
Thank you for purchasing a SAMSUNG CCD CAMERA.
Before attempting to connect or operate this product,
please read these instructions carefully and save this manual for future use.
ENGLISH

This installation should be made by a qualified service person and
should conform to all local codes.
The lightning flash with an arrowhead symbol, within an equilateral triangle is
intended to alert the user to the presence of uninsulated “dangerous voltage”
within the product's enclosure that may be of sufficient magnitude to constitute
a risk of electric shock to persons.
The exclamation point within an equilateral triangle is intended to alert the user
to the presence of important operating and maintenance (servicing) instructions
in the literature accompanying the appliance.
This equipment has been tested and found to comply with limits for a Class A
digital device, pursuant to part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the
equipment is operated in a commercial environment. This equipment
generates, uses, and can radiate radio frequency energy and, if not installed
and used in accordance with the instruction manual, may cause harmful
interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful
interference in which case the user will be required to correct the interference
at his own expense.
WARNING - Changes or modifications not expressly approved by the
manufacturer could void the user’s authority to operate the
equipment.
WARNING - To prevent electric shock and risk of fire hazards:
◆ Do NOT use power sources other than that specified.
◆ Do NOT expose this appliance to rain or moisture.
Before operating the camera, confirm the camera model and proper input power
voltage. In order to that you can understand this manual thoroughly, we'll introduce our
model description.
n SHC-737 SERIES
 •NTSCMODELS •PALMODELS
  SHC-737N  SHC-737P
nMODEL DESCRIPTION
 •SHC-737X
_
 •SIGNALSYSTEM
  NNTSCMODEL
  PPALMODEL
SIGNALSYSTEM

COLOR CCD CAMERA User’s Manual
4
COLOR CCD CAMERA User’s Manual
5
Contents
Contents
• Features ………………………………………………………………………… 5
• Precautions …………………………………………………………………… 7
• Components and Accessories …………………………………………… 8
• Overview ………………………………………………………………………… 9
nFront View
 

n
SideView 
n Bottom View 
n Rear View 
• Installation Procedures …………………………………………………… 12
nLens
 
  WhenUsingAutoIrisLens  
  WhenUsingC/CSMountLens  
nConnectingtoaMonitor
  

nConnectingtoPower
 
nControlviaRS-485Interface
  
• How to Use the Camera …………………………………………………… 18
nFunctionMenuStructure
 
nHowtoSetuptheFunctions
  
  LENS  
  EXPOSURE  
  WHITEBALANCE   
  BACKLIGHT  
  SSNR  
  DAY/NIGHT  
  IMAGEADJ  
  SPECIAL   
  EXIT   
• Troubleshooting …………………………………………………………… 36
• Specifications ………………………………………………………………… 37
Features
Excellent Sensitivity
Byadoptingadiagonal6mm(1/3")highlysenstiveCCD,
and digital signal processing technology, it can clearly
distinguish the outline and color of a subject in an
extremely low luminance environment – even, for
example,understarlight.Sincesurveillanceispossible
in places where the light is poor, the camera is
appropriate for day and night surveillance outdoors or
on the outside of buildings.
-Color:0.05Lux(50IRE,F1.2)
 0.0002Lux(F1.2,SENS-UP)
-B/W:0.0025Lux(50IRE,F1.2)
 0.00001Lux(F1.2,SENS-UP)
Day & Night
The camera identifies whether it is day or night and
automatically switches to the appropriate mode,
depending on its environment. By day, the camera
switches to color mode in order to maintain optimal
color.Atnight,itswitchestoB/Wmodesoastoobtain
better picture definition.
Motion Detection
Sincethecameradetectsmotionandgenerates
signals without any additional external sensors, you
can monitor activity more efficiently by connecting the
camera to an alarm device.
DIS (Digital Image Stabilizer)
TheDISfunctioncompensatesforanycamera
movement, to produce more stable pictures.
Video/DC Drive Lens Support
YoucanselectVideoorDCDriveLensfromthemenu.
Miscellaneous Functions
HLC(High Light Compensation), SYNC (INT/LL), SENS-
UP,FLIP(H/V-REV),D-ZOOM,SHARPNESS,MOTION
DETECTIONandPRIVACYMASKINGfunctionsare
provided.
RS-485 Communication
Control Support
RemoteOSDmenucontrolviaanRS-485interfaceis
supported.
OSD
Thecameracontrolisconvenientbyusing8different
foreignlanguageO.S.D.
-NTSC:Korea,English,Spanish,Japanese,French
-PAL:English,French,German,Spanish,Italian,
Chinese
BLC
Byadoptinga proprietarySV-IV DSPchip, thecamera
delivers clear, high quality pictures even in backlight, by
increasing exposure in dark areas while decreasing it in
bright areas; a corrected image with clear details
results.
SSNR (Samsung Super Noise
Reduction) Function
ThehighperformanceSV-IVDSPchipdramatically
reduces the gain noise in digital image processing,
producing clear, sharp images in low lighting
environments.
Ultra High Resolution
Byadoptingadiagonal6mm(1/3") 410,000pixel
ExView Sony CCD, the camera produces clear picture
quality with a horizontal resolution of 580 TV lines for
color,and700TVlinesforB/W.

COLOR CCD CAMERA User’s Manual
6
COLOR CCD CAMERA User’s Manual
7
SamsungTechwincaresfortheenvironmentatallproductmanufacturing
stages to preserve the environment, and is taking a number of steps to provide
customerswithmoreenvironment-friendlyproducts.TheEcomarkrepresents
SamsungTechwin'swilltocreateenvironment-friendlyproducts,andindicates
thattheproductsatisfiestheEURoHSDirective.
This information is provided to ensure your safety and to prevent any losses, financial or
otherwise.Pleasereaditcarefullyandusetheproductaccordingly.
* For product inquiries, please contact the retail shop where you bought the camera. The use of equipment such as
anaerialladderwhileprovidingafter-salesserviceshallbeatyourexpense.
 *Separatethepowerplugwhenthundercrashesorlightingflashes.
 *Thisproductissupportequipmentforsurveillancesystem.Therefore,wecan'tcompensateformateriallossand/or
personal injuries by robbery, fire, natural disaster or something like this type.
Ignoring this information may
resultinmateriallossand/or
serious personal injuries including
death.
Indicates"NeverAllowed."
Ignoring this information may
resultinmateriallossand/ora
slight injuries.
Indicates"NoDisassembling."
Warnings & Cautions
Warning/Attention/Special Mark Messages
Precautions
Do not install under extreme
temperature conditions.
Do not install in high humidity
environment.
Do not install under unstable
lighting conditions.
The lens is the most important component of
the camera. Be careful not to smear it with
fingerprints.
Severe lighting changes or flickering may hinder
normal camera operation.
May lower image quality.Use only under temperature conditions between
-10ºC and +50ºC. Provide good ventilation when
using in high temperature conditions.
Avoid touching the camera lens.
Do not drop the camera or subject
it to physical shock.
May damage the CCD.May cause a product malfunction.
Never keep the camera face to
strong light directly.

COLOR CCD CAMERA User’s Manual
8
COLOR CCD CAMERA User’s Manual
9
•Exposuretoaspotlightoranobjectemittingstronglightmaycausesmearorblooming.
•Ensurethatthepowersourcecomplieswithnormalspecificationsbeforesupplyingitto
the camera.
Notes
Precautions
Do not expose the camera to rain
or other types of liquids.
Radioactivity exposure may damage the CCD.May cause a product malfunction.Wipe dry any
liquids. Liquids may contain minerals that are
corrosive to electronic components.
Do not expose the camera to
radioactivity.
Components and Accessories
1Ultra Low Light Color CCD Camera SHC-737 2Instruction Manual
3Auto Iris Lens Connector Plug 4C-Mount Adapter
1 2 3 4
Overview
3
2
❶
Front View
1
Tripod Mounting Bracket Screw Hole
Used to fix the Tripod Mounting Bracket to the top of the camera.
2
C-Mount Lens Adapter
Install this adapter to use a C-Mount Lens.
3
Back Focus Control Lever
Adjust focus by this Back Focus Lever.
4
Auto Iris Lens Connector
Used to connect Auto Iris Lens plug.
4
Side View

COLOR CCD CAMERA User’s Manual
10
COLOR CCD CAMERA User’s Manual
11
5
Bottom View
1/4"-20UNC(20THREAD)
L:4.5mm±0.2mm(ISOstandard),
or0.197"(ASAstandard)
5
Tripod Mounting Bracket Screw Hole
Used to fix the camera on a bracket or tripod.
The screw sizes for this hole are as follows:
6
Function Setup Button
• SET Button : Displays the menu on the screen. Press this button to confirm status or
after changing a selected item.
• Up and Down Button : Used to move the cursor up or down in the menu screen to
select a desired menu item.
• Left and Right Button : Used to move the cursor left or right in the menu screen or to
change the value of the selected item.
7
D & N Input Port
You can switch to Day & Night Mode by connecting an external signal to this port.
8
MD Output Port
Motion detection signals are output through this port.
9
RS-485 Control Port
You can control SETUP MENU through this port by using external controllers like a Remote
controller that RS-485 Communication is supported. For details, see page 16.
❿
Video OUT Port
Video signals are output through this port. Connect this port to the Video IN port of a
monitor.
⓫
Power LED
When power is properly connected, this LED comes on.
⓬
Power Input Terminal
Connect the power as specified for each model here.
You can separate the Tripod Mounting Bracket and install it on the
top or bottom of the camera. Make sure to use the Tripod
Mounting Bracket when fixing the camera to a bracket or tripod.
Otherwise the camera may not be secure, or the internal circuitry of
the camera may be damaged.
OverviewOverview
❿
⓫
⓬
6
7
8
9
Rear View

COLOR CCD CAMERA User’s Manual
12
COLOR CCD CAMERA User’s Manual
13
Installation Procedures Installation Procedures
Lens
•ItisrecommendedtousetheDCtypeAutoIrisLenstoeffectivelyenjoythemajor
functions of this camera.
•Keepthelens surfaceclean,sinceifit iscontaminatedwith dirtorfingerprints the
picture quality suffers.
Notes
The lens is not supplied with this camera. Purchase a lens suitable for your
environment. This camera accepts the auto iris lens and both C-and CS-mount
lens.
1. Strip the insulation of the auto iris lens cable 8mm from the end.
2. Strip the insulation of the core of the auto iris lens cable to expose a 2mm length.
When Using Auto Iris Lens
approx. 8mm
approx. 2mm
3. Remove the cover of the auto iris lens connector plug and solder the lens cable to
the connector pin of the plug.
4. Fit the cover of the auto iris lens connector
plug, remove the protective glass cover
from the front of the camera, and fasten
the auto iris lens by turning it clockwise.
• For a Video Drive Lens
Pin 1: Red (Power)
Pin 2: NC
Pin 3: White (Video Signal)
Pin 4: Black (Ground)
• For a DC Drive Lens
Pin 1: Damping -
Pin 2: Damping +
Pin 3: Drive +
Pin 4: Drive -
5. Set focus of camera using Back Focus Control
Lever of camera side after combining Auto
Iris lens.
Back Focus Control Lever
No. 3 Pin
No. 1 Pin
connector
Lens cable
No. 4 Pin
No. 2 Pin

COLOR CCD CAMERA User’s Manual
14
COLOR CCD CAMERA User’s Manual
15
Installation Procedures
Before installing a lens, identify whether the lens to be installed is a C-Mount or CS-Mount.
This camera is set for a CS-Mount Lens by default. To install a C-Mount Lens, a
simple modification is required.
When Using C/CS Mount Lens
•Usethelensconnectorshowninthefollowingfigure.Ifthedimensionsoftheconnector
are not correct, it may damage the camera, or the lens may not be installed firmly.
•Ifthelensistooheavy,thecamerabecomesunbalancedand
there may be problems. Use a lens that weighs less than
450g.
•WhenadjustingtheAutomaticLevelControl(ALC)ofanauto
irislens,useAvmodeifavailable.IfyouusethePkmode,the
picture brightness may change continuously.
Notes
C-MountLens:10mmorless
CS-MountLens:5mmorless
• When Using a CS Mount Lens
Remove the protective glass cover at the
front of this product and turn the CS-Mount
Lens clockwise to install it. And set focus of
camera using Back Focus Control Lever of
camera side after combining CS-Mount lens.
• When Using a C Mount Lens
1. Remove the protective glass cover at the
front of this product and turn the C-Mount
Adapter clockwise to install it.
2. Turn the C-Mount lens clockwise to install
it.
3. Set focus of camera using Back Focus
Control Lever of camera side after
combining C-Mount lens.
Installation Procedures
Connecting to Monitor
Connect the Video OUT port on the rear panel of the camera to a monitor.
• Since the connection procedure may differ depending on the type of monitor or
peripheral device to be connected, refer to the User Manual for the device to be
connected.
• Make sure to turn off the device to be connected before making any connections.
• Turn the 75Ω/Hi-Z switches of interim display devices to the Hi-Z position, and the
switches of any final device to the 75Ωposition.
CCD Camera
CCD Camera
Intermediate End monitor
Monitor

COLOR CCD CAMERA User’s Manual
16
COLOR CCD CAMERA User’s Manual
17
Installation Procedures
Connecting to Power
Control via RS-485 Interface
Since power specifications differ depending on the model, make sure to check your
model name and specifications before connecting power.
You can connect power as shown in the following figure.
For AC / DC power
• Since the power specification supports
both AC and DC, connect AC 24V,
500mA Adaptor or DC 12V, 500mA
Adaptor.
• As shown in the table above, voltage decreases as the wire gets longer.
Therefore use of an excessively long adaptor output line for connection to the
camera may affect the performance of the camera.
 Standardvoltageforcameraoperation:DC12V±10%,AC24V±10%
 There may be some deviation in voltage drop depending on the type of wire and the manufacturer.
Whentheresistancevalueofcopperwireisat[20°C(68°F)]
Copper wire size (AWG) #24(0.22mm2)#22(0.33mm2)#20(0.52mm2)#18(0.83mm2)
Resistance (Ω/m) 0.078 0.050 0.030 0.018
Voltage Drop (V/m) 0.028 0.018 0.011 0.006
RS-485 converter.
Example) PC Serial Port (COM1)  Serial Cable  RS-485 Converter  Camera
RS-485 Control Port
The camera can be controlled by using external controllers like a Remote controller.
(RS-485 Communication)
(1) To control by PC
Connect the RS-485 control port of the camera and the serial cable through an
* RS-485 Communication establishment initial value
•To control the camera by constructing an additional controller, use Pelco-D protocol or
STWprotocol(SamsungTechwinprotocol).
•YoucanuseSystemControllersuchasSCC-101orSCC-3100AthroughRS-485
communication.
Notes
485 Control Board Connection Port RS-485 Control Port
(+) CONNECTION TERMINAL (TRX+) 485+
(-) CONNECTION TERMINAL (TRX-) 485-
Item Camera ID BAUD RATE UART MODE RET PKT
Initial value 19600 8-NONE-1 ENABLE
Installation Procedures

COLOR CCD CAMERA User’s Manual
18
COLOR CCD CAMERA User’s Manual
19
You can set up functions using the 5 buttons on the rear of the camera.
UP button
SET button
LEFT button
DOWN button
RIGHT button
How to Use the Camera
1. Press the SET button.
• Main setup menu is displayed on the monitor screen.
2. Select a desired function using the Up and Down buttons.
• Place the cursor over a desired item.
3. Set up a selected item by using the Left and Right buttons.
4. To finish the setting, select ‘EXIT’ and press the SET button.
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
6.DAY/NIGHT AUTO
7.IMAGE ADJ
8.SPECIAL
9.EXIT
Selectthefunctionusing
theUPorDOWNbutton.
Changethestatus
usingtheLEFTor
RIGHTbutton.
•Anitemwiththe icon also has sub menus. To select a sub menu, select an item with the icon
andpresstheFunctionSetupswitch.
•Anitemwiththe---iconisunavailableduetofunctionsettings.
Notes
How to Use the Camera
How to Set up the Functions
Setup Menu
LENS SHADE
 DC  VIDEO  MANUAL
EXPOSURE
 SHUTTER  AGC  SENS-UP
 RETURN
WHITE BALANCE
 ATW  MANUAL  AWC → SET
 OUTDOOR  INDOOR
BACKLIGHT
 OFF  BLC  HLC
SSNR
 ON  OFF
DAY/NIGHT
 COLOR  B/W  AUTO
 EXTERN
IMAGE ADJUSTMENT
(IMAGE ADJ.)
 V-REV  H-REV  D-ZOOM
 SHARPNESS  RETURN
SPECIAL
 CAMTITLE  SYNC  MOTION DET
 PRIVACY  DIS  COMM ADJ
 LANGUAGE  RESET  RETURN
EXIT
Function Menu Structure

COLOR CCD CAMERA User’s Manual
20
COLOR CCD CAMERA User’s Manual
21
How to Use the Camera How to Use the Camera
EXPOSURE
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
1. When the SETUP menu screen is displayed, select
EXPOSUREby using the Up and Down buttons
so that the arrow indicatesEXPOSURE.
2. Select a desired mode using the Up and Down
buttons.
 
SHUTTER : You can select either auto or manual shutter.
- A.FLK : Select this when you experience picture flicker, which can happen when
there is a clash with the frequency of the installed lighting.
- ESC : Select this to control the shutter speed automatically. If ESC is selected,
the shutter speed is automatically controlled depending on the ambient
illumination of the subject.
- MANUAL : You can control shutter speed manually.
•WhenyouuseDClens,settheshuttermodetofixed(---)ifColorRollingisoccurred.
•WhentheSHUTTERissettoESCafterselectingtheInternalSynchronizationType,the
picture may become unstable if the camera faces a bright fluorescent light. Therefore,
take care when choosing the installation position.
•WhentheSHUTTERissettoMANUALorA.FLKmode,SENS-UPwillbedisabled.
Notes
MAIN SETUP
1.LENS DC
2.EXPOSURE
Using this function, you can control screen brightness.
1. When the SETUP menu screen is displayed, selectLENSby using the Up and
Down buttons so that the arrow indicatesLENS.
2. Select the connected lens type by using the Left and Right buttons.
LENS
 
DC/Video : Select Auto Iris Lens
• When DC is selected, you can control screen
brightness. The range of brightness control is
between 1 and 70. Adjust the brightness
appropriately for optimal screen brightness.
 
Manual : Select Manual Lens
•WhenyouuseDClens,settheshuttermodetofixed(---)ifColorRollingisoccurred.
•Somelensesmaynotworkproperly,dependingonthesettingoftheBRIGHTNESSLEVEL.
•WhenUsingaVideo-TypeAutoIrisLens
1AdjusttheALCadjustmentterminalon thelensappropriately.Ingeneral,setittoAV
(Average).
2Itmaynotworkproperlydependingontheinstalledlens.SettheLevelVRofthelens
to the optimal value.
3Set AGC to OFF and adjust the Lens VR to an appropriate brightness.
4
AdjusttheLensVR,adjusttheBRIGHTNESS,andthencheckifthescreenbrightnesschanges
properly.Otherwise,adjusttheLensVRagain.
Notes

COLOR CCD CAMERA User’s Manual
22
COLOR CCD CAMERA User’s Manual
23
Use the White Balance function to adjust the screen color.
1. When the SETUP menu screen is displayed, selectWhite Bal.by using the Up
and Down buttons so that the arrow indicatesWhite Bal..
2. Select a desired mode using the Up and Down buttons.
White Balance (White Bal.)
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
 Select one of the following 5 modes, as appropriate for your purpose.
 
ATW : Select this when the color temperature is between 1,700°K and
11,000°K.
 
INDOOR : Select this when the color temperature is between 4,500°K and
8,500°K.
 
OUTDOOR : Select this when the color temperature is between 1,700°K and
11,000°K. (sodium light inclusion)
 
AWC→SET : To find the optimal setting for the current luminance
environment in this mode, set the point the camera towards a
sheet of white paper and press the SET button. If the
environment changes, readjust it.
 
MANUAL : Select this to fine-tune White Balance manually. Set White Balance
first by using the ATW or AWC mode.After that switch to MANUAL
mode, fine-tune the White Balance and then press the SET button.
How to Use the Camera How to Use the Camera
 
AGC (AUTO GAIN CONTROL) :
The higher the gain level, the brighter the screen - but the higher the noise.
- OFF : Deactivates the AGC function.
- LOW : Allows automatic gain control from 0 to 30dB.
- HIGH : Allows automatic gain control from 0 to 42dB.
 
RETURN :
Select this to save the changes in the EXPOSURE menu and return to the
SETUP menu.
 
SENS-UP : When it is night or dark, the camera
automatically detects the light level
and maintains a clear picture if this
mode is activated.
- OFF : Deactivates the SENS-UP function.
- AUTO : Activates the SENS-UP function.
•IfyoupresstheSETbuttonin‘AUTO’mode,Youcanadjustbrightnessbyincreasingor
decreasingtheshutterspeed.(x2~x512)
•Notethatthehigherthezoomlevel,thebrighterthescreen,butthemorelikelyitisthat
anafter-imagewillappear.
•AlthoughNoise,Spots,andWhitishsymptomsmayoccurinSENS-UPoperationwhenthe
zoom level is increased, this is normal.
Notes

COLOR CCD CAMERA User’s Manual
24
COLOR CCD CAMERA User’s Manual
25
How to Use the Camera How to Use the Camera
 
HLC (High Light Compensation) :
If there is a high light installed in a limited environment such as an apartment
parking garage or gas station entrance, removing the high light makes it
possible to view car license plates efficiently.
- DAY : In normal daylight conditions, the HLC is not activated.
- NIGHT : If a high light that is larger than a certain size is present on the
screen, remove the high light to see license plates clearly.
 
HLC : Enable a user to select a mask color of
high light area from a picture.
 
OFF : Not being used
HLCMASKINGAREA
HLCON HLCOFF
3. Select a desired mode using the Left and Right
buttons and press the SET button.
 
Select ‘BLC’ to adjust the area to be enhanced
and enhancement level.
•WhiteBalancemaynotworkproperlyunderthefollowingconditions.Inthiscaseselect
theAWCmode.
1When the color temperature of environment surrounding the subject is out of the
control range (e.g. clear sky, or sunset)
2When the ambient illumination of the subject is dim.
3
If the camera is directed towards a fluorescent light or is installed in a place where illumination
changes dramatically, the White Balance operation may become unstable.
Notes
This camera is designed so that it delivers a distinctive subject and background at
the same time, even when the subject is in backlight, unlike conventional cameras,
by adopting a proprietary SV-IV DSP chip.
1. When the SETUP menu screen is displayed, selectBACKLIGHTby using the
Up and Down buttons so that the arrow indicatesBACKLIGHT.
BACKLIGHT
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
BLCON BLCOFF
2. Select a desired mode using the Left and Right buttons depending on the camera purpose.
 
BLC : Enables a user to directly select a desired area from a picture, and to
view the area more clearly.

COLOR CCD CAMERA User’s Manual
26
COLOR CCD CAMERA User’s Manual
27
How to Use the Camera How to Use the Camera
•YoucannotsettheSSNRto‘ON’or‘OFF’whentheAGCmodeoftheEXPOSUREmenuis
‘OFF’.
•WhenadjustingthenoisereductionleveloftheSSNRmode,rememberthatthehigherthe
level set, the more the noise level will be reduced but that after image may also occur.
Notes
You can display pictures in color or black and white.
1. When the SETUP menu screen is displayed, selectDAY/NIGHTby using the Up
and Down buttons so that the arrow indicatesDAY/NIGHT.
DAY/NIGHT
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
6.DAY/NIGHT AUTO
7.IMAGE ADJ
2. Select a desired mode using the Left and Right buttons according to the picture
display you want.
 
COLOR :The picture is always displayed in color.
 
B/W :The picture is always displayed in black and white.
 
AUTO :The mode is switched to Color in a
normal environment, but switches to
B/W mode when ambient illumination
is low. To set up the sswitching time or
speed for AUTO mode, press the SET
button.
•BecausetherecanbeadifferenceintheeffectivenessofHLCaccordingtotheamountof
lightareainthescreen,optimizetheinstallationangleforthebestHLCperformance.
•Inadark environment,the HLCis only activatedwhen ahighlight thatislarger thana
certain area is present.
•TheHLCisnotactivatedinlightoroverlydarkconditions.
Notes
This function reduces the background noise in a low luminance environment.
1. When the SETUP menu screen is displayed, selectSSNRby using the Up and
Down buttons so that the arrow indicatesSSNR.
SSNR
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
6.DAY/NIGHT AUTO
2. Select a desired mode using the Left and Right buttons.
 
OFF : Deactivates SSNR. Noise is not reduced.
 
ON : Activates SSNR so that noise is reduced.
3. Set the SSNR mode toONand press the SET
button. Then you can adjust the noise reduction
level.

COLOR CCD CAMERA User’s Manual
28
COLOR CCD CAMERA User’s Manual
29
How to Use the Camera How to Use the Camera
1. When the SETUP menu screen is displayed, selectIMAGE ADJ.by using the
Up and Down buttons so that the arrow indicates IMAGE ADJ.
IMAGE ADJ.
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
6.DAY/NIGHT AUTO
7.IMAGE ADJ
8.SPECIAL
2. Select a desired mode using the Up and Down buttons.
IMAGE SETUP
1.V-REV OFF
2.H-REV OFF
3.D-ZOOM OFF
4.SHARPNESS ON
5.RETURN
 
V-REV :You can flip the picture vertically on the screen.
 
H-REV :You can flip the picture horizontally on the screen.
 
D-ZOOM : You can use a digital zoom of x2~x10.
 
EXTERN :This mode allows you to apply a desired filter to external signals.
- DWELL TIME : You can select the duration time about changing the day/night
mode. 5s, 7s, 10s, 15s, 20s, 30s, 40, 60s
- DURATION : You can select brightness of illumination about changing the day/
night mode.
* The brightness of illumination is changeable by
installed environment.
Color B/W B/W Color
Fast 2.5 lux 4 lux
Slow 0.8 lux 6 lux
•Whenusing aVideoAuto IrisLens,ifyou setthelensleveltolow,automaticswitching
betweenColorandBlack&Whitemaynotoccur.
• YoucannotcontroltheDAY/NIGHTmenuwhenAGCintheEXPOSUREmenuisOFF.
Atthistime,theexchangebetweenDAYmodeandNIGHTmodeoperatesaslikeselecting
COLORmode.
•The OSD key does not work for 3 seconds when switching to Color or B/W, to ensure
stable camera operation.
• The camera may focus less well under infrared illumination than under normal illumination.
•Sincethe cameramay notfocusaswellunderinfraredillumination atnight asitdoes
undernormalillumination,installanExtra-lowDispersionLenstoobtainsharppictures.
Notes

COLOR CCD CAMERA User’s Manual
30
COLOR CCD CAMERA User’s Manual
31
2. Select a desired mode using the Up and Down buttons.
How to Use the Camera How to Use the Camera
SPECIAL
1.CAM TITLE OFF
2.SYNC INT
3.MOTION DET OFF
4.PRIVACY OFF
5.DIS OFF
6.COMM ADJ
7.LANGUAGE ENGLISH
8.RESET
9.RETURN
 
CAM TITLE : If you enter a title, the title will appear on the monitor.
❶If the SPECIAL menu screen is displayed, use the Up and Down buttons so
that the arrow indicates ‘CAM TITLE’.
2Set it to ‘ON’ by using the Left and Right buttons.
･WhentheCAMTITLEmenuis･OFF･, no
title will be displayed on the monitor screen
even if you enter one.
Notes
•WhentheCAMTITLEmenuisOFF, no title
will be displayed on the monitor screen even if
you enter one.
•OnlyEnglishisavailableinthemode.
Notes
SPECIAL
1.CAM TITLE OFF
2.SYNC INT
3.MOTION DET OFF
4.PRIVACY OFF
5.DIS OFF
6.COMM ADJ
7.LANGUAGE ENGLISH
8.RESET
9.RETURN
 
SHARPNESS : As you increase this value, the
picture outline becomes stronger
and clearer. Adjust this value
appropriately depending on the
sharpness of the picture.
 
RETURN : Select this to save the settings for the IMAGE ADJ. menu and to
return to the SETUP menu.
0
•WhentheV-REVorH-REVmodeisenabled,thetextonthescreendoesnotflip.
• IfyouincreasetheSHARPNESSleveltoohigh,thepicturemaybecomedistortedornoisemay
appear.
Notes
1. When the SETUP menu screen is displayed, selectSPECIALby using the Up
and Down buttons so that the arrow indicatesSPECIAL.
SPECIAL
MAIN SETUP
1.LENS DC
2.EXPOSURE
3.WHITE BAL ATW
4.BACKLIGHT OFF
5.SSNR ON
6.DAY/NIGHT AUTO
7.IMAGE ADJ
8.SPECIAL
9.EXIT

COLOR CCD CAMERA User’s Manual
32
COLOR CCD CAMERA User’s Manual
33
How to Use the Camera How to Use the Camera
•WhenusingACpowerat60Hzfrequency,youcanusetheL/Ltypesynchronization.
•WhenthepowerisDC12V,theSYNC.menuisfixedtothe‘INT’mode.
•MDareasshowonlyMOTIONDETmenu.Therefore,MDareasdon’tdisplayonthe
monitor screen.
Notes
Notes
 
MOTION DET :
If you connect an alarm device to this camera,
you can monitor activity more efficiently,
because a signal is generated by the camera
whenever motion is detected. The motion
detection signal is output through the MD OUT
port.
❶When the SPECIAL menu screen is displayed, press the Up and Down
buttons so that the arrow indicates MOTION DET .
2Set up the mode using the 4 direction buttons.
- SENSITIVITY : You can select up to 8 MD areas. When SENSITIVITY number
is high, motion detection sensitivity is increased to recognize
even small movement.
- AREA MODE : Determines whether to use the MD area selected in
SENSITIVITY.
- SEL POS : Determines which of the 4 vertices of each MD area is to be
used.
- YPOS : Determines the coordinate of the vertical axis for SEL POS.
- XPOS : Determines the coordinate of the horizontal axis for SEL POS.
- FILLSET : Fills in a selected MD area. Fills in a selected MD area. The
color of filling is sequentially selected as brown, orange, blue,
cyan, yellowish green, yellow and red.
- RETURN : Select this to save the MOTION DET menu settings and return to
the SPECIAL menu.
3Press the SET button.
4 Use the 4 direction buttons to move
to a desired letter and select the letter
by pressing the SET button. Repeat
this to enter multiple letters. You can
enter up to 15 letters.
5 Enter a title, move the cursor to ’POS’ and
press the SET button. The entered title
appears on the screen. Select the position to
display the title on the screen by using the 4
direction buttons and press the SET button.
When the position is determined, select
’END’ and press the SET button to return to
the SPECIAL menu.
CAMERA TITLE SETUP
ABCDEFGHIJKLM
NOPQRSTUVWXYZ
abcdefghijklm
nopqrstuvwxyz
-.0123456789
CLR POS END
•IfyoumovethecursortoCLRandpresstheSETbutton,allthelettersaredeleted.Toedit
aletter,changethecursortothebottomleftarrowandpresstheSETbutton.Movethe
cursor over the letter to be edited, move the cursor to the letter to be inserted and then
presstheSETbutton.
Notes
FRONT DOOR
 
SYNC : In areas where the supply is at 60Hz,
you can synchronize the output phase
of multiple cameras using the power
synchronization function (Line-Lock)
without using a synchronization signal
generator.
- INT : Internal Synchronization Type
- L/L : Power Synchronization Type, Line-lock
• Press the SET button.
• You can select a desired phase from 0 to 359 when select 'phase'.
• You can decide the synchronization between luminance and color signal
when select the 'Mode' to TRACE.

COLOR CCD CAMERA User’s Manual
34
COLOR CCD CAMERA User’s Manual
35
How to Use the Camera
 
COMM ADJ (Communication Adjustment) :
This function sets up the camera communication
status when controlling the camera through an
external control device.
 
LANGUAGE : You can select the menu language according to your
requirements.
 
RESET : Resets the camera settings to the factory defaults. Communication
status and language is not initialized.
 
RETURN : Select this to save the SPECIAL menu settings and return to the
MAIN SETUP menu.
❶ When the SPECIAL menu screen is displayed, press the Up and Down
buttons so that the arrow indicates ‘COMM ADJ’.
2Set up the mode using the 4 direction buttons.
- CAM ID : Determines the camera's identification number (between 0 and
255).
- BAUD RATE : You can select 2400/4800/9600/19200/38400/57600 bps.
- UART MODE : You can select NONE, EVEN or ODD for the parity bits.
- RET PKT : Determines whether to send a command back to the controller
device when a communication control command is sent to the
camera.
- DISP CAM ID : Display camera title on top left corner of the screen.
Press the SET button in the EXIT menu to save the current settings and exit the MAIN SETUP
menu .
EXIT
•ThechanceofresolutiondecreaseisexistedbecauseDISfunctionusesthedigitalzoom.
•DISdoesn’toperatewhenbackgroundilluminationistoolow.
•DISdoesn’toperatewhenobjectpatternismonotonicaslikeskyorwhitewall.
•IfDISisenabled,thedigitalzoomisnotconfiguredtolessthan46level.
Notes
 
PRIVACY : Hide an area you want to hide on
the screen.
❶ When the SPECIAL menu screen is displayed,
press the Up and Down buttons so that the
arrow indicates ‘PRIVACY’.
2Set up the mode using the 4 direction
buttons.
- AREA SEL : You can select up to 8 PRIVACY
areas.
- AREA MODE :
Determines whether to use the area
selected in the AREA SEL, and the size and
position of the area.
 
DIS (Digital Image Stabilizer) :
This function mitigates any picture movement due to external factors such as
wind.
- MASK COLOR : Determine area color. You can select Gray, Green, Red,
Blue, Black, White.
- TRANSP : Determine the transparency of selected area as controlling
number from 0 to 3.
- RETURN : Select this to save the PRIVACY menu settings and return to the
SPECIAL menu.
How to Use the Camera

COLOR CCD CAMERA User’s Manual
36
COLOR CCD CAMERA User’s Manual
37
Specifications
SHC-737N SHC-737P
ELECTRICAL
Input Voltage AC 24V / DC 12V
Power Consumption 4.0W
VIDEO
Imaging Device 1/3" Super HAD CCD
Total Pixels 811(H) x 508(V) 795(H)x596(V)
Effective Pixels 768(H) x 494(V) 752(H)x582(V)
Scanning System 2:1 Interlace
Synchronization Internal / Line Lock
Frequency H : 15.734KHz / V : 59.94Hz H: 15.625KHz / V: 50.00Hz
Horizontal Resolution COLOR : 580TV lines (Min.) / B&W : 700TV lines (Min.)
Min. Illumination
COLOR : 0.05Lux (50 IRE , F1.2)
0.0002Lux (F1.2, SENS-UP)
B/W : 0.0025Lux (50 IRE, F1.2)
: 0.00001Lux (F1.2, SENS-UP)
S/N (Y Signal) 52dB (AGC Off, Weight On)
Video Output CVBS : 1.0Vp-p / 75Ω
OPERATIONAL
IRIS Adustment DC / VIDEO
Electronic Shutter Speed ESC (1/60(PAL : 1/50) ~ 1/120,000 sec) / MANUAL / A.FLK
On Screen Display Multi Language Available
Backlight Compensation BLC / HLC / OFF
Day & Night COLOR / B&W / AUTO (ICR)
Gain Control LOW / HIGH / OFF
White Balance ATW / AWC / MANUAL / INDOOR / OUTDOOR (1,700°K ~ 11,000°K)
SENS-UP (frame Integration) AUTO / OFF (x2 ~ x512)
Motion Detection ON / OFF (8 programmable zones , Alarm output)
Privacy Masking ON / OFF (8 programmable zones)
3D Noise Filter (SSNRII) ON / OFF (Level adjustable)
Digital Zoom ON / OFF (x2 ~ x10)
Digital Image Stabilization(DIS) ON / OFF
Camera Title ON / OFF
Sharpness ON / OFF
Flip / Mirror ON / OFF
Communication RS - 485 (Baudrate 2400, 4800, 9600, 19200, 38400, 57600bps selectable)
Protocol Samsung Techwin Protocol, Pelco-D Protocol
ENVIRONMENTAL
Operating Temperature / Humidity -10°C ~ +50°C / 30% ~ 80% RH
MECHANICAL
Lens Mount C / CS Mount (Easy Focus type)
Back Focus Adjustment Manual
Dimension 65.8(W)x60.6(H)x101.9(D)mm
Weight 315g
Troubleshooting
If you have trouble operating your camera, refer to the following table.
If the guidelines do not enable you to solve the problem, contact an authorized
technician.
* RS-485 Communication establishment initial value
Item Camera ID BAUD RATE UART MODE RET PKT
Initial value 19600 8-NONE-1 ENABLE
485 Control Board Connection Port RS-485 Control Port
(+) CONNECTION TERMINAL (TRX+) 485+
( - ) CONNECTION TERMINAL (TRX-) 485-
●
Nothing appears on the screen.
▶ Check that the power cord and line connection between the camera and monitor are fixed properly.
▶ Check that you have properly connected VIDEO cable to the camera VIDEO output jack.
▶ Check that the lens type is VIDEO lens or DC lens.
● The image on the screen is dim.
▶ Is lens stained with dirt? Clean your lens with soft, clean cloth.
▶ Set the monitor to proper condition.
▶ If the camera is exposed to too strong light, change the camera position.
● The image on the screen is dark.
▶ Adjust the contrast feature of the monitor.
▶ If you have an intermediate device, set the 75Ω / Hi-z properly.
● The camera is not working properly, and the surface of the camera is hot.
▶ Check that you have properly connected the camera to an appropriate power source.
● The DAY/NIGHT menu does not work.
▶ Check that AGC of EXPOSURE SETUP menu is ‘OFF’.
● The SENS-UP function does not work.
▶ Check that AGC of EXPOSURE SETUP menu is ‘OFF’.
▶ Check that SHUTTER of EXPOSURE SETUP menu is ‘A.FLK’ or ‘MANUAL’.
● The Motion Detection function does not work.
▶ Check that MOTION DEF of SPECIAL SETUP menu is ‘OFF’.
● Color is not correct.
▶ Check the setting of WHITE BAL SETUP menu .
● The screen flickers continually.
▶ Check that direction of camera turns toward the Sun.
● RS-485 communication fails.
▶ Check the polarity between RS-485 Control Port and RS-485 cable.
▶ Check the RS-485 Communication establishment initial value
▶ We recommend that you make ground connect between camera and controller in order to maintain
safety communication control.

COLOR CCD CAMERA User’s Manual
38
COLOR CCD CAMERA User’s Manual
39
DECLARATION OF CONFORMITY
ApplicationofCouncilDirective(s) 89/336/EEC
Manufacturer'sName SAMSUNGTECHWINCO.,LTD
Manufacturer'sAddress SAMSUNGTECHWINCO.,LTD
 42,SUNGJU-DONGCHANGWON-CITY,
 KYUNGNAM,KOREA,641-716
EuropeanRepresentativeName
EuropeanRepresentativeAddress
EquipmentType/Environment CCTVCamera
ModelName SHC-737P
BeginningSerialNO. C10S101000
YearofManufacture 2009.01.15
Conformanceto EN50081-1:1992
 EMC-Directive89/336EECand92/31/EEC
 EN50130-4:1996
We, the undersigned, hereby declare that the equipment specified above conforms
totheaboveDirective(s).
Manufacturer SAMSUNGTECHWINCO.,LTD LegalRepresentativeinEurope
Signature  Signature
FullName HANSEUGKIM FullName
Position QUALITYCONTROLMANAGER Position
Place CHANGWON,KOREA Place
Date 2009.01.15 Date
MEMO
