Samsung Galaxy Note PRO User manual

User Guide

TABLET
User Manual
Please read this manual before operating your device
and keep it for future reference.

i
Legal Notices
Legal Notices
Warning: This product contains chemicals known to
the State of California to cause cancer, birth defects, or
other reproductive harm. For more information, please
call 1-800-SAMSUNG (726-7864).
Intellectual Property
All Intellectual Property, as defined below, owned by
or which is otherwise the property of Samsung or its
respective suppliers relating to the SAMSUNG mobile
device, including but not limited to, accessories, parts,
or software relating there to (the “mobile device”), is
proprietary to Samsung and protected under federal
laws, state laws, and international treaty provisions.
Intellectual Property includes, but is not limited to,
inventions (patentable or unpatentable), patents, trade
secrets, copyrights, software, computer programs, and
related documentation and other works of authorship.
You may not infringe or otherwise violate the rights
secured by the Intellectual Property. Moreover,
you agree that you will not (and will not attempt to)
modify, prepare derivative works of, reverse engineer,
decompile, disassemble, or otherwise attempt to
create source code from the software. No title to or
ownership in the Intellectual Property is transferred to
you. All applicable rights of the Intellectual Property
shall remain with SAMSUNG and its suppliers.
Open Source Software
Some software components of this product, including
but not limited to ‘PowerTOP’ and ‘e2fsprogs’,
incorporate source code covered under GNU General
Public License (GPL), GNU Lesser General Public
License (LGPL), OpenSSL License, BSD License and
other open source licenses. To obtain the source code
covered under the open source licenses, please visit:
opensource.samsung.com
VZW_P905V_EN_UM_TN_OH1_100615_FINAL

ii
Legal Notices
Disclaimer of Warranties;
Exclusion of Liability
EXCEPT AS SET FORTH IN THE EXPRESS
WARRANTY CONTAINED ON THE WARRANTY
PAGE ENCLOSED WITH THE PRODUCT, THE
PURCHASER TAKES THE PRODUCT “AS IS”, AND
SAMSUNG MAKES NO EXPRESS OR IMPLIED
WARRANTY OF ANY KIND WHATSOEVER WITH
RESPECT TO THE PRODUCT, INCLUDING BUT
NOT LIMITED TO THE MERCHANTABILITY OF THE
PRODUCT OR ITS FITNESS FOR ANY PARTICULAR
PURPOSE OR USE; THE DESIGN, CONDITION OR
QUALITY OF THE PRODUCT; THE PERFORMANCE
OF THE PRODUCT; THE WORKMANSHIP OF THE
PRODUCT OR THE COMPONENTS CONTAINED
THEREIN; OR COMPLIANCE OF THE PRODUCT
WITH THE REQUIREMENTS OF ANY LAW, RULE,
SPECIFICATION OR CONTRACT PERTAINING
THERETO. NOTHING CONTAINED IN THE
INSTRUCTION MANUAL SHALL BE CONSTRUED
TO CREATE AN EXPRESS OR IMPLIED WARRANTY
OF ANY KIND WHATSOEVER WITH RESPECT TO
THE PRODUCT. IN ADDITION, SAMSUNG SHALL
NOT BE LIABLE FOR ANY DAMAGES OF ANY KIND
RESULTING FROM THE PURCHASE OR USE OF THE
PRODUCT OR ARISING FROM THE BREACH OF THE
EXPRESS WARRANTY, INCLUDING INCIDENTAL,
SPECIAL OR CONSEQUENTIAL DAMAGES, OR LOSS
OF ANTICIPATED PROFITS OR BENEFITS.
Modification of Software
SAMSUNG IS NOT LIABLE FOR PERFORMANCE
ISSUES OR INCOMPATIBILITIES CAUSED BY YOUR
EDITING OF REGISTRY SETTINGS, OR YOUR
MODIFICATION OF OPERATING SYSTEM SOFTWARE.
USING CUSTOM OPERATING SYSTEM SOFTWARE
MAY CAUSE YOUR DEVICE AND APPLICATIONS
TO WORK IMPROPERLY. YOUR CARRIER MAY
NOT PERMIT USERS TO DOWNLOAD CERTAIN
SOFTWARE, SUCH AS CUSTOM OS.
IF YOUR CARRIER PROHIBITS THIS, IF YOU
ATTEMPT TO DOWNLOAD SOFTWARE ONTO THE
DEVICE WITHOUT AUTHORIZATION, YOU WILL
BE NOTIFIED ON THE SCREEN THAT THE DEVICE
WILL NO LONGER OPERATE AND BE INSTRUCTED
TO POWER DOWN THE DEVICE. YOU MUST THEN
CONTACT YOUR CARRIER TO RESTORE THE DEVICE
TO THE CARRIER AUTHORIZED SETTINGS.

iii
Legal Notices
Samsung KNOX
Samsung KNOX™ is Samsung’s security platform and
is a mark for a Samsung device tested for security
with enterprise use in mind. Additional licensing fee
may be required. For more information about Knox,
please refer to: samsung.com/us/knox [030115]
Samsung Electronics America
(SEA), Inc.
Address:
85 Challenger Road
Ridgefield Park,
New Jersey 07660
Phone:
1-800-SAMSUNG (726-7864)
Internet Address:
samsung.com
©2015 Samsung Electronics America, Inc. Samsung
Galaxy, Multiwindow
TM, and KNOX are registered
trademarks of SamsungElectronics Co., Ltd.
Note: Screen images are simulated. Appearance of
device may vary.
Do you have questions about your
Samsung Mobile Device?
For 24 hour information and assistance, we offer a
new FAQ/ARS System (Automated Response System)
at: samsung.com/us/support.
The actual available capacity of the internal memory is
less than the specified capacity because the operating
system and default applications occupy part of the
memory. The available capacity may change when you
upgrade the device.
The Bluetooth®word mark, figure mark (stylized
“BDesign”), and combination mark (Bluetooth word
mark and “B Design”) are registered trademarks and
are wholly owned by the Bluetooth SIG.
microSD™ and the microSD logo are Trademarks of
the SD Card Association.

iv
Legal Notices
Google, the Google logo, Android, the Android logo,
Google Play, Gmail, Google Maps, Google Music,
Google Hangouts, Picasa, Play Newsstand, YouTube,
and other marks are trademarks of Google Inc.
Wi-Fi is a registered trademark of the Wireless Fidelity
Alliance, Inc.
Swype and the Swype logos are trademarks of Swype,
Inc.
Legal Information
Important legal information can be accessed in writing
on the mobile device or at samsung.com.
READ THIS INFORMATION BEFORE USING YOUR
MOBILE DEVICE.
Samsung Limited Warranty - This product is covered
under the applicable Samsung Limited Warranty,
including its dispute resolution procedure. Full
written terms and detailed information about the
warranty and obtaining service are available on
the device at: Settings > Aboutdevice > Legal
Information > Samsung legal or you may access the
online version of the Health/Safety and Warranty guide
for your device at samsung.com
The online version of the Health/Safety and Warranty
guide for your device can be found at:
English
samsung.com/us/Legal/Tablet-HSGuide
Spanish
samsung.com/us/Legal/Tablet-HSGuide-SP
Location of Legal Information on the device:
• Health and Safety Information
Settings > About device > Legal information >
Samsung legal > Health and Safety.
• Warranty
Settings > About device > Legal information >
Samsung legal > Warranty.
• End User License Agreement (EULA)
Settings > About device > Legal information >
Samsung legal > End User License Agreement.

v
Table of Contents
Table of Contents
Getting Started............................................................1
Front View........................................................................2
Back View........................................................................4
Assemble Your Device ..................................................6
Set Up Your Device .......................................................9
Set Up Accounts on Your Device .............................11
Know Your Device ...................................................12
Home Screen................................................................13
Status Bar......................................................................19
Navigation, Motions, and Gestures ..........................21
Notification Panel.........................................................24
Multi Window .................................................................27
S Pen..............................................................................31
Enter Text.......................................................................38
Applications.................................................................41
Apps List........................................................................42
Google Applications ....................................................46
Verizon Applications....................................................50
Other Applications.......................................................51
Alarm ..............................................................................54
Calculator ......................................................................56
Calendar ........................................................................57
Camera and Video.......................................................59
Chrome ..........................................................................65
Contacts .........................................................................66
Email...............................................................................72
Gallery............................................................................76
Internet ...........................................................................80
Music Player .................................................................83
My Files..........................................................................86
SNote ............................................................................89
S Voice...........................................................................91
Scrapbook.....................................................................92
Video Player..................................................................94
VerizonMessages........................................................97
World Clock ............................................................... 100
Settings....................................................................... 102
About Settings........................................................... 103
Airplane Mode ........................................................... 104
Wi-Fi Settings............................................................. 105
Bluetooth .................................................................... 109

vi
Table of Contents
Data Usage................................................................. 112
More Networks .......................................................... 114
Sound and Notification Settings............................ 121
Display Settings ........................................................ 124
Storage and Memory Card ..................................... 130
Power Saving Mode ................................................. 133
Battery......................................................................... 134
Application Manager ................................................ 135
Default Applications ................................................. 139
Users ........................................................................... 140
Location Settings...................................................... 142
Lock Screen .............................................................. 145
Security Settings ...................................................... 147
Language and Input Settings ................................. 151
Backup and Reset .................................................... 155
Accounts..................................................................... 157
Motions and Gestures.............................................. 159
Voice Control ............................................................. 160
S Pen Settings........................................................... 161
Accessories ............................................................... 162
Date and Time Settings ........................................... 163
Accessibility............................................................... 164
About Your Device .................................................... 167
Software Updates ..................................................... 168

Getting Started
This manual documents
default settings. If you select
other settings, steps may be
different.

2 Front View
Getting Started
Recent
Power key
Volume key
Front camera
Back
Light sensor
Memory
cardslot
SIM card slot
Home key
Front View

3 Front View
Getting Started
Here are some key features found on
the front of yourdevice.
• Light sensor: Detects the intensity of ambient
lighting.
• Front camera: Take pictures and record videos of
yourself.
• Memory card slot: Install an optional memory card
(not included) for storage of files.
• SIM card slot: Install the device’s SIM Card.
• Back: Tap to return to the previous screen, or to
close a dialog box, menu, or keyboard.
• Home key: Press to return to the Home screen.
• Recent: Tap to display recent apps or touch and
hold for Home screen options.
• Power key: Press and hold to turn the device on or
off. Press to lock or wake up the screen. Press and
hold to turn the device off or restart it, or for quick
access to Airplane mode.
• Volume key: Press to adjust the volume of your
device’s sounds.

4 Back View
USB charger/
Accessory port
Speaker
Flash
SPen
Speaker
Headset jack
Microphone
Infrared
transmitter
Rear camera
Back View
Getting Started

5 Back View
Getting Started
Here are some key features found on
the back of yourdevice.
•
USB charger/Accessory port: Connect the
Charger/USB cable (included), and other optional
accessories (not included).
• Flash: Illuminate subjects in low-light environments
when taking a photo or recording video.
• Infrared transmitter: Control external devices
using infrared transmissions. • SPen: Use the stylus to assist you in performing
various functions.
• Microphone: Record audio and detect voice
commands. • Rear camera: Take pictures and record videos.
• Headset jack: Connect an optional headset
(notincluded).
• Speaker: Play music and other sounds.

6 Assemble Your Device
Assemble Your Device
This section helps you to assemble
your device.
Optional: Replace the SIMCard
When you subscribe to a cellular network, you are
provided with a plug-in SIM card.
Warning: Please be careful when handling the SIM card
to avoid damaging it. Keep all SIM cards out of reach of
small children.
Caution: Exercise care when using the removal tool to
eject the internal SIM Card slot.
If you need to replace the SIM card:
1. With the tablet’s screen facing up, locate and open
the SIM card slot cover.
2. Carefully slide the SIM card into the SIM card slot
(as shown) until it clicks into place.
3. Close the SIM card slot cover.
• Make sure that the card’s gold contacts face
down into the device and that card is positioned
as shown.
Caution: If the card is not inserted correctly, the device
cannot detect the SIM card. Re-orient the card back into
the slot if the SIM is not detected.
Getting Started

7 Assemble Your Device
Getting Started
Install a Memory Card
You can use an optional microSD or microSDHC
memory card (not included) to expand available
memory space.
Note: A memory card can be installed at any time; it is
not necessary to install it prior to using the device.
For more information on installing a memory card, see
“Install a Memory Card” on page 131.
Charge the Battery
Your device is powered by a rechargeable, standard
Li-Ion battery. A Wall/USB Charger (charging head
and USB cable) is included with the device for
charging the battery from any standard outlet.
The battery comes partially charged. A fully
discharged battery requires up to four hours of charge
time. You can use the device while charging.
Caution: Use only Samsung-approved charging devices.
Samsung accessories are designed to maximize
battery life. Using other accessories may invalidate your
warranty and may cause damage.
1. Insert the USB cable into the port.
2. Connect the USB cable to the charging head, and
then plug the charging head into a standard outlet.
3. When charging is complete, unplug the charging
head from the outlet and remove the USBcable
from the device.

8 Assemble Your Device
Getting Started
( )
When to Charge the Battery
When the battery is weak and only a few minutes of
battery power remaining, the device sounds a warning
tone at regular intervals.
In this condition, your device conserves its remaining
battery power by dimming the screen.
When the battery level becomes too low, the device
automatically turns off.
►For a quick check of your battery level, glance at
the battery charge indicator located in the Status
bar of your device’s display. A solid color
indicates a full charge.
You can also choose to display a percentage value.
Having a percentage value can provide a better
idea of the remaining charge on the battery. For
more information, see “Battery” on page 134.

9 Set Up Your Device
Set Up Your Device
Turn Your Device On or Off
Turn the Device On
►Press and hold the Power key until the device
vibrates and starts up.
Turn the Device Off
1. Press and hold the Power key until the device
vibrates and the Tablet Options menudisplays.
2. At the prompt, tap POWER OFF.
Setup Wizard
The first time you turn your device on, Setup Wizard
guides you through the basics of setting up your
device.
Follow the prompts to choose a default language,
set up accounts, choose location services, and learn
more about your device.
Secure Your Device
Use your device’s screen lock features to secure
your device. To set a personal screen lock, use the
Screenlock option.
Lock the Device
By default, the device locks automatically when the
screen times out.
►To lock the device, press the Power key.
Unlock the Device
The default Screen lock on your device is Swipe.
►To unlock your device, press the Powerkey or
Home key, then touch and drag your finger across
the screen.
Getting Started

10 Set Up Your Device
Getting Started
Set Up a Secure Screen Lock
The default Screen lock is Swipe, which offers no
security. To choose a more secure screen lock, see
“Set a Screen Lock” on page 145.

11 Set Up Accounts on Your Device


Set Up Accounts on Your Device
Google Account
Your new device uses your Google Account to fully
utilize its Android features, including Gmail, Google
Hangouts, and the Google Play store. When you turn
on your device for the first time, set up a connection
with your existing Google Account, or create a new
Google Account.
To create a Google Account, or set up your Google
Account on your device, use Accounts settings. For
more information, see “Accounts” on page 157.
1. From a Home screen, tap Apps > Settings >
Accounts > Add account > Google.
2. Follow the prompts to set up your new or existing
Google Account.
Samsung Account
Create a Samsung account, for access to Samsung
content and apps on your device.
To create a Samsung account, or set up
your Samsung account on your device, use
Accounts settings. For more information, see
“Accounts” on page 157.
1. From a Home screen, tap Apps > Settings >
Accounts > Add account > Samsung account.
2. Follow the prompts to set up your new or existing
Samsung account.
Getting Started

Know Your Device
Warning: A touch screen responds best to
a light touch from the pad of your finger or a
non-metallic stylus. Using excessive force or
a metallic object when pressing on the touch
screen may damage the tempered glass
surface and void the warranty.
This section outlines some
key features of your device
and describes the screen and
icons as they appear when the
device is in use.
Learn how to navigate the
device and how to use special
features of this device.
